Ford Transit (2022 year). Manual in english - page 5

4. Select a setting and press the

OK

button.

5. Configure the setting.

6. Switch the ignition off.

CLEARING ALL MYKEYS

When you clear all MyKeys, you remove all
restrictions and return all MyKeys to their
original admin key status.

1.

Switch the ignition on using an admin
key.

2. Using the information display controls

on the steering wheel, select

Settings

.

3. Select

MyKey

.

4. Select

Clear MyKeys

.

5. Press and hold the

OK

button until a

confirmation message appears in the
information display.

CHECKING MYKEY SYSTEM
STATUS

You can find information about the
distance traveled using a MyKey and also
the number of admin keys and MyKeys
created for your vehicle.

1.

Switch the ignition on.

2. Using the information display controls

on the steering wheel, select

Settings

.

3. Select

MyKey

.

4. Select

MyKey Info

.

USING MYKEY WITH REMOTE
START SYSTEMS

The system is not compatible with
non-Ford remote start systems.

MYKEY – TROUBLESHOOTING

MYKEY – INFORMATION MESSAGES - VEHICLES WITH: KEYED IGNITION

Description

Message

Displays when trying to create a MyKey with a key already
designated as a MyKey.

Key is Already a MyKey

Displays to confirm that the key is restricted after you switch
the ignition off.

This Key restricted at
Next Key Cycle. Label
Key as MyKey

85

MyKey™

MYKEY – INFORMATION MESSAGES - VEHICLES WITH: PUSH BUTTON
START

Description

Message

Displays when trying to create a MyKey and the admin key is
not placed in the backup position. See

Creating a MyKey

Place Key in Backup
Location

Displays when trying to create a MyKey with a key already
designated as a MyKey.

Key is Already a MyKey

Displays to confirm that the key is restricted after you switch
the ignition off.

This Key restricted at
Next Key Cycle. Label
Key as MyKey

86

MyKey™

MYKEY – FREQUENTLY ASKED
QUESTIONS - VEHICLES WITH:
KEYED IGNITION

What is an admin key?

•

An admin key is a key that has not been
created as a MyKey. See

Why can I not create a MyKey?

•

The key used to switch the ignition on
is not an admin key.

•

The key used to switch the ignition on
is the only admin key. There always has
to be at least one admin key.

Why can I not program a MyKey?

•

The key used to switch the ignition on
is not an admin key.

•

No MyKeys are created. See

Why can I not clear the MyKeys?

•

The key used to switch the ignition on
is not an admin key.

•

No MyKeys are created. See

Why does the MyKey distance not
accumulate?

•

The key used to start the engine is an
admin key.

•

No MyKeys are created. See

•

The MyKeys have been cleared.

MYKEY – FREQUENTLY ASKED
QUESTIONS - VEHICLES WITH:
PUSH BUTTON START

What is an admin key?

•

An admin key is a key that has not been
created as a MyKey. See

Why can I not create a MyKey?

•

The admin key is not placed in the
backup position. See

•

The key used to switch the ignition on
is not an admin key.

•

The key used to switch the ignition on
is the only admin key. There always has
to be at least one admin key.

•

The last MyKey was created without
switching the ignition off.

Why can I not program a MyKey?

•

The admin key is not inside your
vehicle.

•

The key used to switch the ignition on
is not an admin key.

•

No MyKeys are created. See

Why can I not clear the MyKeys?

•

The admin key is not inside your
vehicle.

•

The key used to switch the ignition on
is not an admin key.

•

No MyKeys are created. See

87

MyKey™

Why does the MyKey distance not
accumulate?

•

The key used to start the engine is an
admin key.

•

An admin key and a MyKey are inside
your vehicle.

•

No MyKeys are created. See

•

The MyKeys have been cleared.

Why can I not start the engine with
a MyKey?

•

An admin key and a MyKey are inside
your vehicle.

88

MyKey™

OPERATING THE DOORS
FROM OUTSIDE YOUR
VEHICLE

UNLOCKING AND LOCKING THE
DOORS USING THE REMOTE
CONTROL

You can only use the remote control when
your vehicle is stationary.

Unlocking the Doors

E267112

Press the button to unlock all
doors.

Locking the Doors

E267111

Press the button to lock all
doors. One short flash of the
turn signal lamps confirms that

your vehicle has locked.

Note:

For more information on operating

the doors from outside your vehicle See

Keyless Entry

UNLOCKING AND LOCKING THE
DOORS USING THE KEY BLADE

Unlocking the Doors

1.

Release the key blade from the remote
control.

2. Fully insert the key into the driver door

lock cylinder.

3. Turn the top of the key toward the front

of your vehicle.

Locking the Doors

1.

Release the key blade from the remote
control.

2. Fully insert the key into the driver door

lock cylinder.

3. Turn the top of the key toward the rear

of your vehicle.

OPENING AND CLOSING THE
DOORS

Opening the Double Rear Doors

E148805

E148806

89

Doors and Locks

Fully Opening the Double Rear
Doors

E178366

1.

Slide the lever to release the catch.

2. Fully open the cargo door.

OPERATING THE DOORS
FROM INSIDE YOUR VEHICLE

UNLOCKING AND LOCKING THE
DOORS USING THE CENTRAL
LOCKING

E148829

A

B

Lock

A

Unlock

B

OPENING THE REAR DOORS
FROM INSIDE YOUR VEHICLE IN
AN EMERGENCY

Wagon and Bus

E236264

90

Doors and Locks

1.

Lift the locking button up.

E179501

2. Pull the interior handle up to open the

door in an emergency.

OPENING THE DOORS FROM
INSIDE YOUR VEHICLE

Double Rear Door

E175828

1.

Lift the locking button up.

E255876

2. Pull the upper release lever toward you

or slide the lower release lever
downward to open the door.

E148806

3. Pull the release lever to open the other

door.

REPROGRAMMING THE
UNLOCKING FUNCTION

You can program the unlocking function
so that only the driver door, or cabin door
unlocks.

91

Doors and Locks

Press and hold the unlock and lock buttons
on the remote control simultaneously for
at least four seconds with the ignition off.
The direction indicators flash twice to
confirm the change.

To return to the original unlocking function,
repeat the process.

If you program the unlocking function so
that only the driver door, or cabin door
unlocks, the following occurs:
•

If you unlock the driver door, or cabin
door first, all other doors remain locked.
You can unlock all of the other doors
from inside your vehicle using the
power door lock control on the driver
door or cabin door. Doors can be
individually unlocked by pulling the
interior door handles on those doors.

•

If you press the unlocking button on the
remote control once, only the driver
door, or cabin door unlocks. Press the
unlocking button on the remote control
twice within three seconds to unlock
all doors.

•

If you unlock any other door first, all
other doors and the liftgate unlock.

Note:

Depending on the locking

mechanism, you can program the unlocking
function to unlock the driver door or the
cabin doors.

You can also change between the
unlocking modes in the information
display.

1.

Using the information display controls
on the steering wheel, select

Settings

.

2. Select

Vehicle Settings

.

3. Select

Locks

.

4. Select

Remote Unlock

.

5. Select

All Doors

or

Driver's Door

.

AUTOUNLOCK

WHAT IS AUTOUNLOCK

Autounlock is an unlocking feature that
unlocks the vehicle doors when your
vehicle comes to a stop.

AUTOUNLOCK REQUIREMENTS

Autounlock unlocks all the doors when all
of the following occur:
•

The ignition is on, all the doors are
closed and your vehicle is moving at a
speed greater than 12 mph (20 km/h).

•

Your vehicle comes to a stop.

•

You open the driver door within 10
minutes of switching the ignition off or
to the accessory position.

SWITCHING AUTOUNLOCK ON
AND OFF

1.

Using the information display controls
on the steering wheel, select

Settings

.

2. Select

Vehicle Settings

.

3. Select

Locks

.

4. Switch

Autounlock

on or off.

AUTOLOCK

WHAT IS AUTOLOCK

Autolock is a locking feature that locks the
vehicle doors when you start driving.

92

Doors and Locks

AUTOLOCK REQUIREMENTS

Autolock locks all the doors when all of the
following occur:
•

All doors are closed.

•

The ignition is on.

•

Your vehicle reaches a speed greater
than 12 mph (20 km/h).

AUTORELOCK

(IF EQUIPPED)

HOW DOES AUTORELOCK WORK

The doors automatically relock if you do
not open a door within 30 seconds of
unlocking the doors with the remote
control. The door locks and the alarm
return to their previous state.

DOOR LOCK INDICATORS

An LED on the power door lock control
illuminates when you lock the door. It
remains on for up to five minutes after you
switch the ignition off.

DOORS AND LOCKS AUDIBLE
WARNINGS

Door Ajar Audible Warning

Sounds when a door is not fully closed and
your vehicle is moving.

DOORS AND LOCKS –
TROUBLESHOOTING

DOORS AND LOCKS – WARNING
LAMPS

Door Ajar Warning Lamp

E249859

It illuminates when you switch
the ignition on and remains on if
any door or the hood is open.

DOORS AND LOCKS – INFORMATION MESSAGES

Action

Message

Displays if a door is open. Fully close the door.

Driver Door Ajar

Passenger Door Ajar

Rear Left Door Ajar

Rear Right Door Ajar

93

Doors and Locks

SLIDING DOOR PRECAUTIONS

WARNING:

Fully close the sliding

door before driving, to prevent
passengers and cargo from falling out.
Failure to follow this instruction could
result in personal injury or death.

WARNING:

Do not open or close

the sliding door when your hands are
near the tracks or rollers. Failure to
follow this instruction could result in
personal injury.

Note:

Do not leave the sliding door open

when you are driving. This could damage
the sliding door and its components.

OPENING THE SLIDING DOOR

OPENING THE SLIDING DOOR

FROM INSIDE YOUR VEHICLE

E148804

Pull the interior door handle to open the
sliding door.

OPENING THE SLIDING DOOR
FROM OUTSIDE YOUR VEHICLE

E293743

Pull the exterior door handle to open the
sliding door.

CLOSING THE SLIDING DOOR

CLOSING THE SLIDING DOOR
FROM INSIDE YOUR VEHICLE

E171966

1

2

94

Sliding Door - Vehicles Without: Power Sliding Door

1.

Pull the interior door handle to release
the door check feature.

2. Slide the door to close.

CLOSING THE SLIDING DOOR
FROM OUTSIDE YOUR VEHICLE

E172313

1

2

1.

Pull the exterior door handle to release
the door check feature.

2. Slide the door to close.

95

Sliding Door - Vehicles Without: Power Sliding Door

SLIDING DOOR PRECAUTIONS

WARNING:

Fully close the power

sliding door before driving, to prevent
passengers and cargo from falling out.
Failure to follow this instruction could
result in personal injury or death.

WARNING:

Do not open or close

the power sliding door when your hands
are near the tracks or rollers. Failure to
follow this instruction could result in
personal injury.

WARNING:

When closing the

power sliding door, verify that it is free of
obstruction and make sure that people
and pets are not in the proximity of the
sliding door opening.

Note:

Do not leave the sliding door open

when you are driving. This could damage
the sliding door and its components.

Note:

If you operate the sliding door often

during a short period of time, the system
could become not available for a certain
time to prevent damage due to overheating.

Allow the system to open the sliding door.
Do not manually push or pull the sliding
door when it is moving. This could damage
the sliding door and its components.

OPENING THE SLIDING DOOR

OPENING THE SLIDING DOOR
FROM INSIDE YOUR VEHICLE

Opening the Sliding Door From
Inside Your Vehicle Using the
Instrument Panel Button

E293692

Press the button on the
instrument panel twice to open
the sliding door.

Opening the Sliding Door From
Inside Your Vehicle Using the
Sliding Door Handle

E310708

1.

Lift the locking button up.

E148804

2. Pull and release the interior sliding door

handle to open the sliding door.

96

Sliding Door - Vehicles With: Power Sliding Door

OPENING THE SLIDING DOOR
FROM OUTSIDE YOUR VEHICLE

E293743

Pull and release the exterior door handle
to open the sliding door.

OPENING THE SLIDING DOOR
WITH THE REMOTE CONTROL

E293692

Press the button on the remote
control twice within three
seconds.

CLOSING THE SLIDING DOOR

CLOSING THE SLIDING DOOR
FROM INSIDE YOUR VEHICLE

Closing the Sliding Door From
Inside Your Vehicle Using the
Instrument Panel Button

E293692

Press the button on the
instrument panel to close the
sliding door. A tone sounds when

the sliding door begins to close.

Closing the Sliding Door From
Inside Your Vehicle Using the
Sliding Door Handle

E293744

Pull and release the interior sliding door
handle to close the sliding door.

97

Sliding Door - Vehicles With: Power Sliding Door

CLOSING THE SLIDING DOOR
FROM OUTSIDE YOUR VEHICLE

E293742

Pull and release the exterior door handle
to close the sliding door.

CLOSING THE SLIDING DOOR
WITH THE REMOTE CONTROL

E293692

Press the button on the remote
control twice within three
seconds. A tone sounds when

the sliding door begins to close.

STOPPING THE SLIDING DOOR
MOVEMENT

You can stop the sliding door movement
by doing any of the following:
•

Pressing the sliding door button on the
remote control twice within three
seconds.

•

Pressing the sliding door button on the
instrument panel.

•

Pulling the sliding door interior or
exterior door handle.

RESETTING THE POWER
SLIDING DOOR

Make sure that you complete the
procedure within 10 seconds.

To reset the power sliding door do the
following:

1.

Manually close the sliding door.

Note:

Make sure that the sliding door is fully

closed.

2. Pull the interior door handle in closing

direction three times within three
seconds.

98

Sliding Door - Vehicles With: Power Sliding Door

SLIDING DOOR – TROUBLESHOOTING

SLIDING DOOR – INFORMATION MESSAGES

Action

Message

The system has malfunctioned. Manually close the power
sliding door. Pull and release the power sliding door handle
to open the power sliding door.
If the message continues to appear, have your vehicle
checked as soon as possible.

Right Power Sliding Door
Calibration Needed

Left Power Sliding Door
Calibration Needed

The system has malfunctioned. Reset the power sliding door.
See

Resetting the Power Sliding Door

If the message continues to appear, have your vehicle
checked as soon as possible.

Right Rear Door Motor
Disconnected See
Manual

Left Rear Door Motor
Disconnected See
Manual

99

Sliding Door - Vehicles With: Power Sliding Door

SLIDING DOOR – FREQUENTLY
ASKED QUESTIONS

Why does the power sliding door stop
moving?

The power sliding door stops when it
detects an obstacle. A tone sounds
and the power sliding door starts
moving in the opposite direction. After
you remove the obstacle, you can
continue to operate the power sliding
door.

Why is the power sliding door moving
with reduced speed?

You let the power sliding door open
for more than five minutes. Fully close
the power sliding door using the button
on the instrument panel or the power
sliding door handles. Open the power
sliding door as normal.

Why can I not close the power sliding
door?

If the power sliding door does not
close, restart the engine and then
close it as normal. See

Sliding Door From Inside Your
Vehicle

(page 97). If the power sliding

door still does not close, manually
close the power sliding door and then
open it as normal. If the power sliding
door still does not close the system
has malfunctioned. Have your vehicle
checked as soon as possible.

What can I do if the power sliding door
does not operate as normal?

If there is a malfunction on the power
sliding door, restart the engine.

How can I open the sliding door if the
system loses power?

If the sliding door loses power, you
could need to apply more force when
trying to open it. Push the back of the
sliding door and the interior sliding
door handle in opening direction at the
same time and open it as normal.

100

Sliding Door - Vehicles With: Power Sliding Door

Content .. 3 4 5 6 ..
