414-03B-104
414-03B-104
High Voltage/Traction Battery — Nickel Metal Hydride
REMOVAL AND INSTALLATION (Continued)
2. Remove the traction battery cover.
1 Remove the 22 bolts.
2 Remove the cover.
3.
WARNING: The nominal voltage of
the traction battery is 300 volts. The buffer
zone must be set up and insulated rubber
gloves and a face shield must be worn.
Failure to follow these precautions may
result in severe personal injury or death.
Observe the EV-specific precautions. Refer to
1 Set up the buffer zone.
2 Test and wear the insulated rubber gloves.
3 Wear the face shield.
4. Disconnect the +23 module high voltage
jumper.
5. Open the contactor box.
1 Remove the four screws.
2 Open the contactor box.
