116

Safety

U:

Seat position suitable for the installation of
a child seat secured using the seat belt and
universally approved for "rearward facing"
and/or "forward facing" use.

UF:

Seat position suitable for the installation a
child seat secured using the seat belt and
universally approved for "forward facing"
use.

X:

Seat position not suitable for the installation

of a child seat for the specified weight group.

(a)

Universal child seat: child seat that can be
installed in all vehicles using the seat belt.

(b)

Group 0: from birth to 10 kg. Carrycots and
"car" infant carriers cannot be installed on
the front passenger seat(s) or the seats in
row 3.

(c)

Refer to the current legislation in the country
in which you are driving before placing a
child in this seat position.

(d)

To install a "rearward facing" or "forward
facing" child seat on a rear seat, move the
seats in front of it forward, then straighten

their backrests to allow sufficient room for

the child seat and the child's legs.

(e)

The seat can be installed centrally in the
vehicle; it then prevents the use of the outer
seats.

(f)

When a "rearward facing" child seat is
installed on the front passenger seat, the
front passenger airbag must be deactivated.
Otherwise, the child risks being severely
injured or killed if the airbag is deployed.

"ISOFIX" mountings and
i-Size









Combi

,

Business

,

Feel





Shine

,

Business Lounge





The vehicle has been approved in accordance
with the latest ISOFIX and i-Size regulations.

If fitted to the vehicle, approved ISOFIX and

i-Size fixings can be identified by the labels

attached to them.
There are three rings for each seat:
–  Two front rings

A

, located between the vehicle

seat backrest and cushion, indicated by an
"ISOFIX" or "i-Size" marking,

–  If fitted to your vehicle, a rear ring

B

, called a

Top Tether, is located behind the vehicle's seat
and is used to secure the upper strap and is
indicated by a "Top Tether" marking.
The Top Tether secures the upper strap of child

seats fitted with them. In case of frontal impact,

this device limits the extent to which the child
seat can tilt forward.

14/02/2022   15:33:30

117

Safety

5

This ISOFIX and i-Size mounting system

provides fast, reliable and safe fitting of a child

seat inside the vehicle.

ISOFIX and i-Size child seats are fitted with two

latches which are secured to the two front rings

A

.

Some child seats also have an upper strap which
is attached to rear ring

B

.

To secure the child seat to the Top Tether:
–  remove and stow the head restraint before

installing a child seat on this seat (refit it once

the child seat has been removed),
–  pass the strap of the child seat over the top
of the seat backrest, centring it between the
openings for the head restraint rods,
–  attach the hook of the upper strap to rear ring

B

,

–  tighten the upper strap.

Incorrect installation of a child seat in a
vehicle can compromise a child's safety

in the event of an accident.

Strictly follow the fitting instructions provided

in the installation guide supplied with the child
seat.

For information on the various options for
installing ISOFIX child seats in your

vehicle, refer to the summary table.

Recommended ISOFIX child

seats

Also consult the user guide from the child

seat’s manufacturer to find out how to

install and remove the seat.

"RÖMER Baby-Safe and its ISOFIX base"

(size category:

E

)

Group 0+: from birth to 13 kg





Installed "rearward facing" using an ISOFIX

base which is attached to rings

A

.

The base has a support leg, height-

adjustable, which rests on the vehicle's floor.

This child seat can also be secured with a

seat belt. In this case, only the shell is used

and attached to the vehicle seat using the

three-point seat belt.

"

RÖMER Duo Plus ISOFIX

"

(size category:

B1

)

Group 1: from 9 to 18 kg





Suitable for forward-facing installation only.

Attached to rings

A

 and ring

B

, referred to as

TOP TETHER, using an upper strap.

Three seat body angles: sitting, reclining,

lying down.

This child seat can also be used in seat

positions not equipped with ISOFIX

mountings. In this case, it must be secured to
the vehicle's seat by the three-point seat belt.
Adjust the front seat of the vehicle so that the

child's feet do not touch the backrest.

14/02/2022   15:33:30

118

Safety

Locations

for

ISOFIX child seats

In accordance with European regulations, this table indicates the options for installing ISOFIX child seats on vehicle seats fitted with ISOFIX mountings.

In the case of universal and semi-universal ISOFIX child seats, the ISOFIX size category, determined by a letter from

A

 to

G

, is indicated on the child seat

next to the ISOFIX logo.





Weight of the child

/indicative age

Under 10 kg

(group 0)

Up to about 6

months old

Under 10 kg

(group 0)

Under 13 kg

(group 0+)

Up to about 1 year old

From 9 to 18 kg (group 1)

From about 1 to 3 years old

Type of ISOFIX child seat

Carrycot

 (1)

rearward facing

rearward

facing

forward facing

F

G

C

D

E

C

D

A

B

B1

B2

B3

ISOFIX size category









Individual

passenger seat or
2-seat bench seat

with passenger

airbag deactivated
"

OFF

" or activated

"

ON

"

Not ISOFIX

14/02/2022   15:33:30

119

Safety

5





Weight of the child

/indicative age

Under 10 kg

(group 0)

Up to about 6

months old

Under 10 kg

(group 0)

Under 13 kg

(group 0+)

Up to about 1 year old

From 9 to 18 kg (group 1)

From about 1 to 3 years old

Type of ISOFIX child seat

Carrycot

 (1)

rearward facing

rearward

facing

forward facing

F

G

C

D

E

C

D

A

B

B1

B2

B3

Row 2 with 2-seat bench seat in row

1





Outer seats

X

IUF

IUF

*

X

Centre seat

Not ISOFIX

Row 2 with individual seats in row 1





Outer seats

IL

IL

 (6)

IL

IL

 (6)

IL

IUF

X

Centre seat

Not ISOFIX

* Fixed bench seat only

14/02/2022   15:33:30

120

Safety

Combi





Weight of the child

/indicative age

Under 10 kg

(group 0)

Up to about 6

months old

Under 10 kg

(group 0)

Under 13 kg

(group 0+)

Up to about 1 year old

From 9 to 18 kg (group 1)

From about 1 to 3 years old

Type of ISOFIX child seat

Carrycot

 (1)

rearward facing

rearward

facing

forward facing

ISOFIX size category

F

G

C

D

E

C

D

A

B

B1

B2

B3

Row 1 (a)





Individual

passenger seat or
2-seat bench seat

with passenger

airbag deactivated
"

OFF

" or activated

"

ON

"

Not ISOFIX

Row 2





Outer seats and

centre seat (b)

X

IL

 (3)

IL

 (2)

IL

IL

 (2)

IUF, IL

14/02/2022   15:33:30

121

Safety

5

Combi





Weight of the child

/indicative age

Under 10 kg

(group 0)

Up to about 6

months old

Under 10 kg

(group 0)

Under 13 kg

(group 0+)

Up to about 1 year old

From 9 to 18 kg (group 1)

From about 1 to 3 years old

Type of ISOFIX child seat

Carrycot

 (1)

rearward facing

rearward

facing

forward facing

ISOFIX size category

F

G

C

D

E

C

D

A

B

B1

B2

B3

Row 3





Fixed one-piece

bench seat, outer

seats and centre

seat (b)

X

IUF, IL

X





Seat and fixed

rear bench seat,

outer seats and

centre seat (b)

X

IUF, IL

X

14/02/2022   15:33:31

122

Safety

Business





Weight of the child

/indicative age

Under 10 kg

(group 0)

Up to about 6

months old

Under 10 kg

(group 0)

Under 13 kg

(group 0+)

Up to about 1 year old

From 9 to 18 kg (group 1)

From about 1 to 3 years old

Type of ISOFIX child seat

Carrycot

 (1)

rearward facing

rearward

facing

forward facing

ISOFIX size category

F

G

C

D

E

C

D

A

B

B1

B2

B3

Row 1 (a)









Individual

passenger seat or
2-seat bench seat

with passenger

airbag deactivated
"

OFF

" or activated

"

ON

"

Not ISOFIX

Row 2





Rear seats

X

IL



(1-3)

IL

 (2)

IL

IL

 (2)

IUF, IL

14/02/2022   15:33:31

123

Safety

5

Business





Weight of the child

/indicative age

Under 10 kg

(group 0)

Up to about 6

months old

Under 10 kg

(group 0)

Under 13 kg

(group 0+)

Up to about 1 year old

From 9 to 18 kg (group 1)

From about 1 to 3 years old

Type of ISOFIX child seat

Carrycot

 (1)

rearward facing

rearward

facing

forward facing

ISOFIX size category

F

G

C

D

E

C

D

A

B

B1

B2

B3

Row 3





Fixed one-piece

bench seat, rear

seats

X

IUF, IL

X





Seat and fixed

rear bench seat,

rear seats

X

IUF, IL

X

14/02/2022   15:33:31

124

Safety

Feel





Weight of the child

/indicative age

Under 10 kg

(group 0)

Up to about 6

months old

Under 10 kg

(group 0)

Under 13 kg

(group 0+)

Up to about 1 year old

From 9 to 18 kg (group 1)

From about 1 to 3 years old

Type of ISOFIX child seat

Carrycot

 (1)

rearward facing

rearward

facing

forward facing

ISOFIX size category

F

G

C

D

E

C

D

A

B

B1

B2

B3

Row 1 (a)





Passenger seat

with passenger

airbag deactivated
"

OFF

" or activated

"

ON

"

Not ISOFIX

Row 2





Rear seats

IL

IUF, IL

Row 3





Rear seats

IL

 (1-4)

X

IL

 (4)

X

IL

 (4)

IUF, IL

X

14/02/2022   15:33:31

125

Safety

5

Shine

,

Business Lounge





Weight of the child

/indicative age

Under 10 kg

(group 0)

Up to about 6

months old

Under 10 kg

(group 0)

Under 13 kg

(group 0+)

Up to about 1 year old

From 9 to 18 kg (group 1)

From about 1 to 3 years old

Type of ISOFIX child seat

Carrycot

 (1)

rearward facing

rearward

facing

forward facing

ISOFIX size category

F

G

C

D

E

C

D

A

B

B1

B2

B3

Row 1 (a)





Passenger seat

with passenger

airbag deactivated
"

OFF

" or activated

"

ON

"

Not ISOFIX

Row 2





Seat behind driver
or front passenger

X

IL

 (5)

IL

IL

 (5)

IL

IUF, IL

IUF

*

, IL





Centre seat (b)

X

IL

 (5)

IL

IL

 (5)

IL

IUF, IL

* Except short (XS) vehicle version.

14/02/2022   15:33:31

126

Safety

Shine

,

Business Lounge





Weight of the child

/indicative age

Under 10 kg

(group 0)

Up to about 6

months old

Under 10 kg

(group 0)

Under 13 kg

(group 0+)

Up to about 1 year old

From 9 to 18 kg (group 1)

From about 1 to 3 years old

Type of ISOFIX child seat

Carrycot

 (1)

rearward facing

rearward

facing

forward facing

ISOFIX size category

F

G

C

D

E

C

D

A

B

B1

B2

B3





Rear seats

IL

 (1-5)

IL

IL

IUF, IL

Row 3





Outer seats

X

IL

 (4)

IL

IL

 (4)

IUF, IL





Centre seat (b)

X

IL

 (4)

IL

IL

 (4)

IUF, IL





Rear seats

IL

 (1-4)

X

IL

 (4)

X

IL

 (4)

IUF, IL

X

14/02/2022   15:33:31

127

Safety

5

IUF:

Seat position suitable for the installation of
an

I

sofix

U

niversal seat, "

F

orward facing",

secured using the upper strap.

IL:

Seat position suitable for the installation
of an

I

sofix Semi-Universa

L

 seat which is

either:

–  "rearward facing" fitted with an upper

strap or a support leg,

–  "forward facing" fitted with a support leg,

–  a carrycot fitted with an upper strap or a

support leg.

X:

Seat position not suitable for the installation
of an ISOFIX child seat or carrycot for the

specified weight group.

(a)

Refer to the current legislation in the country
in which you are driving before placing a
child in this seat position.

(b)

The seat can be installed centrally in the
vehicle; it then prevents the use of the outer
seats.

For information on securing the upper
strap using the

ISOFIX mountings

, refer

to the corresponding section.

(1)

Installing a carrycot on this seat may
prevent the use of one or more of the other
seats in this row.

(2)

Installation possible only behind the driver's
seat.

(3)

Installation possible only behind the driver's
seat with individual passenger seat.

(4)

The seat in row 2 must be adjusted so that
there is no contact between the child in row
3 and the seat immediately in front.

(5)

The front seat must be adjusted so that
there is no contact between the child in row
2 and the seat immediately in front.

(6)

The front seat must be adjusted so that
there is no contact between the child in row
2 and the seat immediately in front (with the
front seat adjusted to 2 notches ahead of
the centre of the slide).

14/02/2022   15:33:31

128

Safety

i-Size child seats

i-Size child seats have two latches that are anchored to the two rings

A

.

These i-Size child seats also have:
–  either an upper strap that is attached to ring

B

.

–  or a support leg that rests on the vehicle floor, compatible with the approved i-Size seat position.

Their role is to prevent the child seat from tipping forward in the event of a collision.
For more information on the

ISOFIX mountings

, refer to the corresponding section.

Locations for i-Size child seats

In accordance with the new

European regulations, this table indicates the options for installing i-Size child seats on seats in the vehicle fitted with i-Size

approved ISOFIX mountings.

Seat

i-Size restraint system





Row 1 (a)





Passenger seat with passenger

airbag deactivated "

OFF

" or

activated "

ON

"

Not i-Size





Row 2

With 2-seat bench seat in row 1





Outer seats

Not i-Size

Centre seat

Not i-Size

With individual seats in row 1





Outer seats

Not i-Size

Centre seat

Not i-Size

14/02/2022   15:33:31

129

Safety

5

Seat

i-Size restraint system

Combi

,

Business

,

Feel





Row 2

With 2-seat bench seat in row 1





Fixed one-piece bench seat, outer

seats and centre seat (b)

i-UF





Seat and bench seat, outer seats

and centre seat (b)

i-UF

With individual seats in row 1





Fixed one-piece bench seat, outer

seats and centre seat (b)

i-U





Seat and bench seat, outer seats

and centre seat (b)

i-U

Combi

,

Business

,

Feel





Row 3





Fixed one-piece bench seat, outer

seats and centre seat (b)

i-U

 (c)





Seat and bench seat, outer seats

and centre seat (b)

i-U

 (c)

Shine

,

Business Lounge





Row 2 and 3





Rear seats with seat and bench

seat

i-U

 (c)





Rear seats with 2 individual seats

Not i-Size





Rear seats with 1 individual seat

Not i-Size

14/02/2022   15:33:32

130

Safety

i-U:

Suitable for forward facing and rearward facing "Universal" i-Size restraint systems.

i-UF:

Only suitable for forward facing "Universal" i-Size restraint systems.

(a)

Refer to the current legislation in the country in which you are driving before placing a child in this seat position.

(b)

The seat can be installed centrally in the vehicle; it then prevents the use of the outer seats.

(c)

The seat in row 2 cannot be used when an i-Size child seat is installed immediately behind.

Manual child lock

Mechanical system to prevent opening of the
sliding side door using its interior lever.





Locking/Unlocking

►  Rotate the control located on the edge of the

side door

up

 to

lock

 it, or

down

 to

unlock

 it.

Electric child lock

Remote control system to
prevent opening of the rear
doors (sliding side door(s), side-
hinged rear doors or tailgate
(depending on version)) using
their interior controls.

This control prevents the opening of the rear
doors using their interior handles and the use of
the rear electric windows.

Activation/Deactivation









►  With the ignition on, press this button to

activate/deactivate the child lock.

A message is displayed, confirming activation/

deactivation of the child lock.
When the indicator lamp is on, the child lock is
activated.

In the event of a serious impact, the
electric child lock is deactivated

automatically.

Any other status of the indicator lamp

indicates a malfunction of the electric

child lock.

With the child lock activated, it is still
possible to open the doors from outside.

This system is independent and in no
circumstances does it take the place of

the central locking control.
Check the status of the child lock each time
you switch on the ignition.

14/02/2022   15:33:32

131

Safety

5

Always keep the electronic key with you when
leaving the vehicle, even for a short time.
In the event of a serious impact, the electric

child lock is switched off automatically to

permit the exit of the rear passengers.

Child lock on rear
windows

This mechanical system
prevents opening of the left-
hand and/or right-hand rear side
windows.





►  The system is locked/unlocked using

the

remote control key or the back-up key for the
Keyless Entry and Start system.

14/02/2022   15:33:32
