66

Lighting and visibility

If the driver's door is opened, a temporary

audible signal warns the driver that the lamps

are on.

They will go off automatically after a period

of time that depends on the level of charge in

the battery (entering energy economy mode).

Switching off of the lamps when the

ignition is switched off

When the ignition is switched off, all of the

lamps turn off immediately, except for dipped

beam headlamps if automatic guide-me-home

lighting is activated.

In some weather conditions (e.g. low

temperature or humidity), misting on the

internal surface of the glass of the headlamps

and rear lamps is normal, and will disappear

after the lamps have been on for a few

minutes.

Never look too closely at the light beam

of LED technology lamps - risk of serious

eye injury!





Travelling abroad

If planning to use your vehicle in a

country that drives on the other side of the

road, the dipped beam headlamps must be

adjusted to avoid dazzling oncoming drivers.

Contact a CITROËN dealer or a qualified

workshop.

Daytime running lamps/

Sidelamps

These LED lamps at the front and rear of the

vehicle light up automatically when the engine

starts.

They perform the following functions:

–  Daytime running lamps (lighting control stalk

at position

"AUTO

" with adequate ambient light).

–  Sidelamps (lighting control stalk at position

"

AUTO

" with low ambient light or "Sidelamps

only" or "Dipped/main beam headlamps").

Direction indicators





►  Left or right: lower or raise the lighting control

stalk, beyond the point of resistance.

If you keep the direction indicators on for

more than 20 seconds, the volume of the

audible signal will increase if the speed is

above 50 mph (80 km/h).

Three flashes

►  Press briefly upwards or downwards, without

going beyond the point of resistance; the

direction indicators will flash 3 times.

Parking lamps

(Depending on version)

Vehicle side marking by lighting the sidelamps

on the traffic side only.

►  Within one minute after switching off the

ignition, operate the lighting control stalk

upwards or downwards, depending on the side

of the traffic (e.g. when parking on the right, push

the lighting control stalk down to light up on the

left).

This is confirmed by an audible signal and the

lighting of the corresponding direction indicator

lamp on the instrument panel.

►  To switch off the parking lamps, return the

lighting control stalk to the central position.

Automatic illumination of

lamps

With the lighting control stalk in the “

AUTO

”

position and if a low level of exterior brightness

is detected by the rain/sunshine sensor, the

67

Lighting and visibility

4

sidelamps and dipped beam headlamps are

switched on automatically, without any action on

the part of the driver. They may also come on if

rain is detected, at the same time as automatic

operation of the windscreen wipers.

As soon as the brightness returns to a sufficient

level or after the windscreen wipers are switched

off, the lamps are switched off automatically.

Malfunction

In the event of a malfunction of the rain/

sunshine sensor, the vehicle’s lamps

come on and this warning lamp is displayed on

the instrument panel, accompanied by an

audible signal and/or the display of a message.

Have it checked by a CITROËN dealer or a

qualified workshop.

Do not cover the rain/sunshine sensor

located at the top centre of the

windscreen behind the interior rear view

mirror; the associated functions would no

longer be controlled.

In fog or snow, the rain/sunshine sensor

may detect sufficient light. For this

reason, the lighting will not come on

automatically.

The inner surface of the windscreen may

become misted up and affect the proper

operation of the rain/sunshine sensor.

In humid and cold weather, demist the

windscreen regularly.

Guide-me-home and

welcome lighting

Guide-me-home lighting

Automatic

With the ring of the lighting control stalk in the

"

AUTO

" position and when the light is poor, the

dipped beam headlamps come on automatically

when the ignition is switched off.

You can activate/deactivate this function

and adjust the guide-me-home lighting

duration in the

Driving

/

Vehicle

 touch screen

menu.

Manual





►  With the ignition off, pull the lighting control

stalk toward you ("headlamp flash") to activate/

deactivate the function.

Manual guide-me-home lighting goes off

automatically after a period of time.

Automatic exterior welcome

lighting

With the "Automatic illumination of lamps"

function activated and when the light is poor, the

sidelamps, dipped beam headlamps and door

mirror spotlamps come on automatically when

the vehicle is unlocked.

The activation, deactivation and duration

of the exterior welcome lighting are set in

the

Driving

/

Vehicle

 touch screen menu.

Door mirror spotlamps

These spotlamps facilitate access to the vehicle

by lighting the ground near the front doors.

When the front courtesy lamp switch is in

this position, the spotlamps come on

automatically:

–  when the vehicle is unlocked.

–  when a door is opened.

–  when a request to locate the vehicle is

received from the remote control.

Whatever the position of the front courtesy lamp

switch, they also come on with the welcome

lighting and guide-me-home lighting functions.

They go off automatically after 30 seconds.

68

Lighting and visibility

Headlamp beam height

adjustment









To avoid dazzling other road users, the height

of these headlamp beams must be adjusted

according to the load in the vehicle.

0 (Initial setting)

Driver only or driver + front passenger

1

5 people

4

5 people + load in the boot

5

Driver only + load in the boot

This information is provided as a guide only.

Depending on version, the unused positions may

be required.

Automatic lighting

systems - General

recommendations

The automatic lighting systems use a detection

camera, located at the top of the windscreen.

Operating limits

The system may be disrupted or not work

correctly:

–  When visibility conditions are poor

(e.g. snowfall, heavy rain).

–  If the windscreen is dirty, misted-up or

masked (e.g. sticker) in front of the camera.

–  If the vehicle is facing highly reflective signs

or safety barrier reflectors.

The system is not able to detect:

–  Road users that do not have their own

lighting, such as pedestrians.

–  Vehicles with hidden lighting (e.g. travelling

behind a safety barrier on the motorway).

–  Vehicles at the top or bottom of a steep

slope, on winding roads, on crossroads.

Maintenance

Clean the windscreen regularly,

particularly the area in front of the camera.

The internal surface of the windscreen can

also become misted around the camera.

In humid and cold weather, demist the

windscreen regularly.

Do not allow snow to accumulate on the

bonnet or roof of the vehicle as this could

obstruct the camera.

Automatic headlamp

dipping

For more information, refer to the

General recommendations for

automatic lighting systems

.

With the ring of the lighting control stalk in the

"

AUTO

" position and the function activated on

the touch screen, this system automatically

switches between dipped and main beam

headlamps, according to lighting and traffic

conditions, using a camera located at the top of

the windscreen.





This system is a driving aid.

The driver remains responsible for

the vehicle's lighting, its correct use in the

prevailing light, visibility and traffic conditions,

and for compliance with driving and vehicle

regulations.

69

Lighting and visibility

4

The system becomes operational when

the vehicle exceeds 16 mph (25 km/h).

When the speed falls below 9 mph (15 km/h),

the function is no longer operational.

Activation/Deactivation

The settings are changed via the

Driving/

Vehicle

 touch screen menu.

When deactivated, the lighting system changes

to "automatic illumination of headlamps" mode.

The state of the system is stored when the

ignition is switched off.

Operation

If the ambient light level is very low and traffic

conditions permit:

–  The main beam headlamps

come on automatically. These

indicator lamps light up on the instrument panel.

If the ambient light level is sufficient and/or the

traffic conditions do not allow the main beam

headlamps to be lit:

–  The dipped beam headlamps

remain lit. These indicator lamps

light up on the instrument panel.

The function is deactivated if the foglamps

are switched on or if the system detects poor

visibility conditions (e.g. fog, heavy rain,

snowfall).

When the foglamps are switched off or when the

visibility conditions become favourable again, the

function is automatically reactivated.

This indicator lamp goes out when the

function is deactivated.

Pause

If the situation requires a change of headlamp

beam, the driver can take over at any time.

►  Switch the headlamps manually between

dipped and main beam to pause the function.

If the "AUTO" and "Dipped beam" indicator

lamps were on, the system changes to main

beam.

If the "AUTO" and "Main beam" indicator lamps

were on, the system changes to dipped beam.

►  To reactivate the function, once again switch

the headlamps manually between dipped and

main beam.

Cornering lighting

(Only on versions equipped with halogen

foglamps)

This system makes use of the beam from a front

foglamp to illuminate the inside of a bend, when

the main or dipped beam headlamps are on and

the vehicle speed is below 25 mph (40 km/h)

(urban driving, winding road, junctions, parking

manoeuvres).





Without/With cornering lighting

Activation / Deactivation

It is set via the

Driving / Vehicle

 touch

screen menu.

Switching on/off

This system starts:

–  when the corresponding direction indicator is

switched on.

or

–  from a certain angle of rotation of the steering

wheel.

It becomes inactive:

–  below a certain angle of rotation of the

steering wheel.

–  above approximately 25 mph (40 km/h).

–  when reverse gear is engaged.

Wiper control stalk

Before operating the wipers in wintry

conditions, clear any snow, ice or frost

from the windscreen and around the wiper

arms and blades.

70

Lighting and visibility

Do not operate the wipers on a dry

windscreen. In extremely hot or cold

weather, check that the wiper blades are not

stuck to the windscreen before operating the

wipers.

After using an automatic car wash, you

may temporarily notice abnormal noises

and poorer wiping performance.  You do not

need to replace the wiper blades.

Without AUTO wiping









With AUTO wiping





Windscreen wipers

►  To select the wiping speed: raise or lower the

stalk to the desired position.

Fast wiping (heavy rain)

Normal wiping (moderate rain)

Intermittent wiping (proportional to the

vehicle’s speed)

Off



Single wipe (press down and release).

or

Automatic wiping

Refer to the corresponding section.

In position

1

 or

2

, the wiping frequency is

automatically reduced when the speed of

the vehicle drops below 3 mph (5 km/h).

When the speed is above 6 mph (10 km/h)

again, the wiping frequency returns to the

original frequency (fast or normal).

After switching off the ignition, a slight

movement of the windscreen wipers to

store them under the bonnet may occur.

If the ignition has been switched off with

the windscreen wiper active, it is

necessary to operate the control stalk to

reactivate the wiping when the ignition is

switched on (unless the ignition is off for less

than 1 minute).

Windscreen wash

►  Pull the wiper control stalk towards you and

hold.

A final wiping cycle is performed when

screenwashing ends.

The windscreen wash jets are

incorporated into the tip of each wiper

arm.

Screenwash fluid is sprayed along the length

of the wiper blade. This improves visibility and

reduces screenwash fluid consumption.

To avoid damaging the wiper blades, do

not operate the screenwash if the

screenwash reservoir is empty.

Only operate the screenwash if there is no

risk of the fluid freezing on the windscreen

and hindering visibility. During the winter

period, use "very cold climate" rated products.

Never top up with water.

Rear wiper





71

Lighting and visibility

4

►  Turn the ring to align the desired symbol with

the marking.

Off



Intermittent wiping

Screenwash-wipe

Reverse gear

When reverse gear is engaged, the rear wiper

will come into operation automatically if the front

windscreen wipers are operating.

The system is activated or deactivated via the

vehicle settings menu in the screen.

This function is activated by default.

In the event of accumulation of snow or

hard frost or if a bicycle carrier is fitted to

a towing device, deactivate the automatic rear

wiper via the touch screen's

Driving/ Vehicle



menu.

Rear screenwash

►  Turn the ring all the way towards the

dashboard and hold.

The screenwash and the wiper operate for as

long as the ring remains turned.

A final wiping cycle is performed when

screenwashing ends.

Automatic windscreen

wipers

In

AUTO

 mode, the windscreen wipers operate

automatically and adapt to the intensity of the

rainfall.

Detection is via a rain/brightness sensor, located

at the top centre of the windscreen behind the

rear view mirror.

Do not cover the rain/sunshine sensor.

When using an automatic car wash,

switch off the automatic wipers and the

ignition.

In winter, wait until the windscreen is

completely clear of ice before activating the

automatic wipers.

Switching on





►  Give a short downwards push to the control

stalk.

A wiping cycle confirms that the instruction has

been accepted.

This indicator lamp lights up on the

instrument panel, accompanied by a

message.

Switching off

►  Give the control stalk another brief push

downwards or set the control stalk to another

position (

Int

,

1

 or

2

).

This indicator lamp goes off on the

instrument panel, accompanied by a

message.

If the ignition has been off for more than

one minute, the automatic wipers must

be reactivated by pushing the control stalk

downwards.

Malfunction

If a fault occurs with the automatic wipers, the

wipers operate in intermittent mode.

Have it checked by a CITROËN dealer or a

qualified workshop.

Special position of the

windscreen wipers

This maintenance position is used while cleaning

or replacing the wiper blades. It can also be

useful, in wintry weather (ice, snow), to release

the wiper blades from the windscreen.

To maintain the effectiveness of the flat

wiper blades, it is advisable to:

–  handle them with care.

–  clean them regularly using soapy water.

72

Lighting and visibility

–  avoid using them to hold cardboard on the

windscreen.

–  replace them at the first signs of wear.

Before removing a windscreen wiper blade





Operating the wiper control stalk immediately

after switching off the ignition will place the wiper

blades in a vertical position.

►  Proceed with the desired operation or the

replacement of the wiper blades.

After refitting a windscreen wiper blade

►  To return the wiper blades to their initial

position after the operation, switch on the ignition

and operate the wiper control stalk.

Changing a wiper blade

Removing/Refitting at the front





►  Carry out these wiper blade replacement

operations from the driver's side.

►  Starting with the wiper blade farthest from

you, hold each arm by the rigid section and raise

it as far as possible.

Take care not to hold the arms at the jet

locations.

Do not touch the wiper blades - risk of

irreparable deformation.

Do not release them while moving them. Risk

of damaging the windscreen!

►  Clean the windscreen using screenwash

fluid.

Do not apply "Rain X" type water-

repellent products.

►  Unclip the worn wiper blade closest to you

and remove it.

►  Install the new wiper blade and clip it to the

arm.

►  Repeat the procedure for the other wiper

blade.

►  Starting with the wiper blade closest to you,

once again hold each arm by the rigid section,

then guide it carefully onto the windscreen.

Removing/refitting at the rear

►  Hold the arm by the rigid section and raise it

as far as possible.

►  Clean the rear screen using screenwash

fluid.

►  Unclip the worn wiper blade and remove it.

►  Install the new wiper blade and clip it to the

arm.

►  Once again hold the arm by the rigid section,

then guide it carefully onto the rear screen.

73

Safety

5

General safety

recommendations

Do not remove the labels attached in

different places on your vehicle. They

include safety warnings as well as

identification information for the vehicle.

For all work on your vehicle, use a

qualified workshop that has the technical

information, skills and equipment required, all

of which a CITROËN dealer is able to

provide.

Depending on country regulations,

certain safety equipment may be

mandatory: high visibility safety vests,

warning triangles, breathalysers, spare bulbs,

spare fuses, fire extinguisher, first aid kit, mud

flaps at the rear of the vehicle, etc.

Installing electrical accessories:

–  The fitting of electrical equipment or

accessories not approved by CITROËN may

cause excessive current consumption and

faults and failures with the electrical system

of your vehicle. Contact a CITROËN dealer

for information on the range of approved

accessories.

–  As a safety measure, access to the

diagnostic socket, used for the vehicle's

electronic systems, is reserved strictly for

CITROËN dealers or qualified workshops,

equipped with the special tools required (risk

of malfunctions of the vehicle's electronic

systems that could cause breakdowns or

serious accidents). The Manufacturer cannot

be held responsible if this advice is not

followed.

–  Any modification or adaptation not intended

or authorised by CITROËN or carried out

without meeting the technical requirements

defined by the Manufacturer will result in the

suspension of the commercial warranty.

Installation of accessory radio

communication transmitters

Before installing a radio communication

transmitter with an external aerial, you must

without fail contact a CITROËN dealer for

the specification of transmitters which can

be fitted (frequency, maximum power, aerial

position, specific installation requirements),

in line with the Vehicle Electromagnetic

Compatibility Directive (2004/104/EC).

Declarations of conformity for radio

equipment

The relevant certificates are available on the

brand website:

http://service.citroen.com/ACddb/

Hazard warning lamps









►  Pressing the red button causes all the

direction indicators to flash.

They can operate with the ignition off.

Automatic operation of

hazard warning lamps

When braking in an emergency, depending on

the rate of deceleration, the hazard warning

lamps come on automatically. They switch off

automatically when you next accelerate.

They can be turned off by pressing the button

again.

74

Safety

Horn





►  Press the central part of the steering wheel.

Pedestrian horn

(Rechargeable hybrid)

This system alerts pedestrians that the vehicle

is approaching, when driving in

Electric

 mode

(100% electric driving).

The pedestrian horn operates once the vehicle

is moving and at speeds of up to 19 mph

(30 km/h), in forward or reverse gear.

This function cannot be deactivated.

Malfunction

In the event of a malfunction, this warning

lamp lights up on the instrument panel.

* In accordance with the general conditions of use of the service, available from dealers and subject to technological and technical limitations.

** Depending on the geographic coverage provided by the "eCall (SOS)" and "ASSISTANCE" systems.

The list of countries covered and the telematic services provided is available from dealers or on the website for your country.

Have it checked by a CITROËN dealer or a

qualified workshop.

Emergency or assistance

call









eCall (SOS)

Your vehicle may be fitted with the eCall (SOS)

system either as standard or as an option.

The eCall (SOS) system provides direct contact

to the emergency services and is fully built

into the vehicle. This contact is made either

automatically via the sensors built into the

vehicle, or by pressing button

1

.

According to the country of sale, the eCall (SOS)

system corresponds to the systems PE112,

ERAGLONASS, 999, etc.

The eCall (SOS) system is activated by default.

►  To make an emergency call manually, press

button

1

 for more than 2 seconds.

The lit indicator lamp and a voice message

confirm that the call has been made to the

emergency services*.

The eCall (SOS) system immediately locates

your vehicle and puts you in contact with the

appropriate emergency services**.

►  Pressing again immediately cancels the

request.

The indicator lamp flashes while the vehicle

data is being sent, and then remains lit when

communication is established.

In the event that a serious accident is

detected by the sensors built into the

vehicle, such as the airbag control unit, an

emergency call is made automatically.

The eCall (SOS) system is a public

service of general interest and is

free-of-charge.

System operation

–  Upon switching on the ignition, if the indicator

lamp lights up red, then green, and then goes

out: the system is operating correctly.

75

Safety

5

–  If the indicator lamp is fixed red: system

malfunction

–  If the indicator lamp flashes red: replace the

emergency battery.

In the latter two cases, emergency and

assistance call services may not work.

Contact a dealer or a qualified repairer as soon

as possible.

The system fault does not prevent the

vehicle from being driven.

Data processing

All processing of personal information

by the "Localised Emergency Call" system

(PE112) complies with the framework for

protection of personal information established

by Regulation 2016/679 (GDPR) and

Directive 2002/58/EC of the European

Parliament and the Council, and in particular,

seeks to protect the vital interests of the

data subject, in accordance with Article 6.1,

paragraph d) of Regulation 2016/679.

Personal information processing is strictly

limited to the management of the "Localised

Emergency Call" system used with the “112”

European single emergency call number.

The "Localised Emergency Call" system is

able to collect and process only the following

* Depending on the geographic coverage of the "eCall (SOS)" and "ASSISTANCE" systems and the official national language chosen by the owner of the

vehicle.

The list of countries covered and the telematic services provided is available from dealers or on the website for your country.

data relating to the vehicle: chassis number,

type (passenger vehicle or light commercial

vehicle), fuel type or power source, most

recent three locations and direction of travel,

and a timestamped log file recording the

automatic activation of the system.

The recipients of the processed data are the

emergency call handling centres designated

by the relevant national authorities in the

territory in which they are located, enabling

priority reception and handling of calls to the

“112” emergency number.

Data storage

Data contained in the system’s memory

is not accessible from outside the system until

a call is made. The system is not traceable

and is not continuously monitored in its

normal operating mode.

The data in the system's internal memory is

automatically and continuously erased. Only

the vehicle’s three most recent locations are

stored.

When an emergency call is triggered, the data

log is stored for no more than 13 hours.

Access to data

You have the right to access the data

and, if necessary, submit a request to

rectify, erase or restrict the processing of

any personal information not processed in

accordance with the provisions of Regulation

2016/679 (GDPR). Third parties to which data

has been communicated shall be notified of

any rectification, erasure or restriction carried

out in accordance with the aforementioned

Directive, unless doing so would be

impossible or require a disproportionate effort.

You also have the right to lodge a complaint

with the relevant data protection authority.

ASSISTANCE

►  If the vehicle breaks down, press button

2



for more than 2 seconds to request assistance

(confirmed by a voice message*).

►  Pressing again immediately cancels the

request.

Privacy mode allows you to manage the

level of sharing (data and/or position)

between your vehicle and the CITROËN

brand.

It can be configured in the

Settings

 menu on

the touch screen.

76

Safety

By default, depending on equipment,

deactivate/reactivate geolocation by

simultaneously pressing the 2 buttons, then

press the "Localised Assistance Call" button

to confirm.

If you purchased your vehicle outside the

CITROËN dealer network, we invite you

to have a dealer check the configuration of

these services and, if desired, modify them to

suit your wishes. In a multilingual country,

configuration is possible in the official national

language of your choice.

For technical reasons, in particular to

improve the quality of telematic services

for customers, the Manufacturer reserves the

right to carry out updates to the vehicle's

on-board telematic system at any time.

If you benefit from the Citroën Connect

Box offer with the SOS and Assistance

Pack included, there are additional services

available to you in your personal space, via

the website for your country.

For information about the SOS and

Assistance Pack, please refer to the general

conditions for these services.

Electronic stability control

(ESC)

The electronic stability control programme

includes the following systems:

–  Anti-lock braking system (ABS) and Electronic

brake force distribution (EBFD).

–  Emergency braking assistance (EBA).

–  Anti-slip regulation (ASR).

–  Dynamic stability control (DSC).

–  Intelligent traction control.

–  Trailer stability assist (TSA).

Anti-lock braking system

(ABS)/Electronic brake force

distribution (EBFD)

These systems enhance the vehicle’s stability

and handling during braking, and enable greater

control while cornering, particularly on poor or

slippery road surfaces.

ABS prevents wheel locking in the event of

emergency braking.

Electronic brake force distribution (EBFD)

manages overall braking pressure on each

individual wheel.

►

When braking in an emergency, depress

the pedal very firmly and maintain this

pressure.

Normal operation of the ABS may make

itself felt by slight vibrations of the brake

pedal.

The fixed illumination of this warning lamp

signals that there is a fault with the ABS.

The vehicle retains conventional braking. Drive

carefully at a moderate speed.

Have it checked by a CITROËN dealer or a

qualified workshop.

This warning lamp, when lit together with

the

STOP

 and ABS warning lamps,

accompanied by a message and an audible

signal, indicates an EBFD malfunction.

You must stop the vehicle.

Stop as soon as it is safe to do so and switch off

the ignition.

Contact a CITROËN dealer or a qualified

workshop.

When changing wheels (tyres and rims),

ensure that these are approved for your

vehicle.

After an impact

Have it checked by a CITROËN dealer or

a qualified workshop.

Emergency braking

assistance (EBA)

This system reduces the emergency stopping

distance, by optimising the braking pressure.

It is triggered in relation to the speed at which

the brake pedal is depressed. The effect of this

is a reduction in the resistance of the pedal and

an increase in braking efficiency.

77

Safety

5

Anti-slip regulation (ASR)

/ Dynamic stability control

(DSC)

Anti-slip regulation (or traction control) optimises

traction by using engine braking and by applying

the brakes on the driving wheels to avoid one

or more wheels spinning. It also enhances the

vehicle's directional stability.

If there is a difference between the vehicle’s

trajectory and the path desired by the driver, the

dynamic stability control system automatically

uses engine braking and the brakes on one or

more wheels to return the vehicle to the desired

path, within the limits of the laws of physics.

These systems are activated automatically every

time the vehicle is started.

These systems are activated in the event

of a problem with grip or trajectory

(confirmed by this warning lamp flashing on the

instrument panel).

Deactivation/Reactivation

In exceptional conditions (starting a vehicle

which is bogged down, stuck in snow, on soft

ground, etc.), it may be advisable to deactivate

these systems, so that the wheels can turn freely

and regain grip.

Deactivation is possible up to 19 mph (30 km/h).

Reactivate the systems as soon as the level of

grip permits.

The settings are changed via the

Driving/

Vehicle

 touch screen menu.

Deactivation is confirmed by the lighting

of this indicator lamp on the instrument

panel and the display of a message.

These systems are reactivated automatically

every time the ignition is switched off, or at

speeds over 31 mph (50 km/h).

Reactivation is manual below 31 mph (50 km/h).

Malfunction

In the event of a malfunction, this warning

lamp comes on on the instrument panel,

accompanied by the display of a message and

an audible signal.

Have it checked by a CITROËN dealer or a

qualified workshop.

ASR/DSC

These systems enhance safety during

normal driving, but should not encourage

the driver to take extra risks or drive at high

speed.

It is in conditions of reduced grip (rain, snow,

ice) that the risk of loss of grip increases. It

is therefore important for your safety to keep

these systems activated in all conditions, and

particularly in difficult conditions.

Correct operation of these systems depends

on compliance with the manufacturer's

recommendations relating to the wheels

(tyres and rims), braking and electronic

components, as well as the assembly and

repair procedures provided by CITROËN

dealers.

In order to ensure that these systems remain

effective in wintry conditions, the use of snow

or all-season tyres is recommended. All four

wheels must be fitted with tyres approved for

your vehicle.

All tyre specifications are listed on the

tyre/paint label. For more information

on

Identification markings

, refer to the

corresponding section.

Intelligent traction control

("Snow motion")

(Depending on version)

The intelligent traction control system helps

improve grip when driving on snow.

This system detects situations of poor surface

grip that could make it difficult to move off

or make progress on deep fresh snow or

compacted snow.

In these situations, the system limits the amount

of wheel spin to provide the best traction and

trajectory control for the vehicle.

The use of winter tyres is strongly

recommended on slippery surfaces.

Trailer stability assist (TSA)

When towing, this system reduces the risk of the

vehicle or trailer snaking.

78

Safety

Operation

The system is activated automatically when the

ignition is switched on.

The electronic stability control system (ESC)

must not have any faults.

The vehicle speed must be between 37 and 99

mph (60 and 160 km/h).

If the system detects that the trailer is

snaking, it applies the brakes to stabilise

the trailer and reduces engine power, if

necessary, to slow the vehicle (indicated by the

flashing of this warning lamp on the instrument

panel and the brake lamps coming on).

For information on weights and towed loads,

refer to the

Engine technical data and towed

loads

 section or your vehicle’s registration

certificate.

To ensure safe driving with a

Towing device

,

refer to the corresponding section.

Malfunction

If a fault occurs, this warning lamp lights

up on the instrument panel, accompanied

by a message and an audible signal.

To continue towing a trailer, reduce speed and

drive carefully!

Have it checked by a CITROËN dealer or a

qualified workshop.

The trailer stability control system

provides an extra safety feature under

normal driving conditions, when following the

recommendations for use of trailers and

current legislation in force in your country. It

must not encourage the driver to take extra

risks, such as using a trailer in unsuitable

conditions of operation (e.g. excessive load,

exceeded nose weight, worn or under-inflated

tyres, faulty braking system) or driving at

excessive speed.

In certain cases, the system may not detect

trailer snaking, particularly with a light trailer.

When driving on slippery or poor surfaces, the

system may not be able to prevent sudden

trailer snaking.

Advanced Grip Control

This special patented traction control system

improves grip on snow, mud and sand.

For optimum grip on snow, it is

recommended that you fit the vehicle

with winter tyres.

For optimum system performance, contact a

CITROËN dealer to choose the most suitable

tyres.

Activation/Deactivation









►  Press the

DRIVE MODE

 button; the various

modes are displayed on the instrument panel.

►  Select “

Snow

”, “

Mud

” or “

Sand

” depending

on the context.

The chosen mode continues to be displayed in

the instrument panel.

►  To deactivate, select “

Normal

” mode or any

other driving mode.

The system is automatically deactivated when

the ignition is switched off.

Operating modes

Snow

This mode constantly adapts the level of wheel

spin to offer maximum traction according to the

snow conditions (a lot of wheel spin in thick

snow; very little on ice). The wheel spin is also

adapted to the conditions encountered when

79

Safety

5

driving uphill by optimising the acceleration of

the vehicle.

(mode active up to 50 mph (80 km/h))

Mud

This mode, when moving off, allows considerable

spin on the wheel with the least grip to optimise

clearing of the mud and to regain grip. At the

same time, the wheel with the most grip is

controlled in such a way as to transmit as much

traction torque as possible.

When moving, the system optimises wheel spin

to respond to the driver's requirements as fully

as possible.

(mode active up to 31 mph (50 km/h))

Sand

This mode allows little spin on the two driving

wheels at the same time to allow the vehicle to

move forward and limit the risks of getting stuck

in the sand.

(mode active up to 75 mph (120 km/h))

Do not use the other modes on sand as

the vehicle may become stuck.

Recommendations

The vehicle is designed principally

to drive on tarmac roads, but it may

occassionally drive on other less passable

terrain.

However, it does not permit off-road driving:

–  Driving on terrain that can damage the

underbody or tear off elements (e.g. fuel

pipe, fuel cooler) by obstacles or stones in

particular.

–  Driving on terrain with steep gradients and

poor grip.

–  Crossing a waterway.

Hill Assist Descent

Control

Hill Assist Descent Control system for medium to

steep slopes, on tarmac or other road surfaces

(e.g. gravel, mud).

This system reduces the risk of slip or loss of

control of the vehicle when descending, whether

going forward or in reverse.

During a descent, the system assists the driver

in maintaining a constant speed, depending on

the gear engaged, while progressively releasing

the brakes.

For the system to activate, the gradient

must be greater than 5%.

The system can be used with the gearbox in

neutral.

Otherwise, engage a gear corresponding to

the speed to prevent the engine stalling.

With an automatic gearbox, the system can

be used with the selector at

N

,

D

 or

R

.

When the system is regulating, the Active

Safety Brake system is automatically

deactivated.

The system is no longer available if the

speed of the vehicle is:

–  above 43 mph (70 km/h).

–  managed by the Adaptive cruise control,

depending on the type of gearbox.

Operation

Switching on

By default, the system is not selected.

The state of the function is not saved when the

ignition is switched off.

The driver can select the system when the

engine is running, when the vehicle is stationary

or when moving at speeds up to approximately

31 mph (50 km/h).









With instrument panels with dials

►  To select the system, at speeds below

31 mph (50 km/h), press this button until

its indicator lights up; this lamp appears in green

in the instrument panel.

The system becomes active at speeds below 19

mph (30 km/h).

80

Safety

With digital instrument panel

►  To select the system, at speeds below

31 mph (50 km/h), press this button until

its green indicator lamp comes on; this lamp

appears in grey in the instrument panel.

►  The system becomes active at speeds

below 19 mph (30 km/h); this indicator

lamp comes on in green in the instrument panel.

►  When the vehicle begins its descent, you can

release the accelerator and brake pedals; the

system regulates the speed:

–  if the gearbox is in first or second gear,

the speed decreases and the

indicator lamp flashes rapidly,

–  if the gearbox is in neutral or if the clutch pedal

is depressed, the speed decreases and the

indicator lamp flashes slowly; in this case, the

maintained descent speed is lower.

On a descent, with the vehicle stationary, if you

release the accelerator and brake pedals, the

system will release the brakes to set the vehicle

gradually in motion.

The brake lamps light up automatically when the

system is regulating.

If the speed exceeds 19 mph (30 km/h),

regulation is paused automatically, the

indicator lamp goes back to grey in the

instrument panel, but the green indicator lamp in

the button remains on.

Regulation resumes automatically when the

speed falls below 19 mph (30 km/h) again, if the

slope and pedal release conditions are met.

You can depress the accelerator or brake pedal

again at any time.

Switching off

►  Press the button until its indicator lamp goes

off; the indicator lamp on the instrument panel

goes off.

At speeds above 43 mph (70 km/h), the system

is automatically deactivated; the indicator lamp in

the button goes off.

Malfunction

In the event of a malfunction, a message is

displayed on the instrument panel.

Have it checked by a CITROËN dealer or a

qualified workshop.

Seat belts

Inertia reel

The seat belts are equipped with an inertia

reel which allows the strap length to adjust

automatically to the shape of the user. The seat

belt returns to its storage automatically when it

is not used.

The inertia reels are fitted with a device which

automatically locks the strap in the event of a

collision, emergency braking or if the vehicle rolls

over. It can be released by pulling the strap firmly

and then releasing it so that it reels in slightly.

Pyrotechnic pretensioning

This system improves safety in the event of a

frontal or side impact.

Depending on the severity of the impact, the

pyrotechnic pretensioning system instantly

tightens the seat belts against the body of the

occupants.

The pyrotechnic pretensioning seat belts are

enabled when the ignition is on.

Force limiting system

This system reduces the pressure of the seat

belt on the chest of the occupant, thus improving

their protection.

In the event of an impact

Depending on the nature and

seriousness of the impacts, the pyrotechnic

device may trigger before and independently

of airbag deployment. Deployment of the

pretensioners is accompanied by a slight

discharge of harmless smoke and a noise,

due to the activation of the pyrotechnic

cartridge incorporated in the system.

In all cases, the airbag warning lamp comes

on.

Following an impact, have the seat belt

system checked, and if necessary replaced,

by a CITROËN dealer or a qualified

workshop.

Front seat belts

The front seat belts are fitted with a pyrotechnic

pretensioning system and a force limiting

system.

81

Safety

5

Height adjustment





►  To adjust the height of the anchorage point,

squeeze control

A

 and slide it to the notch

desired.

Rear seat belts





Each of the rear seats has a three-point seat belt

with inertia reel.

The outer seats are fitted with a pyrotechnic

pretensioning and force limiting system.

Fastening

►  Pull the strap, then insert the tongue in the

buckle.

►  Check that the seat belt is fastened correctly

by pulling the strap.

Unfastening

►  Press the red button on the buckle.

►  Guide the seat belt as it is reeled in.

►  On the side seat belts, raise the bar to the

top of the backrest to prevent the tongue from

knocking against the side trim.

Rear central seat belt

The seat belt for the rear central seat is

integrated into the roof.

Installation





►  Pull the strap and insert the tongue

A

 into the

left buckle (located on the passenger’s right side

when seated in the vehicle).

►  Insert the tongue

B

 into the right buckle

(located on the passenger’s left side when

seated in the vehicle).

►  Check that each buckle is fastened correctly

by pulling the strap.

Removal and storage

►  Press the red button on buckle

B

, then the

black button on buckle

A

.

►  Guide the strap as it reels in and offer up

tongue

B

, then

A

 to the magnet at the anchoring

point on the roof.

Before performing any operations on the

rear seats, to avoid damage to the seat

belts, check that the outer seat belts are

properly tensioned and attach the tongues to

their anchorage points. The central seat belt

must be completely reeled in.

Seat belt not fastened/

unfastened alerts









Not fastened/unfastened warning lamp
