68

Ease of use and comfort

a risk of injury in the event of an accident or
sudden braking.

Front door storage pockets

Liquids carried in an open vessel (e.g. a
cup or mug) could be spilt, presenting a

risk of damage on contact with the controls in
the dashboard and centre console. Be
careful.

Upper glove box

This is located in the dashboard, behind the
steering wheel.





Press the control to open the lid (depending on
version) then guide it to its fully open position.
To close it, guide the lid then press the centre
gently.

Any liquid which could spill risks causing

an electrical short circuit and therefore a

potential fire.

"Aircraft" type tables





Fitted to the back of each front seat.





►  To use the table, lower it fully until it locks in

the low position.

►  To stow it, raise the table to the high position,

passing the point of resistance.

On the passenger side, do not forget to
fold the table up before placing the seat

in the "table" position.
Do not place hard or heavy objects on
the table. They could become dangerous
projectiles in the event of emergency braking
or impact.

For more information on the

Front seats

,

and in particular placing the backrest in

the "table" position, refer to the corresponding
section.

12 V socket(s)

Depending on version.













14/02/2022   15:33:16

69

Ease of use and comfort

3





►  To connect a 12 V accessory (maximum

power: 120 Watts), lift the cover and plug in a
suitable adapter.

Observe the maximum power rating to
avoid damaging the accessory.

The connection of an electrical device
not approved by Fiat, such as a USB

charger, may adversely affect the operation of

vehicle electrical systems, causing faults such
as poor radio reception or interference with
displays in the screens.

USB socket









The socket can be used to connect a portable
device or a USB memory stick.

The socket reads audio files that are sent to your

audio system to be played through the vehicle's
speakers.

These files can be managed using the steering-

mounted controls or those on the audio system.

The USB socket also allows a
smartphone to be connected by

Android Auto

®

 or CarPlay

®

, enabling certain

smartphone applications to be used on the touch
screen.
For best results, use a cable made or approved
by the device manufacturer.
These applications can be managed using the
steering-mounted controls or the audio system
controls.

When the USB socket is used, the
portable device charges automatically.

While charging, a message is displayed if the
power drawn by the portable device exceeds
the current supplied by the vehicle.

For more information about how to use this
equipment, refer to the sections describing
the audio and telematics systems.

220 V socket





Depending on version, a 220 V/50 Hz socket
(maximum power: 120 W) is located underneath
the front right-hand seat and therefore
accessible from row 2.
This socket works with the engine running, as
well as in STOP mode of Stop & Start.





►  Lift the cover.

►  Check that the indicator lamp is on green.

►  Connect your multimedia or other electrical

device (telephone charger, laptop computer,
CD-DVD player, bottle warmer, etc.).

14/02/2022   15:33:17

70

Ease of use and comfort

In the event of a malfunction, the

green indicator lamp flashes.

Have it checked by a Fiat Dealership or a

qualified workshop.

Connect only one device to the socket at
a time (do not use an extension lead or

multi-socket) and only connect devices with
Class II insulation (indicated on the device).
Do not use devices with metallic cases.

If the power consumption becomes too
high and when required by the vehicle's

electrical system (particular weather
conditions, electrical overload, etc.), the

power supply to the socket will be cut off; the

green indicator lamp goes off

Load space cover









►  To remove it, lift it up.

►  To install it, insert the guides into their

housings.

In the event of sudden deceleration,
objects placed on the load space cover

can turn into projectiles.

Loading area fittings

Stowing rings

















Use the stowing rings on the rear floor to secure

loads.
As a safety precaution in case of sharp braking,
we recommend placing heavy objects as far
forwards as possible (i.e. near the cab).

We recommend immobilising the load by firmly

securing it using the stowing rings present on

the floor.

14/02/2022   15:33:17

71

Ease of use and comfort

3

Load retaining partition









On the floor, behind the front seats, a vertical

partition protects the driver and front passengers
against the risk of load movement.
Steel or glazed partitions separate the loading
area from the cab.

Recommendations on

loading

The weight of the load must comply with
the Gross Train Weight (GTW).

For more information on

Engine technical

data and towed loads

, refer to the

corresponding section.

If you are using a carrying system (roof
bars/roof rack), comply with the

maximum loads associated with this system.
For more information on

Roof bars/Roof

rack

, refer to the corresponding section.

Make sure that the size, shape and
volume of the loads carried are

compatible with the highway code and safety

regulations and do not impair the driver’s field

of vision.

The load must be evenly distributed in
the loading area so as not to interfere

with driving the vehicle.
Place the load close to the side wall panels,
or push it against the side wall panels
between the wheel arches.
However, it is recommended that heavy
objects are placed as close to the cab as
possible as a precaution in case of sharp
braking.

Firmly secure all parts of the load using

the stowing rings on the floor of the

loading area.
For more information on the

Interior fittings



and in particular on the stowing rings, refer to
the corresponding section.

To avoid the risk of injury or accident, the
load must be made stable so that it

cannot slide, tip over, fall or be projected. To
do this, use only retaining straps that conform
to current standards (DIN, for example).
For more information on putting straps in
place, refer to the manufacturer’s user guide.
To prevent the load from sliding, there must
not be any empty spaces between the load
items and the vehicle wall panels.
As well as the straps, optimise the stability
of the load with stable handling equipment
(wedges, rigid blocks of wood or padding).

When washing your vehicle, never clean
the inside directly using a water jet.

14/02/2022   15:33:17

72

Ease of use and comfort

Seating area fittings





High load retaining net

This allows the use of the entire loading capacity,
up to the roof:
–  behind the front seats in row 1, when the rear
seats (and bench seats) in rows 2 and 3 are
folded or removed,
–  behind the rear seats (and bench seats) in row
2, when the rear seats (and bench seats) in row
3 are folded or removed.

Upper fixings





►  Unclip the anchorage cover in the roof on

each side.

Lower fixings (behind row 1)

If your vehicle has

fixed

 one-piece bench seats

or seats and bench seats:





►  On each side in row 2, insert the fixings in the

floor anchorages (as shown above).

If your vehicle has seats and bench seats or
individual seats on

rails

:





►  On each side in row 2, insert the fixings in the

floor anchorages then turn them a quarter turn to

lock them in place (as shown above).
Place them as close as possible to the end of
the rail.

Lower fixings (behind row 2)





►  Use the stowing rings.

Fit the net

Unclip the upper fixing covers and secure the

lower fixings (as previously described).

►  Fold (table position) the seats and bench

seats in rows 2 and 3 (according to equipment).

►  Close the rear heating and air conditioning

vents (depending on the equipment you have).

►  Unroll the high load retaining net.

►  Position the net upper fixings in the

corresponding anchorages in the roof (first one

side, then the other).

►  Fully extend the straps.

►  On each side, attach the bottom fixings of the

net to the lower anchorages (behind row 1) or in
the stowing rings (behind row 2).

►  Tension the straps to extend the net.

►  Check that the net is attached securely and

properly extended.

14/02/2022   15:33:17

73

Ease of use and comfort

3

Never use the ISOFIX ring provided for

fixing the strap of a child seat with Top

Tether.

Rear windows in row 2

If fitted to your vehicle, the side windows in row 2

can be opened.





While driving, the windows must be closed or
secured at one of the notches.

►  Squeeze the two controls then move the

window sideways.

For more information on the

Child lock

on rear windows

, refer to the

corresponding section.

Side blinds

Fitted to the windows in row 2, these protect the
passenger compartment from the sun's rays.





►  Pull the tab

A

 and attach the blind to the hook

B

.

Always guide the blind slowly, using the

tab, when raising or lowering it.

Panoramic sunroof





This is fitted with two manual and independent

blinds, which improve thermal and acoustic
comfort.

Blinds
Opening/Closing





►  Take one of the blinds by its grip and push it

back or pull it forwards to the desired position.

Retractable sliding table

Shine

,

Business Lounge



14/02/2022   15:33:17

74

Ease of use and comfort



The table has a central storage space covered
by a lid. When deployed, this device becomes
a table with two table tops on which you can
place objects. The central part has two cup/
can holders and can also be used to hold small
objects (e.g. credit card, pen).
The assembly is mounted on a runner allowing it
to be positioned either in row 2 or row 3.

Storage





►  Slide back the cover for access to 11 litres of

storage space.

The storage space can only support a
maximum weight of 3 kg; do not exceed

this maximum load in use.

Moving forward or backward





►  Lift the control (without going beyond the

point of resistance) and slide the assembly
forwards or backwards.

►  Release the control when it is in the desired

position.

►  Check that the table is secured on the runner.

If this is not the case, move the assembly slightly
to the next notch on the runner.

You can move the table in both the open
and stowed position. However, to ensure

safety, it is advised that you handle the
assembly in the stowed position.

For the table to run smoothly, ensure that
no objects are blocking the space used

by the runner on the floor.

Before manoeuvring the table, check that
there is nothing on the table.

Unfolding





►  Operate the control on the top and pull the

table assembly up until it clicks into place.

►  Pull each table top fully up then pivot them on

each side into the horizontal position.

Folding

►  Raise each table top, going beyond the point

of resistance, to the vertical position.

►  Push each table top down into its housing

until it clicks into place.



14/02/2022   15:33:18

75

Ease of use and comfort

3



►  Push the control then tip the table assembly

downward until it clicks into place.

Before stowing the table tops, check that
they are clear. Before tipping the

assembly down, check that the two table tops
have clicked home in the low position and that
there is nothing in the cup holder area (such
as a can or pen).

Cup holders

Two cups or cans and small objects (such as
a credit card, portable ashtray or pen) can be
carried in the middle of the unfolded table.

Liquids carried in an open vessel (a cup
or mug) could be spilt, presenting a risk.

Be careful.
Never use the table in this position while the
vehicle is being driven.

Removal





►  Raise the control fully to release the

anchorages and tip the table assembly forward.

►  Remove the table assembly through the

sliding door in row 2.

Check that there is nothing in the space

around the runner on the floor, so that

the table disengages cleanly.

Changing the direction





With the table removed, you can turn it 180°.

Remove a seat to make this easier.

Refitting

►  Check that there is no object obstructing the

runner and preventing proper locking.





14/02/2022   15:33:18

76

Ease of use and comfort

►  Check that the control is in the upper position

(locking mechanism armed). If not, lift this control
fully to arm the mechanism.

►  Place the front of the table on the runner.

►  Taking care not to interfere with the control,

tip the assembly towards the rear until you hear
it lock into place.

►  Check that the assembly is fully locked into

the runner. If not, slide the assembly gently along
the runner until it meets the next notch.

Check that the table is fully locked into
the runner - risk of injury in the event of

an accident or sudden braking.

►  Release the control until the guide locks into

the runner.

Be careful of passengers' feet when
manoeuvring the assembly.

Storage off the runner

If removing the table from the vehicle for
storage, ensure that it is placed in a

clean area, in order to avoid introducing any
foreign bodies into the mechanisms.
The table must be placed outside the vehicle,

on a flat and level surface, resting on the

guide so as not to damage visible parts.

Caution, when out of the vehicle, the
table leans to the right or left when

placed on a surface.





Incorrect use of the table can cause
serious injury.

Never use the table in the open or deployed
position while the vehicle is in motion. In the
event of sudden braking, any object placed on
the table can become a projectile.
Ensure that the table is correctly stowed in

the low position before setting off.

Never use the table tops as seats or lean on
them.
A label attached to the side of the table
serves as a reminder of this.

Never place hot objects such as
saucepans or frying pans on the table

- risk of damaging the surface and starting a

fire!

When the table is deployed, each table
top can support a maximum of 10 kg. If

you exceed the maximum weight limit, you
risk damaging part or all of the table.
Never lift the table when it is between
individual seats; you risk damaging the table
tops.





Before moving the table or an individual
seat forwards or backwards, make sure

that the seat's backrest is upright and the
table is stowed.



14/02/2022   15:33:18

77

Ease of use and comfort

3



When stowing the table tops, never place
your hand inside the slide area - risk of

trapping your fingers! Use the handle

provided.

Heating and Ventilation

Advice

Using the ventilation and air

conditioning system

►  To ensure that air is distributed evenly,

keep the external air intake grilles at the base
of the windscreen, the nozzles, the vents, the
air outlets and the air extractor in the boot
free from obstructions.

►  Do not cover the sunshine sensor located

on the dashboard; this sensor is used to
regulate the automatic air conditioning
system.

►  Operate the air conditioning system for at

least 5 to 10 minutes once or twice a month to
keep it in good working order.

►  If the system does not produce cold air,

switch it off and contact a Fiat Dealership or a

qualified workshop.

When towing a large load on a steep gradient

in high temperatures, switching off the air

conditioning increases the available engine
power, enhancing the towing capacity.

Avoid driving for too long with the

ventilation off or with prolonged operation

of interior air recirculation. Risk of misting and
deterioration of the air quality!

If the interior temperature is very high
after the vehicle has stood for a long

time in the sunshine, air the passenger
compartment for a few moments.

Put the air flow control at a setting high

enough to quickly change the air in the
passenger compartment.

Condensation created by the air
conditioning results in a discharge of

water underneath the vehicle. This is perfectly
normal.

Servicing the ventilation and air

conditioning system

►  Ensure that the passenger compartment

filter is in good condition and have the filter

elements replaced regularly.
We recommend using a composite passenger

compartment filter. Its specific active additive

helps protect against polluting gases and bad
smells.

►  To ensure correct operation of the

air conditioning system, have it checked
according to the recommendations in the
Manufacturer’s service schedule.





Contains R134A fluorinated

greenhouse gases

Depending on version and country of sale, the
air conditioning system may contain R134A

fluorinated greenhouse gases. Gas capacity

0.5 kg (+/- 0.025 kg), GWP index 1430 (CO

2

equivalent: 0.715 t).

Stop & Start

The heating and air conditioning systems

only work when the engine is running.
Temporarily deactivate the Stop & Start
system to maintain a comfortable temperature
in the passenger compartment.
For more information on

Stop & Start

, refer

to the corresponding section.

ECO driving mode

Selecting this mode reduces electrical

energy consumption, but restricts the
performance of the heating and air
conditioning systems, although it does not
deactivate them.

14/02/2022   15:33:18

78

Ease of use and comfort

Heating





Manual air conditioning

The air conditioning system only operates with
the engine running.





1.

Temperature.

2.

Air flow.

3.

Air distribution.

4.

Interior air recirculation.

5.

Air conditioning on/off.

Air flow

►  Turn the thumbwheel

2

 to obtain a

comfortable air flow.

If you set the air flow control to the

minimum

 position (off), the temperature

in the vehicle will no longer be controlled. A

slight air flow can still be felt however,

resulting from the forward movement of the
vehicle.

Temperature

►  Turn the thumbwheel

1

 from "

LO

" (cold)

to "

HI

" (hot) to adjust the temperature to your

requirements.

Air distribution

►  Pressing button

3

 successively directs the air

flow towards:

–  windscreen, side windows and footwells,
–  footwells,
–  central vents, side vents and footwells,
–  windscreen, side windows, central vents, side
vents and footwells,
–  central and side vents,
–  windscreen and side windows (demisting or
defrosting).

Air conditioning

With the engine running, the air conditioning is

designed to operate effectively in all seasons,

with the windows closed.
It enables you to:
–  lower the temperature in summer,

–  enhance the effectiveness of the demisting

function in winter, above 3°C.

On/Off

►  Press button

5

 to activate/deactivate the air

conditioning system.
When the air conditioning is in operation, to
cool the air more quickly, you can use interior

air recirculation for a few moments by pressing
button

4

. Then restore the intake of exterior air.

The air conditioning does not operate

when the air flow adjustment is set to off.

Switching the system off could result in

discomfort (humidity, misting).

Dual-zone automatic air
conditioning





1.

Temperature.

2.

Air flow.

3.

Air distribution.

4.

Recirculation of interior air.

5.

Air conditioning on/off.

6.

Automatic comfort mode.

7.

Visibility programme.

8.

“Mono” function or Rear heating and air

conditioning on/off (depending on version).

Automatic comfort mode

►  Press the "

AUTO

" button

6

 to toggle the

mode.

14/02/2022   15:33:18

79

Ease of use and comfort

3

The active mode appears in the display screen,
as described below:

Ensures soft, quiet operation by limiting

air flow.

Offers the best compromise between a

comfortable temperature and quiet

operation.

Provides dynamic, effective air flow.



When the engine is cold, the air flow will

only increase to its optimum level

gradually, to avoid distributing too much cold
air.
In cold weather, it prioritises the distribution of
warm air to the windscreen, the side windows
and the footwells only.

Manual mode

It is possible to make a different choice from that

offered by the system by changing a setting.

The other functions will still be automatically
managed.
The "

AUTO

” symbol disappears if you change a

setting.

Deactivating the system

►  Press button

2

 "

-

" until the fan symbol

disappears.

This action switches off all of the functions of the

system.

Temperature is no longer controlled. A slight air

flow can still be felt, however, resulting from the

forward movement of the vehicle.

►  Press button

2

 "

+

" to switch the system on

again.

Temperature

The driver and front passenger can each set the
temperature to suit their preferences.
The value shown on the display is a level
of comfort, not a temperature in Celsius or
Fahrenheit.

►  Push button

1

 down to decrease the value or

up to increase it.

A setting of around 21 provides optimum

comfort. Depending on your

requirements, a setting between 18 and 24 is
normal.
In addition, we recommend avoiding left/right

setting differences of more than 3.

On entering the vehicle, if the interior

temperature is significantly colder or

warmer than the comfort value setting, there
is no need to alter the value displayed in
order to reach the required level of comfort.
The system compensates automatically and

corrects the temperature difference as quickly

as possible.

For maximum cooling or heating of the
passenger compartment, it is possible to

exceed the minimum value 14 or the
maximum value 28.

►  Push button

1

 down until

"LO"

 is

displayed or up until

"HI"

 is displayed.

"Mono" function

The comfort setting for the passenger's side
can be indexed to the driver's comfort setting
(mono-zone).





►  Press the corresponding button

8

 to activate/

deactivate the function.
The indicator lamp in the button is on when the
function is activated.
The function is deactivated automatically if a
passenger uses the temperature control.

Rear heating - air

conditioning





►  Press the corresponding button

8

 to activate/

deactivate the function.

For more information, refer to the

Rear

heating - air conditioning

 section.

14/02/2022   15:33:19

80

Ease of use and comfort

Visibility programme

►  Press the "

visibility

" button

7

 to demist or

de-ice the windscreen and side windows more
quickly.
The system automatically manages the air

conditioning, air flow and air intake, and provides

optimum distribution towards the windscreen and
side windows.

►  Press the "

visibility

" button

7

 again to stop

the programme.
Or

►  Press the "

AUTO

" button

6

 to return to the

automatic comfort programme.

Air

conditioning

With the engine running, the air conditioning is

designed to operate effectively in all seasons,

with the windows closed.
It is used to:
–  lower the temperature in summer,

–  increase the effectiveness of the demisting in

winter, above 3°C.

On/Off

►  Press button

5

 to activate/deactivate the air

conditioning system.
When the air conditioning is in operation, to
cool the air more quickly, you can use interior
air recirculation for a few moments by pressing
button

4

. Then restore the intake of exterior air.

The air conditioning does not operate

when the air flow adjustment is set to off.

Switching the system off could result in

discomfort (humidity, misting).

Air distribution

►  Pressing button

3

 successively directs the air

flow towards:

–  windscreen, side windows and footwells,
–  footwells,
–  central vents, side vents and footwells,
–  windscreen, side windows, central vents, side
vents and footwells,
–  central and side vents,
–  windscreen and side windows (demisting or
defrosting).

Air flow

►  Press the buttons

2

 to increase/decrease the

air flow.

The air flow symbol (a fan) appears. It is filled in

or emptied gradually, according to the value set.

Interior air recirculation

The intake of exterior air prevents the formation
of mist on the windscreen and side windows.
Recirculating the interior air isolates the
passenger compartment from outside odours
and fumes and allows the desired passenger
compartment temperature to be achieved more
rapidly.

►  Press this button to activate/deactivate

the function (confirmed by the

illumination/extinction of the indicator lamp).

Front demisting
- defrosting

These markings on the control panel
indicate the positioning of the controls for

rapid demisting or defrosting of the windscreen
and side windows.

Heating or manual air

conditioning









►  Set the air flow, temperature and air

distribution controls to the appropriately marked
positions.

14/02/2022   15:33:19

81

Ease of use and comfort

3

►  For air conditioning, press this button;

its indicator lamp comes on.

Dual-zone automatic air

conditioning





►  Press this button to demist or defrost

the windscreen and side windows more

quickly.
The system automatically manages the air

conditioning, air flow and air intake, and provides

optimum distribution towards the windscreen and
side windows.

►  To turn it off, press this button

again or press "

AUTO"

.

The system restarts with the values in use before
it was deactivated.

Demisting/de-icing the
rear screen and/or the
door mirrors









►  Press one of these buttons to switch on/off

rear screen and door mirror demisting/de-icing
(depending on version).
The indicator lamp in the button comes

on

 when

the function is

activated

.

Demisting/de-icing switches off automatically to

prevent excessive power consumption.

Switch off demisting/de-icing as soon

as you no longer consider it necessary,

as decreased power consumption in turn
reduces energy consumption.

Demisting/de-icing only operates with the
engine running.

Rear heating - air
conditioning









If your vehicle is fitted with a rear air conditioning

unit located in the roof, this system distributes
conditioned and heated air via a distribution rail
and individual outlets.

14/02/2022   15:33:19

82

Ease of use and comfort

Air flow

►  Turn the dial to increase or decrease

the air flow.

Comfort temperature

–  Turn the thumbwheel from blue (cold)
to red (hot) to modulate the temperature

to your liking.
This control simultaneously adjusts the
temperature and the location of the air delivery:
–  blue: the air is delivered mainly at roof level,
–  red: the air is delivered mainly by the vent
located in row 3 on the right.

Activation/Deactivation





Depending on version, this button is accessible
at the front, from the dual-zone automatic air
conditioning control panel.

►  Press this button to activate/deactivate

the operation of the rear controls.

Additional heating/

ventilation system

Only available for Diesel vehicles.









Heating

This is an additional and separate system which
heats the passenger compartment and improves
defrosting performance.

This indicator lamp is lit while the system
is programmed or set in operation

remotely via the remote control.

It flashes during the whole duration of the

heating and goes off at the end of the heating

cycle or when stopped using the remote control.

Ventilation

This system allows ventilation of the passenger
compartment with exterior air to improve the
temperature experienced on entering the vehicle
in summer.

Programming

With a Connect Nav, use the remote control to
start/stop the additional heating.
With a Bluetooth

®

 audio system or a Connect

Radio, use the remote control to start/stop the
additional heating and/or adjust the pre-heating
times.

With Bluetooth

®

 audio system





►  Press the

MENU

 button to access the

main menu.

►  Select "

Pre-heat. / Pre-ventil.

".

►  Select "

Activation

" and, if necessary, for

programming,

“Parameters

".

►  Select "

Heating

" to heat the engine and

passenger compartment or "

Ventilation

" to

ventilate the passenger compartment.





►  Select:

•  the first clock to set/save the time at which

the pre-heating temperature will be reached,

•  the second clock to set/save a second time

at which the pre-heating temperature will be
reached,

14/02/2022   15:33:20

83

Ease of use and comfort

3

Using these two clocks and depending
on the season you can, for example,

select one or the other start time.

A message on the screen confirms your

choice.

With Connect Radio

Press

Connect-App

 to display the main

page.
Then press "

Programmable heating/

ventilation

".

►  Select the "

Status

" tab to activate/deactivate

the system.

►  Select the "

Other settings

" tab to choose

the "

Heating

" mode, to heat the engine and

passenger compartment, or "

Ventilation

" to

ventilate the passenger compartment.

►  Then set/save the time at which the

preheating temperature will be reached for each
selection.

Press this button to save.

With Connect Nav

In the

Applications > Car Apps

 menu:

►  Select

Temperature conditioning

.

►  Press the

Status

 tab to activate/deactivate

the system.

►  Press the

Settings

 tab to select

Heating



mode to heat the engine and passenger

compartment or

Ventilation

 to ventilate the

passenger compartment.

►  Then programme/save the activation time for

each selection.

►  Press

OK

 to confirm.

You must allow at least 60 minutes
between programming operations.

Depending on the outside temperature, a
certain amount of pre-conditioning time is

necessary in order to reach the programmed
temperature by the stored activation time.
This pre-conditioning time lasts up to 45 min.

Long-range remote control

This enables you to switch the heating in

the passenger compartment on or off from a

distance.
The remote control has a range of about 0.6
miles (1 km) in open country.





On

►  Pressing and holding this button starts

the heating immediately (confirmed by the

green indicator lamp coming on briefly).

Switching off

►  Pressing and holding this button stops

the heating immediately (confirmed by the

temporary illumination of the red indicator lamp).

The indicator lamp in the remote control flashes

for about 2 seconds if the vehicle has not
received the signal.
Then repeat the command after having changed
location.

Changing the battery

The indicator lamp in the remote control will
change to orange if the battery charge is low.
If the indicator lamp is not on, the battery is
discharged.





14/02/2022   15:33:21
