66

Safety

General safety

recommendations

Do not remove the labels attached in

different places on your vehicle. They

include safety warnings as well as

identification information for the vehicle.

For all work on your vehicle, use a

qualified workshop that has the technical

information, skills and equipment required, all

of which a CITROËN dealer is able to

provide.

Depending on country regulations,

certain safety equipment may be

mandatory: high visibility safety vests,

warning triangles, breathalysers, spare bulbs,

spare fuses, fire extinguisher, first aid kit, mud

flaps at the rear of the vehicle, etc.

Installing electrical accessories:

–  The fitting of electrical equipment or

accessories not approved by CITROËN may

cause excessive current consumption and

faults and failures with the electrical system

of your vehicle. Contact a CITROËN dealer

for information on the range of approved

accessories.

–  As a safety measure, access to the

diagnostic socket, used for the vehicle's

electronic systems, is reserved strictly for

CITROËN dealers or qualified workshops,

equipped with the special tools required (risk

of malfunctions of the vehicle's electronic

systems that could cause breakdowns or

serious accidents). The Manufacturer cannot

be held responsible if this advice is not

followed.

–  Any modification or adaptation not intended

or authorised by CITROËN or carried out

without meeting the technical requirements

defined by the Manufacturer will result in the

suspension of the commercial warranty.

Installation of accessory radio

communication transmitters

Before installing a radio communication

transmitter with an external aerial, you must

without fail contact a CITROËN dealer for

the specification of transmitters which can

be fitted (frequency, maximum power, aerial

position, specific installation requirements),

in line with the Vehicle Electromagnetic

Compatibility Directive (2004/104/EC).

Declarations of conformity for radio

equipment

The relevant certificates are available on the

http://service.citroen.com/ACddb/ website.

Hazard warning lamps









►  Pressing this red button causes all the

direction indicators to flash.

They can work with the ignition switched off.

Automatic operation of

hazard warning lamps

When braking in an emergency, depending on

the rate of deceleration, the hazard warning

lamps come on automatically. They switch off

automatically when you next accelerate.

They can be turned off by pressing the button

again.

67

Safety

5

Horn





►  Press the central part of the steering wheel.

Pedestrian horn (Electric)

This system alerts pedestrians that the vehicle is

approaching.

The pedestrian horn operates once the vehicle

is moving and at speeds of up to 19 mph

(30 km/h), in forward or reverse gear.

This function cannot be deactivated.

Malfunction

In the event of a malfunction, this warning

lamp comes on on the instrument panel.

Have it checked by a CITROËN dealer or a

qualified workshop.

* In accordance with the general conditions of use of the service, available from dealers and subject to technological and technical limitations.

** Depending on the geographic coverage provided by the "eCall (SOS)" and "ASSISTANCE" systems.

The list of countries covered and the telematic services provided is available from dealers or on the website for your country.

Emergency or assistance

call









1.

eCall (SOS)

2.

ASSISTANCE

eCall (SOS)

Your vehicle may be fitted with the eCall (SOS)

system either as standard or as an option.

The eCall (SOS) system provides direct contact

to the emergency services and is fully built

into the vehicle. This contact is made either

automatically via the sensors built into the

vehicle, or by pressing button

1

.

According to the country of sale, the eCall (SOS)

system corresponds to the systems PE112,

ERAGLONASS, 999, etc.

The eCall (SOS) system is activated by default.

►  To make an emergency call manually, press

button

1

 for more than 2 seconds.

The lit indicator lamp and a voice message

confirm that the call has been made to the

emergency services*.

The eCall (SOS) system immediately locates

your vehicle and puts you in contact with the

appropriate emergency services**.

►  Pressing again immediately cancels the

request.

The indicator lamp flashes while the vehicle

data is being sent, and then remains lit when

communication is established.

In the event that a serious accident is

detected by the sensors built into the

vehicle, such as the airbag control unit, an

emergency call is made automatically.

The eCall (SOS) system is a public

service of general interest and is

free-of-charge.

Operation of the system

–  Upon switching on the ignition, the indicator

lamp lights up red, then green, and then goes

out: the system is operating correctly.

68

Safety

–  The indicator lamp flashes red: replace the

back-up battery.

–  The indicator lamp is fixed red: system

malfunction. The emergency and assistance call

services may not work.

–  If the indicator lamp does not come on when

the ignition is switched on, this also means that

there is a system malfunction.

If the problem persists, contact a qualified

workshop as soon as possible.

A system fault does not prevent the

vehicle from being driven.

Data processing

All processing of personal data by

the eCall (SOS) function complies with

the framework for protection of personal

information established by Regulation

2016/679 (General Data Protection

Regulation - GDPR) and Directive 2002/58/

EC of the European Parliament and the

Council, and in particular, seeks to protect

the vital interests of the data subject, in

accordance with Article 6 (1) d) GDPR.

The processing of personal data is strictly

limited to the purpose of handling the eCall

(SOS) function used with the “112” single

European emergency call number.

* Depending on the geographic coverage of the "eCall (SOS)" and "ASSISTANCE" systems and the official national language chosen by the owner of the

vehicle.

The list of countries covered and the telematic services provided is available from dealers or on the website for your country.

The eCall (SOS) function is only able to

collect and process the following data

relating to the vehicle: vehicle identification

number, vehicle type (passenger vehicle or

light commercial vehicle), fuel type or power

source, three most recent locations and

direction of travel, number of passengers

and a timestamped log file of the automatic

activation of the system and its timestamp.

The recipients of the processed data are the

emergency call handling centres designated

by the relevant national authorities in the

territory in which they are located, enabling

priority routing and handling of calls to the

“112” emergency number.

Data storage

Data contained in the system’s memory

is not accessible from outside the system until

a call is made. The system is not traceable

and is not continuously monitored in its

normal operating mode.

The data in the system's internal memory is

automatically and continuously erased. Only

the vehicle’s three most recent locations,

necessary for the normal functioning of the

system, are stored.

When an emergency call is triggered, the data

log is stored for no more than 13 hours.

Access to data

You have the right of access to data and

as appropriate to request the rectification,

erasure or restriction of processing of any

personal data not processed in accordance

with the provisions of GDPR. Third parties

to which data has been disclosed shall

be notified of any rectification, erasure or

restriction carried out in compliance with

GDPR, unless it proves impossible or

involves a disproportionate effort.

You also have the right to lodge a complaint

with the respective data protection

supervisory authority.

If you want to claim your above-mentioned

rights please contact us per email at:

privacyrights@stellantis.com.

For more information regarding our contact

details please take a look at our Privacy &

Cookies Policy on the brand's website.

ASSISTANCE

►  If the vehicle breaks down, press button

2



for more than 2 seconds to request assistance

(confirmed by a voice message*).

►  Pressing again immediately cancels the

request.

69

Safety

5

Privacy mode allows you to manage the

level of sharing (data and/or location)

between your vehicle and CITROËN.

It can be configured in the

Settings

 touch

screen menu.

By default, depending on equipment,

deactivate/reactivate geolocation by

simultaneously pressing the 2 buttons, then

press the "ASSISTANCE" button to confirm.

If you purchased your vehicle outside the

CITROËN dealer network, we invite you

to have a dealer check the configuration of

these services and, if desired, modify them to

suit your wishes. In a multilingual country,

configuration is possible in the official national

language of your choice.

For technical reasons, in particular to

improve the quality of telematic services

for customers, the Manufacturer reserves the

right to carry out updates to the vehicle's

on-board telematic system at any time.

If you benefit from the Citroën Connect

Box offer with the SOS and Assistance

Pack included, there are additional services

available to you in your personal space, via

the website for your country.

For information about the SOS and

Assistance Pack, please refer to the general

conditions for these services.

Electronic stability control

(ESC)

The electronic stability control programme

includes the following systems:

–  Anti-lock braking system (ABS) and Electronic

brake force distribution (EBFD).

–  Emergency braking assistance (EBA).

–  Post Collision Safety Brake (PCSB).

–  Anti-slip regulation (ASR).

–  Dynamic stability control (DSC).

Anti-lock braking system

(ABS)/Electronic brake force

distribution (EBFD)

These systems enhance the vehicle’s stability

and handling during braking, and enable greater

control while cornering, particularly on poor or

slippery road surfaces.

ABS prevents wheel locking in the event of

emergency braking.

Electronic brake force distribution (EBFD)

manages overall braking pressure on each

individual wheel.

►

When braking in an emergency, depress

the pedal very firmly and maintain this

pressure.

Normal operation of the ABS may make

itself felt by slight vibrations of the brake

pedal.

The fixed illumination of this warning lamp

signals that there is a fault with the ABS.

The vehicle retains conventional braking. Drive

carefully at a moderate speed.

Have it checked by a CITROËN dealer or a

qualified workshop.

This warning lamp, when lit together with

the

STOP

 and ABS warning lamps,

accompanied by a message and an audible

signal, indicates an EBFD malfunction.

You must stop the vehicle.

Stop as soon as it is safe to do so and switch off

the ignition.

Contact a CITROËN dealer or a qualified

workshop.

When changing wheels (tyres and rims),

ensure that these are approved for your

vehicle.

After an impact

Have it checked by a CITROËN dealer or

a qualified workshop.

Post Collision Safety Brake

(PCSB)

If an accident is detected, the vehicle initiates

automatic post collision braking. The goal of this

system is to reduce the risk of further collisions if

the driver does not react.

The system is not operational if the capability

of the vehicle is to trigger and execute the

70

Safety

automatic post collision braking is not available,

as it can occur in destructive accidents or in

other specific accident scenarios.

It is possible to override the automatic braking by

pressing the brake pedal or accelerator pedal.

Operating conditions

The system operates, if the following conditions

are met:

–  Airbags or pyrotechnic seat belt pretensioners

have been deployed by the collision.

–  Braking systems and electric functions remain

continuously operational during and after

collision.

–  Driver has not depressed the brake or

accelerator pedal.

Malfunction

In the event of a

malfunction, one of these

warning lamps will come on fixed on the

instrument panel, accompanied by the Service

warning lamp, the display of a message and an

audible signal.

Have it checked by a CITROËN dealer or a

qualified workshop.

Emergency braking

assistance (EBA)

This system reduces the emergency stopping

distance, by optimising the braking pressure.

It is triggered in relation to the speed at which

the brake pedal is depressed. The effect of this

is a reduction in the resistance of the pedal and

an increase in braking efficiency.

Anti-slip regulation (ASR)

/ Dynamic stability control

(DSC)

Anti-slip regulation (or traction control) optimises

traction by using engine braking and by applying

the brakes on the driving wheels to avoid one

or more wheels spinning. It also enhances the

vehicle's directional stability.

If there is a difference between the vehicle’s

trajectory and the path desired by the driver, the

dynamic stability control system automatically

uses engine braking and the brakes on one or

more wheels to return the vehicle to the desired

path, within the limits of the laws of physics.

These systems are activated automatically every

time the vehicle is started.

These systems are activated in the event

of a problem with grip or trajectory

(confirmed by this warning lamp flashing on the

instrument panel).

Deactivation/Reactivation

In exceptional conditions (starting a vehicle

which is bogged down, stuck in snow, on soft

ground, etc.), it may be advisable to deactivate

the ASR system, so that the wheels can turn

freely and regain grip.

Reactivate the system as soon as the level of

grip permits.

This function is set via the

Driving/Vehicle



touch screen menu.

Deactivation is confirmed by the lighting

of this indicator lamp on the instrument

panel and the display of a message.

The ASR system is reactivated automatically

every time the ignition is switched off, or at

speeds over 31 mph (50 km/h).

Reactivation is manual below 31 mph (50 km/h).

Malfunction

In the event of a malfunction, this warning

lamp comes on on the instrument panel,

accompanied by the display of a message and

an audible signal.

Have it checked by a CITROËN dealer or a

qualified workshop.

ASR/DSC

These systems enhance safety during

normal driving, but should not encourage

the driver to take extra risks or drive at high

speed.

It is in conditions of reduced grip (rain, snow,

ice) that the risk of loss of grip increases. It

is therefore important for your safety to keep

these systems activated in all conditions, and

particularly in difficult conditions.

Correct operation of these systems depends

on compliance with the manufacturer's

recommendations relating to the wheels

71

Safety

5

(tyres and rims), braking and electronic

components, as well as the assembly and

repair procedures provided by CITROËN

dealers.

In order to ensure that these systems remain

effective in wintry conditions, the use of snow

or all-season tyres is recommended. All four

wheels must be fitted with tyres approved for

your vehicle.

All tyre specifications are listed on the

tyre/paint label. For more information

on

Identification markings

, refer to the

corresponding section.

Seat belts

Inertia reel

The seat belts are equipped with an inertia

reel which allows the strap length to adjust

automatically to the shape of the user. The seat

belt returns to its storage automatically when it

is not used.

The inertia reels are fitted with a device which

automatically locks the strap in the event of a

collision, emergency braking or if the vehicle rolls

over. It can be released by pulling the strap firmly

and then releasing it so that it reels in slightly.

Pyrotechnic pretensioning

This system improves safety in the event of a

frontal or side impact.

Depending on the severity of the impact, the

pyrotechnic pretensioning system instantly

tightens the seat belts against the body of the

occupants.

The pyrotechnic pretensioning seat belts are

enabled when the ignition is on.

Force limiting system

This system reduces the pressure of the seat

belt on the chest of the occupant, thus improving

their protection.

In the event of an impact

Depending on the nature and

seriousness of the impacts, the pyrotechnic

device may trigger before and independently

of airbag deployment. Deployment of the

pretensioners is accompanied by a slight

discharge of harmless smoke and a noise,

due to the activation of the pyrotechnic

cartridge incorporated in the system.

In all cases, the airbag warning lamp comes

on.

Following an impact, have the seat belt

system checked, and if necessary replaced,

by a CITROËN dealer or a qualified

workshop.

Front seat belts

The front seat belts are fitted with a pyrotechnic

pretensioning system and a force limiting

system.

Rear seat belts





Each of the rear seats has a three-point seat belt

with inertia reel.

The outer seats are fitted with a pyrotechnic

pretensioning and force limiting system.

Fastening

►  Pull the strap, then insert the tongue into the

buckle.

►  Check that the seat belt is fastened correctly

by pulling on the strap.

Unfastening

►  Press the red button on the buckle.

►  Guide the seat belt as it is reeled in.

72

Safety

Seat belts warning lamps

display









1.

Front left seat belt warning lamp

2.

Front right seat belt warning lamp

3.

Rear left seat belt warning lamp

4.

Rear centre seat belt warning lamp

5.

Rear right seat belt warning lamp

Not fastened/unfastened warning lamp

It comes on in red on both the instrument panel

and on the seat belts warning lamps display as

soon as the system detects that a seat belt is not

fastened or has been unfastened.

Type 1

Front seat belt not fastened alert

When the ignition is switched on, if the

driver or front passenger has not fastened their

seat belt, the corresponding warning lamp (

1

 or

2

) comes on in red. At a speed greater than 12

mph (20 km/h), the warning lamp flashes red,

accompanied by an audible signal for around 2

minutes. After this time has elapsed, the warning

lamp remains on fixed in red until the seat belt is

fastened.

Rear seat belt not fastened alert

When the ignition is switched on, if one of

the rear passengers has not fastened their seat

belt, the corresponding warning lamp (

3

,

4

 or

5

)

comes on in red for 60 seconds.

Seat belt unfastened alert

After the ignition is switched on, if the

driver or a passenger unfastens their seat belt,

the corresponding warning lamp (

1

,

2

,

3

,

4

 or

5

) comes on in red. At a speed greater than

12 mph (20 km/h), the warning lamp flashes,

accompanied by an audible signal for around 2

minutes. After this time has elapsed, the warning

lamp remains on until the seat belt has been

fastened again.

With the ignition on, if the driver or a

passenger fastens their seat belt, the

corresponding warning lamp (

1

,

2

,

3

,

4

 or

5

)

comes on in green on the display.

With the ignition on, if one of the front or

rear passenger seats is detected as being

unoccupied, the corresponding warning lamp (

2

,

3

,

4

 or

5

) comes on in grey.

When there are no longer any not fastened/

unfastened alerts, the green or grey warning

lamps remain on for around 30 seconds, then

go off.

Type 2

Front seat belt not fastened alert

When the ignition is switched on, if the

driver or front passenger has not fastened their

seat belt, the corresponding warning lamp (

1

 or

2

) comes on in red. At a speed greater than 12

mph (20 km/h), the warning lamp flashes red,

accompanied by an audible signal for around 2

minutes. After this time has elapsed, the warning

lamp remains on fixed in red until the seat belt is

fastened.

Rear seat belt not fastened alert

When the ignition is switched on, if one of

the rear passengers has not fastened their seat

belt, the corresponding warning lamp (

3

,

4

 or

5

)

comes on in red for 60 seconds.

Seat belt unfastened alert

After the ignition is switched on, if the

driver or a passenger unfastens their seat belt,

the corresponding warning lamp (

1

,

2

,

3

,

4

 or

5

) comes on in red. At a speed greater than

12 mph (20 km/h), the warning lamp flashes,

accompanied by an audible signal for around 2

minutes. After this time has elapsed, the warning

lamp remains on until the seat belt has been

fastened again.

Advice

The driver must ensure that passengers

use the seat belts correctly and that they

are all fastened before setting off.

Wherever seated in the vehicle, you must

always fasten the seat belt, even for short

journeys.

Do not invert the seat belt buckles, as they

will not fulfil their role properly.

73

Safety

5

To ensure the proper functioning of the belt

buckles, make sure that there are no foreign

bodies present (e.g. a coin) before fastening.

Before and after use, ensure that the seat belt

is reeled in correctly.

After folding or moving a seat or rear bench

seat, ensure that the seat belt is positioned

and reeled in correctly.

Installation

The lower part of the strap must be

positioned as low as possible over the pelvis.

The upper part must be positioned in the

hollow of the shoulder.

In order to be effective, a seat belt must:

–  be tightened as close to the body as

possible.

–  be pulled in front of you with a smooth

movement, ensuring that it is not twisted.

–  only be used to secure one person.

–  not show signs of tearing or fraying.

–  not be changed or modified, in order to

avoid affecting its performance.

Recommendations for children

Use a suitable child seat if the passenger

is less than 12 years old or shorter than 1.5

metres.

Never use the same seat belt to secure more

than one child.

Never carry a child on your lap.

For more information on

Child seats

, refer to

the corresponding section.

Maintenance

In accordance with current safety

regulations, for all work on your vehicle's

seat belts, contact a qualified workshop with

the skills and equipment needed, which a

CITROËN dealer is able to provide.

Have the seat belts checked regularly by a

CITROËN dealer or a qualified workshop,

particularly if the straps show signs of

damage.

Clean the seat belt straps with soapy water or

a textile cleaning product, sold by CITROËN

dealers.

Airbags

General information

System designed to help improve the safety

of the occupants sitting in the front seats and

the rear outer seats, in the event of a violent

collision. The airbags supplement the action

of the seat belts equipped with a force limiting

system.

Electronic detectors record and analyse the

front and side impacts sustained in the impact

detection zones:

–  In the event of violent impact, the airbags

deploy instantly and help better protect the

occupants of the vehicle; immediately after the

impact, the airbags deflate rapidly in order not

to hinder the visibility or the possible exit of the

occupants.

–  In the event of a slight impact, a rear impact

and under certain rollover conditions, the airbags

may not deploy; only the seat belt helps to

protect you in these situations.

The seriousness of the impact depends on the

nature of the obstacle and the speed of the

vehicle at the moment of collision.

The airbags do not operate when the

ignition is switched off.

This equipment will only deploy once. If a

second impact occurs (during the same or a

subsequent accident), the airbag will not be

deployed again.

Impact detection zones

A.

Front impact zone

B.

Side impact zone

When one or more airbags are deployed,

the detonation of the pyrotechnic charge

74

Safety

incorporated in the system makes a noise and

releases a small quantity of smoke.

This smoke is not harmful, but sensitive

individuals may experience irritation.

The detonation noise associated with the

deployment of one or more airbags may result

in a slight loss of hearing for a short time.

Front airbags





System that protects the driver and front

passenger in the event of a serious front impact,

limiting the risk of head and chest injury.

The driver's airbag is fitted in the centre of the

steering wheel; the front passenger airbag is

fitted in the dashboard above the glove box.

* For more information on Deactivating the front passenger airbag, refer to the corresponding section.

Deployment

They deploy, except the front passenger airbag

if it is deactivated*, in the event of a serious front

impact to all or part of the front impact zone

A

.

The front airbag inflates between the thorax and

head of the front occupant of the vehicle and the

steering wheel, driver's side, and the dashboard,

passenger's side, to cushion their forward

movement.

Lateral airbags





In the event of a serious side impact, this system

protects the driver and front passenger to

mitigate the risk of injury to the chest, between

the hip and the shoulder.

Each lateral airbag is fitted in the seat backrest

frame, on the door side.

Deployment

The lateral airbags are deployed on one side in

the event of a serious side impact applied to all

or part of the side impact zone

B

.

The lateral airbag inflates between the chest of

the vehicle's occupant and the corresponding

door panel.

Curtain airbags

System contributing towards greater protection

for the driver and passengers (with the exception

of the rear centre passenger) in the event of a

serious side impact in order to limit the risk of

injury to the side of the head.

Each curtain airbag is built into the pillars and

the upper passenger compartment area.

Deployment

It deploys simultaneously with the corresponding

lateral airbag in the event of a serious side

impact applied to all or part of the side impact

zone

B

.

The curtain airbag inflates between the front

and rear occupants of the vehicle and the

corresponding windows.

Malfunction

In the event of a malfunction, this warning

lamp lights up on the instrument panel.

75

Safety

5

Contact a CITROËN dealer or a qualified

workshop to have the system checked.

The airbags may not be deployed in the event of

a serious impact.

In the event of a minor impact or bump at

the side of the vehicle or if the vehicle

rolls over, the airbags may not be deployed.

In the event of a rear or front collision, none of

the lateral airbags are deployed.

Advice

For the airbags to be fully effective,

observe the safety recommendations

below.

Adopt a normal and upright sitting position.

Fasten your seat belt and position it correctly.

Do not place anything between the occupants

and the airbags (e.g. child, animal, object), do

not fix or attach anything near or in the path of

the airbags, as this could cause injuries when

they are deployed.

Never modify the original definition of the

vehicle, particularly in the area directly around

the airbags.

Even if all of the precautions mentioned are

observed, a risk of injury or of minor burns to

the head, chest or arms cannot be ruled out

when an airbag is deployed. The bag inflates

almost instantly (within a few milliseconds)

then deflates within the same time,

discharging the hot gas via openings provided

for this purpose.

After an accident or if the vehicle has been

stolen, have the airbag systems checked.

All work must be carried out only by a

CITROËN dealer or a qualified workshop

Front airbags

Do not drive holding the steering wheel

by its spokes or resting your hands on the

centre part of the wheel.

Passengers must not place their feet on the

dashboard.

Do not smoke as deployment of the airbags

can cause burns or the risk of injury from a

cigarette or pipe.

Never remove or pierce the steering wheel or

hit it violently.

Do not fix or attach anything to the steering

wheel or dashboard, as this could cause

injuries when the airbags are deployed.

Lateral airbags

Use only approved seat covers

compatible with the deployment of these

airbags. For information on the range of seat

covers suitable for your vehicle, contact a

CITROËN dealer.

Do not fix or attach anything to the seat

backrests (e.g. clothing) as this could cause

injuries to the chest or arm when the airbag is

deployed.

Do not sit with the upper part of the body any

nearer to the door than necessary.

The vehicle's front door panels include side

impact sensors.

A damaged door or any unauthorised or

incorrectly executed work (modification or

repair) on the front doors or their interior trim

could compromise the operation of these

sensors - risk of malfunction of the lateral

airbags!

All work must be carried out only by a

CITROËN dealer or a qualified workshop

Curtain airbags

Do not fix or attach anything to the roof,

as this could cause head injuries when the

curtain airbag is deployed.

Do not remove the grab handles installed on

the roof.

Child seats

The regulations on carrying children are

specific to each country. Refer to the

legislation in force in your country.

For maximum safety, please observe the

following recommendations:

–  In accordance with European regulations,

all children under the age of 12 or less than

1,5 metres tall must travel in approved child

76

Safety

seats suited to their weight

, on seats fitted with

a seat belt or ISOFIX mountings.

–

Statistically, the safest seats in your

vehicle for carrying children are the rear

seats.

–

Children weighing less than 9 kg must

travel in the "rearward facing" position,

whether in the front or rear of the vehicle.

It is recommended

 that children travel

on the

rear seats

 of the vehicle:

– ‘

rearward facing

’ up to the age of 3,

– ‘

forward facing

’ over the age of 3.

Make sure that the seat belt is correctly

positioned and tightened.

For child seats with a support leg, ensure that

the support leg is in firm and steady contact

with the floor.

Advice

An incorrectly installed child seat

compromises the child's safety in the

event of an accident.

Ensure that there is no seat belt or seat belt

buckle under the child seat, as this could

destabilise it.

Remember to fasten the seat belts or the

harness of child seats, keeping the slack

relative to the child's body to a minimum,

even for short journeys.

When installing a child seat using the seat

belt, ensure that the seat belt is tightened

correctly on the child seat and that it secures

the child seat firmly on the seat of the vehicle.

If the passenger seat is adjustable, move it

forwards if necessary.

Remove the head restraint before

installing a child seat with a backrest on a

passenger seat.

Ensure that the head restraint is stored or

attached securely to prevent it from being

thrown around the vehicle in the event of

sharp braking. Refit the head restraint once

the child seat has been removed.

Installing a booster seat

The chest part of the seat belt must be

positioned on the child's shoulder without

touching the neck.

Ensure that the lap part of the seat belt

passes correctly over the child's thighs.

Use a booster seat with backrest, equipped

with a belt guide at shoulder level.

Additional protections

To prevent accidental opening of the

doors and rear windows, use the "Child lock".

Take care not to open the rear windows by

more than one third.

To protect young children from the rays of the

sun, fit side blinds on the rear windows.

As a safety precaution, do not leave:

–  a child alone and unattended in a vehicle,

–  a child or an animal in a vehicle which is

exposed to the sun, with the windows closed,

–  the keys within reach of children inside the

vehicle.

Child seat at the rear

Forward-facing or rearward-facing









►  Move the vehicle's front seat forward and

straighten the backrest so that the legs of the

child in the forward-facing or rearward-facing

child seat itself do not touch the vehicle's front

seat.

►  Check that the backrest of the forward-facing

child seat is as close as possible to the backrest

of the vehicle's rear seat, and ideally in contact

with it.

Centre rear seat

A child seat with a support leg must never be

installed on the

centre rear passenger seat

.

77

Safety

5

Child seat at the front





►  Adjust the front passenger seat to the

highest

 and

fully back longitudinal position

,

with the backrest straightened

.

"Forward facing"





You must leave the front passenger

airbag active.

"Rearward facing"





The front passenger airbag must be

deactivated before installing a rearward

facing child seat. Otherwise,

the child risks

being seriously injured or killed if the

airbag is deployed

.





Warning label - Front passenger airbag





You must comply with the following instruction,

as reminded by the warning label on both sides

of the passenger sun visor:

NEVER use a rearward facing child restraint

on a seat protected by an ACTIVE AIRBAG in

front of it, DEATH or SERIOUS INJURY to the

CHILD can occur.

Deactivating the front

passenger airbag





Passenger airbag OFF

To ensure the safety of the child, the front

passenger airbag MUST be deactivated

when a "rearward facing" child seat is

installed on the front passenger seat.

Otherwise, the child risks being seriously

injured or killed in the event of deployment of

the airbag.

Vehicles not equipped with a

deactivation/reactivation control

Installing a "rearward facing" child seat on

the front passenger seat is strictly prohibited

- risk of death or serious injury in the event of

airbag deployment!

Deactivating/Reactivating the front

passenger airbag

For vehicles on which it is fitted, the switch is

located on the side of the dashboard or inside

the glove box.



78

Safety



With the ignition off:

►  To deactivate the airbag, turn the key in the

switch to the "

OFF

" position.

►  To reactivate it, turn the key to the "

ON

"

position.

When the ignition is switched on:

This warning lamp comes on and remains

lit to signal deactivation.

Or

This warning lamp comes on for about 1

minute to signal activation.

Recommended child seats

Range of child seats secured using a

three-

point seat belt

.

Group 0+: from birth to 13 kg





L1

"RÖMER Baby-Safe"

Installed in the "rearward facing" position.

Groups 2 and 3: from 15 to 36 kg





L5

"RÖMER KIDFIX 2R"

Can be fitted to the vehicle's ISOFIX

mountings.

The child is restrained by the seat belt.

Only suitable for installation on the side rear

seats.

The head restraint on the vehicle seat must

be removed.

Groups 2 and 3: from 15 to 36 kg





L6

"GRACO Booster"

The child is restrained by the seat belt.

Only suitable for installation on the front

passenger seat or on the rear side seats.

"ISOFIX" mountings

The seats shown below are fitted with ISOFIX

compliant mountings:





The mountings comprise three rings for each

seat, indicated by a marking:

–  Two rings

A

, located between the vehicle seat

backrest and cushion.



79

Safety

5



These rings are located behind zips.

The 2 latches on

ISOFIX child seats

 are

secured to them.

–  One ring

B,

 located behind the seat, called the

TOP TETHER

, for attaching seats fitted with an

upper strap.





This system prevents the child seat from tipping

forwards in the event of a front impact.

This ISOFIX mounting system provides fast,

reliable and safe fitting of the child seat in the

vehicle.

To secure the child seat to the

TOP TETHER

:

►  Remove and stow the head restraint before

installing the child seat on this seat (refit it once

the child seat has been removed).

►  Pass the strap of the child seat behind the

seat backrest, centring it between the openings

for the head restraint rods.

►  Secure the upper strap hook to ring

B

.

►  Tighten the upper strap.

When fitting an ISOFIX child seat to the

left-hand rear seat of the bench seat,

before fitting the seat, first move the centre

rear seat belt towards the middle of the

vehicle, so as to avoid the seat interfering

with the operation of the seat belt.

An incorrectly installed child seat in a

vehicle compromises the child's safety in

the event of an accident.

Strictly observe the fitting instructions

provided in the user guide supplied with the

child seat.

For information about the options for

fitting ISOFIX child seats in your vehicle,

refer to the summary table.

Recommended ISOFIX child seats

Also consult the user guide from the child

seat’s manufacturer to find out how to

install and remove the seat.

"RÖMER Baby-Safe and its ISOFIX base"

(size category:

E

)

Group 0+: from birth to 13 kg





Installed "rearward facing" using an ISOFIX

base which is attached to rings

A

.

The base has a support leg, height-

adjustable, which rests on the vehicle's floor.

This child seat can also be secured with a

seat belt. In this case, only the shell is used

and attached to the vehicle seat using the

three-point seat belt.

"

RÖMER Duo Plus ISOFIX

"

(size category:

B1

)

Group 1: from 9 to 18 kg





80

Safety

"

RÖMER Duo Plus ISOFIX

"

(size category:

B1

)

Group 1: from 9 to 18 kg

Suitable for forward-facing installation only.

Attached to rings

A

 and ring

B

, referred to as

TOP TETHER, using an upper strap.

Three seat body angles: sitting, reclining,

lying down.

This child seat can also be used in seat

positions not equipped with ISOFIX

mountings. In this case, it must be secured to

the vehicle's seat by the three-point seat belt.

Adjust the front seat of the vehicle so that the

child's feet do not touch the backrest.

i-Size child seats

i-Size child seats have two latches that are anchored to the two rings

A

.

These i-Size child seats also have:

–  either an upper strap that is attached to ring

B

.

–  or a support leg that rests on the vehicle floor, compatible with the approved i-Size seat position.

Their role is to prevent the child seat from tipping forward in the event of a collision.

For more information on the

ISOFIX mountings

, refer to the corresponding section.

81

Safety

5

Installing universal, ISOFIX and i-Size child seats

In compliance with European regulations, this table indicates the possibilities for installing child seats secured using the seat belt and universally approved

(a)

 as well as the largest

ISOFIX

 and

i-Size

 child seats for the seat positions fitted with

ISOFIX

 anchorage points in the vehicle.

Seat number

Front seats

(j)

Rear seats

(j)





1

3

4

5

6





3

1

4

5

6

Front passenger airbag

Deactivated "OFF"

(b)

Activated "ON"

(c)

Position compatible with a

universal (a)



child seat

no

yes

(d) (h)

yes

(d) (i)

yes

yes

(e)

yes

Position compatible with an

i-Size

 child

seat

no

no

(f)

yes

no

(f)

yes

Position equipped with a

TOP TETHER



hook

no

no

(f)

yes

no

(f)

yes

"

Carrycot

" type child seat

no

no

(f)

no

"Rearward facing"

ISOFIX

 child seat

no

no

(f)

R3

(g)

no

(f)

R3

(g)

"Forward facing"

ISOFIX

 child seat

no

no

(f)

F3

(g)

no

(f)

F3

(g)

Booster child seat

no

B3

(f) (k)

B3

(g)

B3

(f)

B3

(g)
