Fig. 39: Water Hose Test
Courtesy of GENERAL MOTORS CORP.

26. Use a soft spray of warm water in order to immediately water test the window.

27. Inspect the window for leaks.

28. If any leaks are found, use a plastic paddle in order to apply extra urethane adhesive at the leak point.

29. Retest the window for leaks.

IMPORTANT: Do not direct a hard stream of high pressure water to the freshly applied

urethane adhesive.

CAUTION: Insufficient curing of urethane adhesive may allow unrestrained

occupants to be ejected from the vehicle resulting in personal injury.

z

For the moisture-curing type of urethane adhesive, allow a
minimum of 6 hours at 21°C (70°F) or greater and with at least
30 percent relative humidity. Allow at least 24 hours for the
complete curing of the urethane adhesive.

z

For the chemical-curing type of urethane adhesive, allow a
minimum of 1 hour.





2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Stationary Windows - Hummer H2



30. Maintain the following conditions in order to properly cure the urethane adhesive:

z

Partially lower a door window in order to prevent pressure buildups when closing doors before the
urethane adhesive cures.

z

Do not drive the vehicle until the urethane adhesive is cured. Refer to the above curing times.

z

Do not use compressed air in order to dry the urethane adhesive.

REAR LIFT WINDOW REPLACEMENT

Tools Required

z

J 24402-A Glass Sealant Remover (Cold Knife). See Special Tools and Equipment .

z

J 39032 Stationary Glass Removal Tool. See Special Tools and Equipment .

z

J 34940 Rivet Gun

z

Urethane Adhesive Kit GM P/N 12346392 or Equivalent

z

Isopropyl Alcohol or Equivalent

z

Cartridge-type Caulking Gun

z

Commercial-type Utility Knife

z

Razor Blade Scraper

z

Suction Cups

z

Plastic Paddle

Removal Procedure

1. Remove the window garnish molding from the door frame.

Do NOT physically disturb the repair area until after these minimum
times have elapsed.

CAUTION: If a window is cracked but still intact, crisscross the window with

masking tape in order to reduce the risk of damage or personal
injury.

IMPORTANT: Before cutting out a window, apply a double layer of masking tape around

the perimeter of the painted surfaces and the interior trim.



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Stationary Windows - Hummer H2



Fig. 40: Electrical Connector & Window Defogger
Courtesy of GENERAL MOTORS CORP.

2. Disconnect the electrical connector from the window defogger on the window, if equipped.

CAUTION: Refer to Glass and Sheet Metal Handling Caution in Cautions and

Notices.



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Stationary Windows - Hummer H2



Fig. 41: Separating Urethane Adhesive From Quarter Window
Courtesy of GENERAL MOTORS CORP.

3. This will allow the urethane adhesive to be separated from the glass.

z

Leave a base of urethane on the pinchweld flange.

z

The only suitable lubrication is clear water.

z

Use J 24402-A ,. See Special Tools and Equipment .J 39032 or equivalent in order to remove the
liftgate window. See Special Tools and Equipment .

IMPORTANT: Keep the cutting edge of the tool against the glass.
