Honda CR-V (2022 year). Manual in english

Honda Sensing

Adaptive Cruise Control (ACC)

590

Driving

■

There is no vehicle ahead

Your vehicle maintains the set speed without
having to keep your foot on the brake or
accelerator pedal.
If there previously was a vehicle detected
ahead that kept your vehicle from travelling at
the set speed, ACC accelerates your vehicle to
the set speed, and then maintains it.

■

When you depress the accelerator pedal

You can temporarily increase the vehicle speed. In this case, there is no audible or
visual alert even if a vehicle is in the ACC range.
ACC stays on unless you cancel it. Once you release the accelerator pedal, the
system resumes an appropriate speed for keeping the following-interval while a
vehicle ahead is within the ACC range.

When in Operation

Even if the interval between your vehicle and the
vehicle detected ahead is short, ACC may start
accelerating your vehicle under the following
circumstances:

•

The vehicle ahead of you is going at almost the
same speed as, or faster than, your vehicle.

•

A vehicle that cuts in front of you is going faster
than your vehicle, gradually increasing the interval
between the vehicles.

You can also set the system to beep when a vehicle
detected in front of you comes in and goes out of the
ACC detecting range. Change the

ACC Vehicle

Ahead Detected Beep

setting.

Customized Features

P. 157, 408

Limitations

You may need to use the brake to maintain a safe
interval when using ACC. Additionally, ACC may not
work properly under certain conditions.

ACC Conditions and Limitations

P. 591

A vehicle icon with dotted-line
contour appears on the driver
information interface

Continued

591

Honda Sensing

Adaptive Cruise Control (ACC)

Driving

The system may automatically shut off and the

ACC

indicator will come on under

certain conditions. Some examples of these conditions are listed below. Other
conditions may reduce some of the ACC functions.

Front Sensor Camera

P. 623

■

Environmental conditions

Driving in bad weather (rain, fog, snow, etc.).

■

Roadway conditions

Driving on a snowy or wet roadway (obscured lane marking, vehicle tracks, reflected
lights, road spray, high contrast).

■

Vehicle conditions

•

The outside of the windscreen is blocked by dirt, mud, leaves, wet snow, etc.

•

An abnormal tyre or wheel condition (Wrong sized, varied size or construction,
improperly inflated, compact spare tyre, etc.).

•

The camera temperature gets too high.

•

The parking brake is applied.

•

When the front grille is dirty.

•

The vehicle is tilted due to a heavy load or suspension modifications.

•

When tyre chains are installed.

■

ACC Conditions and Limitations

ACC Conditions and Limitations

For directions on the proper handling of the radar
sensor, refer to the following page.

Radar Sensor

P. 625

You can read about handling information for the
camera equipped with this system.

Front Sensor Camera

P. 623

If you need the radar sensor to be repaired, or
removed, or the radar sensor cover is strongly
impacted, turn off the system by pressing the

MAIN

button and take your vehicle to a dealer.

592

Honda Sensing

Adaptive Cruise Control (ACC)

Driving

■

Detection limitations

•

A vehicle suddenly crosses in front of you.

•

The interval between your vehicle and the vehicle ahead of you is too short.

•

A vehicle cuts in front of you at a slow speed, and it brakes suddenly.

•

When you accelerate rapidly and approach the vehicle ahead of you at high
speed.

•

The vehicle ahead of you is a motorcycle, bicycle, mobility scooter, or other small
vehicle.

•

When there are animals in front of your vehicle.

•

When you drive on a curved or winding or undulating road that makes it difficult
for the sensor to properly detect a vehicle in front of you.

•

The speed difference between your vehicle and a vehicle in front of you is
significantly large.

•

An oncoming vehicle suddenly comes in front of you.

•

Your vehicle abruptly crosses over in front of an oncoming vehicle.

593

Honda Sensing

Adaptive Cruise Control (ACC)

Continued

Driving

•

When driving through a narrow iron bridge.

•

When the vehicle ahead of you brakes suddenly.

•

When the vehicle ahead of you has a unique shape.

•

When your vehicle or the vehicle ahead of you is driving on one edge of the lane.

Radar detects upper section of
an empty carrier lorry.

Panel lorry,
tanker lorry,
etc.

Honda Sensing

Adaptive Cruise Control (ACC)

594

Driving

Increase or decrease the vehicle speed using the

RES/+

–/SET

buttons on the

steering wheel.

•

Each time you press the

RES/+

–/SET

button, the vehicle speed is increased or

decreased by about 1 km/h or 1 mph accordingly.

•

If you keep the

RES/+

–/SET

button pressed, the vehicle speed increases or

decreases by about 10 km/h or 10 mph accordingly.

■

To Adjust the Vehicle Speed

To Adjust the Vehicle Speed

If a vehicle detected ahead is going at a speed slower
than your increased set speed, ACC may not
accelerate your vehicle. This is to maintain the set
interval between your vehicle and the vehicle ahead.

When you depress the accelerator pedal and then
push and release the

–/SET

button, the current speed

of the vehicle is set.

To increase speed

To decrease speed

595

Honda Sensing

Adaptive Cruise Control (ACC)

Continued

Driving

Press the (interval) button to change ACC
following-interval.
Each time you press the button, the following-
interval (the interval behind a vehicle detected
ahead of you) setting cycles through short,
middle, long and extra long following-
intervals.

Determine the most appropriate following-
interval setting based on your specific driving
conditions. Be sure to adhere to any
following-interval requirements set by local
regulation.

■

To Set or Change Following-interval

Interval Button

Honda Sensing

Adaptive Cruise Control (ACC)

596

Driving

The higher your vehicle’s following-speed is, the longer the short, middle, long or
extra long following-interval becomes. See the following examples for your
reference.

Following-interval

When the Set Speed is:

80 km/h (50 mph)

104 km/h (65 mph)

Short

25.4 metres

83.3 feet

1.1 sec

30.6 metres

100.4 feet

1.1 sec

Middle

33.4 metres

109.6 feet

1.5 sec

41.9 metres

137.4 feet

1.5 sec

Long

46.9 metres

153.8 feet

2.1 sec

60.9 metres

199.8 feet

2.1 sec

Extra
Long

65.1 metres

213.5 feet

2.9 sec

86.2 metres

282.7 feet

2.9 sec

To Set or Change Following-interval

The driver must in all circumstances preserve a
sufficient braking interval from the vehicle which
precedes it and be aware that minimum intervals or
times of spacing can be provided by the provisions of
the Motorway Code locally applicable and that it is
the driver’s responsibility to respect those laws.

Continued

597

Honda Sensing

Adaptive Cruise Control (ACC)

Driving

To cancel ACC, do any of the following:

•

Press the

CANCEL

button.

•

Press the

MAIN

button.

ACC indicator (green) goes off.

•

Press the

LIM

button.

•

Depress the brake pedal.

•

Depress the clutch pedal for five seconds or
more.

■

To Cancel

To Cancel

Resuming the prior set speed: After you have
cancelled ACC, you can resume the prior set speed
while it is still displayed. Press the

RES/+

button

when driving at a speed of at least 30 km/h (18 mph)
or more.

The set speed cannot be set or resumed when ACC
has been turned off using the

MAIN

button. Press

the

MAIN

button to activate the system, then set the

desired speed.

MAIN

Button

LIM

Button

CANCEL

Button

Honda Sensing

Adaptive Cruise Control (ACC)

598

Driving

■

Automatic cancellation

The beeper sounds and a message appears on the driver information interface when
ACC is automatically cancelled. Any of these conditions may cause the ACC is
automatically cancelled.

•

Bad weather (rain, fog, snow, etc.)

•

When the radar sensor in the front grille gets dirty.

•

The vehicle ahead of you cannot be detected.

•

An abnormal tyre condition is detected, or the tyres are skidding.

•

Driving on a mountainous road, or driving off road for extended periods.

•

Abrupt steering wheel movement.

•

When the ABS, VSA or CMBS is activated.

•

When the ABS or VSA system indicator comes on.

•

When you manually apply the parking brake.

•

When the detected vehicle within the ACC range is too close to your vehicle.

•

The camera behind the rearview mirror, or the area around the camera, including
the windscreen, gets dirty.

•

When the Maximum Load Limit is exceeded.

•

When passing through an enclosed space, such as tunnel.

•

Ignoring shift down indication shown under the tachometer will cancel the ACC
after about 10 seconds.

•

The engine speed goes into the tachometer’s red zone.

•

The engine speed goes to below 1,000 rpm.

•

You shift into neutral temporarily when shifting into a higher or lower gear.

Automatic cancellation

Even though ACC has been automatically cancelled,
you can still resume the prior set speed. Wait until the
condition that caused ACC to cancel improves, then
press the

–/SET

button.

599

Honda Sensing

Adaptive Cruise Control (ACC)

Continued

Driving

Provides an early prediction for a cut-in situation. The system detects that a vehicle
running in the adjacent slower lane has an intention to cut in front of you and
adjusts the speed of your vehicle in advance while ACC is activated.

■

How the system works

■

Intelligent Adaptive Cruise Control Function

The radar sensor in the front grille detects
vehicles ahead of you including those in the
adjacent lane, and the camera behind the
rearview mirror detects the lane markings.

This system improves ACC’s following/tracking
property; it adjusts your vehicle speed in
advance predicting a situation that a vehicle
running in the adjacent slower lane catches up
with a slower vehicle ahead of it and changes
the lane to cut in front of you early.
When such a cut-in situation is predicted, your
vehicle speed decreases a little. When
detected, your vehicle speed decreases
according to the vehicle cutting in front of
you.

As the speed is adjusted by the system, the cut
in vehicle icon appears on the driver
information interface to indicate that the
system is activated.

Slow
Vehicle

Cut-in
Vehicle

Your
Vehicle

Left-hand drive type is shown.

Honda Sensing

Adaptive Cruise Control (ACC)

600

Driving

■

How the system activates

When a vehicle cuts in front of you is going faster than the vehicle ahead of it, and
your vehicle is going faster than the cut-in vehicle (i.e., when you need to slow
down), ACC predicts the cutting-in and adjust your vehicle speed.

The system activates when all the following conditions are met:

•

When ACC is activated.

•

When you are driving on a multi-lane road.

•

When your vehicle speed is between about 80 km/h (50 mph) and about 180
km/h (112 mph).

•

The vehicle is on a straight or slightly curved road.

•

The turn signals are off.

•

The brake pedal is not depressed.

•

When a vehicle cuts in from a slower lane.

■

Intelligent adaptive cruise control on and off

You can turn the system on and off using the driver information interface.

Customized Features

P. 157, 408

Intelligent Adaptive Cruise Control Function

When traffic changes from right hand side to left
hand side, driving on a road where there is oncoming
traffic for some distance automatically switches the
lane to be detected from right to left.

Intelligent adaptive cruise control may not activate
under the following conditions:

•

When the speed difference between the cut-in
vehicle and the vehicle ahead of it in the adjacent
lane is small

•

When the speed difference between the cut-in
vehicle and your vehicle is small (i.e., when speed
adjustment is not required)

•

When a vehicle simply cuts in front of your vehicle
with no vehicle ahead in the adjacent lane

•

When a vehicle cuts in from a faster lane

601

Honda Sensing

Lane Keeping Assist System (LKAS)

Continued

Driving

Lane Keeping Assist System (LKAS)

Provides steering input to help keep the vehicle in the middle of a detected lane and
provides tactile, audible and visual alerts if the vehicle is detected drifting out of its
lane.

Lane Keeping Assist System (LKAS)

Important Safety Reminders

The LKAS is for your convenience only. It is not a
substitute for your vehicle control. The system does
not work if you take your hands off the steering
wheel or fail to steer the vehicle.

Driver Information Interface Warning and
Information Messages

P. 122

Do not place objects on the instrument panel.
Objects may reflect on the front windscreen and
prevent correct detection of the traffic lanes.

The LKAS only alerts you when lane drift is detected
without a turn signal in use. The LKAS may not detect
all lane markings or lane departures; accuracy will
vary based on weather, speed, and lane marker
condition.
It is always your responsibility to safely operate the
vehicle and avoid collisions.

The LKAS is convenient when it is used on motorways
or a dual carriage way.

The LKAS may not work properly or may work
improperly under the certain conditions:

LKAS Conditions and Limitations

P. 606

You can read about handling information for the
camera equipped with this system.

Front Sensor Camera

P. 623

When you operate the turn signals to change lanes, the system is suspended, and
resumes after the signals are off.
If you make a lane change without operating the turn signals, the LKAS alerts
activate, and torque is applied to the steering.

■

Front sensor

camera

Monitors the
lane lines

■

Steering input assist

The system applies torque to the
steering to keep the vehicle between
the left and right lane lines. The applied
torque becomes stronger as the vehicle
gets closer to either of the lane lines.

■

Tactile, audible and visual alerts

Rapid vibrations on the steering wheel, audible and a warning display alert you
that the vehicle is drifting out of a detected lane.

Honda Sensing

Lane Keeping Assist System (LKAS)

602

Driving

Provides assistance to keep the vehicle in the centre of the lane, when the vehicle
nears a white or yellow line, steering force of the electric power steering will become
stronger.

When the vehicle enters the warning area, the LKAS alerts you with slight steering
wheel vibration, and audible and visual warnings.

■

Lane Keep Support Function

Lane Keeping Assist System (LKAS)

The LKAS may not function as designed while driving
in frequent stop and go traffic, or on roads with
sharp curves.

When it fails to detect lanes, the system will
temporarily be cancelled. When lane is detected,
system will recover automatically.

■

Lane Departure Warning Function

Warning Area

Continued

603

Honda Sensing

Lane Keeping Assist System (LKAS)

Driving

The system can be used when the following conditions are met.

•

The lane in which you are driving has detectable lane markers on both sides, and
your vehicle is in the centre of the lane.

•

The vehicle is travelling between about 72 and 185 km/h (45 and 115 mph).

•

You are driving on a straight or slightly curved road.

•

The turn signals are off.

•

The brake pedal is not depressed.

•

The wipers are not in high speed operation.

■

How to activate the system

Press the

MAIN

button.

The LKAS is on in the driver information
interface.
The system is ready to use.

Press the LKAS button.

Lane outlines appear on the driver
information interface.
The system is activated.

■

When the System can be Used

When the System can be Used

If the vehicle drifts towards either left or right lane
line due to the system applying torque, turn off the
LKAS and have your vehicle checked by a dealer.

MAIN

Button

LKAS
Button

Honda Sensing

Lane Keeping Assist System (LKAS)

604

Driving

Keep your vehicle near the centre of the
lane while driving.

The dotted outer lines change to solid
ones once the system starts operating
after detecting the left and right lane
markings.

To cancel the LKAS:
Press the

MAIN

or LKAS button.

The LKAS is turned off every time you stop the
engine, even if you turned it on the last time
you drove the vehicle.

■

To Cancel

To Cancel

Pressing the

MAIN

button also turns ACC with LSF

on and off.

Pressing the

MAIN

button also turns ACC on and off.

Models with ACC with LSF

Models with ACC

LKAS Button

MAIN

Button

605

Honda Sensing

Lane Keeping Assist System (LKAS)

Continued

Driving

■

The system operation is suspended if
you:

•

Set the wipers to

Turning the wipers off or setting it to

resumes the LKAS.

•

Set the wiper switch to

AUTO

and the

wipers operate at high speed.

The LKAS resumes when the wipers stop
or operate at low speed.

•

Decrease the vehicle speed to 64 km/h (40
mph) or less.

Increasing the vehicle speed to 72 km/h
(45 mph) or more resumes the LKAS.

•

Depress the brake pedal.

The LKAS resumes and starts detecting
the lane lines again once you release the
brake pedal.

■

The LKAS may automatically be suspended when:

•

The system fails to detect lane lines.

•

The steering wheel is quickly turned.

•

You fail to steer the vehicle.

•

Driving through a sharp curve.

•

Driving at a speed in excess of approximately 185 km/h (115 mph).

•

The Road Departure Mitigation System is activated.

Once these conditions no longer exist, the LKAS automatically resumes.

When the LKAS is suspended,
the lane lines on the driver
information interface change
to contour lines, and the
beeper sounds (if activated).

Models with automatic intermittent wipers

All models

Honda CR-V (2022 year). Manual in english - page 37
