82

Safety

Rules:

–  A position that is

i-Size

 compatible is also

compatible with

R1

,

R2

 and

F2X

,

F2

,

B2

.

–  A position that is

R3

 compatible is also

compatible for

R1

 and

R2

.

–  A position that is

F3

 compatible is also

compatible for

F2X

 and

F2

.

–  A position that is

B3

 compatible is also

compatible with

B2

.

(a)

Universal child seat: child seat that can be

installed in all vehicles using the seat belt.

(b)

To install a "

rearward facing

" child seat at

this seat position, the front passenger airbag

must be deactivated ("

OFF

").

(c)

Only a "

forward facing

" child seat is

authorised at this seat position with the front

passenger airbag activated ("

ON

").

(d)

For a seat with height adjustment, adjust the

seat to the highest position and move it fully

back, with the backrest straightened.

For a seat without height adjustment,

move the seat fully back, with the backrest

straightened.

(e)

Never install a child seat with a support leg

on the centre rear seat.

(f)

Seats not fitted with "ISOFIX" mountings.

(g)

Adjust the front passenger seat to the

middle longitudinal position with the

backrest straightened.

(h)

For a "rearward facing" and/or "forward

facing" universal child seat (U) in groups 0,

0+, 1, 2 or 3.

(i)

For a "forward facing" universal child seat

(UF) in groups 1, 2 or 3.

(j)

Depending on version, refer to the

legislation in force in your country before

installing a child in this seat position.

(k)

Adjust the front passenger seat to the fully

backward position.





Key

Seat position where the installation of a

child seat is forbidden.

Front passenger airbag

deactivated

.

Front passenger airbag

activated

.

Seat position suitable for the installation

of a child seat secured using the seat belt

83

Safety

5

and

universally approved "rearward facing"

and/or "forward facing"

 (

U

) for all sizes and

weight groups.

Seat position suitable for the installation

of a child seat secured using the seat belt

and

universally approved "forward facing"



(

UF

) for groups

1

,

2

 &

3

 only.

Seat position authorised for the

installation of an

i-Size

 child seat.

Seat position not suitable for the

installation of a child seat with support

leg.

Presence of a

Top Tether

 anchorage

point at the rear of the backrest,

authorising the installation of a

universal ISOFIX

child seat

.

"Rearward facing"

ISOFIX

 child seat:

–

R1

:

ISOFIX

 child seat for a

baby

.

–

R2

:

ISOFIX reduced size

 child seat.

–

R3

:

ISOFIX large size

 child seat.

"Forward facing"

ISOFIX

 child seat:

–

F2X

:

ISOFIX

 child seat

for toddlers

.

–

F2

:

ISOFIX reduced height

 child seat.

–

F3

:

ISOFIX full height

 child seat.

Booster

 child seat:

–

B2

:

reduced width booster

 seat.

–

B3

:

full width booster

 seat.

Seat position where the installation of an

ISOFIX

 child seat is forbidden.

For seat adjustments, refer to the table

"

Installing universal, ISOFIX and i-Size child

seats

".

Manual child lock

The system prevents a rear door from being

opened using its interior handle.

The control is located on the edge of each rear

door (marked by a label on the bodywork).

Activation/Deactivation





►  To activate, turn the built-in key fully:

•  To the right on the left-hand rear door.

•  To the left on the right-hand rear door.

►  To deactivate, turn it in the opposite direction.

84

Driving

Driving recommendations

►  Observe the driving regulations and remain

vigilant whatever the traffic conditions.

►  Monitor your environment and keep your

hands on the wheel to be able to react to

anything that may happen any time.

►  Drive smoothly, anticipate the need for

braking and maintain a longer safety distance,

especially in bad weather.

►  Stop the vehicle before performing operations

that require sustained attention (e.g. settings).

►  During long trips, take a break every 2 hours.

Important!

Never leave the engine running in a

closed space without sufficient

ventilation.

 Internal combustion engines emit

toxic exhaust gases such as carbon

monoxide. Danger of poisoning and death!

In very severe wintry conditions

(temperature below -23°C), let the engine

run for 4 minutes before moving off, to ensure

the correct operation and durability of the

mechanical components of your vehicle

(engine and gearbox).

Never drive with the parking brake

applied

. Risk of overheating and

damaging the braking system!

Never park the vehicle and never

leave the engine running on a

flammable surface (e.g. dry grass, dead

leaves).

The vehicle exhaust system is very

hot, even several minutes after the engine

stops. Risk of fire!

Never drive on surfaces covered with

vegetation (e.g. tall grass,

accumulated dead leaves, crops, debris)

such as a field, a country lane overgrown

with bushes or a grassy verge.

This vegetation could come into contact with

the vehicle's exhaust system or other systems

which are very hot. Risk of fire!

Make sure you do not leave any item in

the passenger compartment which could

act like a magnifying glass under the effect of

the sun's rays and cause a fire. Risk of fire or

damage to interior surfaces!

Never leave the vehicle unattended,

with the engine running

. If you have to

leave your vehicle with the engine running,

apply the parking brake and put the gearbox

into neutral or position

N

 or

P

 (depending on

the type of gearbox).

Never leave children inside the vehicle

unsupervised

.

On flooded roads

We strongly advise against driving on flooded

roads, as this could cause serious damage to the

engine or gearbox, as well as to your vehicle's

electrical systems.





If the vehicle absolutely must drive through a

flooded section of road:

►  Check that the depth of the water does not

exceed 15 cm, taking account of waves that

might be generated by other users.

►  Deactivate the Stop & Start function.

►  Drive as slowly as possible without stalling. In

all cases, do not exceed 6 mph (10 km/h).

►  Do not stop and do not switch off the engine.

On leaving the flooded road, as soon as safety

conditions allow, make several light brake

applications to dry the brake discs and pads.

If in doubt about the state of your vehicle,

contact a CITROËN dealer or a qualified

workshop.

85

Driving

6

Noise (Electric)

On the outside

Due to the vehicle’s quiet operation when

driving, the driver must pay particular attention.

When manoeuvring, the driver must always

check the vehicle's immediate surroundings.

At speeds of up to 19 mph (30 km/h), the

pedestrian horn warns other road users of the

vehicle’s presence.

Cooling the traction battery

The cooling fan comes on during

charging to cool the on-board charger and the

traction battery.

On the inside

During use, you may hear certain perfectly

normal noises specific to electric vehicles, such

as:

–  Traction battery relay when starting.

–  Vacuum pump when braking.

–  Vehicle tyres or aerodynamics when driving.

–  Jolting and knocking noise during hill starts.

Towing

Driving with a trailer places greater

demands on the towing vehicle and

particular care must be taken.

Do not exceed the maximum towable

weights.

At altitude:

 reduce the maximum load by

10% per 1,000 metres of altitude; the lower

air density at high altitudes decreases engine

performance.

New vehicle:

 do not tow a trailer until the

vehicle has driven at least 620 miles

(1,000 kilometres).

If the outside temperature is high, let the

engine idle for 1 to 2 minutes after the

vehicle comes to a stop, to help it to cool.

Before setting off

Nose weight

►  Distribute the load in the trailer so that the

heaviest items are as close as possible to the

axle and the nose weight (at the point where it

joins your vehicle) approaches the maximum

permitted without exceeding it.

Tyres

►  Check the tyre pressures of the towing

vehicle and of the trailer, observing the

recommended pressures.

Lighting

►  Check the electrical signalling on the trailer

and the headlamp beam height of your vehicle.

If a genuine CITROËN towing device is

used, the rear parking sensors will be

deactivated automatically to avoid the audible

signal.

When driving

Cooling

Towing a trailer uphill causes the coolant

temperature to increase. The maximum towable

load depends on the gradient and the exterior

temperature. The fan’s cooling capacity does not

increase with engine speed.

►  Reduce speed and lower the engine speed to

limit the amount of heating produced.

►  Pay constant attention to the coolant

temperature.

If this warning lamp and the

STOP



warning lamp come on, stop the

vehicle and switch off the engine as soon as

possible.

Brakes

Using the engine brake is recommended to limit

the overheating of the brakes. Braking distances

are increased when towing a trailer.

Side wind

Bear in mind that the vehicle will be more

susceptible to wind when towing.

86

Driving

Anti-theft protection

Electronic immobiliser

The keys contain a code, which must be

recognised by the vehicle before starting is

possible.

If the system malfunctions, indicated by the

display of a message, the engine will not start.

Contact a CITROËN dealer.

Starting / Switching off the

engine with the key

Key ignition switch





It has 3 positions:

–

1. Stop

: inserting and removing the key,

steering column locked.

–

2. Ignition

: steering column unlocked, ignition

on, Diesel preheating, engine running.

–

3. Starting

.

Avoid attaching heavy objects to the key

or the remote control. It would weigh

down on its shaft in the ignition switch and

could cause a malfunction.

Ignition on position

It allows the use of the vehicle's electric

equipment or the charging of accessories.

Once the state of charge of the battery drops to

the reserve level, the system switches to energy

economy mode: the power supply is cut off

automatically to preserve the remaining battery

charge.

Starting the engine

With the parking brake applied:

►  With a

manual gearbox

, place the gear lever

in neutral then fully depress the clutch pedal.

►  With an

automatic gearbox

, place the gear

selector in mode

N

 or

P

 then depress the brake

pedal.

►  Insert the key into the ignition switch; the

system recognises the code.

►  Unlock the steering column by simultaneously

turning the steering wheel and the key.

In certain cases, you may need to apply

significant force to move the steering

wheel (e.g. wheels turned to full lock).

►  With a

petrol engine

, operate the starter

motor by turning the key to position

3

 without

pressing the accelerator pedal, until the engine

starts. Once the engine has started, release the

key and allow it to return to position

2

.

Petrol engines

After a cold start, preheating the catalytic

converter can cause noticeable engine

vibrations, for anything up to 2 minutes

(accelerated idle speed).

►  With a

Diesel engine

, turn the key to position

2

, to activate the engine preheating system.

Wait until this warning lamp goes off on

the instrument panel, then turn the key to

position

3

 without pressing the accelerator pedal,

to operate the starter motor. Once the engine

has started, release the key and allow it to return

to position

2

.

In wintry conditions, the warning lamp

may stay on for a longer period. When

the engine is hot, the warning lamp does not

come on.

In mild conditions, do not leave the engine

to warm up while stationary, but move off

straight away and drive at moderate speed.

If the engine does not start straight away,

switch off the ignition. Wait a few

seconds before operating the starter motor

again. If the engine does not start after a few

attempts, do not keep trying - risk of

damaging the starter motor and the engine!

Contact a CITROËN dealer or a qualified

workshop.

87

Driving

6

Switching off the engine

►  Immobilise the vehicle.

►  With the engine at idle, turn the key to

position

1

.

►  Remove the key from the ignition switch.

►  To lock the steering column, turn the steering

wheel until it locks.

To facilitate unlocking of the steering

column, it is recommended that the

wheels be returned to the straight ahead

position before switching off the engine.

Never switch off the ignition before the

complete immobilisation of the vehicle.

With the engine off, the braking and steering

assistance systems are also cut off - risk of

loss of control of the vehicle!

Check that the parking brake is correctly

applied, particularly on sloping ground.

When leaving the vehicle, keep the key in

your possession and lock the vehicle.

Energy economy mode

After the engine has stopped (position

1. Stop

),

for a maximum combined duration of 30 minutes,

you can still use functions such as the audio and

telematics system, courtesy lamps or dipped

beam headlamps.

For more information on

Energy

economy mode

, refer to the

corresponding section.

Key left in

When the driver's door is opened, a

message is displayed, accompanied by an

audible signal, if the key has been left in the

ignition switch in position

1

.

If the key has been left in the ignition switch

in position

2

, the ignition will be switched off

automatically after one hour.

To switch the ignition back on, turn the key to

position

1

, then back to position

2

.

Starting/switching off the

engine with Keyless Entry

and Start

The electronic key must be present in the

passenger compartment.

The electronic key is also detected in the

boot.

If the electronic key is not detected, a

message is displayed.

Move the electronic key so that the engine

can be started or switched off.

If there is still a problem, refer to the "Key

not detected - Back-up starting or Back-up

switch-off" section.

Starting





►  With a

manual gearbox

, place the gear lever

in neutral and fully depress the clutch pedal.

►  With an

automatic gearbox

, select mode

P



or

N

 and press the brake pedal.

►  Press the "

START/STOP

" button while

maintaining pressure on the pedal until the

engine starts.

Diesel engines

In negative temperatures and/or when the

engine is cold, starting takes place only after the

preheating warning lamp goes out.

If this warning lamp comes on after

pressing the "

START/STOP

" button:

►  Keep the pedal fully depressed and do not

press the "

START/STOP

" button again until the

engine is running.

In all circumstances, if one of the starting

conditions is not met, a message is displayed.

In some circumstances, a message indicates

that it is necessary to turn the steering wheel

88

Driving

while pressing the "

START/STOP

" button to

assist unlocking of the steering column.

Petrol engines

With Petrol engines, after a cold start,

pre-heating the catalytic converter can cause

noticeable engine vibrations, for anything up

to 2 minutes (accelerated idle speed).

If the engine stalls, release the clutch

pedal and fully depress it again, the

engine will restart automatically.

Switching off

►  Immobilise the vehicle using the parking

brake.

►  With a

manual gearbox

, ideally put the gear

lever into neutral.

►  With an

automatic gearbox

, ideally select

mode

P

 or

N

.

►  Press the "

START/STOP

" button.

In some circumstances, it is necessary to turn

the steering wheel to lock the steering column.

On certain versions with an automatic gearbox

(EAT8), the steering column does not lock, but

the gearbox locks in mode

P

.

If the vehicle is not immobilised, the

engine will not stop.

With the engine off, the braking and

steering assistance systems are also cut

off - risk of loss of control of the vehicle!

Never leave your vehicle with the

electronic key still inside.

Switching on the ignition

without starting the engine





With the electronic key in the passenger

compartment, pressing the "

START/STOP

"

button,

without depressing any of the pedals

,

allows the ignition to be switched on without

starting the engine.

►  Press this button again to switch off the

ignition and allow the vehicle to be locked.

Key not detected

Back-up starting

A back-up reader is fitted to the steering column,

to enable the engine to be started if the system

fails to detect the key in the recognition zone, or

if the battery in the electronic key is flat.





►  Place and hold the remote control against the

reader.

►

With a manual gearbox

, place the gear lever

in neutral, then fully depress the clutch pedal.

►

With an automatic gearbox or a drive

selector

, select mode

P

, then depress the brake

pedal.

►  Press the "

START/STOP

" button.

The engine starts.

Back-up switch-off





If the electronic key is not detected or is no

longer in the recognition zone, a message

89

Driving

6

appears in the instrument panel when closing a

door or trying to switch off the engine.

►  To confirm the instruction to switch off the

engine, press the "

START/STOP

" button for

approximately 5 seconds.

In the event of a fault with the electronic key,

contact a CITROËN dealer or a qualified

workshop.

Emergency switch-off

In case of emergency only, the engine can be

switched off without conditions (even when

driving).

►  Press the "

START/STOP

" button for about

5 seconds.

In this case, the steering column locks as soon

as the vehicle stops.

Starting/Switching off the

electric motor

Starting

The drive selector must be in mode

P

.

►  If using a remote control key, depress the

brake pedal and turn the key until it reaches

position

3

 (Start).

►  If using Keyless Entry and Start, depress the

brake pedal and briefly press the "

START/STOP

"

button.

►  Keep your foot on the brake pedal until the

READY

 indicator lamp comes on and an audible

signal is emitted, indicating that the vehicle is

ready to drive.

►  With your foot on the brake, select mode

D



or

R

.

►  Release the brake pedal, then accelerate.

On starting, the instrument panel lights up and

the power indicator cursor moves to the "neutral"

position. The steering column automatically

unlocks (you may hear a sound and feel the

steering wheel move).

Switching off

►  If using a remote control key, turn the key

fully to position

1 (Stop)

.

►  If using Keyless Entry and Start, press the

"

START/STOP

" button.

Before exiting the vehicle, check that:

–  The drive selector is in mode

P

.

– The

READY

 indicator lamp is off.

The drive selector moves automatically

to mode

P

 when the motor is switched off

or when the driver's door is opened.

If the driver's door is opened while the

required conditions for switching off are

not met, an audible signal is emitted,

accompanied by the display of a warning

message.

For the procedures for switching on the

ignition without starting the engine and

those for back-up starting/switching off using

the Keyless Entry and Start system, refer to

the

Starting/Switching off the engine

using Keyless Entry and Start section

.

Manual parking brake

Release





►  Pull the parking brake lever up slightly, press

the release button, then lower the lever fully.

 /

When driving the vehicle, if this

warning lamp and the

STOP



warning lamp come on, accompanied by an

audible signal and the display of a message, this

means that the parking brake is still applied or

has not been fully released.

Application

►  Pull the parking brake lever up to immobilise

the vehicle.

When parking on a slope, turn the

wheels against the kerb, apply the

parking brake, engage a gear and switch off

the ignition.

90

Driving

Electric parking brake

In automatic mode, this system applies the

parking brake when the engine is switched off

and releases it when the vehicle moves off.









At any time, with the engine running:

►  To apply the parking brake, briefly pull the

control.

►  To release it, briefly push the control while

pressing the brake pedal.

Automatic mode is activated by default.

This automatic operation can be temporarily

deactivated.

Indicator lamp

This indicator lamp comes on both on the

instrument panel and on the control to

confirm that the parking brake has been applied,

accompanied by display of the message

"

Parking brake applied

".

The indicator lamp goes out to confirm the

release of the parking brake, accompanied by

the display of the message "

Parking brake

released

".

The indicator lamp flashes in response to a

manual request to apply or release the brake.

In the event of a battery failure, the

electric parking brake will not operate.

As a safety measure, with a manual gearbox,

if the parking brake is not applied, immobilise

the vehicle by engaging a gear.

As a safety measure, with an automatic

gearbox or drive selector, if the parking brake

is not applied, immobilise the vehicle by

placing the supplied chock against one of the

wheels.

Contact a CITROËN dealer or a qualified

workshop.





Before leaving the vehicle, check that the

parking brake is applied: the parking

brake indicator lamps on the instrument panel

and the control must be on fixed.

If the parking brake is not applied, there is an

audible signal and a message is displayed on

opening the driver's door.

Never leave a child alone inside the

vehicle, as they could release the parking

brake.

When the vehicle is parked: on a

steep slope, heavily loaded or during

towing

With a manual gearbox, turn the wheels

toward the pavement and engage a gear.

With an automatic gearbox or a drive selector,

turn the wheels toward the pavement and

select mode

P

.

When towing, the vehicle is approved for

parking on slopes of up to 12%.

Manual operation

Manual release

With the ignition on or engine running:

►  Press the brake pedal.

►  While maintaining pressure on the brake

pedal, briefly push the control.

If the brake pedal is not depressed, the

parking brake is not released and a

message is displayed.

Manual application

With the vehicle stationary:

►  Briefly pull the control.

The control indicator lamp flashes to confirm the

application request.

91

Driving

6

Automatic operation

Automatic release

First ensure that the engine is running and that

the driver's door is closed.

The electric parking brake gradually releases

automatically as the vehicle moves off.

With a manual gearbox

►  Fully depress the clutch pedal and engage

first gear or reverse.

►  Depress the accelerator pedal and release

the clutch pedal.

With an automatic gearbox

►  Depress the brake pedal.

►  Select mode

D

,

M

 or

R

.

►  Release the brake pedal and depress the

accelerator pedal.

With a drive selector

►  Depress the brake pedal.

►  Select mode

D

,

B

 or

R

.

►  Release the brake pedal and depress the

accelerator pedal.

With an automatic gearbox or drive

selector, if the brake does not release

automatically, check that the front doors are

properly closed.

When stationary with the engine running,

do not depress the accelerator pedal

unnecessarily. Risk of parking brake release.

Automatic application

With the vehicle stationary, the parking brake

is applied automatically when the engine is

switched off.

It is not applied automatically if the

engine stalls or enters STOP mode with

Stop & Start.

In automatic mode, the parking brake

can be manually applied or released at

any time using the control.

Special cases

Immobilising the vehicle with the

engine running

To immobilise the vehicle with the engine

running, briefly pull the control.

Parking the vehicle with the brake

released

In very cold conditions (ice), applying the

parking brake is not recommended.

To immobilise the vehicle, engage a gear or

place the chocks against one of the wheels.

With an automatic gearbox or drive

selector, mode

P

 is automatically

selected when the ignition is switched off. The

wheels are blocked.

For more information on

Free-wheeling

, refer

to the corresponding section.

With an automatic gearbox or drive

selector, while mode

N

 is selected,

opening the driver’s door triggers an audible

signal. It stops when the driver's door closes

again.

Deactivating automatic

operation

In some situations, for example when it is

extremely cold or when towing (e.g. caravan,

breakdown), it may be necessary to deactivate

automatic operation of the system.

►  Start the engine.

►  Use the control to apply the parking brake, if

it is released.

►  Take your foot fully off the brake pedal.

►  Keep the control pushed in the release

direction for 10 to a maximum of 15 seconds.

►  Release the control.

►  Depress and hold the brake pedal.

►  Pull the control in the application direction for

2 seconds.

This indicator lamp on the instrument

panel comes on to confirm deactivation of

the automatic functions.

►  Release the control and the brake pedal.

92

Driving

From this point onwards, only the manual

functions, using the control, allow the parking

brake to be applied and released.

►  Follow this procedure again to reactivate

automatic operation (confirmed by the indicator

lamp on the instrument panel going out).

Emergency braking

If depressing the brake pedal fails to provide

effective braking or in exceptional circumstances

(e.g. driver unwell, assisted driving), the vehicle

can be braked by sustained pulling on the

electric parking brake control. Braking continues

for as long as the control is kept pulled, and

ceases when the control is released.

The ABS and DSC systems stabilise the vehicle

during emergency braking.

If emergency braking malfunctions, the message

"

Parking brake fault

" will be displayed on the

instrument panel.

If the ABS and DSC systems

malfunction, indicated by lighting

one or both warning lamps on the instrument

panel, the vehicle’s stability is no longer ensured.

►  In this case, ensure the vehicle's stability by

successive and repeated "pull-release" actions

on the electric parking brake control until the

vehicle comes to a complete stop.

6-speed manual gearbox

Engaging 5

th

 or 6

th

 gear

►  Move the gear selector fully to the right to

engage 5

th

 or 6

th

 gear.

Failure to follow this instruction could

cause permanent damage to the gearbox

(inadvertent engagement of 3

rd

 or 4

th

 gear).

Engaging reverse gear





►  Raise the ring under the knob and move the

gear selector to the left, then forwards.

Only engage reverse gear when the

vehicle is stationary with the engine at

idle.

As a safety precaution and to facilitate

starting the engine:

–  Always select neutral.

–  Press the clutch pedal.

Automatic gearbox

Automatic 8-speed gearbox with push selector.

It also offers a manual mode with gear changes

via control paddles located behind the steering

wheel.

Push selector





P.

Auto Park

Press this button to switch to Parking mode.

For parking the vehicle: the front wheels are

blocked.

R.

Reverse

N.

Neutral

To free-wheel and move the vehicle, with the

ignition off.

For more information on

Free-wheeling

, refer

to the corresponding section.

D.

Driving in automatic mode

The gearbox manages gear changes

according to the style of driving, the road

profile and the vehicle load.

93

Driving

6

M.

Driving in manual mode

Press this button to switch to manual mode.

The driver changes gear using the steering-

mounted controls.

►  In mode

N

, with your foot on the brake pedal,

push without passing the point of resistance:

•  Forwards, mode

R

 is selected.

•  Backwards, mode

D

 is selected.

Release the selector fully after each push; it

will then return to its initial position.

Special cases

To avoid mode

N

 (quick change from

D

 to

R

 and

back again):

►  In mode

R

, push backwards past the point of

resistance, mode

D

 is selected.

►  In mode

D

, push forwards past the point of

resistance, mode

R

 is selected.

►  To return to mode

N

, push without passing

the point of resistance.

Steering-mounted controls

(Depending on equipment)

In mode

M

 or

D

, the steering-mounted control

paddles can be used to change gear manually.

They cannot be used to select neutral or to

engage or disengage reverse gear.





►  Pull the "

+

" or "

-

" paddle towards you and

release to shift up or down a gear, respectively.

Information displayed on

the instrument panel

When the ignition is switched on, the gearbox

status is displayed on the instrument panel:

P

Parking

R

Reverse

N

Neutral

D1...8

Automatic forward gear

M1...8

Manual forward gear

The state of the gearbox remains displayed on

the instrument panel for a few seconds after

switching off the ignition.

Operation

Only appropriate mode change instructions are

validated.

With the engine running, if it is necessary to

depress the brake pedal to change modes,

an alert message will be displayed on the

instrument panel.

With the engine running and the brakes

released, if

R

,

D

 or

M

 is selected, the

vehicle moves off, even without pressing the

accelerator pedal.

Never depress the accelerator and brake

pedals at the same time - risk of damage to

the gearbox!

If you open the driver's door while mode

N

 is engaged, an audible signal will

sound. The audible signal stops when the

driver's door is closed.

At very low speeds, opening the driver's

door triggers the gearbox to switch to

mode

P

.

In the event of battery failure, it is

essential to place the chock(s) supplied

with the tool kit against one of the wheels to

immobilise the vehicle.

Special aspects of automatic mode

The gearbox selects the gear that provides

optimal performance based on ambient

temperature, road profile, vehicle loading and

driving style.

For maximum acceleration, press the accelerator

fully down (kick-down). The gearbox changes

down automatically or holds the selected gear

until the maximum engine speed is reached.

94

Driving

Steering mounted controls allow the driver to

temporarily select a gear, if the vehicle speed

and engine speed conditions permit.

Special aspects of manual mode

The gearbox only changes from one gear to

another if the vehicle speed and engine speed

conditions permit.

Starting the vehicle

►  Fully depress the brake pedal.

►  Start the engine.

►  With your foot on the brake pedal, push once

or twice backwards to select automatic mode

D

,

or forwards to shift into reverse gear

R

.

►  Release the brake pedal.

►  Accelerate gradually to automatically release

the electric parking brake.

The vehicle moves off immediately.

Automatic gearbox

Never try to start the engine by pushing

the vehicle.

Switching the vehicle off

Regardless of the current gearbox mode, mode

P

 is immediately engaged automatically when

the ignition is switched off.

However, in mode

N

, mode

P

 will be engaged

after a delay of 5 seconds (time to enable free-

wheeling mode).

Check that mode

P

 has been engaged and

that the electric parking brake was applied

automatically; if not, apply it manually.

The corresponding indicator lamps on the

gear selector and the electric parking

brake control must be on, as well as the

indicator lamps on the instrument panel.

Gearbox malfunction

This warning lamp comes on,

accompanied by an audible signal and

the display of a message.

Visit a CITROËN dealer or a qualified workshop.

Do not drive faster than 62 mph (100 km/h),

keeping to the speed limit.

Switching of the gearbox to back-up mode

Mode

D

 locks in third gear.

The paddles on the steering wheel do not work

and mode

M

 is no longer accessible.

You may feel a significant jolt on engaging

reverse gear. This will not damage the gearbox.

Selector malfunction

Minor malfunction

This warning lamp comes on,

accompanied by the display of a message

and an audible signal.

Drive carefully.

Visit a CITROËN dealer or a qualified workshop.

In some cases, the selector indicator lamps may

no longer come on, but the gearbox state is still

displayed on the instrument panel.

Major malfunction

This warning lamp comes on,

accompanied by the display of a

message.

You must stop the vehicle.

Stop as soon as it is safe to do so and

switch off the ignition.

Contact a CITROËN dealer or a qualified

workshop.

Drive selector (Electric)





The drive selector is a pulse selector with a

regenerative braking function.

The drive selector provides traction control

based on the driving style, the road profile and

the vehicle load.

With regenerative braking activated, it also

manages engine braking when the accelerator

pedal is released.

95

Driving

6

P.

Park

Button for parking the vehicle: the front

wheels are locked (the button lights up to

indicate that it is activated).

R.

Reverse

To engage reverse gear, with your foot on the

brake pedal.

N.

Neutral

To move the vehicle with the ignition off and

so allow it to free-wheel.

For more information on

Free-wheeling

, refer

to the corresponding section.

D.

Drive (automatic forward gear)

B.

Brake (regenerative braking)

Button for changing to Drive/automatic

forward gear mode with regenerative braking

function (the button lights up to indicate that it

is activated).

Information displayed on

the instrument panel

When the ignition is switched on, the drive

selector status is displayed on the instrument

panel:

P

 : Park.

R

 : Reverse.

N

 : Neutral.

D

 : Drive (automatic forward gear).

B

 : Brake (automatic forward gear with

regenerative braking function activated).

Operation

►  In mode

N

, with your foot on the brake pedal,

push without passing the point of resistance:

•  Forwards, mode

R

 is selected.

•  Backwards, mode

D

 is selected.

Release the selector fully after each push; it

will then return to its initial position.

Special cases

To avoid mode

N

 (quick change from

D

 to

R

 and

back again):

►  In mode

R

, push backwards past the point of

resistance, mode

D

 is selected.

►  In mode

D

, push forwards past the point of

resistance, mode

R

 is selected.

►  To return to mode

N

, push without passing

the point of resistance.

Regenerative braking

With the Brake function and when

decelerating

The Brake function emulates engine braking,

slowing the vehicle with no need to depress the

brake pedal. The vehicle slows more quickly

when the driver releases the accelerator pedal.

The energy recovered when the accelerator

pedal is released is then used to partially

recharge the traction battery, thereby increasing

the vehicle's driving range.

The resulting deceleration of the vehicle

does not cause the brake lamps to come

on.

►  From mode

D

, press button

B

 to activate/

deactivate the function (the button lights up when

the function is activated).

B

 is displayed on the instrument panel.

The system status is not saved when the ignition

is switched off.

In some situations (e.g. battery full,

extreme temperatures), the amount of

regenerative braking may be temporarily

limited, resulting in less deceleration.

The driver must remain alert to traffic

conditions and must always be ready to use

the brake pedal.

With the brake pedal

When the brake pedal is depressed, the

intelligent braking system automatically recovers

some of the energy and uses it to recharge the

traction battery.

This energy recovery also reduces use of the

brake pads, thereby limiting their wear.

The driver may experience a different

sensation when depressing the brake

pedal compared to a vehicle without

regenerative braking.

Driving modes

The driving modes available depend on the

engine and equipment of the vehicle.

96

Driving

Driving modes are selected using the following

control:









►  Press the control to display the modes on the

instrument panel.

When the message disappears, the selected

mode is activated and remains indicated on the

instrument panel (except

Normal mode).

Whenever the ignition is switched on,

Normal

 driving mode is selected by default.

Normal

To restore the default settings.

Eco

To reduce energy consumption by reducing the

performance of the heating and air conditioning,

without deactivating them.

Free-wheeling in

Eco

 mode: depending on

version, with the EAT8 gearbox, switching

into "free-wheeling" is encouraged to slow the

vehicle down without using engine braking. You

can save fuel by taking your foot gradually and

fully off the accelerator pedal in anticipation of

slowing down.

To reduce consumption of the traction battery's

electrical energy by limiting engine torque.

Sport

To obtain more dynamic driving with action

on the accelerator and gear changes with an

automatic gearbox.

Hill start assist

This system keeps the vehicle briefly stationary

(for approximately 2 seconds) when making a hill

start, while you transfer your foot from the brake

pedal to the accelerator pedal.

The system is only active when:

–  The vehicle is completely stationary, with your

foot on the brake pedal.

–  Certain slope conditions are met.

–  The driver’s door is closed.

Do not leave the vehicle while it is being

held temporarily by hill start assist.

If someone needs to get out of the vehicle

with the engine running, apply the parking

brake manually. Then check that the parking

brake indicator lamp and the

P

 indicator lamp

in the electric parking brake control are on

fixed.

The hill start assist function cannot be

deactivated. However, using the parking

brake to immobilise the vehicle interrupts its

operation.

Operation





Facing uphill, with the vehicle stationary,

the vehicle is held for a short time when the

driver releases the brake pedal:

–  If first gear or neutral is engaged on a manual

gearbox.

–  If mode

D

 or

M

 is selected on an automatic

gearbox.

–  If mode

D

 or

B

 is selected on the drive

selector.





Facing downhill, with the vehicle stationary

and reverse gear engaged, the vehicle is held

for a short time when the driver releases the

brake pedal.

97

Driving

6

Malfunction

If the event of a malfunction, these

warning lamps light up on the

instrument panel, accompanied by the display of

a message.

Have it checked by a CITROËN dealer or a

qualified workshop.

Gear shift indicator

(Depending on engine)

This system is designed to reduce fuel

consumption by recommending the most suitable

gear.

Operation

Depending on the driving situation and

the vehicle's equipment, the system may

recommend skipping one or more gears.

Gear engagement recommendations are

not to be considered mandatory. Indeed, the

configuration of the road, the traffic density and

safety remain determining factors when choosing

the best gear. Therefore, the driver remains

responsible for deciding whether or not to follow

the system’s advice.

The system cannot be deactivated.

With an automatic gearbox, the system is

only active in manual operation.

The information appears on the

instrument panel, in the form of an arrow

and the recommended gear.

The system adapts the gear change

instructions according to the driving

conditions (e.g. slope, load) and driving style

(e.g. power demand, acceleration, braking).

The system never suggests:

–  engaging first gear;

–  engaging reverse gear.

Stop & Start

The Stop & Start function puts the engine

temporarily into standby - STOP mode - during

phases when the vehicle is stationary (e.g. red

lights, traffic jams). The engine automatically

restarts - START mode - as soon as the driver

indicates the intention of moving off again.

Primarily designed for urban use, the function

is intended to reduce fuel consumption and

exhaust emissions as well as the noise level

when stationary.

The function does not affect the functionalities of

the vehicle, in particular the braking.

Deactivation/Reactivation

The function is

activated

 by default when the

ignition is switched on.

The settings are changed via the

Driving

/

Vehicle

 touch screen menu.

A message on the instrument panel confirms the

change of status.

When the function is deactivated, if the engine

was in standby, it restarts immediately.

Associated indicator lamps

Function activated.

Function deactivated or malfunction.

Opening the bonnet

Before doing anything under the bonnet,

deactivate the Stop & Start system to avoid

any risk of injury caused by the engine

restarting automatically.

Driving on flooded roads

Before entering into a flooded area, it is

strongly recommended that you deactivate

the Stop & Start system.

For more information on

Driving

recommendations

, particularly on flooded

roads, refer to the corresponding section.

Operation

Main conditions for operation

–  The driver’s door must be closed.

–  The driver's seat belt must be fastened.
