36

Access

Central locking









Manual

►  Press this button to lock/unlock the vehicle

(doors, tailgate or side-hinged doors) from inside
the passenger compartment.

The indicator lamp comes on to confirm the

central locking of the vehicle.

Central locking does not take place if any
of the doors are open.

When locking/deadlocking from the

outside

When the vehicle is locked or deadlocked

from the outside, the indicator lamp flashes

and the button is deactivated.

►  After normal locking, pull one of the

interior door controls to unlock the vehicle.

►  After deadlocking, you must use the

remote control, the "Keyless Entry and
Start" system or the built-in key to unlock the
vehicle.

Driving with the doors locked makes
access for the emergency services more

difficult in an emergency.





When transporting an oversized load
(tailgate or side-hinged doors open),

press the button to lock only the cab doors.





When transporting an oversized load
(tailgate or side-hinged doors open),

press the button to lock only the front and rear
doors (sliding side door).

When locking from inside, the door
mirrors do not fold.

Central locking from the inside does not
operate if one of the doors is open (indicated
by a mechanical noise coming from the
locks).
When the tailgate or side-hinged doors are
open, only the other doors are locked (the
button does not light up).

Automatic (anti-intrusion

security)

The doors and the tailgate or the side-hinged
doors can lock automatically while driving (speed
above 6 mph (10 km/h)).
To deactivate/reactivate this function (activated
by default):

►  Press the button until an audible signal is

heard and/or a message appears on the screen.

Locking/unlocking the

loading area













This button is unavailable if the vehicle
has been locked or deadlocked from

outside (using the key, remote control or
Keyless Entry and Start, depending on
equipment) or if any of the doors are still
open.

14/02/2022   15:33:08

37

Access

2

Automatic

The

loading area

 is always locked when driving.

To deactivate this automatic locking, go

to a Fiat Dealership or a qualified

workshop.

Manual

►  With complete unlocking activated,

press this button to lock (indicator lamp

comes on)/unlock (indicator lamp goes off) the

vehicle

.

►  With selective unlocking activated, press this

button to lock (indicator lamp comes on)/unlock

(indicator lamp goes off) the

loading area

.

Driving with the doors locked could make

it more difficult for the emergency

services to enter the vehicle in an emergency.

The indicator lamp goes off when

unlocking one or more doors of the

loading area

.

With the ignition off and the vehicle fully

locked, the indicator lamp goes off for energy

economy reasons.

Electric sliding side
door(s)

The exterior and interior door handles and the
interior buttons allow the electrically powered
movement of the door to be started.
Opening and closing of the doors is
accompanied by an audible signal.

Opening

With the exterior or interior handle





►  With the door unlocked, pull and release the

handle to start opening the door. Pull the handle
again to reverse the direction of the door's
movement.

With the remote control





►  With the door unlocked, press and

hold this button until the corresponding

sliding side door has opened.

►  Press this button again to reverse the

direction of the door's movement.

The remote control buttons are not active
with the ignition switched on.

With the button(s) on the door pillar









With the button(s) at the front









►  With total unlocking activated and the child

lock deactivated, to unlock the vehicle and start

14/02/2022   15:33:09

38

Access

opening a door, press the button corresponding
to the door you wish to open.

►  With selective unlocking activated, to unlock

only the

loading area

 and start opening a door,

press the button corresponding to the door you
wish to open.

►  In both cases, pressing the button again

reverses the direction of the door's movement.

Closing

With the exterior handle





►  Pull and release the handle to start closing

the door. Pull the handle again to reverse the
direction of the door's movement.

With the remote control

►  Press and hold this button until the

sliding side door has closed. Pull the

handle again to reverse the direction of the
door's movement.

The remote control buttons are not active
with the ignition switched on.

With the button(s) on the door pillar









With the button(s) at the front









►  To start closing a door, press the

corresponding button for that door. Press again
to reverse the direction of the door's movement.

The button is not operational and
pressing it results in an audible signal, if

the speed of the vehicle is above 20 mph (30
km/h).

The button(s) at the front or on the door
pillar is not operational and pressing it

results in an audible signal, if:
–  the vehicle is moving,
–  the child lock is on (activated) (for the
buttons on the door pillars),
–  the vehicle has been locked or deadlocked
from outside (using the key, remote control
or Keyless Entry and Starting, depending on
equipment).
The button for the left-hand door is not
operational and pressing it results in an

audible signal if the fuel filler flap is open.

General
recommendations for the
sliding side doors

Doors must only be operated when the
vehicle is stationary.

For your safety and that of your passengers,
as well as for correct operation of the doors,
you are strongly advised not to drive with a
door open.
Always check that it is safe to operate the
door and in particular, be sure not to leave
children or animals near the door controls
without supervision.
The audible warning, the lighting of the "door
open" warning lamp and the message on the
screen are there to remind you. Contact a Fiat

14/02/2022   15:33:09

39

Access

2

Dealership or a qualified workshop if you want

to deactivate this warning.
Lock the vehicle when you use an automatic
car wash.

Before opening or closing and while
moving doors, ensure that no person,

animal or object is in the door frame or any
other position that would block the desired
movement, inside or outside the vehicle.
If this advice is not followed, injuries or
damage may occur if any part of a person or
an object is trapped or caught.
Electrical door opening is disabled at speeds
above 2 mph (3 km/h):
–  However, if the vehicle started moving
while the doors were open, the speed must

be reduced below 19 mph (30 km/h) before

they can be closed.
–  Any attempt to open a door electrically
using the interior handle while driving results
in it only being possible to open the door
manually.
–  This situation is accompanied by the
audible warning, the lighting of the "door
open" warning lamp and the message on the
screen. To release the door and be able to
operate it again, it is necessary to stop the
vehicle.

Take care not to block the guide space

on the floor so that the door can slide

correctly.
For safety and functional reasons, do not
drive with the sliding side door open.

The electric controls are disabled in the
event of an impact. Manual opening and

closing remain possible.

While starting the engine, door
movements are paused, resuming when

the engine is running.

Depending on the engine fitted, if

the door is closed and an opening

request is issued in Stop mode of Stop &
Start, the door will open slightly and then
stop. In Start mode, the door will resume its
movement when the engine re-starts.

To hold the sliding side door in the open
position, open the door fully to engage

the latch (located at the bottom of the door).

Doors and door clearances





When open, a door projects beyond the body.
Allow adequate clearance when parking
alongside walls, lamp-posts, high pavements,
etc.





When open, a door never projects
beyond the rear bumper.

14/02/2022   15:33:09

40

Access

Safety/Obstacle detection

with electric door(s)





The obstacle detection system is triggered when
the moving door encounters an obstacle with a
certain level of physical resistance. If an obstacle
is detected:
–  while the door is closing, the door stops then
opens fully.
–  while the door is opening, the door stops then
closes.
–  twice in succession during a movement of the
door, the door will no longer close electrically
(uninitialisation).
On a steep slope: a safety system slows down
the movement of the door.
In all cases, wait a few seconds before operating
the door (closing or opening).
Close the door manually for safety reasons.
Then reinitialise the door.

Reinitialising electric doors

If electrical operations no longer work:

►  Fully close the door(s)

manually

.

►  Fully open the door(s)

electrically

.

►  Close the door(s)

electrically

.

On completion of this procedure, electric
operation of the doors is restored.
However, if a problem persists following this
procedure, contact a Fiat Dealership or a

qualified workshop.

On a steep slope





It is possible to open and close the doors
electrically on slopes of up to a 20% gradient.
If the vehicle is on a slope, with the front of the
vehicle facing up the slope, open the door with
care. The door may open more quickly due to
the incline.
On a steep slope, guide the side door manually
to help it to close.





If your vehicle is on a slope, with the front of the
vehicle facing down the slope, the door may not
stay open and may close

violently

 with the risk

of injury.

In the case of a steep slope, the door
may be driven by its own weight and as a

consequence may open or close

violently

.

There would not be time for action at the

electric controls to take effect.

There would not be time for the obstacle

detection system to react.

Take care not to leave the vehicle on a
steep slope with the door(s) open without
supervision. If this advice is not followed,
injuries or damage may occur if a person or
an object is trapped or caught.

14/02/2022   15:33:09

41

Access

2

Hands-free sliding side
door(s)

Opening/Closing





With a movement of your foot while keeping the
remote control on your person in the recognition
zone

A

, the system unlocks and opens the

sliding side door or closes and locks it.
The remote control must be located at the rear
of the vehicle, at least about 30 cm but no more
than about 2 m from the vehicle.

The automatic locking after closing the
door can be programmed in the vehicle

configuration menu.

Before making the movement with your
foot, ensure that you are steady and well

positioned, so that you do not lose your
balance (rain, snow, ice, mud, etc.).
Take care not to touch the exhaust tailpipe
when making the movement with your foot -
risk of burns.





►  Put your foot beneath the corner of the rear

bumper, then move the foot at normal speed with
a sweeping side movement.
The sensor detects the foot approaching and
leaving and triggers the opening or closing of the
side door.

Make the movement without interruption
and do not repeat it immediately

afterwards or several times.
If the door does not open, wait about
2 seconds before trying again.
Do not keep the foot in the air.

Confirmation that the door is going to

open or close is signalled by the direction

indicators flashing for a few seconds,

accompanied by an audible signal.
The movement of the door is reversed if the
movement of the foot takes place during the
manoeuvre.
If the vehicle is so equipped, the electric door
mirrors fold/unfold on locking/unlocking the
vehicle.

Automatic locking

The vehicle locks itself following the hands-free
closing of the sliding door.

If your vehicle is not fitted with an alarm,

locking is signalled by the fixed

illumination of the direction indicators for
about two seconds.
Depending on your version, the door mirrors
fold at the same time.

Activation/Deactivation

With audio system or touch screen

By default, hands-free access is activated.

The "Hands-Free Tailgate Access"
function or automatic vehicle

locking when the sliding door is closed is
activated and deactivated via the vehicle

configuration menu.

14/02/2022   15:33:09

42

Access

Malfunction

An audible signal repeated three times while
using the function indicates a fault with the
system.
Have it checked by a Fiat Dealership or a

qualified workshop.

If the "

Hands-free tailgate access

self-locking

" option is selected in the

vehicle menu and after closing the door,
check that the vehicle is properly locked.
Locking will not take place:
–  if the ignition is on,
–  if one of the doors or the tailgate is open,
–  if a "Keyless Entry and Start" remote
control is inside the vehicle.
If a number of gestures with your foot have

no effect, wait a few seconds before starting

again.
The system is automatically deactivated in
heavy rain or with accumulations of snow.
If it does not work, make sure that the
remote control is not exposed to a source of
electromagnetic interference (smartphone,
etc.).

Operation may be affected if using a

prosthetic leg.
This system may not work correctly if your

vehicle is fitted with a towbar.

The side door may open or close without
warning if:

–  Your vehicle is fitted with a towbar.

–  A trailer is coupled or decoupled.
–  A bicycle carrier is installed or removed.
–  Bicycles are loaded on to or unloaded from
the bicycle carrier.
–  Something is deposited or lifted behind the
vehicle.
–  An animal approaches the bumper,
–  The vehicle is washed.
–  The vehicle is being serviced.
–  A wheel is changed.
To avoid any sudden operation, keep the key
away from the detection zone (also from the
boot’s interior sides) or deactivate the function

in the vehicle configuration menu.

Ensure that no person or object might
prevent the correct opening or closing of

the doors.
Be aware of children when operating the
doors.

Side-hinged rear doors





►  After first opening the left-hand door, pull the

lever

A

 towards you to open the right-hand door.

Closing

►  First close the right-hand door, then the left-

hand door.

If the left-hand door is closed first, a

buffer stop located on the edge of the

right-hand door prevents it closing.

If the left-hand side-hinged door is not properly
closed, the "

door open

" warning lamp lights up

14/02/2022   15:33:10

43

Access

2

(the right-hand door is not detected). For more
information on the

List of warning lamps

 and,

in particular, the door open warning, refer to the
corresponding section.

Opening to approximately

180°





If fitted to your vehicle, a check strap system

allows the doors to be opened from about 90° to

about 180°.

►  Pull the yellow control when the door is open.

The check strap will engage again automatically
on closing.

When parked with the rear doors open to

90°, the doors will cover the rear lamps.

In order to warn other road users travelling in
the same direction (who may not be aware
that the vehicle is stationary) of the vehicle's
position, use a warning triangle or other

device required by legislation and regulations
in your country.

Tailgate

Opening





►  After unlocking the vehicle, pull the handle,

then raise the tailgate.

Closing

►  Lower the tailgate using the interior grab

handle, then lock it.
If the tailgate is not properly closed, the "

door

open

" warning lamp comes on. For more

information on the

list of warning and indicator

lamps

, and in particular the door open warning,

refer to the corresponding section.

In the event of a malfunction or if you

experience difficulty opening or closing

the tailgate, have it checked by a Fiat

Dealership or a qualified workshop without

delay, to avoid the issue deteriorating and
prevent any risk of the tailgate dropping,
potentially causing serious injury.

Tailgate rear screen

The opening rear screen allows you to access
the rear of the vehicle directly, without having to
open the tailgate.

Opening





After unlocking the vehicle, press this control and
lift the rear screen to open it.

Closing

Close the rear screen by pressing the centre of
the glass until it is fully closed.
If the tailgate rear screen is not properly closed,
the "

door open

" warning lamp comes on. For

more information on the

list of warning and

14/02/2022   15:33:10

44

Access

indicator lamps

 and in particular the door open

warning, refer to the corresponding section.

The tailgate and rear screen cannot both
be open at the same time, to avoid

damaging them.

Alarm





(Depending on version)









System which protects and provides a deterrent
against theft and break-ins.

Exterior perimeter monitoring

The system checks for opening of the vehicle.
The alarm is triggered if anyone tries to open a
door, the boot or the bonnet, for example.

Interior volumetric monitoring

The system only checks for any
variation in volume in the

cab

.

The alarm is triggered if anyone
breaks a window or enters the
vehicle’s

cab

; however it is not

triggered if someone enters the

loading area

.

The system checks for any
variation in volume in the
passenger compartment.
The alarm is triggered if anyone
breaks a window, enters the
passenger compartment or
moves inside the vehicle.

Self-protection function

The system checks whether any of its
components are out of service.
The alarm is triggered if the battery, the central
control or the siren wiring is put out of service or
damaged.

Work on the alarm system

Contact a Fiat Dealership or a qualified

workshop.

If your vehicle is fitted with Additional

Heating / Ventilation, volumetric

monitoring is not compatible with this system.
For more information on

Additional Heating

/ Ventilation

, refer to the corresponding

section.

Locking the vehicle with full

alarm system

Activation

►  Switch off the ignition and exit the vehicle.

►  Lock or deadlock the vehicle using the

remote control or with the Keyless Entry and
Start system.
When the monitoring system is active, the red

indicator lamp in the button flashes once per

second and the direction indicators come on for
about 2 seconds.
The exterior perimeter monitoring is activated
after 5 seconds and the interior volumetric
monitoring after 45 seconds.

If an opening (door, tailgate/side-hinged
doors or bonnet) is not properly closed,

the vehicle is not locked, but the exterior
perimeter monitoring will be activated after 45
seconds, at the same time as the interior
volumetric monitoring.

14/02/2022   15:33:10

45

Access

2

Deactivation

►  Press the remote control unlocking

button.

or

►  Unlock the vehicle with the Keyless Entry and

Start system.
The monitoring system is deactivated: the

indicator lamp in the button goes off and the

direction indicators flash for about 2 seconds.

If the vehicle automatically locks itself
again (as happens if a door or the boot is

not opened within 30 seconds of unlocking),
the monitoring system is automatically
reactivated.

Triggering of the alarm

This is indicated by sounding of the siren

and flashing of the direction indicators for 30

seconds.
The monitoring functions remain active until
the alarm has been triggered ten times in
succession.

When the vehicle is unlocked, rapid flashing of

the indicator lamp in the button indicates that the
alarm was triggered during your absence. When

the ignition is switched on, this flashing stops

immediately.

Locking the vehicle

with exterior perimeter

monitoring only

Deactivate the interior volumetric monitoring to
avoid the unwanted triggering of the alarm, in
certain cases such as:
–  Slightly open window.
–  Washing the vehicle.
–  Changing a wheel.
–  Towing the vehicle.
–  Transport on a ship or ferry.

Deactivating interior volumetric

monitoring

►  Switch off the ignition and within 10 seconds

press the alarm button until the indicator lamp is

on fixed.

►  Exit the vehicle.

►  Immediately lock the vehicle using the remote

control or the "Keyless Entry and Start" system.
Only exterior perimeter monitoring is activated;

the red indicator lamp in the button flashes every

second.

To take effect, this deactivation must be

performed whenever the ignition is switched

off.

Reactivating interior volumetric

monitoring

►  Deactivate exterior perimeter monitoring by

unlocking the vehicle using the remote control or
the "Keyless Entry and Start" system.

The indicator lamp in the button goes off.

►  Reactivate the full alarm system by locking

the vehicle using the remote control or the
"Keyless Entry and Start" system.
The red indicator lamp in the button once again

flashes every second.

Locking the vehicle without

activating the alarm

►  Lock or deadlock the vehicle using the key

(integral to the remote control) in the driver's
door lock.

Failure of the remote control

To deactivate the monitoring functions:

►  unlock the vehicle using the key (integral to

the remote control) in the driver's door lock,

►  Open the door; this sets off the alarm.

►  Upon switching on the ignition the alarm

stops. The button indicator lamp goes off.

Malfunction

When the ignition is switched on, the fixed

lighting of the red indicator lamp in the button
indicates a system malfunction.
Have it checked by a Fiat Dealership or a

qualified workshop.

14/02/2022   15:33:10

46

Access

Automatic activation

(Depending on version)
The system is activated automatically 2 minutes
after the last door or the boot is closed.

►  To avoid triggering the alarm on entering the

vehicle, first press the unlocking button on the

remote control or unlock the vehicle using the
"Keyless Entry and Start" system.

Electric windows

1.

Left-hand front.

2.

Right-hand front.

Operation

►  To open/close the window manually, press/

pull the switch without passing the point of
resistance; the window stops as soon as the
switch is released.

►  To open/close the window automatically,

press/pull the switch fully, beyond the point of
resistance; the window opens/closes completely
when the switch is released (pressing the switch
again stops the movement of the window).

The electric window controls remain
operational for about 45 seconds after

the ignition is switched off if the front doors

are not open.
After that time, the controls are disabled. To
reactivate them, switch the ignition on again.

Safety anti-pinch

If your vehicle is fitted with the safety anti-pinch

function, when the window rises and meets an
obstacle, it stops and partially lowers.
In the event of unwanted opening of the window
on closing, press the control until the window
opens completely. Within 4 seconds, pull the
control until the window closes.
The safety anti-pinch does not operate while
doing this.

Reinitialising the electric

windows

After reconnecting the battery, or in the event
of abnormal window movement, the anti-pinch
function must be reinitialised.

The anti-pinch function is disabled during the

following sequence of operations.

For each window:

►  Lower the window fully, then raise it; it will

rise in steps of a few centimetres each time the
control is pressed. Repeat the operation until the
window is fully closed.

►  Continue to pull the control for at least one

second after the window reaches the closed
position.

If an electric window meets an obstacle
during operation, the movement of the

window must be reversed. To do this, press
the relevant control.
When the driver operates the passenger
electric window control, it is important to
ensure that nothing can prevent the window
from closing properly.
Pay particular attention to children when
operating the windows.
Do not put your head or arms through the
open windows when the vehicle is moving -
risk of serious injury!

14/02/2022   15:33:10

47

Ease of use and comfort

3

Correct driving position

Before taking to the road and to make the most
of the ergonomic layout of the instruments and
controls, carry out these adjustments in the
following order:
–  the height of the head restraint,
–  the seat backrest angle,
–  the seat cushion height,
–  the longitudinal position of the seat,
–  the height and reach of the steering wheel,
–  the rear view mirror and door mirrors.





Once these adjustments have been
made, check the instrument panel can be

viewed correctly from your driving position.

Manually-adjusted front
seats

For more information on the

Seat belts

,

refer to the corresponding section.

Longitudinal





►  Raise the control bar and slide the seat

forwards or backwards.

►  Release the control bar to lock the seat in

position on one of the notches.

Before moving the seat backwards,
ensure that there is nothing that might

prevent the full travel of the seat.
There is a risk of trapping or pinching
passengers if present in the rear seats or
jamming the seat if large objects are placed

on the floor behind the seat.

Height





►  Pull the control upwards to raise or push it

downwards to lower, until you obtain the position
required.

Backrest angle





►  Depending on equipment, turn the knob

or pull the control all the way up and tilt the
backrest forwards or backwards to obtain the
desired angle.

Lumbar





14/02/2022   15:33:11

48

Ease of use and comfort

►  Turn the knob to obtain the desired level of

lumbar support.

Table position of the driver's

and/or the front passenger

seat backrest





On the front passenger side, this position allows
long objects to be carried.
On the driver's side, this position allows rear
passengers to be helped out of the vehicle (by
the emergency services).

Check that there is no object that could
interfere with the movement of a seat,

both above and below.

►  Place the head restraint in the low position,

and if fitted to your vehicle, raise the armrest and

fold the table fitted to the back of the seat.

We recommend deactivating the front
passenger airbag.





►  Pull the control fully up and tip the backrest

forward.
To return to the normal position, pull the control
up to release the backrest, then pull the backrest
up to its raised position.

When sharp deceleration occurs, objects
placed on the folded backrest can turn

into projectiles.

Electric front seat

To avoid discharging the battery, carry
out these adjustments with the engine

running.

For more information on the

Seat belts

,

refer to the corresponding section.

Longitudinal





►  Push the control forwards or rearwards to

slide the seat.

Before moving the seat backwards,
ensure that there is nothing that might

prevent the full travel of the seat.
There is a risk of trapping or pinching
passengers if present in the rear seats or
jamming the seat if large objects are placed

on the floor behind the seat.

Seat cushion height





►  Tilt the control upwards or downwards to

obtain the desired height.

14/02/2022   15:33:11

49

Ease of use and comfort

3

Backrest angle





►  Tilt the control forwards or rearwards to

adjust the angle of the backrest.

Head restraint height
adjustment





If fitted to your vehicle.

►  To raise it, pull it upwards as far as possible

(notch).

►  To remove it, press the lug

A

 and pull it

upwards.

►  To put it back in place, engage the head

restraint rods in the openings keeping them in
line with the seat backrest.

►  To lower it, press the lug

A

 and push down on

the head restraint at the same time.

The head restraint has a frame with
notches which prevents it from lowering;

this is a safety device in case of impact.

The adjustment is correct when the upper

edge of the head restraint is level with the

top of the head.

Never drive with the head restraints removed;

they must be fitted and correctly adjusted.

2-seat front bench seat

If fitted in the vehicle, this is fixed and has a seat

belt built into the backrest for the seat next to the
driver’s seat.

For more information on the

Seat belts

,

refer to the corresponding section.

Under-seat storage





If the vehicle is so equipped, a storage space is
provided under the seat.

►  Pull the strap towards you to tip the seat

cushion.

Armrest





The armrest has notches.

►  Pull the armrest fully up

►  Lower it fully down.

►  Raise the armrest to the desired position.

14/02/2022   15:33:11

50

Ease of use and comfort

Heated seats and bench
seat













If fitted to your vehicle.

►  With the engine running and when the

outside temperature is below 20 °C, use the
adjustment knob to switch on and select the level
of heating required from

0

 (off) to

3

 (high).

Prolonged use of heated seats is not
recommended for people with sensitive

skin.
There is a risk of burns for people whose
perception of heat is impaired (e.g. illness,
taking medication).
To keep the heated pad intact and to prevent
a short circuit:
–  Do not place heavy or sharp objects on the
seat.
–  Do not kneel or stand on the seat.
–  Do not spill liquids onto the seat.
–  Never use the heating function if the seat
is damp.

Do not use the function when the seat
is not occupied.

Reduce the heating intensity as soon as
possible.
When the seat and passenger compartment
have reached a satisfactory temperature,

switch the function off; reducing electrical

consumption in turn decreases energy
consumption.

Electric lumbar
adjustment





►  Press the control to obtain the desired lumbar

support.

Massage function





14/02/2022   15:33:11

51

Ease of use and comfort

3

This function provides lumbar massage; it only
operates when the engine is running as well as
in STOP mode of the Stop & Start system.

Activation/Deactivation

►  Press this button to activate/deactivate

the function.

Upon activation, the indicator lamp comes on.
The massage function is activated for a period
of one hour.
During this time, massage is performed in
6 cycles of 10 minutes (6 minutes of massage
followed by a 4-minute break).
After one hour, the function is deactivated; the

indicator lamp goes off.

Adjustment of intensity





Press this button to adjust the intensity of
the massage.

Two levels of massage are available.

Steering wheel
adjustment





►

When stationary

, lower the control lever to

release the steering wheel.

►  Adjust the height and reach.

►  Pull the control lever to lock the steering

wheel.

As a safety precaution, these operations

must only be carried out while the vehicle

is stationary.

Mirrors

Door mirrors

As a safety measure, the mirrors should

be adjusted to reduce the "blind spots".

The objects that you see in the mirrors are
in fact closer than they appear. Take this

into account in order to correctly judge the
distance of vehicles approaching from behind.





►  Move control

A

 to the right or to the left to

select the corresponding mirror.

►  Move control

B

 in any of the four directions

to adjust.

►  Return control

A

 to its central position.

Manual folding

The mirrors can be folded manually (parking
obstruction, narrow garage, etc.).

►  Turn the mirror towards the vehicle.

Electric folding

Depending on equipment, the door mirrors can
be folded electrically.

►  From the inside, with the

ignition on, place control

A

 in the

central position.

►  Pull control

A

 backwards.

14/02/2022   15:33:12
