111

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Electric Power
Steering (EPS)
System
Indicator

●

Comes on if there is a problem with the EPS
System.

●

Stays on constantly

 - Have your vehicle

checked by a dealer.

●

Do Not Drive displays on the driver
information interface

 - Immediately stop in a

safe place and contact a dealer.

2

If the Electric Power Steering (EPS) System
Indicator Comes On

 P. 596

Turn Signal and
Hazard
Warning
Indicators

●

Blinks when you operate the turn signal lever.

●

Blink along with all turn signals when you press
the hazard warning button.

●

Does not blink or blinks rapidly

2

Replacing Light Bulbs

 P. 530

●

Blink along with all turn signals when you
depress the brake pedal while the high speed
driving.

2

Emergency Stop Signal

 P. 480

High-Beam
Indicator

●

Comes on when the high beam headlights are
on.

—

Lights On
Indicator

●

Comes on when the position, tail, and other
external lights are on.

2

Lights

 P. 183

Front Fog Light
Indicator

*

●

Comes on when the front fog lights are on.

2

Fog Lights

 P. 187

* Not available on all models

112

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Rear Fog Light
Indicator

•

Comes on when the rear fog light is on.

2

Fog Lights

 P. 187

Low Tyre
Pressure/
Deflation
Warning
System
Indicator

•

May come on briefly if the power mode is set
to ON and the vehicle is not moved within 45
seconds, to indicate the initialisation process is
not yet complete.

•

Comes on and stays on when:

-

One or more tyres’ pressures are determined
to be significantly low.

-

The system has not been initialised.

•

Comes on while driving

- Stop in a safe

place, check tyre pressures, and inflate the
tyre(s) if necessary.

•

Stays on after the tyres are inflated to the
recommended pressures

- The system needs

to be initialised.

2

Deflation Warning System Calibration



P. 392

•

Blinks for about one minute, and then stays on
if there is a problem with the deflation warning
system.

•

Blinks and remains on

- Have your vehicle

checked by a dealer.

•

Comes on if the deflation warning system is
deactivated temporarily after the 12-volt
battery has been disconnected, then
reconnected.

•

Drive a short distance at more than 20 km/h
(12 mph). The indicator should go off. If it does
not, have your vehicle checked by a dealer.

113

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Auto High-
Beam Indicator

●

Comes on when all the operating conditions of
the auto high-beam are met.

2

Auto High-Beam

 P. 193

Immobilizer
System
Indicator

●

Blinks if the immobilizer system cannot
recognise the key information.

●

Blinks

 - You cannot start the engine. Set the

power mode to VEHICLE OFF, then select the
ON mode again.

Depress and hold the brake pedal before
setting the power mode to ON.

●

Repeatedly blinks

 - The system may be

malfunctioning. Have your vehicle checked by a
dealer.

●

Do not attempt to alter this system or add other
devices to it. Electrical problems can occur.

Security System
Alarm Indicator

●

Blinks when the security system alarm has been
set.

2

Security System Alarm

 P. 175

Indicator

Right-hand drive type

All models

Indicator

114

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

ECON

 Mode

Indicator

●

Comes on when you set the drive mode to

ECON

.

2

ECON Mode

 P. 373

SPORT

 Mode

Indicator

●

Comes on when you set the drive mode to

SPORT

.

●

The ambient meter remains lit up in red as long
as

SPORT

 mode is selected.

2

Drive Mode Switch

 P. 371

NORMAL



Mode Indicator

●

Comes on when you set the drive mode to

NORMAL

.

2

Drive Mode Switch

 P. 371

System
Message
Indicator

●

Comes on along with a beep when a problem
is detected. A system message on the driver
information interface appears at the same time.

●

While the indicator is on, press the

 (home)

button, and select

Information

 to see the

message again.

2

Switching the Display

 P. 135

●

Refer to the Indicators information in this
chapter when a system message appears on
the driver information interface. Respond to
the message accordingly.

●

The driver information interface does not
return to the normal screen unless the warning
is cancelled, or the

 (home) button is

pressed.

115

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Adjustable
Speed Limiter
Indicator
(White/Green)

•

Lights up in white when you press the



button.
If a different indicator comes on, subsequently
press the

LIM

 button.

•

Lights up in green when the adjustable speed
limiter is set.

2

Adjustable Speed Limiter

 P. 376

Intelligent
Speed Limiter
Indicator
(White/Green)

•

Lights up in white when you press the



button.
If a different indicator comes on, subsequently
press the

LIM

 button.

•

Lights up in green when you press the

RES/+



button or

SET/−

 button.

2

Intelligent Speed Limiter

 P. 382

 Hill Descent
Control System
Indicator
(White/Green)

•

Lights up in white when the hill descent control
system is on and ready to use.

•

Lights up in green when the hill descent
control system is in operation.

2

Hill Descent Control System

 P. 374

116

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Adaptive Cruise
Control (ACC)
with Low Speed
Follow Indicator
(Amber)

•

Comes on if there is a problem with ACC with
Low Speed Follow.

•

Comes on while driving

- Have your vehicle

checked by a dealer.

•

Comes on if the ACC with Low Speed Follow is
deactivated temporarily after the 12-volt battery
has been disconnected, then re-connected.

•

Drive a short distance at more than 20 km/h
(12 mph). The indicator should go off. If it does
not, have your vehicle checked by a dealer.

•

Indicator may come on temporarily when the
maximum permissible weight is exceeded.

•

ACC with Low Speed Follow has been
automatically cancelled.

•

Make sure the total load is within the
maximum permissible weight.

2

Load Limit

 P. 355

•

Stays on constantly

- Have your vehicle

checked by a dealer.

Adaptive Cruise
Control (ACC)
with Low Speed
Follow Indicator
(White/Green)

•

Lights up in white when you press the



button.
If a different indicator comes on, subsequently
press the

LIM

 button.

•

Lights up in green when you press the

RES/+



button or

SET/−

 button.

2

Adaptive Cruise Control (ACC) with Low
Speed Follow

 P. 423

Lane Keeping
Assist System
(LKAS)
Indicator
(Amber)

•

Comes on if there is a problem with the LKAS.

•

Stays on constantly

- Have your vehicle

checked by a dealer.

•

Indicator may come on temporarily when the
maximum permissible weight is exceeded.

•

Make sure the total load is within the
maximum permissible weight.

2

Load Limit

 P. 355

•

Stays on constantly

- Have your vehicle

checked by a dealer.

117

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Lane Keeping
Assist System
(LKAS)
Indicator
(White/Green)

•

Lights up in white when you press the LKAS
button.

•

Lights up in green when the LKAS is in
operation.

2

Lane Keeping Assist System (LKAS)

 P. 441

Road
Departure
Mitigation
Ready to Assist
Indicator

●

Comes on when all activation conditions for
the Road Departure Mitigation system are
satisfied and lane markers are detected.

2

Road Departure Mitigation System

 P. 453

Safety Support
Indicator
(Amber)

•

Comes on if there is a problem with Road
Departure Mitigation system, CMBS, Low
Speed Braking Control, or blind spot
information system

*

.

•

Stays on constantly

 - Have your vehicle

checked by a dealer.

•

Indicator may come on temporarily when the
maximum permissible weight is exceeded.

•

Make sure the total load is within the
maximum permissible weight.

2

Load Limit

 P. 355

•

Stays on constantly

 - Have your vehicle

checked by a dealer.

•

Comes on if the Road Departure Mitigation
system, CMBS, and Low Speed Braking Control
are deactivated temporarily after the 12-volt
battery has been disconnected and then re-
connected.

•

Drive a short distance at more than 20 km/h
(12 mph). The indicator should go off. If it does
not, have your vehicle checked by a dealer.

* Not available on all models

118

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Safety Support
Indicator
(Amber)

•

Comes on when the Road Departure
Mitigation system and/or CMBS shuts itself off.

•

Stays on

 - The temperature inside the camera

is too high.
Use the climate control system to cool down
the camera.
The system activates when the temperature
inside the camera cools down.

2

Front Wide View Camera

 P. 468

•

Stays on

 - The area around the camera is

blocked by dirt, mud, etc. Stop your vehicle in
a safe place and wipe the debris off with a soft
cloth.

•

Have your vehicle checked by a dealer if the
indicator and message are still displayed even
after you have cleaned the area around the
camera.

2

Front Wide View Camera

 P. 468

•

It may come on when the ambient conditions
are dark, such as when driving in a tunnel, or at
night, dawn, or dusk.

119

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Safety Support
Indicator
(Amber)

•

Comes on when mud, snow, or ice
accumulates in the vicinity of sonar.

●

Remove the obstacle in the vicinity of the sonar
sensor.

2

Low Speed Braking Control

 P. 417

●

Comes on when mud, snow, or ice
accumulates in the vicinity of the blind spot
information system sensor.

●

Comes on when the temperature of the blind
spot information system sensor is high.

●

Comes on while driving

- Something may be

interfering with the blind spot information
system sensor. Check the vicinity of the blind
spot information system sensor and remove
any obstacles.

●

The system will return to normal when the
temperature cools down.

2

Blind spot information System

*

 P. 394

Safety Support
Indicator
(Green/Grey)

•

Lights up in green when Road Departure
Mitigation system, CMBS, Low Speed Braking
Control, and blind spot information system

*



are on.

•

Lights up in green and grey when Road
Departure Mitigation system, CMBS, Low
Speed Braking Control, or blind spot
information system

*

, or any two or three of

these systems are off.

•

Lights up in grey when the Road Departure
Mitigation system, CMBS, Low Speed Braking
Control, and blind spot information system

*



are off.

2

Road Departure Mitigation system On and
Off

 P. 456

2

CMBS On and Off

 P. 409

2

Blind spot information System On and Off



P. 397

2

System On and Off

 P. 420

Models with blind spot information system

* Not available on all models

120

uu

Indicators

u

Driver Information Interface Warning and Information Messages

In

strum

e

nt Pa

nel

Driver Information Interface Warning and Information Messages

The warning and information messages appear only on the driver information interface. Press the

 (home) button, select

Information

,

then press the left selector wheel to see the message again with the system message indicator on.

Since messages will not display on the driver information interface when Warning Message is set to OFF, you can check the messages
below. Please take the appropriate action outlined in the message, such as contacting a dealer.

2

Red Icons

 P. 121

2

Amber Icons

 P. 122

2

Green Icons

 P. 127

2

Other Icons

 P. 128

Display messages by setting

Warning Message

 to ON. You can also change the message language.

2

Customized Features

 P. 305

■

Icons

121

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

■

Red Icons

Icon

Message

Critical System Failure Detected.
Stop Driving When Safe

Steering Assist Reduced.
Stop Driving When Safe.

Brake Performance Reduced.
Stop Driving When Safe.

Brake Fluid Low.
Check Fluid Level.

Parking Brake Engaged

Release Parking Brake

Cannot Set Cruise:
Parking Brake Is Applied

Cruise Cancelled:
Parking Brake Was Applied

Brake System Problem.
Brake Performance May Be Reduced.

Icon

Message

Brake System Problem.
Brake Performance May Be Reduced.

Fasten Seat Belt

Fasten Passenger’s Seat Belt

2

Seat Belt Reminder

 P. 47

12 Volt Battery Charging System Problem.
Do Not Drive.

Engine Oil Pressure Low.
Stop Engine.

2

If the Engine Oil Pressure Low Warning
Appears

 P. 593

uu

Indicators

u

Driver Information Interface Warning and Information Messages

122

In

strum

e

nt Pa

nel

Icon

Message

Engine Temperature Too Hot.
Allow Engine To Cool.

2

Overheating

 P. 591

Supplemental Restraint System Problem

Check Rear Seats

Steering Required

Lane Departure

Parking Sensor System Problem

■

Amber Icons

Icon

Message

Apply Parking Brake
To Keep Vehicle
Stationary

System Problem.
Shift To Park.

Shift To Park

2

Adaptive Cruise Control (ACC) with
Low Speed Follow

 P. 423

2

Collision Mitigation Braking System
(CMBS)

 P. 405

2

Low Speed Braking Control

 P. 417

Lane Departure

Temperature Too Low For Vehicle To
Operate

Please Wait While Vehicle Warms Up

123

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Icon

Message

2

Speed Alarm

 P. 144

Emissions System Problem.
Power May Be Reduced.

Emission System Problem.
Avoid Strong Acceleration And High Speed.

Emission System Problem.
Do Not Drive.

Engine Oil Level Low.
Check Engine Oil Level.

Engine Oil Level Low.
Check Engine Oil Level.

2

If the Engine Oil Level Low Warning
Appears

 P. 599

Engine Cooling System Problem.
Power May Be Reduced.

Fuel Gauge System Problem.
Level Not Accurate.

Icon

Message

Fuel Low

Transmission System Problem.
Performance May Be Reduced.

Transmission System Problem.
Do Not Drive.

Anti-Lock Brake System Problem.
Brake Performance May Be Reduced.

Brake System Problem.
Brake Performance May Be Reduced.

Brake System Problem.
Do Not Depress Brake + Accelerator
Together.

Brake System Problem.
Brake Performance May Be Reduced.

uu

Indicators

u

Driver Information Interface Warning and Information Messages

124

In

strum

e

nt Pa

nel

Icon

Message

Brake System Problem.
Brake Performance May Be Reduced.

Reduced Stopping Power.
Avoid Heavy Deceleration And High
Speed.

Electric Parking Brake System Problem.
Parking Brake Not Available.

Vehicle Stability Assist System Problem.
Traction And Handling May Be Reduced.

Drive Carefully.
Systems Initializing…

Hill Start Assist Problem.
Vehicle May Roll Upon Brake Release.

Hill Descent Control System Problem.
Apply Brake When Descending.

Icon

Message

Brake Hold System Problem.
Apply Brake When Stopped.

Apply Brake Pedal

Cruise Cancelled:
Depress Brake Pedal

To Release Parking Brake:
Brake + Push

Power Tailgate System Problem.
Operate Tailgate Manually.

Electric Power Steering System Problem.
Steering Assist Reduced.

Electric Power Steering System Problem.
No Steering Assist.
Do Not Drive.

Models with power tailgate

125

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Icon

Message

Automatic Lighting Control System
Problem.
Manual Controls Available.

Headlight System Problem.
Headlight Performance May Be Reduced.

Auto High-Beam Problem.
Manual Controls Available.

Keyless Remote Not Detected

Change Keyless Remote Battery

2

Replacing the Remote Battery

 P. 552

Icon

Message

Smart Entry System Problem

Digital Key System Problem

Carry Digital Key And Switch Vehicle OFF
When Exiting

Tyre Pressure Monitor System Problem

Tyre Pressures Low.
Check All Tyres And Initialise Deflation
Warning System

uu

Indicators

u

Driver Information Interface Warning and Information Messages

126

In

strum

e

nt Pa

nel

Icon

Message

Adaptive Cruise Control System Problem

Collision Mitigation Braking System
Problem

Low Speed Braking Control Problem.

Low Speed Braking Control Problem.
Parking Sensor Obstructed.

Lane Keeping Assist System Problem

Road Departure Mitigation System
Problem

Icon

Message

Service Due Soon

2

Service Reminder System

*

 P. 504

Service Due Now

2

Service Reminder System

*

 P. 504

Service Overdue

2

Service Reminder System

*

 P. 504

Blind Spot Information System Problem

Blind Spot Information Not Available

Models with service reminder system

Models with service reminder system

Models with service reminder system

Models with blind spot information system

Models with blind spot information system

* Not available on all models
