When you are decelerating with either your
foot off the accelerator pedal or on the brake
pedal, you will see a green or white solid bar
indicating the power being used to slow
down the vehicle. You may also see a green
rectangular box which shows the amount of
power that can be recaptured by the
regenerative braking system and returned
to the high voltage battery.

•

When the power level is completely
within the box, the color of the bar will
be all green. This means that the
regenerative braking system is being
used to efficiently slow the vehicle down
and return the maximum percentage of
energy to the high voltage battery.

•

When the power level is outside of the
green box, then the bar will be white. This
means that both the regenerative braking
system and conventional braking system
are in use.

Electric Efficiency

This screen shows your average driving
distance per kWh of electricity used on your
hybrid vehicle. The value is calculated only
when your available electric range is being
used and the gasoline engine is off.

Distance per full charge is also shown. This
is an estimate of the electric range you would
have if you plugged in and fully charged your
vehicle right now. The higher your electric
efficiency, the higher your distance per full
charge.

Your electric efficiency is affected by your
driving style and route, climate control use,
outside temperature and other factors. Best
efficiency is achieved in mild ambient
temperatures with mild to moderate
acceleration and braking, moderate speeds
and low climate control usage.

INFORMATION MESSAGES

E

E281

281

281

81

81

81

81

1

1

1

8

220

22

220

220

2

2

220

2

220

22

220

E265041

Move the selector switch to the
right to acknowledge and remove
some messages from the

information display. The system removes
other messages after a short time.

You need to confirm certain messages
before you can access the menus.

Active Park

Action

Message

The system requires service.  Have the system checked as soon as possible.

Active Park Fault

142

Information Displays

Adaptive Cruise Control

Action

Message

A radar concern is preventing the adaptive cruise from engaging.  See

How Does Adaptive

Cruise Control With Stop and Go Work

 (page 305).

Adaptive Cruise Malfunction

Front Sensor Not Aligned

Conditions exist such that the adaptive cruise cannot function properly.  See

How Does

Adaptive Cruise Control With Stop and Go Work

 (page 305).

Adaptive Cruise Not Available

Inclement weather, ice, mud, or water is blocking the radar, causing the system to become

unavailable. You can typically clean the sensor to resolve.  See

How Does Adaptive Cruise

Control With Stop and Go Work

 (page 305).

Adaptive Cruise Not Available Sensor Blocked

See Manual

Displays when the system disables automatic braking.

Normal Cruise Active Adaptive Braking Off

Displays when the system reinstates adaptive cruise control to you.

Adaptive Cruise - Driver Resume Control

Displays when the vehicle speed is too slow to activate the adaptive cruise.

Adaptive Cruise Speed Too Low to Activate

Adaptive Headlamps

Action

Message

Displays when the system detects a concern. Have the system checked as soon as possible.

Check Headlamp System See Manual

143

Information Displays

AdvanceTrac™ and Traction Control

Action

Message

The system detects a condition that requires service. Have the system checked as soon as

possible.

Service AdvanceTrac

The status of the system after you switch it off.

AdvanceTrac Off

The status of the system after you switch it on.

AdvanceTrac On

The status of the system after you switch it on.

AdvanceTrac SPORT MODE

The status of the system after you switch it off.

Traction Control Off

The status of the system after you switch it on.

Traction Control On

Alarm

Action

Message

Alarm triggered due to unauthorized entry.  See

Anti-Theft Alarm

 (page 100).

Vehicle Alarm To Stop Alarm, Start Vehicle.

144

Information Displays

AWD

Action

Message

The all-wheel drive system temporarily turns off to protect itself from overheating.

AWD Temporarily Disabled

The all-wheel drive system is locking the torque transfer clutch to reduce clutch temperature.

AWD Temporarily Locked

The all-wheel drive system temporarily turns off to protect itself from overheating or if you

are using the temporary spare tire.

AWD OFF

The all-wheel drive system resumes normal function and clears this message after driving a

short distance with the road tire re-installed or after the system cools.

AWD Restored

The all-wheel drive system is not operating properly. If the warning stays on or continues to

come on, have the system checked as soon as possible.

AWD Fault Service Required

Displays when the transfer case fluid requires service.

Change AWD Power Transfer Unit Lube

Displays when the transfer case fluid has been changed and reset to new.

AWD Power Transfer Unit Lube Set to New

145

Information Displays

Battery and Charging System (12 volt)

Action

Message

The charging system needs servicing. If the warning stays on or continues to come on, have

the system checked as soon as possible.

Check Charging System

The charging system needs servicing. If the warning stays on or continues to come on have

the system checked as soon as possible.

Charging System Service Soon

The charging system needs servicing. Have the system checked as soon as possible.

Charging System Service Now

The battery management system determines that the 12V battery is at a low state of charge.

Start the engine to charge the battery or charge the battery using an aftermarket battery

charger. This message clears once you restart your vehicle and the battery state of charge

has recovered.

Battery State of Charge Low

The battery management system determines that the battery is at a low state of charge. Turn

the ignition off as soon as possible to protect the battery. This message clears once the

vehicle has been started and the battery state of charge has recovered. Turning off unneces-

sary electrical loads allows faster battery state-of-charge recovery.

Turn Power Off To Save Battery

Displays when the battery management system detects an extended low-voltage condition.

The system disables various vehicle features to help preserve the battery. Turn off as many

of the electrical loads as soon as possible to improve system voltage. When the system

voltage recovers, the disabled features operate again as normal.

Low Battery Features Temporarily Turned Off

146

Information Displays

Battery and Charging System (High Voltage)

Action

Message

Your vehicle needs confirmation it is unplugged before allowing a start. Make sure you unplug

your vehicle and respond to the message prompt before starting your vehicle.

Vehicle Plugged In ? Yes No

Your vehicle detects it is still plugged in after you attempt to start it.

Unplug Prior to Starting Vehicle

Your vehicle enables the engine due to the climate control defrost setting. This is normal

operation.

Engine Enabled Due to Defrost Setting

For full defrost heat, select a drive mode other than Pure EV. The engine may run to provide

more cabin heat.

Press EV Button for Full Defrost

Your vehicle enables the engine for system performance. This is normal operation.

Engine Enabled for System Performance

You can press OK to enable the engine temporarily for increased performance when in Pure

EV drive mode.

Press OK to Enable Engine

147

Information Displays

Blind Spot Information and Cross Traffic Alert System

Action

Message

The system may require service. Have the system checked as soon as possible.

Blind Spot System Fault

Something is blocking the sensor, causing the system to become unavailable. You can

typically clean the sensor to resolve.  See

Blind Spot Information System

 (page 326).

Blind Spot Not Available Sensor Blocked See

Manual

The system detects a vehicle and applies the brakes.

Cross Traffic Alert Applying Brakes

Something is blocking the sensor, causing the system to become unavailable. In most cases,

you can clean the sensor to resolve.

Cross Traffic Not Available Sensor Blocked

See Manual

The system may require service. Have the system checked as soon as possible.

Cross Traffic System Fault

The system automatically turns off and displays this message when you connect a trailer to

the vehicle that does not have a trailer blind spot system or when you switch the trailer blind

spot system off through the information display.  See

Cross Traffic Alert

 (page 330).

Cross Traffic Alert Deactivated Trailer

Attached

The system automatically turns off and displays this message when you connect a trailer to

the vehicle that does not have a trailer blind spot system or when you switch the trailer blind

spot system off through the information display.  See

Blind Spot Information System

 (page

326).

Blind Spot Alert Deactivated Trailer Attached

148

Information Displays

Doors and Locks

Action

Message

The driver door is not completely closed.

Driver Door Ajar

The passenger door is not completely closed.

Passenger Door Ajar

The rear left-hand door is not completely closed.

Rear Left Door Ajar

The rear right-hand door is not completely closed.

Rear Right Door Ajar

The liftgate is not completely closed.

Liftgate Ajar

The hood is not completely closed.

Hood Ajar

The system has disabled the door switches.

Switches Inhibited Security Mode

Displays when the door lock is turned on and you attempt to open the door.

Doors Locked Unlock Before Opening

Indicates a driver door concern that requires manually opening the door by the override lever.

Have the system checked as soon as possible.

Driver Door Fault Use Inside Override Lever

In Map Pocket

Indicates a concern with the electronic door system. Have the system checked as soon as

possible.

Door Fault Service Required

Displays when the system requires service. Have the system checked as soon as possible.

Child Lock Malfunction Service Required

149

Information Displays

Action

Message

Indicates that the rear seat interior door release switches and power windows are switched

off, preventing rear seat occupants from opening the doors or windows.

Child Lock ON

Indicates that the rear seat interior door release switches and power windows are switched

on, allowing the rear seat occupants to open the doors and windows.

Child Lock OFF

The factory keypad code displays in the information display after the system resets the keypad.

See

Passive Anti-Theft System

 (page 99).

Factory Keypad Code {X X X X X}

Driver Alert

Action

Message

Stop and rest as soon as it is safe to do so.

Driver Alert Warning Rest Now

Take a rest soon.

Driver Alert Warning Rest Suggested

Fuel

Action

Message

An early reminder of a low fuel condition.

Fuel Level Low

The fuel fill inlet valve may not be properly closed.

Check Fuel Fill Inlet

Wait for up to 15 seconds while the fuel system depressurizes.

Fuel Door Opening

150

Information Displays

Action

Message

The fuel system has finished depressurizing and you can begin to refuel.

Fuel Door Open

A reminder to close the fuel door. Failure to follow this instruction can cause the check engine

light to illuminate.

Close Fuel Door to Avoid ""Check Engine""

Light

There is an error in attempting to refill your vehicle.

Refuel Error See Manual

Hill Descent Control

Action

Message

Displays when you switch off hill descent control mode.

Hill Descent Control OFF

Displays when hill descent speed exceeds 20 mph (32 km/h).

For Hill Descent Reduce Speed 20 MPH or

Less

Displays when hill descent speed exceeds 20 mph (32 km/h).

For Hill Descent Reduce Speed 32 Km/h or

Less

Displays when hill descent control mode requires you to shift the transmission into gear.

For Hill Descent Select Gear

Displays when the hill control mode requires you to resume control.

Hill Descent Driver Resume Control

Displays when a hill descent system fault is present.

Hill Descent Control Fault

151

Information Displays

Action

Message

Displays when you disable the hill descent control mode to cool the brake system.

Hill Descent Control Off System Cooling

Displays when hill descent control mode is ready.

Hill Descent Control Ready

Displays when you activate the hill descent control mode.

Hill Descent Control Active

Hill Start Assist

Action

Message

Hill start assist is not available. Have the system checked as soon as possible.  See

Hill Start

Assist

 (page 274).

Hill Start Assist Not Available

Keys and Intelligent Access

Action

Message

A reminder to press the brake while starting your vehicle.

To START Press Brake

The key is not detected by the system.

No Key Detected

The start stop button is pressed to shut off the engine and an intelligent access key is not

detected inside your vehicle.

Restart Now or Key is Needed

Your vehicle is in the accessory ignition state.

Full Accessory Power Active

152

Information Displays

Action

Message

There is a problem with your vehicle’s starting system. Have the system checked as soon as

possible.

Starting System Fault

Displays when you successfully program an intelligent access key to the system.

Key Program Successful

Displays when you successfully program the maximum number of intelligent access key to

the system.

Max Number of Keys Learned

Displays during spare key programming when intelligent access key programming fails.

Key Program Failure

Displays during spare key programming when you have not programmed enough keys.

Not Enough Keys Learned

Displays when the key battery is low. Change the battery as soon as possible.

Key Battery Low Replace Soon

Displays when you switch the vehicle off.

Vehicle Switched Off

153

Information Displays

Lane Keeping System

Action

Message

Displays when the system requires service. Have the system checked as soon as possible.

Lane Keeping Sys. Malfunction Service

Required

Check to make sure there are no objects or debris blocking the camera. Have the system

checked if this condition persists.

Front Camera Temporarily Not Available

Clean the windshield to improve visibility and allow the camera to properly operate.

Front Camera Low Visibility Clean Screen

Displays when the system requires service. Have the system checked as soon as possible.

Front Camera Malfunction Service Required

The system requests that you keep your hands on the steering wheel.

Keep Hands on Steering Wheel

Maintenance

Action

Message

Stop your vehicle as soon as safely possible and turn off the engine. Check the oil level. If

this message stays on or continues to come on with your engine running, have the system

checked as soon as possible.

Low Engine Oil Pressure

The engine oil life is low and needs to be changed soon.  See

General Maintenance

Information

 (page 579).

Change Engine Oil Soon

The engine oil life is low and needs to be changed immediately.  See

General Maintenance

Information

 (page 579).

Oil Change Required

154

Information Displays

Action

Message

The brake fluid level is low. Have the system checked immediately.  See

Brake Fluid Check

(page 409).

Brake Fluid Level Low

The brake system needs servicing. Stop the vehicle in a safe place. Have the system checked

as soon as possible.

Check Brake System

The engine coolant temperature is excessively high. Have the system checked immediately.

Engine Coolant Over Temperature

The washer fluid is low and needs to be refilled.

Washer Fluid Level Low

Indicates that your vehicle is still in Transport mode. This may not allow some features to

properly operate. Have the system checked as soon as possible.

Transport Mode Contact Dealer

Indicates that your vehicle is still in Factory mode. This may not allow some features to

properly operate. Have the system checked as soon as possible.

Factory Mode Contact Dealer

Informs the driver that the powertrain needs service due to a powertrain concern. Have the

system checked as soon as possible.

See Manual

The engine has reduced power to help reduce high engine temperature.

Power Reduced to Lower Engine Temp

The brake system has reduced stopping power.

Brake Applied Power Reduced

The motor electronics are overheating. Stop your vehicle as soon as safely possible, turn off
your vehicle and let it cool. If the warning stays on or continues to come on, have the system

checked as soon as possible.

Motor Coolant Over Temperature

EV functionality is disabled and the engine is running to maintain oil quality.  See

Plug-In

Hybrid Vehicle Operation

 (page 219).

Engine ON Due to Low Use Normal Operation

155

Information Displays

MyKey

Action

Message

You cannot program a MyKey.

MyKey not Created

MyKey is active.

MyKey Active Drive Safely

When switching on your vehicle and MyKey is in use, displays that the MyKey speed limit is

on.

Speed Limited to XX MPH/km/h

MyKey is in use and the MyKey speed limit is on and the vehicle speed is approaching 80 mph

(130 km/h).

Near Vehicle Top Speed

You have reached the speed limit set for your MyKey.

Vehicle at Top Speed of MyKey Setting

You have an active MyKey with a programmed set speed limit.

Check Speed Drive Safely

Belt-Minder turns on with a MyKey in use.

Buckle Up to Unmute Audio

With a MyKey in use, AdvanceTrac turns on.

AdvanceTrac On - MyKey Setting

With a MyKey in use, traction control turns on.

Traction Control On - MyKey Setting

With a MyKey in use, park aid is always on.

MyKey Park Aid Cannot be Deactivated

With a MyKey in use, lane keeping alert turns on.

Lane Keeping Alert On MyKey Setting

156

Information Displays

Park Aid

Action

Message

The system requires service.  Have the system checked as soon as possible.

Check Front Park Aid

The system requires service.  Have the system checked as soon as possible.

Check Rear Park Aid

The radar is blocked due to inclement weather, ice, mud or water in front of radar. You can

typically clean the sensor to resolve.  See

Rear Parking Aid

 (page 286).

Rear Park Aid Not Available Sensor Blocked

See Manual

The radar is blocked due to inclement weather, ice, mud or water in front of radar. You can

typically clean the sensor to resolve.  See

Front Parking Aid

 (page 288).

Front Park Aid Not Available Sensor Blocked

See Manual

The radar is blocked due to inclement weather, ice, mud or water in front of radar. You can

typically clean the sensor to resolve.  See

Principle of Operation

 (page 286).

Park Aid Not Available Sensor Blocked See

Manual

Displays the park aid status.

Front Park Aid On Off

Displays the park aid status.

Rear Park Aid On Off

157

Information Displays
