414-03B-100
414-03B-100
High Voltage/Traction Battery — Nickel Metal Hydride
REMOVAL AND INSTALLATION (Continued)
2. Remove the traction battery cover.
1 Remove the 22 bolts.
2 Remove the cover.
3.
WARNING: The nominal voltage of
the traction battery is 300 volts. The buffer
zone must be set up and insulated rubber
gloves and a face shield must be worn.
Failure to follow these precautions may
result in severe personal injury or death.
Observe the EV-specific precautions. Refer to
1 Set up the buffer zone.
2 Test and wear the insulated rubber gloves.
3 Wear the face shield.
4.
CAUTION: Disconnect only one HVJ
at a time.
Disconnect the HVJs from the contactor box.
•
Open the cap.
•
Remove the bolt.
5. Wrap the HVJ ends with orange electrical tape.
