Fig. 92: Radio
Courtesy of GENERAL MOTORS CORP.

15. Install the radio. Refer to Radio Replacement in Entertainment.



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Instrument Panel, Gauges, and Console - Hummer H2



Fig. 93: Onstar(R) Module
Courtesy of GENERAL MOTORS CORP.

16. Install the Onstar(R) module from center stack. Refer to OnStar Button Assembly Replacement in

Cellular Communication.



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Instrument Panel, Gauges, and Console - Hummer H2



Fig. 94: HVAC Control
Courtesy of GENERAL MOTORS CORP.

17. Install the HVAC control. Refer to HVAC Control Module Replacement in HVAC Systems -

Automatic.



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Instrument Panel, Gauges, and Console - Hummer H2



Fig. 95: I/P Upper Trim Pad
Courtesy of GENERAL MOTORS CORP.

18. Install the I/P upper trim pad. Refer to Trim Pad Replacement - Instrument Panel (I/P) Upper .



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Instrument Panel, Gauges, and Console - Hummer H2
