100

Safety

Only the ASR system can be deactivated
from the touch screen.

Deactivating using the button or Advanced

Grip Control

Press this button or turn the thumbwheel
to this position.

The indicator lamp in the button or thumbwheel
comes on: the DSC/ASR systems no longer

have an effect on engine operation.

Deactivating using the touch screen

In the "

Driving/Vehicle

" menu, deactivate

the ASR system.

A confirmation message is displayed and

this warning lamp on the instrument panel

comes on.
The ASR system no longer acts on the operation
of the engine.

Reactivating using the button or Advanced

Grip Control

Press this button.

Or

Turn the thumbwheel to this position.

The indicator lamp in the button or thumbwheel

goes off.

Reactivating using the touch screen

In the "

Driving/Vehicle

" menu, activate

the ASR system.

A confirmation message is displayed and

this warning lamp on the instrument panel

goes off.

These systems are reactivated automatically

every time the ignition is switched off, or at

speeds over 31 mph (50 km/h).
Below 31 mph (50 km/h), these systems must be
reactivated manually.

Malfunction

In the event of a malfunction, this warning
lamp lights up on the instrument panel,

accompanied by the display of a message and
an audible signal.
Have it checked by a Fiat Dealership or a

qualified workshop.

ASR/DSC

These systems enhance safety during

normal driving, but should not encourage
the driver to take extra risks or drive at high
speed.
It is in conditions of reduced grip (rain, snow,
ice) that the risk of loss of grip increases. It
is therefore important for your safety to keep
these systems activated in all conditions, and

particularly in difficult conditions.

Correct operation of these systems depends
on compliance with the manufacturer's
recommendations relating to the wheels
(tyres and rims), braking and electronic
components, as well as the assembly
and repair procedures provided by Fiat
Dealerships.
In order to ensure that these systems remain

effective in wintry conditions, the use of snow

or all-season tyres is recommended. All four

wheels must be fitted with tyres approved for

your vehicle.

All tyre specifications are listed on the

tyre/paint label. For more information
on

Identification markings

, refer to the

corresponding section.

Intelligent traction control

("Snow motion")

(Depending on version)
The intelligent traction control system helps
improve grip when driving on snow.
This system detects situations of poor surface

grip that could make it difficult to move off

or make progress on deep fresh snow or
compacted snow.
In these situations, the system limits the amount
of wheel spin to provide the best traction and
trajectory control for the vehicle.

The use of winter tyres is strongly
recommended on slippery surfaces.

Trailer stability assist (TSA)

When towing, this system reduces the risk of the
vehicle or trailer snaking.

Operation

The system is activated automatically when the
ignition is switched on.

14/02/2022   15:33:27

101

Safety

5

The electronic stability control system (ESC)
must not have any faults.

The vehicle speed must be between 37 and 99

mph (60 and 160 km/h).

If the system detects that the trailer is
snaking, it applies the brakes to stabilise

the trailer and reduces engine power, if
necessary, to slow the vehicle (indicated by the

flashing of this warning lamp on the instrument

panel and the brake lamps coming on).
For information on weights and towed loads,
refer to the

Engine technical data and towed

loads

 section or your vehicle’s registration

certificate.

To ensure safe driving with a

Towing device

,

refer to the corresponding section.

Malfunction

If a fault occurs, this warning lamp lights
up on the instrument panel, accompanied

by a message and an audible signal.
To continue towing a trailer, reduce speed and
drive carefully!
Have it checked by a Fiat Dealership or a

qualified workshop.

The trailer stability control system
provides an extra safety feature under

normal driving conditions, when following the
recommendations for use of trailers and
current legislation in force in your country. It
must not encourage the driver to take extra
risks, such as using a trailer in unsuitable

conditions of operation (e.g. excessive load,

exceeded nose weight, worn or under-inflated

tyres, faulty braking system) or driving at
excessive speed.
In certain cases, the system may not detect
trailer snaking, particularly with a light trailer.
When driving on slippery or poor surfaces, the
system may not be able to prevent sudden
trailer snaking.

Advanced Grip Control





(Depending on version)
A special, patented traction control system,
which improves driveability on snow, mud and
sand.
This system, optimised for operation in a range
of conditions, enables you to manoeuvre in most
slippery conditions (encountered during normal
passenger car use).
When combined with all-season Peak Mountain

Snow Flake tyres, this system offers a

compromise between safety, grip and driveability.
The accelerator pedal should be pressed

sufficiently to allow the system to harness the

power of the engine. Operation at high engine
speeds is completely normal.

A five-position selector knob allows you to

choose the setting best suited to the driving
conditions encountered.

An indicator lamp associated with each mode
comes on, accompanied by the display of a

message to confirm your choice.

Operating modes









Standard (ESC)

This mode is calibrated for a low level of

wheel spin, based on the different levels

of grip normally encountered on the road.

Whenever the ignition is switched off, the

system automatically resets to this mode.

Snow

This mode adapts its strategy to the
conditions of grip encountered for each of

the two front wheels on moving off.

(mode active up to 50 mph (80 km/h))

14/02/2022   15:33:27

102

Safety

All terrain (mud, damp grass, etc.)

This mode, when moving off, allows

considerable spin on the wheel with the

least grip to optimise clearing of the mud and to
regain grip. At the same time, the wheel with the
most grip is controlled in such a way as to
transmit as much torque as possible.
When moving, the system optimises wheel spin
to respond to the driver's requirements as fully
as possible.
(mode active up to 31 mph (50 km/h))

Sand

This mode allows little spin on the two
driving wheels at the same time to allow

the vehicle to move forward and limit the risks of
getting stuck in the sand.
(mode active up to 75 mph (120 km/h))

Do not use the other modes on sand as
the vehicle may become stuck.

Deactivation

You can deactivate the ASR and DSC
systems by turning the knob to the "

OFF

"

position.

The ASR and DSC systems will no
longer act on the operation of the engine

or of the brakes in the event of a change of
trajectory.
These systems are reactivated automatically
from 31 mph (50 km/h) and whenever the
ignition is switched on.

Recommendations

Your vehicle is designed principally to

drive on tarmac roads but it allows you to
occasionally drive on other less passable
terrain.

However, it does not permit off-road driving

such as:
–  crossing and driving on terrain which
could damage the underbody or strip away
components (fuel pipe, fuel cooler, etc.) due
to obstacles or stones in particular,
–  driving on terrain with steep gradients and
poor grip,
–  crossing a stream.

Seat belts

Inertia reel

The seat belts are equipped with an inertia
reel which allows the strap length to adjust
automatically to the shape of the user. The seat
belt returns to its storage automatically when it
is not used.

The inertia reels are fitted with a device which

automatically locks the strap in the event of a
collision, emergency braking or if the vehicle rolls

over. It can be released by pulling the strap firmly

and then releasing it so that it reels in slightly.

Pyrotechnic pretensioning

This system improves safety in the event of a
frontal or side impact.
Depending on the severity of the impact, the
pyrotechnic pretensioning system instantly
tightens the seat belts against the body of the
occupants.
The pyrotechnic pretensioning seat belts are
enabled when the ignition is on.

Force limiting system

This system reduces the pressure of the seat
belt on the chest of the occupant, thus improving
their protection.

In the event of an impact

Depending on the nature and

seriousness of the impacts, the pyrotechnic
device may trigger before and independently
of airbag deployment. Deployment of the
pretensioners is accompanied by a slight
discharge of harmless smoke and a noise,
due to the activation of the pyrotechnic
cartridge incorporated in the system.
In all cases, the airbag warning lamp comes
on.
Following an impact, have the seat belt
system checked, and if necessary replaced,

by a Fiat Dealership or a qualified workshop.

14/02/2022   15:33:27

103

Safety

5

Front seat belts





The front seat belts are fitted with a pyrotechnic

pretensioning system and a force limiting
system.
This system improves safety in the front seats in
the event of a front or side impact.
Depending on the severity of the impact, the
pyrotechnic pretensioning system instantly
tightens the seat belts against the body of the
occupants.
The pyrotechnic pretensioning seat belts are
enabled when the ignition is on.

The force limiter reduces the pressure of the
seat belt on the chest of the occupant, thus
improving their protection.

Fastening





►  Pull the strap, then insert the tongue into the

buckle.

►  Check that the seat belt is fastened correctly

by pulling on the strap.

Unfastening

►  Press the red button on the buckle.

►  Guide the seat belt as it reels in.

Height adjustment





►  To lower the attachment point, while moving

control

A

 downwards, slide the assembly down

to the desired position.

►  To raise the attachment point, slide the

assembly up to the desired position.

The upper part of the diagonal strap
should lie across the shoulder.

Two-seat front bench seat





14/02/2022   15:33:28

104

Safety

If the vehicle is fitted with a front bench seat,

ensure that each seat belt is used with its correct
buckle.
Do not interchange the driver's seat belt or
buckle with the centre seat belt or buckle.

Rear seat belts









A 3-seat bench seat (one-piece or split 1/3 seat

- 2/3 bench seat) is fitted with three-point seat

belts and inertia reels on the outer seats.
The centre seat has a seat belt guide and inertia

reel fitted into the seat backrest.

The seat belt inertia reels for the outer seats in

row 2 are fitted with force limiters.

The seats in row 3 have three-point seat belts
with inertia reels.

For rows 2 and 3, connect each seat belt
to its correct buckle.

Do not interchange the belts or buckles for
the outer seats with the belt or buckle for the
centre seat.
When folding the side seats or placing the
backrests in the table position, avoid trapping
the belt for the centre seat.
After folding or moving a rear seat or bench
seat, ensure that the seat belt has reeled
in correctly and that the buckle is ready to
receive the belt tongue.
When removing/repositioning the outer seats
or when accessing row 3, avoid trapping the
centre belt.

With individual seats

Shine

,

Business Lounge





They are fitted with three-point seat belts

with guides and belt inertia reels built into the
backrests.

Seat belt(s) warning lamps

A.

Front seat belts not fastened/unfastened
warning lamp.

B.

Left-hand seat belt not fastened/unfastened
warning lamp.

C.

Centre seat belt unfastened warning lamp (if

your vehicle is fitted with a 2-seat front bench

seat).

D.

Right-hand seat belt not fastened/unfastened

warning lamp (if your vehicle is fitted with

individual front seats).
Right-hand seat belt unfastened warning

lamp (if your vehicle is fitted with a 2-seat

front bench seat).

On switching on the ignition, the warning lamp(s)
come(s) on if the corresponding seat belt is not
fastened or is unfastened.
At speeds above approximately 12 mph

(20 km/h), the warning lamp(s) flash(es) for 2

minutes, accompanied by an audible signal.
Once these 2 minutes have elapsed, the warning
lamp(s) remain(s) on until the driver or the
passenger fastens their seat belt.

14/02/2022   15:33:28

105

Safety

5

Advice

The driver must ensure that passengers
use the seat belts correctly and that they

are all fastened before setting off.

Wherever seated in the vehicle, you must
always fasten the seat belt, even for short
journeys.
Do not invert the seat belt buckles, as they

will not fulfil their role properly.

To ensure the proper functioning of the belt
buckles, make sure that there are no foreign
bodies present (e.g. a coin) before fastening.
Before and after use, ensure that the seat belt
is reeled in correctly.
After folding or moving a seat or rear bench
seat, ensure that the seat belt is positioned
and reeled in correctly.

Installation

The lower part of the strap must be

positioned as low as possible over the pelvis.
The upper part must be positioned in the
hollow of the shoulder.
At the front, adjusting the position of the
seat belt may require the seat height to be
adjusted.

In order to be effective, a seat belt must:

–  be tightened as close to the body as
possible.
–  be pulled in front of you with a smooth
movement, checking that it is not twisted.
–  must only be used to secure one person.

–  not show signs of tearing or fraying.

–  not be changed or modified, in order to

avoid affecting its performance.

Recommendations for children

Use a suitable child seat if the passenger

is less than 12 years old or shorter than 1.5
metres.
Never use the same seat belt to secure more
than one child.
Never carry a child on your lap.
For more information on

Child seats

, refer to

the corresponding section.

Maintenance

In accordance with current safety

regulations, for all work on your vehicle's

seat belts, contact a qualified workshop with

the skills and equipment needed, which a
Fiat Dealership is able to provide.
Have the seat belts checked regularly by

a Fiat Dealership or a qualified workshop,

particularly if the straps show signs of
damage.
Clean the seat belt straps with soapy water
or a textile cleaning product, sold by Fiat
Dealerships.

Airbags

General information

System designed to help improve the safety
of the occupants sitting in the front seats and
the rear outer seats, in the event of a violent
collision. The airbags supplement the action
of the seat belts equipped with a force limiting
system.
Electronic detectors record and analyse the
front and side impacts sustained in the impact
detection zones:
–  In the event of violent impact, the airbags
deploy instantly and help better protect the
occupants of the vehicle; immediately after the

impact, the airbags deflate rapidly in order not

to hinder the visibility or the possible exit of the
occupants.
–  In the event of a slight impact, a rear impact
and under certain rollover conditions, the airbags
may not deploy; only the seat belt helps to
protect you in these situations.
The seriousness of the impact depends on the
nature of the obstacle and the speed of the
vehicle at the moment of collision.

The airbags do not operate when the

ignition is switched off.

This equipment will only deploy once. If a
second impact occurs (during the same or a
subsequent accident), the airbag will not be
deployed again.

14/02/2022   15:33:28

106

Safety

Impact detection zones

A.

Front impact zone

B.

Side impact zone

When one or more airbags are deployed,
the detonation of the pyrotechnic charge

incorporated in the system makes a noise and
releases a small quantity of smoke.
This smoke is not harmful, but sensitive
individuals may experience irritation.
The detonation noise associated with the
deployment of one or more airbags may result
in a slight loss of hearing for a short time.

* For more information on Deactivating the front passenger airbag, refer to the corresponding section.

Front airbags





This system protects the driver and front
passenger in the event of a serious front impact,
limiting the risk of head and chest injury.

The driver's airbag is fitted in the centre of the

steering wheel; the front passenger airbag is

fitted in the dashboard above the glove box.

Deployment

They are deployed, except for the front
passenger airbag if it is deactivated*, in the
event of a violent front impact applied to all or
part of front impact zone

A

.

The front airbag inflates between the chest and

head of the front occupant of the vehicle and
the steering wheel, on the driver's side, and the
dashboard, on the passenger's side, to cushion
their forward movement.





When driving

, keep the storage

compartment closed. Otherwise, there is

a risk of injury in the event of an accident or
sudden braking.

14/02/2022   15:33:28

107

Safety

5

Lateral airbags





This system protects the driver and front
passenger in the event of a serious side impact,
limiting the risk of injury to the chest, between
the hip and the shoulder.

Each lateral airbag is fitted in the seat backrest

frame, on the door side.

Deployment

They are deployed on one side in the event
of a serious side impact applied to all or part
of the side impact zone, perpendicular to the
longitudinal centreline of the vehicle on a
horizontal plane and directed from the outside
towards the inside of the vehicle.

The lateral airbag inflates between the front

occupant's abdomen and head and the
associated door trim panel.

Curtain airbags (Row 2 & 3)

Feel

,

Shine

,

Business Lounge

If fitted to your vehicle, this is a system that

contributes towards greater protection for
passengers (with the exception of the centre
seats) in the event of a serious side impact, in
order to limit the risk of injury to the side of the
head.
Each curtain airbag is built into the pillars and
the upper passenger compartment area.

Deployment

They are deployed on one side in the event
of a serious side impact applied to all or part
of the side impact zone, perpendicular to the
longitudinal centreline of the vehicle on a
horizontal plane and directed from the outside
towards the inside of the vehicle.

The curtain airbag inflates between the outer

rear passenger and the windows.

Malfunction

In the event of a malfunction, this warning
lamp lights up on the instrument panel.

Contact a Fiat Dealership or a qualified

workshop to have the system checked.
The airbags may not be deployed in the event of
a serious impact.

In the event of a minor impact or bump at
the side of the vehicle or if the vehicle

rolls over, the airbags may not be deployed.
In the event of a rear or front collision, none of
the lateral airbags are deployed.

Advice

For the airbags to be fully effective,

observe the safety recommendations

below.

Adopt a normal and upright sitting position.
Fasten your seat belt and position it correctly.
Do not place anything between the occupants
and the airbags (e.g. child, animal, object), do

not fix or attach anything near or in the path of

the airbags, as this could cause injuries when
they are deployed.

Never modify the original definition of the

vehicle, particularly in the area directly around
the airbags.
Even if all of the precautions mentioned are
observed, a risk of injury or of minor burns to
the head, chest or arms cannot be ruled out

when an airbag is deployed. The bag inflates

almost instantly (within a few milliseconds)

then deflates within the same time,

discharging the hot gas via openings provided
for this purpose.
After an accident or if the vehicle has been
stolen, have the airbag systems checked.
All work must be carried out only by a Fiat

Dealership or a qualified workshop

14/02/2022   15:33:28

108

Safety

Front airbags

Do not drive holding the steering wheel

by its spokes or resting your hands on the
centre part of the wheel.
Passengers must not place their feet on the
dashboard.
Do not smoke as deployment of the airbags
can cause burns or the risk of injury from a
cigarette or pipe.
Never remove or pierce the steering wheel or
hit it violently.

Do not fix or attach anything to the steering

wheel or dashboard, as this could cause
injuries when the airbags are deployed.

Lateral airbags

Use only approved seat covers

compatible with the deployment of these
airbags. For information on the range of seat
covers suitable for your vehicle, contact a Fiat
Dealership.

Do not fix or attach anything to the seat

backrests (e.g. clothing) as this could cause
injuries to the chest or arm when the airbag is
deployed.
Do not sit with the upper part of the body any
nearer to the door than necessary.
The vehicle's front door panels include side
impact sensors.
A damaged door or any unauthorised or

incorrectly executed work (modification or

repair) on the front doors or their interior trim
could compromise the operation of these

sensors - risk of malfunction of the lateral
airbags!
All work must be carried out only by a Fiat

Dealership or a qualified workshop

Feel

,

Shine

,

Business Lounge

Curtain airbags

Do not fix or attach anything to the roof,

as this could cause head injuries when the
curtain airbag is deployed.
Do not remove the grab handles installed on
the roof, as these help to secure the curtain
airbags.

Child seats

The regulations on carrying children are

specific to each country. Refer to the

legislation in force in your country.

For maximum safety, please observe the
following recommendations:
–  In accordance with European regulations,

all children under the age of 12 or less than

1.5 metres tall must travel in approved child

seats suited to their weight

, on seats fitted with

a seat belt or ISOFIX mountings.

–

Statistically, the safest seats in your

vehicle for carrying children are the rear

seats.

–

Children weighing less than 9 kg must

travel in the "rearward facing" position,

whether in the front or rear of the vehicle.

It is recommended

 that children travel

on the

rear seats

 of the vehicle:

–  "

rearward facing

" up to the age of 3,

–  "

forward facing

" over the age of 3.

Make sure that the seat belt is correctly
positioned and tightened.

For child seats with a support leg, ensure that

the support leg is in firm and steady contact

with the floor.

An incorrectly installed child seat in a

vehicle compromises the child's safety in

the event of an accident.
Ensure that there is no seat belt or seat belt
buckle under the child seat, as this could
destabilise it.
Remember to fasten the seat belts or the
child seat harness keeping the slack relative
to the child's body to a minimum, even for
short journeys.
When installing a child seat using the seat
belt, ensure that the seat belt is tightened
correctly on the child seat and that it secures

the child seat firmly on the vehicle seat. If

14/02/2022   15:33:28

109

Safety

5

the passenger seat is adjustable, move it
forwards if necessary.

Remove the head restraint before

installing a child seat with a backrest on a

passenger seat.

Ensure that the head restraint is stored or
attached securely to prevent it from being
thrown around the vehicle in the event of

sharp braking. Refit the head restraint once

the child seat has been removed.

Installing a booster seat

The chest part of the seat belt must be

positioned on the child's shoulder without
touching the neck.
Ensure that the lap part of the seat belt
passes correctly over the child's thighs.
Use a booster seat with a backrest, equipped
with a belt guide at shoulder level.

Additional protections

To prevent accidental opening of the

doors and rear windows, use the "Child lock".
Take care not to open the rear windows by
more than one third.
To protect young children from the sun's rays,

fit side blinds on the rear windows.

As a safety measure, do not leave:
–  A child alone and unsupervised inside a
vehicle.
–  A child or an animal in a vehicle which is
exposed to the sun, with the windows closed.

–  The keys within reach of children inside the
vehicle.

Child seat at the rear

Row 2





Forward-facing or rearward-facing









►  Move the vehicle's front seat forward and

straighten the backrest so that the legs of the
child in the forward-facing or rearward-facing
child seat itself do not touch the vehicle's front
seat.

►  Check that the backrest of the forward-facing

child seat is as close as possible to the backrest
of the vehicle's rear seat, and ideally in contact
with it.

►  Adjust the rear seat to the fully back

longitudinal position, with the backrest
straightened.

Ensure that the seat belt is correctly
tensioned.

For child seats with a support leg, ensure

that the support leg is in firm and steady

contact with the floor. If necessary, adjust the

vehicle's front seat.

Row 3





If a child seat is installed on a passenger seat in
the third row, move the seats in the second row
forward and straighten the backrests so that the
child seat and the child's legs do not touch the
seats in the second row.

Child seat at the front





►  Adjust the front passenger seat to the

highest

 and

fully back longitudinal position

,

with the backrest straightened

.

14/02/2022   15:33:29

110

Safety

"Forward facing"





You must leave the front passenger
airbag active.

"Rearward facing"





The front passenger airbag must be
deactivated before installing a rearward

facing child seat. Otherwise,

the child risks

being seriously injured or killed if the

airbag is deployed

.





Warning label - Front passenger airbag





You must comply with the following instruction,
as reminded by the warning label on both sides
of the passenger sun visor:

NEVER use a rearward facing child restraint

on a seat protected by an ACTIVE AIRBAG in

front of it, DEATH or SERIOUS INJURY to the

CHILD can occur.

Deactivating the front

passenger airbag

To ensure the safety of the child, the front
passenger airbag MUST be deactivated

when a "rearward facing" child seat is
installed on the front passenger seat.
Otherwise, the child risks being seriously

injured or killed in the event of deployment of
the airbag.

Vehicles not equipped with a

deactivation/reactivation control

Installing a "rearward facing" child seat on the
front passenger seat or bench seat is strictly
prohibited - risk of death or serious injury in
the event of airbag deployment!

Deactivating/Reactivating the front

passenger airbag

For vehicles on which it is fitted, the switch is

located inside the glove box.









14/02/2022   15:33:29

111

Safety

5









With the ignition off:

►  To deactivate the airbag, turn the key in the

switch to the "

OFF

" position.

►  To reactivate it, turn the key to the "

ON

"

position.
When the ignition is switched on:

This warning lamp comes on and remains
lit to signal deactivation.

Or

This warning lamp comes on for about 1
minute to signal activation.

Recommended child seats

Range of child seats secured using a

three-

point seat belt

.

Group 0+: from birth to 13 kg





L1

"RÖMER Baby-Safe"

Installed in the "rearward facing" position.

Groups 2 and 3: from 15 to 36 kg





L5

"RÖMER KIDFIX 2R"

Can be fitted to the vehicle's ISOFIX

mountings.

The child is restrained by the seat belt.

A version with a removable backrest may be

used for children weighing more than 25 kg.

However, for better protection, use a booster

seat with backrest for all children weighing up

to 36 kg.

Only suitable for installation on the side rear

seats.

14/02/2022   15:33:29

112

Safety

Locations for child seats secured using the seat belt

In accordance with European regulations, the table indicates the options for installing child seats secured using a seat belt and universally approved

(a)



according to the weight of the child and the seating position in the vehicle.





Weight of the child

/indicative age

Seats

Under 13 kg

(groups 0 (b) and

0+)

Up to about 1 year

old

From 9 to 18 kg

(group 1)

From about 1 to 3

years old

From 15 to 25 kg

(group 2)

From about 3 to 6

years old

From 22 to 36 kg

(group 3)

From about 6 to 10

years old

Cab/Row 1 (c) (f)





Individual seat,

passenger seat

U





Bench seat, outer seat

U





Bench seat, centre

seat

X

Row 2 (d)

 (Fixed and folding bench seat)





Rear seats

U

14/02/2022   15:33:29

113

Safety

5

Combi





Weight of the child

/indicative age

Seats

Under 13 kg

(groups 0 (b) and

0+)

Up to about 1 year

old

From 9 to 18 kg

(group 1)

From about 1 to 3

years old

From 15 to 25 kg

(group 2)

From about 3 to 6

years old

From 22 to 36 kg

(group 3)

From about 6 to 10

years old

Row 1 (c)





Individual seat, passenger

seat with passenger airbag

deactivated "

OFF

"

UF

Individual seat, passenger seat

with passenger airbag activated

"

ON

"

X

UF





Bench seat, centre seat with

passenger airbag deactivated

"

OFF

" or activated "

ON

"

X





Bench seat, outer seat with

passenger airbag deactivated

"

OFF

"

UF

Bench seat, outer seat with

passenger airbag activated "

ON

"

X

UF

Row 2 and 3





Rear seats

U

14/02/2022   15:33:30

114

Safety

Business

,

Feel





Weight of the child

/indicative age

Seats

Under 13 kg

(groups 0 (b) and

0+)

Up to about 1 year

old

From 9 to 18 kg

(group 1)

From about 1 to 3

years old

From 15 to 25 kg

(group 2)

From about 3 to 6

years old

From 22 to 36 kg

(group 3)

From about 6 to 10

years old

Row 1 (c)





Passenger seat (electric

adjustments) with passenger

airbag deactivated "

OFF

"

UF

Passenger seat (electric

adjustments) with passenger

airbag activated "

ON

"

X

U

Passenger seat (without

height adjustment) with

passenger airbag deactivated

"

OFF

"

UF

Passenger seat (without

height adjustment) with

passenger airbag activated

"

ON

"

X

U

Row 2 (d) and 3 (d)





Rear seats

U

14/02/2022   15:33:30

115

Safety

5

Shine

,

Business Lounge





Weight of the child

/indicative age

Seats

Under 13 kg

(groups 0 (b) and

0+)

Up to about 1 year

old

From 9 to 18 kg

(group 1)

From about 1 to 3

years old

From 15 to 25 kg

(group 2)

From about 3 to 6

years old

From 22 to 36 kg

(group 3)

From about 6 to 10

years old

Row 1 (c)





Passenger seat

(electric adjustments)

with passenger airbag

deactivated "

OFF

"

UF

Passenger seat

(electric adjustments)

with passenger airbag

activated "

ON

"

X

U

Row 2 (d) and 3 (d)





Outer seats

UF





Centre seat (e)

UF

14/02/2022   15:33:30
