Overview

Presentation

These illustrations and descriptions are intended

as a guide. The presence and location of some

elements vary depending on the version or trim

level.

Instruments and controls

Door mirrors

Electric windows

Bonnet release

Dashboard fuses

Horn

Driver front airbag

Instrument panel

Courtesy lamp

Warning lamps display for seat belts and

front passenger airbag

Sunroof and blind controls

Interior rear view mirror/Driving in

Electric

mode indicator LED

Emergency and assistance call buttons

Touch screen with CITROËN Connect Radio

or CITROËN Connect Nav

Switching the engine on/off

Gearbox

10.

Electric parking brake

11.

Wireless smartphone charger

12 V socket/USB sockets

12.

Choice of driving mode

Hill Assist Descent Control

Advanced Grip Control

13.

Glove box

Front passenger airbag deactivation switch

14.

Central control bar (lower and upper)

15.

Side control bar

Steering-mounted controls

External lighting controls/Direction indicators

Wiper controls/Screenwash/Trip computer

Automatic gearbox control paddles

Audio system controls

Select the instrument panel display mode

Voice commands

Decrease/Increase volume

Select previous/next media

Confirm a selection

Access the

Telephone

Manage calls

Select an audio source

Display the list of radio stations/audio tracks

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Overview

Controls for Cruise control/Speed limiter/

Adaptive cruise control

Side control bar

Headlamp beam height adjustment

Active lane departure warning system

Lane positioning assist

Heated windscreen

Alarm

Electric child lock

Opening the fuel filler flap

Central control bar (lower and upper)

Access the touch screen menus (CITROËN

Connect Radio or CITROËN Connect Nav)

Heated seats

Access the

Energy

Windscreen and front windows demisting

Manual recirculation of interior air

Rear screen demisting/de-icing

Ventilation off

Central locking

Stop & Start or temperature pre-conditioning

operation indicator lamp

10.

Hazard warning lamps

Rechargeable hybrid

system

Petrol engine

Electric motor

Traction battery

12 V accessories batteries

8-speed electric automatic gearbox (e-EAT8)

Charging flap

Fuel filler flap

Driving mode selector

Domestic charging cable

The

rechargeable hybrid

technology combines

two sources of energy: that of the petrol engine

and that of the electric motor, which drive the

front wheels (traction).

The engine and the motor can operate

alternately or simultaneously, according to the

driving mode selected and the driving conditions.

The electric power alone provides the mobility

of the vehicle in

Electric

mode, and in

Hybrid

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Overview

mode in case of moderate demand. It assists the

petrol engine during starting and acceleration

phases.

The electric power is supplied by a rechargeable

traction battery.

Labels

"Ease of use and comfort - Front

fittings -

Wireless smartphone charger" section:

"Lighting and visibility - Exterior lighting

control stalk" and "In the event of a

breakdown - Changing a bulb" sections:

"Safety - Child seats - Deactivating the front

passenger airbag" section

"Safety - ISOFIX mountings" section:

i-Size

TOP TETHER

"Driving - Electric parking brake" section

"Driving - Stop & Start" section:

"Practical information - Compatibility of

fuels" section:

"Practical information - Rechargeable hybrid

system" section:

"Practical information - Charging the traction

battery (Rechargeable hybrid)" section:

"Practical information - Bonnet" section:

"In the event of a breakdown - Temporary

puncture repair kit" section:

"In the event of a breakdown - Spare wheel"

section:

"In the event of a breakdown - 12 V battery/

Accessory batteries" section:

24V

12V

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Eco-driving

Eco-driving refers to a range of everyday

practices that allow the motorist to optimise

the vehicle's energy consumption (fuel and/or

electricity) and CO

emissions.

Optimise your use of the gearbox

With a manual gearbox, move off gently and

change up promptly. While accelerating, change

up early.

With an automatic gearbox, favour automatic

mode. Do not depress the accelerator pedal

heavily or suddenly.

The gear shift indicator prompts you to engage

the most suitable gear. Whenever this indication

is displayed on the instrument panel, follow it

straight away.

With an automatic gearbox, this indicator

appears only in manual mode.

Drive smoothly

Maintain a safe distance between vehicles, use

engine braking rather than the brake pedal and

press the accelerator gradually. These practices

help to save on energy consumption, reduce

emissions and decrease general traffic

noise.

Favour the use of the "Eco" driving mode.

With an EAT8 gearbox, with the gear selector in

mode

, and except in Sport mode, favour "free-

wheeling" by gradually lifting your foot fully off

the accelerator pedal in order to save fuel.

When the traffic is flowing smoothly, select the

cruise control.

Control the use of electrical equipment

Before moving off, if the passenger compartment

is too warm, ventilate it by opening the windows

and air vents before using the air conditioning.

At speeds above 31 mph (50 km/h), close the

windows and leave the air vents open.

Consider using equipment that can help keep

the temperature in the passenger compartment

down (e.g. sunroof blind, window blinds).

Unless automatically regulated, switch off the air

conditioning as soon as the desired temperature

has been reached.

Switch off the demisting and defrosting functions,

if they are not managed automatically.

Switch off the heated seat as soon as possible.

Adapt your use of the headlamps and/or

foglamps to the level of visibility, in accordance

with current legislation in the country in which

you are driving.

Avoid running the engine before moving off,

particularly in winter (other than in severe wintry

conditions: temperature below -23°C). The

vehicle will warm up much faster while driving.

As a passenger, avoid connecting your

multimedia devices (e.g. film, music, video

game) to help reduce the consumption of energy.

Disconnect all portable devices before leaving

the vehicle.

Limit the causes of excess consumption

Spread loads throughout the vehicle. Place the

heaviest items in the boot as close as possible to

the rear seats.

Limit the loads carried in the vehicle and

minimise wind resistance (e.g. roof bars, roof

rack, bicycle carrier, trailer). Preferably, use a

roof box.

Remove roof bars and roof racks after use.

At the end of winter, remove snow tyres and refit

summer tyres.

Avoid using Sport mode for too long, in order to

limit your energy consumption.

Comply with the servicing instructions

Check tyre pressures regularly, with the tyres

cold, referring to the label in the door aperture on

the driver's side.

Carry out this check in particular:

– before a long journey.

– at each change of season.

– after a long period out of use.

Do not forget the spare wheel and, where

applicable, the tyres on your trailer or caravan.

Have your vehicle serviced regularly (e.g. engine

oil, oil filter, air filter, passenger compartment

filter, etc.). Observe the schedule of operations in

the manufacturer's service schedule.

With a BlueHDi Diesel engine, if the SCR system

has a fault, your vehicle will emit pollution. Visit

a CITROËN dealer or a qualified workshop

as soon as possible to restore your vehicle's

nitrogen oxide emissions to legal levels.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Eco-driving

When filling the fuel tank, do not continue after

the third cut-out of the nozzle, to avoid overflow.

You will only see the fuel consumption of your

new vehicle settle down to a consistent average

after the first 1,900 miles (3,000 kilometres).

Optimising the driving range

(rechargeable hybrid vehicles)

Connect the vehicle as soon as possible.

Favour the

ECO

zone of the power indicator by

driving smoothly and at a steady speed.

Anticipate slowing down as much as possible

and, if possible, favour decelerations with

regenerative braking mode activated (power

indicator in the

CHARGE

zone).

With the vehicle connected, carry out

temperature pre-conditioning before setting off.

To optimise consumption during a journey:

► Programme a destination in the vehicle’s

GPS navigation system.

► Select the

Hybrid

driving mode.

► Make sure that the battery charge level is

close to maximum.

► Do not use the e-Save function while driving.

► Use the heating/air conditioning system

wisely.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Dashboard instruments

Driver information

Instrument panel

The instrument panel displays all the information

the driver needs about the status of the vehicle's

various systems.

This information appears in the form of warning

and indicator lamps and messages.

Depending on the vehicle's equipment, the

instrument panel may be either:

– Analogue dials with an LCD or matrix display.

– A fully digital display.

Instrument panel with

dials

Dials

Speedometer (mph or km/h)

Fuel gauge

Engine coolant temperature gauge

Rev counter (x 1,000 rpm)

Display screen

Control buttons

Resetting the service indicator

Alert log display

Reminder of servicing information or the

remaining range associated with AdBlue

and

the SCR system (miles or km)

Tyre pressure status information display

General lighting dimmer

Resetting the trip distance recorder

Display

Cruise control or speed limiter settings

Speed suggested by the Road signs

recognition

Gear shift indicator and/or selector position,

gear and Sport mode indicator with an

automatic gearbox

Display area: alert messages or state of

functions, trip computer, digital speedometer

(mph or km/h), range associated with the

AdBlue

and the SCR system (miles or km),

etc.

Service indicator, then total distance recorder

(miles or km)

These functions are displayed in turn when

the ignition is switched on

Trip distance recorder (miles or km)

Digital instrument panel

This instrument panel can be customised.

The content and availability of information

depends on the display mode selected and the

vehicle’s equipment.

Example in the "DIALS" display mode:

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Dashboard instruments

Fuel gauge

Remaining fuel range (km or miles)

(Rechargeable hybrid)

Trip computer

Rev counter (x 1,000 rpm) (Petrol or Diesel)

Power indicator (Rechargeable hybrid)

Digital speedometer (mph or km/h)

Cruise control or speed limiter settings

Display of speed limit signs

Selector position and gear on automatic

gearbox

Gear shift indicator

Driving mode selected

Coolant temperature indicator (°C) (Petrol

or Diesel)

Battery charge level and remaining range

(miles or km) (Rechargeable hybrid)

Total distance recorder (miles or km)

10.

Trip distance recorder (miles or km)

Control button

Short press: display the alerts log, reminder

of servicing information or the remaining

range associated with the AdBlue

and the

SCR system (miles or km) and tyre pressure

status information display.

Long press: reset the service indicator or trip

distance recorder (depending on the context).

Displays

Some

lamps have a fixed location, others can

change location.

For certain functions that have indicator lamps

for both operation and deactivation, there is only

one dedicated location.

Permanent information

In the standard display, the instrument panel

shows:

– in fixed locations:

• Rev counter (Petrol or Diesel).

• Fuel level indicator.

• Coolant temperature indicator.

• Charge level and range indicator

(Rechargeable hybrid).

• Power indicator (Rechargeable hybrid).

• Distance recorders.

– in variable locations:

• Information related to the gearbox and gear

shift indicator.

• Digital speedometer.

• Status or alert messages displayed

temporarily.

Optional information

Depending on the selected display mode and

active features, additional information may be

displayed:

– Rev counter (Petrol or Diesel).

– Trip computer.

– Driving aid functions.

– Speed limiter or cruise control.

– Media currently playing.

– Navigation instructions.

– Analogue speedometer.

– Engine oil level and temperature.

Customising the instrument

panel

You can modify the appearance of the instrument

panel by choosing:

– a display colour.

– a display mode.

Display language and units

These depend on the touch screen

settings.

When travelling abroad, the speed must be

shown in the official units of the country you

are driving in (mph, miles or km/h, km).

As a safety measure, these adjustments

must be carried out with the vehicle

stationary.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Dashboard instruments

Choosing the display colour

► Press "

Settings

" in the upper banner

of the touch screen.

► Select "

Color schemes

► Select a display colour.

Choosing the display mode

In each mode, specific types of information are

displayed on the instrument panel.

► Turn the thumbwheel on the left of the

steering wheel to display and scroll through

the various modes on the left-hand side of the

instrument panel.

► Press the thumbwheel to confirm the mode.

The new display mode is applied immediately.

If you do not press the thumbwheel, the selected

display mode is automatically applied after a few

moments.

Display modes

– "

Dials

": standard display of analogue and

digital speedometers, total distance recorder

and:

• fuel gauge, coolant temperature indicator

and rev counter (Petrol or Diesel).

• fuel gauge, battery charge level indicator and

power indicator (Rechargeable hybrid).

– "

Navigation

": specific display, showing current

navigation information (map and instructions).

– "

Driving

": specific display, showing

information relating to active driving aid systems.

– "

Minimum

": limited display with digital

speedometer, total distance recorder and:

• fuel gauge and coolant temperature indicator

(Petrol or Diesel).

• fuel gauge and battery charge level indicator

(Rechargeable hybrid).

– "

Personal

": minimal display, with the ability

to select and display optional information in the

personalisable areas on the left and right.

Configuring a "Personal" display mode

With CITROËN Connect Radio

► Press

Settings

in the banner of the

touch screen.

► Select "

Configuration

► Select "

Instrument panel

personalisation

With CITROËN Connect Nav

► Press

Settings

in the banner of the

touch screen.

► Select "

OPTIONS

► Select "

Instrument panel

personalisation

► For each personalised display area (left and

right), select a type of information using the

corresponding scroll arrows on the touch screen:

• "

Driving aids

• "

Default

" (empty).

• "

G-metres

" (depending on version).

• "

Media

• "

Navigation

• "

Trip computer

• "

Hybrid flows

" (depending on version).

• "

Rev counter

" (depending on version).

► Confirm to save and exit.

The information is displayed immediately on the

instrument panel if the corresponding display

mode is selected.

Warning and indicator

lamps

Displayed as symbols, the warning and indicator

lamps inform the driver of the occurrence of a

malfunction (warning lamps) or of the operating

status of a system (operation or deactivation

indicator lamps). Certain lamps light up in two

ways (fixed or flashing) and/or in several colours.

Associated warnings

The illumination of a lamp may be accompanied

by an audible signal and/or a message displayed

in a screen.

Relating the type of alert to the operating status

of the vehicle allows you to determine whether

the situation is normal or whether a fault has

occurred: refer to the description of each lamp

for further information.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Dashboard instruments

When the ignition is switched on

Certain red or orange warning lamps come on

for a few seconds when the ignition is switched

on. These warning lamps should go off as soon

as the engine is started.

For more information on a system or a function,

refer to the corresponding section.

Persistent warning lamp

If a red or orange warning lamp comes on, there

may be fault which needs further investigation.

If a lamp remains lit

The references

(1)

(2)

and

(3)

in the warning

and indicator lamp description indicate whether

you should contact a qualified professional in

addition to the immediate recommended actions.

(1)

You must stop the vehicle

Stop as soon as it is safe to do so and switch off

the ignition.

(2)

: Contact a CITROËN dealer or a qualified

workshop.

(3)

: Visit a CITROËN dealer or a qualified

workshop.

List of warning and

indicator lamps

Red warning/indicator lamps
STOP

Fixed, associated with another warning

lamp, accompanied by the display of a

message and an audible signal.

A serious fault with the engine, braking system,

power steering, automatic gearbox or a major

electrical fault has been detected.

Carry out (1) and then (2).

Engine oil pressure

Fixed.

There is a fault with the engine lubrication

system.

Carry out (1) and then (2).

Maximum coolant temperature

Fixed.

The temperature of the cooling system is

too high.

Carry out (1), then wait until the engine has

cooled down before topping up the level, if

necessary. If the problem persists, carry out (2).

System malfunction (Rechargeable hybrid)

Fixed.

The rechargeable hybrid system is faulty.

Carry out (1) and then (2).

Cable connected (Rechargeable hybrid)

Fixed when the ignition is switched on.

The charging cable is connected to the

vehicle's connector.

Fixed when the ignition is switched on,

accompanied by a message.

It is not possible to start the vehicle while the

charging cable is connected to the vehicle’s

connector.

Disconnect the charging cable and close the

flap.

12 V battery charge

Fixed.

The battery charging circuit is faulty

(e.g. dirty terminals, loose or severed alternator

belt).

Carry out (1).

If the electric parking brake stops working,

immobilise the vehicle:

► With the manual gearbox, engage a gear.

► With the automatic gearbox, fit the chocks

against one of the wheels.

Clean and tighten the terminals. If the warning

lamp does not go off when the engine is started,

carry out (2).

Door(s) open

Fixed, associated with a message

identifying the access.

An audible signal supplements the alert if the

speed is higher than 6 mph (10 km/h).

A door or the boot is not properly closed.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Dashboard instruments

Seat belts not fastened/unfastened

Fixed or flashing, accompanied by an

increasing audible signal.

A seat belt has not been fastened or has been

unfastened.

Electric parking brake

Fixed.

The electric parking brake is applied.

Flashing.

Application/release is faulty.

Carry out (1): park on flat ground (on a level

surface).

With a manual gearbox, engage a gear.

With an automatic gearbox, select mode

Switch off the ignition and carry out (2).

Braking

Fixed.

The brake fluid level in the braking circuit

has dropped significantly.

Carry out (1), then top up with fluid that complies

with the manufacturer's recommendations. If the

problem persists, carry out (2).

Fixed.

The electronic brake force

distribution (EBFD) system is faulty.

Carry out (1) and then (2).

Orange warning/indicator lamps
Anti-lock braking system (ABS)

Fixed.

The anti-lock braking system has a fault.

The vehicle retains conventional braking.

Drive carefully at moderate speed, then carry

out (3).

Service

Temporarily on, accompanied by the

display of a message.

One or more minor faults, for which there is/are

no specific warning lamp(s), have been detected.

Identify the cause of the fault using the message

displayed on the instrument panel.

You may be able to deal with some faults

yourself, such as changing the battery in the

remote control.

For other faults, such as with the tyre under-

inflation detection system, carry out (3).

Fixed, accompanied by the display of a

message.

One or more major faults, for which there is/are

no specific warning lamp(s), have been detected.

Identify the cause of the fault using the message

displayed on the instrument panel, then carry

out (3).

Service warning lamp fixed and

service spanner flashing then

fixed.

The servicing interval has been exceeded.

The vehicle must be serviced as soon as

possible.

Only with BlueHDi Diesel engines.

AdBlue

(BlueHDi)

On for around 30 seconds when starting

the vehicle, accompanied by a message

indicating the driving range.

The driving range is between 1,500 and 500

miles (2,400 and 800 km).

Top up the AdBlue

Fixed, on switching on the ignition,

accompanied by an audible signal and a

message indicating the driving range.

The driving range is between 500 and 62 miles

(800 and 100 km).

Promptly

top up the AdBlue

, or carry out (3).

Flashing, accompanied by an audible

signal and a message indicating the

driving range.

The driving range is less than 62 miles (100 km).

You

must

top up the AdBlue

avoid engine

starting being prevented

, or carry out (3).

Flashing, accompanied by an audible

signal and a message indicating that

starting is prevented.

The AdBlue

tank is empty: the legally required

engine immobiliser system prevents the engine

from starting.

To restart the engine, top up the AdBlue

or carry

out (2).

It is

essential

to add at least 10 litres of AdBlue

to the tank.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Dashboard instruments

SCR emissions control system (BlueHDi)

Fixed when the ignition is switched

on, accompanied by an audible

signal and a message.

A malfunction of the SCR emissions control

system has been detected.

This alert disappears once the exhaust

emissions return to normal levels.

Flashing AdBlue

warning lamp on

switching on the ignition, with the

Engine self-diagnostics warning lamp on fixed,

accompanied by an audible signal and a

message indicating the driving range.

Depending on the message displayed, it is

possible to drive for up to 685 miles (1,100 km)

before the engine immobiliser is triggered.

Carry out (3) without delay, to

avoid starting

being prevented

Flashing AdBlue

warning lamp on

switching on the ignition, with the

Engine self-diagnostics warning lamp on fixed,

accompanied by an audible signal and a

message indicating that starting is prevented.

The engine immobiliser prevents the engine from

restarting (the permitted driving limit has been

exceeded after confirmation of a malfunction of

the emissions control system).

To start the engine, carry out (2).

Engine self-diagnostic system

Flashing.

The engine management system has a

fault.

There is a risk that the catalytic converter will be

destroyed.

You

must

carry out (2).

Fixed.

The emissions control system has a fault.

The warning lamp should go off when the engine

is started.

Carry out (3) without delay.

Collision Risk Alert/Active Safety Brake

Fixed, accompanied by the display of a

message.

The system has been deactivated via the touch

screen (

Driving

Vehicle

menu).

Flashing.

The system activates and brakes the

vehicle momentarily to reduce the speed of

collision with the vehicle in front.

For more information, refer to the

Driving

section.

Fixed, accompanied by a message and

an audible signal.

The system has a fault.

Carry out (3).

Fixed.

The system is deactivated

temporarily because the driver and/or front

passenger (depending on version) has been

detected as present but the corresponding seat

belt has not been fastened.

Active lane departure warning system

Fixed.

The system has been automatically

deactivated or placed on standby.

Flashing.

You are about to cross a broken

lane marking without operating the direction

indicators.

The system is activated, then corrects the

trajectory if it detects a risk of unintentionally

crossing a line or hard shoulder (depending on

version).

For more information, refer to the

Driving

section.

Fixed.

The system has a fault.

Carry out (3).

Lane positioning assist

Fixed, accompanied by the

Service warning lamp.

The system has a fault.

Carry out (3).

Dynamic stability control (DSC)/Anti-slip

regulation (ASR)

Fixed.

The system is deactivated.

The DSC/ASR system is reactivated

automatically when the vehicle is restarted,

and at speeds above approximately 31 mph

(50 km/h).

At speeds below 31 mph (50 km/h), it can be

reactivated manually.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Dashboard instruments

Flashing.

DSC/ASR system regulation is activated

in the event of a loss of grip or trajectory.

Fixed.

The DSC/ASR system has a fault.

Carry out (3).

Emergency brake malfunction (with

electric parking brake)

Fixed, accompanied by the

message "Parking brake fault".

Emergency braking does not deliver optimal

performance.

If automatic release is not available, use manual

release or carry out (3).

Hill start assist

Fixed, accompanied by the

message "Anti roll-back system

fault".

The system has a fault.

Carry out (3).

Under-inflation

Fixed, accompanied by an audible signal

and a message.

The pressure in one or more tyres is too low.

Check the pressure of the tyres as soon as

possible.

Reinitialise the detection system after adjusting

the pressure.

Under-inflation warning lamp

flashing then fixed and Service

warning lamp fixed.

The tyre pressure monitoring system is faulty.

Under-inflation detection is no longer monitored.

Check the tyre pressures as soon as possible

and carry out (3).

Engine preheating (Diesel)

Temporarily on

(up to approximately 30 seconds in

severe weather conditions).

When switching on the ignition, if the weather

conditions and the engine temperature make it

necessary.

Wait until the warning lamp goes off before

starting.

When the warning lamp goes off, starting will

occur immediately if you press and hold:

– the clutch pedal with a manual gearbox.

– the brake pedal with an automatic gearbox.

If the engine does not start, make the engine

starting request again, while keeping your foot

on the pedal.

Front passenger airbag (ON)

Fixed.

The front passenger airbag is activated.

The control is set to the "

" position.

In this case, do not install a "rearward facing"

child seat on the front passenger seat - risk

of serious injury!

Front passenger airbag (OFF)

Fixed.

The front passenger airbag is deactivated.

The control is set to the “

OFF

” position.

A "rearward facing" child seat can be installed,

unless there is a fault with the airbags (Airbags

warning lamp on).

Airbags

Fixed.

One of the airbags or seat belt

pretensioners is faulty.

Carry out (3).

Pedestrian horn (Rechargeable hybrid)

Fixed.

Horn fault detected.

Carry out (3).

Low fuel level

Fixed (warning lamp or LED)

and needle in the red zone

(depending on version), accompanied by an

audible signal and a message.

The audible signal and the message are

repeated with increasing frequency as the level

drops towards zero.

When it first comes on, there remains

approximately 5 litres of fuel

in the tank

(reserve).

Refuel without delay to avoid running out of fuel.

Never drive until completely empty

, as

this could damage the emissions control and

injection systems.

Diesel fuel filter (Diesel)

Fixed.

The Diesel fuel filter contains water.

Carry out (2) without delay. Risk of damaging the

fuel injection system!

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Dashboard instruments

Particle filter (Diesel)

Fixed, accompanied by an audible signal

and a message about the risk of particle

filter blockage.

The particle filter is nearing saturation.

As soon as traffic conditions allow, regenerate

the filter by driving at a speed of at least 37 mph

(60 km/h), with an engine speed of above 2,500

rpm, until the warning lamp goes off.

Fixed, accompanied by an audible signal

and a message indicating that the

additive level in the particle filter is too low.

The low level in the additive tank has been

reached.

Top up without delay: carry out (3).

Automatic functions deactivated (electric

parking brake)

Fixed.

The "automatic application" (on switching

off the engine) and "automatic release" (on

acceleration) functions are deactivated.

If automatic application/release is no longer

possible:

► Start the engine.

► Use the control to apply the electric parking

brake.

► Take your foot fully off the brake pedal.

► Hold the control pressed in the release

direction for between 10 and 15 seconds.

► Release the control.

► Depress and hold the brake pedal.

► Pull the control in the application direction for

2 seconds.

► Release the control and the brake pedal.

Malfunction (with electric parking brake)

Fixed, accompanied by the

message "Parking brake fault".

The vehicle cannot be immobilised with the

engine running.

If manual application and release commands are

not working, the electric parking brake control

lever is faulty.

The automatic functions must be used at all

times and are automatically re-enabled in the

event of a control lever fault.

Carry out (2).

Fixed, accompanied by the

message "Parking brake

fault".

The parking brake is faulty: manual and

automatic functions may not be working.

When stationary, to immobilise the vehicle:

► Pull and hold the control lever for

approximately 7 to 15 seconds, until the indicator

lamp comes on on the instrument panel.

If this procedure does not work, secure the

vehicle:

► Park on a level surface.

► With a manual gearbox, engage a gear.

► With an automatic gearbox, select

, then

place the supplied chocks against one of the

wheels.

Then carry out (2).

Parking sensors

Fixed, accompanied by an onscreen

message and an audible signal.

The system is deactivated.

Fixed, associated with the Service

warning lamp, accompanied by the

display of a message and an audible signal.

The system has a fault.

Carry out (3).

Foot on the clutch

Fixed.

Stop & Start: the change to START mode

is rejected because the clutch pedal is not fully

depressed.

Fully depress the clutch pedal.

Power steering

Fixed.

The power steering has a fault.

Drive carefully at moderate speed, then carry

out (3).

Stop & Start

Fixed, accompanied by the display of a

message.

The Stop & Start system has been deactivated

manually.

The engine will not switch off at the next traffic

stop.

Press the button to reactivate the system.

Fixed.

The Stop & Start system has been

deactivated automatically.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Dashboard instruments

The engine will not switch off at the next traffic

stop, if the exterior temperature is:

– below 0°C.

– above +35°C.

For more information, refer to the

Driving

section.

Flashing then fixed, accompanied by a

message.

The system has a fault.

Carry out (3).

Rear foglamps

Fixed.

The lamps are on.

Green warning/indicator lamps
Stop & Start

Fixed.

When the vehicle stops, the Stop & Start

system puts the engine into STOP mode.

Flashing temporarily.

STOP mode is momentarily unavailable

or START mode is automatically triggered.

For more information, refer to the

Driving

section.

Vehicle ready to drive (Rechargeable

hybrid)

Fixed, accompanied by an audible signal

when it comes on.

The vehicle is ready to drive.

The indicator lamp goes out upon reaching a

speed of approximately 3 mph (5 km/h) and

lights up again when the vehicle stops moving.

The lamp will go out when you turn off the

engine and exit the vehicle.

Park Assist

Fixed.

The function is active.

For more information, refer to the

Driving

section.

Lane positioning assist

Fixed.

The function has been activated.

All conditions have been met: the system is

operating.

For more information, refer to the

Driving

section.

Hill Assist Descent Control

Fixed.

The system has been activated, but the

conditions for regulation are not met (gradient,

speed too high, gear engaged).

Flashing.

The function is regulating the speed of

the vehicle.

The vehicle is being braked; the brake lamps

come on during the descent.

Direction indicators

Flashing with audible signal.

The direction indicators are on.

Sidelamps

Fixed.

The lamps are on.

Dipped beam headlamps

Fixed.

The lamps are on.

Automatic headlamp dipping

Fixed.

The function has been activated

via the touch screen (

Driving

Vehicle

menu).

The lighting control stalk is in the "AUTO"

position.

For more information, refer to the

Lighting and

visibility

section.

Front foglamps

Fixed.

The front foglamps are on.

Automatic wiping

Fixed.

Automatic windscreen wiping is activated.

Blue warning/indicator lamps
Main beam headlamps

Fixed.

The lamps are on.

eSave function (Rechargeable hybrid)

Fixed, accompanied by the reserved

electric range.

The eSave function is activated.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Citroën C5 Aircross (2022 year). Manual in english - page 1
