Honda Sensing

Collision Mitigation Braking System (CMBS)

Driving

Collision Mitigation Braking System (CMBS)

Can assist you when there is a possibility of your vehicle colliding with a vehicle or a
pedestrian detected in front of yours. The CMBS is designed to alert you when a
potential collision is determined, as well as to reduce your vehicle speed to help
minimize collision severity when a collision is deemed unavoidable.

Collision Mitigation Braking System (CMBS)

Important Safety Reminder

The CMBS is designed to reduce the severity of an
unavoidable collision. It does not prevent collision nor
stop the vehicle automatically. It is still your
responsibility to operate the brake pedal and steering
wheel appropriately according to the driving
conditions.

When the CMBS activates, the engine may stop
automatically.
Start the engine by normal operation if the engine
stops.

Starting the Engine

P. 510, 513

The CMBS may not activate or may not detect a
vehicle in front of your vehicle under certain
conditions:

CMBS Conditions and Limitations

P. 563

You can read about handling information for the
camera equipped with this system.

Front Sensor Camera

P. 623

For directions on the proper handling of the radar
sensor, refer to the following page.

Radar Sensor

P. 625

Manual transmission models

Continued

559

Honda Sensing

Collision Mitigation Braking System (CMBS)

Driving

■

How the System Works

How the System Works

When the CMBS activates, it may automatically apply
the brake. It will be cancelled when your vehicle stops
or a potential collision is not determined.

The system starts monitoring the roadway ahead when your vehicle speed is about
5 km/h (3 mph) and there is a vehicle in front of you.

The radar sensor is
in the front grille.

The CMBS activates when:

●

The speed difference between your vehicle and a vehicle or pedestrian detected
in front of you becomes about 5 km/h (3 mph) and over with a chance of a
collision.

●

Your vehicle speed is about 100 km/h (62 mph) or less and the system determines
there is a chance of a collision with:

- Vehicles detected in front of you that are stationary, oncoming, or travelling in
your same direction.
- A pedestrian who is detected in front of you.

●

Your vehicle speed is above 100 km/h (62 mph), and the system determines there
is a chance of a collision with a vehicle detected in front of you travelling in your
same direction.

The camera is
located behind
the rearview
mirror.

When to use

Honda Sensing

Collision Mitigation Braking System (CMBS)

560

Driving

■

When the system activates

At system’s earliest collision alert stage, you can change the distance (

Far

Normal

Near

) between vehicles at which alerts will come on through the driver information

interface or audio/information screen setting options.

Customized Features

P. 157, 408

How the System Works

The camera in the CMBS is also designed to detect
pedestrians.
However, this pedestrian detection feature may not
activate or may not detect a pedestrian in front of
your vehicle under certain conditions.
Refer to the ones indicating the pedestrian detection
limitations from the list.

CMBS Conditions and Limitations

P. 563

The head-up warning

uses a lens located at the front

end of the dashboard.
Do not cover the lens or spill any liquid on it.

Lens

The system provides visual and audible alerts of a possible collision, and stops
if the collision is avoided.

Take appropriate action to prevent a collision (apply the brakes, change lanes,
etc.)

Beep

Visual Alerts

Audible Alert

Head-up Warning
Lights

* Not available on all models

561

Honda Sensing

Collision Mitigation Braking System (CMBS)

Continued

Driving

The system has three alert stages for a possible collision. However, depending on circumstances, the CMBS may not go through all of the
stages before initiating the last stage.

■

Collision Alert Stages

Distance between vehicles

CMBS

The sensors

detect a vehicle

E-pretensioner

Audible & Visual WARNINGS

Braking

Stage

one

There is a risk of a
collision with the
vehicle ahead of
you.

—

When in

Far

, visual and audible

alerts come on at a longer distance
from a vehicle ahead than in

Normal

setting, and in

Near

, at a

shorter distance than in

Normal

—

Stage

two

The risk of a
collision has
increased, time to
respond is
reduced.

Retracts the driver’s seat belt
gently a few times, providing
a physical warning.

Visual and audible alerts.

Lightly

applied

Stage

three

The CMBS
determines that a
collision is
unavoidable.

Forcefully tightens driver and
front passenger seat belts.

Forcefully

applied

Your Vehicle

Vehicle
Ahead

Normal

Near

Far

Your
Vehicle

Vehicle
Ahead

Your
Vehicle

Vehicle
Ahead

Honda Sensing

Collision Mitigation Braking System (CMBS)

562

Driving

Press and hold the button until the beeper
sounds to switch the system on or off.

When the CMBS is off:

•

The CMBS indicator in the instrument panel
comes on.

•

A message on the driver information
interface reminds you that the system is off.

The CMBS is turned on every time you start
the engine, even if you turned it off the last
time you drove the vehicle.

■

CMBS On and Off

Collision Mitigation Braking System (CMBS)

The CMBS may automatically shut off, and the CMBS
indicator will come and stay on under certain
conditions.

CMBS Conditions and Limitations

P. 563

When the CMBS is activated, it will continue to
operate even if the accelerator pedal is partially
depressed. However, it will be cancelled if the
accelerator pedal is deeply depressed.

The adaptive cruise control (ACC)

, adaptive cruise

control (ACC) with low speed follow (LSF)

, road

departure mitigation, vehicle stability assist (VSA)
system, vehicle stability assist (VSA) OFF, low tyre
pressure/deflation warning system, collision
mitigation braking system (CMBS), and parking brake
and brake system (amber) indicators may come on in
amber along with a message in the driver information
interface when you turn the ignition switch to ON

(

after reconnecting the battery. Drive a short

distance at more than 20 km/h (12 mph). Each
indicator should go off. If any do not, have your
vehicle checked by a dealer.

*1: Models with the keyless access system have an

ENGINE START/STOP

button instead of an ignition

switch.

* Not available on all models

Continued

563

Honda Sensing

Collision Mitigation Braking System (CMBS)

Driving

The system may automatically shut off and the CMBS indicator will come on under
certain conditions. Some examples of these conditions are listed below. Other
conditions may reduce some of the CMBS functions.

Front Sensor Camera

P. 623

■

Environmental conditions

•

Driving in bad weather (rain, fog, snow, etc.).

•

Sudden changes between light and dark, such as an entrance or exit of a tunnel.

•

There is little contrast between objects and the background.

•

Driving into low sunlight (e.g., at dawn or dusk).

•

Strong light is reflected onto the roadway.

•

Driving in the shadows of trees, buildings, etc.

•

Roadway objects or structures are misinterpreted as vehicles and pedestrians.

•

Reflections on the interior of the windscreen.

•

Driving at night or in a dark place such as a tunnel (due to low-light conditions,
pedestrians or other vehicles may not be detected).

■

Roadway conditions

•

Driving on a snowy or wet roadway (obscured lane marking, vehicle tracks,
reflected lights, road spray, high contrast).

•

Driving on curvy, winding, or undulating roads.

•

The road is hilly or the vehicle is approaching the crest of a hill.

■

CMBS Conditions and Limitations

CMBS Conditions and Limitations

Have your vehicle checked by a dealer if you find any
unusual behaviour of the system (e.g. the warning
message appears too frequently).

564

Honda Sensing

Collision Mitigation Braking System (CMBS)

Driving

■

Vehicle conditions

•

Headlight lenses are dirty or the headlights are not properly adjusted.

•

The outside of the windscreen is blocked by dirt, mud, leaves, wet snow, etc.

•

The inside of the windscreen is fogged.

•

An abnormal tyre or wheel condition (wrong sized, varied size or construction,
improperly inflated, etc.).

•

When tyre chains are installed.

•

The vehicle is tilted due to a heavy load or suspension modifications.

•

The camera temperature gets too high.

•

Driving with the parking brake applied.

•

When the radar sensor in the front grille gets dirty.

•

The vehicle is towing a trailer.

•

Driving at night or in a dark place (e.g., a tunnel) with the headlights off.

565

Honda Sensing

Collision Mitigation Braking System (CMBS)

Continued

Driving

■

Detection limitations

•

A vehicle or pedestrian suddenly crosses in front of you.

•

The distance between your vehicle and the vehicle or pedestrian ahead of you is
too short.

•

A vehicle cuts in front of you at a slow speed, and it brakes suddenly.

•

When you accelerate rapidly and approach the vehicle or pedestrian ahead of you
at high speed.

•

The vehicle ahead of you is a motorcycle, bicycle, mobility scooter or other small
vehicle.

•

When there are animals in front of your vehicle.

•

When you drive on a curved, winding or undulating road that makes it difficult for
the sensor to properly detect a vehicle in front of you.

•

The speed difference between your vehicle and a vehicle or pedestrian in front of
you is significantly large.

•

An oncoming vehicle suddenly comes in front of you.

•

Another vehicle suddenly comes in front of you at an intersection, etc.

•

Your vehicle abruptly crosses over in front of an oncoming vehicle.

•

When driving through a narrow iron bridge.

•

When the lead vehicle suddenly slows down.

566

Honda Sensing

Collision Mitigation Braking System (CMBS)

Driving

•

When there is a group of people in front of your vehicle walking together side by
side.

•

Surrounding conditions or belongings of the pedestrian alter the pedestrian’s
shape, preventing the system from recognizing that the person is a pedestrian.

•

When the pedestrian is shorter than about 1 metre or taller than about 2 metres
in height.

•

When a pedestrian blends in with the background.

•

When a pedestrian is bent over or squatting, or when their hands are raised or
they are running.

•

When several pedestrians are walking ahead in a group.

•

When the camera cannot correctly identify that a pedestrian is present due to an
unusual shape (holding luggage, body position, size).

■

Automatic shutoff

CMBS may automatically shut itself off and the CMBS indicator comes and stays on
when:

•

The temperature inside the system is high.

•

You drive off-road or on a mountain road, or curved and winding road for an
extended period.

•

An abnormal tyre condition is detected (wrong tyre size, flat tyre, etc.).

•

The camera behind the rearview mirror, or the area around the camera, including
the windscreen, gets dirty.

Once the conditions that caused CMBS to shut off improve or are addressed (e.g.,
cleaning), the system comes back on.

Limitations applicable to pedestrian detection only

567

Honda Sensing

Collision Mitigation Braking System (CMBS)

Continued

Driving

The CMBS may activate even when you are aware of a vehicle ahead of you, or
when there is no vehicle ahead. Some examples of this are:

■

When Passing

Your vehicle approaches another vehicle ahead of you and you change lanes to pass.

■

At an intersection

Your vehicle approaches or passes another vehicle that is making a left or right turn.

■

With Little Chance of a Collision

568

Honda Sensing

Collision Mitigation Braking System (CMBS)

Driving

■

On a curve

When driving through curves, your vehicle comes to a point where an oncoming
vehicle is right in front of you.

■

Through a low bridge at high speed

You drive under a low or narrow bridge at high speed.

■

Speed bumps, road work sites, train tracks, roadside objects, etc.

You drive over speed bumps, steel road plates, etc., or your vehicle approaches train
tracks or roadside objects (such as a traffic sign and guard rail) on a curve or, when
parking, stationary vehicles and walls.

569

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow (LSF)

Continued

Driving

Adaptive Cruise Control (ACC) with Low Speed
Follow (LSF)

Helps to maintain a constant vehicle speed and a set following-interval behind a
vehicle detected ahead of yours and, if the detected vehicle comes to a stop, can
decelerate and stop your vehicle, without you having to keep your foot on the brake
or the accelerator.
When ACC with LSF slows your vehicle by applying the brakes, your vehicle’s brake
lights will illuminate.

Continuously variable transmission models

Adaptive Cruise Control (ACC) with Low Speed Follow (LSF)

Important Reminder

As with any system, there are limits to ACC with LSF. Use
the brake pedal whenever necessary, and always keep a
safe interval between your vehicle and other vehicles.

For directions on the proper handling of the radar
sensor, refer to the following page.

Radar Sensor

P. 625

You can read about handling information for the
camera equipped with this system.

Front Sensor Camera

P. 623

WARNING

Improper use of ACC with LSF can lead to a
crash.

Use ACC with LSF only when driving on
motorways and in good weather
conditions.

WARNING

ACC with LSF has limited braking capability
and may not stop your vehicle in time to
avoid a collision with a vehicle that quickly
stops in front of you.

Always be prepared to apply the brake
pedal if the conditions require.

■

Vehicle speed for ACC with LSF:

A vehicle is detected ahead within ACC with

LSF range

– ACC with LSF operates at speeds up to 180 km/h (112 mph).

No vehicle is detected within ACC with LSF range

– ACC with LSF operates at

the speed of 30 km/h (18 mph) or above.

■

Shift position for ACC with LSF: In

(

The radar sensor is inside the
front grille.

When to use

The camera is
located behind
the rearview
mirror.

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow (LSF)

570

Driving

■

How to activate the system

Adaptive Cruise Control (ACC) with Low Speed Follow (LSF)

When the

MAIN

button is pressed, both ACC with

LSF and the Lane Keeping Assist System (LKAS) are
either turned on or off.

ACC with LSF may not work properly under certain
conditions.

ACC with LSF Conditions and Limitations

P. 576

When not using ACC with LSF: Turn off adaptive
cruise by pressing the

MAIN

button. This also will

turn off the Lane Keeping Assist System (LKAS).

Do not use ACC with LSF under the following
conditions:

•

On roads with heavy traffic or while driving in
continuous stop and go traffic.

•

On roads with sharp turns.

•

On roads with steep downhill sections, as the set
vehicle speed can be exceeded by coasting. In such
cases, ACC with LSF will not apply the brakes to
maintain the set speed.

•

On roads with toll collection facilities or other
objects between lanes of traffic, or in parking
areas, or facilities with drive through access.

How to use

■

Press the

MAIN

button on

the steering wheel.

ACC (green) is on in
the instrument panel.

ACC with LSF is ready
to use.

If a different instrument panel is displayed, press
the

LIM

button to change it to ACC with LSF.

LIM

Button

MAIN

Button

Continued

571

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow (LSF)

Driving

When driving at about 30 km/h (18 mph) or above:

Take your foot off the

pedal and press the

–/SET

button when you reach the desired speed. The moment

you release the button, the set speed is fixed, and ACC with LSF begins.

When driving slower than about 30 km/h (18 mph):

If the vehicle is moving

and the brake pedal is not depressed, pressing the button fixes the set speed to
about 30 km/h (18 mph) regardless of current vehicle speed.
If your vehicle is stationary, you can set the vehicle speed even with the brake pedal
depressed.

*1: Models with the keyless access system have an

ENGINE START/STOP

button instead of an

ignition switch.

■

To Set the Vehicle Speed

Adaptive Cruise Control (ACC) with Low Speed Follow (LSF)

The adaptive cruise control (ACC) with low speed
follow (LSF), road departure mitigation, vehicle
stability assist (VSA) system, vehicle stability assist
(VSA) OFF, low tyre pressure/deflation warning
system, collision mitigation braking system (CMBS),
and parking brake and brake system (amber)
indicators may come on in amber along with a
message in the driver information interface when you
turn the ignition switch to ON

(

after

reconnecting the battery. Drive a short distance at
more than 20 km/h (12 mph). Each indicator should
go off. If any do not, have your vehicle checked by a
dealer.

To Set the Vehicle Speed

You can switch the displayed set speed
measurements on the driver information interface or
audio/information screen between km/h and mph.

Speedometer

P. 146

Customized Features

P. 157, 408

On when ACC with LSF
begins

Press and release

−/SET

Button

572

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow (LSF)

Driving

When ACC with LSF starts operating, the
vehicle icon, interval bars and set speed
appear on the driver information interface.

When you use ACC with LSF, Straight Driving
Assist (a feature of the Electric Power Steering
system) is activated.
By enabling the steering system to
automatically compensate for natural steering
pull, Straight Driving Assist makes it easier for
you to keep your vehicle in a straight line.

Set Vehicle Speed

Set Vehicle Interval

Continued

573

Honda Sensing

Adaptive Cruise Control (ACC) with Low Speed Follow (LSF)

Driving

■

There is a vehicle ahead

ACC with LSF monitors if a vehicle ahead of you enters the ACC with LSF range. If a
vehicle is detected doing so, the ACC with LSF system maintains or decelerates your
vehicle’s set speed in order to keep the vehicle’s set following-interval from the
vehicle ahead.

To Set or Change Following-interval

P. 580

When a vehicle whose speed is slower than
your set speed is detected in front of you, your
vehicle starts to slow down.

■

When in Operation

When in Operation

If the vehicle ahead of you slows down abruptly, or if
another vehicle cuts in front of you, the beeper
sounds, a message appears on the driver information
interface, and the head-up warning lights

flash.

Depress the brake pedal, and keep an appropriate
interval from the vehicle ahead.

Beep

Head-up
Warning
Lights

ACC with LSF Range: 120 m

A vehicle icon appears on the
driver information interface

* Not available on all models

Honda CR-V (2022 year). Manual in english - page 35
