Hummer H2. Manual - part 1368

Fig. 85: C202 and C203 Component Views
Courtesy of GENERAL MOTORS CORP.

Callouts For Fig. 85

Callout

Component Name

1

Steering Column

2

C203

3

C202



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Wiring Systems - Hummer H2



Fig. 86: C210 Component Views
Courtesy of GENERAL MOTORS CORP.

Callouts For Fig. 86

Callout

Component Name

1

C210 Headliner Harness Side



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Wiring Systems - Hummer H2



Fig. 87: C298 Component Views
Courtesy of GENERAL MOTORS CORP.

Callouts For Fig. 87

Callout

Component Name

1

RH Cowl Panel

2

C298 - Body Harness Side



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Wiring Systems - Hummer H2



Fig. 88: C310 - LR Shown - RR Similar Component Views
Courtesy of GENERAL MOTORS CORP.

Callouts For Fig. 88

3

C298 - I/P Harness Side

Callout

Component Name

1

C310 - Body Harness Side

2

C310 - LR Door Harness Side

3

Passthrough Grommet

4

B Pillar
