SECTION : 211-05 Steering Column Switches

VEHICLE APPLICATION : 2003.0 BA Falcon
CONTENTS

PAGE

DESCRIPTION AND OPERATION

  Steering Column Switches  .....................................................................................................211-05-2

  Steering Column Switches  ...................................................................................................211-05-2

DIAGNOSIS AND TESTING

  Steering Column Switches  .....................................................................................................211-05-3

  Inspection and Verification  ...................................................................................................211-05-3

 Symptom

Chart



....................................................................................................................211-05-3

  Connector Circuit Reference  ................................................................................................211-05-3

 Pinpoint

Tests



......................................................................................................................211-05-5

REMOVAL AND INSTALLATION

  Steering Column Multifunction Switch  ...................................................................................211-05-7

  Ignition Key Barrel  ..................................................................................................................211-05-7



Pedal Adjust  Switch................................................................................................................211-05-7

211-05-2 Steering

Column

Switches 211-05-2

DESCRIPTION AND OPERATION

Steering Column Switches

Steering Column Switches

The steering column switches consist of the following:

Multifunction switch
Ignition switch
Pedal adjustment switch (if fitted)

G57380 en

211-05-3 Steering

Column

Switches 211-05-3

DIAGNOSIS AND TESTING

2.  Visually inspect the ignition switch and the

Steering Column Switches

steering column multifunction switch for damage;

refer to the following chart:

Refer to Wiring Diagram Section 700-02 for schematic

and connector information.

Visual Inspection Chart

Mechanical

Special Tool(s)

Ignition switch

Multimeter

Turn signal switch (component of steering

WDS

column multifunction switch)

Wiper/washer switch (component of steering

column multifunction switch)

Pedal Adjust switch

3.  If cause of the switch concern is not visually

apparent, proceed to Symptom Chart.

Inspection and Verification

1.  Verify the customer concern by operating ignition

switch and the multifunction switch.

Symptom Chart

Condition

Source

Action

  Ignition switch is inoperative (No

Ignition switch

Go to PinPoint Test A.

Circuitry

power in ACC/ON or START)

Battery

  Wiper/washer, turn signal switch or

Steering column multifunction switch

Go to PinPoint Test B

headlamp switch does not operate

Circuitry

correctly

Battery

  Adjustable pedals do not operate

Pedal adjustment switch

Go to PinPoint Test C

Pedal box

correctly

Circuitry
Battery

Connector Circuit Reference

C167 - View of Multifunction connector - Harness side

G57381 en

211-05-4 Steering

Column

Switches 211-05-4

DIAGNOSIS AND TESTING (Continued)

Pinout

Pin Number(s)

Circuit Designation/Description

Normal Condition/Measurement

1

175 Park

Red

2

57 Earth (H/Lamps)

Yellow

3

293 BEM (Auto H/Lamp)

Grey

5

590A Rear Wipe

Orange / Brown

6

20 Dipper (High Beam)

Green / Orange

7

942 Rear Wash

Blue

8

56 Wiper (High)

S/C to GND when high wipe on

Blue / Yellow

9

58Wiper (Low)

S/C to GND when low wipe on

White / Blue

10

589 Var Wiper Earth

Orange

11

993 Var Wipe (to BEM)

See “Intermittent Wipe” table below

Brown / White

12

18 Dipper (Low Beam)

Red / Yellow

13

2 Turn RH

S/C to pin17 when RH Ind activated

Brown / White

14

2 Turn RH

S/C to pin17 when RH Ind activated

Brown / White

16

57 Wiper, Dipper, rear wiper earth

Black, violet, pink

17

8 Turn Ign

Green / Red

20

3 Turn LH

S/C to pin17 when LH Ind activated

Green

22

941 Wash (to BEM)

S/C to GND when activated

Grey / Black

23

28 Wiper (Park)

Blue / Pink

24

59C Wiper (Int)

Green / White

Intermittent Wipe Resistance values

Detent

Resistance

1

400 - 600

Ω

2

1,372 - 1,678

Ω

3

2300 - 2800

Ω

4

3,218 - 3,933

Ω

5

4,140 - 5,060

Ω

G57381 en
