Fig. 74: Removing Cup Plug In Front Output Shaft (If Leaking)
Courtesy of GENERAL MOTORS CORP.

47. If the cup plug in the front output shaft is leaking, remove the plug using a brass drift.

2004 Hummer H2

2004 DRIVELINE/AXLE Transfer Case - BW 4484 - Hummer H2

Fig. 75: Removing Input Seal By Using Hammer & Punch
Courtesy of GENERAL MOTORS CORP.

48. Using a hammer and a suitable punch, remove the input seal.

2004 Hummer H2

2004 DRIVELINE/AXLE Transfer Case - BW 4484 - Hummer H2

Fig. 76: Removing Input Shaft Bearing From Front Case Half Using Hammer & Brass Drift
Courtesy of GENERAL MOTORS CORP.

49. Using a hammer and a brass drift, remove the input shaft bearing from the front case half.

2004 Hummer H2

2004 DRIVELINE/AXLE Transfer Case - BW 4484 - Hummer H2

Fig. 77: Removing Front Output Shaft Bearing From Front Case Half By Using Brass Drift
Courtesy of GENERAL MOTORS CORP.

50. Using a brass drift, remove the front output shaft bearing from the front case half.

2004 Hummer H2

2004 DRIVELINE/AXLE Transfer Case - BW 4484 - Hummer H2
