237

uu

Operating the Switches Around the Steering Wheel

u

Brightness Control

Continued

Co
ntrols

Brightness Control

When the brightness of the meter is reduced,
you can use the

 (TRIP) knob to adjust

instrument panel brightness.

Brighten:

Turn the knob to the right.

Dim:

Turn the knob to the left.

Several seconds after you have adjusted the
brightness, you will be returned to the
previous screen.

■

Brightness level indicator

The brightness level is shown on the display
while you are adjusting it.

*1: Models with the keyless access system have an

ENGINE START/STOP

 button instead of an

ignition switch.

■

Adjusting the Instrument Panel Brightness

1

Brightness Control

The brightness of the instrument panel will be
reduced when the following condition have been
met:

•

The ignition switch is in ON

(

w

*1

.

•

The position lights are turned on.

•

The ambient lighting is low.

The brightness can be set differently for when the
exterior lights are on, and when they are off.

 (TRIP) Knob

238

uu

Operating the Switches Around the Steering Wheel

u

Brightness Control

Co
ntrols

You can operate the head-up display to press
the

HUD

 button for about one second when

the power mode is in ON.

When the head-up display is on, press and
hold the

HUD

 button until its brightness level

indicator on the driver information interface.

Brighten:

Press the

 button.

Dim:

Press the

 button.

The driver information interface will return to
its original state several seconds after you
adjust the brightness.

■

Brightness level indicator

The brightness level is shown on the driver
information interface while you are adjusting
it.

■

Adjusting the Head-up Display Brightness

*

HUD

 Button

 Button

3

 Button

4

3

4

* Not available on all models

239

uu

Operating the Switches Around the Steering Wheel

u

Driving Position Memory System

*

Continued

Co
ntrols

Driving Position Memory System

*

You can store two driver’s seat positions (except for power lumbar) with the driving
position memory system.

When you unlock and open the driver’s door with a remote transmitter or the
keyless access system, the seat adjusts automatically to one of the two preset
positions.

•

DRIVER 1

 transmitter is linked to memory button 1.

•

DRIVER 2

 transmitter is linked to memory button 2.

1

Driving Position Memory System

*

Using the audio/information screen, you can disable
the automatic seat adjustment function.

2

Customized Features

 P. 408

System Operation
The system will not operate if:

•

The vehicle speed is above 5 km/h (3 mph).

•

The transmission is out of the

(

P

 position.

(continuously variable transmission)

•

Release the parking brake (manual transmission).

•

Either memory button is pressed while the seat is in
motion.

•

The seat position is adjusted while in operation.

•

The memory

1

 or

2

 position is set fully to the rear.

DRIVER 1

DRIVER 2

* Not available on all models

uu

Operating the Switches Around the Steering Wheel

u

Driving Position Memory System

*

240

Co
ntrols

1.

Set the power mode to ON. Adjust the
driver’s seat to the desired position.

2.

Press the

SET

 button.

u

The memory button indicator light will
blink.

3.

Press and hold memory button

(

1

 or

(

2



within five seconds of pressing the

SET



button.

u

Once the seat position has been
memorized, the indicator light on the
button you pressed stays on.

1.

Put the transmission into

(

P

.

2.

Press a memory button (

(

1

 or

(

2

).

u

The indicator light will blink.

1.

Apply the parking brake.

2.

Press a memory button (

(

1

 or

(

2

).

u

The indicator light will blink.

The seat will automatically move to the
memorized position. When it has finished
moving, the indicator light stays on.

■

Storing a Position in Memory

1

Storing a Position in Memory

After you press the

SET

 button, the storing operation

will be cancelled when:

•

You do not press the memory button within five
seconds.

•

You readjust the seat position before the double-
beep.

•

You set the power mode to any position except
ON.

SET

 Button

Memory
Button 1

Memory
Button 2

■

Recalling the Stored Position

1

Recalling the Stored Position

The seat will stop moving if you:

•

Press the

SET

 button, or a memory button (

(

1

 or

(

2

).

•

Adjust the seat position.

•

Put the transmission into a position other than

(

P



(continuously variable transmission).

•

Release the parking brake (manual transmission).

Memory
Button 1

Memory
Button 2

Continuously variable transmission models

Manual transmission models

241

uu

Operating the Switches Around the Steering Wheel

u

Adjusting the Steering Wheel

Co
ntrols

Adjusting the Steering Wheel

The steering wheel height and distance from your body can be adjusted so that you
can comfortably grip the steering wheel in an appropriate driving posture.

1.

Pull the steering wheel adjustment lever up.

u

The steering wheel adjustment lever is
under the steering column.

2.

Move the steering wheel up or down, and
in or out.

u

Make sure you can see the instrument
panel gauges and indicators.

3.

Push the steering wheel adjustment lever
down to lock the steering wheel in position.

u

After adjusting the position, make sure
you have securely locked the steering
wheel in place by trying to move it up,
down, in, and out.

1

Adjusting the Steering Wheel

3

WARNING

Adjusting the steering wheel position while
driving may cause you to lose control of the
vehicle and be seriously injured in a crash.

Adjust the steering wheel only when the
vehicle is stopped.

To adjust

To lock

Lever

242

Co
ntrols

Mirrors

Interior Rearview Mirror

Adjust the angle of the rearview mirror when you are sitting in the correct driving
position.

Flip the tab to switch the position.
The night position will help to reduce the glare
from headlights behind you when driving
after dark.

When you are driving after dark, the
automatic dimming rearview mirror reduces
the glare from headlights behind you, based
in inputs from the mirror sensor. This feature
is always active.

■

Rearview Mirror with Day and Night Positions

*

1

Mirrors

Keep the inside and outside mirrors clean and
adjusted for best visibility.

Adjust the mirrors before you start driving.

2

Front Seats

 P. 246

Tab

Daytime
Position

Night
Position

■

Automatic Dimming Rearview Mirror

*

Sensor

1

Automatic Dimming Rearview Mirror

*

The auto dimming function cancels when the
transmission is in

(

R

.

* Not available on all models

243

uu

Mirrors

u

Power Door Mirrors

Continued

Co
ntrols

Power Door Mirrors

You can adjust the door mirrors when the
ignition switch is in ON

(

w

*1

.

■

Mirror position adjustment

L/R selector switch:

 Select the left or right

mirror. After adjusting the mirror, return the
switch to the centre position.

Mirror position adjustment switch:

 Press

the switch left, right, up, or down to move the
mirror.

■

Folding door mirrors

Press the folding button to fold in and out the
door mirrors.

*1: Models with the keyless access system have an

ENGINE START/STOP

 button instead of an

ignition switch.

Selector
Switch

Adjustment
Switch

Folding
button

244

uu

Mirrors

u

Power Door Mirrors

Co
ntrols

If activated, the passenger side door mirror
automatically tilts downward when you put
the transmission into

(

R

; this improves close-

in visibility on the passenger side of the vehicle
when backing up. The mirror automatically
returns to its original position when you take
the transmission out of

(

R

.

To activate this feature, set the ignition switch
is in ON

(

w

*1

, and slide the selector switch to

the passenger’s side.

*1: Models with the keyless access system have an

ENGINE START/STOP

 button instead of an

ignition switch.

■

Reverse Tilt Door Mirror

*

Selector Switch

* Not available on all models

245

uu

Mirrors

u

Power Door Mirrors

Co
ntrols

■

Folding in the door mirrors

Press the lock button on the remote transmitter twice within 10 seconds, and hold
it.

u

You can release the button once the mirrors start folding in automatically.

Touch the door lock button on either front door or the tailgate twice within 10
seconds.

u

The mirrors start folding in automatically.

■

Folding out the door mirrors

Unlock all doors and the tailgate using the remote transmitter. Open the driver’s
door.

u

The mirrors start folding out automatically.

Grab the door handle on either front door and unlock all doors. Open the driver’s
door.

u

The mirrors start folding out automatically.

■

Automatic Folding Door Mirror Function

*

1

Automatic Folding Door Mirror Function

*

You cannot turn the automatic folding out
automatically if they have been folded in using the
folding button.

Door mirrors will not fold automatically when locking
from inside the vehicle using lock tab or master door
lock switch.

Models with keyless access system

Models with keyless access system

* Not available on all models

246

Co
ntrols

Seats

Front Seats

Adjust the driver’s seat as far back as possible
while allowing you to maintain full control of
the vehicle. You should be able to sit upright,
well back in the seat and be able to
adequately press the pedals without leaning
forward, and grip the steering wheel
comfortably. The passenger’s seat should be
adjusted in a similar manner, so that it is as far
back from the front airbag in the dashboard
as possible.

■

Adjusting the front power seat

*

1

Seats

In addition to the seat adjustment, you can adjust the
steering wheel up and down, in and out. Allow at
least 25 cm between the centre of the steering wheel
and the chest.

Always make seat adjustments before driving.

3

WARNING

Sitting too close to a front airbag can result
in serious injury or death if the front
airbags inflate.

Always sit as far back from the front
airbags as possible while maintaining
control of the vehicle.

Move back.

Allow sufficient
space.

■

Adjusting the Seat Positions

Horizontal
Position
Adjustment

Height
Adjustment

*



(Driver’s seat
only)

Seat-back Angle
Adjustment

* Not available on all models

247

uu

Seats

u

Front Seats

Continued

Co
ntrols

■

Lumbar Support Adjustment Switch

*

Press the top:

To increase the higher part of

the lumbar support.

Press the bottom:

To increase the lower part

of the lumbar support. (The higher part
support is decreased.)

Press the front:

To increase the entire

lumbar support.

Press the rear:

To decrease the entire lumbar

support.

Lumbar Support
Adjustment Switch

* Not available on all models

uu

Seats

u

Front Seats

248

Co
ntrols

■

Adjusting the front manual seat(s)

*

1

Adjusting the front manual seat(s)

*

Once a seat is adjusted correctly, rock it back and
forth to make sure it is locked in position.

Horizontal Position
Adjustment

Pull up on the bar to move the
seat, then release the bar.

Height Adjustment

*

Pull up or push down the lever
to raise or lower the seat.

Seat-back Angle
Adjustment

Pull up the lever to
change the angle.

* Not available on all models

249

uu

Seats

u

Front Seats

Co
ntrols

Adjust the driver’s seat-back to a comfortable,
upright position, leaving ample space
between your chest and the airbag cover in
the centre of the steering wheel.

The front seat passenger should also adjust
their seat-back to a comfortable, upright
position.

Reclining a seat-back so that the shoulder part of the belt no longer rests against the
occupant’s chest reduces the protective capability of the belt. It also increases the
chance of sliding under the belt in a crash and being seriously injured. The farther a
seat-back is reclined, the greater the risk of injury.

■

Adjusting the Seat-Backs

1

Adjusting the Seat-Backs

Do not put a cushion, or other object, between the
seat-back and your back.

Doing so may interfere with proper seat belt or airbag
operation.

If you cannot get far enough away from the steering
wheel and still reach the controls, we recommend
that you investigate whether some type of adaptive
equipment may help.

3

WARNING

Reclining the seat-back too far can result in
serious injury or death in a crash.

Adjust the seat-back to an upright position,
and sit well back in the seat.

250

uu

Seats

u

Second Row Seats

Co
ntrols

Second Row Seats

■

Adjusting the Seat Positions

1

Second Row Seats

Once a seat is adjusted correctly, rock it back and
forth to make sure it is locked in position.

Lever

Seat-back Angle Adjustment

Pull up the lever to change the
angle.

Models without third row seat

Continued

251

uu

Seats

u

Second Row Seats

Co
ntrols

1

Second Row Seats

3

WARNING

An unsecured seat or seat-back can move
out of position or collapse without warning
if there is sudden acceleration or stop or in
a crash.

A seat or seat-back that suddenly moves or
collapses can result in severe injury or
death.

Always make sure all seats and seat-backs
are securely locked into position before
driving.

Models with third row seat

Strap

Seat-back Angle
Adjustment

Pull up the strap to
change the angle.

Models with third row seat

Lever

Horizontal Position Adjustment

Pull up on the lever to move the seat,
then release the lever.

uu

Seats

u

Second Row Seats

252

Co
ntrols

1.

Store the centre seat belt first. Insert the
latch plate into the slot on the side of the
anchor buckle.

2.

Retract the seat belt into the holder on the
ceiling.

2

Seat Belt with Detachable Anchor

*



P. 51

3.

Lower the second row seat head restraint to
its lowest position. Put the armrest back
into the seat-back.

4.

Pull the release lever and fold down the
seat.

■

Folding Down the Second Row Seats

Models without third row seat

1

Folding Down the Second Row Seats

The rear seat-backs can be folded down to
accommodate bulkier items in the luggage area.

When returning the seat-back to its original position,
push it firmly back. Also, make sure all rear shoulder
belts are positioned in front of the seat-back.

Make sure all items in the luggage area or items
extending through the opening into the rear
seats are properly secured. Loose items can fly
forward if you have to brake hard.

3

WARNING

Make sure the seat-backs are latched
securely before driving.

Latch plate

Anchor buckle

Release
Lever

From the second row seat side

* Not available on all models
