18

Dashboard instruments

Black/white warning lamps
Hill Assist Descent Control

Fixed.

(grey)

The function has been activated, but is currently

paused because the speed is too high.

Reduce the vehicle speed to below 19 mph

(30 km/h).

Indicators

Service indicator

The servicing information is expressed in terms

of distance (miles or kilometres) and time

(months or days).

The alert is given at whichever of these two

terms is reached first.

The servicing information is displayed in the

instrument panel. Depending on the version of

the vehicle:

–  The distance recorder display line indicates

the distance remaining before the next service

is due, or the distance travelled since it was due

preceded by the "-" sign.

–  An alert message indicates the distance

remaining, as well as the period before the next

service is due or how long it is overdue.

The value indicated is calculated

according to the distance covered and

the time elapsed since the last service.

The alert may also be triggered close to a

due date.

Service spanner

On temporarily when the ignition is

switched on.

Between 620 and 1,860 miles (1,000 and 3,000

km) remain before the next service is due.

Fixed, when the ignition is switched on.

The next service is due in less than 620

miles (1,000 km).

Have your vehicle serviced very soon.

Service spanner flashing

Flashing then fixed, when the

ignition is switched on.

(With BlueHDi Diesel engines, combined with the

Service warning lamp.)

The servicing interval has been exceeded.

Have your vehicle serviced as soon as possible.

Resetting the service indicator

The service indicator must be reset after each

service.

►  Switch the ignition off.









►  Press and hold this button.

►  Switch on the ignition; the distance recorder

display begins a countdown.

►  Release the button when

=0

 is displayed; the

spanner disappears.

If you have to disconnect the battery

following this operation, lock the vehicle

and wait at least 5 minutes for the reset to be

registered.

Reminder of the servicing information

You can access the servicing information at any

time via the instrument panel.





►  Press this button to temporarily display the

servicing information.

19

Dashboard instruments

1

Engine oil level indicator

(Depending on version)

On versions fitted with an electric gauge, the

engine oil level status is displayed on the

instrument panel for a few seconds when

the ignition is switched on, after the servicing

information, in the form of messages.

The level read will only be correct if the

vehicle is on level ground and the engine

has been off for more than 30 minutes.

Low oil level

This is indicated by a message prompting you to

top up the level, accompanied by the lighting of

the Service warning lamp and an audible signal.

If a low oil level is confirmed by a check using

the dipstick, the level must be topped up to avoid

damage to the engine.

For more information on

Checking levels

, refer

to the corresponding section.

Oil gauge malfunction

This is indicated by the message "

Oil level

measurement invalid

" on the instrument panel.

Contact a CITROËN dealer or a qualified

workshop.

In the event of a malfunction of the

electric gauge, the oil level is no longer

monitored.

If the system is faulty, you must check the

engine oil level using the manual dipstick

located in the engine compartment.

For more information on

Checking levels

,

refer to the corresponding section.

Coolant temperature

indicator





With the engine running:

–  In zone

A

, the temperature is correct.

–  In zone

B

, the temperature is too high.

The associated warning lamp and the

STOP

 warning lamp light up in red on the

instrument panel, accompanied by the display of

a message and an audible signal.

You must stop the vehicle as soon as it is

safe to do so.

Wait a few minutes before switching off the

engine.

After switching off the ignition, carefully

open the bonnet and check the coolant

level.

For more information on

Checking

levels

, refer to the corresponding

section.

AdBlue

®

 range indicators

(BlueHDi)

The Diesel BlueHDi engines are equipped with

a system that associates the SCR (Selective

Catalytic Reduction) emissions control system

and the Diesel particle filter (DPF) for the

treatment of exhaust gases. They cannot

function without AdBlue

®

 fluid.

The engine starting prevention system

required by regulations is activated

automatically once the AdBlue

®

 tank is empty.

It is then no longer possible to start the

engine until the minimum level of AdBlue

®

 has

been topped up.

Manual display of the range

While the driving range is greater than

1,500 miles (2,400 km), it is not displayed

automatically.

20

Dashboard instruments









►  Press this button to temporarily display the

driving range.

Actions required related to a lack of

AdBlue

®

The following warning lamps light up when the

quantity of AdBlue

®

 is lower than the reserve

level corresponding to a range of 1,500 miles

(2,400 km).

Together with the warning lamps, messages

regularly remind you of the need to top up to

avoid engine starting being prevented. Refer to

the

Warning and indicator lamps

 section for

details of the messages displayed.

For more information on

AdBlue

®



(BlueHDi engines)

, and in particular on

topping up, refer to the corresponding section.

Warning/

indicator

lamps on

Action

Remaining

range





Top up.

Between

1,500 miles

and 500

miles (2,400

km and 800

km)





Top up as

soon as

possible.

Between

500 miles

and 62

miles (800

km and

100 km)





A top-up is

vital

, there is

a risk that the

engine will

be prevented

from starting.

Between 62

miles and 0

miles (100

km and 0

km)





To be able

to restart the

engine, add at

least 10 litres

of AdBlue

®

 to

the tank.

0 miles (km)

Taking into account of top-up

Top-up detection may not be

instantaneous after addition. It may take a few

minutes of driving before the top-up detection

is effective.

Malfunction of the SCR emissions

control system

Malfunction detection





If a malfunction is detected,

these warning lamps come

on, accompanied by an

audible signal and the

display of an "

Emissions

control fault

" message.

The alert is triggered while driving when the

fault is detected for the first time, and thereafter

when switching on the ignition for subsequent

journeys, for as long as the cause of the fault

persists.

If the fault is temporary, the alert

disappears during the next journey, after

self-diagnostic checks of the SCR emissions

control system.

Malfunction confirmed during the

permitted driving phase (between 685

miles and 0 miles (1,100 km and 0 km))

If the fault indication is still displayed

permanently after 31 miles (50 km) of driving, the

fault in the SCR system is confirmed.

The AdBlue warning lamp flashes and

a message is displayed ("

Emissions

21

Dashboard instruments

1

control fault: starting prevented in X miles

(kms)

"), indicating the driving range in miles or

kilometres.

While driving, the message is displayed every 30

seconds. The alert is repeated when switching

on the ignition.

You can continue driving for up to 685 miles

(1,100 km) before the

engine starting

prevention

 system is triggered.

Have the system checked by a

CITROËN dealer or a qualified workshop

as soon as possible.

Starting prevented

Every time the ignition is switched on, the

message "

Emissions control fault: Starting

prevented

" is displayed.

To restart the engine

Contact a CITROËN dealer or a qualified

workshop.

Power indicator

(Rechargeable hybrid)

The power indicator shows in real time the power

demanded from the vehicle.

There are 3 zones:





POWER High power demand, using the

combined capabilities of the petrol

engine and the electric motor.

The slider is located in this zone

during more dynamic driving phases

when high levels of performance are

being demanded.

ECO

Optimal use of energy (internal

combustion or electric).

The slider is located in this zone

when driving under electric power

and when optimal use is being made

of the petrol engine, both accessible

by adopting a suitable driving style.

A symbol indicates the threshold at

which the petrol engine will restart.

The driver can therefore moderate

their acceleration to remain in electric

driving mode.

CHARGE Energy recovery for partly

recharging the traction battery.

The slider is located in this zone

during deceleration: taking your foot

off the accelerator pedal or braking.

Charge level indicator

(Rechargeable hybrid)





The charge level of the traction battery and

the remaining range in electric driving mode

are permanently displayed when the vehicle is

switched on.

The range displayed depends on the use

of the vehicle (type of driving and speed),

the outside temperature and the activated

comfort equipment.

Distance recorders





The total and trip distances are displayed for

thirty seconds when the ignition is switched off,

22

Dashboard instruments

when the driver's door is opened and when the

vehicle is locked or unlocked.

When travelling abroad, you may need to

change the units of distance and speed:

The display of distance and speed must be

expressed in the official unit of the country

(km or miles). The change of units is done via

the screen configuration menu, with the

vehicle stationary.

Total distance recorder

It measures the total distance travelled by the

vehicle since its first registration.

Trip distance recorder

This measures the distance travelled since it was

last reset by the driver.









Resetting the trip recorder

►  With the ignition on, press the button until

zeros appear.

Manual test on the

instrument panel

This function allows you, at any time, to check

certain indicators and to display the alerts log.









►  With the engine running, briefly press this

button.

The following information is displayed on the

instrument panel:

–  Engine oil level.

–  Next service due.

–  Driving range associated with the AdBlue

®

 and

the SCR system (BlueHDi Diesel).

–  Tyre pressure check.

–  Current alerts.

This information is also displayed

automatically every time the ignition is

switched on.

Lighting dimmer

This system allows the brightness of the

instruments and controls to be adjusted to suit

the ambient light level.

With buttons









With the lamps on, press button

A

 to increase

the brightness of the lighting, or button

B

 to

decrease it.

Release the button when the desired brightness

is reached.

With CITROËN Connect

Radio

►  Press this button to select the

Settings

 menu.

►  Select "

Brightness

".

►  Adjust the brightness by pressing the

arrows or moving the slider.

The settings are applied immediately.

►  Press outside the settings window to exit.

You can also switch off the screen:

23

Dashboard instruments

1

►  Press this button to select the

Settings

 menu.

►  Select "

Dark

".

The screen goes off completely.

►  Press the screen again (anywhere on its

surface) to turn it on.

With CITROËN Connect Nav

With the lamps switched on:

►  Press this button to select the

Settings

 menu.

►  Select "

OPTIONS

".

►  Select "

Screen configuration

".

►  Select the "

Brightness

” tab.

►  Adjust the instrument panel and

screen brightness by using the arrows or

moving the slider.

►  Press this button to save and exit.



You can also switch off the screen:

►  Press this button to select the

Settings

 menu.

►  Select "

Turn off screen

".

The screen goes off completely.

►  Press the screen again (anywhere on its

surface) to turn it on.

Trip computer

Displays information related to the current trip

(range, fuel consumption, average speed, etc.).

Data displayed on the

instrument panel













With instrument panels with dials

The display of trip computer data is selected by

pressing the end of the wiper control stalk or by

rotating the thumbwheel located on the left of the

steering wheel.

With digital instrument panel

Trip computer data is displayed permanently

when the "DRIVING" or "PERSONAL" display

mode is selected, depending on version.

In all other display modes, pressing the end of

the wiper control stalk will cause this data to

appear temporarily in a specific window.

Display of the different tabs

►  Pressing the button located on the end of the

wiper control stalk displays the following tabs in

turn:

–  Current information:

•  Total range (Petrol or Diesel).

•  Current consumption (Petrol or Diesel).

•  Stop & Start time counter (Petrol or Diesel).

•  Percentage of the current journey travelled

in all-electric driving mode (Rechargeable

hybrid).

–  Trips "

1

" then "

2

":

•  Average speed.

•  Average fuel consumption.

•  Distance travelled.

Trip reset

►  When

 the desired trip is displayed,

press the button on the end of the wiper

control stalk for more than 2 seconds.

Trips "

1

" and "

2

" are independent and are used

in the same way.

Definitions

Range

(miles or km)

Distance that can still be travelled with the

fuel remaining in the tank (based on the

24

Dashboard instruments

average fuel consumption over the last few miles

(kilometres) travelled).

This value may vary following a change in driving

style or terrain, leading to a significant change in

current fuel consumption.

When the range falls below 19 miles (30 km),

dashes are displayed.

After filling with at least 5 litres of fuel, the range

is recalculated and is displayed if it exceeds 62

miles (100 km).

Dashes appearing permanently in place of

numbers while driving indicates a malfunction.

Contact a CITROËN dealer or a qualified

workshop.

Current consumption

(mpg or l/100 km or km/l)

Calculated during the last few seconds.

This function is only displayed at speeds above

19 mph (30 km/h).

Average consumption

(mpg or l/100 km or km/l)

Calculated since the last trip computer

reset.

Average speed

(mph or km/h)

Calculated since the last trip computer

reset.

Distance travelled

(miles or km)

Calculated since the last trip computer

reset.

Stop & Start time counter

(minutes/seconds or hours/minutes)

If your vehicle is fitted with the Stop & Start

function, a time counter calculates the time spent

in STOP mode during a journey.

The time counter is reset each time the ignition is

switched on.

Touch screen

This system gives access to the following

elements:

–  Permanent display of the time and outside

temperature (a blue warning lamp appears if

there is a risk of ice).

–  Heating/air conditioning system controls.

–  Vehicle functions and equipment setting

menus.

–  Audio system and telephone controls and

display of related information.

–  Display of visual manoeuvring aid functions

(visual parking sensor information, Park Assist,

etc.).

–  Internet services and display of related

information.

–  Front seat massage mode and intensity

settings (depending on version).

–  Navigation system controls and

display of related information (depending on

version).

For safety reasons, always stop the

vehicle before performing operations

that require sustained attention.

Some functions are not accessible while

driving.

Principles

►  Use

the buttons arranged below the touch

screen for access to the menus, then press the

virtual buttons on the touch screen.

Some menus may display across two pages:

press the "

OPTIONS

" button to access the

second page.

After a few moments with no action on

the second page, the first page is

displayed automatically.

To deactivate/activate a function, select "

OFF

"

or "

ON

".

Settings for a function

Access to additional information on the

function

Confirm



Return to the previous page or confirm



25

Dashboard instruments

1

Menus





Press

the touch screen with three fingers

to show all of the menu buttons.

For more information about the menus,

refer to the sections describing the audio

and telematics systems.

Radio/Media



Climate

Settings for temperature, air flow, etc.

For more information on

Manual air

conditioning

 and

Dual-zone automatic air

conditioning

, refer to the corresponding

sections.

Navigation

 (Depending on equipment)

Driving or Vehicle

 (Depending on

equipment)

Activation, deactivation and settings for certain

functions.

The functions are organised in 2 tabs: "

Driving

functions

" and "

Vehicle settings

".

Telephone



Applications

Display of available connected services

and access to the

Eco-coaching

 function.

Settings

Main settings for the audio system, touch

screen and digital instrument panel.

Energy

 (Depending on equipment)

Access to the rechargeable hybrid system

features (energy flow, consumption statistics,

deferred charging, eSave function).

Energy menu

This menu is only available with CITROËN

Connect Nav.

Flow

The page shows the operation of the

rechargeable hybrid system in real time.

1.

Active driving mode

2.

Petrol engine

3.

Electric motor

4.

Traction battery charge level

The energy flows have a colour for each type of

driving:

–  Blue: 100% electrical energy.

–  Orange: energy from the petrol engine.

–  Green: energy recovery.

Statistics

This page shows electrical energy and fuel

consumption statistics.





1.

 Average electrical consumption for the current

trip (kWh/100 km) and historical values:

–  Blue bar chart: directly consumed energy

supplied by the traction battery.

–  Green bar chart: energy recovered during

deceleration and braking, used to recharge the

battery.

2.

 Average fuel consumption for the current trip

(kWh/100 km) and historical values (orange bar

chart).

►  You can change the displayed time scale by

pressing the

-

 or

+

 buttons.

26

Dashboard instruments

A current trip is any trip of more than 20

minutes without switching off the ignition.

Charging

This page allows you to programme deferred

charging.

For more information on

Charging the traction

battery (Rechargeable hybrid)

, refer to the

corresponding section.

eSave

The

eSave

 function makes it possible to reserve

all or part of the electrical energy in the traction

battery for later use during a journey (e.g. driving

in an urban area or in an area reserved for

electric vehicles).

►  Select the electric range to be reserved (

10

km

,

20 km

 or the full range

MAX

) then activate

the function by pressing

ON

.

Activation of the function is confirmed by

the lighting of this indicator lamp on the

instrument panel and the indication of the energy

reserve in miles or kms.

►  To use the energy reserve, choose the

Electric

 driving mode in the mode selector.

If the requested range exceeds the

available range (not recommended), the

internal combustion engine starts to recharge

the traction battery up to the requested

threshold. This leads to excessive fuel

consumption.

Information banner(s)

Certain information is displayed permanently in

the touch screen banner(s).

–  Time and outside temperature (a blue warning

lamp appears if there is a risk of ice).

–  Reminder of the air conditioning information,

and direct access to the corresponding menu.

–  Reminder of the information in the

Radio Media

 and

Telephone

 menus.

–  Notifications.

–  Access to the

Settings

 for the touch screen

and the digital instrument panel (date/time,

languages, units, etc.).

Remotely operable

additional functions

(Rechargeable hybrid)

(Depending on country of sale)





The following functions are

available from the

MyCitroën

App

 application, which is

accessible from a smartphone:

–  Managing the traction battery charging

(deferred charging).

–  Managing the temperature pre-conditioning.

–  Viewing the state of charge and range of the

vehicle.

Installation procedure

►  Download the

MyCitroën App

 application

from the appropriate online store for your

smartphone.

►  Create an account.

►  Enter the vehicle identification number

(available on the vehicle registration certificate).

For more information on

Identification

markings

, refer to the corresponding section.

Network coverage

In order to be able to use the various

remotely operable features, ensure that your

vehicle is located in an area covered by the

mobile network.

A lack of network coverage may prevent

communication with the vehicle (for example,

if it is in an underground car park). In such

cases, the application will display a message

indicating that the connection with the vehicle

could not be established.

27

Access

2

Electronic key with

remote control function

and built-in key

Remote control function





The remote control can be used to perform

the following remote functions (depending on

version):

–  Unlocking/Locking/Deadlocking the vehicle.

–  Unlocking - Opening the boot.

–  Remote operation of lighting.

–  Activating/Deactivating the alarm.

–  Locating the vehicle.

–  Closing the windows.

–  Closing the sunroof.

–  Activating the vehicle’s electronic immobiliser.

Back-up procedures allow the vehicle to be

locked/unlocked in the event of a failure of the

remote control, the central locking, the battery,

etc. For more information on the

Back-up

procedures

, refer to the corresponding section.

Built-in key

Using the remote control built-in key, you can

perform the following operations (depending on

version):

–  Unlocking/Locking/Deadlocking the vehicle.

–  Activation/Deactivation of the manual child

lock.

–  Activation/Deactivation of the front passenger

airbag.

–  Back-up Unlocking/Locking of the doors.

–  Switching on the ignition and starting/switching

off the engine.

Without Keyless Entry and Start





►  To unfold or fold the key, press the button.

With Keyless Entry and Start





►  To eject the key or put it back in place, pull

and hold the button.

Once the built-in key is ejected, always

keep it with you to be able to carry out

the corresponding back-up procedures.

Unlocking the vehicle





Selective unlocking (driver’s door, boot) is

configured in the

Driving

/

Vehicle

 touch

screen menu.

Complete unlocking

►  Press the unlocking button.

Selective unlocking

Driver's door

►  Press the unlocking button.

The driver's door and the fuel filler flap are

unlocked (Petrol or Diesel).

The driver's door is unlocked (Rechargeable

hybrid).

►  Press it

again

 to unlock the other doors and

the boot.

The charging nozzle can be unplugged on the

second press.

Complete or selective unlocking, and alarm

deactivation (depending on version), is confirmed

by the flashing of the direction indicators.

Depending on version, the door mirrors unfold.

28

Access

Selective unlocking and opening of

the tailgate

By default, selective unlocking of the tailgate

is deactivated and its motorised operation is

activated.

►  Press and hold this button to unlock

the boot and, depending on version,

trigger the motorised opening of the tailgate.

When selective unlocking of the tailgate is

activated, the doors and the fuel filler flap remain

locked.

If selective unlocking of the tailgate is

deactivated, pressing the button unlocks the

whole vehicle.

If motorised operation of the tailgate is

deactivated, pressing the button partially

opens the tailgate.

To lock the vehicle, it is necessary to close

the tailgate again.

Locking the vehicle





Normal locking

►  Press the locking button.

The locking, and the activation of the alarm

depending on version, is confirmed by the

lighting of the direction indicators.

Depending on version, the door mirrors fold.

An access (door or boot) that is not

properly closed prevents locking of the

vehicle. However, if the vehicle is fitted with

an alarm, it will be activated after 45 seconds.

If the vehicle is unlocked but the doors or boot

are not subsequently opened, the vehicle

will automatically lock itself again after about

30 seconds. If the vehicle is fitted with an

alarm, it will be reactivated automatically.

Deadlocking





Deadlocking renders the interior door

controls inoperative. It also disables the

central locking button.

The horn remains operational.

Never leave anyone inside the vehicle

when it is deadlocked.

►  Press the locking button.

►  Press the locking button again within 5

seconds to deadlock the vehicle (confirmed by

the temporary lighting of the direction indicators).

Closing the windows and sunroof

Maintaining pressure on the locking

button for more than 3 seconds allows the

windows and, depending on version, the sunroof

to be closed to the desired position.

This operation also closes the sunroof blind.

Ensure that no person or object could

prevent the correct closing of the

windows and sunroof.

If, on versions with alarm, you want to

leave the windows and/or sunroof partially

open, you must first deactivate the interior

volumetric alarm protection.

For more information on the

Alarm

, refer to

the corresponding section.

Locating your vehicle

This function allows you to identify your vehicle

from a distance, particularly in poor light. Your

vehicle must be locked.

►  Press this button. The courtesy lamps

will come on and the direction indicators

will flash for a few seconds.

Remote lighting of the

lamps

Availability of this function depends on version.

►  Press this button. The sidelamps,

dipped beam headlamps, number plate

lamps and door mirror spotlamps come on for 30

seconds.

Pressing again before the end of the timed

period switches off the lamps immediately.

29

Access

2

Advice

Remote control

The remote control is a sensitive, high-

frequency device; avoid handling it in your

pocket, due to the risk of unintentionally

unlocking the vehicle.

Avoid pressing the remote control buttons

while out of range of the vehicle, due to

the risk of rendering the remote control

inoperative. It would then be necessary to

reset it.

The remote control does not work when the

key is in the ignition switch, even when the

ignition is switched off.

Anti-theft protection

Do not modify the electronic vehicle

immobiliser, as this might result in

malfunctions.

For vehicles with a key ignition switch,

remember to remove the key and turn the

steering wheel to engage the steering lock.

Locking the vehicle

Driving with the doors locked could make

it more difficult for the emergency services

to enter the passenger compartment in an

emergency.

As a safety precaution, remove the key from

the ignition or take the electronic key with you

when leaving the vehicle, even for a short

time.

Purchasing a second-hand vehicle

Have the key codes memorised by a

CITROËN dealer, to ensure that the keys in

your possession are the only ones able to

start the vehicle.

Keyless Entry and Start





This system allows the unlocking, locking

and starting of the vehicle, while carrying the

electronic key on your person in the recognition

zone

A

.

Unlocking the vehicle





Selective unlocking (driver’s door, boot) is

configured in the

Driving

/

Vehicle

 touch

screen menu.

Selective unlocking is deactivated by default.

Complete unlocking

►  Pass your hand behind the handle of one

of the front doors or press the tailgate opening

control.

If the motorised tailgate opening control is

activated, this action triggers its automatic

opening.

Opening the windows

Depending on version, keeping your hand

behind the door handle or maintaining the

press on the tailgate opening control allows the

windows to be opened to the desired position.

30

Access

Selective unlocking

Driver's door

►  Pass your hand behind the driver’s door

handle.

The driver's door and the fuel filler flap are

unlocked (Petrol or Diesel).

The driver's door is unlocked (Rechargeable

hybrid).

►  To unlock the vehicle completely, pass your

hand behind the handle of one of the passenger

doors with the electronic key close to the

passenger door, or press the tailgate opening

control with the electronic key close to the rear of

the vehicle.

Complete or selective unlocking, and

deactivation of the alarm depending on version,

is confirmed by the flashing of the direction

indicators.

Depending on version, the door mirrors unfold.

Selective unlocking of the tailgate

►  Press the tailgate opening control to unlock

just the boot.

The doors remain locked.

If selective unlocking of the tailgate is

deactivated, pressing this control also

unlocks the doors.

Locking the vehicle

Normal locking





►  Press the handle on one of the front doors

(at the markings) or the locking control on the

tailgate.

It is not possible to lock the vehicle if one of the

electronic keys is left inside the vehicle.

Closing the windows and sunroof

Maintaining pressure on the door handle or

the tailgate control allows the windows and,

depending on version, the sunroof to be closed

to the desired position.

This operation also closes the sunroof blind.

Make sure that no item or person could

prevent the correct closing of the

windows and sunroof.

Pay particular attention to children when

operating windows.

The locking, and the activation of the alarm

depending on version, is confirmed by the

temporary lighting of the direction indicators.

Depending on version, the door mirrors fold.

Accumulations (water, dust, grime, salt,

etc.) on the inner surface of the door

handle may affect detection.

If cleaning the inner surface of the door

handle using a cloth does not restore

detection, contact a CITROËN dealer or a

qualified workshop.

A sudden splash of water (stream of water,

high pressure jet washer, etc.) may be

identified by the system as the desire to open

the vehicle.

Deadlocking





Deadlocking renders the interior door

controls inoperative. It also disables the

central locking button.

The horn remains operational.

Never leave anyone inside the vehicle when it

is deadlocked.

►  Press the handle on one of the front doors

(at the markings) or the locking control on the

tailgate to lock the vehicle.

►  Press it again within 5 seconds to deadlock

the vehicle.

31

Access

2

Advice

If one of the doors or the boot is still open

or if the electronic key for the Keyless

Entry and Start  system has been left inside

the vehicle, central locking will not take place.

However, if the vehicle is fitted with an alarm,

it will be activated after 45 seconds.

If the vehicle is unlocked but the doors or

boot are not subsequently opened, the

vehicle will automatically lock itself again after

about 30 seconds. If the vehicle is fitted with

an alarm, it will be reactivated automatically.

The automatic door mirror folding/

unfolding function is configured via the

touch screen's

Driving

/

Vehicle

 menu.

As a safety measure, never leave the

vehicle, even for a short time, without

taking the Keyless Entry and Start system’s

electronic key with you.

Be aware of the risk of theft of the vehicle if

the key is present in one of the defined areas

while the vehicle is unlocked.

To preserve the battery charge in the

electronic key and the vehicle's battery,

the "hands-free" functions are set to

hibernation mode after 21 days without use.

To restore these functions, press one of the

remote control buttons or start the engine with

the electronic key against the back-up reader.

For more information on starting with the

Keyless Entry and Start system, refer to the

corresponding section.

Electrical interference

The electronic key may not work if it is

close to an electronic device (e.g. mobile

telephone (switched on or on standby), laptop

computer, strong magnetic fields). If this

occurs, move the electronic key away from

the electronic device.

Central locking









Manual

►  Press this button to lock/unlock the vehicle

(doors, boot and fuel filler flap) from inside the

passenger compartment.

Central locking does not take place if any

of the doors are open.

When locking/deadlocking from the

outside

When the vehicle is locked or deadlocked

from the outside, the indicator lamp flashes

and the button is deactivated.

►  After normal locking, pull one of the

interior door controls to unlock the vehicle.

►  After deadlocking, you must use the

remote control, the "Keyless Entry and

Start" system or the built-in key to unlock the

vehicle.

Automatic (anti-intrusion

security)

The doors and boot lock automatically while

driving (speed above 6 mph (10 km/h)).

To deactivate/reactivate this function (activated

by default):

►  Press the button until an audible signal is

heard and a message appears on the screen.

Transporting long or voluminous

objects

Pressing the central locking button unlocks

the vehicle.

Above 6 mph (10 km/h), this unlocking is

temporary.

32

Access

Back-up procedures

Lost keys, remote control,

electronic key

Go to a CITROËN dealer with the vehicle's

registration certificate, your personal

identification documents and if possible, the label

bearing the key code.

The CITROËN dealer will be able to retrieve the

key code and the transponder code, enabling a

new key to be ordered.

Complete unlocking/locking

of the vehicle with the key

Use this procedure in the following situations:

–  Remote control battery discharged.

–  Remote control malfunction.

–  Vehicle battery discharged.

–  Vehicle in an area subject to strong

electromagnetic interference.

In the first case, change the remote control

battery.

In the second case, reinitialise the remote

control.

Refer to the corresponding sections.





►  Insert the key in the door lock.

►  Turn the key towards the front/rear to unlock/

lock the vehicle.

►  Turn the key towards the rear again within

5 seconds to deadlock the vehicle.

If the vehicle is fitted with an alarm, it will

not be activated when locking with the

key.

If the alarm is activated, the siren sounds

when the door is opened; switch on the

ignition to stop it.

Central locking not

functioning

Use these procedures in the following cases:

–  Central locking malfunction.

–  Battery disconnected or discharged.

In the event of a malfunction of the

central locking system, the battery must

be disconnected to ensure that the vehicle is

locked fully.

Front left-hand door

►  Insert the key into the lock and turn it towards

the rear of the vehicle to lock the door, or

towards the front to unlock it.

Passenger doors

Unlocking

►  Pull the interior door opening control.

Locking





►  Open the doors.

►  For the rear doors, check that the child lock

is not on.

Refer to the corresponding section.

►

Remove the black cap

, located on the edge

of the door, using the key.

►  Insert the key into the socket without forcing

it, then turn the latch towards the inside of the

door.

►  Remove the key and refit the black cap.

►  Close the doors and check from the outside

that the vehicle is locked.

Changing the battery

A message is displayed on the instrument panel

when the battery needs changing.

33

Access

2

Battery type: CR2032/3 volts.
Without Keyless Entry and Start





With Keyless Entry and Start





►  Unclip the cover by inserting a small

screwdriver in the slot and lift the cover.

►  Remove the flat battery from its housing.

►  Put the new battery in place, respecting the

polarity. Start by inserting it into the contacts

located in the corner, then clip the cover onto

the unit.

►  Reinitialise the remote control.

For more information on

Reinitialising the

remote control

, refer to the corresponding

section.

Do not throw remote control batteries

away, as they contain metals that are

harmful to the environment. Take them to an

approved disposal point.

This equipment contains a button type

battery.

Do not swallow the battery. Risk of chemical

burns!

Swallowing the battery can cause serious

internal burning in only 2 hours and can be

fatal.

If batteries have been swallowed or inserted

into a part of the body, seek immediate

medical advice.

Keep new and used batteries out of the reach

of children.

If the battery compartment does not close

properly, stop using the product and keep it

out of the reach of children.

Risk of explosion if the battery is

replaced with an incorrect type!

Replace the battery with the same type.

Risk of explosion or leaking of

inflammable liquid or gas!

Do not use in/store in/place in an environment

where the temperature is extremely high or

where the pressure is extremely low due to

very high altitude.

Do not try to burn, crush or cut a used battery.

Reinitialising the remote

control

Following replacement of the battery or in

the event of a fault, it may be necessary to

reinitialise the remote control.

Without Keyless Entry and Start





►  Switch the ignition off.

►  Turn the key to position

2 (Ignition on)

.

►  Immediately press the closed padlock button

for a few seconds.
