253

uu

Seats

u

Second Row Seats

Continued

Co
ntrols

4.

Pull the release lever and fold down the
seat.

Release Lever

From the luggage area side

uu

Seats

u

Second Row Seats

254

Co
ntrols

Separately fold down the left and right halves of the second row seat to make room
for luggage.

1.

Lower the centre head restraint to its lowest
position. Put the armrest back into the seat-
back.

2.

Pull up on the seat-back angle adjustment
strap.

To return the seat to the original position, pull
up the seat-back in the upright position.

■

Folding Down the Second Row Seats

Models with third row seat

1

Folding Down the Second Row Seats

The front seats must be far enough forward so they
do not interfere with the second row seats as they
fold down.

To lock the seat-back upright, push it backwards until
it locks.

Make sure the seat-back, head restraints and seat
cushion are securely latched back into place before
driving. Also, make sure all rear shoulder belts are
positioned in front of the seat-back, and the centre
shoulder belt is re-positioned in the holding slot.

Strap

Continued

255

uu

Seats

u

Second Row Seats

Co
ntrols

1.

Lower the second row seat head restraint to
its lowest position.

2.

Pull up the strap that is located at the
shoulder of the seat, and fold down the
seat-back.

3.

While pulling the lever, move the entire seat
forward.

■

Third Row Seat Access

Models with third row seat

1

Third Row Seat Access

When you enter the third row seat, be careful not to
trip over the second row seat belt.

The front seats must be far enough forward so they
do not interfere with the second row seats as they
fold down.

Strap

Lever

256

uu

Seats

u

Second Row Seats

Co
ntrols

4.

Lift up the entire seat while pulling up the
strap on the seat.

5.

Hang the hook strap that is located next to
the seat to the pillar, and fix it.

Strap

Hook

Hook Strap

257

uu

Seats

u

Third Row Seats

*

Continued

Co
ntrols

Third Row Seats

*

■

Adjusting the Seat Positions

1

Third Row Seats

*

Once a seat is adjusted correctly, rock it back and
forth to make sure it is locked in position.

Seat-back Angle
Adjustment

Pull the strap to change
the angle.

Strap

* Not available on all models

uu

Seats

u

Third Row Seats

*

258

Co
ntrols

Separately fold down the left and right halves of the third row seat to make room
for luggage.

■

To fold down the seat

1.

Lower the third row seat head restraint to
its lowest position.

2.

Pull the strap on the seat-back fully.

3.

Push the seat-back forward while pulling
the strap.

u

If you want to use the luggage area
flatly, put the floor lid in the upper
position.

2

Luggage Storage Area

 P. 272

■

To return the seat to the original position

1.

Pull the seat-back up with the strap pulled.

2.

Pull the head restraint up to its original
position.

■

Folding Down the Third Row Seat

Models with third row seat

1

Folding Down the Third Row Seat

Make sure all items in the luggage area or items
extending to the third row seats are properly
secured. Loose items can fly forward if you have
to brake hard.

Strap

1

To return the seat to the original position

Make sure the seat-back and head restraints are
securely latched back into place before driving.

Strap

259

uu

Seats

u

Maintain a Proper Sitting Position

Co
ntrols

Maintain a Proper Sitting Position

After all occupants have adjusted their seats and head restraints, and put on their
seat belts, it is very important that they continue to sit upright, well back in their
seats, with their feet on the floor, until the vehicle is safely parked and the engine is
off.

Sitting improperly can increase the chance of injury during a crash. For example, if
an occupant slouches, lies down, turns sideways, sits forward, leans forward or
sideways, or puts one or both feet up, the chance of injury during a crash is greatly
increased.

In addition, an occupant who is out of position in the front seat can be seriously or
fatally injured in a crash by striking interior parts of the vehicle or being struck by an
inflating front airbag.

1

Maintain a Proper Sitting Position

3

WARNING

Sitting improperly or out of position can
result in serious injury or death in a crash.

Always sit upright, well back in the seat,
with your feet on the floor.

260

uu

Seats

u

Head Restraints

Co
ntrols

Head Restraints

Your vehicle is equipped with head restraints in all seating positions.

Head restraints are most effective for
protection against whiplash and other rear-
impact crash injuries when the centre of the
back of the occupant’s head rests against the
centre of the restraint. The tops of the
occupant’s ears should be level with the
centre height of the restraint.

To raise the head restraint:

 Pull it upward.

To lower the head restraint:

 Push it down

while pressing the release button.

■

Adjusting the Front Head Restraints

1

Adjusting the Front Head Restraints

In order for the head restraint system to work
properly:

•

Do not hang any items on the head restraints, or
from the restraint legs.

•

Do not place any objects between an occupant and
the seat-back.

•

Install each restraint in its proper location.

3

WARNING

Improperly positioning head restraints
reduces their effectiveness and increases
the likelihood of serious injury in a crash.

Make sure head restraints are in place and
positioned properly before driving.

Position head in the centre
of the head restraint.

Continued

261

uu

Seats

u

Head Restraints

Co
ntrols

To tilt the head restraint forward:

Push the back of it forward.

To tilt the head restraint backward:

Push it backward while pressing the release
button on the side of the head restraint.

A passenger sitting in the second row seat
seating position should adjust the height of
their head restraint to an appropriate position
before the vehicle begins moving.

To raise the head restraint:

Pull it upward.

To lower the head restraint:

Push it down while pressing the release
button.

■

Changing the Second Row Seat Head Restraint Position

Models without third row seat

1

Changing the Second Row Seat Head Restraint Position

When you use the head restraint in the second row
centre seating position, pull up the head restraint to
its highest position. Do not use it in any lower
position.

uu

Seats

u

Head Restraints

262

Co
ntrols

A passenger sitting in the second row and
third row seating position should adjust the
height of their head restraint to an
appropriate position before the vehicle begins
moving.

To raise the head restraint:

Pull it upward.

To lower the head restraint:

Push it down while pressing the release
button(s).

■

Changing the Second Row and Third Row Seat Head

Restraint Position

Models with third row seat

1

Changing the Second Row and Third Row Seat Head Restraint
Position

When you use the head restraint in the second row
and third row seating position, pull up the head
restraint to its highest position. Do not use it in any
lower position.

Second row seat

Third row seat

263

uu

Seats

u

Head Restraints

Co
ntrols

Head restraints can be removed for cleaning or repair.

To remove a head restraint:

Pull the restraint up as far as it will go. Then push the release button, and pull the
restraint up and out.

To reinstall a head restraint:

Insert the legs back in place, then adjust the head restraint to an appropriate height
while pressing the release button. Pull up on the restraint to make sure it is locked
in position.

■

Removing and Reinstalling the Head Restraints

1

Removing and Reinstalling the Head Restraints

3

WARNING

Failure to reinstall, or correctly reinstall, the
head restraints can result in severe injury
during a crash.

Always replace the head restraints before
driving.

264

uu

Seats

u

Armrest

Co
ntrols

Armrest

The console lid can be used as an armrest.

To adjust:

Slide the armrest to a desired position.

Pull down the armrest in the centre seat-back.

■

Using the Front Seat Armrest

■

Using the Second Row Seat Armrest

265

Continued

Co
ntrols

Interior Convenience Items

Interior Lights

■

ON

The interior lights come on regardless of
whether the doors are open or closed.

■

Door activated

The interior lights come on in the following
situations:

•

When any doors are opened.

•

You unlock the driver’s door.

•

You remove the key from the ignition
switch.

•

When the power mode is set to VEHICLE
OFF (LOCK).

■

OFF

The interior lights remain off regardless of
whether the doors are open or closed.

■

Interior Light Switches

1

Interior Light Switches

In the door activated position, the interior lights fade
out and go off about 30 seconds after the doors are
closed.
The lights go off after about 30 seconds in the
following situations:

•

When you unlock the driver’s door but do not open
it.

•

When you remove the key from the ignition switch
but do not open a door.

•

When you set the power mode to VEHICLE OFF
(LOCK) but do not open a door.

You can change the interior lights dimming time.

2

Customized Features

 P. 157

2

Customized Features

 P. 408

The interior lights go off immediately in the following
situations:

•

When you lock the driver’s door.

•

When you close the driver’s door with the key in
the ignition switch.

•

When you close the driver’s door in ACCESSORY
mode.

•

When you set the power mode to ON.

Models without keyless access system

Models with keyless access system

Models with colour audio system

Models with Display Audio

Models without keyless access system

Models with keyless access system

Door Activated Position

Off

On

Models without keyless access system

Models with keyless access system

uu

Interior Convenience Items

u

Interior Lights

266

Co
ntrols

1

Interior Light Switches

To avoid draining the battery, do not leave the
interior light on for an extended length of time when
the engine is off.

If you leave any of the doors open in VEHICLE OFF
(LOCK) mode, or without the key in the ignition
switch, the interior lights go off after about 15
minutes.

Continued

267

uu

Interior Convenience Items

u

Interior Lights

Co
ntrols

■

Front seat

The map lights can be turned on and off by
pressing the

 (map light) button.

■

Second row seat

The map lights can be turned on and off by
pressing the

 (map light) button.

■

Map Lights

1

Map Lights

When the interior light switch is in the door activated
position and a door is opened or interior light switch
is in the

ON

 position, the rear map light will not go

off when you press the

 (map light) button.

Models with panoramic roof

Front

Rear

uu

Interior Convenience Items

u

Interior Lights

268

Co
ntrols

The luggage area lights come on when you
open the tailgate.

■

Luggage Area Lights

1

Luggage Area Lights

The luggage area lights do not have an on/off switch.
In case the tailgate is left open for an extended period
of time, they automatically go out in 30 minutes.

Models without third row seat

Models with third row seat
