GETTING TO KNOW YOUR VEHICLE

When exiting the vehicle the driver can choose

to have the headlights remain on for 30, 60 or

90 seconds or not remain on. To change the

timer setting, see an authorized dealer.
The headlight delay time is programmable on

vehicles equipped with an instrument cluster

display. Refer to “Instrument Cluster Display” in

“Getting To Know Your Instrument Panel” for

further information.
If the headlights are turned off before the

ignition, they will turn off in the normal manner.

NOTE:

The headlights must be turned off within 45

seconds of placing the ignition in the OFF

position to activate this feature.

Lights-On Reminder

If the headlights or the parking lights are left on,

or if the dimmer control is in the extreme top

position after the ignition has been placed in

the OFF position, a chime will sound when the

driver's door is opened.

Front Fog Lights — If Equipped

To activate the front fog lights, turn on the

parking lights or the low beam headlights and

push in the headlight switch control knob.

Pushing the headlight switch control knob a

second time will turn the front fog lights off.

Turn Signals

Move the multifunction lever up or down and

the arrows on each side of the instrument

cluster display will flash to show proper

operation of the front and rear turn signal lights.

NOTE:

If either light remains on and does not flash, or

there is a very fast flash rate, check for a

defective outside light bulb. If an indicator fails

to light when the lever is moved, it would

suggest that the indicator bulb is defective.

Turn Signal Warning
If the vehicle electronics sense that the vehicle

has traveled at over 18 mph (29 km/h) for

about 1 mile (1.6 km) with the turn signals on, a

chime will sound to alert the driver.

Lane Change Assist

Tap the lever up or down once, without moving

beyond the detent, and the turn signal (right or

left) will flash three times then automatically

turn off.

Battery Protection

This feature provides battery protection to avoid

wearing down the battery if the headlights or

parking lights are left on for extended periods of

time when the ignition is in the OFF position.

After eight minutes of the ignition being placed

in the OFF position, and the headlight switch in

any position other than OFF or AUTO, the lights

will turn off automatically until the next cycle of

the ignition or headlight switch.
The battery protection feature will be disabled if

the ignition is placed in any position other than

OFF during the eight minute delay.

INTERIOR LIGHTS

Courtesy/Interior Lighting

At the forward end of the overhead console are

two courtesy lights (standard dome light has

two buttons). These interior lights are turned on

when a door or the liftgate is opened, the

remote keyless entry key fob is activated, or

when the dimmer control is moved to the

extreme top.

GETTING TO KNOW YOUR VEHICLE

The interior lights will automatically turn off in

approximately 10 minutes for the first

activation and 90 seconds every activation

thereafter until the engine is started, if one of

the following occur:



A door, sliding door or the liftgate is left open.



Any overhead reading light is left on.

NOTE:

The ignition must be placed in the OFF position

for this feature to operate.

The courtesy lights also function as reading

lights. Push in on each lens to turn these lights

on while inside the vehicle. Push a second time

to turn each light off. You may adjust the

direction of these lights by pushing the outside

ring, which is identified with four directional

arrows (LED lamps only).

Rear Courtesy/Reading Lights — If Equipped

The overhead console has two sets of courtesy

lights. The lights turn on when a front door, a

sliding door or the liftgate is opened. If your

vehicle is equipped with Remote Keyless Entry,

the lights will also turn on when the unlock

button on the key fob is pushed.
The courtesy lights also function as reading

lights. Push in on each lens to turn these lights

on while inside the vehicle. Push the lens a

second time to turn each light off. You may

adjust the direction of these lights by pushing

the outside ring, which is identified with four

directional arrows.

Reading Lights

Rear Console Halo Lighting

Halo lights are strategically placed soft lighting

that help to illuminate specific areas to aid the

occupants in locating specific features while

driving at night.
The rear overhead console has recessed halo

lighting around the perimeter of the console

base. This feature provides additional lighting

options while traveling and is controlled by the

ambient light dimmer control of the headlight

switch.

Ambient Light Dimmer Control

GETTING TO KNOW YOUR VEHICLE

Dimmer Controls

The dimmer switch is located next to the

headlight switch.

Instrument Panel Dimmer Control

With the parking lights or headlights on, rotating

the left dimmer control upward will increase the

brightness of the instrument panel lights.
Rotating the left dimmer control completely

upward to the second detent (extreme top

position) will turn on the interior lights. The

interior lights will remain on when the dimmer

control is in this position.
Rotating the left dimmer control to the off

position (extreme bottom) will turn the interior

lights off, and will remain off when the doors or

liftgate are opened.

Parade Mode (Daytime Brightness Feature)

Rotate the dimmer control upward to the first

detent. This feature brightens all text displays

such as the odometer, instrument cluster

display, and radio when the parking lights or

headlights are on.

WINDSHIELD WIPER AND WASHERS

The wipers and washers are operated by a

switch within the multifunction lever. Rotate the

end of the multifunction lever to select the

desired wiper speed.

Washer And Wiper Controls

NOTE:

Always remove any buildup of snow that

prevents the windshield wiper blades from

returning to the off position. If the windshield

wiper switch is turned off and the blades cannot

return to the off position, damage to the wiper

motor may occur.

Windshield Wiper Operation

Rotate the end of the lever upward, to the first

detent past the intermittent settings for

low-speed wiper operation. Rotate the end of

the lever upward to the second detent past the

intermittent settings for high-speed wiper

operation.

WARNING!

Sudden loss of visibility through the

windshield could lead to a collision. You might

not see other vehicles or other obstacles. To

avoid sudden icing of the windshield during

freezing weather, warm the windshield with

the defroster before and during windshield

washer use.

GETTING TO KNOW YOUR VEHICLE

Intermittent Wiper System

Use the intermittent wiper when weather

conditions make a single wiping cycle with a

variable pause between cycles desirable.

Rotate the end of the multifunction lever to the

first detent position, and then turn the end of

the lever to select the desired delay interval.

There are five delay settings, which allow you to

regulate the wipe interval from a minimum of

one cycle every second to a maximum of

approximately 36 seconds between cycles. The

delay intervals will double in duration when the

vehicle speed is 10 mph (16 km/h) or less.

Windshield Washers

To use the windshield washer, push on the end

of the lever to the second detent and hold while

spray is desired. If the lever is pushed while on

the intermittent setting, the wipers will turn on

and operate for several wipe cycles after the

lever is released, and then resume the

intermittent interval previously selected. If the

lever is pushed while the wipers are in the off

position, the wipers will operate several wipe

cycles, then turn off.

Mist Feature

Push the end of the multifunction lever inward

(toward the steering column) to the first detent

and release for a single wiping cycle.

NOTE:

The mist feature does not activate the washer

pump; therefore, no washer fluid will be sprayed

on the windshield. The wash function must be

used in order to spray the windshield with

washer fluid.

Rear Wiper And Washer

Rotating the center ring of the wiper lever to the

first detent activates the rear intermittent

wipers. To activate the washers, rotate the

center ring fully forward and the washers will

spray until the ring is released, and then

resume the intermittent interval.

NOTE:

Rear window wipers function in the intermittent

wiper speed only.

CLIMATE CONTROLS

The Climate Control system allows you to

regulate the temperature, air flow, and direction

of air circulating throughout the vehicle. The

controls are located on the touchscreen (if

equipped) and on the instrument panel below

the radio.

Manual Climate Control Overview

The air conditioning and heating system is

designed to make you comfortable in all types

of weather.

Manual Temperature Controls

GETTING TO KNOW YOUR VEHICLE

Manual Climate Control Descriptions

Icon

Description

A/C Button

Push the A/C button to engage the Air Conditioning (A/C). An LED will illuminate when the A/C system is engaged.

Recirculation Button

Press and release this button to change the system between recirculation mode and outside air mode. Recirculation can

be used when outside conditions such as smoke, odors, dust, or high humidity are present. Recirculation can be used in all

modes except for Defrost. Recirculation may be unavailable if conditions exist that could create fogging on the inside of the

windshield. The A/C can be deselected manually without disturbing the mode control selection. Continuous use of the

Recirculation may make the inside air stuffy and window fogging may occur. Extended use of this mode is not

recommended.
Front Defrost Mode Button

The Front Defrost button changes the current airflow setting to Defrost mode. The indicator illuminates when this feature is

on. Air comes from the windshield and side window demist outlets. When the defrost mode is selected, the blower level will

increase. Use Defrost mode with maximum temperature settings for best windshield and side window defrosting and

defogging.
Rear Defrost Button

Push and release the Rear Defrost Control button to turn on the rear window defroster and the heated outside mirrors

(if equipped). An indicator will illuminate when the rear window defroster is on. The rear window defroster automatically

turns off after 15 minutes.
Left Front Temperature Control

Provides left front seat occupant with independent temperature control. Turn left for cooler or right for warmer temperature

settings.

GETTING TO KNOW YOUR VEHICLE

Front Blower Control

There are seven blower speeds. Use this control to regulate the amount of air forced through the system in any mode you

select. The blower speed increases as you move the control clockwise from the off position.
Right Front Temperature Control

Provides right front seat occupant with independent temperature control. Turn left for cooler or right for warmer

temperature settings.

Panel Mode

Panel Mode Button

Push button to select Panel Mode. The indicator illuminates when this mode is on. Air comes from the outlets in the

instrument panel. Each of these outlets can be individually adjusted to direct the flow of air. The air vanes of the center

outlets and outboard outlets can be moved up and down or side to side to regulate airflow direction.

Bi-Level Mode

Bi-Level Mode Button

Push button to select Bi–Level Mode. The indicator illuminates when this mode is on. Air comes from the instrument panel

outlets and floor outlets. A slight amount of air is directed through the defrost and side window demister outlets.

NOTE:

Bi-Level mode is designed under comfort conditions to provide cooler air out of the panel outlets and warmer air from the

floor outlets.

Icon

Description

GETTING TO KNOW YOUR VEHICLE

Controlling The Rear Climate Controls From

The Front Panel Controls

The rear Manual Climate Control system has

floor air outlets at the rear right side of the third

row seats and overhead outlets at each

outboard rear seating position. The system

provides heated air through the floor outlets or

cool, dehumidified air through the headliner

outlets.

The rear system temperature control buttons on

the faceplate are located below the radio

system, located on the instrument panel.

Floor Mode

Floor Mode Button

Push button to select Floor Mode. The indicator illuminates when this mode is on. Air comes from the floor outlets. A slight

amount of air is directed through the defrost and side window demister outlets.

Mix Mode

Mix Mode Button

Push button to select Mix Mode. The indicator illuminates when this mode is on. Air is directed through the floor, defrost,

and side window demister outlets. This setting works best in cold or snowy conditions that require extra heat to the

windshield. This setting is good for maintaining comfort while reducing moisture on the windshield.

Icon

Description

GETTING TO KNOW YOUR VEHICLE

Rear Manual Temperature Control

The Three-Zone climate control system allows

for adjustment of the rear climate controls from

the rear MTC panel.

Icon

Description

Rear Blower Control — If Equipped

Use this control to regulate the amount of air forced through the rear system in any mode you select. The rear blower speed

increases as you move the control to the right from the O (off) position. There are seven blower speeds. To allow the rear

overhead control, turn the knob fully to the left, past the O (off) position into the REAR control position.
Rear Temperature Control — If Equipped

Provides temperature control for the rear cabin. Turn left for cooler or right for warmer temperature settings in the rear

cabin.

GETTING TO KNOW YOUR VEHICLE

Icon

Description

Panel Mode

Rear Panel Mode

To change Rear Mode to Panel Mode, turn the Rear Mode Knob to Rear Panel Mode position. Air comes from the outlets in

the headliner. Each of these outlets can be individually adjusted to direct the flow of air. Moving the air vanes of the outlets

to one side will shut off the airflow.

Bi-Level Mode

Rear Bi-Level Mode

Air comes from both the headliner outlets and the floor outlets.

NOTE:

To change Rear Mode to Bi-Level Mode, turn the Rear Mode Knob to Rear Bi-Level Mode position. In many temperature

positions, the Bi-Level mode is designed to provide cooler air out of the headliner outlets and warmer air from the floor outlets.

Floor Mode

Rear Floor Mode

To change Rear Mode to Floor Mode, turn the Rear Mode Knob to Rear Floor Mode position. Air comes from the floor outlets.

Rear Temperature Control Knob

To change the temperature in the rear of the vehicle, turn the Temperature Control Knob. Turn it to the right to raise the

temperature, or turn it to the left to lower the temperature. The rear temperature settings are displayed in control head.

When rear controls are locked by the front system, the Rear Temperature Lock symbol on the control head is illuminated and

any rear overhead adjustments are ignored.
Rear Blower Control Knob

The rear blower control can be manually set to off, or any fixed blower speed by rotating the Blower Control Knob in the rear

of the vehicle. This allows the rear seat occupants to control the volume of air circulated in the rear of the vehicle.

GETTING TO KNOW YOUR VEHICLE

Automatic Climate Control Overview

Automatic Temperature Controls

Automatic Climate Control Descriptions

Icon

Description

A/C Button

Push the A/C button to engage the Air Conditioning (A/C). An LED will illuminate when the A/C system is engaged.

Automatic Operation

Automatically controls the interior cabin temperature by adjusting airflow distribution and amount. Toggling this function

will cause the system to switch between manual mode and automatic modes. Refer to “Automatic Operation” within this

section for more information.

GETTING TO KNOW YOUR VEHICLE

Recirculation Button

Press and release this button to change the system between recirculation mode and outside air mode. Recirculation can

be used when outside conditions such as smoke, odors, or high humidity are present. Recirculation can be used in all

modes except for Defrost. Recirculation may be unavailable (button on the touchscreen greyed out) if conditions exist that

could create fogging on the inside of the windshield. The A/C can be deselected manually without disturbing the mode

control selection. Continuous use of the Recirculation mode may make the inside air stuffy and window fogging may occur.

Extended use of this mode is not recommended.
Rear Climate Control Button

Push the Rear Climate Control Button to control rear compartment climate from the Front ATC Panel. The rear climate

modes will be displayed on the Front Automatic Temperature Control (ATC) Panel Rear Control Display.
Rear Defrost Button

Push and release the Rear Defrost Control button to turn on the rear window defroster and the heated outside mirrors

(if equipped). An indicator will illuminate when the rear window defroster is on. The rear window defroster automatically

turns off after 15 minutes.

Driver and Passenger Temperature Up And Down Buttons

Provides the driver and passenger with independent temperature control. Push the up arrow button for warmer

temperature settings. Push the blue arrow button for cooler temperature settings.

Icon

Description

GETTING TO KNOW YOUR VEHICLE

Blower Control

There are seven blower speeds. Use this control to regulate the amount of air forced through the system in any mode you

select. The blower speed increases as you move the control clockwise from the off position.

NOTE:

Depending on the configuration, your vehicle may be equipped with four blower speeds.
Modes Control Button

Toggle the Modes Control Button to adjust airflow distribution. The airflow distribution mode can be adjusted so air comes

from the instrument panel outlets, floor outlets, defrost outlets and demist outlets. The Mode settings are as follows:

Panel Mode

Toggle the Modes Control Button until you see Panel Mode Icon on the display. Air comes from the outlets in the instrument

panel. Each of these outlets can be individually adjusted to direct the flow of air. The air vanes of the center outlets and

outboard outlets can be moved up and down or side to side to regulate airflow direction.

Bi-Level Mode

Toggle the Modes Control Button until you see Bi-Level Mode Icon on the display. Air comes from the instrument panel

outlets and floor outlets. A slight amount of air is directed through the defrost and side window demister outlets.

NOTE:

Bi-Level mode is designed under comfort conditions to provide cooler air out of the panel outlets and warmer air from the

floor outlets.

Floor Mode

Toggle the Modes Control Button until you see Floor Mode Icon on the display. Air comes from the floor outlets. A slight

amount of air is directed through the defrost and side window demister outlets.

Icon

Description

GETTING TO KNOW YOUR VEHICLE

Controlling The Rear Climate Controls From

The Front ATC Panel

The rear ATC system has floor air outlets at the

rear right side of the third row seats and

overhead outlets at each outboard rear seating

position. The system provides heated air

through the floor outlets or cool, dehumidified

air through the headliner outlets. The rear

system temperature control buttons are located

in the Uconnect system, located on the

instrument panel.

Front ATC Panel Rear Control Display

Mix Mode

Toggle the Modes Control Button until you see Mix Mode Icon on the display. Air is directed through the floor, defrost, and

side window demister outlets. This setting works best in cold or snowy conditions that require extra heat to the windshield.

This setting is good for maintaining comfort while reducing moisture on the windshield.

Front Defrost Mode

Front Defrost Mode Button

Push the button to select Front Defrost Mode. The indicator illuminates when this mode is on. Air comes from the

windshield and side window demist outlets. When the defrost mode is selected, the blower level will increase. Use Defrost

mode with maximum temperature settings for best windshield and side window defrosting and defogging.

Icon

Description

GETTING TO KNOW YOUR VEHICLE

Icon

Description

Rear Lock Button

Press to lock out the rear manual temperature controls from adjusting the rear temperature and blower settings.

Rear Passenger Temperature Up and Down Buttons

Provides the rear passengers with independent temperature control. Push the up arrow button to increase the

temperature. Push the down arrow button to decrease the temperature. When the SYNC feature is active, the rear

temperature and the front passenger’s temperature will move up and down with the driver’s temperature.

SYNC Button — If Equipped

Press the SYNC button to toggle the Sync feature on/off. The SYNC indicator is illuminated when this feature is enabled.

SYNC is used to synchronize the front and rear passenger temperature settings with the driver temperature setting.

Changing the front or rear passenger temperature setting while in SYNC will automatically exit this feature.
Rear Blower Control

Turn the Blower Control Knob clockwise or counter clockwise to adjust blower speed. There are seven blower speeds. Use

this control to regulate the amount of air forced through the system in any mode you select in Rear Compartment. The

blower speed increases as you move the control clockwise from the off position.

Panel Mode

Rear Panel Mode

Toggle the Modes Control Button until Rear Panel Mode appears on the display. Air comes from the outlets in the headliner.

Each of these outlets can be individually adjusted to direct the flow of air. Moving the air vanes of the outlets to one side

will shut off the airflow.

GETTING TO KNOW YOUR VEHICLE

Rear Automatic Temperature Control (ATC) —

If Equipped

The Three-Zone ATC system allows for

adjustment of the rear climate controls from the

front ATC panel. To change the rear system

settings:



Press the REAR button to change control to

rear control mode, Rear display will appear.

Control functions now operate rear system.



To return to Front screen, press the REAR

button again, or it will revert to the Front

screen after six seconds.

Rear ATC Control Features

1. Adjust the Rear Blower, Rear Temperature

and the Rear Modes to suit your comfort

needs.

2. ATC is selected by pushing the AUTO button.

Once the desired temperature is displayed, the

ATC System will automatically achieve and

maintain that comfort level. When the system is

set up for your comfort level, it is not necessary

to change the settings. You will experience the

greatest efficiency by simply allowing the

system to function automatically.

Bi-Level Mode

Rear Bi-Level Mode

Toggle the Modes Control Button until the Rear Bi-Level Mode appears on the display. Air comes from both the headliner

outlets and the floor outlets.

NOTE:

In many temperature positions, the Bi-Level mode is designed to provide cooler air out of the headliner outlets and warmer

air from the floor outlets.

Floor Mode

Rear Floor Mode

Toggle the Modes Control Button until the Rear Floor Mode appears on the display. Air comes from the floor vents.

Icon

Description

GETTING TO KNOW YOUR VEHICLE

NOTE:

It is not necessary to move the temperature settings. The system automatically adjusts the temperature, mode and fan speed to provide comfort as

quickly as possible.

Icon

Description

Rear Mode Control Knob

Rotate knob to change the air distribution mode for the rear passengers to one of the following:

Panel Mode

Rear Panel Mode

Air comes from the outlets in the headliner. Each of these outlets can be individually adjusted to direct the flow of air.

Moving the air vanes of the outlets to one side will shut off the airflow.

Bi-Level Mode

Rear Bi-Level Mode

Air comes from both the headliner outlets and the floor outlets.

NOTE:

In many temperature positions, the Bi-Level mode is designed to provide cooler air out of the headliner outlets and warmer

air from the floor outlets.

Floor Mode

Rear Floor Mode

Air comes from the floor outlets.

Content .. 1 2 3 4 ..
