Honda CR-V (2022 year). Manual in english

301

Audio System

Audio System Theft Protection

Features

Audio System Theft Protection

The audio system is disabled when it is disconnected from the power source, such as
when the battery is disconnected or goes dead. In certain conditions, the system
may display a code entry screen. If this occurs, reactivate the audio system.

■

Reactivating the audio system

Turn the ignition switch to ON

(

Turn on the audio system.

Press and hold the audio system power button for more than two seconds.

The audio system is reactivated when the audio control unit establishes a
connection with the vehicle control unit. If the control unit fails to recognise
the audio unit, you must go to a dealer and have the audio unit checked.

*1: Models with the keyless access system have an

ENGINE START/STOP

button instead of an

ignition switch.

302

Audio System

Audio Remote Controls

Features

Audio Remote Controls

Allow you to operate the audio system while driving. The information is shown on
the driver information interface or head-up display

Buttons

Press

to cycle through the audio

mode as follows:

FM1 FM2 DAB1 DAB2 LW MW
USB/iPod

Bluetooth

Audio AUX

FM DAB LW MW USB iPod

Bluetooth

Audio Apps Audio Apps

ENTER

Button

•

When listening to a USB flash drive

From the audio screen in the driver information interface, press

ENTER

to display

the folder list.

Press

to select a folder.

Press

ENTER

to display a list of tracks in that folder.

Press

to select a track, then press

ENTER

Audio Remote Controls

Some modes appear only when an appropriate
device or medium is used.

Depending on the

Bluetooth

device you connect,

some functions may not be available.

Press the

(Hang-up/back) button

to go back

to the previous command or cancel a command.

Press the

(Display/information) button to switch

display.

Switching the Display

P. 147

Button

ENTER

Button

(

Bar

(Display/Information)

Button

3 4

Models with colour audio system

Models with Display Audio

* Not available on all models

303

Audio System

Audio Remote Controls

Continued

Features

•

When listening to an iPod

From the audio screen in the driver information interface, press

ENTER

to display

the iPod music list.

Press

to select a category.

Press

ENTER

to display a list of items in the category.

Press

to select an item, then press

ENTER

Press

ENTER

and press

repeatedly until the desired mode you want

to listen to is displayed.

•

When listening to

Bluetooth

Audio

From the audio screen in the driver information interface, press

ENTER

to display

the track list.

Press

to select a track, then press

ENTER

(

(Volume) Bar

Press

(

To increase the volume.

Press

(

To decrease the volume.

304

Audio System

Audio Remote Controls

Features

Buttons

•

When listening to the radio

Press :

To select the next preset radio station.

Press :

To select the previous preset radio station.

Press and hold

To select the next strong station.

Press and hold

To select the previous strong station.

•

When listening to an iPod, USB flash drive, or

Bluetooth

Audio

Press :

To skip to the next song.

Press :

To go back to the beginning of the current or previous song.

•

When listening to a USB flash drive or

Bluetooth

Audio

Press and hold

To skip to the next folder.

Press and hold

To go back to the previous folder.

* Not available on all models

305

Continued

Features

Audio System Basic Operation

To use the audio system, the ignition switch must be in ACCESSORY

(

or ON

(

Use the selector knob or

MENU/CLOCK

button to access some audio functions.

Press

to switch between the normal and

extended display for some functions.

Selector knob:

Rotate left or right to scroll

through the available choices. Press

to set

your selection.

Audio System Basic Operation

These indications are used to show how to operate
the selector knob.
Rotate

to select.

Press

to enter.

Menu Items

Adjust Clock

P. 174

P. 312

Play Mode

P. 324, 327

RDS Settings

P. 314

DAB Settings

P. 320

Bluetooth

P. 328

Press the buttons on the steering wheel to change
any audio setting.

Audio Remote Controls

P. 302

Models with colour audio system

(Back) Button

Selector Knob

MENU/
CLOCK

Button

(Day/Night) Button

Button

306

Audio System Basic Operation

Features

MENU/CLOCK button:

Press to select any

mode.
The available modes include the wallpaper,
display, clock, language setup, and play
modes. Play mode choices include scan,
random, repeat, and so on.

(Back) button:

Press to go back to the previous display.

TA button:

Press to activate the TA station.

(Day/Night) button:

Press to change the audio/information screen

brightness.
Press the

button, then adjust the brightness using

Each time you press the

button, the mode switches between the daytime

mode, nighttime mode and off mode.

Menu Display

308

Audio System Basic Operation

Audio/Information Screen

Features

■

Audio

Shows the current audio information.

■

Clock/Wallpaper

Shows a clock screen or an image you import.

■

Change display

Press the

MENU/CLOCK

button.

Rotate

to select

Settings

, then press

Rotate

to select

Display change

, then press

Rotate

to select

Wallpaper

, then press

If you want to return to the audio/information screen, select

Audio

Continued

309

Audio System Basic Operation

Audio/Information Screen

Features

You can change, store, and delete the wallpaper on the audio/information screen.

■

Import wallpaper

You can import up to three images, one at a time, for wallpaper from a USB flash
drive.

Connect the USB flash drive to the USB
port.

USB Port(s)

P. 299

Press the

MENU/CLOCK

button.

Rotate

to select

Settings

, then press

Rotate

select

Wallpaper

, then press

Rotate

to select

Import

, then press

The picture name is displayed on the list.

Rotate

to select a desired picture, then

press .

The selected picture is displayed.

Press

to save the picture.

Press

to select

Rotate

to select a location to save the

picture, then press

The display will return to the wallpaper
setting screen.

■

Wallpaper Setup

Wallpaper Setup

•

When importing wallpaper files, the image must be
in the USB flash drive’s root directory. Images in a
folder cannot be imported.

•

The file name must be fewer than 64 characters.

•

The file format of the image that can be imported
is BMP (bmp) or JPEG (jpg).

•

The individual file size limit is 2 MB.

•

The maximum image size is 1,920 x 936 pixels. If
the image size is less than 480 × 234 pixels, the
image is displayed in the middle of the screen with
the extra area appearing in black.

•

Up to 255 files can be selected.

•

If the USB flash drive does not have any pictures,
the error message appears.

•

The wallpaper setup is limited while driving.

Audio System Basic Operation

Audio/Information Screen

310

Features

■

Select wallpaper

Press the

MENU/CLOCK

button.

Rotate

to select

Settings

, then press

Rotate

to select

Wallpaper

, then press

Rotate

to select

Select

, then press

The screen changes to the wallpaper list.

Rotate

to select a desired wallpaper, then press

■

To view wallpaper once it is set

Press the

MENU/CLOCK

button.

Rotate

to select

Settings

, then press

Rotate

to select

Display change

, then press

Rotate

to select

Wallpaper

, then press

Press the

(Back) button until the top screen is displayed.

■

Delete wallpaper

Press the

MENU/CLOCK

button.

Rotate

to select

Settings

, then press

Rotate

to select

Wallpaper

, then press

Rotate

to select

Delete

, then press

The screen changes to the wallpaper list.

Rotate

to select a wallpaper that you want to delete, then press

Rotate

to select

Yes

, then press

The display will return to the wallpaper setting screen.

Wallpaper Setup

To go back to the previous screen, press the

(Back) button.

When the file size is large, it takes a while to be
previewed.

311

Audio System Basic Operation

Adjusting the Sound

Features

Adjusting the Sound

Press the

MENU/CLOCK

button and rotate

to select

Sound

, then press

. Rotate

to scroll through the following choices:

Rotate

to adjust the sound setting, then

press .

Adjusting the Sound

The SVC has four modes:

Off

Low

Mid

, and

High

SVC adjusts the volume level based on the vehicle
speed. As you go faster, audio volume increases. As
you slow down, audio volume decreases.

Selector Knob

MID

is selectable.

BAS

MID

FAD

BAL

SVC

Bass

Middle

Fader

Balance

Speed-sensitive Volume
Compensation

TRE

Treble

312

Audio System Basic Operation

Display Setup

Features

Display Setup

You can change the brightness or colour theme of the audio/information screen.

Press the

MENU/CLOCK

button.

Rotate

select

Settings

, then press

Rotate

select

Display adjustment

then press

Rotate

select

Brightness

, then press

Rotate

to adjust the setting, then press

Press the

MENU/CLOCK

button.

Rotate

select

Settings

, then press

Rotate

select

Colour theme

, then

press .

Rotate

to select the setting you want,

then press

■

Changing the Screen Brightness

Changing the Screen Brightness

You can change the

Contrast

and

Black level

settings in the same manner.

■

Changing the Screen’s Colour Theme

313

Audio System Basic Operation

Playing AM/FM Radio

Continued

Features

Playing AM/FM Radio

RADIO Button

Press to select a band.

(Back) Button

Press to go back to the previous
display or cancel a setting.

(Seek/Skip) Buttons

Press

to search up and down

the selected band for a station with a strong
signal.

VOL/

(Volume/Power)

Knob

Press to turn the audio system
on and off.
Turn to adjust the volume.

Preset Buttons (1-6)

To store a station:
1. Tune to the selected station.
2. Pick a preset button and hold it until you hear a beep.
To listen to a stored station, select a band, then press the preset button.

MENU/CLOCK Button

Press to display the menu items.

Audio/Information Screen

TA Button

Selector Knob

Turn to tune the radio
frequency.
Press, and then turn to select
an item. After that, press again
to make your selection.

Audio System Basic Operation

Playing AM/FM Radio

314

Features

Provides convenient automated services related to your selected RDS-capable FM
station.

■

To find an RDS station from Station List

Press

while listening to an FM station.

Rotate

to select the station, then press

■

Update List

Updates your available station list at any time.

Press

while listening to an FM station.

Rotate

to select

Update list

, then press

■

Radio text

Displays the radio text information of the selected RDS station.

Press the

MENU/CLOCK

button.

Rotate

to select

Settings

, then press

Rotate

to select

RDS settings

, then press

Rotate

to select

Radio text

, then press

Select

Radio text

again to turn it off.

■

Radio Data System (RDS)

FM mode

Playing AM/FM Radio

The

indicator appears on the display indicating

stereo FM broadcasts.
Stereo reproduction in AM is not available.

You can store 12 AM stations and 12 FM stations into
the preset button memory. AM has two types of
frequencies LW and MW, and each lets you store six
stations. FM1 and FM2 let you store six stations each.

Switching the Audio Mode
Press the audio source selecting buttons on the
steering wheel.

Audio Remote Controls

P. 302

Radio Data System (RDS)

When you select an RDS-capable FM station, the RDS
automatically turns on, and the frequency display
changes to the station name. However, when the
signals of that station become weak, the display
changes from the station name to the frequency.

Turning the Alternative Frequency (AF) function on
and off turns the RDS on and off.

Pressing

switches

the

function between on and

off.

Continued

315

Audio System Basic Operation

Playing AM/FM Radio

Features

■

Alternative Frequency (AF)

Automatically changes the frequency of the same programme as you enter different
regions.

Press the

MENU/CLOCK

button.

Rotate

to select

Settings

, then press

Rotate

to select

RDS settings

, then press

Rotate

to select

, then press

Select

again to turn it off.

■

Regional Programme (REG)

Keeps the same frequency of the stations within that region even if the signal gets
weak.

Press the

MENU/CLOCK

button.

Rotate

to select

Settings

, then press

Rotate

to select

RDS settings

, then press

Rotate

to select

REG

, then press

Select

REG

again to turn it off.

■

News Programme (News)

Automatically tunes to the news programme.

Press the

MENU/CLOCK

button.

Rotate

to select

Settings

, then press

Rotate

to select

RDS settings

, then press

Rotate

to select

News

, then press

Select

News

again to turn it off.

Radio Data System (RDS)

If the system cannot find any station on

Station list

a confirmation message for updating the list appears.
Rotate

to select

Yes

, then press

to update the

list.

Except AM/FM/DAB mode

Audio System Basic Operation

Playing AM/FM Radio

316

Features

■

Traffic announcement (TA) button

TA standby function allows the system to stand by for traffic announcements in any
mode. The last tuned station must be an RDS-capable traffic programme station.

To turn the function on:

Press the

button. When a traffic announcement

begins on your last tuned station, the system automatically switches to the FM
mode. TA-INFO appears on the display. The system returns to your last selected
mode after the traffic announcement is finished.

If you want to go back to your last selected mode during the traffic announcement,
press the

button again.

To cancel the function:

Press the

button.

Radio Data System (RDS)

When you press the

button, the

indicator

appears on the display.

If you select

Scan

while the TA standby function is

on, the system searches TP station only.

Pressing the

button while the traffic

announcement is on does not cancel the TA standby
function.

Honda CR-V (2022 year). Manual in english - page 19
