146

Practical information

For a full charge, follow the desired charging

procedure without pausing it, until it ends

automatically. Charging can be either immediate

or deferred (except fast public charger, mode 4).

You can stop domestic or accelerated charging

at any time by unlocking the vehicle and

removing the nozzle. For superfast charging,

refer to the fast public charger.

For more information on the charging displays

on the

Instrument panel

 and the

Touch screen

,

refer to the corresponding section.

It is also possible to monitor the charging

progress using the

MyCitroën App



application.

For more information on

Remote functions

,

refer to the corresponding section.

As a safety measure, the engine will not

start if the charging cable is plugged into

the connector on the vehicle. A warning is

displayed on the instrument panel.

Cooling the traction battery

The cooling fan in the engine

compartment comes on during charging to

cool the on-board charger and the traction

battery.

Low load / Driving

Driving when the charge level of the

traction battery is too low can lead to the

vehicle breaking down and can lead to

accidents or serious injuries. ALWAYS make

sure the traction battery has a sufficient

charge level.

Low load / Parking

If the outside temperature is negative,

it is recommended not to park your vehicle

outside for several hours at a low load (less

than 20%).

Vehicle in storage for more than

1 month

In the event of a long period of non-use of

the vehicle (beyond 4 weeks) without the

possibility of charging when restarting, the

self-discharge may make it impossible to

restart if the traction battery charge level

is a low or very low, especially at negative

ambient temperatures. ALWAYS make sure

that the traction battery has a charge between

20% and 40% if you do not plan to use your

vehicle for several weeks.

Do not connect the charging cable.

Always park the vehicle in a place with

temperatures between -10°C and 30°C

(parking in a place with extreme temperatures

can damage the traction battery).

Disconnect the cable from the (+) terminal

of the accessory battery in the engine

compartment.

Connect a 12 V battery charger to the (+)

and (-) terminals of the accessory battery

about every 3 months in order to recharge the

accessory battery and maintain an operating

voltage.

Precautions

Our electric vehicles have been developed in

accordance with the recommendations on the

maximum limits for electromagnetic fields, as

issued by the International Commission on Non-

Ionizing Radiation Protection (ICNIRP - 1998

Guidelines).

Wearers of pacemakers or equivalent

devices

Ask your doctor about what precautions

you should take, or ask the manufacturer

of your implanted electro-medical device about

whether its operation is guaranteed in an

environment which complies with the ICNIRP

recommendations.

If in doubt

Domestic or accelerated charging

: do

not remain inside or near the vehicle, or near

the charging cable or charging unit, even for

a short time.

Superfast charging

: do not use the system

yourself and avoid approaching public fast

charging points. Leave the area and ask a

third party to recharge the vehicle.

147

Practical information

7

For domestic or accelerated charging

Before charging

Depending on the context:

►  Have a professional check that the

electrical system to be used complies with

applicable standards and is compatible with

the vehicle.

►  Have a professional electrician install

a dedicated domestic power socket or

accelerated charging unit (Wallbox)

compatible with the vehicle.

You should preferably use the charging cable

available as an accessory.

For more information, contact a CITROËN

dealer or a qualified workshop.

During charging

While charging is in progress, unlocking

the vehicle will cause the charging to stop.

If no action is taken on one of the openings

(door or boot) or on the charging nozzle, the

vehicle will lock again after 30 seconds and

charging will resume automatically.

Never work under the bonnet:

–  Some areas remain very hot, even an hour

after charging ends - risk of burns!

–  The fan may start at any time - risk of cuts

or strangulation!

After charging

Check that the charging flap is closed.

Do not leave the cable connected to the

domestic power socket - risk of short-circuit

or electrocution in the event of contact with or

immersion in water!

For superfast charging

Before charging

Check that the fast public charging

station and its charging cable are compatible

with the vehicle.

If the exterior temperature is below:

–  0°C, charging times may be extended.

–  -20°C, charging is still possible, but

charging times may be extended even further

(the battery has to be heated first).

After charging

Check that the charging flap is closed.

Connection

►  Before

charging, check that the drive selector

is in mode

P

, otherwise charging is not possible.

►  Open the charging flap by pressing the

push-button, and check that there are no foreign

bodies on the charging connector.

Domestic charging, mode 2









►  Connect the charging cable from the control

unit to the domestic socket.

When the connection is made, all of the indicator

lamps on the control unit light up, then only the

POWER

 indicator lamp remains on in green.

►  Remove the protective cover from the

charging nozzle.

►  Insert the nozzle into the charging connector.

The start of charging is confirmed by the flashing

green

CHARGE

 indicator lamps in the flap, then

those on the control unit.

If this is not the case, charging has not

started; restart the procedure, ensuring that all

connections are properly established.

The red indicator lamp in the flap comes on to

indicate that the nozzle is locked.

When charging is complete and while the

charging cable is still connected, opening

148

Practical information

the driver's door will display the charge level

on the instrument panel for about 20 seconds.

Accelerated charging, mode 3





►  Follow the accelerated charging unit

(Wallbox) user instructions.

►  Remove the protective cover from the

charging nozzle.

►  Insert the nozzle into the charging connector.

The start of charging is confirmed when the

charging indicator lamp in the flap flashes green.

If this is not the case, charging has not started;

restart the procedure, ensuring that the

connection has been properly established.

The red indicator lamp in the flap comes on to

indicate that the nozzle is locked.

Superfast charging, mode 4





►  Depending on version, remove the protective

cover from the lower part of the connector.

►  Follow the instructions for use of the fast

public charger and connect the cable from the

fast public charger to the vehicle's connector.

The start of charging is confirmed by the flashing

green charging indicator lamp in the flap.

If this is not the case, charging has not started;

restart the procedure, ensuring that the

connection is properly established.

The red indicator lamp in the flap comes on to

indicate that the nozzle is locked.

Deferred charging

Settings

At a CITROËN dealer or qualified

workshop, with touch screen BLUETOOTH

audio system

By default, the deferred charging start time is set

to midnight (vehicle time).

You can have the deferred charging start time

modified.

Visit a CITROËN dealer or a qualified workshop.

On a smartphone or tablet

You can programme the deferred

charging function at any time via the

MyCitroën App

 application.

For more information on

Remote functions

,

refer to the corresponding section.

In the vehicle, with 10-inch touch screen

►  In the

Energy

 touch screen menu,

select the

Charge

 page.

►  Set the charging start time.

►  Press

OK

.

The setting is saved in the system.

Activation

Deferred charging is only possible with

modes 2 and 3.

►  After programming the deferred charging,

connect your vehicle to the desired charging

equipment.





►  Press this button in the flap within one

minute to activate the system (confirmed by the

charging indicator lamp coming on in blue).

Disconnection





Before disconnecting the nozzle from the

charging connector:

►  If the vehicle is unlocked,

lock it and then

unlock it

.

►  If the vehicle is locked, unlock it.

The red indicator lamp in the flap goes out to

confirm that the charging nozzle is unlocked.

149

Practical information

7

►  Within

30 seconds

, remove the charging

nozzle.

The charging indicator lamp comes on in white.

With selective door unlocking activated,

press the unlocking button twice to

disconnect the charging nozzle.

When charging is complete, the green

charging indicator lamp in the flap goes

out after about 2 minutes.

Domestic charging, mode 2

The end of charging is confirmed when the green

CHARGE

 indicator lamp on the control unit and

the green charging indicator lamp in the flap

come on fixed.

►  Replace the protective cover on the charging

nozzle and close the charging flap.

►  Disconnect the control unit end of the

charging cable from the domestic socket.

Accelerated charging, mode 3

The end of charging is indicated by the charging

control unit and by the fixed lighting of the green

indicator lamp in the flap.

►  Hang up the nozzle on the charging unit and

close the charging flap.

Superfast charging, mode 4

The end of charging is indicated by the charger

and by the fixed lighting of the green indicator

lamp in the flap.

►  You can also pause charging by

pressing this button in the flap (in mode 4

only).

►  Hang up the nozzle on the charger.

►  Depending on version, replace the protective

cover on the lower section and close the

charging flap.

When the charging nozzle is

disconnected, a message on the

instrument panel indicates that charging is

complete, even if the charging nozzle was

disconnected before full charging was

completed.

Towing device

Load distribution

►  Distribute the load in the trailer so that the

heaviest items are as close as possible to the

axle, and the nose weight approaches the

maximum permitted without exceeding it.

Air density decreases with altitude, thus reducing

engine performance. The maximum towable load

must be reduced by 10% per 1,000 metres of

altitude.

Use genuine towing devices and wiring

harnesses approved by CITROËN. We

recommend having them fitted by a CITROËN

dealer or a qualified workshop.

If not fitted by a CITROËN dealer, they must

still be fitted in accordance with the vehicle

manufacturer's instructions.

Certain driving or manoeuvring aid functions

are automatically deactivated while an

approved towing system is in use.

For more information about driving with a

towing device fitted to a trailer and associated

with the

Trailer stability assist

, refer to the

corresponding section.

Comply with the maximum authorised

towable weight, as indicated on your

vehicle's registration certificate, on the

manufacturer's label and in the

Technical

data

 section of this guide.

If using accessories attached to the

towing device (e.g. bicycle carriers, tow

boxes):

–  Comply with the maximum authorised nose

weight.

–  Do not transport more than 3 bicycles.

When loading bicycles on to a bicycle carrier

over the towball, be sure to place the heaviest

bicycles as close as possible to the vehicle.

Observe the legislation in force in the

country where you are driving.

150

Practical information

Electric motor

An electric vehicle cannot under any

circumstances be fitted with a towing device.

It is therefore not possible to tow a trailer or

caravan.

Towing device with quickly

detachable towball

Presentation

No tools are required to install or remove this

genuine towing device.





1.

Carrier

2.

Protective plug

3.

Connection socket

4.

Safety eye

5.

Detachable towball

6.

Locking/unlocking wheel

7.

Security key lock

8.

Label to note the key references





A. Locked

 position (the

green

 marks are

opposite each other); the wheel is in contact

with the towball (no gap).

B. Unlocked

 position (

red

 mark opposite

the

green

 mark); the wheel is no longer

in contact with the towball (gap of around

5 mm).

Affix the enclosed label in a clearly visible

location, close to the carrier or in the

boot.

Trailers with LED lamps are not

compatible with the wiring harness of this

device.

To ensure complete safety while driving

with a

Towing device

, refer to the

corresponding section.

Before each use

Verify that the towball is correctly fitted,

checking the follow points:

–  The green mark on the wheel is in line with

the green mark on the towball.

–  The wheel is in contact with the towball

(position

A

).

–  The security key lock is closed and the

key removed; the wheel can no longer be

operated.

–  The towball must not be able to move in

its carrier; test by attempting to shake it with

your hand.

If the towball is not locked, the trailer can

become detached - risk of an accident!

During use

Never release the locking system with a

trailer or load carrier on the towball.

Never exceed the maximum authorised

weight for the vehicle - the Gross Train

Weight or GTW.

Always comply with the maximum authorised

load on the towing device: if it is exceeded,

this device may become detached from the

vehicle - risk of an accident!

Before driving, check the headlamp height

adjustment and check that the lamps on the

trailer operate correctly.

For more information on

Headlamp height

adjustment

, refer to the corresponding

section.

151

Practical information

7

After use

When travelling without a trailer or

load carrier, remove the towball and fit the

protective plug into the carrier, to provide

clear visibility of the number plate and/or its

lighting.

Fitting the towball





►  Below the rear bumper, remove the protective

plug

2

 from the carrier

1

.

►  Insert the end of the towball

5

 into the carrier

1

 and push it upwards; it will lock into position

automatically.





►  The wheel

6

 rotates a quarter turn anti-

clockwise; take care to keep your hands clear!





►  Check that the mechanism has correctly

locked into place (position

A

).

►  Close the lock

7

 using the key.

►  Remove the key. The key cannot be removed

while the lock is open.

►  Clip the cap onto the lock.





►  Remove the protective cover from the

towball.

►  Attach the trailer to the towball.

►  Attach the cable on the trailer to the safety

eye

4

 on the carrier.

►  Lower the connection socket

3

 to put it in

position.

►  Insert the trailer plug and rotate it by a

quarter turn to connect it to the connection

socket

3

 on the carrier.

Removing the towball

►  Grasp the trailer's plug, perform a quarter

turn and pull to disconnect it from the connection

socket

3

 on the carrier.

►  Lift the connection socket

3

 to the right to

stow it away.

►  Detach the trailer's safety cable from the

safety eye

4

 on the carrier.

►  Unhitch the trailer from the towball.

►  Replace the protective cover over the towball.

152

Practical information

►  Remove the cap from the lock and press it

onto the head of the key.





►  Insert the key into the lock

7

.

►  Open the lock using the key.





►  Hold the towball

5

 firmly in one hand; using

the other hand, pull and turn the wheel

6

 fully in

a clockwise direction until it stops; do not release

the wheel.

►  Extract the towball from the base of its

carrier

1

.

►  Release the wheel; it automatically locks in

the unlocked position (position

B

).





►  Replace the protective plug

2

 into the

carrier

1

.

►  Stow the towball in its bag to protect it from

knocks and dirt.

Maintenance

Correct operation is only possible if the towball

and its carrier are kept clean.

Before cleaning the vehicle with a high-pressure

jet wash, the towball must be removed and the

protective plug fitted to the carrier.

Work on the towing device

Contact a CITROËN dealer or a qualified

workshop.

Roof bars

As a safety measure and to avoid

damaging the roof, it is essential to use

transverse roof bars approved for your

vehicle.

Observe the instructions on fitting and use

contained in the guide supplied with the roof

bars.

Maximum load distributed over the

transverse roof bars, for a loading height

not exceeding 40 cm (except bicycle carrier):

80 kg

.

As this value may change, please verify the

maximum load quoted in the guide supplied

with the roof bars.

If the height exceeds 40 cm, adapt the speed

of the vehicle to the profile of the road to

avoid damaging the roof bars and the fixings

on the vehicle.

Be sure to refer to national legislation in order

to comply with the regulations for transporting

objects that are longer than the vehicle.

Recommendations

Distribute the load uniformly, taking care

to avoid overloading one of the sides.

Arrange the heaviest part of the load as close

as possible to the roof.

Secure the load firmly.

153

Practical information

7

Drive gently: the vehicle will be more

susceptible to the effects of side winds and its

stability may be affected.

Regularly check the security and tight

fastening of the roof bars, at least before each

trip.

Remove the roof bars once they are no longer

needed.

Sunroof

Check that the load does not pass below

the roof bars so that it does not impede the

movements of the sunroof - risk of major

damage!

Direct fitting on roof





The transverse bars must only be fixed at the

four anchorage points located on the roof frame.

These points are concealed by the vehicle doors

when the doors are closed.

The roof bar fixings have a stud which must be

inserted into the opening of each anchorage

point.

Snow chains

In wintry conditions, snow chains improve

traction as well as the behaviour of the vehicle

when braking.

Snow chains must be fitted only to the

front wheels. They must never be fitted to

"space-saver" type spare wheels.

Observe the legislation in force in your

country relating to the use of snow

chains and maximum authorised speeds.

Use only chains designed to be fitted to the type

of wheel fitted to the vehicle:

Original tyre size

Chain type

215/65 R16

Polaire XP9 120 (9

mm)

215/60 R17

Polaire XP9 120 (9

mm)

195/60 R18

Polaire PSS 112 (10

mm)

For more information on snow chains, contact a

dealer or a qualified workshop.

Installation tips

►  To fit the snow

chains during a journey, stop

the vehicle on a flat surface at the side of the

road.

►  Apply the parking brake and position any

wheel chocks under the wheels to prevent

movement of the vehicle.

►  Fit the snow chains following the instructions

provided by the manufacturer.

►  Move off gently and drive for a few moments,

without exceeding 31 mph (50 km/h).

►  Stop the vehicle and check that the snow

chains are correctly tightened.

It is strongly recommended that you

practise fitting the snow chains on a level

and dry surface before setting off.

Avoid driving with snow chains on roads

that have been cleared of snow to avoid

damaging the vehicle's tyres and the road

surface. If the vehicle is fitted with alloy

wheels, check that no part of the chain or its

fixings is in contact with the wheel rim.

Energy economy mode

This system manages the duration of use of

certain functions, in order to conserve a sufficient

level of charge in the battery with the ignition off.

After switching off the engine and for a maximum

cumulative period of around 30 minutes, you can

154

Practical information

continue to use functions such as the audio and

telematics system, dipped beam headlamps or

courtesy lamps.

Selecting the mode

A confirmation message is displayed when

energy economy mode is entered, and the active

functions are placed on standby.

If a telephone call is in progress at the

time, it will be maintained for around 10

minutes via the audio system’s hands-free

system.

Exiting the mode

These functions are automatically reactivated the

next time the vehicle is used.

To restore the use of these functions

immediately, start the engine and let it run:

–  For less than 10 minutes, to use the

equipment for approximately 5 minutes.

–  For more than 10 minutes, to use the

equipment for approximately 30 minutes.

Let the engine run for the specified duration to

ensure that the battery charge is sufficient.

To recharge the battery, avoid repeatedly or

continuously restarting the engine.

A flat battery prevents the engine from

starting.

For more information on the

12 V battery/

Accessories battery

/, refer to the

corresponding section.

Load reduction mode

This system manages the use of certain

functions according to the level of charge

remaining in the battery.

When the vehicle is being driven, the load

reduction function temporarily deactivates certain

functions, such as the air conditioning and the

heated rear screen.

The deactivated functions are reactivated

automatically as soon as conditions permit.

Bonnet

Stop & Start

Before doing anything under the bonnet,

you must switch off the ignition to avoid any

risk of injury resulting from an automatic

change to START mode.

Electric motor

Take care with objects or clothing that

could be caught in the blades of the cooling

fan or in certain moving components - risk of

strangulation and serious injury!

Before carrying out any work under the

bonnet, you must switch off the ignition, check

that the

READY

 indicator lamp is off on the

instrument panel and disconnect the charging

nozzle if it is plugged in.

The location of the interior bonnet

release lever prevents the bonnet being

opened when the left-hand front door is

closed.

When the engine is hot, handle the

exterior safety catch and the bonnet stay

with care (risk of burns), using the protected

area.

When the bonnet is open, take care not to

damage the safety catch.

Do not open the bonnet under very windy

conditions.

Cooling of the engine when stopped

The engine cooling fan may start after

the engine has been switched off.

Take care with objects or clothing that

could be caught in the blades of the fan!

Opening

►  Open the left-hand front

door.

155

Practical information

7









►  Pull the interior release lever, located at the

bottom of the door frame, towards you.





►  Lift the exterior safety catch and raise the

bonnet.

►  Unclip the stay from its housing and place it

in the support slot to hold the bonnet open.

Closing

►  Hold the bonnet and pull out the stay from the

support slot.

►  Clip the stay in its housing.

►  Lower the bonnet and release it near the end

of its travel.

►  Pull on the bonnet to check that it is locked

correctly.

Because of the presence of electrical

equipment under the bonnet, it is strongly

recommended that exposure to water (rain,

washing, etc.) be limited.

Engine compartment

The engine shown here is an example for

illustrative purposes only.

The locations of the following elements may

vary:

–  Air filter.

–  Engine oil dipstick.

–  Engine oil filler cap.

Petrol engine





Diesel engine





1.

Screenwash fluid reservoir

2.

Engine coolant reservoir

3.

Brake fluid reservoir

4.

Battery/Fuses

5.

Fusebox

6.

Air filter

7.

Engine oil filler cap

8.

Engine oil dipstick

Diesel fuel system

This system is under very high pressure.

All work must be carried out only by a

CITROËN dealer or a qualified workshop

156

Practical information

Electric motor





1.

Screenwash fluid reservoir

2.

Engine coolant reservoir (level only)

3.

Brake fluid reservoir

4.

Battery/Fuses

5.

Fusebox

6.

400 V electrical circuit

7.

Emergency circuit-breaker for emergency

services and maintenance technicians

For more information on the

Charging system

(Electric)

, refer to the corresponding section.

Checking levels

Check all of the following levels regularly in

accordance with the manufacturer's service

schedule. Top them up if required, unless

otherwise indicated.

If a level drops significantly, have the

corresponding system checked by a CITROËN

dealer or a qualified workshop.

The fluids must comply with the

manufacturer's requirements and with

the vehicle's engine.

Take care when working under the

bonnet, as certain areas of the engine

may be extremely hot (risk of burns) and the

cooling fan could start at any time (even with

the ignition off).

Used products

Avoid prolonged contact of used oil or

fluids with the skin.

Most of these fluids are harmful to health and

very corrosive.

Do not discard used oil or fluids into

sewers or onto the ground.

Empty used oil into the containers reserved

for this purpose at a CITROËN dealer or a

qualified workshop.

Engine oil

The level is checked, with the engine

having been switched off for at least 30

minutes and on level ground, either using the oil

level indicator in the instrument panel when the

ignition is switched on (for vehicles equipped

with an electric gauge), or using the dipstick.

It is normal to top up the oil level between two

services (or oil changes). It is recommended

that you check the level, and top up if necessary,

every 3,000 miles (5,000 km).

In order to maintain the reliability of the

engine and emissions control system,

never use additives in the engine oil.

Checking using the dipstick

For the location of the dipstick, please refer

to the illustration of the corresponding engine

compartment.

►  Grasp the dipstick by its coloured grip and

pull it out completely.

►  Wipe the end of the dipstick using a clean,

lint-free cloth.





►  Reinsert the dipstick and push fully down,

then pull it out again to visually check the oil

level: the correct level is between marks

A

 (max)

and

B (min).

Do not start the engine if the level is:

–  above mark

A

: contact a CITROËN dealer or a

qualified workshop.

–  below mark

B

: top up the engine oil

immediately.

157

Practical information

7

Oil grade

Before topping up or changing the

engine oil, check that the oil is suitable

for your engine and complies with the

recommendations in the service schedule

supplied with the vehicle (or available from

your CITROËN dealer or qualified workshop).

Use of non-recommended oil may invalidate

your warranty in the event of engine failure.

Topping up the engine oil level

For the location of the engine oil filler cap, please

refer to the corresponding engine compartment

illustration.

►  Add oil in small quantities, avoiding any spills

on engine components (risk of fire).

►  Wait a few minutes before checking the level

again using the dipstick.

►  Top up the level if necessary.

►  After checking the level, carefully screw the

oil filler cap back on and replace the dipstick in

its tube.

The oil level indication displayed on the

instrument panel when the ignition is

switched on is not valid for 30 minutes

following an addition of oil.

Brake fluid

The level of this fluid should be

close to

the "

MAX

" mark. If not, check the brake

pads for wear.

To know how often the brake fluid should be

replaced, refer to the manufacturer's servicing

schedule.

Clean the cap before removing it to refill.

Use only DOT4 brake fluid from a sealed

container.

Engine coolant

(Petrol or Diesel)

It is normal to

 top up this fluid between

two services.

The check and top-up must only be done with

the engine cold.

A level of coolant that is too low risks causing

major damage to the engine; the coolant level

must be close to the "

MAX

" mark without ever

going above it.

If the level is close to or below the "

MIN

" mark, it

is essential to top it up.

When the engine is hot, the temperature of the

coolant is regulated by the fan.

As the cooling system is pressurised, wait at

least one hour after switching off the engine

before carrying out any work.

In order to avoid the risk of scalding if you need

to top up in an emergency, wrap a cloth around

the cap and unscrew the cap by two turns to

allow the pressure to drop.

Once the pressure has dropped, remove the cap

and top up to the required level.

(Electric)

Do not top up the coolant.

If the level is close to or below

the "

MIN

" mark, it is essential to contact a

CITROËN dealer or a qualified workshop.

Screenwash fluid

Top up to the required level when

necessary.

Fluid specification

The fluid must be topped up with a pre-mixed

product.

In winter (temperatures below zero), a fluid

containing an anti-freeze agent which is

appropriate for the temperature conditions

must be used in order to protect the system's

components (pump, tank, ducts, jets).

Filling with pure water is prohibited in all

circumstances (risk of freezing,

limescale, etc.).

158

Practical information

AdBlue

®

 (BlueHDi)

An alert is triggered when the reserve level is

reached.

For more information on the

Indicators

 and in

particular the AdBlue range indicators, refer to

the corresponding section.

To avoid the vehicle being immobilised in

accordance with regulations, you must top up the

AdBlue tank.

For more information on

AdBlue

®

 (BlueHDi)

,

and in particular the supply of AdBlue, refer to

the corresponding section.

Checks

Unless otherwise indicated, check these

components in accordance with the

manufacturer's service schedule and according

to your engine.

Otherwise, have them checked by a CITROËN

dealer or a qualified workshop.

Only use products recommended by

CITROËN or products of equivalent

quality and specification.

In order to optimise the operation of

components as important as those in the

braking system, CITROËN selects and offers

very specific products.

12 V battery

The battery does not require any

maintenance.

Check regularly that the terminals are correctly

tightened (versions without quick-release

terminals) and that the connections are clean.

For more information on the precautions

to take before any work on the

12 V

battery

, refer to the corresponding section.

Versions equipped with Stop & Start are

fitted with

a 12 V lead-acid battery of

specific technology and specification.

Its replacement should be carried out only by

a CITROËN dealer or a qualified workshop.

Passenger compartment

filter

Depending on the environment and the

use of the vehicle (e.g. dusty atmosphere,

city driving),

change it twice as often, if

necessary

.

A clogged passenger compartment filter

can adversely affect air conditioning

system performance and generate

undesirable odours.

Air filter

Depending on the environment and the

use of the vehicle (e.g. dusty atmosphere,

city driving),

change it twice as often, if

necessary

.

Oil filter

Change the oil filter each time the

engine

oil is changed.

Particle filter (Diesel)

The start of clogging of

the particle filter is

indicated by the temporary lighting of this

warning lamp, accompanied by an alert

message.

As soon as the traffic conditions permit,

regenerate the filter by driving at a speed of at

least 37 mph (60 km/h) until the warning lamp

goes off.

Following prolonged operation of the

vehicle at very low speed or at idle, you

may, in exceptional circumstances, notice

water vapour coming from the exhaust while

accelerating. These emissions have no

impact on the vehicle’s behaviour and the

environment.

New vehicle

During the first few particle filter

regeneration operations, you may notice a

"burning" smell. This is perfectly normal.

159

Practical information

7

Manual gearbox

The gearbox does not require any

maintenance (no oil change).

Automatic gearbox

The gearbox does not require any

maintenance (no oil change).

Manual parking brake

If you notice excessive brake lever travel

or decreased effectiveness, the parking

brake must be adjusted, even between two

services.

This system must be checked by a CITROËN

dealer or a qualified workshop.

Electric parking brake

This system does not require any routine

servicing. However, in the event of a

problem, do not hesitate to have the system

checked by a CITROËN dealer or a qualified

workshop.

For more information on the

Electric

parking brake

, refer to the

corresponding section.

Brake pads

Brake wear depends on the style of

driving, particularly in the case of vehicles

used in town, over short distances. It may be

necessary to have the condition of the brakes

checked, even between vehicle services.

Unless there is a leak in the circuit, a drop in the

brake fluid level indicates that the brake pads

are worn.

After washing the vehicle, moisture, or in

wintry conditions, ice can form on the

brake discs and pads: braking efficiency may

be reduced. Gently dab the brakes to dry and

defrost them.

Brake disc/drum wear

For any information on checking brake

disc/drum wear, contact a CITROËN

dealer or a qualified workshop.

Wheels and tyres

The inflation pressure of all

tyres,

including the spare wheel, must be

checked on "cold” tyres.

The pressures indicated on the tyre pressure

label are valid for "cold" tyres. If you have driven

for more than 10 minutes or more than 6 miles

(10 kilometres) at over 31 mph (50 km/h), add

0.3 bar (30 kPa) to the values indicated on the

label.

Under-inflation increases energy

consumption. Non-compliant tyre

pressures cause tyres to wear prematurely

and have an adverse effect on the vehicle's

road holding - risk of accident!

Driving with worn or damaged tyres reduces the

braking and road holding performance of the

vehicle. Regularly check the condition of the

tyres (tread and sidewalls) and rims as well as

the presence of the valve caps.

When the wear indicators no longer appear set

back from the tread, the depth of the grooves is

less than 1.6 mm; replace the tyres as soon as

possible.

Using different size wheels and tyres from those

specified can affect the lifetime of tyres, wheel

rotation, ground clearance, the speedometer

reading and have an adverse effect on road

holding.

Fitting different tyres on the front and rear axles

can cause the ESC to mistime.

Always mark the direction of rotation on the tyres

that will be stored when fitting winter or summer

tyres. Store them in a cool, dry place and away

from direct exposure to the sun's rays.

Winter or 4-seasons tyres can be

identified by this symbol on their

sidewalls.

Shock absorbers

It is not easy for drivers to detect when

shock absorbers are worn. Nevertheless,

the shock absorbers have a major impact on

road holding and braking performance.

For your safety and driving comfort, it is

important to have them regularly checked by a

CITROËN dealer or a qualified workshop.

160

Practical information

Timing and accessory kits

The timing and accessory kits are used

from the time the engine is started until it

is switched off. It is normal for them to wear over

time.

A faulty timing or accessory kit can damage

the engine, rendering it unusable. Observe the

recommended replacement frequency, stated in

distance travelled or time elapsed, whichever is

reached first.

AdBlue

®

 (BlueHDi)

To respect the environment and ensure

compliance with the Euro 6 standard, without

adversely affecting the performance or fuel

consumption of its Diesel engines, CITROËN

has taken the decision to equip its vehicles with

a system that combines SCR (Selective Catalytic

Reduction) with a Diesel Particle Filter (DPF) for

the treatment of exhaust gases.

SCR system

Using a liquid called AdBlue

®

 that contains

urea, a catalytic converter turns up to 85% of

the nitrogen oxides (NOx) into nitrogen and

water, which are harmless to health and the

environment.

The AdBlue

®

 is contained in

a special

tank

 holding about 15 litres.

Its capacity allows a driving range of

approximately 4,000 miles (6,500 km),

which

may vary considerably

 depending on your

driving style.

An alert system is triggered once the reserve

level is reached: it is then possible to drive for a

further 1,500 miles (2,400 km) before the tank is

empty and the vehicle is immobilised.

For more information on the

Warning

and indicator lamps

 and the associated

alerts, or the

Indicators

, please refer to the

corresponding sections.

Once the AdBlue

®

 tank is empty, a device

required by law prevents the engine from

being restarted.

If the SCR system is faulty, the level of

emissions from the vehicle will no longer meet

the Euro 6 standard and the vehicle starts

polluting the environment.

In the event of a confirmed SCR system

malfunction, it is essential to visit a CITROËN

dealer or a qualified workshop. After 685

miles (1,100 km), a device is automatically

activated to prevent the engine from starting.

In both cases, a range indicator indicates

the distance that can be travelled before the

vehicle is stopped.

Freezing of the AdBlue

®

AdBlue

®

 freezes at temperatures below

around -11°C.

The SCR system includes a heater for the

AdBlue

®

 tank, allowing you to continue driving

in very cold conditions.

Supply of AdBlue

®

It is recommended that the AdBlue

®

 be topped

up as soon as the first alert is issued indicating

that the reserve level has been reached.

For the correct operation of the SCR

system:

–  Use only AdBlue

®

 fluid that meets the ISO

22241 standard.

–  Never transfer AdBlue

®

 to another container

as it would lose its purity.

–  Never dilute AdBlue

®

 with water.

You can obtain AdBlue

®

 from a CITROËN dealer

or a qualified workshop, as well as service

stations equipped with AdBlue

®

 pumps specially

designed for passenger vehicles.

Recommendations on storage

AdBlue

®

 freezes at about -11°C and deteriorates

above +25°C. Containers should be stored in a

cool area and protected from direct sunlight.

Under these conditions, the fluid can be kept for

at least a year.

If the fluid has frozen, it can be used once it has

completely thawed out at room temperature.

Never store AdBlue

®

 containers in your

vehicle.

161

Practical information

7

Precautions for use

AdBlue

®

 is a urea-based solution. This fluid is

non-flammable, colourless and odourless (when

kept in a cool place).

In the event of contact with the skin, wash the

affected area with soap and running water. In the

event of contact with the eyes, immediately rinse

the eyes with large amounts of water or with an

eye wash solution for at least 15 minutes. Seek

medical attention if you feel a persistent burning

sensation or irritation.

If swallowed, immediately wash out the mouth

with clean water and then drink plenty of water.

In certain conditions (high temperature, for

example), the risk of release of ammonia cannot

be excluded: do not inhale the fluid. Ammonia

vapours have an irritant effect on mucous

membranes (eyes, nose and throat).

Store AdBlue

®

 out of the reach of

children, in its original container.

Procedure

Before starting the top-up procedure, ensure that

the vehicle is parked on a flat and level surface.

In wintry conditions, ensure that the temperature

of the vehicle is above -11°C. Otherwise the

AdBlue

®

 may be frozen and so cannot be poured

into the tank. Park the vehicle in a warmer area

for a few hours to allow the top-up to be carried

out.

Never pour the AdBlue

®

 into the Diesel

fuel tank.

If any AdBlue

®

 is splashed, or if there are

any spillages on the bodywork, rinse

immediately with cold water or wipe with a

damp cloth.

If the fluid has crystallised, clean it off using a

sponge and hot water.

Important:

in the event of a top-up after

a breakdown because of a lack of

AdBlue,

 it is essential to wait around 5

minutes before switching on the ignition,

without opening the driver’s door,

unlocking the vehicle, inserting the key

into the ignition switch, or bringing the

key for the "Keyless Entry and Start"

system into the passenger compartment

.

Switch on the ignition, then wait for 10

seconds before starting the engine.

►  Switch off the ignition and remove the key

from the switch to switch off the engine.

or

►  With Keyless Entry and Start, press the

"

START/STOP

" button to switch off the engine.





►  Turn the blue cap of the AdBlue

®

 tank anti-

clockwise and remove it.

►  With a container of AdBlue

®

: after checking

the expiry date, read the instructions on the

label carefully before pouring the contents of the

container into the vehicle's AdBlue tank.

►  With an AdBlue

®

 pump: insert the nozzle and

fill the tank until the nozzle automatically cuts

out.

In order not to overfill the AdBlue

®

 tank:

–  Add between 10 and 13 litres using

AdBlue

®

 containers.

–  Stop after the nozzle’s first automatic cut-

out, if you are refilling at a service station.

The system only registers AdBlue

®

 top-ups of

5 litres or more.

If the AdBlue

®

 tank is completely empty

– which is confirmed by the message

"Top up AdBlue: Starting impossible" – it is

essential to add at least 5 litres.
