Front Passenger Door Module (FPDM) Terminal Identification - C5 Liftgate Ajar Terminal Identification Switch - Left Connector Part Information z 6383393-4 z 12-Way F AMP 0.64 mm Unsealed (GN) Pin Wire Color Circuit No. Function 1 YE - Low Heat Indicator Control 2 D-GN - High Heat Indicator Control 3 D-BU - Back Only Select 4 GY - Back and Cushion Select 5 - - Not Used 6 BN - Memory/Heated Seat Switch Supply Voltage 7 BK - Back Only Indicator Control 8 WH/BK - Medium Heat Indicator Control 9-11 - - Not Used 12 L-BU - Heated Seat Switch Backlight
2004 Hummer H2 2004 ACCESSORIES & EQUIPMENT Doors - Hummer H2
|
