130

CITROËN Connect Nav

artist, Madonna", "play song, Hey Jude", or "play

album, Thriller".

Media voice commands are available

only with a USB connection.

"Telephone" voice

commands

If there is no telephone connected by

Bluetooth, a voice message announces:

"Please first connect a telephone", and the

voice session will be closed.

Voice commands



Call contact <...>

*

Dial <…>

*

Display contacts

*

Display calls

*

Call (message box | voicemail)

*

Help messages



To make a phone call, say "call" followed by

the contact name, for example: "Call David

Miller". You can also include the phone type, for

example: "Call David Miller at home". To make

a call by number, say "dial" followed by the

* This function is available only if the telephone connected to the system supports downloading of contacts and recent calls and the corresponding

download has been performed.

** This function is available only if the telephone connected to the system supports downloading of contacts and recent calls and the corresponding

download has been performed.

phone number, for example, "Dial 107776 835

417". You can check your voicemail by saying

"call voicemail". To send a text, say "send quick

message to", followed by the contact, and then

the name of the quick message you'd like to

send. For example, "send quick message to

David Miller, I'll be late". To display the list of

calls, say "display calls". For more information on

SMS, you can say "help with texting".

"Text message" voice

commands

If there is no telephone connected by

Bluetooth, a voice message announces:

"Please first connect a telephone", and the

voice session will be closed.

Voice commands



Send text to <...>

Listen to most recent message

**

Help messages



To hear your messages, you can say "listen to

most recent message". When you want to send

a text, there's a set of quick messages ready for

you to use. Just use the quick message name

and say something like "send quick message to

Bill Carter, I'll be late". Check the phone menu

for the names of the supported messages.

Please say "call" or "send quick message to",

and then select a line from the list. To move

around a list shown on the display, you can

say "go to start", "go to end", "next page" or

"previous page". To undo your selection, say

"undo". To cancel the current action and start

again, say "cancel".

The system only sends pre-recorded

"Quick messages".

Navigation

Choice of a destination

To a new destination

Press

Navigation

 to display the main

page.

Press the "

MENU

" button to access the

secondary page.

Select "

Enter address

".

Select the "

Country

".

131

CITROËN Connect Nav

12

Enter the "

City

", the "

Street

" and the

"

Number

", and confirm by pressing on

the displayed suggestions.

Press "

OK

" to select the "

Guidance

criteria

".

And/or

Select "

See on map

" to choose the

"

Guidance criteria

".

Press "

OK

" to start guided navigation.

Zoom in/out using the touch buttons or

with two fingers on the screen.

In order to be able to use the navigation

function, you must enter the "

City

", the

"

Street

" and the "

Number

" on the virtual

keyboard, or select them from the list in

"

Contact

" or in the address "

History

".

If you do not enter the street number, you

will be guided to one end of the street.

To a recent destination

Press

Navigation

 to display the main

page.

Press the "

MENU

" button to access the

secondary page.

Select "

My destinations

".

Select the "

Recent

” tab.

Select the chosen address from the list to display

the "

Guidance criteria

”.

Press "

OK

" to start guided navigation.

Select "

Position

" to see the point of

arrival on the map.

To "My home" or "My work"

Press

Navigation

 to display the main

page.

Press the "

MENU

" button to access the

secondary page.

Select "

My destinations

".

Select the "

Preferred

” tab.

Select "

My home

".

Or

Select "

My work

".

Or

Select a preset favourite destination.

To a contact

Press

Navigation

 to display the main

page.

Press the "

MENU

" button to access the

secondary page.

Select "

My destinations

".

Select the "

Contact

” tab.

Select a contact in the list to start guided

navigation.

To points of interest (POI)

Points of interest (POI) are listed in different

categories.

Press

Navigation

 to display the main

page.

Press the "

MENU

" button to access the

secondary page.

Select "

Points of interest

".

Select the "

Travel

", "

leisure

",

"

Commercial

", "

Public

" or "

Geographic

”

tab.

Or

Select "

Search

" to enter the name and

address of a POI.

Press "

OK

" to calculate the route.

To a point on the map

Press

Navigation

 to display the main

page.

Explore the map by sliding your finger across the

screen.

Select the destination by pressing on the map.

Tap the screen to place a marker and

display the sub-menu.

Press this button to start guided

navigation.

Or

132

CITROËN Connect Nav

Press this button to save the displayed

address.

Pressing and holding on a point opens a

list of nearby POIs.

To GPS coordinates

Press

Navigation

 to display the main

page.

Explore the map by sliding your finger across the

screen.

Press this button to display the world

map.

Using the grid, select the desired country or

region by zooming in.

Press this button to enter the GPS

coordinates.

A marker is displayed in the middle of the

screen, with the "

Latitude

" and

"

Longitude

" coordinates.

Press this button to start guided

navigation.

Or

Press this button to save the displayed

address.

OR

Press this button to enter the "

Latitude

"

value using the virtual keypad.

And

Press this button to enter the "

Longitude

"

value using the virtual keypad.

TMC (Traffic Message

Channel)

TMC (Traffic Message Channel)

messages are linked to a European

standard on the broadcasting of traffic

information via the RDS system on FM radio,

transmitting traffic information in real time.

The TMC information is then displayed on a

GPS Navigation system map and taken into

account straight away during navigation, so

as to avoid accidents, traffic jams and closed

roads.

The display of danger zones depends on

the legislation in force and subscription

to the service.

Connected navigation

Depending on version

Depending on the equipment level of the vehicle

Network connection provided by the

vehicle





OR

Network connection provided by the

user





Connected navigation

connection

As a safety measure and because it

requires sustained attention by the driver,

using a smartphone when driving is

prohibited.

All operations must be done with the

vehicle

stationary

.

For access to connected navigation, you

can use the connection provided by the

vehicle via the "Emergency or assistance call"

services or use your smartphone as a

modem.

Activate and enter settings for sharing the

smartphone connection.

Network connection provided by the

vehicle

The system is automatically connected to

the modem included for the "Emergency

or assistance calls" services and does not

require a connection provided by the user via

their smartphone.

133

CITROËN Connect Nav

12

Network connection provided by the

user

USB connection

Connect a USB cable.

The smartphone charges when

connected by a USB cable.

Bluetooth connection

Activate the Bluetooth function on the

telephone and ensure that it is visible to

all (see the "Applications" section).

Wi-Fi connection

Select a Wi-Fi network found by the

system and connect to it (see the

"Applications" section).

Restrictions of use:

–  With CarPlay

®

, connection sharing is

only with a Wi-Fi connection.

–  With MirrorLink

TM

, connection sharing is

only with a USB connection.

The quality of services depends on the quality

of the network connection.

With the arrival of "TOMTOM TRAFFIC",

the services are available.

The services offered with connected

navigation are as follows.

A Connected Services pack:

– Weather,

–  Filling stations,

–  Car park,

–  Traffic,

–  POI local search.

A Danger zone pack (option).

The processes and standards are

constantly changing; for the

communication process between the

smartphone and the system to work correctly,

we recommend that you

update the

operating system of the smartphone as

well as the date and time of the

smartphone and the system.

Settings specific to

connected navigation

In the "Settings" menu, you can create a

profile for an individual or for a group of

people with shared interests, and configure a

wide range of settings (radio presets, audio

settings, navigation history, favourite contacts,

etc.). Settings are applied automatically.

Press

Navigation

 to display the main

page.

Press the "

MENU

" button to access the

secondary page.

Select "

Settings

".

Select "

Map

".

Activate or deactivate:

– "

Allow declaration of danger zones

".

– “

Guidance to final destination on foot

"

– “

Authorize sending information

"

These settings must be configured for each

profile.

Select "

Alerts

".

Activate or deactivate “

Warn of danger

zones

”.

Select this button.

Activate:

Give an audible warning



For access to connected navigation, you

must tick the option: "

Authorize sending

information

"

Danger zone alerts may or may not be

displayed, depending on the applicable

legislation and subscription to the

corresponding service.

Declaration of "Danger

zones"

To send information on the declaration

of danger zones, you must tick the

option: "

Allow declaration of danger zones

"

Press

Navigation

 to display the main

page.

Press the "

Declare a new danger zone

"

button located in the upper bar on the

touch screen

Select the "

Type

” option to select the type

of "Danger area".

134

CITROËN Connect Nav

Select the "

Speed

" option and enter it

using the virtual keypad.

Press "

OK

" to save and send the

information.

"Danger zones" pack

updates

Press

Settings

 to display the primary

page.

Press the "

OPTIONS

" button to go to the

secondary page.

Select "

System administration

".

Select the "

System info

" tab.

Select "

View

" to display the versions of

the different modules installed in the

system.

Select "

Update(s) due

".

You can download the system and map

updates from the Brand’s website.

The update procedure can also be found on

the website.

Displaying weather

information

Press

Navigation

 to display the main

page.

Press this button to display the list of

services.

Select "

View map

".

Select "

Weather

".

Press this button to display basic

information.

Press this button to display detailed

weather information.

The temperature displayed at 6 a.m. will

be the maximum temperature for the day.

The temperature displayed at 6 p.m. will be

the minimum temperature for the night.

Applications

Internet Browser

Press

Applications

 to display the main

page.

Press "

Connectivity

" to access the "

Internet

Browser

” function.

Press "

Internet Browser

" to display the browser

home page.

Select your country of residence.

Press "

OK

" to save and start the browser.

Connection to the internet is via one of

the network connections provided by the

vehicle or the user.

Connectivity

Press

Applications

 to display the main

page.

Press "

Connectivity

" to access the

CarPlay

®

,

MirrorLink

TM

 or

Android Auto

 functions.

Applications

Press

Applications

 to display the main

page.

Press "

Applications

" to display the applications

home page.

CarPlay

®

 smartphone

connection

As a safety measure and because it

requires sustained attention by the driver,

using a smartphone when driving is

prohibited.

All operations must be done with the

vehicle

stationary

.

Smartphone synchronisation allows

users to display smartphone applications

compatible with the CarPlay

®

 technology on

the vehicle’s screen, provided that the

smartphone's CarPlay

®

 function has

previously been activated.

As processes and standards are constantly

changing,

we recommend updating your

smartphone's operating system

.

135

CITROËN Connect Nav

12

For the list of compatible smartphones, visit

the vehicle brand's website in your country.

Connect the USB cable. The smartphone

charges when connected by the USB

cable.

Press "

Telephone

" to display the

CarPlay

®

 interface.

Or

Connect the USB cable. The smartphone

charges when connected by the USB

cable.

From the system, press "

Applications

" to

display the main page.

Press "

Connectivity

" to access the "CarPlay

®

”

function.

Press "

CarPlay

" to display the CarPlay

®



interface.

On connecting the USB cable, the

CarPlay

®

 function deactivates the

system's Bluetooth

®

 mode.

MirrorLink

TM

 smartphone

connection

As a safety measure and because it

requires sustained attention by the driver,

using a smartphone when driving is

prohibited.

All operations must be done with the

vehicle

stationary

.

Smartphone synchronisation allows

users to display smartphone applications

compatible with the MirrorLink

TM

 technology

on the vehicle’s screen.

Processes and standards are constantly

changing. The communication process

between the smartphone and the system

requires the smartphone to be unlocked;

update the smartphone's operating system

and the date and time on the smartphone

and in the system

.

For the list of compatible smartphones, visit

the vehicle brand's website in your country.

As a safety measure, applications can

only be viewed with the vehicle

stationary; display is interrupted once the

vehicle is moving.

The "

MirrorLink

TM

" function requires the

use of a compatible smartphone and

compatible applications.

When connecting a smartphone to the

system, we recommend enabling

Bluetooth

®

 on the smartphone.

Connect the USB cable. The smartphone

charges when connected by the USB

cable.

From the system, press "

Applications

" to

display the main page.

Press "

Connectivity

" to access the

"MirrorLink

TM

” function.

Press "

MirrorLink

TM

" to start the

application in the system.

Depending on the smartphone, it may be

necessary to activate the "

MirrorLink

TM

"

function.

During the procedure, several screen

pages relating to certain features are

displayed.

Accept to start and complete the connection.

Once the connection is established, a page

is displayed with the applications already

downloaded to your smartphone which are

compatible with the MirrorLink

TM

 technology.

Access to the different audio sources remains

available in the margin of the MirrorLink

TM



display, using the touch buttons located in the

upper bar.

Access to the menus for the system is possible

at any time using the dedicated buttons.

There may be a wait for the availability of

applications, depending on the quality of

your network.

Android Auto smartphone

connection

As a safety measure and because it

requires sustained attention by the driver,

using a smartphone when driving is

prohibited.

All operations must be done with the

vehicle

stationary

.

136

CITROËN Connect Nav

Synchronising a smartphone allows

users to display applications compatible

with the smartphone's Android Auto

technology on the vehicle screen.

Processes and standards are constantly

changing. The communication process

between the smartphone and the system

requires the smartphone to be unlocked;

update the smartphone's operating system

and the date and time on the smartphone

and in the system

.

For the list of compatible smartphones, visit

the vehicle brand's website in your country.

As a safety measure, applications can

only be viewed with the vehicle

stationary; display is interrupted once the

vehicle is moving.

The "

Android Auto

" function requires

the use of a compatible smartphone and

compatible applications.

Connect the USB cable. The smartphone

charges when connected by the USB

cable.

From the system, press "

Applications

" to

display the main page.

Press "

Connectivity

" to access the "Android

Auto” function.

Press "

Android Auto

" to start the

application in the system.

During the procedure, several screen

pages relating to certain features are

displayed.

Accept to start and complete the connection.

Access to the different audio sources remains

available in the margin of the Android Auto

display, using the touch buttons located in the

upper bar.

Access to the menus for the system is possible

at any time using the dedicated buttons.

In Android Auto mode, the function that

displays rolling menus by briefly pressing

the screen with three fingers is disabled.

There may be a wait for the availability of

applications, depending on the quality of

your network.

Bluetooth connection

®

As a safety measure and because they

require prolonged attention on the part of

the driver, the operations for pairing of the

Bluetooth mobile telephone with the Bluetooth

hands-free system of your audio system must

be carried out with the

vehicle stationary



and the ignition on.

Activate the Bluetooth function on the

telephone and ensure that it is "visible to

all" (telephone configuration).

Procedure from the telephone

Select the system name in the list of

devices detected.

In the system, accept the connection request

from the telephone.

To complete the pairing, whichever

procedure used (from the telephone or

from the system), ensure that the code is the

same in the system and in the telephone.

Procedure from the system

Press

Connect-App

 to display the main

page.

Press the "

OPTIONS

" button to go to the

secondary page.

Press on "

Bluetooth connection

".

Select "

Search

".

The list of telephones detected is

displayed.

If the pairing procedure fails, we

recommend deactivating and then

reactivating the Bluetooth function on your

telephone.

Select the name of the chosen telephone

in the list.

Depending on the type of telephone, you

may be prompted to accept (or decline)

the transfer of your contacts and messages.

137

CITROËN Connect Nav

12

Connection sharing

The system offers to connect the telephone with

3 profiles:

– "

Telephone

" (hands-free kit, telephone only),

– "

Streaming

" (streaming: wireless playing of

the audio files on the telephone),

– "

Mobile internet data

".

The "

Mobile internet data

" profile must

be activated for connected navigation

(where the vehicle does not have "Emergency

and assistance call" services), having first

activated sharing of this connection on your

smartphone.

Select one or more profiles.



Press "

OK

" to confirm.



Wi-Fi connection

Network connection via the smartphone's Wi-Fi.

Press

Connect-App

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Wi-Fi network connection

".

Select the "

Secured

", "

Not secured

" or

"

Stored

” tab.

Select a network.

Using the virtual keypad , enter the Wi-Fi

network "

Key

" and "

Password

".

Press "

OK

" to establish the connection.

The Wi-Fi connection and Wi-Fi

connection sharing are exclusive.

Wi-Fi connection sharing

Creation of a local Wi-Fi network by the system.

Press

Connect-App

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Share Wi-Fi connection

".

Select the "

Activation

" tab to activate or

deactivate Wi-Fi connection sharing.

And/or

Select the "

Settings

" tab to change the system’s

network name and password.

Press "

OK

" to confirm.



To protect against unauthorised access

and to make your systems as secure as

possible, we recommend using a complex

password or security code.

Managing connections

Press

Connect-App

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Manage connection

".

With this function, you can view the access to

connected services, check the availability of

connected services and change the connection

mode.

Radio

Selecting a station

Press

Radio Media

 to display the main

page.

Press on "

Frequency

".

Press one of the buttons to perform an

automatic search for radio stations.

Or

Move the slider to manually search for

frequencies up or down.

Or

Press

Radio Media

 to display the main

page.

Press the "

OPTIONS

" button to go to the

secondary page.

Select "

Radio stations

" on the secondary

page.

Press on "

Frequency

".

Enter the values using the virtual keypad.

First enter the units then click on the

decimals field to enter the figures after the

decimal point.

138

CITROËN Connect Nav

Press "

OK

" to confirm.



Radio reception may be affected by the

use of electrical equipment not approved

by the Brand, such as a USB charger

connected to the 12 V socket.

The exterior environment (hills, buildings,

tunnels, basement car parks, etc.) may

block reception, including in RDS mode.

This phenomenon is perfectly normal in the

context of radio wave transmission, and

in no way indicative of an audio system

malfunction.

Presetting a station

Select a radio station or frequency.

(refer to the corresponding section)

Press "

Presets

".

Make a long press on one of the buttons

to preset the station.

Activating/Deactivating RDS

Press

Radio Media

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Radio settings

".

Select "

General

".

Activate/deactivate "

Station follow

".

Press "

OK

" to confirm.



RDS, if activated, allows you to continue

listening to the same station by

automatically retuning to alternative

frequencies. However, in certain conditions,

RDS station tracking may not be possible

nationwide, as radio stations do not always

cover the entire country. This can explain the

loss of reception of a station during a journey.

Displaying text information

The "Radio Text" function displays

information transmitted by the radio

station relating to the station or the currently

playing song.

Press

Radio Media

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Radio settings

".

Select "

General

".

Activate/deactivate "

Display radio text

".

Press "

OK

" to confirm.



Play TA messages

The TA (Traffic Announcement) function

gives priority to TA alert messages. To

operate, this function needs good reception of

a radio station that carries this type of

message. While traffic information is being

broadcast, the current media is automatically

interrupted so that the TA message can be

heard. Normal play of the media previously

playing is resumed at the end of the

message.

Select "

Announcements

".

Activate / Deactivate "

Traffic

announcement

".

Press "

OK

" to confirm.



DAB (Digital Audio

Broadcasting) radio

Terrestrial Digital Radio

Digital radio provides higher quality

reception.

The various "multiplexes/ensembles" offer

a choice of radio stations organised in

alphabetical order.

Press

Radio Media

 to display the main

page.

139

CITROËN Connect Nav

12

Select the audio source.

Press "

Band

" to select the "

DAB

" waveband.

FM-DAB tracking

“DAB" does not cover 100% of the

country.

When the digital radio signal is poor,

“FM-DAB  auto tracking" enables you to

continue listening to the same station by

automatically switching to the corresponding

FM analogue station (if there is one).

Press

Radio Media

 to display the main

page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Radio settings

".

Select "

General

".

Activate/deactivate "

Station follow

".

Press on "

OK

".

If “FM-DAB auto tracking" is activated,

there may be a time lag of a few seconds

when the system switches to "FM" analogue

radio, and in some cases a change in volume.

When the digital signal quality is restored, the

system automatically changes back to "DAB".

If the "DAB" station being listened to is

not available on “FM” (“

FM-DAB

" greyed

out), or "FM-DAB auto tracking" is not

activated, the sound will cut out while the

digital signal is too weak.

Media

USB socket

Insert the USB memory stick into the USB

socket or connect the USB device to the

USB socket using a suitable cable (not supplied).

To protect the system, do not use a USB

hub.

The system builds playlists (in temporary

memory); this operation can take from a

few seconds to several minutes at the first

connection.

Reduce the number of non-music files and the

number of folders to reduce the waiting time.

The playlists are updated every time the ignition

is switched off or a USB memory stick is

connected. The lists are memorised: if they are

not modified, the subsequent loading time will

be shorter.

Auxiliary socket (AUX)

(depending on model / depending on equipment)

Connect a portable device (MP3 player,

etc.) to the auxiliary jack socket using an

audio cable (not supplied).

This source is only available if "Auxiliary input"

has been selected in the audio settings.

First adjust the volume on your portable device

(to a high level). Then adjust the volume on your

audio system.

Controls are managed via the portable device.

CD player

(depending on model / depending on equipment)

Insert the CD in the player.

Selecting the source

Press

Radio Media

 to display the main

page.

Select "

Source

".

Select the source.

Bluetooth

®

 audio streaming

Streaming allows you to listen to music from your

smartphone.

The Bluetooth profile must be activated, first

adjust the volume on your portable device (to a

high level).

Then adjust the volume of your audio system.

If play does not start automatically, it may be

necessary to start the audio playback from the

telephone.

Control is from the portable device or by using

the system's touch buttons.

140

CITROËN Connect Nav

Once connected in streaming mode, the

telephone is considered to be a media

source.

Connecting Apple

®

 players

Connect the Apple

®

 player to the USB port using

a suitable cable (not supplied).

Play starts automatically.

Control is via the audio system.

The classifications available are those of

the portable device connected (artists /

albums / genres / playlists / audiobooks /

podcasts).

The default classification used is by artists.

To modify the classification used, return to the

first level of the menu then select the desired

classification (playlists for example) and

confirm to go down through the menu to the

desired track.

The version of software in the audio system may

not be compatible with the generation of your

Apple

 ®

 player.

Information and advice

The system supports USB mass storage

devices, BlackBerry

®

 devices or Apple

®



players via USB ports. The adapter cable is

not supplied.

Device management is done by the audio

system controls.

Other peripherals, not recognised on

connection, must be connected to the

auxiliary socket using a Jack cable (not

supplied) or via Bluetooth streaming,

depending on compatibility.

To protect the system, do not use a USB

hub.

The audio equipment will only play audio files

with ".wma", ".aac", ".flac", ".ogg" and ".mp3"

file extensions and with a bit rate of between 32

Kbps and 320 Kbps.

It also supports VBR (Variable Bit Rate) mode.

No other file types (".mp4", etc.) can be read.

Files of the ".wma" type should be to the wma 9

standard.

The sampling rates supported are 32, 44 and

48 kHz.

It is advisable to restrict file names to 20

characters, without using special characters (e.g.

" " ? . ; ù) so as to avoid any reading or display

problems.

Use only USB keys in FAT32 format (File

Allocation Table).

It is recommended that the original USB

cable for the portable device is used.

In order to be able to play a burned CDR or

CDRW, select standards ISO 9660 level 1, 2 or

Joliet if possible when burning the CD.

If the disc is burned in another format, it may not

be played correctly.

It is recommended that the same burning

standard is always used on an individual disc,

with the lowest speed possible (4x maximum) for

the best acoustic quality.

In the particular case of a multi-session CD, the

Joliet standard is recommended.

Telephone

Pairing a Bluetooth

®



telephone

As a safety measure and because it

requires sustained attention by the driver,

the pairing of a Bluetooth mobile telephone

with the Bluetooth hands-free system of your

audio system must be done with the

vehicle

stationary

 and the ignition on.

Activate the Bluetooth function on the

telephone and ensure that it is "visible to

all" (telephone configuration).

Procedure from the telephone

Select the system name in the list of

devices detected.

In the system, accept the connection request

from the telephone.

To complete the pairing, whichever

procedure used (from the telephone or

141

CITROËN Connect Nav

12

from the system), ensure that the code is the

same in the system and in the telephone.

Procedure from the system

Press

Telephone

 to display the main

page.

Press "

Bluetooth search

".

Or

Select "

Search

".

The list of telephones detected is

displayed.

If the pairing procedure fails, we

recommend deactivating and then

reactivating the Bluetooth function on your

telephone.

Select the name of the chosen telephone

in the list.

Connection sharing

The system offers to connect the telephone with

3 profiles:

– "

Telephone

" (hands-free kit, telephone only),

– "

Streaming

" (streaming: wireless playing of

the audio files on the telephone),

– "

Mobile internet data

".

Activation of the profile; "

Mobile internet

data

" is obligatory for connected

navigation having first activated sharing of

this connection on your smartphone.

Select one or more profiles.



Press "

OK

" to confirm.



Depending on the type of telephone, you

may be asked to accept or not the

transfer of your contacts and messages.

Automatic reconnection

On return to the vehicle, if the last

telephone connected is present again, it

is automatically recognised and within about

30 seconds of switching on the ignition, the

pairing is established without any action on

your part (with Bluetooth activated).

To modify the connection profile:

Press

Telephone

 to display the main

page.

Press the "

OPTIONS

" button to go to the

secondary page.

Select "

Bluetooth connection

" to display

the list of paired devices.

Press the "Details" button.

Select one or more profiles.



Press "

OK

" to confirm.



The ability of the system to connect just

one profile depends on the telephone.

By default, all three profiles are able to

connect.

The services available depend on the

network, the SIM card and the

compatibility of the Bluetooth devices used.

Refer to your telephone’s user guide and your

service provider to check which services you

are able to access.

The system supports the following

profiles: HFP, OPP, PBAP, A2DP, AVRCP,

MAP and PAN.

Visit the Brand's website for more information

(compatibility, additional help, etc.).

Managing paired telephones

This function lets you connect or

disconnect a device or delete a pairing.

Press

Telephone

 to display the main

page.

Press the "

OPTIONS

" button to go to the

secondary page.

Select "

Bluetooth connection

" to display

the list of paired devices.

Press on the name of the telephone

selected in the list to disconnect it.

Press again to connect it.

142

CITROËN Connect Nav

Deleting a telephone

Select the basket at top right of the

screen to display a basket alongside the

telephone chosen.

Press the basket alongside the telephone

chosen to delete it.

Receiving a call

An incoming call is announced by a ring and a

superimposed display in the screen.

Make a short press on the steering

mounted

PHONE

 button to accept an

incoming call.

And

Make a long press

on the steering mounted

PHONE

 button

to reject the call.

Or

Select "

End call

".

Making a call

Using the telephone is not recommended

while driving.

Park the vehicle.

Make the call using the steering mounted

controls.

Calling a new number

Press

Telephone

 to display the main

page.

Enter the number using the digital

keypad.

Press "

Call

" to start the call.

Calling a contact

Press

Telephone

 to display the main

page.

Or press and hold

on the steering-mounted

TEL

 button.

Select "

Contact

".

Select the desired contact in the displayed list.

Select "

Call

".

Calling a recently used

number

Press

Telephone

 to display the main

page.

Or

Press and hold

on the steering-mounted button.

Select "

Calls

".

Select the desired contact in the displayed list.

It is always possible to make a call

directly from the telephone; as a safety

measure, first park the vehicle.

Managing contacts/entries

Press

Telephone

 to display the main

page.

Select "

Contact

".

Select "

Create

" to add a new contact.

In the "

Telephone

" tab, enter the telephone

numbers for the contact.

In the "

Address

" tab, enter the addresses for the

contact.

In the "

Email

" tab, enter the email addresses for

the contact.

The "

Email

" function allows email

addresses to be entered for a contact,

but the system is not able to send emails.

Managing messages

Press

Telephone

 to display the main

page.

Press the "

OPTIONS

" button to go to the

secondary page.

Select "

Messages

" to display the list of

messages.

Select the "

All

", "

Incoming

" or "

Sent

”

tab.

Select the details of the message chosen

in one of the lists.

143

CITROËN Connect Nav

12

Press "

Answer

" to send a quick message

stored in the system.

Press "

Call

" to start a call.

Press "

Play

" to listen to the message.

Access to "

Messages

" depends on the

compatibility between the smartphone

and the onboard system.

Depending on the smartphone, access to

your messages or email may be slow.

The services available depend on the

network, the SIM card and the

compatibility of the Bluetooth devices used.

Refer to your smartphone manual and your

service provider to check which services are

available to you.

Managing quick messages

Press

Telephone

 to display the main

page.

Press the "

OPTIONS

" button to go to the

secondary page.

Select "

Quick messages

" to display the

list of messages.

Select the "

Delayed

", "

My arrival

", "

Not

available

" or "

Other

" tab, enabling you to

create new messages.

Press "

Create

" to write a new message.

Select the message chosen in one of the

lists.

Press "

Transfer

" to select one or more

recipients.

Press "

Play

" to start playing the message.

Managing email

Press

Telephone

 to display the main

page.

Press the "

OPTIONS

" button to go to the

secondary page.

Select "

Email

" to display the list of

messages.

Select the "

Incoming

", "

Sent

" or "

Not

read

” tab.

Select the message chosen in one of the lists.

Press "

Play

" to start playing the message.

Access to "

Email

" depends on the

compatibility between the smartphone

and the onboard system.

Settings

Audio settings

Press

Settings

 to display the main page.

Select "

Audio settings

".

Select "

Ambience

".

Or

"

Position

".

Or

"

Sound

".

Or

"

Voice

".

Or

"

Ringtone

".

Press "

OK

" to save the settings.

The balance/distribution (or spatialisation

with the Arkamys

 system) uses audio

processing to adjust the sound quality

according to the number of passengers in the

vehicle.

Available only with the front and rear speaker

configuration.

The

Ambience

 setting (choice of 6

ambiances) as well as for

Bass

,

Medium



and

Treble

 are different and independent for

each audio source.

Activate or deactivate "

Loudness

".

The "

Position

” settings (All passengers,

Driver and Front only) are common to all

sources.

Activate or deactivate "

Touch tones

",

"

Volume linked to speed

" and "

Auxiliary

input

".

144

CITROËN Connect Nav

Onboard audio: Arkamys Sound Staging



optimises the sound balance/distribution

inside the passenger compartment.

Configuring profiles

As a safety measure and because it

requires the sustained attention of the

driver, the operations must only be done with

the

vehicle stationary

.

Press

Settings

 to display the main page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Setting of the profiles

".

Select "

Profile 1

", "

Profile 2

", "

Profile 3

” or

"

Common profile

".

Press this button to enter a name for the

profile using the virtual keypad.

Press "

OK

" to confirm.



Press this button to add a photograph to

the profile.

Insert a USB memory stick containing the

photograph in the USB socket.

Select the photograph.

Press "

OK

" to accept the transfer of the

photograph.

Press "

OK

" again to save the settings.

The location for the photograph is

square; the system reshapes the original

photograph if in another format.

Press this button to reset the selected

profile.

Resetting the selected profile activates

the English language by default.

Select a "

Profile

" (1 or 2 or 3) to link the "

Audio

settings

" with it.

Select "

Audio settings

".

Select "

Ambience

".

Or

"

Position

".

Or

"

Sound

".

Or

"

Voice

".

Or

"

Ringtone

".

Press "

OK

" to save the settings.

Modifying system settings

Press

Settings

 to display the main page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Screen configuration

".

Select "

Animation

".

Activate or deactivate: “

Automatic

scrolling

”.

Select "

Brightness

".

Move the slider to adjust the brightness of

the screen and/or the instrument panel.

Press

Settings

 to display the main page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

System settings

".

Select "

Units

" to change the units of distance,

fuel consumption and temperature.

Select "

Factory settings

" to restore the initial

settings.

Returning the system to factory settings

activates the English language by

default.

Select "

System info

" to display the versions of

the various modules installed in the system.

Selecting the language

Press

Settings

 to display the main page.

Press the "

OPTIONS

" button to go to the

secondary page.

Select "

Languages

" to change the

language.

145

CITROËN Connect Nav

12

Setting the date

Press

Settings

 to display the main page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Setting the time-date

".

Select "

Date

".

Press this button to set the date.

Press "

OK

" to confirm.



Select the display format for the date.

Time and date setting is only available if

"GPS synchronisation" is deactivated.

The change between winter and summer time

is made by changing the time zone.

Setting the time

Press

Settings

 to display the main page.

Press the "

OPTIONS

" button to access the

secondary page.

Select "

Setting the time-date

".

Select "

Time

".

Press this button to set the time using the

virtual keypad.

Press "

OK

" to confirm.



Press this button to set the time zone.

Select the display format for the time

(12h/24h).

Activate or deactivate GPS

synchronisation (UTC).

Press "

OK

" to confirm.



The system does not automatically

manage the change between winter and

summer time (depending on country).

Colour schemes

For safety reasons, the colour scheme

can only be changed while the

vehicle is

stationary

.

Press

Settings

 to display the main page.

Select "

Color schemes

".

Select a colour scheme in the list then

press "

OK

" to confirm.

Whenever the colour scheme is

changed, the system restarts, temporarily

displaying a black screen.

Frequently asked

questions

The following information groups together the

answers to the most frequently asked questions

concerning the system.

Navigation

I cannot enter the navigation address.

The address is not recognised.

►  Use the "intuitive method" by pressing

the "Search…" button at the bottom of the

"Navigation” page.

The route calculation is not successful.

The route settings may conflict with the current

location (for example, if toll roads are excluded

but the vehicle is on a toll road).

►  Check the route settings in the "Navigation"

menu.

I do not receive "Danger zone” alerts.

You have not subscribed to the online services

option.

►  If you have subscribed to the option:

- a few days may elapse before the service is

activated,

- services may not be selected in the system

menu,

- online services are not active ("TOMTOM

TRAFFIC" not shown on the map).

The POIs do not appear.

The POIs have not been selected.

►  Set the zoom level to 600 ft (200 m) or select

POIs in the POI list.
