Honda CR-V (2022 year). Manual in english - page 18

Continued

285

Interior Convenience Items

Other Interior Convenience Items

Co
ntrols

■

When charging does not start

Perform one of the solutions in the following table.

Indicator

Cause

Solution

Green

Amber

Blinking
simulta-

neously

There is an obstacle(s) between
the charging area and the
device.

Remove the
obstacle(s).

The device is not within the
charging area.

Move the device to the
centre of the charging
area where

located.

Amber

Blinking

The wireless charger is faulty.

Contact a dealer for
repairs.

Wireless Charger

NOTICE

Do not place any magnetic recording media or
precision machines within the charge area while
charging.
The data on your cards such as credit cards can be
lost because of the magnetic effect. Also precision
machines such as watches may malfunction.

In the following cases, charging may stop or not start:

•

The device is already fully charged.

•

The temperature of the device is extremely high
while charging.

•

You are at a place that emits strong
electromagnetic waves or noises, such as TV
station, electric power plant, or petrol station.

A device may not charge if the size or shape of its
chargeable side is not appropriate for use with the
charging area.

Not all devices are compatible with the system.

During the charging phase, it is normal for the
charging area and the device to heat up.

appears on the audio/information screen when

the device is being charged by the wireless charger.

* Not available on all models

Interior Convenience Items

Other Interior Convenience Items

286

Co
ntrols

Wireless Charger

Charging may be briefly interrupted when:

•

All doors or the tailgate are closed.

To avoid interference with the proper functioning of
the keyless access system.

•

The position of the device is altered.

Do not charge more than one device at a time on a
charging area.

Burn risk:
Any metal objects placed between pad and device
may become hot.

* Not available on all models

Continued

287

Interior Convenience Items

Other Interior Convenience Items

Co
ntrols

The power mode must be in ON to use the
heated steering wheel.

Press the button on the right side of the
steering wheel.

When a comfortable temperature is reached,
press the button again to turn it off.

The heated steering wheel is turned off every
time you start the engine, even if you turned it
on the last time you drove the vehicle.

■

Heated Steering Wheel

Heated Steering Wheel

Do not use the heated steering wheel continuously
when the engine is off. Under such conditions, the
battery may be weakened, making the engine
difficult to start.

* Not available on all models

Interior Convenience Items

Other Interior Convenience Items

288

Co
ntrols

The ignition switch must be in ON

(

to use

the seat heaters.

Press the seat heater button:
Once - The HI setting (three indicators on)
Twice - The MID setting (two indicators on)
Three times - The LO setting (one indicator on)
Four times - The OFF setting (no indicators on)

When the ignition switch must be in ON

(

after it is turned off, the previous setting of
seat heaters is maintained.

*1: Models with the keyless access system have an

ENGINE START/STOP

button instead of an

ignition switch.

■

Front Seat Heaters

Front Seat Heaters

Do not use the seat heaters even in LO when the
engine is off. Under such conditions, the battery may
be weakened, making the engine difficult to start.

After a certain period of time, the strength setting for
the seat heater will automatically be reduced by one
level at a time until the seat heater shuts off. The
elapsed time varies according to the interior
environment.

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

* Not available on all models

289

Interior Convenience Items

Other Interior Convenience Items

Co
ntrols

The power mode must be in ON to use the
seat heaters.
There is no heater in the rear centre seating
position.
Press the seat heater button:
Once - The HI setting (three indicators on)
Twice - The MID setting (two indicators on)
Three times - The LO setting (one indicator on)
Four times - The OFF setting (no indicators on)

■

Rear Seat Heaters

Rear Seat Heaters

Do not use the seat heaters even in LO when the
engine is off. Under such conditions, the battery may
be weakened, making the engine difficult to start.

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

* Not available on all models

290

Co
ntrols

Climate Control System

Using Automatic Climate Control

The automatic climate control system maintains the interior temperature you select.
The system also selects the proper mix of heated or cooled air that raises or lowers
the interior temperature to your preference as quickly as possible.

Using Automatic Climate Control

Press the

CLIMATE

button to display A/C, MODE,

and fan control information on the audio/information
screen to operate manually. Select icon to turn on or
off A/C, change the vent mode, or change the fan
speed.

If any buttons are pressed while using the climate
control system in auto, the function of the button
that was pressed will take priority.

Models with Display Audio

Models with colour audio system

AUTO

Button

Temperature
Control Dial

(Recirculation) Button

(Fresh Air) Button

Fan Control
Dial

(ON/OFF)

Button

A/C

(Air Conditioning)

Button

Air flows from
floor vents.

Air flows from
floor and
windscreen
demister vents.

*1 : Left-hand drive models shown. For the right-hand drive models, these buttons are located

at the symmetrically opposite to the left-hand drive model.

Air flows from floor
and dashboard
vents, and back of
the centre console.

Air flows from
dashboard vents,
and back of the
centre console.

291

Climate Control System

Using Automatic Climate Control

Continued

Co
ntrols

Models with Display Audio

Air flows from
dashboard
vents, and back
of the centre
console.

Air flows from
floor and
dashboard
vents, and back
of the centre
console.

Air flows
from floor
vents.

Air flows from
floor and
windscreen
demister vents.

(CLIMATE) Button

AUTO

Button

Driver’s Side
Temperature
Control Dial

(Recirculation) Button

(Fresh Air) Button

Fan Control Buttons

(ON/OFF) Button

SYNC

(Synchronization) Button

Passenger’s Side Temperature Control Dial

*1 : Left-hand drive models shown. For the right-hand drive models, these buttons are located

at the symmetrically opposite to the left-hand drive model.

Climate Control System

Using Automatic Climate Control

292

Co
ntrols

Use the system when the engine is running.

Press the

AUTO

button.

Adjust the interior temperature using the temperature control dial.

Adjust the interior temperature using the driver’s side or passenger’s side control
dial.

Press the

(on/off) button to cancel.

■

Switching between the recirculation and fresh air modes

Press the

(recirculation) or

(fresh air) button to switch the mode

depending on environmental conditions.

Recirculation mode (indicator on): Recirculates air from the vehicle’s interior

through the system.

Fresh air mode (indicator on): Maintains outside ventilation. Keep the system

in fresh air mode in normal situations.

Using Automatic Climate Control

The

AUTO

indicator will go off, but functions

unrelated to the button that were pressed will be
controlled automatically.

To prevent cold air from blowing in from outside, the
fan may not start immediately when the

AUTO

button is pressed.

During idle-stops, air-conditioning is suspended, and
only the blower remains active.
If you do not want air-conditioning suspended, press
the Auto Idle Stop system

OFF

button to cancel idle-

stop.

If the interior is very warm, you can cool it down
more rapidly by partially opening the windows,
turning the system on AUTO, and setting the
temperature to low. Change the fresh mode to
recirculation mode until the temperature cools down.

When you set the temperature to the lower or upper
limit,

is displayed.

Pressing the

button switches the climate control

system between on and off. When turned on, the
system returns to your last selection.

While ECON mode is active, the climate control
system may have reduced cooling performance.

Models with Auto Idle Stop

Models with colour audio system

Models with Display Audio

Continued

293

Climate Control System

Using Automatic Climate Control

Co
ntrols

Pressing the

(windscreen demister) button

turns the air conditioning system on and
automatically switches the system to fresh air
mode.

Press the

button again to turn off, the

system returns to the previous settings.

■

Defrosting the Windscreen and Windows

Defrosting the Windscreen and Windows

For your safety, make sure you have a clear view
through all the windows before driving.

Do not set the temperature near the upper or lower
limit.
When cold air hits the windscreen, the outside of the
windscreen may fog up.

To defog during the Auto Idle Stop, restart the
engine as follows.
1. Make sure the shift lever is in

(

2. Depress the clutch pedal fully.
3. Press the

button.

Manual transmission models

Models with colour audio system

Models with Display Audio

Climate Control System

Using Automatic Climate Control

294

Co
ntrols

■

To rapidly defrost the windows

Press the

button (indicator on).

Press the

button (indicator on).

To rapidly defrost the windows

After defrosting the windows, switch over to fresh air
mode. If you keep the system in recirculation mode,
the windows may fog up from humidity. This
impedes visibility.

Models with colour audio system

Models with Display Audio

295

Climate Control System

Using Automatic Climate Control

Co
ntrols

You can set the temperature synchronously for the driver’s side and the passenger’s
side in synchronization mode.

Press the

SYNC

button.

The system switches to synchronization mode.

Adjust the temperature using the driver’s side temperature control dial.

Press the

SYNC

button to return to dual mode.

■

Synchronization Mode

Synchronization Mode

When you press the

button, the system changes

to synchronization mode.
When the system is in synchronization mode, the
driver’s side temperature and the passenger’s side
temperature can not be set separately.

SYNC

Button

Driver’s Side
Temperature
Control Dial

Passenger’s
Side
Temperature
Control Dial

* Not available on all models

296

Climate Control System

Automatic Climate Control Sensors

Co
ntrols

Automatic Climate Control Sensors

The automatic climate control system is
equipped with sensors. Do not cover or spill
any liquid on them.

Sensor

298

Features

Audio System

About Your Audio System

The audio system features AM/FM radio. It can also play USB flash drives, and iPod,
iPhone, and

Bluetooth

devices.

You can operate the audio system from the buttons and switches on the panel, the
remote controls on the steering wheel, or the icons on the touchscreen interface

*1: Models with the keyless access system have an

ENGINE START/STOP

button instead of an

ignition switch.

About Your Audio System

iPod, iPhone and iTunes are trademarks of Apple Inc.

Key Off Operation

After you turn the ignition switch to LOCK

(

, you

can use the audio system for up to 30 minutes per
driving cycle. However, whether you can continue
using the audio system depends on the battery
condition. Repeatedly using this feature may drain
the battery.

Remote Controls

iPod

USB Flash Drive

* Not available on all models

299

Audio System

USB Port(s)

Continued

Features

USB Port(s)

Install the iPod USB connector or the USB flash drive to the USB port.

■

On the front of the centre console

The USB port (1.0A) is for playing audio files
on a USB flash drive, connecting a mobile
phone, and charging devices.

The USB port (1.5A) is for charging devices,
playing audio files and connecting compatible
phones with smartphone connection, Apple
CarPlay or Android Auto.

To prevent any potential issues, be sure
to use an Apple MFi Certified Lightning
Connector for Apple CarPlay, and for
Android Auto, the USB cables should be
certified by USB-IF to be compliant with
USB 2.0 Standard.

*1: Models with colour audio system
*2: Models with Display Audio

USB Port(s)

•

Do not leave the iPod or USB flash drive in the
vehicle. Direct sunlight and high temperatures may
damage it.

•

We recommend using an extension cable with the
USB port.

•

Do not connect the iPod or USB flash drive using a
hub.

•

Do not use a device such as a card reader or hard
disk drive, as the device or your files may be
damaged.

•

We recommend backing up your data before using
the device in your vehicle.

•

Displayed messages may vary depending on the
device model and software version.

If the audio system does not recognise the iPod, try
reconnecting it a few times or reboot the device. To
reboot, follow the manufacturer’s instructions
provided with the iPod or visit

www.apple.com/ipod

The USB port can supply up to 1.5A/2.5A of power. It
does not output 1.5A/2.5A unless the device
requests.
For amperage details, read the operating manual of
the device that needs to be charged.

Under certain conditions, a device connected to the
port may generate noise in the radio you are listening
to.

On the front of the centre console

USB Port (1.0A)

USB Port (1.5A)

* Not available on all models

Audio System

Auxiliary Input Jack

300

Features

■

On the back of the centre console

The USB ports (2.5A) are only for charging
devices.

Auxiliary Input Jack

Use the jack to connect devices.

Connect a device to the input jack using a 3.5
mm stereo miniplug.

The audio system automatically switches
to the AUX mode.

USB Port(s)

This port is for battery charge only. You cannot play
music even if you have connected a music player to it.

USB Port (2.5A)

On the back of the centre console

Auxiliary Input Jack

To switch the mode, press any of the audio mode
buttons. You can return to AUX mode by pressing
the

MEDIA

button.

You cannot use the auxiliary input jack if you replace
the audio system.

* Not available on all models

Content .. 16 17 18 19 ..
