276

Connect Nav

"Radio Media" voice

commands

Voice commands



Turn on source radio - Streaming Bluetooth

- …

Help messages



You can select an audio source by saying "turn
on source" followed by the device name. For
example, "turn on source, Streaming Bluetooth",
or "turn on source, radio". Use the command
"play" to specify the type of music you'd like to
hear. You can choose between "song", "artist",
or "album". Just say something like "play artist,
Madonna", "play song, Hey Jude", or "play
album, Thriller".

Voice commands



Tune to channel BBC Radio 2

Tune to 98.5 FM

Tune to preset number five

Help messages



You can pick a radio station by saying "tune to"
and the station name or frequency. For example

"tune to channel Talksport" or "tune to 98.5

FM". To listen to a preset radio station, say for

example "tune to preset number five".

* This function is available only if the telephone connected to the system supports downloading of contacts and recent calls and the corresponding
download has been performed.

Voice commands



What's playing?

Help messages



To choose what you'd like to play, start by saying
"play" and then the item. For example, say "play
song Hey Jude", "play line 3" or "select line 2".
You can undo your last action and start over
by saying "undo", or say "cancel" to cancel the
current action.

Voice commands



Play song Hey Jude

Play artist Madonna

Play album Thriller

Help messages



I'm not sure what you'd like to play. Please say
"play" and then a song title, an album title, or
an artist name. For example, say "play song
Hey Jude", "play artist Madonna" or "play
album Thriller". To select a line number from the
display, say "select line two". To move around
a displayed list, you can say "next page" or
"previous page". You can undo your last action
and start over by saying "undo", or say "cancel"
to cancel the current action.

Media voice commands are available
only with a USB connection.

"Telephone" voice

commands

If there is no telephone connected by
Bluetooth, a voice message announces:

"Please first connect a telephone", and the

voice session is closed.

Voice commands



Call David Miller

*

Call voicemail

*

Display calls

*

Help messages



To make a phone call, say "call" followed by
the contact name, for example: "Call David
Miller". You can also include the phone type, for
example: "Call David Miller at home". To make
a call by number, say "dial" followed by the
phone number, for example, "Dial 107776 835
417". You can check your voicemail by saying
"call voicemail". To send a text, say "send quick
message to", followed by the contact, and then
the name of the quick message you'd like to
send. For example, "send quick message to

14/02/2022   15:34:16

277

Connect Nav

12

David Miller, I'll be late". To display the list of
calls, say "display calls". For more information on
SMS, you can say "help with texting".
To choose a contact, say something like "select
line three". To move around the list say "next
page" or "previous page". You can undo your last
action and start over by saying "undo", or say
"cancel" to cancel the current action.

"Text message" voice

commands

If there is no telephone connected by
Bluetooth, a voice message announces:

"Please first connect a telephone", and the

voice session is closed.

The "Text messages" voice commands
function allows you to dictate and send

an SMS.

Dictate the text, taking care to pause briefly

between each word.

When you have finished, the voice recognition

system will automatically generate an SMS.

Voice commands



Send quick message to Bill Carter, I'll be late

Help messages



* This function is available only if the telephone connected to the system supports downloading of contacts and recent calls and the corresponding
download has been performed.

From the list of quick messages, say the name of
the one you'd like to send. To move around the
list you can say "go to start", "go to end", "next
page" or "previous page". You can undo your last
action and start over by saying "undo", or say
"cancel" to cancel the current action.

Voice commands



Send SMS to John Miller, I'm just arriving

Send SMS to David Miller at the office, don't

wait for me

Help messages



Please say "call" or "send quick message to",
and then select a line from the list. To move
around a list shown on the display, you can
say "go to start", "go to end", "next page" or
"previous page". You can undo your last action
and start over by saying "undo", or say "cancel"
to cancel the current action.

Voice commands



Listen to most recent message

*

Help messages



To hear your last message, you can say "listen to
most recent message". When you want to send
a text, there's a set of quick messages ready for
you to use. Just use the quick message name
and say something like "send quick message to

Bill Carter, I'll be late". Check the phone menu
for the names of the supported messages.

The system only sends pre-recorded
"Quick messages".

Navigation

Choice of a destination

To a new destination

Intuitive method:

Press

Navigation

 to display the main

page.
Press "

Search…

".

Enter an address or the key words for the
destination.
Press "

OK

" to select the "

Guidance

criteria

".

Or

Guided method:

In order to be able to use the navigation,
you must enter the "

City

", the "

Street

"

(suggestions are displayed automatically
when you begin typing), then enter the
"

Number

" using the virtual keypad, or select

14/02/2022   15:34:16

278

Connect Nav

an address from the "

Contact

" list or the

address "

History

".

If you do not confirm the number, the

navigation system will show one end of

the street.

Press the "

MENU

" button to access the

secondary page.

Select "

Enter address

".

Then

Select the "

Country

".

Select the keyboard “language”.

Change the keyboard "type" according to
the selected "language": ABCDE;

AZERTY; QWERTY or QWERTZ.

Enter the "

City

", the "

Street

" and the

"

Number

", and confirm by pressing on

the displayed suggestions.

Press "

OK

" to select the "

Guidance

criteria

".

And/or

Select "

See on map

" to choose the

"

Guidance criteria

".

Press "

OK

" to start guided navigation.

Zoom in/out using the touch buttons or

with two fingers on the screen.

To a recent destination

Press

Navigation

 to display the main

page.

Press the "

MENU

" button to access the

secondary page.

Select "

My destinations

".

Select the "

Recent

” tab.

Select the address chosen in the list to display
the "

Guidance criteria

”.

Press "

OK

" to start guided navigation.

Select "

Position

" to see the point of

arrival on the map.

To "Home" or "My work"

Press

Navigation

 to display the main

page.

Press the "

MENU

" button to access the

secondary page.

Select "

My destinations

".

Select the "

Preferred

” tab.

Select "

Home

".

Or

Select "

My work

".

Or
Select a preset favourite destination.

To a contact

Press

Navigation

 to display the main

page.

Press the "

MENU

" button to access the

secondary page.

Select "

My destinations

".

Select the "

Contact

” tab.

Select a contact in the list to start guided
navigation.

To points of interest (POI)

Guided method:

Points of interest (POI) are listed in different

categories.

Press

Navigation

 to display the main

page.

Press the "

MENU

" button to access the

secondary page.

Select "

Points of interest

".

Select the "

Travel

", "

leisure

",

"

Commercial

", "

Public

" or "

Geographic

”

tab.
Or

Select "

Search

" to enter the name and

address of a POI.
Press "

OK

" to calculate the route.

Or

Intuitive method:

14/02/2022   15:34:17

279

Connect Nav

12

You can only select this method of
using the service if a network connection

is active; this may be either a "network
connection provided by the vehicle", if you
use the Fiat Connect Box solution, or else a
"network connection provided by the user" via
a smartphone,
In both cases, the system is automatically
connected to the Internet, if network coverage
permits.

Press

Navigation

 to display the main

page.

Press the "

MENU

" button to access the

secondary page.

Select "

Search

".

Press on the mode shown in the bottom right of
the screen (On-Board or Connected) to change
the "Database".

Select the "Database" in "On-Board"
mode (integrated into the map), or in

"Connected" mode (connected to the Internet).

Press the back arrow to confirm.



Enter an address or the key words for the
destination (POI).
Press "

OK

" to start the search.

Select the "

On the route

", "

Around the

vehicle

" or "

At destination

" tab to refine

your search.
Select the desired address to calculate the route.

To a point on the map

Press

Navigation

 to display the main

page.

Explore the map by sliding a finger on the

screen.
Select the destination by pressing on the map.

Tap the screen to place a marker and
display the sub-menu.
Press this button to start guided
navigation.

Or

Press this button to save the displayed
address.

A long press on a point opens a list of

nearby POIs.

To GPS coordinates

Press

Navigation

 to display the main

page.

Explore the map by sliding a finger on the

screen.

Touch the screen with a finger to go to the next

image.

Press this button to display the world
map.

Using the grid, select the desired country or
region by zooming.

Press this button to display or enter the
GPS coordinates.

A marker is displayed in the middle of the

screen, with the "

Latitude

" and

"

Longitude

" coordinates.

Choose the type of coordinates:
DMS for: Degrees, Minutes, Seconds.
DD for: Degrees, Decimals.

Press this button to start guided
navigation.

Or

Press this button to save the displayed
address.

OR

Press this button to enter the "

Latitude

"

value using the virtual keypad.

And

Press this button to enter the "

Longitude

"

value using the virtual keypad.

TMC (Traffic Message

Channel)

Available in some countries.

TMC (Traffic Message Channel) messages

are based on a European standard for traffic

information broadcasting via the RDS system on

FM radio, sending traffic information in real time.

The TMC information is then displayed on a GPS
Navigation system map and taken into account
straight away when routes are calculated, to

avoid accidents, traffic jams and closed roads.

Danger zone alerts may or may not be
displayed, depending on the applicable

14/02/2022   15:34:18

280

Connect Nav

legislation and subscription to the
corresponding service.

Connected navigation

Connected navigation

connection

Depending on version, vehicle trim level and
subscription to online services and options.

Network connection provided by the

vehicle

With the Fiat Connect Box solution, the
system is automatically connected to the

Internet and connected services, and does not
require the user to provide a connection via their
smartphone.

OR

Network connection provided by the

user





For the list of compatible smartphones,
visit the Brand's website in your country.

Activate and enter settings for sharing the
smartphone connection.

As processes and standards are

constantly changing, we recommend you

update the smartphone operating system

as well as the date and time on the

smartphone and system

, to ensure that the

communication process between the
smartphone and the system functions
correctly.

USB connection

Connect the USB cable.
The smartphone charges when

connected by the USB cable.

Bluetooth connection

Activate the Bluetooth function on the

telephone and ensure that it is visible to

all (see the "Connect-App" section).

Wi-Fi connection

Select a Wi-Fi network detected by the
system and connect to it.

This function is only available if it has
been activated either via the

"Notifications" or via the "Applications" menu.

Press "

Notifications

".

Select Wi-Fi to activate it.

OR

Press

Connect-App

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Wi-Fi network connection

".

Select the "

Secured

", "

Not secured

" or

"

Stored

” tab.

Select a network.

Using the virtual keypad, enter the "

Key

"

network Wi-Fi and the "

Password

".

Press "

OK

" to establish a connection

between the smartphone and the

vehicle’s system.

Usage restrictions:
With CarPlay

®

, connection sharing is only

available with a Wi-Fi connection.
The quality of services depends on the quality
of the network connection.

Authorize sending

information

Press

Settings

 to display the main page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

System configuration

".

Select the "

Private mode

" tab.

OR

Press "

Notifications

".

Press "

Private mode

".

THEN

14/02/2022   15:34:19

281

Connect Nav

12

Activate or deactivate:

–  "

No data sharing except for company

vehicles

".

–  "

Only data sharing

"

–  "

Sharing data and vehicle position

"

Settings specific to

connected navigation

Press

Navigation

 to display the main

page.

Press the "

MENU

" button to access the

secondary page.

Select "

Settings

".

Select the "

Map

” tab.

Activate or deactivate:

–  "

Allow declaration of danger zones

".

–  "

Guidance to final destination on foot

".

These settings must be configured for each

profile.

Press “

OK”

 to confirm your selection.



Select the "

Alerts

” tab.

Activate or deactivate:

–  "

Advise of car park nearby

".

–  "

Filling station alert

".

–  “

Risk areas alert

" then press the warning icon

(triangle) to configure the alerts.

–  "

Give an audible warning

".

–  "

Advise proximity of POI 1

".

–  "

Advise proximity of POI 2

".

Press “

OK”

 to confirm your selection.



The "Notifications", located in the upper

bar, can be accessed at any time.

Danger zone alerts may or may not be
displayed, depending on the applicable

legislation and subscription to the
corresponding service.

When "TOMTOM TRAFFIC” appears, the
services are available.

The services offered with connected

navigation are as follows.

A Connected Services pack:
–  Weather,
–  Filling stations,
–  Car park,

–  Traffic,

–  POI local search.
A Danger area pack (optional).

Declaration: "Risk areas

alert"

To send information about danger zones,
select the option:

Allow declaration of

danger zones

Press

Navigation

 to display the main

page.
Press the "

Declare a new danger zone

"

button located in the side bars or the

upper bar of the touch screen (depending on
equipment).

Select the "

Type

” option to select the type

of "Danger area".
Select the

"Speed

" option and enter it

using the virtual keypad.
Press "

OK

" to save and send the

information.

Displaying fuel information

Press

Navigation

 to display the main

page.
Press this button to display the list of
services.
Press "

POI on map" to display the list

of points of interest.

Press one of the buttons to search for
"

Stations

".

Activate/deactivate "

Stations

".

Press this button to display a secondary
page.
Select the "

Settings

” tab.

Select the desired fuel.

Press "

OK

" to save.

14/02/2022   15:34:20

282

Connect Nav

Displaying charging station

details

Press

Navigation

 to display the main

page.
Press this button to display the list of
services.
Press "

POI on map" to display the list

of points of interest.

Press one of the buttons to search for
"

Stations

".

Activate/deactivate "

Stations

".

Press this button to display a secondary
page.
Select the "

Settings

" tab.

Select the desired connector type.

Press "

OK

" to save.

Displaying weather

information

Press

Navigation

 to display the main

page.
Press this button to display the list of
services.
Select "

View map

".

Select "

Weather

".

Press this button to display basic
information.
Press this button to display detailed
weather information.

The temperature displayed at 6 a.m. will
be the maximum temperature for the day.

The temperature displayed at 6 p.m. will be
the minimum temperature for the night.

Applications

USB sockets

Depending on equipment, for more information
on the USB sockets compatible with

CarPlay

®

 or

Android Auto

 applications, refer to the "Ease of

use and comfort" section.

For the list of compatible smartphones,
visit the Manufacturer's website in your

country.

Synchronising a smartphone enables
users to display applications that support

the smartphone’s CarPlay

®

 or Android Auto

technology on the vehicle’s screen. For
CarPlay

®

 technology, the CarPlay

®

 function

must first be activated on the smartphone.

Unlock the smartphone for the communication
process between the smartphone and the
system to work.

As principles and standards are constantly
changing,

we recommend keeping the

smartphone's operating system up-to-

date, together with the date and time on

the smartphone and the system

.

Connectivity

Press

Applications

 to display the main

page.

Press "

Connectivity

" to access the

CarPlay

®

 or

Android Auto

 functions.

CarPlay

®

 smartphone

connection

Depending on country.

On connecting the USB cable, the
CarPlay

®

 function deactivates the

system's Bluetooth

®

 mode.

The "

CarPlay

" function requires the use of

a compatible smartphone and compatible
applications.

Connect the USB cable. The smartphone
charges when connected by the USB

cable.
A message appears on the touch screen.

Read it and then confirm with the "

Authorise

"

button.

Press "

Telephone

" to display the

CarPlay

®

 interface.

Or

14/02/2022   15:34:20

283

Connect Nav

12

Connect the USB cable. The smartphone
charges when connected by the USB

cable.

From the system, press "

Applications

" to

display the main page.

Press "

Connectivity

" to access the "CarPlay

®

”

function.

Press "

CarPlay

" to display the CarPlay

®



interface.

When the USB cable is disconnected

and the ignition is switched off then back

on, the system will not automatically switch to
Radio Media mode; the source must be
changed manually.

Android Auto smartphone

connection

Depending on country.

Install the "

Android Auto

" application on

the smartphone via "Google Play".

The "

Android Auto

" function requires the use

of a compatible smartphone and compatible
applications.

Connect the USB cable. The smartphone
charges when connected by the USB

cable.

From the system, press "

Applications

" to

display the main page.

Press "

Connectivity

" to access the "Android

Auto” function.

Press "

Android Auto

" to start the

application in the system.
During the procedure, several screen
pages relating to certain features are

displayed.
Accept to start and complete the connection.

Access to the different audio sources remains

available in the margin of the Android Auto
display, using the touch buttons located in the
upper bar.
Access to the menus for the system is possible
at any time using the dedicated buttons.

In Android Auto mode, the function that

displays rolling menus by briefly pressing

the screen with three fingers is disabled.

There may be a pause before
applications become available,

depending on the quality of the network.

Car Apps

Press

Applications

 to display the main

page.

Press "

Car Apps

" to display the applications

home page.

Internet Browser

Press

Applications

 to display the main

page.

Press "

Connectivity

" to access the "

Connected

Apps

” function.

Press "

Connected Apps

" to display the browser

home page.

Select the country of residence.

Press "

OK

" to save and start the browser.

Connection to the internet is via one of
the network connections provided by the

vehicle or the user.

Bluetooth connection

®

The services available depend on the
network, the SIM card and the

compatibility of the Bluetooth devices used.
Consult the smartphone user guide and the
service provider to check which services are
available.

The Bluetooth function must be activated

and the smartphone configured as

"Visible to all".

To complete the pairing, whichever procedure is
used (from the smartphone or from the system),
ensure that the code is the same in the system
and in the smartphone.

If the pairing procedure fails, we
recommend deactivating and then

reactivating the Bluetooth function on the
smartphone.

14/02/2022   15:34:20

284

Connect Nav

Procedure from the smartphone

Select the name of the system in the list
of detected devices.

In the system, accept the connection request
from the smartphone.

Procedure from the system

Press

Connect-App

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Press "

Bluetooth connection

".

Select "

Search

".

The list of detected smartphones is

displayed.

Select the name of the chosen
smartphone in the list.

Depending on the type of smartphone,
you may by prompted to accept the

transfer of contacts and messages.

Connection sharing

The system offers to connect the smartphone

with 3 profiles:

–  "

Telephone

" (hands-free kit, telephone only),

–  “

Streaming

" (streaming: wireless playing of

audio files on the smartphone),

–  "

Mobile internet data

".

The "

Mobile internet data

" profile must

be activated for connected navigation (if

the vehicle does not have "Emergency and

assistance call" services), after first activating

smartphone connection sharing.

Select one or more profiles.



Press "

OK

" to confirm.



Wi-Fi connection

Network connection via the smartphone's Wi-Fi.

Press

Connect-App

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Wi-Fi network connection

".

Select the "

Secured

", "

Not secured

" or

"

Stored

” tab.

Select a network.

Using the virtual keypad , enter the Wi-Fi
network "

Key

" and "

Password

".

Press "

OK

" to establish the connection.

The Wi-Fi connection and Wi-Fi
connection sharing are exclusive.

Wi-Fi connection sharing

Depending on equipment.
Creation of a local Wi-Fi network by the system.

Press

Connect-App

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Share Wi-Fi connection

".

Select the "

Activation

" tab to activate or

deactivate Wi-Fi connection sharing.
And/or
Select the "

Settings

" tab to change the system’s

network name and password.

Press "

OK

" to confirm.



To protect against unauthorised access
and to make all systems as secure as

possible, the use of a security code or a
complex password is recommended.

Managing connections

Press

Connect-App

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Manage connection

".

With this function, you can view the access to
connected services, the availability of connected
services and modify the connection mode.

14/02/2022   15:34:21

285

Connect Nav

12

Radio

Selecting a station

Press

Radio Media

 to display the main

page.

Press "

Frequency

".

Press one of the buttons to perform an
automatic search for radio stations.

Or

Move the slider to manually search for
frequencies up or down.

Or

Press

Radio Media

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Radio stations

" on the secondary

page.

Press "

Frequency

".

Enter the values using the virtual keypad.
First enter the units then click on the

decimals field to enter the figures after the

decimal point.

Press "

OK

" to confirm.



Radio reception may be affected by the

use of electrical equipment not approved

by the Brand, such as a USB charger
connected to the 12 V socket.
The exterior environment (hills, buildings,
tunnels, basement car parks, etc.) may
block reception, including in RDS mode.

This phenomenon is perfectly normal in the
context of radio wave transmission, and
in no way indicative of an audio system
malfunction.

Presetting a station

Select a radio station or frequency.
(refer to the corresponding section)
Press "

Presets

".

Make a long press on one of the buttons
to preset the station.

Changing the waveband

Press

Radio Media

 to display the main

page.

To change the waveband, press "Band…",
displayed at the top right of the screen.

Activating/Deactivating RDS

RDS, if activated, allows you to continue
listening to the same station by automatic
retuning to alternative frequencies.

Press

Radio Media

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Radio settings

".

Select "

General

".

Activate/deactivate "

Station follow

".

Press "

OK

" to confirm.



RDS station tracking may not be
available nationwide, as many radio

stations do not cover 100 % of the country.
This explains the loss of reception of the
station during a journey.

Displaying text information

The "Radio Text" function displays information
transmitted by the radio station relating to the
station or the currently playing song.

Press

Radio Media

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Radio settings

".

Select "

General

".

Activate/deactivate "

Display radio text

".

Press "

OK

" to confirm.



Playing TA messages

The TA (Traffic Announcement) function gives

priority to TA alert messages. To operate, this
function needs good reception of a radio station

that carries this type of message. While traffic

information is being broadcast, the current
media is automatically interrupted so that the

14/02/2022   15:34:21

286

Connect Nav

TA message can be heard. Normal play of the
previously playing media resumes at the end of
the message.
Select "

Announcements

".

Activate/deactivate "

Traffic

announcement

".

Press "

OK

" to confirm.



DAB (Digital Audio
Broadcasting) radio

Terrestrial Digital Radio

Terrestrial Digital Radio

Digital radio provides higher quality sound.

The various "multiplexes/ensembles" offer a

choice of radio stations organised in alphabetical
order.

Press

Radio Media

 to display the main

page.

Press “Band …" at the top right of the screen to
display the "

DAB

" waveband.

FM-DAB tracking

"DAB" does not cover 100% of the territory.
When the digital radio signal is poor,
“FM-DAB  auto tracking" enables you to continue
listening to the same station by automatically
switching to the corresponding FM analogue
station (if there is one).

Press

Radio Media

 to display the main

page.

Press the "

OPTIONS

" button to go to the

secondary page.

Select "

Radio settings

".

Select "

General

".

Activate/deactivate "

FM-DAB Follow-up

".

Activate/deactivate "

Station follow

".

Press "

OK

".

If "FM-DAB auto tracking" is activated,
there may be a time lag of a few seconds

when the system switches to "FM" analogue
radio, and in some cases a change in volume.
When the digital signal quality is restored, the
system automatically changes back to "DAB".
To minimise this time lag, storing radio
stations in the "DAB" band is recommended.

If the "DAB" station being listened to is
not available on "FM" ("

FM-DAB

" greyed

out), or "FM-DAB auto tracking" is not
activated, the sound will cut out when the
digital signal becomes too weak.

Media

USB port

Insert the USB memory stick into the USB
port or connect the USB device to the

USB port using a suitable cable (not supplied).

To protect the system, do not use a USB
hub.

The system builds playlists (in temporary
memory); this operation can take from a

few seconds to several minutes at the first

connection.

Reduce the number of non-music files and the

number of folders to reduce the waiting time.
Playlists are updated whenever the ignition

is switched off or a USB memory stick is

connected. The audio system memorises these
lists, which will subsequently load faster if they
have not been changed.

Auxiliary socket (AUX)

Depending on equipment

Connect a portable device (MP3 player,
etc.) to the auxiliary jack socket using an

audio cable (not supplied).
This source is only available if "Auxiliary input"
has been selected in the audio settings.
First adjust the volume on the portable device
(to a high level). Then adjust the volume of the
audio system.
Controls are managed via the portable device.

14/02/2022   15:34:21

287

Connect Nav

12

Selecting the source

Press

Radio Media

 to display the main

page.

Select "

SOURCES

".

Select the source.

Watching a video

Depending on equipment/Depending on version/
Depending on country.
Insert a USB memory stick in the USB port.

Video control commands are accessible
only through the touch screen.

Press

Radio Media

 to display the main

page.

Select "

SOURCES

".

Select

Video

 to start the video.

To remove the USB memory stick, press
the pause button to stop the video, then

remove the memory stick.

The system can play video files in the MPEG-4

Part 2, MPEG-2, MPEG-1, H.264, H.263, VP8,
WMV and RealVideo formats.

Streaming Bluetooth

®

Streaming allows you to listen to the audio feed
from your smartphone.

The Bluetooth profile must be activated.

First adjust the volume on the portable device (to
a high level).
Then adjust the volume of the audio system.

If play does not start automatically, it may be
necessary to start the audio playback from the
smartphone.
Control is from the portable device or by using
the system's touch buttons.

Once connected in streaming mode, the
smartphone is considered to be a media

source.

Connecting Apple

®

 players

Connect the Apple

®

 player to the USB port using

a suitable cable (not supplied).
Play starts automatically.
Control is via the audio system.

The classifications available are those of

the portable device connected (artists/

albums/genres/playlists/audio books/
podcasts).

The default classification used is by artist. To

modify the classification used, return to the

first level of the menu then select the desired

classification (playlists for example) and

confirm to go down through the menu to the

desired track.

The version of software in the audio system may
not be compatible with the generation of the
Apple

®

 player.

Information and advice

The system supports USB mass storage
devices, BlackBerry

®

 devices and Apple

®

 players

via the USB ports. The adapter cable is not
supplied.
Devices are managed using the audio system
controls.
Other devices, not recognised on connection,
must be connected to the auxiliary socket using
a jack cable (not supplied) or via Bluetooth
streaming, if compatible.

The audio system will only play audio files with

".wma", ".aac", ".flac", ".ogg" and ".mp3" file

extensions, at bit rates between 32 Kbps and
320 Kbps.
It also supports VBR (Variable Bit Rate) mode.

No other file types (".mp4", etc.) can be read.

All ".wma" files must be standard WMA 9 files.

The supported sampling rates are 32, 44 and
48 KHz.
To avoid reading and display problems, we

recommend choosing file names less than 20

characters long that do not contain any special
characters (e.g. “ ? . ; ù).
Use only USB memory sticks in FAT32 format
(File Allocation Table).

We recommend using the original USB
cable for the portable device.

14/02/2022   15:34:22

288

Connect Nav

Telephone

Pairing a Bluetooth

®



telephone

The services available depend on the
network, the SIM card and the

compatibility of the Bluetooth

®

 devices used.

Consult the telephone user guide and the
service provider to check which services are
available.

The Bluetooth

®

 function must be

activated and the telephone configured

as "Visible to all” (in the telephone settings).

To complete the pairing, whichever procedure is
used (from the telephone or from the system),
ensure that the code is the same in the system
and in the telephone.

If the pairing procedure fails, we
recommend deactivating and then

reactivating the Bluetooth

®

 function on the

telephone.

Procedure from the telephone

Select the system name in the list of
detected devices.

In the system, accept the connection request
from the telephone.

Procedure from the system

Press

Telephone

 to display the main

page.
Press "

Bluetooth search

".

Or

Select "

Search

".

The list of detected telephones is

displayed.

Select the name of the chosen telephone
in the list.

Connection sharing

The system offers to connect the telephone with

3 profiles:

–  "

Telephone

" (hands-free kit, telephone only),

–  “

Streaming

" (streaming: wireless playing of

audio files on the telephone),

–  "

Mobile internet data

".

The "

Mobile internet data

" profile must

be activated for connected navigation,

after first activating smartphone connection

sharing.

Select one or more profiles.



Press "

OK

" to confirm.



Depending on the type of telephone, you may by
prompted to accept the transfer of contacts and
messages.

The ability of the system to connect just

one profile depends on the telephone.

All three profiles may connect by default.

The profiles compatible with the system

are: HFP, OPP, PBAP, A2DP, AVRCP,

MAP and PAN.

Visit the Brand's website for more information
(compatibility, additional help, etc.).

Automatic reconnection

On returning to the vehicle, if the last telephone
connected is present again, it is automatically
recognised and within about 30 seconds
after switching on the ignition, the pairing is
established automatically (Bluetooth activated).

To modify the connection profile:

Press

Telephone

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Bluetooth connection

" to display

the list of paired devices.
Press the "Details" button.

Select one or more profiles.



Press "

OK

" to confirm.



14/02/2022   15:34:22

289

Connect Nav

12

Managing paired telephones

This function lets you connect or disconnect a
device or delete a pairing.

Press

Telephone

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Bluetooth connection

" to display

the list of paired devices.
Press on the name of the telephone
selected in the list to disconnect it.

Press again to connect it.

Deleting a telephone

Select the basket at top right of the
screen to display a basket alongside the

telephone chosen.

Press the basket alongside the telephone
chosen to delete it.

Receiving a call

An incoming call is announced by a ring and a
superimposed display in the screen.

Make a short press on the steering
mounted telephone button to accept an

incoming call.
And

Make a long press

on the steering mounted telephone button
to reject the call.

Or

Select "

End call

" on the touch screen.

Making a call

Using the telephone is strongly
discouraged while driving.

Park the vehicle.
Make the call using the steering-mounted
controls.

Calling a new number

Press

Telephone

 to display the main

page.
Enter the phone number using the digital
keypad.
Press "

Call" to start the call.



Calling a contact

Press

Telephone

 to display the main

page.
Or press and hold

the steering mounted telephone button.

Select "

Contact

".

Select the desired contact from the displayed list.

Select "

Call

".

Calling a recently used

number

Press

Telephone

 to display the main

page.

Or

Press and hold

the steering mounted telephone button.

Select "

Calls

".

Select the desired contact from the displayed list.

It is always possible to make a call
directly from the telephone; as a safety

measure, first park the vehicle.

Managing contacts/entries

Press

Telephone

 to display the main

page.

Select "

Contact

".

Select "

Create

" to add a new contact.

Press the "

Telephone

" tab to enter the

contact’s telephone number(s).
Press the "

Address

" tab to enter the

contact’s address(es).
Press the "

Email

" tab to enter the

contact’s email address(es).
Press "

OK

" to save.

14/02/2022   15:34:23

290

Connect Nav

Press this button to sort contacts by

Surname+first name or by First

name+surname.

The "

Email

" function allows email

addresses to be entered for a contact,

but the system is not able to send emails.

Managing messages

Press

Telephone

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Messages

" to display the list of

messages.
Select the "

All

", "

Incoming

" or "

Sent

”

tab.
Select the details of the message chosen
in one of the lists.
Press "

Answer

" to send a quick message

stored in the system.
Press "

Call" to start the call.



Press "

Play

" to listen to the message.

Access to "

Messages

" depends on the

compatibility between the smartphone

and the onboard system.
Some smartphones retrieve messages or
email messages more slowly than others.

Managing quick messages

Press

Telephone

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Quick messages

" to display the

list of messages.
Select the "

Delayed

", "

My arrival

", "

Not

available

" or "

Other

" tab, enabling you to

create new messages.

Press "

Create

" to write a new message.

Select the message chosen in one of the
lists.
Press "

Transfer

" to select one or more

recipients.
Press "

Play

" to start playing the message.

Managing email

Press

Telephone

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Email

" to display the list of

messages.
Select the "

Incoming

", "

Sent

" or "

Not

read

” tab.

Select the message chosen in one of the lists.

Press "

Play

" to start playing the message.

Access to email messages depends on

the compatibility between the

smartphone and the onboard system.

Settings

Audio settings

Press

Settings

 to display the main page.

Select "

Audio settings

".

Then select "

Ambience

", "

Position

", "

Sound

",

"

Voice

" or "

Ringtone

".

Press "

OK

" to save the settings.

The balance/distribution (or spatialisation
with the Arkamys

 system) uses audio

processing to adjust the sound quality
according to the number of passengers in the
vehicle.
Available only with the front and rear speaker

configuration.

The

Ambience

 setting (choice of 6

ambiances) as well as for

Bass

,

Medium



and

Treble

 are different and independent for

each audio source.
Activate or deactivate "

Loudness

".

14/02/2022   15:34:23

291

Connect Nav

12

The "

Position

" settings (All passengers,

Driver and Front only) are common to all
sources.
Activate or deactivate "

Touch tones

",

"

Volume linked to speed

" and "

Auxiliary

input

".

Onboard audio: Arkamys Sound Staging



optimises the sound distribution inside

the passenger compartment.

Configuring profiles

Press

Settings

 to display the main page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Setting of the profiles

".

Select "

Profile 1

", "

Profile 2

", "

Profile 3

” or

"

Common profile

".

Press this button to enter a name for the

profile using the virtual keypad.

Press "

OK

" to confirm.



Press this button to add a photograph to

the profile.

Insert a USB memory stick containing the
photograph in the USB port.

Select the photograph.

Press "

OK

" to accept the transfer of the

photograph.

Press "

OK

" again to save the settings.

The location for the photograph is
square; the system reshapes the original

photograph if in another format.

Press this button to reset the selected

profile.

Resetting the selected profile activates

the English language by default.

Select a "

Profile

" (1 or 2 or 3) to link "

Audio

settings

" with it.

Select "

Audio settings

".

Then select "

Ambience

", "

Position

"; "

Sound

",

"

Voice

" or "

Ringtone

".

Press "

OK

" to save the selected profile’s

settings.

Modifying system settings

Press

Settings

 to display the main page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Screen configuration

".

Select "

Animation

".

Activate or deactivate:

Automatic

scrolling

Select "

Brightness

".

Move the slider to adjust the brightness of
the screen and/or the instrument panel.
Press

Settings

 to display the main page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

System settings

".

Select "

Units

" to change the units of distance,

fuel consumption and temperature.
Select "

Factory settings

" to restore the initial

settings.

Resetting the system to "Factory
settings" activates English and degrees

Fahrenheit and deactivates summer time.

Select "

System info

" to display the versions of

the various modules installed in the system.

Selecting the language

Press

Settings

 to display the main page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Languages

" to change the

language.

Setting the date

Press

Settings

 to display the main page.

Press the "

OPTIONS

" button to access the

secondary page.

14/02/2022   15:34:24
