Hummer H2. Manual - part 284

4. Remove the fasteners retaining the speaker housing to the body.

Fig. 38: Front Speaker Assembly & I/P Carrier
Courtesy of GENERAL MOTORS CORP.

5. Partially remove the front speaker assembly from the I/P carrier.

6. Disconnect the electrical connector.



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Entertainment - Hummer H2



Fig. 39: Front Speaker Assembly Retainer Clips
Courtesy of GENERAL MOTORS CORP.

7. Remove the clips from front speaker assembly to expose speaker.

Installation Procedure



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Entertainment - Hummer H2



Fig. 40: Front Speaker Assembly Retainer Clips
Courtesy of GENERAL MOTORS CORP.

1. Install the retainer clips to the speaker housing.

NOTE:

Refer to Fastener Notice in Cautions and Notices.

IMPORTANT: Do not exceed torque specification over tightening of the screws will

result in the stud breaking from the front floor console.



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Entertainment - Hummer H2



Tighten: Tighten the screws to 9 N.m (80 lb in).

Fig. 41: Front Speaker Assembly & I/P Carrier
Courtesy of GENERAL MOTORS CORP.

2. Install the front speaker assembly woofer to the I/P carrier.

3. Install the fasteners.



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Entertainment - Hummer H2
