98

Driving

while pressing the "

START/STOP

" button to

assist unlocking of the steering column.

Petrol engines

With Petrol engines, after a cold start,

pre-heating the catalytic converter can cause

noticeable engine vibrations, for anything up

to 2 minutes (accelerated idle speed).

If the engine stalls, release the clutch

pedal and fully depress it again, the

engine will restart automatically.

Starting rechargeable hybrid

vehicles

►  Fully depress the brake pedal and press

the

START/STOP

 button for approximately 2

seconds.

►  Keep your foot on the pedal until this

indicator lamp comes on, indicating the

activation of the rechargeable hybrid system

(confirmed by an audible signal).

To exit Park mode, wait for the READY

indicator lamp to come on.

By default, the system starts in

Electric

 mode.

Depending on certain parameters (battery

charge level or outside temperature), the system

determines whether it is necessary to start the

petrol engine.

It is possible to change the driving mode at any

time using the mode selector.

When the vehicle starts in electric mode,

it makes no noise.

Pay particular attention to pedestrians and

cyclists who may not hear the vehicle coming

despite the pedestrian horn.

Switching off

►  Immobilise the vehicle using the parking

brake.

►  With a

manual gearbox

, ideally put the gear

lever into neutral.

►  With an

automatic gearbox

, ideally select

mode

P

 or

N

.

►  Press the "

START/STOP

" button.

►  For rechargeable hybrid vehicles, before

leaving the vehicle, check that the

READY



indicator lamp is switched off.

In some circumstances, it is necessary to turn

the steering wheel to lock the steering column.

On certain versions with an automatic gearbox

(EAT6/EAT8), the steering column does not lock,

but the gearbox locks in mode

P

.

If the vehicle is not immobilised, the

engine will not stop.

With the engine off, the braking and

steering assistance systems are also cut

off - risk of loss of control of the vehicle!

Never leave your vehicle with the

electronic key still inside.

Switching on the ignition

without starting the engine





With the electronic key in the passenger

compartment, pressing the "

START/STOP

"

button,

without depressing any of the pedals

,

allows the ignition to be switched on without

starting the engine (the instrument panel and

accessories such as the audio system and the

lighting will come on).

►  Press this button again to switch off the

ignition and allow the vehicle to be locked.

Key not detected

Back-up starting

A back-up reader is fitted to the steering column,

to enable the engine to be started if the system

fails to detect the key in the recognition zone, or

if the battery in the electronic key is flat.



99

Driving

6



►  Place and hold the remote control against the

back-up reader.

►

With a manual gearbox

, place the gear lever

in neutral, then fully depress the clutch pedal.

►

With an automatic gearbox

, select mode

P

,

then depress the brake pedal.





►  Press the "

START/STOP

" button.

The engine starts.

Back-up switch-off





If the electronic key is not detected or is no

longer in the recognition zone, a message

appears in the instrument panel when closing a

door or trying to switch off the engine.

►  To confirm the instruction to switch off the

engine, press the "

START/STOP

" button for

approximately 5 seconds.

In the event of a fault with the electronic key,

contact a CITROËN dealer or a qualified

workshop.

Emergency switch-off

In case of emergency only, the engine can be

switched off without conditions (even when

driving).

►  Press the "

START/STOP

" button for about

5 seconds.

In this case, the steering column locks as soon

as the vehicle stops.

On certain versions with automatic gearbox

(EAT6/EAT8), the steering column does not lock.

Electric parking brake

In automatic mode, this system applies the

parking brake when the engine is switched off

and releases it when the vehicle moves off.









At any time, with the engine running:

►  To apply the parking brake, briefly pull the

control.

►  To release it, briefly push the control while

pressing the brake pedal.

Automatic mode is activated by default.

This automatic operation can be deactivated in

certain situations.

Indicator lamp

This indicator lamp comes on both on the

instrument panel and on the control to

confirm that the parking brake has been applied,

accompanied by display of the message

"

Parking brake applied

".

100

Driving

The indicator lamp goes out to confirm the

release of the parking brake, accompanied by

the display of the message "

Parking brake

released

".

The indicator lamp flashes in response to a

manual request to apply or release the brake.

In the event of a battery failure, the

electric parking brake will not operate.

As a safety measure, with a manual gearbox,

if the parking brake is not applied, immobilise

the vehicle by engaging a gear.

As a safety measure, with an automatic

gearbox, if the parking brake is not applied,

immobilise the vehicle by placing the supplied

chocks against one of the wheels.

Contact a CITROËN dealer or a qualified

workshop.





Before leaving the vehicle, check that the

parking brake is applied: the indicator

lamps on the instrument panel and the control

lever must be on fixed.

If the parking brake is not applied, there is an

audible signal and a message is displayed on

opening the driver's door.

Never leave a child alone inside the

vehicle, as they could release the parking

brake.

When the vehicle is parked: on a

steep slope, heavily loaded or during

towing

With a manual gearbox, turn the wheels

toward the pavement and engage a gear.

With an automatic gearbox, turn the wheels

toward the pavement and select mode

P

.

When towing, the vehicle is approved for

parking on slopes of up to 12%.

Manual operation

Manual release

With the ignition on or engine running:

►  Depress the brake pedal.

►  While maintaining pressure on the brake

pedal, briefly push the control lever.

If you push the control lever without

pressing the brake pedal, the parking

brake is not released and a message is

displayed.

Manual application

With the vehicle stationary:

►  Pull briefly on the control lever.

The control lever indicator lamp flashes to

confirm the application request.

Automatic operation

Automatic release

First ensure that the engine is running and the

driver's door is properly closed.

The electric parking brake

gradually releases

automatically as the vehicle moves off

.

With a manual gearbox

►  Fully depress the clutch pedal and engage

first gear or reverse.

►  Depress the accelerator pedal and release

the clutch pedal.

With an automatic gearbox

►  Depress the brake pedal.

►  Select mode

D

,

M

 or

R

.

►  Release the brake pedal and depress the

accelerator pedal.

With an automatic gearbox, if the brake

does not release automatically, check

that the front doors are correctly closed.

When stationary with the engine running,

do not depress the accelerator pedal

unnecessarily. Risk of parking brake release.

101

Driving

6

Automatic application

With the vehicle stationary, the parking brake

is applied automatically when the engine is

switched off.

It is not applied automatically if the

engine stalls or enters STOP mode with

Stop & Start.

In automatic mode, the parking brake

can be manually applied or released at

any time using the control.

Special cases

Immobilising the vehicle with the

engine running

To immobilise the vehicle with the engine

running, briefly pull the control lever.

Parking the vehicle with the brake

released

In very cold conditions (ice), applying the

parking brake is not recommended.

To immobilise the vehicle, engage a gear or

place the chocks against one of the wheels.

With an automatic gearbox, mode

P

 is

automatically selected when the ignition

is switched off. The wheels are blocked.

For more information on

Free-wheeling

, refer

to the corresponding section.

With an automatic gearbox, while mode

N

 is selected, opening the driver’s door

triggers an audible signal. It stops when the

driver's door closes again.

Deactivating automatic

operation

In some situations, for example when it is

extremely cold or when towing (e.g. caravan,

breakdown), it may be necessary to deactivate

automatic operation of the system.

►  Start the engine.

►  Use the control to apply the parking brake, if

it is released.

►  Take your foot fully off the brake pedal.

►  Keep the control pushed in the release

direction for 10 to a maximum of 15 seconds.

►  Release the control.

►  Depress and hold the brake pedal.

►  Pull the control in the application direction for

2 seconds.

This indicator lamp on the instrument

panel comes on to confirm deactivation of

the automatic functions.

►  Release the control and the brake pedal.

From this point onwards, only the manual

functions, using the control, allow the parking

brake to be applied and released.

►  Follow this procedure again to reactivate

automatic operation (confirmed by the indicator

lamp on the instrument panel going out).

Emergency braking

If depressing the brake pedal fails to provide

effective braking or in exceptional circumstances

(e.g. driver unwell, assisted driving), the vehicle

can be braked by sustained pulling on the

electric parking brake control. Braking continues

for as long as the control is kept pulled, and

ceases when the control is released.

The ABS and DSC systems stabilise the vehicle

during emergency braking.

If emergency braking malfunctions, the message

"

Parking brake fault

" will be displayed on the

instrument panel.

If the ABS and DSC systems

malfunction, indicated by lighting

one or both warning lamps on the instrument

panel, the vehicle’s stability is no longer ensured.

►  In this case, ensure the vehicle's stability by

successive and repeated "pull-release" actions

on the electric parking brake control until the

vehicle comes to a complete stop.

102

Driving

Manual gearbox

Engaging 5

th

 or 6

th

 gear

►  Move the gear selector fully to the right to

engage 5

th

 or 6

th

 gear.

Failure to follow this instruction could

cause permanent damage to the gearbox

(inadvertent engagement of 3

rd

 or 4

th

 gear).

Engaging reverse gear





►  Raise the trigger under the knob and move

the gear lever to the left, then forwards.

Only engage reverse gear when the

vehicle is stationary with the engine at

idle.

As a safety precaution and to facilitate

starting of the engine, always select

neutral and depress the clutch pedal.

Automatic gearbox

With petrol / Diesel engines

Automatic 6-speed or 8-speed gearbox with push

selector. It also offers a manual mode with gear

changes via control paddles located behind the

steering wheel.

With rechargeable hybrid

engine

Automatic 8-speed gearbox with push selector

and regenerative braking function.

With the exception of the manual mode and

regenerative braking function, its operation is

identical to that of other EAT8 gearboxes.

Push selector





P.

Auto Park

Press this button to switch to Parking mode.

For parking the vehicle: the front wheels are

blocked.

R.

Reverse

N.

Neutral

To free-wheel and move the vehicle, with the

ignition off.

For more information on

Free-wheeling

, refer

to the corresponding section.

D.

Driving in automatic mode

The gearbox manages gear changes

according to the style of driving, the road

profile and the vehicle load.

M.

Driving in manual mode (Petrol / Diesel)

Press this button to switch to manual mode.

The driver changes gear using the steering-

mounted controls.

B.

Driving in automatic mode with regenerative

braking function (Rechargeable hybrid)

Press this button to activate the regenerative

braking function.

The gearbox also manages braking when the

accelerator pedal is released.

►  In mode

N

, with your foot on the brake pedal,

push without passing the point of resistance:

•  Forwards, mode

R

 is selected.

•  Backwards, mode

D

 is selected.

Release the selector fully after each push; it

will then return to its initial position.

103

Driving

6

Special cases

To avoid mode

N

 (quick change from

D

 to

R

 and

back again):

►  In mode

R

, push backwards past the point of

resistance, mode

D

 is selected.

►  In mode

D

, push forwards past the point of

resistance, mode

R

 is selected.

►  To return to mode

N

, push without passing

the point of resistance.

Steering-mounted controls

(Depending on equipment)

In mode

M

 or

D

, the steering-mounted control

paddles can be used to change gear manually.

They cannot be used to select neutral or to

engage or disengage reverse gear.





►  Pull the "

+

" or "

-

" paddle towards you and

release to shift up or down a gear, respectively.

Information displayed on

the instrument panel

When the ignition is switched on, the gearbox

status is displayed on the instrument panel:

P

Parking

R

Reverse

N

Neutral

D1...6 / 8

Automatic forward gear

B1...8

Automatic forward gear with

regenerative braking function

activated

M1...6 / 8

Manual forward gear

In all-electric driving, the gear engaged is not

indicated.

The state of the gearbox remains displayed on

the instrument panel for a few seconds after

switching off the ignition.

Operation

Only appropriate mode change instructions are

validated.

With the engine running, if it is necessary to

depress the brake pedal to change modes,

an alert message will be displayed on the

instrument panel.

With the engine running and the brakes

released, if

R

,

D

 or

M

 is selected, the

vehicle moves off, even without pressing the

accelerator pedal.

Never depress the accelerator and brake

pedals at the same time - risk of damage to

the gearbox!

If you open the driver's door while mode

N

 is engaged, an audible signal will

sound and mode

P

 will be engaged. The

audible signal stops when the driver's door is

closed.

At speeds below 3 mph (5 km/h),

opening the driver’s door will engage

mode

P

 - risk of sudden braking!

In the event of battery failure, it is

essential to place the chock(s) supplied

with the tool kit against one of the wheels to

immobilise the vehicle.

Special aspects of automatic mode

The gearbox selects the gear that provides

optimal performance based on ambient

temperature, road profile, vehicle loading and

driving style.

For maximum acceleration, press the accelerator

fully down (kick-down). The gearbox changes

down automatically or holds the selected gear

until the maximum engine speed is reached.

Steering mounted controls allow the driver to

temporarily select a gear, if the vehicle speed

and engine speed conditions permit.

Special aspects of manual mode

The gearbox only changes from one gear to

another if the vehicle speed and engine speed

conditions permit.

104

Driving

Regenerative braking (Brake function)

The regenerative braking function emulates

engine braking, slowing the vehicle with no need

to depress the brake pedal. When the driver

releases the accelerator pedal, the vehicle slows

down more quickly.

The energy recovered when the accelerator

pedal is released is used to partially recharge the

traction battery.

This partial recharging has no effect on

the charge level indicator.

The resulting deceleration of the vehicle

does not cause the brake lamps to come

on.

►  From mode

D

, press button

B

 to activate/

deactivate the function.

D

 on the instrument panel is replaced with

B

.

The state of the function is saved when the

ignition is switched off.

In some situations (e.g. battery full,

extreme temperatures), the amount of

regenerative braking may be temporarily

limited, resulting in less deceleration.

The driver must remain alert to traffic

conditions and must always be ready to use

the brake pedal.

Regenerative braking using the brake

pedal

Energy recovery can also be produced

by depressing the brake pedal in order to

partially recharge the traction battery, without

affecting the charge level indicator.

Starting the vehicle

►  Fully depress the brake pedal.

►  Start the engine.

►  With your foot on the brake pedal, push once

or twice backwards to select automatic mode

D

,

or forwards to shift into reverse gear

R

.

►  Release the brake pedal.

►  Accelerate gradually to automatically release

the electric parking brake.

The vehicle moves off immediately.

Automatic gearbox

Never try to start the engine by pushing

the vehicle.

Switching the vehicle off

Regardless of the current gearbox mode, mode

P

 is immediately engaged automatically when

the ignition is switched off.

However, in mode

N

, mode

P

 will be engaged

after a delay of 5 seconds (time to enable free-

wheeling mode).

Check that mode

P

 has been engaged and

that the electric parking brake was applied

automatically; if not, apply it manually.

The corresponding indicator lamps on the

gear selector and the electric parking

brake control must be on, as well as the

indicator lamps on the instrument panel.

Gearbox malfunction

This warning lamp comes on,

accompanied by an audible signal and

the display of a message.

Visit a CITROËN dealer or a qualified workshop.

Do not drive faster than 62 mph (100 km/h),

keeping to the speed limit.

Switching of the gearbox to back-up mode

Mode

D

 locks in third gear.

The paddles on the steering wheel do not work

and mode

M

 is no longer accessible.

You may feel a significant jolt on engaging

reverse gear. This will not damage the gearbox.

Selector malfunction

Minor malfunction

This warning lamp comes on,

accompanied by the display of a message

and an audible signal.

Drive carefully.

Visit a CITROËN dealer or a qualified workshop.

In some cases, the selector indicator lamps may

no longer come on, but the gearbox state is still

displayed on the instrument panel.

105

Driving

6

Major malfunction

This warning lamp comes on,

accompanied by the display of a

message.

You must stop the vehicle.

Stop as soon as it is safe to do so and

switch off the ignition.

Contact a CITROËN dealer or a qualified

workshop.

Progressive Hydraulic

Cushions

This suspension system with progressive

hydraulic cushions improves driving comfort by

filtering out the imperfections and demands of

the road surface.

Each shock absorber is equipped with a

hydraulic compression stop (at the base) and a

hydraulic rebound stop (at the top).

Depending on the intensity of the shock to be

absorbed, these stops provide the vehicle with a

greater freedom of movement or gradually slow

down the amount of movement in order to avoid

any sudden jolts at the end of travel.

Unlike conventional suspension which absorbs

the energy but then partially returns some of it,

this active suspension absorbs and dissipates

this energy, without producing any rebound.

Driving modes

The driving modes available depend on the

engine and equipment of the vehicle.

Driving modes are selected using one of the

following controls (depending on version):









1.

Pressing the control activates

Eco

 mode. The

indicator lamp comes on.

2.

Pressing the control displays the modes on the

instrument panel.

The selected mode is activated immediately.

With the Advanced Grip Control system,

additional driving modes are available.

For more information on

Advanced Grip

Control

, refer to the corresponding section.

With petrol / Diesel engines

Whenever the ignition is switched on,

Normal

 driving mode is selected by default.

Eco

To reduce energy consumption by reducing the

performance of the heating and air conditioning,

without deactivating them.

Normal

To restore the default settings.

Sport

To obtain more dynamic driving with action

on the power steering, accelerator and gear

changes with an automatic gearbox.

Coasting mode

Depending on version or engine, with an

EAT8 gearbox and the gear selector in mode

D

, except in

Sport

 mode, gradually and fully

releasing the accelerator pedal allows free-

wheeling which can save fuel.

A drop in engine speed is normal (rev counter

at idle, drop in engine noise).

With rechargeable hybrid

engine

Whenever the ignition is switched on,

Electric



driving mode is selected by default.

Electric

Allows driving using 100% electrical energy.

The maximum speed is approximately 84 mph

(135 km/h).

When starting the vehicle, if the conditions do

not allow the activation or retention of

Electric



106

Driving

mode, the message "

Electric mode currently

unavailable

" is displayed on the instrument

panel. The vehicle automatically changes to

Hybrid

 mode.

If an LED comes on under the interior rear view

mirror, visible from outside the vehicle, this

confirms that you are driving in

Electric

 mode

(depending on country of sale).

The LED can be deactivated by inserting

the tip of a paper clip or other similar

object into the hole located underneath the

interior rear view mirror.

Conditions of activation

–  Adequate battery charge level. Charging

the vehicle after each drive is therefore

recommended.

Electric

 mode is available as

long as there is power left in the battery.

–  Outside temperature between approximately

-5°C and 45°C.

Manually exiting the mode

►  Fully depress the accelerator pedal, or

►  Select another mode.

In case of non-use of the vehicle for a

long period (several months), a restart of

the petrol engine may occur even if the

battery is charged.

In the event of multiple starts of the

internal combustion engine without a

sufficient rise in

temperature,

Electric

 mode may be

temporarily unavailable (natural phenomenon

of dilution of fuel in oil). The message

"

Electric mode unavailable: automatic

operation in progress

" then appears on the

instrument panel.

To regain normal electrical operation, drive

approximately 50 miles (80 km) in "motorway"

conditions or approximately 125 miles (200

km) in urban conditions.

This phenomenon does not cause any

mechanical or electrical damage. It can occur

several times in the life of the vehicle.

Hybrid

To optimise the vehicle's fuel consumption by

managing the

alternating or simultaneous

operation of the two types of engine

,

depending on driving conditions and driving

style.

In

Hybrid

 mode, it is possible to drive in 100%

electric mode if the battery charge level is

sufficient and acceleration requirements are

moderate.

Sport

To obtain more dynamic driving in order to

benefit from the maximum performance of the

vehicle.

Electric power is used to supplement the petrol

engine as long as there is energy left in the

battery.

Hill start assist

This system keeps the vehicle briefly stationary

(for approximately 2 seconds) when making a hill

start, while you transfer your foot from the brake

pedal to the accelerator pedal.

The system is only active when:

–  The vehicle is completely stationary, with your

foot on the brake pedal.

–  Certain slope conditions are met.

–  The driver’s door is closed.

Do not leave the vehicle while it is being

held temporarily by hill start assist.

If someone needs to get out of the vehicle

with the engine running, apply the parking

brake manually. Then check that the parking

brake indicator lamp and the

P

 indicator lamp

in the electric parking brake control are on

fixed.

The hill start assist function cannot be

deactivated. However, using the parking

brake to immobilise the vehicle interrupts its

operation.

107

Driving

6

Operation





Facing uphill, with the vehicle stationary,

the vehicle is held for a short time when the

driver releases the brake pedal:

–  If first gear or neutral is engaged on a manual

gearbox.

–  If mode

D

 or

M

 is selected on an automatic

gearbox.





Facing downhill, with the vehicle stationary

and reverse gear engaged, the vehicle is held

for a short time when the driver releases the

brake pedal.

Malfunction

If the event of a malfunction, these

warning lamps light up on the

instrument panel, accompanied by the display of

a message.

Have it checked by a CITROËN dealer or a

qualified workshop.

Gear shift indicator

(Depending on engine)

This system is designed to reduce fuel

consumption by recommending the most suitable

gear.

Operation

Depending on the driving situation and

the vehicle's equipment, the system may

recommend skipping one or more gears.

Gear engagement recommendations are

not to be considered mandatory. Indeed, the

configuration of the road, the traffic density and

safety remain determining factors when choosing

the best gear. Therefore, the driver remains

responsible for deciding whether or not to follow

the system’s advice.

The system cannot be deactivated.

With an automatic gearbox, the system is

only active in manual operation.

The information appears on the

instrument panel, in the form of an arrow

and the recommended gear.

The system adapts the gear change

instructions according to the driving

conditions (e.g. slope, load) and driving style

(e.g. power demand, acceleration, braking).

The system never suggests:

–  engaging first gear.

–  engaging reverse gear.

Stop & Start

The Stop & Start function puts the engine

temporarily into standby - STOP mode - during

phases when the vehicle is stationary (e.g. red

lights, traffic jams). The engine automatically

restarts - START mode - as soon as the driver

indicates the intention of moving off again.

Primarily designed for urban use, the function

is intended to reduce fuel consumption and

exhaust emissions as well as the noise level

when stationary.

The function does not affect the functionalities of

the vehicle, in particular the braking.

Deactivation/Reactivation

The function is

activated

 by default when the

ignition is switched on.

To deactivate/reactivate the function:

108

Driving









►  Press the button.

A message in the instrument panel confirms the

change of status.

When the function is deactivated, the orange

indicator lamp is lit; if the engine was in standby,

it restarts immediately.

Associated indicator lamps

Function activated.

Function deactivated or malfunction.

Opening the bonnet

Before doing anything under the bonnet,

deactivate the Stop & Start system to avoid

any risk of injury caused by the engine

restarting automatically.

Driving on flooded roads

Before entering into a flooded area, it is

strongly recommended that you deactivate

the Stop & Start system.

For more information on

Driving

recommendations

, particularly on flooded

roads, refer to the corresponding section.

Operation

Main conditions for operation

–  The driver’s door must be closed.

–  The driver's seat belt must be fastened.

–  The level of charge in the battery must be

sufficient.

–  The temperature of the engine must be within

its nominal operating range.

–  The outside temperature must be between

0°C and 35°C.

Putting the engine into standby

(STOP mode)

The engine automatically enters standby mode

as soon as the driver indicates their intention to

stop:

–

With a manual gearbox

: at speeds below 2

mph (3 km/h), with the gear lever in neutral and

the clutch pedal released.

–

With an automatic gearbox

:

•  With the gear selector in mode

D

 or

M

,

at speeds below 12 mph (20 km/h) or 2

mph (3 km/h) (depending on engine), by

depressing the brake pedal.

•  Gear selector in mode

N

, at a speed of 0

mph (0 km/h).

•  Gear selector in mode

P

 and brake pedal

released, at a speed of 0 mph (0 km/h).

Time counter

A time counter adds up the time spent in standby

during the journey. It is reset to zero every time

the ignition is switched on.

Special cases:

The engine will not go into standby if the

conditions for operation are not met and in the

following cases:

–  Steep slope (ascending or descending).

–  Vehicle has not exceeded 6 mph (10 km/h)

since the last engine start (with the key or the

START/STOP

 button).

–  Needed to maintain a comfortable temperature

in the passenger compartment.

–  Demisting active.

In these cases, this indicator lamp flashes

for a few seconds, then goes off.

After the engine has restarted, STOP

mode is not available until the vehicle

has reached a speed of 5 mph (8 km/h).

During parking manoeuvres, STOP mode

is not available for a few seconds after

coming out of reverse gear or turning the

steering wheel.

109

Driving

6

Restarting the engine (START mode)

The engine automatically restarts as soon as the

driver indicates the intention of moving off again:

With a manual gearbox

: with the clutch pedal

fully depressed.

With an automatic gearbox:

–  With the selector in mode

D

 or

M

: with the

brake pedal released.

–  With the selector in mode

N

 and the brake

pedal released: with the selector at

D

 or

M

.

–  With the selector in mode

P

 and the brake

pedal depressed: with the selector at

R

,

N

,

D



or

M

.

–  With reverse gear engaged.

Special cases

The engine will restart automatically if the

conditions for operation are met again and in the

following cases:

–  With a manual gearbox: vehicle speed

exceeds 2.5 mph (4 km/h).

–  With an automatic gearbox:

•  With the selector in position

N

 and the brake

pedal released, vehicle speed exceeds 0.6

mph (1 km/h).

•  Adaptive cruise control function deactivated.

In these cases, this indicator lamp flashes

for a few seconds, then goes off.

Malfunctions

In the event of a fault with the system, this

warning lamp flashes for a few moments

on the instrument panel, then remains on,

accompanied by the display of a message.

Have it checked by a CITROËN dealer or a

qualified workshop.

The vehicle stalls in STOP mode

All of the instrument panel warning lamps come

on if there is a fault.

►  Switch off the ignition then start the engine

again with the key or the "

START/STOP

" button.

12 V battery

The Stop & Start system requires a

12 V battery of specific technology and

specification.

All work must be carried out only by a

CITROËN dealer or a qualified workshop

Tyre under-inflation

detection

This system alerts the driver if one or more tyres

suffer a drop in pressure.

The alert is raised when the vehicle is moving,

not when stationary.

It compares the information given by the wheel

speed sensors with

reference values, which

must be reinitialised every time the tyre

pressures are adjusted or a wheel changed

.

It takes into account the last values stored

during the reinitialisation request. It is therefore

essential that the tyre pressure is correct during

the operation. This operation is the driver’s

responsibility.

The tyre under-inflation detection cannot,

in any circumstances, replace the need

for vigilance on the part of the driver.

This system does not avoid the need to

regularly check the tyre pressures (including

the spare wheel), especially before a long

journey.

Driving with under-inflated tyres, particularly

in adverse conditions (heavy load, high

speed, long journey):

–  worsens road-holding.

–  lengthens braking distances.

–  causes premature wear of the tyres.

–  increases energy consumption.

The inflation pressures defined for the

vehicle can be found on the tyre pressure

label.

For more information on the

Identification

markings

, refer to the corresponding section.

Checking tyre pressures

This check should be done monthly

when the tyres are "cold" (vehicle stopped for

1 hour or after a journey of less than 6 miles

(10 km) at moderate speeds).

Otherwise, add 0.3 bar to the pressures

shown on the label.

110

Driving

Under-inflation alert

This is signalled by the fixed illumination

of this warning lamp, accompanied by an

audible signal and the display of a message.

►  Reduce speed immediately, avoid excessive

steering movements and avoid sudden braking.

►  Stop the vehicle as soon as it is safe to do

so.

The loss of pressure detected may not

always cause visible deformation of the

tyre.

Do not rely on just a visual check.

►  Using a compressor, such as the one in

the temporary puncture repair kit, check the

pressures of all four tyres when cold.

►  If it is not possible to carry out this check

immediately, drive carefully at reduced speed.

►  In the event of a puncture, use the

temporary puncture repair kit or the spare wheel

(depending on equipment).

Driving too slowly may not ensure

optimum monitoring.

The alert is not immediately triggered in the

event of a sudden loss of pressure or tyre

blow-out. This is because analysis of the

values read by the wheel's speed sensors

can take several minutes.

The alert may be delayed at speeds below

25 mph (40 km/h), or when adopting a sporty

driving mode.

The alert is kept active until the system is

reinitialised.

Reinitialisation

The system must be reinitialised after any

adjustment to the pressure of one or more tyres,

and after changing one or more wheels.

Before reinitialising the system, make

sure that the pressures of the four tyres

are correct for the conditions of use of the

vehicle and conform to the values written on

the tyre pressure label.

Check the pressures of the four tyres before

performing the reinitialisation.

The system does not advise if a pressure is

incorrect at the time of reinitialisation.

With the vehicle stationary, the system is

reinitialised via the

Driving/Vehicle

 touch

screen menu.

►  In this menu, select the “

Driving functions

”

tab.

►  On this page, select the "

 Under-inflation

initialisation

" function.

►  Select "

Yes

" to confirm.

The reinitialisation is confirmed by the display of

a message and an audible signal.

Snow chains

The system does not have to be

reinitialised after fitting or removing snow

chains.

Malfunction

In the event of a malfunction,

these warning lamps light up on

the instrument panel.

A message appears, accompanied by an audible

signal.

In this case, the tyre under-inflation monitoring

function is no longer performed.

Have it checked by a CITROËN dealer or a

qualified workshop.

Non-standard or 'space-saver' spare

wheel

The use of this type of spare wheel may

suspend tyre pressure monitoring.

In this case, the malfunction warning lamp

comes on and disappears once the wheel

has been replaced by one of uniform size (the

same as the others), the pressure readjusted

and the reinitialisation carried out.

111

Driving

6

Driving and manoeuvring

aids - General

recommendations

Driving and manoeuvring aids cannot, in

any circumstances, replace the need for

vigilance on the part of the driver.

The driver must comply with the Highway

Code, must remain in control of the vehicle in

all circumstances and must be able to retake

control of it at all times. The driver must adapt

the speed to climatic conditions, traffic and

the state of the road.

It is the driver's responsibility to constantly

monitor traffic conditions, assess the distance

and relative speed of other vehicles, and

anticipate their manoeuvres before using the

direction indicator and changing lanes.

These systems do not make it possible to

exceed the laws of physics.

Driving aids

You should hold the steering wheel with

both hands, always use the door and interior

mirrors, always leave your feet close to the

pedals and take a break every 2 hours.

Manoeuvring aids

The driver must always check the

surroundings of the vehicle before and during

the whole manoeuvre, in particular using the

mirrors.

Radar(s)

The operation of the radar(s), along with

any associated functions, may be affected

by the accumulation of dirt (e.g. mud, ice),

in poor weather conditions (e.g. heavy rain,

snow), or if the bumpers are damaged.

If the front bumper is to be repainted, contact

a CITROËN dealer or a qualified workshop;

certain types of paint could interfere with the

operation of the radar(s).





Driving aids camera

This camera and its associated functions

may be impaired or not work if the windscreen

area in front of the camera is dirty, misty,

frosty, covered with snow, damaged or

masked by a sticker.

In humid and cold weather, demist the

windscreen regularly.

Poor visibility (e.g. inadequate street lighting,

heavy rain, thick fog, snowfall), dazzle

(e.g. headlamps of an oncoming vehicle, low

sun, reflections on a damp road, leaving a

tunnel, alternating shade and light) can also

impair detection performance.

In the event of a windscreen replacement,

contact a CITROËN dealer or a qualified

workshop to recalibrate the camera;

otherwise, the operation of the associated

driving aids may be disrupted.

Other cameras

The images from the camera(s)

displayed on the touch screen or on the

instrument panel may be distorted by the

terrain.

In the presence of areas in shade, or in

conditions of bright sunlight or inadequate

lighting, the image may be darkened and with

lower contrast.

Obstacles may appear further away than they

actually are.

Sensors

The operation of the sensors, as well as

any associated functions, may be disrupted

by noise pollution such as that emitted by

noisy vehicles and machinery (e.g. lorries,

pneumatic drills), by the accumulation of

snow or dead leaves on the road or in the

event of damaged bumpers and mirrors.

When reverse gear is engaged, an audible

signal (long beep) indicates that the sensors

may be dirty.

112

Driving

A front or rear impact to the vehicle can

upset the sensors’ settings, which is not

always detected by the system: distance

measurements may be distorted.

The sensors do not systematically detect

obstacles that are too low (pavements, studs)

or too thin (trees, posts, wire fences).

Certain obstacles located in the sensors’ blind

spots may not be detected or may no longer

be detected during the manoeuvre.

Certain materials (fabrics) absorb sound

waves: pedestrians may not be detected.

Maintenance

Clean the bumpers and door mirrors and

the field of vision of the cameras regularly.

When washing your vehicle at high pressure,

direct the spray from at least 30 cm away

from the radar, sensors and cameras.

Mats/Pedal trims

The use of mats or pedal trims not

approved by CITROËN may interfere with

the operation of the speed limiter or cruise

control.

To avoid any risk of jamming the pedals:

–  Ensure that the mat is secured correctly.

–  Never fit one mat on top of another.

Units of speed

Ensure that the units of speed displayed

on the instrument panel (mph or km/h) are

those for the country you are driving in.

If this is not the case, when the vehicle is

stationary, set the display to the required

units of speed so that it complies with what is

authorised locally.

In case of doubt, contact a CITROËN dealer

or a qualified workshop.

Road signs recognition

For more information, refer to the

General recommendations on the use

of driving and manoeuvring aids

.





This system displays the maximum speed

authorised locally on the instrument panel, using:

–  Speed limit signs detected by the camera.

–  Speed limit information from the navigation

system’s mapping.

–  Signs indicating a shared traffic zone detected

by the camera.

Sign detected

Suggested speed

(calculated)

Entry into a shared

traffic zone

Example:





Without CITROËN

Connect Nav

10 mph or 20 km/h

(depending on

the units on the

instrument panel)

With CITROËN

Connect Nav

Display of the speed

in force in the country

you are driving in.

–  Some supplementary traffic signs detected by

the camera.

113

Driving

6

Supplementary

traffic sign detected

Display of

the speed

associated with

the supplementary

traffic sign

Speed limit when

raining

Examples:





If the wiper control

stalk is in the

"intermittent wipe"

or "automatic wipe"

position (in order

to activate the rain

sensor):

68 mph (110 km/h)

(for example)

Speed limit when

towing





If an approved towing

device is fixed to the

vehicle:

56 mph (90 km/h)

(for example)

Speed limit

applicable over a

certain distance

Example:





43 mph (70 km/h)

(for example)

Supplementary

traffic sign detected

Display of

the speed

associated with

the supplementary

traffic sign

Speed limit for

vehicles with a

gross vehicle

weight or gross

train weight less

than 3.5 tonnes





56 mph (90 km/h)

(for example)

Speed limit in case

of snow

Example:





If the outside

temperature is below

3°C:

19 mph (30 km/h)

(for example)

with a "snowflake"

symbol

Speed limit at

certain times of the

day

Example:





19 mph (30 km/h)

(for example)

with a "clock" symbol

Navigation mapping should be regularly

updated in order to receive accurate

speed limit information from the system.

The units for the speed limit (mph or

km/h) depend on the country you are

driving in.

This should be taken into account to ensure

you observe the speed limit.

For the system to work properly when

changing countries, the speed unit of the

instrument panel must match that of the

country you are driving in.

Automatic sign reading is a driving aid

system and does not always display the

correct speed limits.

The speed limit signs present on the road

always take priority over those displayed by

the system.

The system is designed to detect signs that

conform to the Vienna Convention on road

signs.

Specific speed limits, such as those for

heavy goods vehicles, are not displayed.

The display of the speed limit on the

instrument panel is updated when passing

a speed limit sign intended for cars (light

vehicles).

Activation/Deactivation

By default, the system is automatically activated

at every engine start.

The settings are changed via the

Driving

/

Vehicle

 touch screen menu.
