Geely FC. Manual part - 93
Engine cover/automobile door--Front automobile door Overhaul Hint: z When assembling, please work by the sequence which is opposite with disassembling sequence; but when it has items that need to pay special attention, it will add special specification. z Overhaul procedure for right side is same as the left side. z Please refer to subassembly figure of front door on page 360. 1. Disassemble left front door control panel assembly [68000142] (a) Disassemble the screw. (b) Use screw driver to disassemble left front door control panel assembly. Hint: before using screw driver, it is necessary to wrap its needled top with adhesive tape. (c) Disassemble the joint. 2. Disassemble left front door inner defending board assembly [68010049] (a) Disassemble the screw. (b) Without equipping with door control light: use screw driver to disassemble door inner defending board assembly. (c) Equipping with door control light: use screw driver to disassemble door inner defending board assembly, then disassemble the joint again. (d) Equipping with door control light: use screw driver to disassemble door control light. 3. Disassemble left door inner handle assembly [68010051] (a) Disassemble inner handle, and disassemble two pull cables from inner handle. 4. Disassemble repairing hole cover of left front door 5. Disassemble left front small loudhail cover assembly [67000131] 369 6. Disassemble left exterior electric rearview mirror assembly [67000155] (a) Disassemble the joint. (b) Disassemble three screw caps and left exterior electric rearview mirror. 7. Disassemble exterior seal tape of left front door glass [68000158] |
