Honda CR-V Hybrid (2022 year). Manual in english

Honda Sensing

Collision Mitigation Braking System

(CMBS

)

510

Driving

Press and hold the button until the beeper
sounds to switch the system on or off.

When the CMBS

is off:

•

The CMBS

indicator in the instrument

panel comes on.

•

A message on the driver information
interface reminds you that the system is off.

The CMBS

is turned on every time you turn

the power system on, even if you turned it off
the last time you drove the vehicle.

■

CMBS

On and Off

Collision Mitigation Braking System

(CMBS

)

The CMBS

may automatically shut off, and the

CMBS

indicator will come and stay on under certain

conditions.

CMBS

Conditions and Limitations

P. 511

When the CMBS

is activated, it will continue to

operate even if the accelerator pedal is partially
depressed. However, it will be canceled if the
accelerator pedal is fully depressed.

The indicators for the Adaptive Cruise Control (ACC)
with Low Speed Follow, Road Departure Mitigation
(RDM), Vehicle Stability Assist

(VSA

) system,

Vehicle Stability Assist

(VSA

) OFF, low tire

pressure/TPMS, Collision Mitigation Braking System

(CMBS

), and Parking Brake and Brake System

(Amber) may come on along with a message in the
Driver Information Interface after reconnecting the
12V-battery. Drive a short distance at more than 12
mph (20 km/h). The indicator should go off. If it does
not, have your vehicle checked by a dealer.

Have your vehicle checked by a dealer if you find any
unusual behavior of the system (e.g. the warning
message appears too frequently).

511

Honda Sensing

Collision Mitigation Braking System

(CMBS

)

Continued

Driving

The system may automatically shut off and the CMBS

indicator will come on under

certain conditions. Some examples of these conditions are listed below. Other
conditions may reduce some of the CMBS

functions.

Front Sensor Camera

P. 548

Radar Sensor

P. 550

■

Environmental conditions

•

Driving in bad weather (rain, fog, snow, etc.).

•

Sudden changes between light and dark, such as an entrance or exit of a tunnel.

•

There is little contrast between objects and the background.

•

Driving into low sunlight (e.g., at dawn or dusk).

•

Strong light is reflected onto the roadway.

•

Driving in the shadows of trees, buildings, etc.

•

Roadway objects or structures are misinterpreted as vehicles and pedestrians.

•

Reflections on the interior of the front windshield.

•

Driving at night or in a dark place such as a tunnel (due to low-light conditions,
pedestrians or other vehicles may not be detected).

■

Roadway conditions

•

Driving on a snowy or wet roadway (obscured lane marking, vehicle tracks,
reflected lights, road spray, high contrast).

•

Driving on curvy, winding, or undulating roads.

•

The road is hilly or the vehicle is approaching the crest of a hill.

■

CMBS

Conditions and Limitations

512

Honda Sensing

Collision Mitigation Braking System

(CMBS

)

Driving

■

Vehicle conditions

•

Headlight lenses are dirty or the headlights are not properly adjusted.

•

The outside of the windshield is blocked by dirt, mud, leaves, wet snow, etc.

•

The inside of the windshield is fogged.

•

An abnormal tire or wheel condition (incorrect sizes, varied sizes or construction,
improperly inflated, etc.).

•

When tire chains are installed.

•

The vehicle is tilted due to a heavy load or suspension modifications.

•

The camera temperature gets too high.

•

Driving with the parking brake applied.

•

When the radar sensor in the front grille gets dirty.

•

Driving at night or in a dark place (e.g., a tunnel) with the headlights off.

513

Honda Sensing

Collision Mitigation Braking System

(CMBS

)

Continued

Driving

■

Detection limitations

•

A vehicle or pedestrian suddenly crosses in front of you.

•

The distance between your vehicle and the vehicle or pedestrian ahead of you is
too short.

•

A vehicle cuts in front of you at a slow speed, and it brakes suddenly.

•

When you accelerate rapidly and approach the vehicle or pedestrian ahead of you
at high speed.

•

The vehicle ahead of you is a motorcycle, bicycle, mobility scooter or other small
vehicle.

•

When there are animals in front of your vehicle.

•

When you drive on a curved, winding or undulating road that makes it difficult for
the sensor to properly detect a vehicle in front of you.

•

The speed difference between your vehicle and a vehicle or pedestrian in front of
you is significantly large.

•

An oncoming vehicle suddenly comes in front of you.

•

Another vehicle suddenly comes in front of you at an intersection, etc.

•

Your vehicle abruptly crosses over in front of an oncoming vehicle.

•

When driving through a narrow iron bridge.

•

When the lead vehicle suddenly slows down.

514

Honda Sensing

Collision Mitigation Braking System

(CMBS

)

Driving

•

When there is a group of people in front of your vehicle walking together side by
side.

•

Surrounding conditions or belongings of the pedestrian alter the pedestrian’s
shape, preventing the system from recognizing that the person is a pedestrian.

•

When the pedestrian is slouching or squatting.

•

When the pedestrian is shorter than about 3 feet (1 meter) or taller than about 7
feet (2 meter) in height.

•

When a pedestrian blends in with the background.

•

When a pedestrian is bent over or squatting, or when their hands or raised or they
are running.

•

When several pedestrians are walking ahead in a group.

•

When the camera cannot correctly identify that a pedestrian is present due to an
unusual shape (holding luggage, body position, size).

■

Automatic shutoff

CMBS

may automatically shut itself off and the CMBS

indicator comes and stays

on when:

•

The temperature inside the system is high.

•

You drive off-road or on a mountain road, or curved and winding road for an
extended period.

•

An abnormal tire condition is detected (incorrect tire size, flat tire, etc.).

•

The camera behind the rearview mirror, or the area around the camera, including
the windshield, gets dirty.

Once the conditions that caused CMBS

to shut off improve or are addressed (e.g.,

cleaning), the system comes back on.

Limitations applicable to pedestrian detection only

515

Honda Sensing

Collision Mitigation Braking System

(CMBS

)

Continued

Driving

The CMBS

may activate even when you are aware of a vehicle ahead of you, or

when there is no vehicle ahead. Some examples of this are:

■

When Passing

Your vehicle approaches another vehicle ahead of you and you change lanes to pass.

■

At an intersection

Your vehicle approaches or passes another vehicle that is making a left or right turn.

■

With Little Chance of a Collision

516

Honda Sensing

Collision Mitigation Braking System

(CMBS

)

Driving

■

On a curve

When driving through curves, your vehicle comes to a point where an oncoming
vehicle is right in front of you.

■

Through a low bridge at high speed

You drive under a low or narrow bridge at high speed.

■

Speed bumps, road work sites, train tracks, roadside objects, etc.

You drive over speed bumps, steel road plates, etc., or your vehicle approaches train
tracks or roadside objects (such as a traffic sign and guard rail) on a curve or, when
parking, stationary vehicles and walls.

517

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow

Continued

Driving

Adaptive Cruise Control (ACC) with Low Speed
Follow

Helps maintain a constant vehicle speed and a set following-interval behind a vehicle
detected ahead of yours and, if the detected vehicle comes to a stop, can decelerate
and stop your vehicle, without you having to keep your foot on the brake or the
accelerator.
When ACC with Low Speed Follow slows your vehicle by applying the brakes, your
vehicle’s brake lights will illuminate.

Adaptive Cruise Control (ACC) with Low Speed Follow

Important Reminder

As with any system, there are limits to ACC with Low
Speed Follow. Use the brake pedal whenever
necessary, and always keep a safe interval between
your vehicle and other vehicles.

For directions on the proper handling of the radar
sensor, refer to the following page.

Radar Sensor

P. 550

WARNING

Improper use of ACC with Low Speed
Follow can lead to a crash.

Use ACC with Low Speed Follow only
when driving on expressways or
freeways and in good road and weather
conditions.

WARNING

ACC with Low Speed Follow has limited
braking capability and may not stop
your vehicle in time to avoid a collision
with a vehicle that quickly stops in front
of you.

Always be prepared to apply the brake
pedal if the conditions require.

When to use

■

Vehicle speed for ACC with Low Speed Follow:

A vehicle is detected ahead

within ACC with Low Speed Follow range

– ACC with Low Speed Follow

operates at speeds up to 90 mph (145 km/h).

No vehicle is detected within ACC with Low Speed Follow range

– ACC with

Low Speed Follow operates at the speed of 25 mph (40 km/h) or above.

■

Shift position for ACC with Low Speed Follow: In

(

The radar sensor is

inside the front grille.

The camera is

located behind

the rearview

mirror.

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow

518

Driving

■

How to activate the system

Adaptive Cruise Control (ACC) with Low Speed Follow

You can read about handling information for the
camera equipped with this system.

Front Sensor Camera

P. 548

When the

MAIN

button is pressed, both ACC with

Low Speed Follow and the Lane Keeping Assist
System (LKAS) are either turned on or off.

ACC with Low Speed Follow may not work properly
under certain conditions.

ACC with Low Speed Follow Conditions
and Limitations

P. 524

When not using ACC with Low Speed Follow: Turn
off adaptive cruise by pressing the

MAIN

button. This

also will turn off the Lane Keeping Assist System
(LKAS).

Do not use ACC with Low Speed Follow under the
following conditions:

•

On roads with heavy traffic or while driving in
continuous stop and go traffic.

•

On roads with sharp turns.

•

On roads with steep downhill sections, as the set
vehicle speed can be exceeded by coasting. In such
cases, ACC with Low Speed Follow will not apply
the brakes to maintain the set speed.

•

On roads with toll collection facilities or other
objects between lanes of traffic, or in parking
areas, or facilities with drive through access.

How to use

■

Press the

MAIN

button on

the steering wheel.

ACC (green) is on in the
driver information
interface.

ACC with Low Speed

Follow is ready to use.

Continued

519

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

When driving at about 25 mph (40 km/h) or above:

Take your foot off the

pedal and press the

–/SET

button when you reach the desired speed. The moment

you release the button, the set speed is fixed, and ACC with Low Speed Follow
begins.

When driving slower than about 25 mph (40 km/h):

If the vehicle is moving

and the brake pedal is not depressed, pressing the button fixes the set speed to
about 25 mph (40 km/h) regardless of current vehicle speed. If the vehicle is
stationary, you can set the vehicle speed even with the brake pedal depressed.

■

To Set the Vehicle Speed

Adaptive Cruise Control (ACC) with Low Speed Follow

The indicators for the Adaptive Cruise Control (ACC)
with Low Speed Follow, Road Departure Mitigation
(RDM), Vehicle Stability Assist

(VSA

) system,

Vehicle Stability Assist

(VSA

) OFF, low tire

pressure/TPMS, Collision Mitigation Braking System

(CMBS

), and Parking Brake and Brake System

On when ACC with Low

Speed Follow begins

Press and release

−/SET

button

To Set the Vehicle Speed

You can switch the displayed set speed
measurements on the driver information interface

audio/information screen

between mph and km/h.

Customized Features

P. 140, 369

* Not available on all models

520

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

When ACC with Low Speed Follow starts
operating, the vehicle icon, distance bars and
set speed appear on the driver information
interface.

When you use ACC with Low Speed Follow,
Straight Driving Assist (a feature of the Electric
Power Steering system) is activated.
By enabling the steering system to
automatically compensate for natural steering
pull, Straight Driving Assist makes it easier for
you to keep your vehicle in a straight line.

Set Vehicle Speed

Set Vehicle Distance

Continued

521

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

■

There is a vehicle ahead

ACC with Low Speed Follow monitors if a vehicle ahead of you enters the ACC with
Low Speed Follow range. If a vehicle is detected doing so, the ACC with Low Speed
Follow system maintains or decelerates your vehicle’s set speed in order to keep the
vehicle’s set following-interval from the vehicle ahead.

To Set or Change Following-Interval

P. 528

When a vehicle whose speed is slower than
your set speed is detected in front of you, your
vehicle starts to slow down.

■

When in Operation

When in Operation

If the vehicle ahead of you slows down abruptly, or if
another vehicle cuts in front of you, a beeper sounds,
a message appears on the driver information
interface.

Depress the brake pedal, and keep an appropriate
interval from the vehicle ahead.

Beep

ACC with Low Speed Follow Range: 394 ft. (120 m)

A vehicle icon appears on the

driver information interface

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow

522

Driving

■

There is no vehicle ahead

Your vehicle maintains the set speed without
having to keep your foot on the brake or
accelerator pedal.
If there previously was a vehicle detected
ahead that kept your vehicle from traveling at
the set speed, ACC with Low Speed Follow
accelerates your vehicle to the set speed, and
then maintains it.

■

When you depress the accelerator pedal

You can temporarily increase the vehicle speed. In this case, there is no audible or
visual alert even if a vehicle is in the ACC with Low Speed Follow range.
ACC with Low Speed Follow stays on unless you cancel it. Once you release the
accelerator pedal, the system resumes an appropriate speed for keeping the
following-interval while a vehicle ahead is within the ACC with Low Speed Follow
range.

When in Operation

Even if the distance between your vehicle and the
vehicle ahead is short, ACC with Low Speed Follow
may start accelerating your vehicle under the
following circumstances:

•

The vehicle ahead of you is going at almost the
same speed as, or faster than, your vehicle.

•

A vehicle that cuts in front of you is going faster
than your vehicle, gradually increasing the interval
between the vehicles.

You can also set the system to beep when a vehicle in
front of you comes in and goes out of the ACC with
Low Speed Follow detecting range. Change the

ACC

Forward Vehicle Detect Beep

setting.

Customized Features

P. 140, 369

Limitations

You may need to use the brake to maintain a safe
interval when using ACC with Low Speed Follow.
Additionally, ACC with Low Speed Follow may not
work properly under certain conditions.

ACC with Low Speed Follow Conditions
and Limitations

P. 524

A vehicle icon with dotted-line

contour appears on the driver

information interface

Continued

523

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow

Driving

■

A vehicle detected ahead is within ACC with Low Speed Follow range and
slows to a stop

Your vehicle also stops, automatically. The

Stopped

message appears on the driver

information interface.
When the vehicle ahead of you starts again,
the vehicle icon on the driver information
interface blinks. If you press the

RES/+

–/

SET

button, or depress the accelerator pedal,

ACC with Low Speed Follow operates again
within the prior set speed.
If no vehicle is ahead of you before you
resume driving, depressing the accelerator
pedal will resume operation of ACC with Low
Speed Follow within the prior set speed.

A vehicle detected ahead is within ACC with Low Speed Follow
range and slows to a stop

WARNING

Exiting a vehicle that has been stopped
while the ACC with Low Speed Follow
system is operating can result in the
vehicle moving without operator
control.

A vehicle that moves without operator
control can cause a crash, resulting in
serious injury or death.

Never exit a vehicle when the vehicle is
stopped by ACC with Low Speed Follow.

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow

524

Driving

The system may automatically shut off under certain conditions. Some examples of
these conditions are listed below. Other conditions may reduce some of the ACC
functions.

Front Sensor Camera

P. 548

Radar Sensor

P. 550

■

Environmental conditions

•

Driving in bad weather (rain, fog, snow, etc.).

■

Roadway conditions

•

Driving on a snowy or wet roadway (obscured lane marking, vehicle tracks,
reflected lights, road spray, high contrast).

■

Vehicle conditions

•

The outside of the windshield is blocked by dirt, mud, leaves, wet snow, etc.

•

An abnormal tire or wheel condition (incorrect sizes, varied sizes or construction,
improperly inflated, etc.).

•

The camera temperature gets too high.

•

The parking brake is applied.

•

When the front grille is dirty.

•

The vehicle is tilted due to a heavy load or suspension modifications.

•

When tire chains are installed.

■

ACC with Low Speed Follow Conditions and Limitations

ACC with Low Speed Follow Conditions and Limitations

The radar sensor for ACC with Low Speed Follow is
shared with the collision mitigation braking system

(CMBS

Collision Mitigation Braking System

(CMBS

)

P. 506

If you need the radar sensor to be repaired, or
removed, or the radar sensor cover is strongly
impacted, turn off the system by pressing the

MAIN

button and take your vehicle to a dealer.

Have your vehicle checked by a dealer if you find any
unusual behavior of the system (e.g., the warning
message appears too frequently).

If the front of the vehicle is impacted in any of the
following situations, the radar sensor may not work
properly. Have your vehicle checked by a dealer:

•

The vehicle mounted onto a bump, curb, chock,
embankment, etc.

•

You drive the vehicle where water is deep.

•

Your vehicle has a frontal collision.

525

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow

Continued

Driving

■

Detection limitations

•

A vehicle or pedestrian suddenly crosses in front of you.

•

The interval between your vehicle and the vehicle or pedestrian ahead of you is
too short.

•

A vehicle cuts in front of you at a slow speed, and it brakes suddenly.

•

When you accelerate rapidly and approach the vehicle or pedestrian ahead of you
at high speed.

•

The vehicle ahead of you is a motorcycle, bicycle, mobility scooter, or other small
vehicle.

•

When there are animals in front of your vehicle.

•

When you drive on a curved or winding or undulating road that makes it difficult
for the sensor to properly detect a vehicle or a pedestrian in front of you.

•

The speed difference between your vehicle and a vehicle or pedestrian in front of
you is significantly large.

•

An oncoming vehicle suddenly comes in front of you.

•

Your vehicle abruptly crosses over in front of an oncoming vehicle.

Honda CR-V Hybrid (2022 year). Manual in english - page 32
