20-190
Openers
In-Bed Trunk Lid Lock Cylinder Replacement
A
D
E
B
C
NOTE:
• Put on gloves to protect your hands.
• Take care not to scratch the in-bed trunk lid.
1. Remove the nuts, then remove the in-bed trunk lid
opener from the in-bed trunk lid (see step 4 on page
20-188).
2. Remove the opener seat from the in-bed trunk lid
opener as needed (see step 7 on page 20-189).
3. Insert the key (A) to the in-bed trunk lid lock
cylinder (B). Remove the lock cylinder by pulling
out it while pulling the pin (C) by using pliers (D).
4. Install the lock cylinder in the reverse order of
removal, and note these items:
• Position the lock cylinder with the keyed pin hole
(E) facing up. Push the lock cylinder into the
opener until the pin clicks into place.
• Make sure the opener seat is installed properly.
• Make sure the in-bed trunk lid opens properly.
