178

In the event of a breakdown

Repair procedure

Do not remove any foreign body

(e.g. nail, screw) which has penetrated

the tyre.

►  Park the vehicle without obstructing traffic

and apply the parking brake.

►  Follow the safety instructions (hazard

warning lamps, warning triangle, high visibility

jacket, etc.) according to the legislation in force

in the country in which you are driving.

►  Switch the ignition off.

►  Remove the valve cap from the tyre to be

repaired, and place it in a clean place.





►  Connect the pipe from the bottle of sealant to

the valve of the tyre to be repaired and tighten

firmly.

►  Connect the pipe from the compressor to the

bottle of sealant.

►  Check that the compressor switch is in

position "

O

".

►  Fully uncoil the electric cable stowed under

the compressor.

►  Connect the compressor's electric plug to one

of the vehicle's 12 V sockets.

►  Affix the speed limit sticker.

The speed limit sticker must be affixed

inside the vehicle in the area close to the

driver, to remind them that a wheel is in

temporary use.

►  Switch the ignition on.





►  Switch on the compressor by moving the

switch to position "

I

" until the tyre pressure

reaches 2 bar. The sealant product is injected

under pressure into the tyre; do not disconnect

the pipe from the valve during this operation (risk

of blowback).

If after approximately 7 minutes, the

pressure of 2 bar is not reached, this

indicates that the tyre is not repairable;

contact a CITROËN dealer or a qualified

workshop for assistance.

►  Move the switch to position "

O

".

►  Disconnect the compressor's electric plug

from the vehicle's 12 V socket.

►  Remove the kit.

►  Refit the cap on the valve.

►  Remove and store the bottle of sealant.

The sealant product is harmful if

swallowed and causes irritation to the

eyes.

Keep this product out of the reach of children.

The use-by date of the fluid is marked on the

bottle.

After use, do not discard the bottle into the

environment; take it to a CITROËN dealer or

an authorised waste disposal site.

Do not forget to obtain a new bottle of

sealant, available from a CITROËN dealer or

a qualified workshop.





►  Drive immediately for approximately 3 miles

(5 kilometres) at reduced speed (between

12 and 37 mph (20 and 60 km/h)) to plug the

puncture.

179

In the event of a breakdown

8

►  Stop to check the repair

and the tyre

pressure

 using the kit.

With a tyre repaired using this type of kit,

do not exceed a speed of 50 mph

(80 km/h) and do not drive more than

50 miles (80 km).

You must contact a CITROËN dealer or a

qualified workshop to have the repair checked

and the tyre changed.

Checking/adjusting tyre

pressures

The compressor can be used,

without injecting

sealant

, to check and, if necessary, adjust the

tyre pressures.

►  Remove the valve cap from the tyre and keep

it in a clean place.

►  Uncoil the pipe stowed under the compressor.

►  Screw the pipe onto the valve and tighten

firmly.

►  Check that the compressor switch is in

position "

O

".

►  Fully uncoil the electric cable stowed under

the compressor.

►  Connect the compressor's electric plug to one

of the vehicle's 12 V sockets.

►  Switch the ignition on.

►  Start the compressor by placing the switch at

position "

I

" and adjust the pressure to the value

shown on the vehicle's tyre pressure label. To

deflate: press the black button located on the

compressor pipe, near the valve connection.

If after 7 minutes the pressure of 2 bar is

not reached, the tyre is damaged;

contact a CITROËN dealer or a qualified

workshop for assistance.

►  Once the correct pressure is reached, put the

switch in position "

O

".

►  Remove the kit and stow it.

►  Refit the cap on the valve.

Spare wheel

Visit this link to view explanatory videos:

http://q-r.to/bagGl9

For more information on the

Tool kit

,

refer to the corresponding section.

Accessing the spare wheel





The spare wheel is stored in the boot, under the

floor.

To access the spare wheel, first refer to the

Tool

kit

 section.

Depending on version, the spare wheel

may be a standard size steel or alloy

wheel.

In some countries, it is a ‘space saver’ wheel.

Removing the spare wheel





►  Slacken the central nut.

►  Remove the fastening device (nut and bolt).

180

In the event of a breakdown

►  Lift the spare wheel towards you from the

rear.

►  Take the wheel out of the boot.

Putting the spare wheel back in place





►  Put the spare wheel back in place in its

housing.

►  Slacken the nut on the bolt by a few turns.

►  Position the fastening device (nut and bolt) in

the middle of the wheel.

►  Tighten the central nut sufficiently to retain

the wheel correctly.

►  Put the tool box back in place in the middle of

the wheel and clip it in place.

If there is no wheel in the well, the

fastening device (nut and bolt) cannot be

refitted.

Removing a wheel

Parking the vehicle

Immobilise the vehicle where it does

not obstruct traffic: the ground must be level,

stable and non-slippery.

With a manual gearbox, engage first gear

to lock the wheels, apply the parking brake,

unless it is set to automatic mode, and switch

off the ignition.

With an automatic gearbox, select mode

P



to lock the wheels, apply the parking brake,

unless it is set to automatic mode, and switch

off the ignition.

Check that the parking brake indicator lamps

on the instrument panel are on fixed.

The occupants must get out of the vehicle

and wait where they are safe.

If necessary, place a chock under the wheel

diagonally opposite the wheel to be changed.

Never go underneath a vehicle raised using a

jack; use an axle stand.

Wheel with wheel trim

When removing the wheel

, first remove

the wheel trim by pulling at the valve aperture

using the wheelbrace.

When refitting the wheel

, refit the wheel

trim, starting by placing its aperture in line

with the valve and then pushing it into place

all round its edge with the palm of your hand.









►  To remove the wheel bolt cover on each of

the bolts, use tool

7

 (alloy wheels).

►  Fit security socket

2

 on wheelbrace

5

 to

slacken the security bolt.

►  Slacken the other bolts using the

wheelbrace

5

 only.

Never use an impact wrench on the

security bolt socket.





►  Place the foot of jack

6

 on the ground and

ensure that it is directly below the front

A

 or

181

In the event of a breakdown

8

rear

B

 jacking point on the underbody, whichever

is closest to the wheel to be changed.





►  Extend jack

6

 until its head comes into

contact with jacking point

A

 or

B

; contact area

A



or

B

 on the vehicle must be properly inserted

into the central part of the head of the jack.

►  Raise the vehicle until there is sufficient

space between the wheel and the ground to

easily admit the spare (not punctured) wheel.

Ensure that the jack is stable. If the

ground is slippery or loose, the jack may

slip or collapse - risk of injury!

Take care to position the jack strictly at

one of the jacking points

A

 or

B

 under the

vehicle, ensuring that the head of the jack is

centred under the contact area on the vehicle.

Otherwise, there is a risk of damage to the

vehicle and/or of the jack collapsing - risk of

injury!





►  Remove the bolts and store them in a clean

place.

►  Remove the wheel.

Fitting a wheel

Fitting a steel or "space-saver" type

spare wheel

If the vehicle is fitted with alloy wheels, the

washers

A

 do not make contact with the steel

or "space-saver" type spare wheel. The wheel

is held in place by the conical contact surface

B

 of each bolt.





►  Fit the wheel on the hub.

►  Screw in the bolts by hand as far as possible.

►  Pre-tighten the security bolt using the

wheelbrace

5

 equipped with a security socket

2

.

►  Pre-tighten the other bolts using the

wheelbrace

5

 only.





►  Lower the vehicle again fully.

►  Fold jack

6

 and remove it.



182

In the event of a breakdown



►  Tighten the security bolt using the

wheelbrace

5

 equipped with a security socket

2

.

►  Tighten the other bolts using the

wheelbrace

5

 only.

►  Refit the bolt covers to each of the bolts

(depending on equipment).

►  Store the tools.

After changing a wheel

Store the punctured wheel in the boot or,

depending on version, remove the central cover

first to store it beneath the floor in place of the

spare wheel.

With a non-standard or 'space-saver'

spare wheel

Deactivate certain driving aid functions

(Active Safety Brake, Adaptive cruise control,

etc.).

Do not exceed the maximum authorised

speed of 50 mph (80 km/h) or the maximum

distance of 50 miles (80 km).

Driving with more than one spare wheel of

this type is prohibited.

The wheel trim from the replaced wheel must

not be refitted.

Visit a CITROËN dealer or a qualified

workshop.

Have the tightening of the spare wheel's bolts

and its tyre pressure checked.

Have the punctured tyre examined. After

inspection, the technician will advise you on

whether the tyre can be repaired or if it must

be replaced.

Changing a bulb

In some weather conditions (e.g. low

temperature or humidity), misting on the

internal surface of the glass of the headlamps

and rear lamps is normal, and will disappear

after the lamps have been on for a few

minutes.

Never look too closely at the light beam

of LED technology lamps - risk of serious

eye injury!





The headlamps have polycarbonate

lenses with a protective coating:

–

Do not clean them with a dry or abrasive

cloth, nor with detergent or solvent

products.

–  Use a sponge and soapy water or a pH

neutral product.

–  When using a high-pressure washer on

persistent marks, do not keep the lance

directed towards the headlamps, lamps or

their edges for too long, so as not to damage

their protective coating and seals.

Changing a bulb must only be done with

the ignition off and after the headlamp /

lamp has been switched off for several

minutes - risk of serious burns!

Do not touch the bulb directly with your

fingers; use a lint-free cloth.

183

In the event of a breakdown

8

It is essential only to use anti-ultraviolet

(UV) type bulbs, so as not to damage the

headlamp.

Always replace a failed bulb with a new bulb

of the same type and specification. To avoid

lighting imbalance, replace the bulbs in pairs.

Refitting the lamp units

Perform the operations in the reverse

order to dismantling.

Light-emitting diode (LED)

headlamps and lamps

Depending on version, the affected types of

headlamps/lamps are:

–  LED technology headlamps.

–  Front foglamps.

–  Direction indicator side repeaters.

–  Side spotlamps.

–  Brake lamps.

–  Third brake lamp.

–  Rear sidelamps.

–  Number plate lamps.

If you need to replace this type of bulb,

you must contact a CITROËN dealer or a

qualified workshop.

Do not touch the LED technology bulbs - risk

of electrocution!

Front lamps





1.

Daytime running lamps or Direction indicators

(LED)

2.

Dipped beam (LED)

3.

Daytime running lamps (LED)

4.

Main beam headlamps (LED)

5.

Foglamps (P21W or LED)

Foglamps (P21W)





►  Insert a flat screwdriver into the hole in the

trim.

►  Pull and lever to unclip the foglamp trim.

►  With a Torx screwdriver, remove the two

module fixing screws.

►  Remove the module from its housing.





►  Disconnect the bulb holder connector.

►  Turn the bulb holder a quarter turn and

remove it.

►  Replace the unit.

184

In the event of a breakdown

To replace this type of bulb, you can also

contact a CITROËN dealer or a qualified

workshop.

Rear lamps





1.

Brake lamps (LED)

2.

Sidelamps (LED)

3.

Direction indicators (WY21W)

4.

Reversing lamps (W16W)

5.

Foglamps (P21W)

Direction indicators (on the wings)





►  Open the tailgate, then unclip the access

cover on the side in question.

►  Unblock the 2 lamp fixing nuts with a 10 mm

box spanner.

►  To avoid losing the nuts in the wing trim if it

drops, first place a cloth below.

►  Manually unscrew and remove the lamp

fixing nuts.





►  From the outside, carefully remove the lamp

by pulling it to the rear, then up.

►  Disengage the cable sleeve from the body

panel.

►  Turn the bulb holder a quarter turn using a

universal pair of pliers, if necessary, and pull it

out.

►  Remove the bulb and replace it.

Reversing lamps (on the tailgate)





►  Open the tailgate, then insert a flat

screwdriver into the cut-out to unclip the access

cover on the side in question.

►  Unscrew and remove the 2 lamp fixing Torx

screws with a Torx screwdriver.





►  From the outside, carefully remove the lamp

by pulling it to the rear.

185

In the event of a breakdown

8

►  Disconnect the lamp connector by pressing

on each side.

►  Turn the bulb holder a quarter turn and

remove it.

►  Remove the bulb and replace it.

Foglamps





These bulbs are replaced from outside the rear

bumper.

►  Pass your hand under the bumper.

►  Turn the bulb holder a quarter turn and

remove it.

►  Turn the bulb a quarter turn and replace it.

When changing the bulb within a few

minutes of switching off the ignition, take

care not to touch the exhaust - risk of burns!

Fuses

Changing a fuse

All work must be carried out only by a

CITROËN dealer or a qualified workshop

The replacement of a fuse by a third party

could cause a serious malfunction of the

vehicle.

Installing electrical accessories

The vehicle's electrical system is

designed to operate with standard or optional

equipment.

Before fitting other electrical equipment

or accessories to your vehicle, contact a

CITROËN dealer or a qualified workshop.

CITROËN accepts no responsibility for

the cost incurred in repairing the vehicle

or for rectifying malfunctions resulting from

the installation of accessories not supplied or

not recommended by CITROËN and not

installed in accordance with its

recommendations, in particular when the

combined power consumption of all of the

additional equipment connected exceeds 10

milliamperes.

12 V battery/Accessory

batteries

Lead-acid starter batteries

These batteries contain harmful

substances (sulphuric acid and lead).

They must be disposed of in accordance

with regulations and must never under any

circumstances be discarded with household

waste.

Dispose of used batteries at a designated

collection point.

Protect your eyes and face before

handling the battery.

All operations on the battery must be carried

out in a well ventilated area and away from

naked flames and sources of sparks, to avoid

any risk of explosion or fire.

Wash your hands afterwards.

Electronic control units/LED

technology headlamps

Never connect the negative jump lead to the

metal part of the electronic control units or at

the back of the headlamps.

Risk of destroying the electronic control

units and/or headlamps!

Connect to the remote earth point provided

for this purpose.

186

In the event of a breakdown

Frozen battery

Never try to charge a frozen battery - risk

of explosion!

If the battery has frozen, have it checked by a

CITROËN dealer or by a qualified workshop,

who will verify that the internal components

have not been damaged and that the case

has not cracked, which could lead to a risk of

leakage of toxic and corrosive acid.

Automatic gearbox

Never try to start the engine by pushing

the vehicle.

Symbols

No sparks or naked flames, no smoking.



Always protect your eyes. Explosive

gases can cause blindness and injury.

Keep the vehicle's battery out of the reach

of children.

The vehicle's battery contains sulphuric

acid which can make you go blind or

cause severe burns.

For more information, refer to the

handbook.

Explosive gases can be present close to

the battery.

With petrol/Diesel engines

Procedure for starting the engine using another

battery or for charging a discharged battery.

Accessing the battery

The battery is located under the bonnet.





For access to the (+) terminal:

►  Release the bonnet by pulling the internal

release lever, then the external safety catch.

►  Raise the bonnet.

(+)

 Positive terminal with a quick-release

terminal.

(-)

 Negative terminal.

As the battery's negative terminal is not

accessible, a remote earth point is located near

the battery.

Starting using another battery

If the vehicle's battery is flat, the engine can be

started using a backup battery (either external or

from another vehicle) and jump leads or using a

battery booster.

Never start the engine by connecting a

battery charger.

Never use a 24 V or higher battery booster.

Check beforehand that the backup battery

has a nominal voltage of 12 V and a capacity

at least equal to that of the discharged

battery.

The two vehicles must not be in contact with

each other.

Switch off all electricity-consuming equipment

on both vehicles (audio system, wipers,

lighting, etc.).

Make sure that the jump leads are well away

from the engine’s moving parts (fan, belt,

etc.).

Do not disconnect the (+) terminal while the

engine is running.





►  Lift the plastic cover on the (+) terminal, if the

vehicle has one.

►  Connect the red cable to the (+) terminal of

flat battery

A

 (at the metal elbow), then to the

(+) terminal of the backup battery

B

 or of the

booster.

►  Connect one end of the green or black cable

to the (-) terminal of the backup battery

B

 or of

187

In the event of a breakdown

8

the booster (or to an earth point on the assisting

vehicle).

►  Connect the other end of the green or black

cable to the earth point

C

.

►  Start the engine on the assisting vehicle and

leave it running for a few minutes.

►  Operate the starter on the broken down

vehicle and let the engine run.

If the engine does not start immediately, switch

off the ignition and wait a few moments before

trying again.

►  Wait for it to return to idle.

►  Disconnect the jump leads

in reverse order

.

►  Refit the plastic cover to the (+) terminal, if

the vehicle has one.

►  Allow the engine to run for at least

30 minutes, with the vehicle stationary, so that

the battery reaches an adequate state of charge.

Driving immediately without having

reached a sufficient level of charge may

affect some of the vehicle's functions (e.g.

Stop & Start).

Charging the battery using a battery

charger

For optimum service life of the battery, it is

essential to maintain an adequate state of

charge.

In some circumstances, it may be necessary to

charge the battery:

–  When using the vehicle mainly for short

journeys.

–  If the vehicle is to be taken off the road for

several weeks.

Contact a CITROËN dealer or a qualified

workshop.

To charge the vehicle's battery yourself,

use only a charger compatible with

lead-acid batteries with a nominal voltage of

12 V.

Follow the instructions provided by the

manufacturer of the charger.

Never reverse polarities.

It is not necessary to disconnect the

battery.

►  Switch the ignition off.

►  Switch off all electrical consumers (audio

system, lighting, wipers, etc.).





►  Switch off charger

B

 before connecting

the cables to the battery, so as to avoid any

dangerous sparks.

►  Ensure that the charger cables are in good

condition.

►  Lift the plastic cover on the (+) terminal, if the

vehicle has one.

►  Connect the cables of charger

B

 as follows:

•  the positive (+) red cable to the (+) terminal

of battery

A

,

•  the negative (-) black cable to earth point

C



on the vehicle.

►  At the end of the charging operation, switch

off charger

B

 before disconnecting the cables

from battery

A

.

If this label is present, use only a 12 V

charger to avoid causing irreversible

damage to the electrical components.

24V

12V

Disconnecting/reconnecting the

battery

In order to maintain an adequate state of

charge for starting the engine, we recommend

disconnecting the battery if the vehicle is to be

unused for an extended period.

Before disconnecting the battery:

►  Close all openings (doors, boot, windows,

roof).

188

In the event of a breakdown

►  Switch off all electricity-consuming devices

(audio system, wipers, lamps, etc.).

►  Switch off the ignition and wait for 4 minutes.

After accessing the battery, it is only necessary

to disconnect the (+) terminal.

Quick-release terminal clamp

Disconnecting the (+) terminal





►  Depending on equipment, lift the plastic cover

on the

(+)

 terminal.

►  Raise lever

A

 fully to release clamp

B

.

►  Remove clamp

B

 by lifting it off.

Reconnecting the (+) terminal





►  Raise lever

A

 fully.

►  Refit open clamp

B

 on the

(+)

 terminal.

►  Push clamp

B

 fully down.

►  Lower lever

A

 to lock clamp

B

.

►  Depending on equipment, lower the plastic

cover on the

(+)

 terminal.

Do not force the lever when pressing on

it, as if the clamp is not positioned

correctly, locking will then not be possible.

Start the procedure again.

The Stop & Start system may not be

operational during the trip following the

first engine start.

In this case, the system will only be available

again after a continuous period with the

vehicle immobilised, the duration of which

depends on the exterior temperature and the

state of charge of the battery (up to about 8

hours).

With Rechargeable hybrid

engines

The rechargeable hybrid system has two

accessory batteries: one at the front and one at

the rear of the vehicle.

Replacing the accessory batteries

Contact a CITROËN dealer or a qualified

workshop.

Jump-starting another vehicle

Do not start or jump-start another vehicle

using the vehicle’s accessory batteries.

Accessing the accessory batteries

Front

The front battery is located under the bonnet.





For access to the (+) terminal:

189

In the event of a breakdown

8

►  Release the bonnet by pulling the internal

release lever, then the external safety catch.

►  Raise the bonnet.

(+)

 Positive terminal with a quick-release

terminal.

(-)

 Negative terminal.

As the battery's negative terminal is not

accessible, a remote earth point is located near

the battery.

Rear

The rear battery is located in the boot.

To reach the battery:





►  Lift the boot floor.

(+)

 Positive terminal, protected by a red plastic

cover (not accessible).

(-)

 Negative terminal with a black quick-release

connector.

Charging the front battery using a

battery charger

For optimum service life of the front battery, it

is essential to maintain an adequate state of

charge.

In some circumstances, it may be necessary to

charge the front battery:

–  When using the vehicle mainly for short

journeys.

–  If the vehicle is to be taken off the road for

several weeks.

Contact a CITROËN dealer or a qualified

workshop.

To charge the vehicle's front battery

yourself, use only a charger compatible

with lead-acid batteries with a nominal voltage

of 12 V.

Follow the instructions provided by the

manufacturer of the charger.

Never reverse polarities.

It is not necessary to disconnect the

battery.

►  Switch the ignition off.

►  Switch off all electrical consumers (audio

system, lighting, wipers, etc.).





►  Switch off charger

B

 before connecting

the cables to the battery, so as to avoid any

dangerous sparks.

►  Ensure that the charger cables are in good

condition.

►  Lift the plastic cover on the (+) terminal, if the

vehicle has one.

►  Connect the cables of charger

B

 as follows:

•  Positive (+) red cable to the (+) terminal on

battery

A

.

•  Negative (-) black cable to earth point

C

 on

the vehicle.

►  At the end of the charging operation, switch

off charger

B

 before disconnecting the cables

from battery

A

.

Disconnecting/reconnecting the

accessory batteries

Procedure for disconnecting/reconnecting the

accessory batteries in the event of long-term

immobilisation of the vehicle.

Before disconnecting the accessory batteries:

►  Open the driver's door and boot.

190

In the event of a breakdown

►  Close all other doors.

►  Switch off all electrical consumers (audio

system, wipers, lamps, etc.).

►  Switch off the ignition and wait for the

READY

 indicator lamp to go out.

►  Observe a waiting time of 4 minutes.

Never reverse the order of the steps for

disconnecting and reconnecting the

accessory batteries - risk of irreversible

damage!

Disconnection

Rear battery:

►  Disconnect the

(-)

 terminal using the black

quick-release connector.

Front battery:





►  Disconnect the

(+)

 terminal by disconnecting

the red quick-release clamp:

•  Raise lever

A

 fully to release clamp

B

.

•  Remove clamp

B

 by lifting it off.

Reconnection

Front battery:





►  Connect the

(+)

 terminal by connecting the

red quick-release clamp:

•  Raise lever

A

 fully.

•  Refit open clamp

B

 on the

(+)

 terminal.

•  Push clamp

B

 fully down.

•  Lower lever

A

 to lock clamp

B

.

Rear battery:

►  Connect the

(-)

 terminal using the black

quick-release connector.

Following reconnection

After reconnecting the battery, turn on the

ignition and wait 1 minute before starting the

engine, to enable the electronic systems to

initialise.

If minor problems nevertheless persist following

this operation, contact a CITROËN dealer or a

qualified workshop.

Referring to the relevant section, reinitialise

certain equipment:

–  Remote control key or electronic key

(depending on version).

–  Sunroof and electric blind.

–  Electric windows.

–  Date and time.

–  Preset radio stations.

After reconnecting the battery, the

message "

Collision risk detection

system fault

" is displayed on the instrument

panel when the ignition is switched on. This

operation is perfectly normal. The message

will disappear while driving.

191

In the event of a breakdown

8

Towing the vehicle

General recommendations

Observe the legislation in force in the

country where you are driving.

Ensure that the weight of the towing vehicle is

higher than that of the towed vehicle.

The driver must remain at the wheel of the

towed vehicle and must have a valid driving

licence.

When towing a vehicle with all four wheels on

the ground, always use an approved towing

arm; rope and straps are prohibited.

The towing vehicle must move off gently.

When the vehicle is towed with its engine

off, there is no longer braking and steering

assistance.

A professional towing service must be

called if:

–  Broken down on a motorway or main road.

–  Not possible to put the gearbox into neutral,

unlock the steering, or release the parking

brake.

–  Not possible to tow a vehicle with an

automatic gearbox, with the engine running.

–  Towing with only two wheels on the ground.

–  Four-wheel drive vehicle.

–  No approved towbar available.

Rechargeable hybrid vehicles

Before any intervention, with the ignition

on, depress the brake pedal and select mode

N

, then switch off the hybrid system (

READY



indicator lamp off).

Always call on professionals for recovery of

the vehicle on a flatbed lorry or trailer.

Use the towing eye

only

 to free the vehicle

if it is stuck, or to secure it for recovery on a

flatbed lorry or trailer.

Towing constraints

Type of vehicle

(engine/gearbox)

Front wheels on the

ground

Rear wheels on the

ground

Flatbed

4 wheels on the ground

with towbar

Internal combustion/Manual

















Internal combustion/Automatic

















Hybrid 2WD

















2WD:

 2-wheel drive.

In case of battery or electric parking brake failure, it is essential to call a professional using flatbed recovery vehicles (excluding manual gearbox).



192

In the event of a breakdown

Accessing the tools





The towing eye is stored in a tool box, under the

boot floor.

The opening tool for the rear protective cover is

secured to the towing eye.

For more information on accessing the

Tool kit

,

refer to the corresponding section.

Towing your vehicle

To access the front screw thread:





►  Unclip the cover, using the tool attached to

the towing eye.

►  Release the cover to the right and then

downwards.

To be towed:

►  Screw the towing eye in fully.

►  Install the towbar.

►  Put the gearbox into neutral.

Failure to observe this instruction could

result in damage to certain components

(e.g. braking, transmission) and to the

absence of braking assistance the next time

the engine is started.

Automatic gearbox

Never tow the vehicle with the driving

wheels on the ground and the engine off.

►  Unlock the steering and release the parking

brake.

►  Switch on the hazard warning lamps on both

vehicles in accordance with the legislation in

force in the country in which you are driving.

►  Move off gently, drive slowly and only for a

short distance.

Towing another vehicle

To access the rear screw thread:





►  Unclip the cover, using the tool attached to

the towing eye.

►  Pull the cover downwards.

To tow:

►  Screw the towing eye in fully.

►  Install the towbar.

►  Switch on the hazard warning lamps on both

vehicles.

►  Move off gently, drive slowly and only for a

short distance.

193

Technical data

9

Engine technical data and

towed loads

Engines

The engine characteristics are given in the

vehicle's registration document, as well as in

sales brochures.

Only the values available at the time of

publication are presented in the tables.

Contact a CITROËN dealer or a qualified

workshop to obtain missing values.

The maximum power corresponds to the

value type-approved on a test bed, under

conditions defined by European legislation

(Directive 1999/99/EC).

For more information, contact a CITROËN dealer

or a qualified workshop.

Weights and towed loads

The weights and towed loads relating to

the vehicle are indicated on the registration

document, as well as in sales brochures.

These values are also indicated on the

manufacturer's plate or label.

For more information, contact a CITROËN dealer

or a qualified workshop.

The GTW (Gross Train Weight) and towed load

values indicated are valid up to a maximum

altitude of 1,000 metres. The towed load value

must be reduced by 10% for each additional

1,000 metres of altitude.

The maximum authorised nose weight

corresponds to the weight permitted on the

towball.

When exterior temperatures are high, the

vehicle performance may be limited in

order to protect the engine. When the exterior

temperature is higher than 37°C, reduce the

towed weight.

Towing even with a lightly loaded vehicle

can adversely affect its road holding.

Braking distances are increased when towing

a trailer.

When using a vehicle to tow, never exceed

a speed of 62 mph (100 km/h) (observe the

local legislation in force).
