Outside Rear View Mirror - Passenger (Front Passenger Door Module (FPDM) Terminal Identification - Connector Part Information z 6383393-5 z 10-Way F 0.64 mm Unsealed AMP (BK) Pin Wire Color Circuit No. Function 1 YE - Driver Folding Mirror Motor Extend Control 2 OG - Mirror Heating Element Supply Voltage 3 RD - Driver Mirror Horizontal Position Sensor Signal 4 D-GN - 5-Volt Reference 5 D-BU - Driver Mirror Vertical Position Sensor Signal 6 L-BU - Driver Folding Mirror Motor Retract Control 7 YE/WH - Driver Mirror Right/Down Motors Common 8 L-BU - Driver Mirror Motor Right Control 9 L-GN - Driver Mirror Motor Down Control 10 - - Not Used
2004 Hummer H2 2004 ACCESSORIES & EQUIPMENT Doors - Hummer H2
|
