130

Driving

Operation

The system operates subject to the following

conditions:

–  At reduced speed in an urban environment,

when a stationary vehicle, pedestrian or cyclist

is detected.

–  The vehicle's speed is above 6 mph (10 km/h)

(versions with camera and radar) or between

6 mph and 53 mph (10 km/h and 85 km/h)

(versions with camera only) when a moving

vehicle is detected.

This warning lamp flashes (for

approximately 10 seconds) as soon as

the function applies the vehicle’s brakes.

During the flashing time, the function is not

available.

With an automatic gearbox, in the event of

automatic emergency braking, keep the brake

pedal depressed, also after a complete stop is

reached, to prevent the vehicle from rolling away.

With a manual gearbox, in the event of automatic

emergency braking bringing the vehicle to a

complete stop, the engine may stall.

The driver can override the automatic

emergency braking at any time by firmly

turning the steering wheel and/or firmly

depressing the accelerator pedal.

The brake pedal may feel hard and

vibrate slightly while the function is

operating.

If the vehicle comes to a complete stop,

automatic braking is maintained for 1 to 2

seconds.

Malfunction

This warning lamp lights up on the

instrument panel with the message

"

Sensor blind

" in certain cases.

Version with camera only:

 the system is

deactivated.

Version with camera and radar:

 the system

may continue to operate in a degraded mode.

This may be caused by a reduced visibility

(e.g. rain, fog, snow, blinding by low sun) or by

a real sensor blockage. In this case, stop the

vehicle and verify if the front camera or the front

radar is covered by dirt, snow, ice or anything

preventing the sensing.

In the event of a malfunction, this warning

lamp lights up on the instrument panel,

accompanied by the display of a message and

an audible signal.

Have it checked by a CITROËN dealer or a

qualified workshop.

These warning lamps light up on

the instrument panel and/or in the

warning lamp display for seat belts and front

passenger airbag to indicate that the driver's

and/or front passenger's seat belt is not fastened

(depending on version). The automatic braking

system is deactivated until the seat belts are

fastened.

Distraction detection

For more information, refer to the

General recommendations on the use

of driving and manoeuvring aids

.

The function comprises the "Coffee Break Alert"

system combined with the "Driver Attention

Warning" system.

These systems are in no way designed

to keep the driver awake or to prevent

the driver from falling asleep at the wheel.

It is the driver’s responsibility to stop if feeling

tired.

Take a break if you are feeling tired or at least

every 2 hours.

Activation/Deactivation

This function is set via the touch screen

Driving

/

Vehicle

 menu.

The state of the system is memorised when the

ignition is switched off.

Coffee Break Alert

The system triggers an alert when it

detects that the driver has not taken a

131

Driving

6

break after two hours of driving at a speed above

43 mph (70 km/h).

This alert is issued via the display of a message

encouraging the driver to take a break,

accompanied by an audible signal.

If the driver does not follow this advice, the alert

is repeated hourly until the vehicle is stopped.

The system resets itself if one of the following

conditions is met:

–  With the engine running, the vehicle has been

stationary for more than 15 minutes.

–  The ignition has been switched off for a few

minutes.

–  The driver's seat belt is unfastened and their

door is opened.

As soon as the speed of the vehicle

drops below 43 mph (70 km/h), the

system goes into standby.

Driving time starts being counted again once

the speed reaches above 43 mph (70 km/h).

Driver Attention Warning





The system assesses the driver's level of

alertness, fatigue and distraction by

identifying trajectory changes in relation to the

lane markings.

To do this, the system uses a camera, placed on

the upper part of the windscreen.

This system is particularly suited to fast roads

(speed higher than 43 mph (70 km/h)).

At a first alert level, the driver is warned by the

message "

Be vigilant!

", accompanied by an

audible signal.

After three first-level alerts, the system triggers

a further alert with the message "

Dangerous

driving: take a break

", accompanied by a more

pronounced audible signal.

In certain driving conditions (poor road

surface or strong winds), the system may

give alerts independent of the driver's level of

vigilance.

The following situations may interfere

with the operation of the system or

prevent it from working:

–  lane markings absent, worn, hidden (snow,

mud) or multiple (roadworks);

–  close to the vehicle ahead (lane markings

not detected);

–  roads that are narrow, winding, etc.

Active lane departure

warning system

For more information, refer to the

General recommendations on the use

of driving and manoeuvring aids

.

The system corrects the vehicle's trajectory by

alerting the driver as soon as it detects a risk of

involuntary lane departure or crossing of a verge

or hard shoulder (depending on version).

To do this, the system uses a camera, placed on

the upper part of the windscreen, identifying the

lane markings on the ground and the side of the

road (depending on version).

This system is particularly useful on

motorways and main roads.





132

Driving

Operating conditions

–  Vehicle speed between 43 and 112 mph (70

and 180 km/h).

–  Road marked with a central dividing line.

–  Steering wheel held with both hands.

–  Direction indicators off upon activation of the

system.

–  ESC system activated and operational.

The system helps the driver only if there

is a risk of the vehicle unintentionally

wandering from the lane it is being driven in. It

does not manage the safe driving distance,

vehicle speed or braking.

The driver must hold the steering wheel with

both hands so that they can maintain control

when the conditions no longer allow the

system to intervene (e.g. in the event that

the central dividing line marking on the road

surface disappears).

Operation

Once the system identifies a risk of the vehicle

involuntarily crossing one of the lane markings

detected, it makes the necessary trajectory

correction to return the vehicle to its initial path.

The driver will notice a turning movement of the

steering wheel.

This warning lamp flashes during

trajectory correction.

The driver can prevent the correction by

firmly holding the steering wheel

(e.g. during an emergency manoeuvre).

The correction is interrupted immediately if

the direction indicators are operated.





While the direction indicators are activated and

for a few seconds after switching them off, the

system considers that a change of trajectory is

intentional and no correction is triggered during

this period.

However, with the Blind spot monitoring system

activated, if the driver is about to change lanes

while another vehicle is detected in the blind

spots of their vehicle, a trajectory correction is

initiated by the system despite the activation of

the direction indicators.

For more information on the

Blind spot

monitoring

 system, refer to the corresponding

section.

If the system detects that the driver is not

holding the wheel firmly enough during

an automatic correction of trajectory, it

interrupts the correction. An alert is triggered

to encourage the driver to take back control of

the vehicle.

133

Driving

6

Driving situations and related alerts

The table below describes the alerts and messages displayed in different driving situations.

The actual order of display of these alerts may be different.

Function status

Indicator lamp

Display and/or associated

message

Comments

OFF









(grey)

Function deactivated.

ON





(grey)

System active, conditions not met:

–  Speed below 43 mph (70 km/h).

–  No lane marking recognised.

–  ASR/DSC systems deactivated or operation of ESC

system triggered.

–  "Sporty" driving.

ON









(grey)

Automatic deactivation/standby of the function

(e.g. detection of a trailer, use of the "space-saver" type

spare wheel supplied with the vehicle).

ON





(green)

Lane marking detected.

Speed above 43 mph (70 km/h).

ON









(orange)/(green)

The system corrects the trajectory on the side where the

risk of unintentional crossing is detected (orange line).

134

Driving

Function status

Indicator lamp

Display and/or associated

message

Comments

ON













(orange)/(green)

"

Put your hands back on

the steering wheel

"

–  If, during the correction, the system detects that the

driver has not held the steering wheel for a few seconds, it

stops the correction and returns control to the driver.

–  During the trajectory correction, the system determines

that the correction will not be enough: the driver is warned

that they must provide additional trajectory correction.

The duration of audible warnings will increase if multiple

corrections are performed in quick succession. The

warning will become continuous, persisting until the driver

responds.

This message may also be displayed with your hands on

the steering wheel.

Operating limits

The system goes into standby automatically in

the following cases:

–  ESC deactivated or operation triggered.

–  Speed below 43 mph (70 km/h) or greater

than 112 mph (180 km/h).

–  Electrical connection to a trailer.

–  Use of a"space-saver" spare wheel detected

(as detection is not immediate, deactivation of

the system is recommended).

–  Dynamic driving style detected, pressure on

the brake or accelerator pedal.

–  Driving over lane markings.

–  Activation of the direction indicators.

–  Crossing the inside line on a bend.

–  Driving on a tight bend.

–  Inactivity by the driver detected during

correction.

The following situations may interfere

with the operation of the system or

prevent it from working:

–  Insufficient contrast between the road

surface and the verge or hard shoulder

(e.g. shade).

–  Lane markings worn, hidden (snow, mud)

or multiple (roadworks, etc.),

–  Close proximity to the vehicle in front (lane

markings may not be detected).

–  Roads that are narrow, winding.

Risk of undesirable operation

The system should be deactivated in the

following situations:

–  When changing a wheel or working near a

wheel.

–  Towing or with a bicycle carrier on a towing

device, especially with trailer not plugged in or

not approved.

–  Road in poor condition, unstable or with very

poor grip (risk of aquaplaning, snow, ice).

–  Adverse weather conditions.

–  Driving on racing circuits.

–  Driving on a rolling road.

135

Driving

6

Deactivation/Activation









►  Press this button to deactivate/reactivate the

system at any time.

Deactivation is signalled by the lighting of

the indicator lamp in the button and this

warning lamp on the instrument panel.

The system is

automatically reactivated

 every

time the ignition is switched on.

Malfunction

In the event of a malfunction,

these warning lamps light up on

the instrument panel, accompanied by the

display of a message and an audible signal.

Have it checked by a CITROËN dealer or a

qualified workshop.

Blind spot monitoring

For more information, refer to the

General recommendations on the use

of driving and manoeuvring aids

.





This system warns the driver of a potential

danger posed by the presence of another vehicle

(car, lorry, motorcycle) in the vehicle's blind

spots (areas hidden from the driver's field of

vision) using sensors located on the sides of the

bumpers.





A warning lamp appears in the door mirror on the

side in question:

–

fixed

, immediately, when being overtaken;

–

flashing

, after a delay of about one second,

when overtaking a vehicle slowly, and when the

direction indicator is used.

Activation/Deactivation

The settings are changed via the

Driving/

Vehicle

 touch screen menu.

The status of the system is memorised when the

ignition is switched off.

The system is automatically deactivated

when towing with a towing device

approved by CITROËN.

Operating conditions

–  All vehicles are moving in the same direction

and in adjacent lanes.

–  The speed of your vehicle must be between 7

and 87 mph (12 and 140 km/h).

–  When overtaking a vehicle, the speed

difference is less than 6 mph (10 km/h).

–  When overtaken by a vehicle, the speed

difference is less than 16 mph (25 km/h).

–  Traffic is flowing normally.

–  Overtaking a vehicle over a certain period of

time and the vehicle being overtaken remains in

the blind spot.

–  You are driving on a straight or slightly curved

road.

–  Your vehicle is not pulling a trailer, a caravan,

etc.

136

Driving

Operating limits









No alert is triggered in the following conditions:

–  presence of stationary objects (e.g. parked

vehicles, safety rails, lampposts, signs).

–  vehicles travelling in the opposite direction.

–  on winding roads or in case of sharp turns.

–  when overtaking or being overtaken by a

very long vehicle (e.g. truck, bus), which is both

detected in a blind spot from behind and present

in the driver's field of vision from the front.

–  quick overtaking manoeuvre.

–  very heavy traffic: vehicles detected in front

and behind are confused with a lorry or a

stationary object.

–  activation of the Park Assist function.

Malfunction

If the event of a malfunction, this warning

lamp lights up on the instrument panel,

accompanied by the display of a message.

Have it checked by a CITROËN dealer or a

qualified workshop.

The system may be temporarily disturbed

by certain weather conditions (e.g. rain,

hail).

In particular, driving on a wet road or going

from a dry to a wet area can cause false

alerts (e.g. presence of a cloud of water

droplets in the blind spot interpreted as a

vehicle).

In bad or wintry weather, ensure that the

sensors are not covered by mud, ice or snow.

Take care not to cover the warning zone in

the door mirrors, or the detection zones on

the front and rear bumpers with adhesive

labels or other objects; they may hamper

correct operation of the system.

Active Blind Spot

Detection

In addition to the fixed

warning lamp in the

door mirror on the side in question, a trajectory

correction will be felt if you attempt to cross

a lane marking with the direction indicator

activated, to help you avoid a collision.

This system is a combination of the Active

lane departure warning system and Blind spot

monitoring functions.

These two functions must be activated and in

operation.

The vehicle speed must be between 43 and

87 mph (70 and 140 km/h).

These functions are especially suitable for

driving on motorways and main roads.

For more information on the

Active lane

departure warning system

 and

Blind spot

monitoring

, refer to the corresponding sections.

Parking sensors

For more information, refer to the

General recommendations on the use

of driving and manoeuvring aids

.



137

Driving

6



This system detects and signals the proximity of

obstacles (e.g. pedestrian, vehicle, tree, barrier)

using sensors located in the bumper.

Rear parking sensors

►  Engage reverse gear to start

the system

(confirmed by an audible signal).

The system is switched off when reverse gear is

disengaged.

Audible assistance





The system signals the presence of obstacles

within the sensors’ detection zone.

The proximity information is given by an

intermittent audible signal, the frequency of

which increases as the vehicle approaches the

obstacle.

When the distance between the vehicle and

the obstacle becomes less than about thirty

centimetres, the audible signal becomes

continuous.

The sound emitted by the speaker (right or

left) indicates the side on which the obstacle is

located.

Adjusting the audible signal

Depending on version, with

CITROËN Connect Radio or

CITROËN Connect Nav, pressing this button

opens the window for adjusting the volume of

the audible signal.

Visual assistance





This supplements the audible signal by

displaying bars on the screen whose location

represents the distance between the obstacle

and the vehicle (white: more distant, orange:

close, red: very close).

When the obstacle is very close, the "Danger"

symbol is displayed on the screen.

Front parking sensors

Supplementing the rear parking sensors, the

front parking sensors are triggered when an

obstacle is detected in front and the speed of the

vehicle is below 6 mph (10 km/h).

Front parking sensor operation is suspended if

the vehicle stops for more than three seconds in

forward gear, if an obstacle is no longer detected

or the vehicle speed exceeds 6 mph (10 km/h).

The sound emitted by the speaker (front

or rear) locates the obstacle relative to

the vehicle, in front or behind it.

Deactivation/Activation

The settings are changed via

the

Driving

/

Vehicle

 touch screen menu.

The status of the function is saved when the

ignition is switched off.





The rear parking sensors system will be

deactivated automatically if a trailer or

bicycle carrier is connected to a towing device

installed in accordance with the

manufacturer's recommendations.

In this case, the outline of a trailer is displayed

at the rear of the image of the vehicle.

138

Driving

The parking sensors are deactivated while the

Park Assist function is measuring a space.

For more information on the

Park

Assist

 function, refer to the corresponding

section.

When starting the vehicle, the graphic

and audible aids are only available after

the touch screen has started up.

Operating limits

If the boot is heavily loaded, the vehicle may tilt,

affecting distance measurements.

Malfunction

In the event of a malfunction when

changing into reverse gear, one of

these warning lamps lights up on the instrument

panel, accompanied by the display of a message

and an audible signal (short beep).

If the malfunction occurs while the parking

sensors are being used, it causes the function to

deactivate.

Have it checked by a CITROËN dealer or a

qualified workshop.

Top Rear Vision - Top 360

Vision

For more information, refer to the

General recommendations on the use

of driving and manoeuvring aids

.





With the engine running, these systems allow

views of your vehicle’s close surroundings to be

displayed on the touch screen using one camera

for Top Rear Vision and two cameras for 360

vision.









The screen is divided into two parts with a

contextual view and a view from above the

vehicle in its close surroundings.

The parking sensors supplement the information

on the view from above the vehicle.

Various contextual views may be displayed:

–  Standard view.

–  180° view.

–  Zoom view.

AUTO mode is activated by default.

In this mode, the system chooses the best

view to display (standard or zoom).

You can change the type of view at any time

during a manoeuvre.

►  Press the button in the bottom left-hand

corner of the touch screen.

►  Select the type of view:

• "

Standard view

".

• "

180° view

".

• "

Zoom view

".

• "

AUTO view

".

The display is immediately updated with the type

of view selected.

The system status is not saved when the ignition

is switched off.

139

Driving

6

Operating principle





Using one or two cameras, the close

surroundings of the vehicle are recorded whilst

manoeuvring at low speed.

An image from above your vehicle in its close

surroundings is reconstructed (represented

between the brackets) in real time and as the

manoeuvre progresses.

It facilitates the alignment of your vehicle when

parking and allows obstacles close to the vehicle

to be seen. It is automatically deleted if the

vehicle remains stationary for too long.

With 360 vision, the image is created using

both cameras, when going forward and when

reversing.

When the function is activated, it is possible

that the view from above is not displayed. If

the system is activated when the vehicle has

already moved, the view from above can be fully

displayed.

Top Rear Vision

Rear view





To activate the camera located near the number

plate lamps, engage reverse gear and do not

exceed a speed of 6 mph (10 km/h).

The system is deactivated:

–  Automatically, at speeds above approximately

6 mph (10 km/h),

–  Automatically, if the tailgate is opened.

–  Upon changing out of reverse gear (the image

remains displayed for 7 seconds).

–  By pressing the white arrow in the upper-left

corner of the touch screen.

AUTO mode





This mode is activated by default.

Using sensors in the rear bumper, the automatic

view changes from the rear view (standard) to

the view from above (zoom) as an obstacle is

approached at the level of the red line (less than

30 cm) during a manoeuvre.

Standard view





The area behind the vehicle is displayed on the

screen.

The blue lines

1

 represent the width of your

vehicle, with the mirrors unfolded; their direction

changes according to the position of the steering

wheel.

The red line

2

 represents a distance of 30 cm

from the rear bumper; the two blue lines

3

 and

4



represent 1 m and 2 m, respectively.

This view is available with AUTO mode or in the

view selection menu.

140

Driving

Zoom view





The camera records the vehicle's surroundings

during the manoeuvre in order to create a

view from above the rear of the vehicle in its

near surroundings, allowing the vehicle to be

manoeuvred around nearby obstacles.

This view is available with AUTO mode or in the

view selection menu.

Obstacles may appear further away than

they actually are.

It is important to monitor the sides of the

vehicle during the manoeuvre, using the

mirrors.

Parking sensors also provide additional

information about the area around the vehicle.

180° view





The 180° view facilitates reversing out of a

parking space, making it possible to see the

approach of vehicles, pedestrians and cyclists.

This view is not recommended for carrying out a

complete manoeuvre.

It features 3 areas: left

A

, centre

B

 and right

C

.

This view is only available via the view selection

menu.

Top 360 Vision

The vehicle has a camera at the front

, fitted in

the grille, and a camera at the rear, located close

to the number plate lamps.

Using these cameras, the system displays the

vehicle's near surroundings on the touch screen,

offering views from the rear of the vehicle (rear

vision) when reverse gear is engaged and views

from the front of the vehicle (front vision) when

the gearbox is in neutral or a gear is engaged.

Rear vision





The system activates automatically when

reverse gear is engaged.

The system is deactivated:

–  Automatically, at speeds above approximately

6 mph (10 km/h).

–  When shifting out of reverse (the front vision

image replaces the rear vision image for 7

seconds).

–  By pressing the white arrow in the upper-left

corner of the touch screen.

If a trailer or a bicycle carrier is fitted to

the towball, the area behind the vehicle

on the view from above goes dark.

The surroundings are reconstructed by the

front camera only.

141

Driving

6

The rear vision views are similar to those for the

Top Rear Vision function.

For more information on the

Top Rear

Vision

 function, refer to the corresponding

section.

Front and rear vision





With the engine running and the speed

below 12 mph (20 km/h), the system is

activated via the

Driving/Vehicle

 touch screen

menu:

►  Select "

Visual parking assistance

".

AUTO mode is displayed by default, with front

vision, if the gearbox is in neutral or with a

gear engaged, or with rear vision, if reverse is

engaged.

The system is deactivated:

–  Automatically above about 19 mph (30 km/h)

(the image disappears temporarily from 12 mph

(20 km/h)).

–  By pressing the white arrow in the upper-left

corner of the touch screen.

AUTO mode





This mode is activated by default.

Using sensors in the front bumper, the automatic

view changes from the front view (standard) to

the view from above (zoom) as an obstacle is

approached during a manoeuvre.

Standard view





The area in front of your vehicle is displayed on

the screen.

The orange lines

1

 represent the width of your

vehicle, with the mirrors unfolded; their direction

changes according to the position of the steering

wheel.

The red line

2

 represents a distance of 30 cm

from the front bumper; the two orange lines

3



and

4

 represent 1 m and 2 m, respectively.

This view is available with AUTO mode or by

selecting it in the view change menu.

Zoom view





The camera records the vehicle's surroundings

during the manoeuvre in order to create a

view from above the front of the vehicle in its

near surroundings, allowing the vehicle to be

manoeuvred around obstacles nearby.

This view is available with AUTO mode or in the

view selection menu.

Obstacles may appear further away than

they actually are.

It is important to check the sides of the

vehicle during the manoeuvre, using the

mirrors.

The parking sensors also supplement the

information on the vehicle's surroundings.

142

Driving

180° view





The 180° view assists with exiting from a parking

space in forward gear, making it possible to

see the approach of vehicles, pedestrians and

cyclists.

This view is not recommended for carrying out a

complete manoeuvre.

It consists of 3 areas: left

A

, centre

B

 and

right

C

.

This view is available only from the view

selection menu.

Park Assist

For more information, refer to the

General recommendations on the use

of driving and manoeuvring aids

.

This system provides active parking assistance:

it detects a parking space then operates the

steering system to park in this space.

With

manual and automatic gearboxes

, the

driver manages the accelerator, brakes and

forward and reverse gear engagement.

During phases of entry into and exit from a

parking space, the system provides visual and

audible information to the driver in order to make

the manoeuvres safe. Several forward and

reverse manoeuvres may be required.

At any time, the driver can take back control by

holding the steering wheel.





The Park Assist system provides assistance for

the following manoeuvres:

A.

Entry into a "parallel" parking space

B.

Exit from a "parallel" parking space

C.

Entry into a "bay" parking space

The Park Assist system cannot operate

with the engine switched off.

When Park Assist is activated, it prevents

Stop & Start from going into STOP mode. In

STOP mode, activation of Park Assist restarts

the engine.

The Park Assist system takes control of

the steering for a maximum of 4

manoeuvring cycles. It is deactivated after

these 4 cycles. If the vehicle is not positioned

correctly, take back control to complete the

manoeuvre.

The sequence of manoeuvres and the

driving instructions are displayed on the

touch screen.

The assistance is activated: the display

of this symbol and a speed limit

indicate that the steering manoeuvres are

controlled by the system: do not touch the

steering wheel.

The assistance is deactivated: the

display of this symbol indicates that the

steering manoeuvres are no longer controlled

by the system: take over the steering.

Activation of Park Assist deactivates the

Blind spot monitoring.

The Parking sensors function is not

available during parking space

143

Driving

6

measurement. It intervenes later when

manoeuvring to warn that the vehicle is

approaching an obstacle: the audible signal

becomes continuous when the obstacle is

less than 30 centimetres away.

If the Parking sensors function has

been deactivated, it will be automatically

reactivated during the assisted manoeuvring

phases.

During parking and exit from parking

manoeuvres, the Top Rear Vision - Top

360 Vision functions may come into operation.

They allow better monitoring of the

surroundings of the vehicle, by displaying

additional information in the touch screen.

For more information on the

Top Rear Vision

- Top 360 Vision

 functions, refer to the

corresponding section.

In some circumstances, the sensors may

not detect small obstacles located in their

blind spots.

Any object exceeding the size of the vehicle

(e.g. roof ladder, towball) is not taken

into account by the Park Assist during a

manoeuvre.

Always check the surroundings of the

vehicle before starting a manoeuvre.

If the lateral distance between the vehicle and

the space is too great, the system may not be

able to measure the space.

During manoeuvring phases, the steering

wheel performs rapid turns: do not hold

the steering wheel or put your hands between

the spokes of the steering wheel.

Beware of any object likely to block the

manoeuvre (e.g. loose clothing, scarves, ties)

- risk of injury!

Assistance with "parallel"

parking manoeuvres

►  When parking, select "

Park Assist

" in

the

Driving/Vehicle

 touch screen menu

to activate the function.

With a digital instrument panel, this

indicator lamp lights up on the instrument

panel to confirm the activation of the function.

►  Limit the vehicle speed to a maximum

of 12 mph (20 km/h) and select "

Enter

parallel parking space

" on the touch screen.

To enter a "parallel" parking space, the

system does not identify spaces that are

clearly smaller or larger than the vehicle.

►  Operate the direction indicator on the

side you have chosen to park in order to

activate the measurement function. The vehicle

must drive at a distance of between 0.5 m and

1.5 m from the row of parked vehicles.

20

►  Drive at a speed below 12 mph (20

km/h) following the instructions until the

system finds an available space.

►  Move forwards slowly until a message

is displayed, accompanied by an audible

signal, asking you to engage reverse gear.

►  Engage reverse gear, release the

steering wheel and move without

exceeding a speed of 4 mph (7 km/h).

The assisted parking manoeuvre is in

progress.

7

►  Without exceeding 5 mph (7 km/h),

move forwards and backwards, aided by

the warnings from the "Parking sensors" system,

until the end of the manoeuvre is indicated.

►  At the end of the manoeuvre, the

indicator lamp on the instrument panel

goes off, accompanied by a message and an

audible signal.

Parking assistance is deactivated: you can take

over the controls again.

Assistance with "bay"

parking manoeuvres

►  When parking, select "

Park Assist

" in

the

Driving/Vehicle

 touch screen menu

to activate the function.

144

Driving

With a digital instrument panel, this

indicator lamp lights up on the instrument

panel to confirm the activation of the function.

►  Limit the vehicle speed to a maximum

of 12 mph (20 km/h) and select “

Enter

bay parking space

” on the touch screen.

►  Operate the direction indicator on the

parking side chosen to activate the

measurement function. The vehicle should drive

at a distance of between 0.5 m and 1.5 m from

the row of parked vehicles.

20

►  Drive at a speed below 12 mph (20

km/h) following the instructions until the

system finds an available space.

When several successive spaces are

found, the vehicle will be directed

towards the last one.

►  Move forwards slowly until a message

is displayed, accompanied by an audible

signal, asking you to engage reverse gear.

►  Engage reverse gear, release the

steering wheel and move without

exceeding the speed of 5 mph (7 km/h).

The assisted parking manoeuvre is in

progress.

7

►  Without exceeding 5 mph (7 km/h),

follow the instructions and the warnings

from the "Parking sensors" system, until the end

of the manoeuvre is indicated.

At the end of the manoeuvre, the indicator

lamp in the instrument panel goes off,

accompanied by a message and an audible

signal.

The system is deactivated: it is possible to retake

control.

During a "bay" parking manoeuvre, the

Park Assist system is automatically

deactivated once the rear of the vehicle is

within 50 cm of an obstacle.

Assistance with "parallel"

parking exit manoeuvres

►  To leave a "parallel" parking space, switch

the engine on.

►  With the vehicle stationary, select

"

Park Assist

" in the

Driving/Vehicle



touch screen menu to activate the function.

With a digital instrument panel, this

indicator lamp comes on in the instrument

panel to confirm the activation of the function.

►  Press "

Exit parking slot

" on the touch

screen.

►  Operate the direction indicator for the

exit side chosen.

►  Engage reverse or forward

gear and release the steering

wheel.

The assisted parking manoeuvre is in

progress.

5

►  Without exceeding 3 mph (5 km/h),

move forwards and backwards, aided by

the warnings from the "Parking sensors" system,

until the end of the manoeuvre is indicated.

The manoeuvre is complete when the vehicle's

front wheels are clear of the parking space.

At the end of the manoeuvre, the indicator

lamp in the instrument panel goes off,

accompanied by a message and an audible

signal.

The system is deactivated: it is possible to retake

control.

Deactivation

The system is deactivated via the

Driving /

Vehicle

 touch screen menu.

The system is automatically deactivated:

–  when the ignition is switched off.

–  if the engine stalls.

–  if the driver's seat belt is not fastened.

–  on opening the driver's door.

–  if no manoeuvre is performed within 5 minutes

of selecting the type of manoeuvre.

–  after a prolonged stop of the vehicle during a

manoeuvre.

–  if the wheel anti-slip regulation (ASR) is

triggered.

–  if the speed of the vehicle is above 43 mph

(70 km/h).

–  when the driver interrupts the rotation of the

steering wheel.

–  after 4 manoeuvring cycles.

–  if one of the front wheels encounters an

obstacle.

–  when towing a trailer, connected electrically.

145

Driving

6

The indicator lamp in the instrument panel goes

off and a message is displayed, accompanied by

an audible signal.

The driver should then take back control of the

vehicle's steering.

If the system is deactivated during a

manoeuvre, the driver should reactivate

it to repeat the measurement.

To switch the system off for a prolonged period,

contact a CITROËN dealer or a qualified

workshop.

Malfunctions

When the function is not activated, this

indicator lamp (on a vehicle with a type 2

instrument panel) will flash briefly and/or an

audible signal will be emitted to indicate a

system malfunction.

If the malfunction occurs while the system is in

use, the indicator lamp goes off.

Contact a CITROËN dealer or a qualified

workshop.

In the event of a power steering

malfunction, this warning lamp is

displayed on the instrument panel, accompanied

by a warning message.

You must stop the vehicle.

Stop as soon as it is safe to do so and

switch off the ignition.

Contact a CITROËN dealer or a qualified

workshop.
