6. Install the lower HVAC air temperature sensors from the HVAC ducts. Refer to Air Temperature

Sensor Replacement - Lower Left and Air Temperature Sensor Replacement - Lower Right in
HVAC Systems - Automatic.

Fig. 84: Driver Knee Bolster
Courtesy of GENERAL MOTORS CORP.

7. Install the steering column. Refer to Steering Column Replacement in Steering Wheel and Column.



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Instrument Panel, Gauges, and Console - Hummer H2



Fig. 85: Knee Bolster Trim Panel
Courtesy of GENERAL MOTORS CORP.

8. Install the drivers knee bolster. Refer to Trim Panel Replacement - Knee Bolster .



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Instrument Panel, Gauges, and Console - Hummer H2



Fig. 86: I/P Air Bag Module
Courtesy of GENERAL MOTORS CORP.

9. Install the I/P air bag module. Refer to Inflatable Restraint Instrument Panel Module Replacement in

SIR.



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Instrument Panel, Gauges, and Console - Hummer H2



Fig. 87: I/P Compartment
Courtesy of GENERAL MOTORS CORP.

10. Install the I/P storage compartment. Refer to Compartment Replacement - Instrument Panel (I/P) .
