20

Dashboard instruments

indicating the driving range in miles or
kilometres.
While driving, the message is displayed every 30
seconds. The alert is repeated when switching
on the ignition.
You can continue driving for up to 685 miles
(1,100 km) before the

engine starting

prevention

 system is triggered.

Have it checked by a Fiat Dealership or a

qualified workshop.

Starting prevented

Every time the ignition is switched on, the
message "

Emissions control fault: Starting

prevented

" or "

NO START IN

" is displayed.

To restart the engine

Contact a Fiat Dealership or a qualified

workshop.

Power

indicator (Electric)





CHARGE

Traction battery charging during deceleration
and braking.

ECO

Moderate energy consumption and optimised
driving range.

POWER

Energy consumption by the drive train during
acceleration.

NEUTRAL

When the ignition is switched on, the vehicle’s
electric drive train neither consumes nor
generates energy; after sweeping over the
indicator, the needle returns to its "neutral"
position: between ECO and CHARGE.

With the ignition off, opening the driver's

door activates the indicator, which moves

to the "neutral" position: between ECO and
CHARGE.

Charge level indicator

(Electric)





The traction battery's actual charge level and
the remaining range are displayed continuously
when the vehicle is started.

With the ignition off, opening the driver's

door activates the indicator.

Associated warning lamps

Two successive alert levels indicate that the
energy available has dropped to a low level:

1st level: Reserve

0 %

100

The state of charge of the traction battery
is low.

14/02/2022   15:33:02

21

Dashboard instruments

1

Fixed LED and needle in the red zone,
accompanied by an audible signal.

►  View the remaining range on the instrument

panel.

►  Put the vehicle on charge as soon as

possible.

2nd level: Critical

The state of charge of the traction battery
is critical.

Fixed, together with the reserve LED,
accompanied by an audible signal.

►  You must put the vehicle on charge.

The remaining range is no longer
calculated. The drive train power

gradually decreases.
The heating and air conditioning are switched

off (even if the needle indicating their

consumption is not at the "

ECO

" position).

Thermal comfort

consumption indicator

(Electric)





The gauge shows the consumption of the
traction battery's electrical energy by the thermal
comfort devices in the passenger compartment.
The devices in question are the heating and air
conditioning systems.
This equipment can be used:
–  If the vehicle is not plugged in, when the

READY

 lamp is lit.

–  If the vehicle is plugged in, when the ignition is
switched on ("Lounge" mode).
Selecting

ECO

 mode limits the performance

of some of this equipment. The needle on the
thermal comfort consumption indicator then
moves into the "

ECO

" zone.

To quickly heat or cool the passenger
compartment, feel free to temporarily

select the maximum heating or cooling
setting.
When the heating is on maximum, the gauge
on the thermal comfort consumption indicator
is in the

MAX

 zone. When the air conditioning

is on maximum, it stays in the

ECO

 zone.

Excessive use of thermal comfort equipment,

particularly at low speed, can significantly

decrease the vehicle's range.
Remember to optimise equipment settings
upon achieving the desired level of comfort,
and adjust them if necessary whenever you
start the vehicle.
After an extended period without using the
heating, you may notice a slight odour during

the first few minutes of use.

Distance recorders

The total and trip distances are displayed for

thirty seconds when the ignition is switched off,

when the driver's door is opened and when the
vehicle is locked or unlocked.

14/02/2022   15:33:02

22

Dashboard instruments

Total distance recorder









This measures the total distance travelled by the
vehicle since its initial registration.

Trip distance recorder (Diesel)









This measures the distance travelled since it was
last reset by the driver.

Resetting the trip recorder





►  With the ignition on, press the button until

zeros appear.

Lighting dimmer

This system allows the brightness of the
instruments and controls to be adjusted manually
to suit the ambient light level.

With buttons









With the lamps on, press button

A

 to increase

the brightness of the lighting, or button

B

 to

decrease it.
Release the button when the desired brightness
is reached.

With touch screen





►  In the

Settings

 menu, select "

Brightness

"

or "

OPTIONS

", "

Screen configuration

" then

"

Brightness

".

►  Adjust the brightness by pressing the arrows

or moving the slider.

The brightness can be set differently for

day mode and night mode.

Trip computer

Displays information related to the current trip
(range, fuel consumption, average speed, etc.).

Information

display

To display the various trip computer tabs in turn:

14/02/2022   15:33:03

23

Dashboard instruments

1









►  Press the button located on the end of the

wiper control stalk

.

With steering-mounted controls





►  Press the knob on the

steering wheel

.

On the instrument panel









►  Press this button.

The following current information is shown in
turn:
–  Driving range (Diesel).

–  Current consumption.
–  Stop & Start time counter (Diesel).
–  Trip "

1

" followed by (depending on version)

trip "

2

" including average speed, average

consumption and distance travelled for each trip.
Trips "

1

" and "

2

" are independent but their use

is identical.
For example, trip "

1

" can be used for daily

figures and trip "

2

" for monthly figures.

Trip reset

The reset is performed when the trip counter is
displayed.









►  Press the button on the end of the

wiper

control stalk

 for more than two seconds.





►  Press the knob on the

steering wheel

 for

more than two seconds.









►  Press this button for more than 2 seconds.

Definitions

Range

(miles or km)
(Traction battery charge level percentage)
(Electric)

Distance that can still be travelled with the
fuel remaining in the tank (based on the

average fuel consumption over the last few miles
(kilometres) travelled).
This value may vary following a change in driving

style or terrain, leading to a significant change in

current fuel consumption.

When the range falls below 19 miles (30 km),

dashes are displayed.

After filling with at least 5 litres of fuel, the range

is recalculated and is displayed if it exceeds 62
miles (100 km).
Dashes appearing permanently in place of
numbers while driving indicates a malfunction.

14/02/2022   15:33:03

24

Dashboard instruments

Contact a Fiat Dealership or a qualified

workshop.

Current consumption

(mpg or l/100 km or km/l)
(miles/kWh or kWh/100 km or km/kWh) (Electric)

/

Calculated during the last few
seconds.

This function is only displayed at speeds above

19 mph (30 km/h) (Diesel).

Average consumption

(mpg or l/100 km or km/l)
(miles/kWh or kWh/100 km or km/kWh) (Electric)

/

Calculated since the last trip
computer reset.

Average speed

(mph or km/h)

Calculated since the last trip computer
reset.

Distance travelled

(miles or km)

Calculated since the last trip computer
reset.

Stop & Start time counter

(minutes/seconds or hours/minutes)

If your vehicle is fitted with the Stop & Start

function, a time counter calculates the time spent
in STOP mode during a journey.

The time counter is reset each time the ignition is
switched on.

Touch screen

This system gives access to the following
elements:
–  Permanent display of the time and outside
temperature (a blue warning lamp appears if
there is a risk of ice).
–  Vehicle functions and equipment setting
menus.
–  Audio system and telephone controls and
display of related information.
–  Display of visual manoeuvring aid functions
–  Internet services and display of related
information.
–  Navigation system controls and
display of related information (depending on
version).

For safety reasons, always stop the

vehicle before performing operations

that require sustained attention.

Some functions are not accessible while
driving.

Recommendations

This screen uses capacitive sensing technology.
–  Do not use pointed objects on the touch
screen.
–  Do not touch the touch screen with wet hands.

–  Use a soft, clean cloth to clean the touch
screen.

Principles

►  Use the buttons on each side of the touch

screen to access the menus, then press the
buttons that appear on the touch screen.
Some menus may display across two pages:
press the "

OPTIONS

" button to access the

second page.

After a few moments with no action on

the second page, the first page is

displayed automatically.

To deactivate/activate a function, select "

OFF

"

or "

ON

".

Configuring a function



Access to additional information on the

function

Confirm



Return to the previous page or confirm



Menus





14/02/2022   15:33:04

25

Dashboard instruments

1

Press the touch screen with three fingers

to show all of the menu buttons.

For more information about the menus,
refer to the sections describing the audio

and telematics systems.

Radio/Media



Navigation

 (Depending on equipment)

Driving or Vehicle

 (Depending on

equipment)

Activation, deactivation and settings for certain
functions.
The functions are organised in 2 tabs: "

Driving

functions

" and "

Vehicle settings

".

Telephone



Applications

Display of available connected services.

Energy

Access the specific Electric functions

(energy flow, consumption statistics, deferred

charge) organised in the corresponding 3 tabs.
or

Settings

Main settings for the audio system and

touch screen.

Audio system on/off

Volume adjustment/mute

Upper bar

Certain information is displayed permanently in
the upper bar of the touch screen:
–  Time and outside temperature (a blue warning
lamp appears if there is a risk of ice).
–  Reminder of information from the

RadioMedia

 and

Telephone

 menus and

navigation instructions (depending on
equipment).

–  Notifications.

–  Access to the

Settings

.

Energy menu (Electric)

Depending on version, this is accessible either:

–  directly, by pressing the button near the
touch screen.
–  via the

Applications

 menu.

Flow

The page displays a real-time representation of
the electric drive train’s operation.





1.

Active driving mode

2.

Electric motor

3.

Estimated traction battery charge level

4.

Energy flows

The energy flows have a specific colour for each

type of driving:

A.

Blue: energy consumption

B.

Green: energy recovery

Statistics

This page shows electrical energy consumption
statistics.





–  Blue bar chart: directly consumed energy
supplied by the traction battery.
–  Green bar chart: energy recovered during
deceleration and braking, used to recharge the
battery.
The average result for the current trip is stated in
kWh/100 km.

►  You can change the displayed time scale by

pressing the

-

 or

+

 buttons.

A current trip is any trip of more than 20

minutes without switching off the ignition.

14/02/2022   15:33:05

26

Dashboard instruments

Charging

This page allows you to programme deferred
charging.
For more information on

Charging the traction

battery (Electric)

, refer to the corresponding

section.

Setting the date and time

With audio system

►  Press the

MENU

 button for access to the

main menu

.

►  Press the "

7

" or "

8

" button to select the

"

Personalisation-configuration

" menu, then

confirm by pressing the

OK

 button.

►  Press the "

5

" or "

6

" button to select the

Display configuration

 menu, then confirm by

pressing the

OK

button.

►  Press the "

5

" or "

6

" and "

7

" or "

8

" buttons

to adjust the date and time values, then confirm

by pressing the

OK

 button.

With Connect Radio

►  Select the

Settings

 menu in the upper

banner of the touch screen.

►  Select "

Configuration

".

►  Select "

Date and time

".

►  Select "

Date

" or "

Time

".

►  Choose the display formats.

►  Change the date and/or time using the

numeric keypad.

►  Confirm with "

OK

".

With Connect Nav

Time and date settings are only available if GPS
synchronisation is deactivated.

►  Select the

Settings

 menu in the

banner of the touch screen.

►  Press the "

OPTIONS

" button to access the

secondary page.

►  Select "

Setting the time-date

".

►  Select the "

Date:

" or "

Time

" tab.

►  Set the date and/or time using the numeric

keypad.

►  Confirm with "

OK

".

Additional settings

You can choose:
–  To change the time zone.
–  To change the display format of the date and
time (12h/24h).
–  To activate or deactivate the summer time
management function (+1 hour).
–  To activate or deactivate GPS synchronisation
(UTC).

The system does not automatically
change between winter and summer time

(depending on the country of sale).

14/02/2022   15:33:05

27

Access

2

Electronic key with
remote control function
and built-in key

Advice

If one of the doors or the boot is still open
or if the electronic key for the Keyless

Entry and Start  system has been left inside
the vehicle, central locking will not take place.

However, if the vehicle is fitted with an alarm,

it will be activated after 45 seconds.

If the vehicle is unlocked but the doors or
boot are not subsequently opened, the

vehicle will automatically lock itself again after

about 30 seconds. If the vehicle is fitted with

an alarm, it will be reactivated automatically.

Automatic door mirror folding and

unfolding can be deactivated by a Fiat

Dealership or a qualified workshop.

As a safety measure, never leave the

vehicle, even for a short time, without

taking the Keyless Entry and Start system’s
electronic key with you.
Be aware of the risk of theft of the vehicle if

the key is present in one of the defined areas

while the vehicle is unlocked.

If a door is not properly closed (except the
right-hand door with side-hinged rear

doors):
–  when the vehicle is stationary and engine
running, this warning lamp comes on,
accompanied by a warning message for a few
seconds,
–  when the vehicle is moving (at speeds above
6 mph (10 km/h)), this warning lamp comes on,
accompanied by an audible signal and a warning
message for a few seconds.

Remote control key

This allows the central locking or unlocking of the
vehicle using the door lock or from a distance.
It also allows the vehicle to be located, the fuel

filler cap and charging flap to be opened and

closed and the engine to be started or switched

off, as well as providing protection against theft.

The remote control buttons are not active
with the ignition switched on.

Unfolding / Folding the key





►  Press this button to unfold or fold the key.

The remote control may be damaged if
you do not press the button.

Keyless Entry and Start

This allows the central locking or unlocking of the
vehicle from a distance.
It is also used to locate and start the vehicle, as
well as providing protection against theft.

Integral key

This is used to lock and unlock the vehicle when
the remote control cannot operate:

–  cell battery flat, vehicle battery discharged or

disconnected, etc.
–  vehicle located in an area with strong
electromagnetic signals.



14/02/2022   15:33:05

28

Access



►  Keep this button

1

 pulled while removing

key

2

 from the housing.

If the alarm is activated, the audible
signal triggered on opening a door with

the key (integral with the remote control) will
stop when the ignition is switched on.

Once the built-in key is ejected, always
keep it with you to be able to carry out

the corresponding back-up procedures.

"Keyless Entry and Start" on your

person





It allows the unlocking, locking and starting of the
vehicle while carrying the remote control on your
person in recognition zone "

A

".

In the ignition on (accessories) position,
with the "START/STOP" button, the

hands-free function is deactivated and it is
impossible to open the doors.
For more information on

Starting/switching

off the engine, Keyless Entry and Start

 and

in particular the "ignition on" position, refer to
the corresponding section.

Locating the vehicle

This function helps you to spot your vehicle from
a distance, with the vehicle locked:

–  The direction indicators flash for approximately

10 seconds.
–  The courtesy lamps come on.

►  Press this button.



Remote operation of lighting

If fitted to the vehicle.

A short press on this button switches on

the lighting remotely (lighting of

sidelamps, dipped beam headlamps and number
plate lamps).
A second press on the button before the end of
the timed period cancels the remote lighting.

Advice

Remote control

The remote control is a sensitive, high-

frequency device; avoid handling it in your
pocket, due to the risk of unintentionally
unlocking the vehicle.
Avoid pressing the remote control buttons
while out of range of the vehicle, due to
the risk of rendering the remote control
inoperative. It would then be necessary to
reset it.
The remote control does not work when the
key is in the ignition switch, even when the

ignition is switched off.

Anti-theft protection

Do not modify the electronic vehicle

immobiliser, as this might result in
malfunctions.
For vehicles with a key ignition switch,
remember to remove the key and turn the
steering wheel to engage the steering lock.

Locking the vehicle

Driving with the doors locked could make

it more difficult for the emergency services

to enter the passenger compartment in an
emergency.
As a safety precaution, remove the key from
the ignition or take the electronic key with you
when leaving the vehicle, even for a short
time.

14/02/2022   15:33:06

29

Access

2

Purchasing a second-hand vehicle

Have the key codes memorised by a Fiat

Dealership, to ensure that the keys in your
possession are the only ones able to start the
vehicle.

To preserve the battery charge in the
electronic key and the vehicle's battery,

the "hands-free" functions are set to
hibernation mode after 21 days without use.
To restore these functions, press one of the
remote control buttons or start the engine with
the electronic key in the reader.
For more information on starting with the
Keyless Entry and Start system, refer to the
corresponding section.

Electrical interference

The electronic key may not work if it is

close to an electronic device (e.g. mobile
telephone (switched on or on standby), laptop

computer, strong magnetic fields). If this

occurs, move the electronic key away from
the electronic device.

Accumulations (water, dust, grime, salt,

etc.) on the inner surface of the door

handle may affect detection.

If cleaning the inner surface of the door
handle using a cloth does not restore
detection, contact a Fiat Dealership or a

qualified workshop.

A sudden splash of water (stream of water,
high pressure jet washer, etc.) may be

identified by the system as the desire to open

the vehicle.

Unlocking/Complete or
selective unlocking

What is the purpose of total

or selective unlocking?









Total unlocking unlocks

all

 the vehicle’s doors

(front, side and rear).





Selective unlocking unlocks either the

cab

 doors,

or the doors of the

loading area

 (side and rear).

The separated unlocking system
between

cab

 and

loading area

 is a

security measure. This prevents access to the
part of the vehicle where the driver is not
present.

Activation/Deactivation









►  To

activateselective

 unlocking

between the

cab

 and the

loading

area

 or to

deactivate

 selective unlocking and

return to

total

 unlocking mode, switch on the

ignition and press this button for more than two
seconds.
An audible signal and, depending on equipment,

a display message, confirm that the request has

been acknowledged.

Selective unlocking between

cab

 and

loading area

 is activated by default.

14/02/2022   15:33:06

30

Access

Unlocking/Complete

unlocking

Unlocking is signalled by rapid flashing of

the direction indicators for a few

seconds.
Depending on version, the door mirrors unfold
and the alarm is deactivated.

With the key

►  To unlock the vehicle

fully

, turn the key in the

front left-hand door lock towards the front of the
vehicle.
If the vehicle has an alarm, it will not be
deactivated. Opening a door will trigger the
alarm, which can be stopped by switching the
ignition on.

With the remote control

►  Depending on equipment,

press one of these buttons to

unlock the vehicle.

Using the remote control with electric

sliding side door(s)

►  To

fully

 unlock the vehicle and open

the side door, press and hold this button

until the door has opened.

With Keyless Entry and Start on your

person

To unlock the vehicle, the remote control must be
in recognition zone

A

.

►  To unlock the vehicle

fully

, pass your hand

behind one of the door handles (front door(s),
manual sliding side door(s) or left-hand side-
hinged door) and then pull the handle to open
the corresponding door.

With electric sliding side door(s)





►  With the Keyless Entry and Start on your

person, pass your hand behind the handle
to unlock the vehicle, then pull and release
the handle. This action also causes the
corresponding door to open.

With tailgate





►  With the Keyless Entry and Start on your

person, to unlock the

vehicle

, pull the tailgate

handle and then lift it up to open it.

With an opening rear screen in the tailgate





►  With the Keyless Entry and Start on your

person, to unlock the vehicle, press the tailgate
opening rear screen unlocking control. The
screen will open slightly; then, lift it up to open it.

14/02/2022   15:33:07

31

Access

2

Selective unlocking





Unlocking is signalled by rapid flashing of

the direction indicators for a few

seconds.
Depending on version, the door mirrors unfold
and the alarm is deactivated.

With the remote control

►  To unlock the

cabin

 doors alone,

press this button

once

.

►  To unlock the side and rear doors of the

loading area

, press this button a

second time

.

If the vehicle is fitted with this function:

►  Press this button to unlock the

loading area

 only.

Using the remote control with electric

sliding side door(s)

►  To unlock the

loading area

 alone

without opening the side door, press the

relevant door button or keep the button pressed
down to open the door.

With Keyless Entry and Start on your

person





►  To unlock the

cabin

 alone, pass your hand

behind a handle of the front left or right doors,
then pull the handle to open the door.

The door locking state of the

loading

area

 remains unchanged.





►  To unlock the loading area alone, the remote

control on your person in

recognition zone



A

,

B



or

C

, pass your hand behind a handle of the front

left or right doors, then pull the handle to open
the corresponding door.

Depending on the version, the door
mirrors unfold only when the cabin is

unlocked, the alarm is deactivated.

With electric sliding side door(s)





►  With the Keyless Entry and Start on your

person, pass your hand behind the left-hand or
right-hand door handle to unlock the

loading

area

, then pull and release the handle. This

action also causes the corresponding door to
open.

With tailgate





14/02/2022   15:33:07

32

Access

►  With the Keyless Entry and Start on your

person, to unlock the

loading area

, pull the

tailgate handle and then lift it up.

Unlocking is signalled by rapid flashing of

the direction indicators for a few

seconds.

Locking

With the key

►  To lock the vehicle

fully

, turn the key in the

front left-hand door lock towards the rear of the
vehicle.
If your vehicle has an alarm, it will not be
activated.

With the remote control

►  To lock the vehicle

completely

, press

this button.

With Keyless Entry and

Start on your person

To lock the vehicle, the remote control must be in
recognition zone

A

.





►  To lock the vehicle, press the markings on

one of the door handles (front door(s), manual
sliding side door(s) or left-hand side-hinged
door).

With electric sliding side door(s)

►  With the Keyless Entry and Start on your

person, to lock the vehicle

fully

, press the

markings on one of the

front

 door handles.

With tailgate





►  With the Keyless Entry and Start on your

person, press the tailgate locking control to lock
the vehicle.

Depending on version, keeping
the locking controls depressed

closes the windows. If the control is released,
the window stops in its current position.

Ensure that no person or object might
prevent the windows from closing

properly.
Pay particular attention to children when
operating windows.

If the vehicle is not fitted with an alarm,

locking is signalled by fixed lighting of the

direction indicators for approximately two
seconds.
Depending on version, the door mirrors fold at
the same time.

Driving with the doors locked could make

it more difficult for the emergency

services to enter the passenger compartment
in an emergency.
As a safety measure, never leave the vehicle
without taking the remote control with you,
even for a short time.

Deadlocking

Deadlocking deactivates the exterior and
interior door controls, as well as the

central locking button on the dashboard.
The horn remains operational.
You must therefore never leave anyone inside
the vehicle when it is deadlocked.

With the key

►  To deadlock the vehicle, turn the key in the

front left-hand door lock towards the rear of the
vehicle.

►  Then,

within five seconds

, turn the key

towards the rear again.

14/02/2022   15:33:07

33

Access

2

With the remote control

►  To deadlock the vehicle, press this

button.

►  Then

within five seconds after locking

,

press this button again.

Depending on version, the electric door
mirrors fold at the same time.

If the vehicle is not fitted with an alarm,

deadlocking is confirmed by fixed

illumination of the direction indicators for
about two seconds.

With Keyless Entry and Start on your

person

To lock the vehicle, the remote control must be in
recognition zone

A

.





►  To lock the vehicle

fully

, press the markings

on one of the door handles (front door(s),
manual sliding side door(s) or left-hand side-
hinged door).

►  To deadlock the vehicle, press the markings

again

within five seconds.

With electric sliding side door(s)

►  With the Keyless Entry and Start on your

person, to lock the vehicle

fully

, press the

markings on one of the

front

 door handles.

►  To deadlock the vehicle, press the markings

again

within five seconds.

With tailgate





►  With the Keyless Entry and Start on your

person, press the tailgate locking control to lock
the

entire

 vehicle.

►  To deadlock the vehicle, press the control

again

within five seconds

.

If the vehicle is not fitted with an alarm,

deadlocking is signalled by fixed lighting

of the direction indicators for approximately
two seconds.

Back-up procedures

Lost keys, remote control,

electronic key

Go to a Fiat Dealership with the vehicle's

registration certificate, your personal

identification documents and if possible, the label

bearing the key code.
The Fiat Dealership will be able to retrieve the
key code and the transponder code, enabling a
new key to be ordered.

Complete unlocking/locking

of the vehicle with the key

Use this procedure in the following situations:
–  Remote control battery discharged.
–  Remote control malfunction.
–  Vehicle battery discharged.
–  Vehicle in an area subject to strong
electromagnetic interference.

In the first case, change the remote control

battery.
In the second case, reinitialise the remote
control.
Refer to the corresponding sections.

►  Insert the key into the door lock.

►  Turn the key towards the front/rear to unlock/

lock the vehicle.

►  Turn the key towards the rear again within

5 seconds to deadlock the vehicle.

If the vehicle is fitted with an alarm, it will

not be activated when locking with the

key.
If the alarm is activated, the siren sounds
when the door is opened; switch on the
ignition to stop it.

14/02/2022   15:33:07

34

Access

If the vehicle is unlocked with the key in
the lock

after locking it with the remote

control or the Keyless Entry and Start

system

,

all doors and the boot

 are

unlocked.
If the vehicle is unlocked with the key in the
lock

after locking it with the key

, only the

doors (front door and sliding side door(s)) are
unlocked. The side-hinged doors and tailgate
are not unlocked. Switching on the ignition
unlocks them.

Central locking not

functioning

Use these procedures in the following cases:
–  Central locking malfunction.
–  Battery disconnected or discharged.

In the event of a malfunction of the
central locking system, the battery must

be disconnected to ensure that the vehicle is
locked fully.

Front left-hand door

►  Insert the key into the door lock.

►  Turn the key towards the rear of the vehicle

to lock it, or towards the front to unlock it.

Front passenger door and sliding

side door

Unlocking

►  Pull the interior door opening handle.

Locking

►  Open the door.

►  For the side door, check that the child lock is

not on. Refer to the corresponding section.





Front passenger door





Sliding side door

►  Remove the black cap on the edge of the

door, using the key.

►  Insert the key in the aperture without

forcing it, then without turning it, move the latch
sideways towards the inside of the door.

►  Remove the key and refit the black cap.

►  Close the doors and check from the outside

that the vehicle is locked.

Side-hinged doors

Unlocking

►  Use the interior opening handle.

Locking

►  If fitted to your vehicle, check that the electric

child lock is not on.

►  Open the left-hand side-hinged door.





►  Insert the key into the latch aperture on the

edge of the door (without forcing it) and slide the
assembly upwards.

►  Remove the key.

►  Close the door and check from the outside

that the vehicle is locked.

Unlocking the tailgate





►  From inside the vehicle, insert a small

screwdriver into hole

A

 on the lock to unlock the

tailgate.

►  Move the latch to the left.

If the fault persists after closing again,
the tailgate will remain locked.

14/02/2022   15:33:08

35

Access

2

Changing the battery

If the battery is flat, this warning lamp

comes on, accompanied by an audible

signal and the display of a message.

Battery type: CR2032/3 volts.





►  Unclip the cover by inserting a small

screwdriver in the slot and lift the cover.

►  Remove the flat battery from its housing.

►  Put the new battery in place, respecting the

polarity. Start by inserting it into the contacts
located in the corner, then clip the cover onto
the unit.

►  Reinitialise the remote control.

For more information on

Reinitialising the

remote control

, refer to the corresponding

section.

Do not throw remote control batteries
away, as they contain metals that are

harmful to the environment. Take them to an
approved disposal point.

Reinitialising the remote

control

Following replacement of the battery or in
the event of a fault, it may be necessary to
reinitialise the remote control.

Without Keyless Entry and Start





►  Switch the ignition off.

►  Turn the key to position

2 (Ignition on)

.

►  Immediately press the closed padlock button

for a few seconds.

►  Switch off the ignition and remove the key

from the ignition switch.
The remote control is now fully operational
again.





►  Insert the mechanical key (incorporated into

the remote control) into the lock to open the
vehicle.

►  Place the electronic key against the back-up

reader on the steering column and hold it there
until the ignition is switched on.

►

With a manual gearbox,

 place the gear lever

in neutral then fully depress the clutch pedal.

►

With an automatic gearbox or drive

selector

, while in mode

P

, depress the brake

pedal.

►  Switch on the ignition by pressing the

"

START/STOP

" button.

If the fault persists after reinitialisation, contact a

Fiat Dealership or a qualified workshop without

delay.

14/02/2022   15:33:08
