34

Access

►  Switch off the ignition and remove the key

from the ignition switch.

The remote control is now fully operational

again.

With Keyless Entry and Start





►  Insert the mechanical key (incorporated into

the remote control) into the lock to open the

vehicle.

►  Place the electronic key against the back-up

reader on the steering column and hold it there

until the ignition is switched on.

►

With a manual gearbox,

 place the gear lever

in neutral then fully depress the clutch pedal.

►

With an automatic gearbox,

 while in mode

P

, depress the brake pedal.

►  Switch on the ignition by pressing the

"

START/STOP

" button.

If the fault persists after reinitialisation, contact a

CITROËN dealer or a qualified workshop without

delay.

Doors

Opening

From outside

►  After unlocking the vehicle or with the

"Keyless Entry and Start" system electronic key

in the recognition zone, pull the door handle.

From inside

►  Pull the interior opening control of a door; this

unlocks the vehicle completely.

With selective unlocking activated:

–  Opening the driver's door unlocks

the driver's door only (if the vehicle has not

already been completely unlocked).

–  Opening one of the passenger doors

unlocks the rest of the vehicle.

The interior opening control on a rear

door does not work if the child lock is on.

For more information on the

Child Lock

, refer

to the corresponding section.

Boot

Opening





►  With the vehicle unlocked or with the Keyless

Entry and Start electronic key in the recognition

zone, press the left-hand button on the central

tailgate control.

►  Lift the tailgate.

When selective unlocking is activated,

the electronic key must be close to the

rear of the vehicle.

For more information on the

Remote control

 or

on the

Keyless Entry and Start

, please refer to

the corresponding section.

If there is a fault or if it is difficult to move

the tailgate when opening or closing it,

have it checked as soon as possible by a

CITROËN dealer or a qualified workshop to

prevent the problem becoming worse, and

potentially causing the tailgate to drop and

thereby inflicting serious injuries.

35

Access

2

The tailgate is not designed to support a

bicycle carrier.

Closing

►  Lower the tailgate using the interior grab

handle.

In the event of a malfunction or if you

experience difficulty opening or closing

the tailgate, have it checked by a CITROËN

dealer or a qualified workshop without delay,

to avoid the issue deteriorating and prevent

any risk of the tailgate dropping, potentially

causing serious injury.

Back-up release

To manually unlock the boot in the event of a

battery or central locking failure.

Unlocking

►  Fold the rear seats to gain access to the lock

from inside the boot.





►  Insert a small screwdriver into hole

A

 of the

lock to unlock the boot.

►  Move the latch to the left.

Locking after closing

If the fault persists after closing again, the boot

will remain locked.

In the event of a fault with the central

locking system, it is essential to

disconnect the battery to lock the boot and so

ensure complete locking of the vehicle.

Hands-free tailgate

(Depending on version)

The motorised tailgate must only be operated

with the vehicle stationary.





Check that there is enough space to

allow for the movement of the motorised

tailgate.





Never insert a finger in the locking

system of the motorised tailgate - risk of

serious injury!

Anti-pinch

The motorised tailgate has an obstacle detection

system that automatically interrupts and reverses

its movement by a few degrees, to allow the

obstacle to be cleared.

Please note that this anti-pinch system is not

active at the end of the closing travel (around

1 cm from completely closed).

To avoid the risk of injury through

pinching or trapping, before and during

operation of the motorised tailgate:

–  ensure that there is no-one close to the

rear of the vehicle.

–  monitor the activity of the rear passengers,

particularly any children.

36

Access

Bicycle carrier/Towing device

The motorised tailgate is not designed to support

a bicycle carrier.

When installing a bicycle carrier on the towing

device with connection of the cable to the trailer

socket, the motorised operation of the tailgate

will be automatically deactivated.

If using a towing device or bicycle carrier

not recommended by CITROËN, it is

essential to deactivate the motorised

operation of the tailgate.

Motorised operation

Motorised operation of the tailgate is set

via the

Driving/Vehicle

 touch screen

menu.





There are several ways of operating the tailgate:

A.

Using the Keyless Entry and Start system’s

electronic key

B.

Using the exterior tailgate control

C.

Using the interior tailgate control

Opening

►  A long press on the central button

A

 of the

electronic key.

or

►  A short press on the exterior tailgate control

B

, with the electronic key on your person.

The tailgate opens, either completely by

default, or to the position memorised

beforehand.

If motorised operation is not activated, these

actions release the tailgate (partially-open

position).

When the vehicle is locked, the request to

open the boot with one of the controls

A



or

B

 unlocks the vehicle, or only the boot if

selective unlocking is activated, prior to the

opening of the boot.

Closing

►  A short press on the interior tailgate control

C

.

It is possible to interrupt the operation of

the tailgate at any point.

Pressing one of these controls again

interrupts the movement that is underway.

Hands-free function (Hands-Free

Tailgate Access)

With the electronic key on your person, this

function allows the motorised tailgate to be

opened, closed or stopped via a "kicking"

movement under the rear bumper.

The "Hands-Free Tailgate/Access"

function is set via the

Driving/Vehicle



touch screen menu.

Ensure that you are steady on your feet

before performing the "kicking"

movement.

Take care not to touch the exhaust system

which may be hot - risk of burns!

Rechargeable hybrid vehicles

The function is not available when the

vehicle is connected.



37

Access

2



►  Position yourself behind the vehicle by the

number plate and perform a "kicking" movement

in the "

OK

" detection zone.

The "kicking" movement must be given forwards,

smoothly, not too fast and with a vertical

movement from low to high. Raise the foot

sufficiently and remove it immediately.

Recognition of the "kicking" movement is

confirmed by the lighting of the direction

indicators followed by an audible signal.

"Sideward kicking" movements do not

work. If the "kicking" movement has not

been detected, wait at least 2 seconds before

repeating the movement.

Do not perform repetitive "kicking"

movements.

If the motorised tailgate has not started to open,

check that:

–  the function is activated.

–  the electronic key is on your person, outside

the vehicle in the rear recognition area.

–  the "kicking" movement was performed in the

detection zone, close enough to the bumper.

–  the foot was removed from the bumper quickly

enough.

Automatic locking with the hands-free

function

The automatic locking of the vehicle with

the hands-free function can be activated/

deactivated via the

Driving/Vehicle

 touch

screen menu.

When the vehicle is locked, the request

to open the tailgate with this function

unlocks the vehicle, or only the tailgate if

selective unlocking is activated, prior to the

opening of the tailgate.

Closing the tailgate with the "Hands-Free

Tailgate Access" function enables you to lock

the vehicle.

Recommendations on the hands-free

function (Hands-Free Tailgate Access)

If it does not work, check that the electronic key

is not exposed to a source of electromagnetic

interference (e.g. smartphone).

The function may be deactivated or affected if

there is rain or snow.

The function may not work correctly with a

prosthetic leg.

In some circumstances, the tailgate may open or

close by itself, particularly when:

–  hitching up or removing a trailer;

–  operating a towing device;

–  fitting or removing a bicycle carrier;

–  loading or unloading bicycles on/from a bicycle

carrier;

–  depositing or lifting something behind the

vehicle;

–  an animal approaches the rear bumper;

–  washing the vehicle;

–  maintenance is performed on the vehicle;

–  accessing the spare wheel.

To avoid such operating problems, keep the

electronic key away from the recognition zone or

deactivate the hands-free function.

Towing device

The installation of a towing device may

disturb the detection system.

►  Perform the "kicking" movement on the

right side of the towing device.

38

Access

Memorising an opening

position

To

memorise

 a position, in order to limit the

motorised tailgate opening angle:

►  move the tailgate to the desired position

manually or by pressing the button.

►  press button

C

 or the exterior control

B

 for

more than 3 seconds (memorisation is confirmed

by a brief audible signal).

Memorising is not available until the

height of opening is more than or equal

to 1 metre between the low position and the

high position of the tailgate.

To

delete

 the memorised position:

►  open the tailgate to any position.

►  press button

C

 or the exterior control

B

 for

more than 3 seconds (deletion is confirmed by a

long audible signal).

Manual operation

The tailgate can be manoeuvred by hand, even

with motorised operation activated.

The tailgate must be stationary.

With resumption of the motorised function

The motorised tailgate function can be activated

manually.

►  With the boot open: vigorously move the

tailgate a little in the closing direction to activate

motorised closing.

►  With the boot partly open: vigorously move

the tailgate a little in the opening direction to

activate motorised opening.

Without resumption of the motorised

function

►  Move the tailgate as slowly and smoothly as

possible.

Assistance from the gas struts is no longer

available when opening and closing the

motorised tailgate manually. Resistance to

opening and closing is therefore quite normal.

In case of the motor overheating

Repeatedly opening and closing the

tailgate can cause overheating of its electric

motor, after which opening and closing will not

be possible.

Allow the electric motor to cool down for at

least 10 minutes before carrying out any

manoeuvre.

If you are unable to wait, operate it manually.

Manual closing of the

motorised tailgate in case of

failure

This operation is

only necessary in the case of

failure of the tailgate motor

.

If the failure originates from the battery, it is

recommended to recharge it or change it with the

tailgate

closed

.

In this situation, a significant force may be

needed to close the tailgate.

►  Close it gently without slamming, as slowly as

possible, by pushing at the centre of the tailgate.

Do not lower the tailgate by pushing at

one of its sides - risk of damage!

Precautions in use

In wintry conditions

To avoid any operating problems, remove

the snow or wait until the ice melts before

requesting motorised opening of the tailgate.

When washing

When washing the vehicle in an

automatic car wash, do not forget to lock and

move away from the vehicle to prevent any

risk of unwanted opening.

Alarm

(Depending on version)

39

Access

2









System which protects and provides a deterrent

against theft and break-ins.

Exterior perimeter monitoring

The system checks for opening of the vehicle.

The alarm is triggered if anyone tries to open a

door, the boot or the bonnet, for example.

Interior volumetric monitoring

The system checks for any variation in volume in

the passenger compartment.

The alarm is triggered if anyone breaks a

window, enters the passenger compartment or

moves inside the vehicle.

Anti-tilt monitoring

The system checks for any change in the attitude

of the vehicle.

The alarm goes off if the vehicle is lifted or

moved.

When the vehicle is parked, the alarm

will not be triggered if the vehicle is

knocked.

Self-protection function

The system checks whether any of its

components are out of service.

The alarm is triggered if the battery, the central

control or the siren wiring is put out of service or

damaged.

Work on the alarm system

Contact a CITROËN dealer or a qualified

workshop.

Locking the vehicle with full

alarm system

Activation

►  Switch off the ignition and exit the vehicle.

►  Lock or deadlock the vehicle using the

remote control or with the Keyless Entry and

Start system.

When the monitoring system is active, the red

indicator lamp in the button flashes once per

second and the direction indicators come on for

about 2 seconds.

The exterior perimeter monitoring is activated

after 5 seconds and the interior volumetric and

anti-tilt monitoring after 45 seconds.

Door, boot or bonnet

If an opening is not properly closed,

the vehicle is not locked, but the exterior

perimeter monitoring will be activated after

45 seconds, at the same time as the interior

volumetric and anti-tilt monitoring.

Sunroof

If the sunroof is remained open, the

vehicle will be locked with exterior perimeter

monitoring activated but without interior

volumetric or anti-tilt monitoring.

Deactivation

►  Press one of the remote control unlocking

buttons:

short press

long press

or

►  Unlock the vehicle with the Keyless Entry and

Start system.

The monitoring system is deactivated: the

indicator lamp in the button goes off and the

direction indicators flash for about 2 seconds.

If the vehicle automatically locks itself

again (as happens if a door or the boot is

not opened within 30 seconds of unlocking),

the monitoring system is automatically

reactivated.

40

Access

Locking the vehicle

with exterior perimeter

monitoring only

Deactivate the interior volumetric and anti-tilt

monitoring to avoid the unwanted triggering of

the alarm, in certain cases such as:

–  Slightly open window.

–  Washing the vehicle.

–  Changing a wheel.

–  Towing the vehicle.

–  Transport on a ship or ferry.

Deactivating the interior volumetric

and anti-tilt monitoring

►  Switch off the ignition and within 10 seconds

press the alarm button until its red indicator lamp

is on fixed.

►  Get out of the vehicle.

►  Immediately lock the vehicle using the remote

control or the Keyless Entry and Start system.

Only the exterior perimeter monitoring is

activated; the button's red indicator lamp flashes

once every second.

To take effect, this deactivation must be

carried out after each time the ignition is

switched off.

Reactivating the interior volumetric

and anti-tilt monitoring

►  Deactivate the exterior perimeter monitoring

by unlocking the vehicle using the remote control

or the Keyless Entry and Start system.

The indicator lamp in the button goes off.

►  Reactivate all monitoring by locking the

vehicle using the remote control or the Keyless

Entry and Start system.

The red indicator lamp in the button once again

flashes every second.

Triggering of the alarm

This is indicated by sounding of the siren

and flashing of the direction indicators for 30

seconds.

Depending on the country of sale, certain

monitoring functions remain active until the alarm

has been triggered eleven times consecutively.

When the vehicle is unlocked using the remote

control or the Keyless Entry and Start system,

rapid flashing of the red indicator lamp in the

button informs you that the alarm was triggered

during your absence. When the ignition is

switched on, this flashing stops.

Failure of the remote control

To deactivate the monitoring functions:

►  Unlock the vehicle using the key in the front

left-hand door lock.

►  Open the door; the alarm is triggered.

►  Switch on the ignition; this stops the alarm.

The indicator lamp in the button goes off.

Locking the vehicle without

activating the alarm

►  Lock the vehicle using the key (built-in the

remote control) in the front left-hand door lock.

Automatic activation

(Depending on version)

The system is activated automatically 2 minutes

after the last door or the boot is closed.

►  To avoid triggering the alarm on entering the

vehicle, first press the unlocking button on the

remote control or unlock the vehicle using the

"Keyless Entry and Start" system.

Malfunction

When the ignition is switched on, the fixed

lighting of the red indicator lamp in the button

indicates a system malfunction.

Have it checked by a CITROËN dealer or a

qualified workshop.

41

Access

2

Electric windows

1.

Left-hand front

2.

Right-hand front

3.

Right-hand rear

4.

Left-hand rear

5.

Deactivation of electric window controls

located by rear seats

Manual operation

►  To open/close the window, press/pull the

switch without passing the point of resistance;

the window stops as soon as the switch is

released.

Automatic operation

►  To open/close the window, press/pull the

switch past its resistance point: the window

opens/closes completely when the switch is

released.

Operating the switch again stops the movement

of the window.

Window controls remain operational for

approximately 45 seconds after switching

off the ignition or after locking the vehicle.

After that time, the controls are disabled.

To reactivate them, switch on the ignition or

unlock the vehicle.

Anti-pinch

If the window meets an obstacle while rising, it

stops and immediately partially lowers again.

Deactivating the rear

controls for the rear electric

windows

For your children's safety, press control

5



to deactivate the controls for the rear

electric windows, irrespective of their positions.

The red indicator lamp in the button comes

on and a confirmation message is displayed.

The lamp will remain lit until the controls are

reactivated.

The rear electric windows can still be controlled

using the driver's controls.

Reinitialising the electric

windows

After reconnecting the battery, or in the event

of abnormal window movement, the anti-pinch

function must be reinitialised.

The anti-pinch function is disabled during the

following sequence of operations.

For each window:

►  Lower the window fully, then raise it; it will

rise in steps of a few centimetres each time the

control is pressed. Repeat the operation until the

window is fully closed.

►  Continue to pull the control for at least one

second after the window reaches the closed

position.

If an electric window meets an obstacle

during operation, the movement of the

window must be reversed. To do this, press

the relevant control.

When the driver operates the passengers’

electric window controls, it is important to

ensure that nothing can prevent the window

from closing properly.

It is important to ensure that passengers use

the electric windows correctly.

Pay particular attention to children when

operating the windows.

Be aware of passengers and/or other persons

present when closing windows remotely using

the electronic key.

Do not put your head or arms through the

open windows when the vehicle is moving -

risk of serious injury!

Panoramic sunroof

The panoramic sunroof consists of a movable

glass panel that slides over the roof and a blind

42

Access

that can be opened independently. Opening the

sunroof automatically opens the blind.

►  To operate the panoramic sunroof or the

blind, use the buttons in the roof console.





A.

Sunroof blind control

B.

Sunroof control

The sunroof or blind can be operated when the

ignition is turned on (if the battery is charged

enough), with the engine running, in STOP mode

of Stop & Start, and up to 45 seconds after

turning off the ignition or after locking the vehicle.

Precautions

Do not put your head or arms through the

sunroof while the vehicle is moving - risk

of serious injury!

Ensure that any luggage or accessories

carried on the roof bars do not interfere

with the movement of the sunroof.

Do not place heavy loads on the movable

glass panel of the sunroof.

If the sunroof is wet, following a rain

shower or washing the vehicle, wait until

it is completely dry before operating it.

Do not operate the sunroof if it is covered by

snow or ice - risk of damage!

Use only plastic scrapers to remove snow or

ice from the sunroof.

Regularly check the condition of the

sunroof seals (e.g. presence of dust,

dead leaves).

If using a car wash, check first that the roof is

correctly closed and keep the high-pressure

jet at least 30 centimetres from the seals.

Never leave the vehicle with the sunroof

open.

Operation

When opening the sunroof fully, the movable

glass moves to a partially open position, then

slides over the roof. Any intermediate position is

possible.

Depending on the speed of the vehicle,

the partially open position may vary to

improve the acoustics.

Before operating the sunroof or blind

control buttons, ensure that no object or

person might prevent the movement.

Be particularly aware of children when

operating the sunroof or blind.

If something is trapped when operating the

sunroof or blind, you should reverse the

movement of the sunroof or blind by pressing

the control in question.

The driver must ensure that passengers use

the sunroof and blind correctly.

Anti-pinch system

If the sunroof or blind encounters an obstacle

when closing, the movement is automatically

reversed.

The roof anti-pinch system is designed to be

effective at speeds of up to 75 mph (120 km/h).

Opening/Closing

►  To open the sunroof or the blind, use the

part of the button located towards the rear of the

vehicle.

►  To close the sunroof or the blind, use the part

of the button located towards the front of the

vehicle.

Operation of buttons

►  Pressing a button beyond its point of

resistance directly opens or closes the sunroof

or blind fully.

►  Pressing the button again stops the current

movement.

43

Access

2

►  When holding a button (without going

beyond the point of resistance), the movement

of the sunroof or blind stops when this button is

released.

►  When the sunroof is closed: pressing once

without passing the point of resistance moves it

to a partially open position.

►  When the sunroof is partially open: pressing

once without passing the point of resistance

opens or closes it fully.

The sunroof and windows, then the blind,

can be closed by holding down the door

locking control. The manoeuvre stops as soon

as the locking control is released.

Closing of the blind is limited by the

position of the sunroof: the blind cannot

go further than the front of the movable glass.

During simultaneous movements of the

sunroof and blind, the blind automatically

stops or resumes movement depending on

the position of the sunroof.

Reinitialisation

Following reconnection of the battery or in the

event of a fault or jerky movement of the sunroof

or blind, reinitialisation is required.

►  Check that nothing is interfering with the

sunroof or blind and that the seals are clean.

►  With the ignition on, fully close the sunroof

and blind.

►  Press and hold the front part of button

B

, until

the sunroof and blind move slightly, then hold for

a further 1 second before releasing.

►  Wait 2 seconds and then press and hold the

front part of button

B

. The blind and the sunroof

will open and close, one after the other. When

both are completely closed again, hold for a

further 2 seconds and release.

If there is an operating fault, restart the

whole procedure.

44

Ease of use and comfort

Correct driving position

For safety reasons, adjustments must

only be made when the vehicle is

stationary.

Before taking to the road and to make the most

of the ergonomic layout of the instruments and

controls, carry out these adjustments in the

following order:

–  head restraint height.

–  seat backrest angle.

–  seat cushion height.

–  longitudinal seat position.

–  steering wheel height and reach.

–  rear view mirror and door mirrors.





Once these adjustments have been

made, check that the instrument panel

can be viewed correctly from your driving

position.

Front head restraints

Adjusting the height

The adjustment is correct when the

upper edge of the head restraint is level

with the top of the head.

‘Two-way’ adjustment model





Upwards:

►  pull the head restraint up to the desired

position; the head restraint can be felt to click

into position.

Downwards:

►  press lug

A

 and push the head restraint down

to the desired position.

‘Four-way’ adjustment model





Upwards:

►  pull the head restraint up to the desired

position; the head restraint can be felt to click

into position.

Downwards:

►  press and hold button

B

 and push the head

restraint down to the desired position.

Adjusting the angle

“Four-way” adjustment model





►  press and hold button

B

 and push the lower

part of the head restraint forwards or backwards.

45

Ease of use and comfort

3

Removing a head restraint

►  Pull the head restraint fully up.

►  Press the lug(s)

A

 (depending on version) to

release the head restraint and raise it fully.

►  Stow the head restraint securely.

Refitting a head restraint

►  Insert the head restraint rods into the guides

in the corresponding seat backrest.

►  Push the head restraint fully down.

►  Press the lug(s)

A

 (depending on version) to

release the head restraint and push it down.

►  Adjust the height of the head restraint.

Never drive with the head restraints

removed; they should be in place and

adjusted for the occupant of the seat.

Front seats

Before moving the seat backwards,

ensure that there is no person or object

that might prevent the full travel of the seat.

There is a risk of trapping or pinching

passengers if present in the rear seats or of

jamming the seat if large objects are placed

on the floor behind the seat.

Manually-adjusted seats

Longitudinal





►  Raise the control bar and slide the seat

forwards or backwards.

►  Release the control bar to lock the seat in

position on one of the notches.

Backrest angle





►  Turn the knob to obtain the desired angle.

Lumbar

(driver only)





►  Turn the knob to obtain the desired level of

lumbar support.

Height





►  Pull the control upwards to raise or push it

downwards to lower, until you obtain the position

required.

Electrically-adjustable seats

To avoid draining the battery, carry out

these adjustments with the engine

running.

46

Ease of use and comfort

Longitudinal





►  Push the control forwards or backwards to

slide the seat.

Backrest angle





►  Tilt the control forwards or rearwards.

Lumbar





The control allows independent adjustment of

the depth and vertical position of the lumbar

support.

►  Press and hold the front or rear of the

control to increase or reduce the lumbar

support.

►  Press and hold the top or bottom of the

control to raise or lower the lumbar support area.

Cushion height and angle





►  Tilt the rear of the control upwards or

downwards to obtain the required height.

►  Tilt the front of the control upwards or

downwards to obtain the required angle.

Comfort functions

Memorising driving positions





Associated with the electrically-adjusted driver’s

seat, this function allows two driving positions

to be memorised, to make these adjustments

easier if there are frequent driver changes.

It records the electric adjustments made to the

seat and door mirrors.





Using buttons 1/2/M

►  Enter the vehicle and switch the ignition on.

►  Adjust your seat and the door mirrors.

►  Press button

M

, then press button

1

 or

2



within 4 seconds.

An audible signal confirms the memorisation.

Memorising a new position cancels the previous

position.

Recalling a stored position

While the seat is moving, take care that

no person or object hinders the

automatic movement of the seat.

With the ignition on or engine running

►  Press button

1

 or

2

 to recall the

corresponding position.

An audible signal sounds when adjustment is

complete.

You can interrupt the current movement by

pressing button

M

,

1

 or

2

 or by using one of the

seat adjustment controls.

47

Ease of use and comfort

3

A stored position cannot be recalled while

driving.

The recalling of stored positions is deactivated

45 seconds after switching off the ignition.

Heated seats









The function is active only with the engine

running and when the outside temperature is

below 20°C.

►  Press the button corresponding to the seat.

►  Each press changes the heating level; the

corresponding number of indicator lamps come

on.

►  To switch off the heating, press the button

until all of the indicator lamps are off.

The system status is memorised when the

ignition is switched off.

Do not use the function when the seat

is not occupied.

Reduce the heating intensity as soon as

possible.

When the seat and passenger compartment

have reached a satisfactory temperature,

switch the function off; reducing electrical

consumption in turn decreases energy

consumption.

Prolonged use of heated seats is not

recommended for people with sensitive

skin.

There is a risk of burns for people whose

perception of heat is impaired (e.g. illness,

taking medication).

To keep the heated pad intact and to prevent

a short circuit:

–  Do not place heavy or sharp objects on the

seat.

–  Do not kneel or stand on the seat.

–  Do not spill liquids onto the seat.

–  Never use the heating function if the seat

is damp.

Multipoint massage

System with a choice of type of massage and

adjustment of its intensity.

This system operates with the engine running, as

well as in STOP mode of the Stop & Start.

The massage settings are adjusted via the touch

screen.

The function is activated using the button on the

front seat.

►  Press this button; its indicator lamp

comes on.

The function is activated immediately using the

last settings memorised and the settings page is

displayed on the touch screen.

If the settings suit you and you make no

changes, the display returns to its original state.

To modify the settings:

►  Select another type of massage from the five

available.

►  Select a massage intensity from the three

preset levels: "

1

" (Low), "

2

" (Normal) or "

3

"

(High).

The changes are applied immediately.

Once activated, the system starts a one-hour

massage cycle, made up of sequences of 6

minutes of massage followed by 4 minutes of

rest.

The system automatically stops at the end of the

cycle; the button's indicator lamp goes off.

Steering wheel

adjustment





►  When stationary, pull control

A

 to release the

steering wheel.

48

Ease of use and comfort

►  Adjust the height and reach to suit your

driving position.

►  Push the control to lock the steering wheel.

For safety reasons, these adjustments

must only be carried out with the vehicle

stationary.

Mirrors

Door mirrors

Adjustment





►  Move control

A

 to the right or to the left to

select the corresponding mirror.

►  Move control

B

 in any of the four directions

to adjust.

►  Return control

A

 to its central position.

As a safety measure, the mirrors should

be adjusted to reduce the "blind spots".

The objects that you see in the mirrors are

in fact closer than they appear. Take this

into account in order to correctly judge the

distance of vehicles approaching from behind.

Manual folding





The mirrors can be folded manually (parking

obstruction, narrow garage, etc.).

►  Turn the mirror towards the vehicle.

Electric folding

Depending on equipment, the mirrors can be

folded electrically, when the vehicle is parked.

►  From the inside, with the

ignition on, place control

A

 in the

central position.

►  Pull control

A

 backwards.

►  Lock the vehicle from the outside.

Electric unfolding

►  From outside: unlock the vehicle.

►  From inside: with the ignition on, place

control

A

 in the central position and then pull it

rearwards.

The remote-controlled automatic door

mirror folding/unfolding function is

configured via the

Driving

 /

Vehicle

 touch

screen menu.

Automatic tilting in reverse gear





Depending on version, this function allows to

automatically tilt the mirrors downwards to assist

with parking manoeuvres in reverse gear.

With the engine running, on engaging reverse

gear, the mirror glasses tilt downwards.

They return to their initial position:

–  A few seconds after coming out of reverse

gear.

–  Once the vehicle speed exceeds 6 mph

(10 km/h).

–  When the engine is switched off.

This function is set via the

Driving/

Vehicle

 touch screen menu.

Demisting/Defrosting

If the vehicle is so equipped, demisting/

defrosting of the heated door mirrors is

performed when the heated rear screen is

switched on.

For more information on

Rear screen

demisting/defrosting

, refer to the

corresponding section.

Interior rear view mirror

Equipped with an anti-dazzle system, which

darkens the mirror glass and reduces the

49

Ease of use and comfort

3

nuisance to the driver caused by the sun,

headlamps of other vehicles, etc.

Manual model

Day/night position





►  Pull the lever to change to the anti-dazzle

"night" position.

►  Push the lever to change to the normal "day"

position.

Adjustment

►  Adjust the mirror to the normal "day" position.

Automatic "electrochrome" models









The electrochrome system uses a sensor to

detect the level of exterior brightness, as well as

that coming from the rear of the vehicle, in order

to automatically and gradually switch between

day and night usage.

To ensure optimum visibility while

manoeuvring, the mirror automatically

brightens when reverse gear is engaged.

The system is deactivated if the load in the

boot exceeds the height of the load space

cover or if the load space cover has items

placed on it.

Rear seats

The 3 seats of the 2

nd

 row are independent and

of the same width. Their backrests are adjustable

to adapt the boot load space.

Rear head restraints





They have two positions:

– A

high position

, for when the seat is in use:

►  Pull the head restraint fully up.

– A

low position

, for stowing, when the seat is

not in use:

►  Press the lug

A

 to release the head

restraint and push it down.

The rear head restraints can be removed.

Removing a head restraint

►  Release the backrest.

►  Tilt the backrest slightly forwards.

►  Pull the head restraint fully up.

►  Press the lug

A

 to release the head restraint

and remove it completely.

Refitting a head restraint

►  Insert the head restraint rods into the guides

in the corresponding backrest.

►  Push the head restraint fully down.

►  Press the lug

A

 to release the head restraint

and push it down.

Never drive with passengers seated at

the rear when the head restraints are
