Park Brake

Action

Message

The parking brake is set, the engine is running and you drive your vehicle more than 3 mph

(5 km/h). If the warning stays on after the parking brake is released, have the system checked

as soon as possible.

Park Brake Engaged

The electric parking brake is set and a manual release is attempted without the brake pedal

being pressed.

To Release: Press Brake and Switch

The electric parking brake is set and an automatic release is attempted but cannot be

performed. Perform a manual release.

Park Brake Use Switch to Release

The electric parking brake is set and your vehicle speed exceeds 3 mph (5 km/h). Release

park brake before continued driving.

Release Park Brake

The electric parking brake is not fully applied.

Park Brake Not Applied

The electric parking brake is not fully released.

Park Brake Not Released

The electric parking brake system has been put into a special mode to allow service of the

rear brakes. Have the system checked as soon as possible.

Park Brake Maintenance Mode

158

Information Displays

Action

Message

The electric park brake system has detected a condition that requires service. Some function-

ality may still be available. Have the system checked as soon as possible.

Park Brake Limited Function Service Required

The electric parking brake system has detected a condition that requires service. Have the

system checked as soon as possible.

Park Brake Malfunction Service Now

Applying the electric parking brake numerous times has overheated the system. Wait two

minutes before attempting to apply again.

Park Brake System Overheated

Power Steering

Action

Message

The power steering system has detected a condition that requires service. Have the system

checked as soon as possible.

Steering Fault Service Now

The power steering system is not working.  Stop your vehicle in a safe place.  Have the system

checked as soon as possible.

Steering Loss Stop Safely

The power steering system has detected a condition within the power steering system or

passive entry or passive start system that requires service. Have the system checked as soon

as possible.

Steering Assist Fault Service Required

The steering lock system has detected a condition that requires service. Have the system

checked as soon as possible.

Steering Lock Malfunction Service Now

159

Information Displays

Pre-Collision Assist

Action

Message

You have a blocked sensor due to inclement weather, ice, mud or water in front of the radar

sensor. In most cases, you can clean the sensor to resolve.

Pre-Collision Assist Not Available Sensor

Blocked

Displays when the system requires service. Have the system checked as soon as possible.

Pre-Collision Assist Not Available

Remote Start

Action

Message

Displays as a reminder to apply the brake and push the gear shift button to drive the vehicle

after a remote start.

To Drive: Press Brake and Gear Shift Button

Seats

Action

Message

Objects are by the passenger seat. After the objects are moved away from the seat, if the

warning stays on or continues to come on have the system checked as soon as possible.

Occupant Sensor BLOCKED Remove Objects

Near Passenger Seat

Displays as a reminder that memory seats are not available while driving.

Memory Recall Not Permitted While Driving

Displays to show where your memory setting has been saved.

Memory {0} Saved

160

Information Displays

Starting System

Action

Message

Displays when starting the vehicle as a reminder to apply the brake.

To START Press Brake

Displays when the starter has exceeded its cranking time in attempting to start the vehicle.

Cranking Time Exceeded

Displays when the starter is attempting to start the vehicle.

Engine Start Pending Please Wait

Displays when the pending start has been cancelled.

Pending Start Cancelled

Tire Pressure Monitoring System

Action

Message

One or more tires on your vehicle have low tire pressure.   See

Tire Pressure Monitoring

System

 (page 447).

Tire Pressure Low

The system may require service. If this message stays on or continues to come on, have the

system checked as soon as possible.  See

Tire Pressure Monitoring System

 (page 447).

Tire Pressure Monitor Fault

The system may require service, or your spare tire is in use. For more information on how the
system operates under these conditions,  See

Tire Pressure Monitoring System

 (page 447).

If this message stays on or continues to come on, have the system checked as soon as

possible.

Tire Pressure Sensor Fault

161

Information Displays

Trailer

Action

Message

A correct trailer connection is sensed during a given ignition cycle.

Trailer Connected

A trailer connection becomes disconnected, either intentionally or

unintentionally, and has been sensed during a given ignition cycle.

Trailer Disconnected

The trailer sway control has detected trailer sway.

Trailer Sway Reduce Speed

There is a concern with your vehicle wiring and trailer wiring or brake

system.  See

Towing a Trailer

 (page 354).

Trailer Wiring Fault

There is a concern with your trailer turn lamp. Check your lamp.

Trailer Left Turn Lamps Fault Check Lamps

There is a concern with your trailer turn lamp. Check your lamp.

Trailer Right Turn Lamps Fault Check Lamps

There is a concern with your trailer battery.  See

Towing a Trailer

(page 354).

Trailer Battery Not Charging See Manual

There is a concern with your vehicle trailer lighting module.  See

Towing a Trailer

 (page 354).

Trailer Lighting Module Fault See Manual

162

Information Displays

Transmission

Action

Message

You switched the engine off and the gear selector is in any position other than park (P).

Shift to Park

The transmission is too cold. Wait for it to warm up before you drive.

Transmission Warming Up Please Wait

Displays when you need to press the brake pedal.

Press Brake Pedal

The transmission is overheating and needs to cool.  Stop in a safe place as soon as it’s

possible.

Transmission Over Temperature Stop Safely

Have the system checked as soon as possible.

Transmission Service Required

The transmission is overheating and needs to cool.  Stop in a safe place as soon as it is

possible.

Transmission Too Hot Press Brake

The transmission has limited functionality.  Have the system checked as soon as possible.

Transmission Limited Function See Manual

A reminder to shift into park (P). In addition, this message is typical after reconnecting or

recharging the battery until you cycle the ignition to the on mode.  See

Changing the 12V

Battery

 (page 410).

Transmission Not in Park

Displays when there is a concern and the park brake needs to be depressed before exiting

the vehicle. Have the system checked as soon as possible.

SHIFT SYS FAULT Confirm Park Brake Apply

Before Exiting the Vehicle

Have the system checked as soon as possible.

SHIFT SYS FAULT Service Required

Displays when there is a concern while the vehicle is shifting to park (P). Have the system

checked as soon as possible.

SHIFT SYS FAULT Vehicle is Shifting to Park

163

Information Displays

Action

Message

Displays when there is a concern while the vehicle is shifting to reverse (R). Have the system

checked as soon as possible.

SHIFT SYS FAULT Reverse Unavailable

Service Required

Have the system checked as soon as possible.

SHIFT SYS FAULT Drive Unavailable Select

S for Drive Service Required

Have the system checked as soon as possible.

SHIFT SYS FAULT Neutral Unavailable Service

Required

Have the system checked as soon as possible.

SHIFT SYS FAULT Sport Unavailable Service

Required

Displays when an invalid gear has been selected.

Invalid Gear Selection

Displays when the brake pedal needs to be pressed to enable the transmission to shift from

park.

Depress Brake to Shift from Park

164

Information Displays

AUTOMATIC CLIMATE CONTROL

E286903

Note:

Depending on your vehicle option

package, the controls may look different
from what you see here.

Note:

You can switch temperature units

between Fahrenheit and Celsius.

Note:

You can control some of the climate

features through the touchscreen.

Note:

For Hybrid vehicles, the air

conditioning compressor may run and airflow
may be felt when the climate control is off
to provide cooling to the battery.

Accessing the Air Distribution Controls

E265283

Press and release the button to
activate the selection screen.

From the screen you can direct air to the
windshield, instrument panel or footwell
vents. You can direct air through any
combination of these vents.  See

Climate

(page 533).

Accessing the Climate Control Menu

E265038

Press and release the button to
access additional controls for the
front climate system.

Accessing Rear Climate Controls

E270447

Press and release the button to
access additional controls for the
rear climate system.

Setting the Blower Motor Speed

E2265389

E2

265

389

265389

Turn the control to adjust the volume of air
circulated in the vehicle.

165

Climate Control

Setting the Temperature

E266187

E266186

Press the toggle button on the left-hand side
of the climate control upward or downward
to set the left-hand temperature.

Note:

This control also adjusts the right-hand

side temperature when you switch off dual
zone mode.

Press the toggle button on the right-hand
side of the climate control upward or
downward to set the right-hand temperature.

Switching Auto Mode On and Off

Press and release the button to
switch on automatic operation.
Repeatedly press the button to

adjust auto mode.

The system adjusts the blower motor speed,
air distribution, air conditioning operation,
and outside or recirculated air to reach and
maintain the temperature you have set.

Under high humidity conditions, the system
adjusts the blower motor speed, air
distribution and air conditioning operation
to reduce window fogging.

Note:

The system starts at the previous

setting when you switch on AUTO mode.

Note:

You can also switch off dual zone

mode by pressing and holding the button for
more than two seconds.

166

Climate Control

Auto Mode Indicator Status

Description

Auto Mode Indicator Status

One indicator illuminated.

•

The blower motor speed is reduced.

•

Use this setting to minimize the amount of noise from the blower motor.

•

This setting increases the time taken to cool the interior.

Two indicators illuminated.

•

The blower motor speed is moderate.

Three indicators illuminated.

•

The blower motor speed is increased.

•

Use this setting to reduce the time taken to cool the interior.

•

This setting increases the amount of noise from the blower motor.

Switching the Air Conditioning On and
Off

Press and release the button.

Use air conditioning with recirculated air to
improve cooling performance and efficiency.

Note:

In certain conditions, such as

maximum defrost, the air conditioning
compressor may continue to operate even
though you switch off the air conditioning.

Note:

The A/C LED light may turn on and off

based on the temperature setting or the
current conditions.

Switching the Climate Control On and
Off

Press and release the button.

Note:

Your vehicle may not have a physical

button. You can use the touchscreen to turn
the climate control on and off.

167

Climate Control

Switching Maximum Air Conditioning
On and Off

Press and release the button for
maximum cooling.

The driver and passenger temperatures are
set to LO, recirculated air flows through the
instrument panel air vents, air conditioning
turns on and the blower motor adjusts to the
highest speed.

Switching Maximum Defrost On and
Off

Press and release the button for
maximum defrosting.

The driver and passenger temperatures are
set to HI, air flows through the windshield air
vents, and the blower motor adjusts to the
highest speed.

Note:

Depending on your region, air

conditioning turns on.

You can also use this setting to defog and
clear the windshield of a thin covering of ice.

Note:

To prevent window fogging, you

cannot select recirculated air when
maximum defrost is on.

Note:

The heated rear window also turns on

when you select maximum defrost.

Switching Recirculated Air On and Off

Press and release the button to
switch between outside air and
recirculated air.

The air currently in the passenger
compartment recirculates. This may reduce
the time needed to cool the interior, when
used with A/C, and reduce unwanted odors
from entering your vehicle.

Note:

Recirculated air may turn off

automatically, or prevent you from switching
on in all air flow modes except MAX A/C to
reduce the risk of fogging. Recirculation may
also turn on and off automatically in various
air distribution control combinations to
improve heating or cooling efficiency.

HINTS ON CONTROLLING THE
INTERIOR CLIMATE

General Hints

Note:

Prolonged use of recirculated air may

cause the windows to fog up.

Note:

You may feel a small amount of air

from the footwell air vents regardless of the
air distribution setting.

Note:

To reduce humidity build-up inside

your vehicle, do not drive with the system
switched off or with recirculated air always
switched on.

Note:

Do not place objects under the front

seats as this may interfere with the airflow
to the rear seats.

Note:

Remove any snow, ice or leaves from

the air intake area at the base of the
windshield.

Note:

To improve the time to reach a

comfortable temperature in hot weather,
drive with the windows open until you feel
cold air through the air vents.

168

Climate Control

Automatic Climate Control

Note:

Adjusting the settings when your

vehicle interior is extremely hot or cold is not
necessary. Automatic mode is best
recommended to maintain set temperature.

Note:

The system adjusts to heat or cool the

interior to the temperature you select as
quickly as possible.

Note:

For the system to function efficiently,

the instrument panel and side air vents
should be fully open.

Note:

If you select

AUTO

 during cold outside

temperatures, the system directs air flow to
the windshield and side window air vents. In
addition, the blower motor may run at a
slower speed until the engine warms up.

Note:

If you select

AUTO

 during hot

temperatures and the inside of the vehicle
is hot, the system uses recirculated air to
maximize interior cooling. Blower motor
speed may also reduce until the air cools.

Quickly Heating the Interior

1.

Press and release

AUTO

.

2. Adjust the temperature function to the

setting you prefer.

Recommended Settings for Heating

1.

Press and release

AUTO

.

2. Adjust the temperature function to the

setting you prefer. Use 72°F (22°C) as a
starting point, then adjust the setting as
necessary.

Quickly Cooling the Interior

1.

Press and release

MAX A/C

.

Recommended Settings for Cooling

1.

Press and release

AUTO

.

2. Adjust the temperature function to the

setting you prefer. Use 72°F (22°C) as a
starting point, then adjust the setting as
necessary.

Defogging the Side Windows in Cold
Weather

1.

Press and release defrost or maximum
defrost.

2. Adjust the temperature control to the

setting you prefer. Use 72°F (22°C) as a
starting point, then adjust the setting as
necessary.

REAR PASSENGER CLIMATE
CONTROLS - VEHICLES WITH:
QUADRUPLE ZONE AUTOMATIC
TEMPERATURE CONTROL

Use the rear passenger touchscreen to
select the following:

E283811

Press the climate button on the
feature bar to access the rear
passenger climate control screen.

Rear Passenger Climate Control Screen

E283809

169

Climate Control

Selecting a Row

Press

2nd Row

 to control the second row

climate.

Press

3rd Row

 to control the third row

climate.

Linking the Rows

E282078

Press the button to simultaneously
control the climate of the second
and third row.

Setting the Rear Blower Motor Speed

Press the arrow buttons to adjust
the volume of air circulated in the
rear passenger compartment.

Setting the Rear Temperature

Press the arrow buttons to set the
temperature in the rear passenger
compartment.

Switching the Rear Climate Control On
and Off

Press the button to switch the
selected row controls on or off.

Note:

When linked, touch the button to

switch both rows on or off.

Directing Air to the Overhead and Rear
Footwell Air Vents

Press the button to activate the
selection screen.

E244097

Press the button to direct airflow
to the overhead air vents.

Press the button to direct airflow
to the rear footwell air vents.

Switching Rear Auto Mode On and Off

Press

AUTO

 switch on rear automatic

operation, then set the temperature.

Rear Climate Control Lock Message

A message displays when the controls are
locked through the front and you try to
operate them.

REAR PASSENGER CLIMATE
CONTROLS - VEHICLES WITH:
TRIPLE ZONE AUTOMATIC
TEMPERATURE CONTROL

Use the rear passenger touchscreen to
select the following:

E283811

Press the climate button on the
feature bar to access the rear
passenger climate control screen.

170

Climate Control

Rear Passenger Climate Control Screen

E368025

E368025

Setting the Rear Blower Motor Speed

Press the arrow buttons to adjust
the volume of air circulated in the
rear passenger compartment.

Setting the Rear Temperature

Press the arrow buttons to set the
temperature in the rear passenger
compartment.

Switching the Rear Climate Control On
and Off

Press the button to switch the
controls on or off.

Directing Air to the Overhead and Rear
Footwell Air Vents

Press the button to activate the
selection screen.

E244097

Press the button to direct airflow
to the overhead air vents.

Press the button to direct airflow
to the rear footwell air vents.

Switching Rear Auto Mode On and Off

Press

AUTO

 switch on rear automatic

operation, then set the temperature.

Rear Climate Control Lock Message

A message displays when the controls are
locked through the front and you try to
operate them.

HEATED REAR WINDOW

E184884

Press the button to clear the rear
window of thin ice and fog.  The
heated rear window turns off after

a short period of time.

Note:

Do not use harsh chemicals, razor

blades or other sharp objects to clean or
remove decals from the inside of the heated
rear window. The vehicle warranty may not
cover damage to the heated rear window
grid lines.

HEATED EXTERIOR MIRRORS

When you switch the heated rear window
on, the heated exterior mirrors turn on.

Note:

Do not remove ice from the mirrors

with a scraper or adjust the mirror glass
when it is frozen in place.

Note:

Do not clean the mirror housing or

glass with harsh abrasives, fuel or other
petroleum-based cleaning products. The
vehicle warranty may not cover damage
caused to the mirror housing or glass.

171

Climate Control

REMOTE START

The climate control system adjusts the
interior temperature during remote start.

You can switch this feature on or off and
adjust the settings using the touchscreen.
See

Settings

 (page 555).

You cannot adjust the climate control setting
during remote start operation.  Switch the
ignition on to make adjustments.

Based on your remote start settings, the
following vehicle-dependent features may
or may not remain on after remote starting
your vehicle:

•

Climate controlled seats.

•

Heated steering wheel.

•

Heated mirrors.

•

Heated rear window.

•

Windshield wiper de-icer.

Note:

For dual zone climate controlled seats,

the passenger seat setting defaults to match
the driver seat during remote start.

Automatic Settings

If

Auto

 is on, the system sets the interior

temperature to 72°F (22°C) and heats or
cools the vehicle interior as required to
achieve comfort.

Note:

In cold weather, the heated rear

window and heated mirrors turn on.

Last Settings

If

Last Settings

 is on, the system uses the

settings last selected before you turned off
the vehicle.

Heated and Cooled Features

In

Auto

 mode, certain heated features may

switch on during cold weather, and cooled
features during hot weather.

172

Climate Control

WHAT IS THE CABIN AIR FILTER

The cabin air filter improves the quality of air
in your vehicle by trapping dust, pollen and
other particles.

REPLACING THE CABIN AIR FILTER

Replace the filter at regular intervals.   See

Scheduled Maintenance

 (page 579).

The cabin air filter is behind the glove
compartment.

To remove the lower glove compartment and
access the filter:

1.

Open the glove compartment.

E31

E31

E31

E

1296

1296

12

2. Press the tab on each side.

3. Fully lower the glove compartment.

4. Pull the glove compartment toward you.

WHAT IS AUTO AIR REFRESH

 (IF

EQUIPPED)

Auto Air Refresh helps improve or maintain
the quality of air within your vehicle cabin.

HOW DOES AUTO AIR REFRESH
WORK

 (IF EQUIPPED)

Auto Air Refresh uses an outside gases
sensor to automatically adjust the climate
control system to change from outside air to
recirculated air to help reduce the entry of
outside odors into the cabin. It uses a
particulate matter sensor in the cabin to
estimate and provide information about
particulate matter pollution in the cabin. It
also allows you to refresh the cabin air with
outside air on-demand or automatically.

CHECKING THE INTERIOR AIR
QUALITY

 (IF EQUIPPED)

E283817

Press the button on touchscreen
feature bar to see current cabin
PM2.5 information.

Note:

You can also press the menu button

on the climate control unit and then press
PM2.5 on the touchscreen.

Press

Cabin Air History

 to see a recent

history of average PM2.5 in the cabin.

173

Interior Air Quality
