84

Ease of use and comfort

►  Use a coin to unscrew the cap and replace

the battery.

Do not throw remote control batteries
away, as they contain metals that are

harmful to the environment. Take them to an
approved disposal point.

If the system is switched on using the
long-range remote control, the maximum

heating duration is around 45 min.

The ventilation is activated provided that

the battery is sufficiently charged.

The heating is activated provided that:
–  the battery charge and the fuel level are

sufficient,

–  the engine has been started since the
previous heating cycle,
–  60 minutes have elapsed between two
heating requests.

Programmable heating is supplied by the
vehicle fuel tank. Before use, make sure

that you have sufficient fuel. If the fuel tank is

on reserve, you are strongly recommended
not to programme the heating.

The additional heating must always be

switched off while refuelling to avoid any risk

of fire or explosion.

To avoid the risk of poisoning or
asphyxia, the programmable heating

must not be used, even for short periods, in a
closed environment such as a garage or
workshop which is not equipped with an
exhaust gas extraction system.

Do not park the vehicle on a flammable

surface (dry grass, dead leaves, paper, etc.)

- Risk of fire!

Glazed surfaces such as the rear screen
or windscreen can become very hot in

places.
Never put objects on these surfaces; never
touch these surfaces - Risk of burns!

Independent additional
heating

Depending on the country of sale, this is an
additional and independent system which heats
the hot water circuit of the Diesel engine to
improve comfort and to raise the temperature
of the cold engine. It improves demisting and
defrosting performance. With the engine idling
or the vehicle stationary, it is normal to notice a

high-pitched whistling and some emissions of
smoke or odour.
The temperature near the heating system must
not exceed 120°C. A higher temperature (e.g. in
a paint oven) could damage the components of
electronic circuits.
The additional heating is supplied by the
vehicle's fuel tank. Make sure that the low fuel
warning lamp is not on.

To avoid the risks of poisoning or

suffocation, the additional heating must

not be used, even for short periods, in a
closed environment such as a garage or
workshop which is not equipped with an
exhaust gas extraction system.

Do not park the vehicle on a flammable

surface (for example: dry grass, fallen

leaves, paper, etc.) - risk of fire!

Have the additional heating checked at
least once a year, at the beginning of

winter.
For maintenance and repairs, you must

only contact a Fiat Dealership or a qualified

workshop.

14/02/2022   15:33:21

85

Ease of use and comfort

3

Temperature pre-
conditioning (Electric)

This function allows you to programme the
temperature in the passenger compartment to

reach a pre-defined, non-modifiable temperature

(approx. 21°C) before you enter the vehicle, on
the days and at the times of your choice.
This function is available when the vehicle is
connected or not connected.

Programming

With Bluetooth

®

 audio system

Temperature pre-conditioning is not available
with the Bluetooth

®

 audio system.

With Connect Nav system

In the

Applications

 menu:

Press "

Car Apps

" to display the applications

home page.

Select

Temperature conditioning

.

►  Press

+

 to add a programme.

►  Select the time of entry into the vehicle and

the desired days. Press

OK

.

►  Press

ON

 to activate this programme.

The temperature pre-conditioning sequence
begins approximately 45 minutes before the
programmed time when the vehicle is connected
(20 minutes when it is not connected) and is
maintained for 10 minutes after.

You can set multiple programmes.
Each one is saved in the system.

To optimise the driving range, we recommend
starting a programme while the vehicle is
connected.

The fan noise that occurs during
temperature pre-conditioning is perfectly

normal.

Operating conditions

–  The function is only activated when the

ignition is switched off

 and the

vehicle

locked

.

–  When the vehicle is not connected, the
function is only activated if the battery charge
level is greater than 50%.
–  When the vehicle is not connected and a
recurring programme is active (e.g. from Monday
to Friday), if two temperature pre-conditioning
sequences are run without the vehicle being
used, the programme will be deactivated.

Courtesy lamp(s)

Front: comes on when one of the front or
rear doors is opened (sliding side door

and depending on equipment, left-hand
side-hinged door or tailgate).
Rear or row 2 and row 3: comes on when one of
the rear doors is opened (sliding side door and

depending on equipment, left-hand side-hinged
door or tailgate).

Always lit, ignition on.

Always off.



Front









14/02/2022   15:33:21

86

Ease of use and comfort









Rear

















Automatic switching on/off

The front courtesy lamp comes on when the key
is removed from the ignition switch.
All courtesy lamps come on when the vehicle is
unlocked, when one of the corresponding doors
is opened and when locating the vehicle using
the remote control.

They fade to off after the ignition is switched on

and when the vehicle is locked.

Take care not to allow objects to come
into contact with the courtesy lamp.

Individual reading lamp





If fitted to the vehicle, these are switched

on and off by means of a manual switch.

With the ignition on, operate the corresponding
switch.

Take care not to put anything in contact
with the courtesy lamp.

14/02/2022   15:33:22

87

Lighting and visibility

4

Lighting control stalk

Main lighting









Lamps off (ignition off)/

Daytime running lamps (engine running)

Automatic illumination of lamps/daytime

running lamps
Sidelamps only

Dipped or main beam headlamps

Headlamp dipping





►  Pull the lighting control stalk to switch

between dipped and main beam headlamps.

In lamps off and sidelamps modes, pull the

lighting control stalk to switch the main beam

headlamps on directly ("headlamp flash").

Operation of the selected lighting is

confirmed by the illumination of the

corresponding indicator lamp.

Without AUTO lighting





With AUTO lighting





Foglamps

Rear foglamp

It only works if the sidelamps are on.





►  Rotate the ring forwards/backwards to turn

it on/off.

When the lighting is switched off automatically

(with AUTO model), the foglamp and the dipped
beam headlamps will remain on.

Front foglamps/Rear foglamps

They operate with the sidelamps, dipped
or main beam headlamps on.





►  Rotate the ring forwards:

•  once to switch on the front foglamps,
•  a second time to switch on the rear

foglamps.

►  Turn in the opposite direction to switch off.

If the lighting is switched off automatically (with

AUTO model) or the dipped beam headlamps

are switched off manually, the foglamps and

sidelamps remain on.

►  Rotate the ring backwards to switch the

foglamps off; the sidelamps will then switch off.

14/02/2022   15:33:22

88

Lighting and visibility

Switching on the foglamps is prohibited
in clear weather or in rain, both day and

night. In these situations, the power of their
beams may dazzle other drivers. They must
only be used in fog or falling snow (rules may
vary depending on country).

Do not forget to switch off the foglamps when

they are no longer necessary.

Switching on the lamps after

switching off the ignition

To reactivate the lighting control, rotate the
ring to the "

0

" position - lamps off, then to the

desired position.
If the driver's door is opened, a temporary
audible signal warns the driver that the lamps
are on.

They will go off automatically after a period

of time that depends on the level of charge in
the battery (entering energy economy mode).

Switching off of the lighting when the

ignition is switched off

When the ignition is switched off, all of the

lamps turn off immediately, except for the

dipped beam headlamps if automatic guide-
me-home lighting is activated.

In some weather conditions (e.g. low
temperature or humidity), misting on the

internal surface of the glass of the headlamps
and rear lamps is normal, and will disappear

after the lamps have been on for a few
minutes.

Travelling abroad

If planning to use your vehicle in a

country that drives on the other side of the
road, the dipped beam headlamps must be
adjusted to avoid dazzling oncoming drivers.

Contact a Fiat Dealership or a qualified

workshop.

Direction indicators





►  Left or right: lower or raise the lighting control

stalk, beyond the point of resistance.

If you keep the direction indicators on for
more than 20 seconds, the volume of the

audible signal will increase if the speed is
above 50 mph (80 km/h).

Three flashes

►  Press briefly upwards or downwards, without

going beyond the point of resistance; the

direction indicators will flash 3 times.

Daytime running lamps/

Sidelamps





If the vehicle is so equipped, they come on
automatically when the engine is started, when
the lighting control stalk is in position "

0

" or

"

AUTO

".

Automatic headlamp

illumination

When a low level of ambient light is detected
by a sunshine sensor, the number plate
lamps, sidelamps and dipped beam headlamps
are switched on automatically, without any action
on the part of the driver. They can also come

14/02/2022   15:33:23

89

Lighting and visibility

4

on if rain is detected, at the same time as the
automatic rain sensitive wipers.

As soon as the brightness returns to a sufficient

level or after the windscreen wipers are switched

off, the lamps are switched off automatically.

Malfunction

In the event of a malfunction of the rain/sunshine
sensor, the vehicle’s lamps come on and this
warning lamp is displayed on the instrument
panel, accompanied by an audible signal and/or
the display of a message.
Have it checked by a Fiat Dealership or a

qualified workshop.

Do not cover the rain/sunshine sensor
located at the top centre of the

windscreen behind the interior rear view
mirror; the associated functions would no
longer be controlled.

In fog or snow, the rain/sunshine sensor

may detect sufficient light. For this

reason, the lighting will not come on
automatically.

The inner surface of the windscreen may

become misted up and affect the proper

operation of the rain/sunshine sensor.
In humid and cold weather, demist the
windscreen regularly.

Guide-me-home and

welcome lighting

Guide-me-home lighting

Manual





►  With the ignition off, pull the lighting control

stalk toward you ("headlamp flash") to activate/

deactivate the function.

Manual guide-me-home lighting goes off

automatically after a period of time.

Automatic

With the "Automatic illumination of lamps"
function activated (lighting control stalk in the
"

AUTO

" position) and when the light is poor, the

dipped beam headlamps come on automatically

when the ignition is switched off.

With the ring in the "

AUTO

" position and when

the light is poor, the dipped beam headlamps
come on automatically when the ignition is

switched off.

With audio system or touch screen

The activation, deactivation and
duration of guide-me-home lighting

are set in the vehicle configuration menu.

Exterior welcome lighting

The remote operation of the lighting makes your
approach to the vehicle easier in poor light. It
is activated when the lighting control is in the
"

AUTO

" position and the level of light detected

by the sunshine sensor is low.

Switching on

Press this button on the remote control or
on one of the front door handles with the

"Keyless Entry and Start" system.
The dipped beam headlamps and sidelamps
come on; your vehicle is also unlocked.

Switching off

The exterior welcome lighting switches off

automatically after a set time, when the ignition
is switched on or on locking the vehicle.

Programming

With audio system or touch screen

The activation, deactivation and
duration of the welcome lighting

can be set via the vehicle configuration menu.

14/02/2022   15:33:23

90

Lighting and visibility

Automatic headlamp

dipping

For more information, refer to the

General recommendations for

automatic lighting systems

.

With the ring of the lighting control stalk in the
"

AUTO

" position and the function activated on

the touch screen, this system automatically
switches between dipped and main beam

headlamps, according to lighting and traffic

conditions, using a camera located at the top of
the windscreen.





This system is a driving aid.
The driver remains responsible for

the vehicle's lighting, its correct use in the

prevailing light, visibility and traffic conditions,

and for compliance with driving and vehicle
regulations.

The system becomes operational when
the vehicle exceeds 16 mph (25 km/h).

When the speed falls below 9 mph (15 km/h),

the function is no longer operational.

Activation/Deactivation

With audio system









►  To activate or deactivate the system, press

this button.
The indicator lamp in the button is

on

 when the

function is

activated

.

With touch screen

The settings are adjusted via the vehicle

configuration menu.

►  Then put the lighting control stalk ring in the

"AUTO" or "Dipped/main beam position".

Pause

If the situation requires a change of headlamp
beam, the driver can take over at any time.

►  A "headlamp flash" pauses the

function and the lighting system switches

to "automatic illumination of lamps" mode:
–  If the "AUTO" and "Dipped beam" indicator
lamps were on, the system changes to main
beam.
–  If the "AUTO" and "Main beam"
indicator lamps were on, the system changes to
dipped beam.

►  To reactivate the function, once again switch

the headlamps manually between dipped and
main beam.

Flashing the headlamps does not
deactivate the system.

The state of the system is stored when the

ignition is switched off.

The system may be disrupted or not work
correctly:

–  When visibility conditions are poor
(snowfall, heavy rain, etc.).
–  If the windscreen in front of the camera is
dirty, misted or obscured (for example, by a
sticker).

–  If the vehicle is facing highly reflective

signs.
When the system detects thick fog, it
temporarily deactivates the function.
The system is not able to detect:
–  Road users that do not have their own
lighting, such as pedestrians.

14/02/2022   15:33:23

91

Lighting and visibility

4

–  Vehicles whose lighting is obscured (for
example, vehicles driving behind a safety
barrier on a motorway).
–  Vehicles at the top or bottom of a steep
slope, on winding roads, on crossroads.

Clean the windscreen regularly,
particularly the area in front of the

camera.
The internal surface of the windscreen can
also become misted around the camera.
In humid and cold weather, demist the
windscreen regularly.
Do not allow snow to accumulate on the
bonnet or roof of the vehicle as this could
obstruct the detection camera.

Headlamp beam height
adjustment





To avoid inconvenience to other road users,
the height of the halogen headlamps must be
adjusted according to the load in the vehicle.





0

Empty (initial setting)

1

Partial load

2

Medium load

3

Maximum authorised load

4 5 6

Not used





0

1 or 2 people in the front seats (initial
setting)

1

5 people

2

6 to 9 people

3

Driver + maximum authorised load

4 5 6

Not used

Interior ambient lighting





The dimmed passenger compartment lighting
improves visibility inside the vehicle when the
light is poor.

Switching on

At night, the front roof lighting and panoramic

roof lighting (if fitted to your vehicle) comes on

automatically when the sidelamps are switched
on.

The ambient lighting switches off automatically

when the sidelamps are switched off.

Programming

With audio system or touch screen

The activation, deactivation and
the choice of brightness of the

ambience lighting can be set via the vehicle

configuration menu.

Wiper control stalk

Before operating the wipers in wintry
conditions, clear any snow, ice or frost

from the windscreen and around the wiper
arms and blades.

Do not operate the wipers on a dry
windscreen. In extremely hot or cold

weather, check that the wiper blades are not
stuck to the windscreen before operating the
wipers.

After using an automatic car wash, you

may temporarily notice abnormal noises

and poorer wiping performance.  You do not
need to replace the wiper blades.

14/02/2022   15:33:24

92

Lighting and visibility

Without AUTO wiping









With AUTO wiping





Windscreen wipers

►  To select the wiping speed: raise or lower the

stalk to the desired position.

Fast wiping (heavy rain)

Normal wiping (moderate rain)

Intermittent wiping (proportional to the
vehicle’s speed)

Switching off



Single wipe (press down and release).

or

Automatic wiping

Refer to the corresponding section.

After the ignition has been switched off,

the wipers may move slightly at the foot

of the windscreen.

If the ignition has been switched off with

the windscreen wipers active, you must

operate the control stalk again to reactivate
wiping when the ignition is switched on again

(unless the ignition was off for less than

a minute).

Windscreen wash

►  Pull the wiper control stalk towards you and

hold.
The screenwash then the windscreen wipers
operate for a pre-determined time.

With automatic air conditioning, any
action on the screenwash control results

in temporary closure of the air intake to
protect the passenger compartment from any
odour.

To avoid damaging the wiper blades, do
not operate the screenwash if the

screenwash reservoir is empty.
Only operate the screenwash if there is no

risk of the fluid freezing on the windscreen

and hindering visibility. During the winter
period, use "very cold climate" rated products.
Never top up with water.

Low

screenwash fluid level

When the low level of the reservoir is
reached, this warning lamp lights up on

the instrument panel, accompanied by an
audible signal and a message.
It comes on when the ignition is switched on,
or every time the stalk is operated, until the

reservoir is refilled.

Refill the screenwash reservoir (or have it

refilled) the next time you stop.

Automatic windscreen

wipers

In

AUTO

 mode, the windscreen wipers operate

automatically and adapt to the intensity of the
rainfall.
Detection is via a rain/brightness sensor, located
at the top centre of the windscreen behind the
rear view mirror.

Switching on





14/02/2022   15:33:24

93

Lighting and visibility

4

►  Give a short downwards push to the control

stalk.

A wiping cycle confirms that the instruction has

been accepted.

This indicator lamp lights up on the
instrument panel, accompanied by a

message.

Switching off

►  Give the control stalk another brief push

downwards or set the control stalk to another
position (

Int

,

1

 or

2

).

This indicator lamp goes off on the

instrument panel, accompanied by a

message.

If the ignition has been off for more than

one minute, the automatic wipers must

be reactivated by pushing the control stalk
downwards.

Malfunction

If a fault occurs with the automatic wipers, the
wipers operate in intermittent mode.
Have it checked by a Fiat Dealership or a

qualified workshop.

Do not cover the rain/sunshine sensor.
When using an automatic car wash,

switch off the automatic wipers and the

ignition.

In winter, wait until the windscreen is
completely clear of ice before activating the
automatic wipers.

Rear wiper





Off.



Intermittent wipe.

Wash-wipe (set duration).

Reverse gear

When reverse gear is engaged, if the windscreen
wipers are operating, the rear wiper will come
into operation automatically (activated by
default).

Activation/Deactivation

With audio system or touch screen

The system's settings are adjusted

via the vehicle configuration menu.

This function is activated by default.

In the event of accumulation of snow or

hard frost or if a bicycle carrier is fitted to

the tailgate, deactivate the automatic rear

wiper via the vehicle configuration menu.

Rear screenwash

►  Turn the ring as far as it will go and hold it in

position.
The screenwash and the wiper operate for as
long as the ring remains turned.

A final wiping cycle is performed when screen

washing ends.

Special position of the

windscreen wipers

This maintenance position is used while cleaning
or replacing the wiper blades. It can also be
useful, in wintry weather (ice, snow), to release
the wiper blades from the windscreen.

To maintain the effectiveness of the flat

wiper blades, it is advisable to:

–  handle them with care.
–  clean them regularly using soapy water.
–  avoid using them to hold cardboard on the
windscreen.

–  replace them at the first signs of wear.

14/02/2022   15:33:25

94

Lighting and visibility

Before removing a windscreen wiper blade





Operating the wiper control stalk immediately

after switching off the ignition will place the wiper

blades in a vertical position.

►  Proceed with the desired operation or the

replacement of the wiper blades.

After refitting a windscreen wiper blade

►  To return the wiper blades to their initial

position after the operation, switch on the ignition
and operate the wiper control stalk.

Changing a wiper blade

Removing/Refitting at the front





►  Carry out these wiper blade replacement

operations from the driver's side.

►  Starting with the wiper blade farthest from

you, hold each arm by the rigid section and raise
it as far as possible.

Do not touch the wiper blades - risk of
irreparable deformation.

Do not release them while moving them. Risk
of damaging the windscreen!

►  Clean the windscreen using screenwash

fluid.

Do not apply "Rain X" type water-
repellent products.

►  Unclip the worn wiper blade closest to you

and remove it.

►  Install the new wiper blade and clip it to the

arm.

►  Repeat the procedure for the other wiper

blade.

►  Starting with the wiper blade closest to you,

once again hold each arm by the rigid section,
then guide it carefully onto the windscreen.

Removing/refitting at the rear

►  Hold the arm by the rigid section and raise it

as far as possible.

►  Clean the rear screen using screenwash

fluid.

►  Unclip the worn wiper blade and remove it.

►  Install the new wiper blade and clip it to the

arm.

►  Once again hold the arm by the rigid section,

then guide it carefully onto the rear screen.

14/02/2022   15:33:25

95

Safety

5

General safety
recommendations

Do not remove the labels attached in

different places on your vehicle. They

include safety warnings as well as

identification information for the vehicle.

For all work on your vehicle, use a

qualified workshop that has the technical

information, skills and equipment required, all
of which a Fiat Dealership is able to provide.

Depending on country regulations,
certain safety equipment may be

mandatory: high visibility safety vests,
warning triangles, breathalysers, spare bulbs,

spare fuses, fire extinguisher, first aid kit, mud

flaps at the rear of the vehicle, etc.

Installing electrical accessories:

–  The fitting of electrical equipment

or accessories not approved by Fiat may
cause excessive current consumption and
faults and failures with the electrical system
of your vehicle. Contact a Fiat Dealership
for information on the range of approved
accessories.
–  As a safety measure, access to the
diagnostic socket, used for the vehicle's
electronic systems, is reserved strictly for

Fiat Dealerships or qualified workshops,

equipped with the special tools required (risk
of malfunctions of the vehicle's electronic
systems that could cause breakdowns or
serious accidents). The Manufacturer cannot
be held responsible if this advice is not
followed.

–  Any modification or adaptation not

intended or authorised by Fiat or carried out
without meeting the technical requirements

defined by the Manufacturer will result in the

suspension of the commercial warranty.

Installation of accessory radio

communication transmitters

Before installing a radio communication
transmitter with an external aerial, you must
without fail contact a Fiat Dealership for the

specification of transmitters which can be

fitted (frequency, maximum power, aerial

position, specific installation requirements),

in line with the Vehicle Electromagnetic
Compatibility Directive (2004/104/EC).

Declarations of conformity for radio

equipment

The relevant certificates are available on the

brand website:

http://aftersales.fiat.com/elum/

Changes/Alterations to the

car

Warning

Any change or alteration of the car might

seriously affect its safety and road grip, thus

causing accidents, in which the occupants could
even be fatally injured.

Accessories purchased by the owner

If after buying the car, you decide to install
electrical accessories that require a permanent
electrical supply (e.g. radio, satellite anti-
theft system, etc.) or accessories that in any
case burden the electrical supply, contact a
Fiat Dealership, whose personnel will check
whether the electrical system of the car is able to
withstand the load required, or whether it needs
to be integrated with a more powerful battery.

Take care when fitting additional spoilers,

alloy wheel rims or non-standard wheel

hubs: they could reduce the ventilation of the

brakes and affect efficiency under sharp,

repeated braking or on long descents.

Make sure that nothing obstructs the pedal
stroke (mats, etc.).

Installing electrical/Electronic devices

Electrical and electronic devices installed after
buying the car in the context of after-sales
service must carry the following label:



14/02/2022   15:33:25

96

Safety



FCA Italy S.p.A. authorises the installation of
transceivers provided that installation is carried
out at a specialised centre, in a workmanlike
fashion and in compliance with manufacturer's

specifications.

Traffic police may not allow the car on

the road if devices have been installed

which modify the features of the car. This may
also cause invalidation of warranty in relation
to faults caused by the change either directly
or indirectly related to it.

FCA Italy S.p.A. shall not be liable for damage
caused by the installation of accessories either
not supplied or recommended by FCA Italy
S.p.A. and/or not installed in compliance with the
provided instructions.

Radio transmitters and mobile phones

Radio transmitter equipment (car mobile phones,
CB radios, amateur radio etc.) cannot be
used inside the car unless a separate aerial is
mounted on the roof.
Transmission and reception of these devices

may be affected by the shielding effect of the car

body. As far as the use of EC-approved mobile
phones is concerned (GSM, GPRS, UMTS,
LTE), follow the usage instructions provided by
the mobile phone Manufacturer.

The use of these devices inside the
passenger compartment (without an

external aerial) may cause the electrical
systems to malfunction. This could
compromise the safety of the car in addition
to constituting a potential hazard for
passengers' health.
If mobile phones/laptops/smartphones/
tablets are inside the car and/or close to the
electronic key, a reduced performance of the
Passive Entry/Keyless Entry and Start system
may occur.

Hazard warning lamps









►  Pressing this red button causes all the

direction indicators to flash.

They can work with the ignition switched off.

Automatic operation of

hazard warning lamps

When braking in an emergency, depending on
the rate of deceleration, the hazard warning

lamps come on automatically. They switch off

automatically when you next accelerate.

They can be switched off by pressing the button.

Emergency or assistance
call









1.

Localised Emergency Call

2.

Localised Assistance Call

eCall (SOS)

Your vehicle may be fitted with the eCall (SOS)

system either as standard or as an option.
The eCall (SOS) system provides direct access
to the emergency services and is built directly
into the vehicle.
According to the country of sale, the eCall (SOS)
system corresponds to the systems PE112,

ERAGLONASS, 999, etc.

The eCall (SOS) system is activated by default.

►  In an emergency, press button

1

 for more

than 2 seconds.

14/02/2022   15:33:26

97

Safety

5

The lit indicator lamp and a voice message

confirm that the call has been made to the

emergency services*.
The eCall (SOS) system immediately locates
your vehicle and puts you in contact with the
appropriate emergency services**.

►  Pressing again immediately cancels the

request.

The indicator lamp flashes while the vehicle

data is being sent, and then remains lit when
communication is established.

If an impact is detected by the airbag
control unit, an emergency call is made

automatically, irrespective of the deployment
of any airbags.

This system is a public service and is
free of charge.

Operation of the system

–  Upon switching on the ignition, the indicator
lamp lights up red, then green, and then goes
out: the system is operating correctly.

–  The indicator lamp flashes red: replace the

back-up battery.

* In accordance with the general conditions of use of the service, available from dealers and subject to technological and technical limitations.
** Depending on the geographic coverage of the "eCall (SOS)" and "ASSISTANCE" systems.
The list of countries covered and the telematic services provided is available from dealers or on the website for your country.

–  The indicator lamp is fixed red: system

malfunction. The emergency and assistance call
services may not work.
–  If the indicator lamp does not come on when
the ignition is switched on, this also means that
there is a system malfunction.

If the problem persists, contact a qualified

workshop as soon as possible.

A system fault does not prevent the

vehicle from being driven.

Data processing

All processing of personal information

by the "Localised Emergency Call" system
(PE112) complies with the framework for
protection of personal information established

by Regulation 2016/679 (GDPR) and

Directive 2002/58/EC of the European
Parliament and the Council, and in particular,
seeks to protect the vital interests of the
data subject, in accordance with Article 6.1,

paragraph d) of Regulation 2016/679.

Personal information processing is strictly
limited to the management of the "Localised
Emergency Call" system used with the “112”
European single emergency call number.
The "Localised Emergency Call" system is
able to collect and process only the following

data relating to the vehicle: chassis number,
type (passenger vehicle or light commercial
vehicle), fuel type or power source, most
recent three locations and direction of travel,

and a timestamped log file recording the

automatic activation of the system.
The recipients of the processed data are the
emergency call handling centres designated
by the relevant national authorities in the
territory in which they are located, enabling
priority reception and handling of calls to the
“112” emergency number.

Data storage

Data contained in the system’s memory

is not accessible from outside the system until
a call is made. The system is not traceable
and is not continuously monitored in its
normal operating mode.
The data in the system's internal memory is
automatically and continuously erased. Only
the vehicle’s three most recent locations are
stored.
When an emergency call is triggered, the data
log is stored for no more than 13 hours.

14/02/2022   15:33:26

98

Safety

Access to data

You have the right to access the data

and, if necessary, submit a request to
rectify, erase or restrict the processing of
any personal information not processed in
accordance with the provisions of Regulation

2016/679 (GDPR). Third parties to which data

has been communicated shall be notified of

any rectification, erasure or restriction carried

out in accordance with the aforementioned
Directive, unless doing so would be

impossible or require a disproportionate effort.

You also have the right to lodge a complaint
with the relevant data protection authority.

Localised Assistance Call

►  If the vehicle breaks down, press button

2



for more than 2 seconds to request assistance

(confirmed by a voice message*).

►  Pressing again immediately cancels the

request.

Privacy mode allows you to manage the
level of sharing (data and/or location)

between your vehicle and Fiat.

It can be configured in the

Settings

 touch

screen menu.

* Depending on the geographic coverage of "Localised Emergency Call", "Localised Assistance Call" and the official national language chosen by the

owner of the vehicle.
The list of countries covered and the telematic services provided is available from dealers or on the website for your country.

By default, depending on equipment,
deactivate/reactivate geolocation by
simultaneously pressing the 2 buttons, then

press the "ASSISTANCE" button to confirm.

If you purchased your vehicle outside the
Fiat Dealership network, we invite you to

have a dealer check the configuration of

these services and, if desired, modify them to
suit your wishes. In a multilingual country,

configuration is possible in the official national

language of your choice.

For technical reasons, in particular to
improve the quality of telematic services

for customers, the Manufacturer reserves the
right to carry out updates to the vehicle's
on-board telematic system at any time.

If you benefit from the Fiat Connect Box

offer with the SOS and Assistance Pack

included, there are additional services
available to you in your personal space, via
the website for your country.
For information about the SOS and
Assistance Pack, please refer to the general
conditions for these services.

Horn





►  Press the central part of the steering wheel.

Pedestrian horn (Electric)

This system alerts pedestrians that the vehicle is
approaching.
The pedestrian horn operates once the vehicle

is moving and at speeds of up to 19 mph

(30 km/h), in forward or reverse gear.
This function cannot be deactivated.

Malfunction

In the event of a malfunction, this warning
lamp lights up on the instrument panel.

Have it checked by a Fiat Dealership or a

qualified workshop.

14/02/2022   15:33:26

99

Safety

5

Electronic stability control
(ESC)

The electronic stability control programme
includes the following systems:
–  Anti-lock braking system (ABS) and Electronic
brake force distribution (EBFD).
–  Emergency braking assistance (EBA).
–  Anti-slip regulation (ASR).
–  Dynamic stability control (DSC).
–  Intelligent traction control.
–  Trailer stability assist (TSA).

Anti-lock braking system

(ABS)/Electronic brake force

distribution (EBFD)

These systems enhance the vehicle’s stability
and handling during braking, and enable greater
control while cornering, particularly on poor or
slippery road surfaces.
ABS prevents wheel locking in the event of
emergency braking.
Electronic brake force distribution (EBFD)
manages overall braking pressure on each
individual wheel.

►

When braking in an emergency, depress

the pedal very firmly and maintain this

pressure.

Normal operation of the ABS may make
itself felt by slight vibrations of the brake

pedal.

The fixed illumination of this warning lamp

signals that there is a fault with the ABS.

The vehicle retains conventional braking. Drive
carefully at a moderate speed.
Have it checked by a Fiat Dealership or a

qualified workshop.

This warning lamp, when lit together with
the

STOP

 and ABS warning lamps,

accompanied by a message and an audible
signal, indicates an EBFD malfunction.

You must stop the vehicle.

Stop as soon as it is safe to do so and switch off

the ignition.

Contact a Fiat Dealership or a qualified

workshop.

When changing wheels (tyres and rims),
ensure that these are approved for your

vehicle.

After an impact

Have it checked by a Fiat Dealership or a

qualified workshop.

Emergency braking

assistance (EBA)

In an emergency, this system enables you
to reach the optimum braking pressure more
quickly and therefore reduce the stopping
distance.
It is triggered in relation to the speed at which
the brake pedal is pressed. This is felt by a

reduction in the resistance of the pedal and an

increase in braking efficiency.

Anti-slip regulation (ASR)/

Dynamic stability control

(DSC)

Anti-slip regulation (or traction control) optimises

traction by using engine braking and by applying
the brakes on the driving wheels to avoid one
or more wheels spinning. It also enhances the
vehicle's directional stability.

If there is a difference between the vehicle’s

trajectory and the path desired by the driver, the
dynamic stability control system automatically
uses engine braking and the brakes on one or
more wheels to return the vehicle to the desired
path, within the limits of the laws of physics.
These systems are activated automatically every
time the vehicle is started.

These systems are activated in the event
of a problem with grip or trajectory

(confirmed by this warning lamp flashing on the

instrument panel).

Deactivation/Reactivation

In exceptional conditions (moving a vehicle that
is bogged down in mud, stuck in snow, on loose
soil, etc.), it may prove useful to deactivate the
DSC/ASR systems, so that the wheels can move
freely and regain grip.
However, it is recommended that the systems be
reactivated as soon as possible.

14/02/2022   15:33:26
