98

Driving

Electric power is used to supplement the petrol

engine as long as there is energy left in the

battery.

Hill start assist

This system keeps the vehicle briefly stationary

(for approximately 2 seconds) when making a hill

start, while you transfer your foot from the brake

pedal to the accelerator pedal.

The system is only active when:

–  The vehicle is completely stationary, with your

foot on the brake pedal.

–  Certain slope conditions are met.

–  The driver’s door is closed.

Do not leave the vehicle while it is being

held temporarily by hill start assist.

If someone needs to get out of the vehicle

with the engine running, apply the parking

brake manually. Then check that the parking

brake indicator lamp and the

P

 indicator lamp

in the electric parking brake control are on

fixed.

The hill start assist function cannot be

deactivated. However, using the parking

brake to immobilise the vehicle interrupts its

operation.

Operation





Facing uphill, with the vehicle stationary,

the vehicle is held for a short time when the

driver releases the brake pedal:

–  If mode

D

 or

M

 is selected on an automatic

gearbox.





Facing downhill, with the vehicle stationary

and reverse gear engaged, the vehicle is held

for a short time when the driver releases the

brake pedal.

Malfunction

If the event of a malfunction, these

warning lamps light up on the

instrument panel, accompanied by the display of

a message.

Have it checked by a CITROËN dealer or a

qualified workshop.

Gear shift indicator

(Depending on engine)

This system is designed to reduce fuel

consumption by recommending the most suitable

gear.

Operation

Depending on the driving situation and

the vehicle's equipment, the system may

recommend skipping one or more gears.

Gear engagement recommendations are

not to be considered mandatory. Indeed, the

configuration of the road, the traffic density and

safety remain determining factors when choosing

the best gear. Therefore, the driver remains

responsible for deciding whether or not to follow

the system’s advice.

The system cannot be deactivated.

The system is only active in mode

M

 of

the automatic gearbox.

The information appears on the

instrument panel, in the form of an arrow

and the recommended gear.

The system adapts the gear change

instructions according to the driving

conditions (e.g. slope, load) and driving style

(e.g. power demand, acceleration, braking).

The system never suggests:

–  engaging first gear;

–  engaging reverse gear.

99

Driving

6

Stop & Start

The Stop & Start function puts the engine

temporarily into standby - STOP mode - during

phases when the vehicle is stationary (e.g. red

lights, traffic jams). The engine automatically

restarts - START mode - as soon as the driver

indicates the intention of moving off again.

Primarily designed for urban use, the function

is intended to reduce fuel consumption and

exhaust emissions as well as the noise level

when stationary.

The function does not affect the functionalities of

the vehicle, in particular the braking.

Deactivation/Reactivation

By default, the function is activated when the

ignition is switched on.

It is configured in the

ADAS

 touch screen

application.

or

Direct access to the

Shortcuts for driving aids

.

The display of a message on the instrument

panel confirms the change of state.

If the function is deactivated while the engine is

in STOP mode, it will restart immediately.

Associated indicator lamps

Function activated: engine on standy

(STOP mode)

Function deactivated or malfunction

Opening the bonnet

Before doing anything under the bonnet,

deactivate the Stop & Start system to avoid

any risk of injury caused by the engine

restarting automatically.

Driving on flooded roads

Before entering into a flooded area, it is

strongly recommended that you deactivate

the Stop & Start system.

For more information on

Driving

recommendations

, particularly on flooded

roads, refer to the corresponding section.

Operation

Main conditions for operation

–  The driver’s door must be closed.

–  The driver's seat belt must be fastened.

–  The level of charge in the battery must be

sufficient.

–  The temperature of the engine must be within

its nominal operating range.

–  The outside temperature must be between

0°C and 35°C.

Putting the engine into standby

(STOP mode)

The engine automatically enters standby mode

as soon as the driver indicates their intention to

stop:

–  With the gear selector in mode

D

 or

M

, with

the brake pedal depressed until the vehicle

stops.

–  With the gear selector in mode

N

, with the

vehicle stationary.

Time counter

A time counter adds up the time spent in standby

during the journey. It is reset to zero every time

the ignition is switched on.

Special cases:

The engine will not go into standby if the

conditions for operation are not met and in the

following cases:

–  Steep slope (ascending or descending).

–  Needed to maintain a comfortable temperature

in the passenger compartment.

–  Demisting active.

In these cases, this indicator lamp flashes

for a few seconds, then goes off.

After the engine has restarted, STOP

mode is not available until the vehicle

has reached a speed of 5 mph (8 km/h).

During parking manoeuvres, STOP mode

is not available for a few seconds after

100

Driving

coming out of reverse gear or turning the

steering wheel.

Restarting the engine (START mode)

The engine automatically restarts as soon as the

driver indicates the intention of moving off again:

–  With the selector in mode

D

 or

M

: with the

brake pedal released.

–  With the selector in mode

N

 and the brake

pedal released: when you place the gear

selector in mode

D

 or

M

.

–  With the selector in mode

P

 and the brake

pedal depressed: when you place the gear

selector in mode

R

,

N

,

D

 or

M

.

–  With reverse gear engaged.

Special cases

The engine will restart automatically if the

conditions for operation are met again and in the

following case:

–  Automatic gearbox in mode

N

, vehicle speed

exceeds 0.6 mph (1 km/h).

In this case, this indicator lamp flashes for

a few seconds, then goes off.

Malfunctions

In the event of a fault with the system, this

warning lamp flashes for a few moments

on the instrument panel, then remains on,

accompanied by the display of a message.

Have it checked by a CITROËN dealer or a

qualified workshop.

The vehicle stalls in STOP mode

All of the instrument panel warning lamps come

on if there is a fault.

►  Switch off the ignition then start the engine

again with the "

START/STOP

" button.

12 V battery

The Stop & Start system requires a

12 V battery of specific technology and

specification.

All work must be carried out only by a

CITROËN dealer or a qualified workshop

Tyre under-inflation

detection

This system alerts the driver when one or more

tyres have a drop in pressure.

The alert is raised when the vehicle is moving,

not when stationary.

It compares the information given by the wheel

speed sensors with

reference values, which

must be reinitialised every time the tyre

pressures are adjusted or a wheel changed

.

It takes the last values   stored during

the reinitialisation request into account. It is

therefore essential that the tyre pressure is

correct during the operation. This operation is

the driver’s responsibility.

The tyre under-inflation detection cannot,

in any circumstances, replace the need

for vigilance on the part of the driver.

This system does not avoid the need to

regularly check the tyre pressures (including

the spare wheel), especially before a long

journey.

Driving with under-inflated tyres, particularly

in adverse conditions (heavy load, high

speed, long journey):

–  worsens road-holding.

–  lengthens braking distances.

–  causes premature wear of the tyres.

–  increases energy consumption.

The inflation pressures defined for the

vehicle can be found on the tyre pressure

label.

For more information on the

Identification

markings

, refer to the corresponding section.

Checking tyre pressures

This check should be done monthly

when the tyres are "cold" (vehicle stopped for

1 hour or after a journey of less than 6 miles

(10 km) at moderate speeds).

Otherwise, add 0.3 bar to the pressures

shown on the label.

101

Driving

6

Snow chains

The system does not have to be

reinitialised after fitting or removing snow

chains.

Under-inflation alert

This is signalled by the fixed illumination

of this warning lamp, accompanied by an

audible signal and, depending on equipment, the

display of a message.

►  Reduce speed immediately, avoid excessive

steering movements and avoid sudden braking.

►  Stop the vehicle as soon as it is safe to do

so.

The loss of pressure detected may not

always cause visible deformation of the

tyre.

Do not rely on just a visual check.

►  Using a compressor, such as the one in

the temporary puncture repair kit, check the

pressures of all four tyres when cold.

►  If it is not possible to carry out this check

immediately, drive carefully at reduced speed.

►  In the event of a puncture, use the

temporary puncture repair kit or the spare wheel

(depending on equipment).

Driving too slowly may not ensure

optimum monitoring.

The alert is not immediately triggered in the

event of a sudden loss of pressure or tyre

blow-out. This is because analysis of the

values read by the wheel's speed sensors

can take several minutes.

The alert may be delayed at speeds below

25 mph (40 km/h), or when adopting a sporty

driving mode.

The alert is kept active until the system is

reinitialised.

Reinitialisation

►  The system must be reinitialised after any

adjustment to the pressure of one or more tyres,

and after changing one or more wheels.

Before reinitialising the system, make

sure that the pressures of the four tyres

are correct for the conditions of use of the

vehicle and conform to the values written on

the tyre pressure label.

Check the pressures of the four tyres before

performing the reinitialisation.

The system does not advise if a pressure is

incorrect at the time of reinitialisation.

With the vehicle stationary, the system

can be reinitialised in the

Settings>Vehicle

 touch screen application.

►  Then select

Safety>Under-inflation

reinitialisation

.

►  Press

YES

 to confirm.

The reinitialisation is confirmed by the display of

a message and an audible signal.

Malfunction

In the event of a malfunction,

these warning lamps light up on

the instrument panel.

A message appears, accompanied by an audible

signal.

In this case, the tyre under-inflation monitoring

function is no longer performed.

Have it checked by a CITROËN dealer or a

qualified workshop.

"Space-saver" type spare wheel

The use of this type of spare wheel may

suspend tyre pressure monitoring.

In this case, the malfunction warning lamp

comes on and disappears once the wheel

has been replaced by one of uniform size (the

same as the others), the pressure readjusted

and the reinitialisation carried out.

Driving and manoeuvring

aids - General

recommendations

Driving and manoeuvring aids cannot, in

any circumstances, replace the need for

vigilance on the part of the driver.

The driver must comply with the Highway

Code, must remain in control of the vehicle in

all circumstances and must be able to retake

control of it at all times. The driver must adapt

102

Driving

the speed to climatic conditions, traffic and

the state of the road.

It is the driver's responsibility to constantly

monitor traffic conditions, assess the distance

and relative speed of other vehicles, and

anticipate their manoeuvres before using the

direction indicator and changing lanes.

These systems do not make it possible to

exceed the laws of physics.

Driving aids

You should hold the steering wheel with

both hands, always use the door and interior

mirrors, always leave your feet close to the

pedals and take a break every 2 hours.

Manoeuvring aids

The driver must always check the

surroundings of the vehicle before and during

the whole manoeuvre, in particular using the

mirrors.

Radar(s)

The operation of the radar(s), along with

any associated functions, may be affected

by the accumulation of dirt (e.g. mud, ice),

in poor weather conditions (e.g. heavy rain,

snow), or if the bumpers are damaged.

If the front bumper is to be repainted, contact

a CITROËN dealer or a qualified workshop;

certain types of paint could interfere with the

operation of the radar(s).





Driving aids camera

This camera and its associated functions

may be impaired or not work if the windscreen

area in front of the camera is dirty, misty,

frosty, covered with snow, damaged or

masked by a sticker.

In humid and cold weather, demist the

windscreen regularly.

Poor visibility (inadequate street lighting,

heavy rain, thick fog, snowfall), dazzle

(headlamps of an oncoming vehicle, low sun,

reflections on a damp road, leaving a tunnel,

alternating shade and light) can also impair

detection performance.

In the event of a windscreen replacement,

contact a CITROËN dealer or a qualified

workshop to recalibrate the camera;

otherwise, the operation of the associated

driving aids may be disrupted.

Other cameras

The images from the camera(s)

displayed on the touch screen or on the

instrument panel may be distorted by the

terrain.

In the presence of areas in shade, or in

conditions of bright sunlight or inadequate

lighting, the image may be darkened and with

lower contrast.

Obstacles may appear further away than they

actually are.

Sensors

The operation of the sensors, as well as

any associated functions, may be disrupted

by noise pollution such as that emitted by

noisy vehicles and machinery (e.g. lorries,

pneumatic drills), by the accumulation of

snow or dead leaves on the road or in the

event of damaged bumpers and mirrors.

When reverse gear is engaged, an audible

signal (long beep) indicates that the sensors

may be dirty.

A front or rear impact to the vehicle can

upset the sensors’ settings, which is not

always detected by the system: distance

measurements may be distorted.

The sensors do not systematically detect

obstacles that are too low (pavements, studs)

or too thin (trees, posts, wire fences).

Certain obstacles located in the sensors’ blind

spots may not be detected or may no longer

be detected during the manoeuvre.

Certain materials (fabrics) absorb sound

waves: pedestrians may not be detected.

103

Driving

6

Maintenance

Clean the bumpers and door mirrors and

the field of vision of the cameras regularly.

When washing your vehicle at high pressure,

direct the spray from at least 30 cm away

from the radar, sensors and cameras.

Mats / Pedals covers

The use of mats or pedals covers not

approved by CITROËN may interfere with

the operation of the speed limiter or cruise

control.

To avoid any risk of jamming the pedals:

–  Ensure that the mat is secured correctly.

–  Never fit one mat on top of another.

Units of speed

Ensure that the units of speed displayed

in the instrument panel (mph or km/h) are

those for the country you are driving in.

If this is not the case, when the vehicle is

stationary, set the display to the required

units of speed so that it complies with what is

authorised locally.

In case of doubt, contact a CITROËN dealer

or a qualified workshop.

Steering wheel with

hands-on detection

(with Highway Driver Assist 2.0)

For more information, refer to the

General recommendations on the use

of driving and manoeuvring aids

.

The steering wheel is equipped with a hands-on

detection system to avoid distraction on the part

of the driver.

It is prohibited to cover or attach anything to the

steering wheel.

The driver must always check the

surroundings of the vehicle and

supervise the whole manoeuvre.

Any use of a system built into Highway Driver

Assist 2.0 must remain under the driver’s

vigilance.

The system also detects the presence of

hands when using the Lane Positioning assist

system with Highway Driver Assist.

The system may suffer interference or

not work correctly if:

–  the steering wheel is covered by some

protection.

–  the driver wears thick gloves (e.g. ski

gloves).

In the event of improper detection of hands on

the steering wheel, Highway Driver Assist 2.0

is not activated or is deactivated after a few

seconds.

Installation of mechanical anti-theft

devices on the steering wheel is

prohibited - risk of damage!

Shortcuts for driving aids

Driving aids can be accessed directly to quickly

activate/deactivate them.

By default, driving aids are already stored in the

system (e.g. Stop & Start, Active lane departure

warning system).

Other driving aids can be added or deleted from

the page.

It is configured in the

ADAS>Functions



touch screen application.

►  Press the button corresponding to the

driving assistance concerned:

•  Full symbol: the function is added to the

shortcuts.

•  Empty symbol: the function is deleted from

the shortcuts.

►  Check the modification in the

Shortcuts

 tab.

104

Driving









►  Press this button; the content is identical to

that of the

Shortcuts

 tab.

Road signs recognition

For more information, refer to the

General recommendations on the use

of driving and manoeuvring aids

.





This system displays the maximum speed

authorised locally on the instrument panel, using:

–  Speed limit signs detected by the camera.

–  Speed limit information from the navigation

system’s mapping.

–  Signs indicating a shared traffic zone detected

by the camera.

Sign detected

Suggested speed

(calculated)

Entry into a shared

traffic zone

Example:





Without MyCitroën

Drive Plus

10 mph or 20 km/h

(depending on

the units on the

instrument panel)

With MyCitroën

Drive Plus

Display of the speed

in force in the country

you are driving in.

–  Some supplementary traffic signs detected by

the camera.

Supplementary

traffic sign detected

Display of

the speed

associated with

the supplementary

traffic sign

Speed limit when

raining

Examples:





If the wiper control

stalk is in the

"intermittent wipe"

or "automatic wipe"

position (in order

to activate the rain

sensor):

68 mph (110 km/h)

(for example)

Speed limit when

towing





If an approved towing

device is fixed to the

vehicle:

56 mph (90 km/h)

(for example)

Speed limit

applicable over a

certain distance

Example:





43 mph (70 km/h)

(for example)

105

Driving

6

Supplementary

traffic sign detected

Display of

the speed

associated with

the supplementary

traffic sign

Speed limit for

vehicles with a

gross vehicle

weight or gross

train weight less

than 3.5 tonnes





56 mph (90 km/h)

(for example)

Speed limit in case

of snow

Example:





If the outside

temperature is below

3°C:

19 mph (30 km/h)

(for example)

with a "snowflake"

symbol

Speed limit at

certain times of the

day

Example:





19 mph (30 km/h)

(for example)

with a "clock" symbol

Navigation mapping should be regularly

updated in order to receive accurate

speed limit information from the system.

The units for the speed limit (mph or

km/h) depend on the country you are

driving in.

This should be taken into account to ensure

you observe the speed limit.

For the system to work properly when

changing countries, the speed unit of the

instrument panel must match that of the

country you are driving in.

Automatic sign reading is a driving aid

system and does not always display the

correct speed limits.

The speed limit signs present on the road

always take priority over those displayed by

the system.

The system is designed to detect signs that

conform to the Vienna Convention on road

signs.

Specific speed limits, such as those for

heavy goods vehicles, are not displayed.

The display of the speed limit on the

instrument panel is updated when passing

a speed limit sign intended for cars (light

vehicles).

Activation/Deactivation

By default, the system is automatically activated

at every engine start.

It is configured in the

ADAS

 touch screen

application.

Information displayed on

the instrument panel





1.

Detected speed limit indication

or

2.

End of speed limit indication





The system is active but is not detecting speed

limit information.





On detecting speed limit information, the system

displays the value.





For a suggested maximum speed, the first time

that the vehicle exceeds it

by more than 3 mph

(5 km/h)

 (e.g. 59 mph (95 km/h)), the speed is

displayed and flashes for 10 seconds (depending

on version).

106

Driving

Operating limits

The system does not take account of reduced

speed limits, especially those imposed in the

following cases:

–  Atmospheric pollution.

– Towing.

–  Driving with a space-saver type spare wheel

or snow chains fitted.

–  Tyre repaired using the temporary puncture

repair kit.

–  Young drivers.

The system may not display the speed limit if it

does not detect a speed limit sign within a preset

period and in the following situations:

–  Road signs that are obstructed, non-standard,

damaged or bent.

–  Obsolete or incorrect maps.

Speed setting

recommendations

The driver can select the speed displayed by the

Road signs recognition

 function as the speed

setting for the speed limiter, cruise control or

adaptive cruise control using the

OK

 button.

In the event of rain detection, the system offers

the driver a speed setting lower than the speed

read/from the map in order to adapt to weather

conditions (e.g. on motorways, the proposed

speed is 68 mph (110 km/h) instead of 81 mph

(130 km/h).

Speed setting advance recommendations

With Highway Driver Assist 2.0 activated,

the system detects the next speed limit sign,

displays it in the background and proposes this

new speed as the speed setting.

Once memorised:

–  If the speed setting is lower than the previous

one, the vehicle slows down to reach this new

speed when it gets to the sign.

–  If the speed setting is higher than the previous

one, the vehicle speeds up to reach this new

speed when it passes the sign.

For more information on the

Speed

limiter

,

Cruise control

 or

Adaptive

cruise control

, refer to the corresponding

sections.

Steering-mounted controls









1.

Select speed limiter mode

2.

Select cruise control mode

3.

Memorise the speed setting

Information displayed on the

instrument panel









Without speed setting advance

recommendations





With speed setting advance

recommendations

4.

Current speed setting

107

Driving

6

5.

Speed memorisation prompt

6.

Current speed limit indication

7.

Next speed limit indication

Operating conditions

–  Eligible roads: roads with separate

carriageways with prohibited access for

pedestrians and cyclists.

–  Highway Driver Assist 2.0 activated.

–  Vehicle speed between 0 and 112 mph (0 and

180 km/h).

–  Steering wheel properly held by the driver.

Memorising the speed setting

►  Switch on the speed limiter

1-LIMIT

 or cruise

control

2

.

Information related to the speed limiter or cruise

control is displayed.

When a new speed setting is detected, the

system displays the value and “

OK?

“ to suggest

saving it as a new speed setting.

If there is a difference of less than 3 mph

(5 km/h) between the speed setting and

the speed displayed by the Road signs

recognition, the "

OK?

“ symbol is not

displayed.

Depending on the road conditions, several

speeds may be displayed.

►  Press

3-OK

 to confirm the new speed setting.

The display then reverts to its previous state.

Extended Traffic

Sign

Recognition

For more information, refer to the

General recommendations on the use

of driving and manoeuvring aids

.





This additional system recognises these road

signs and displays them on the instrument panel

if the appropriate display mode is selected:

–

No entry:

 when entering a lane in the wrong

direction, an alert message, including the symbol

of this sign, is displayed on the instrument panel

(request to check the direction of traffic).

–

Other signs:

 as you approach it, the symbol

of the corresponding sign is displayed on the

instrument panel.

The actual road signs always take priority

over the display from the system.

The signs must comply with the Vienna

Convention on road signs.

Activation/Deactivation

It is configured in the

ADAS

 touch screen

application.

Speed limiter

For more information, refer to the

General recommendations on the use

of driving and manoeuvring aids

.

This system prevents the vehicle from

exceeding the speed programmed by the

driver (speed setting).

The speed limiter is switched on manually.

The minimum speed setting is 19 mph (30 km/h).

The speed setting remains in the system

memory when the ignition is switched off.

Steering-mounted controls









1.

Speed limiter ON/OFF

2.

Switch on/pause the speed limiter at the

previously saved speed setting

3.

Increase/Decrease the speed setting

108

Driving

4.

Activate the speed limiter at the previously

saved speed setting

Use the speed suggested by the Road signs

recognition

For more information on the

Road signs

recognition

, refer to the corresponding section.

Information displayed on

the instrument panel





5.

Speed limiter mode selection indication

6.

Speed limiter on (green)/pause (grey)

indication

7.

Speed setting value

8.

Speed suggested by the Road signs

recognition function (depending on version)

Switching on/Pausing

►  Press

1-LIMIT

 to select the speed limiter

mode; the function is paused (grey).

►  If the limit speed setting is suitable (most

recent speed setting programmed in the system),

press

2-I I>

 or

4-OK

 to switch the speed limiter

on (green).

►  Pressing

2-I I>

 again temporarily pauses the

function.

When the speed setting remains below

the vehicle's speed for a prolonged

period of time, an audible warning is emitted.

Adjusting the speed setting

You do not have to switch the speed limiter on in

order to set the speed.

To change the speed setting using the vehicle’s

current speed:

►  For steps of +/- 1 mph (1 km/h), make

successive short presses upwards/downwards

on

3

 to increase/decrease.

►  For steps of +/- 5 mph (5 km/h), press and

hold upwards/downwards on

3

 to increase/

decrease.

When the function is activated, it is possible to

modify the cruise speed setting based on the

speed suggested by the Road signs recognition

function, as shown on the instrument panel:

–

When passing the sign:

►  Press

4-OK

 to save the suggested speed.

This value is then immediately shown as the new

speed setting on the instrument panel.

–

After passing the sign:

►  Press

4-OK

. The message "

OK?

" is

displayed to confirm the request to save.

►  Press

4-OK

 again to save the suggested

speed. The new speed setting value is displayed

on the instrument panel.

Temporarily exceeding the

speed setting

►  Fully depress the accelerator pedal.

The speed limiter is temporarily deactivated and

the displayed speed setting flashes.

►  Release the accelerator pedal to return to

below the speed setting.

When exceeding the speed is not due to the

driver's action (e.g. in case of a steep slope), an

audible signal is triggered immediately.

On a steep descent or in the event of

sharp acceleration, the speed limiter will

not be able to prevent the vehicle from

exceeding the speed setting.

If necessary, apply the brakes to control your

vehicle’s speed.

When the vehicle speed returns to the speed

setting level, the speed limiter operates again:

the speed setting display becomes fixed again.

109

Driving

6

Off

►  Press

1-LIMIT

: the speed limiter information

display disappears.

Malfunction

In the event of a malfunction, dashes are

displayed flashing and then fixed (orange)

instead of the speed setting.

Have it checked by a CITROËN dealer or a

qualified workshop.

Cruise control - Specific

recommendations

The cruise control function does not

guarantee compliance with the maximum

authorised speed and the safety distance

between vehicles, the driver remains

responsible for their driving.

In the interest of public safety, only use cruise

control if the traffic conditions enable vehicles

to drive at a steady speed and maintain an

adequate safety distance.

Remain vigilant while cruise control is

activated.

 If you press and hold one of the

speed setting modification buttons, your

vehicle may change speed very abruptly.

When

descending a steep hill

, the cruise

control system cannot prevent the vehicle

from exceeding the set speed. Brake if

necessary to control the vehicle speed.

On

steep climbs

 or when towing, the set

speed may not be reached or maintained.

Exceeding the programmed speed

setting

You can

temporarily

 exceed the speed

setting by pressing the accelerator pedal (the

programmed speed flashes).

To return to the speed setting, release the

accelerator pedal (when the set speed is

reached again, the displayed speed stops

flashing).

Operating limits

Never use the system in the following

situations:

–  In an urban area with the risk of

pedestrians crossing the road.

–  In heavy traffic (except versions with the

Stop & Go function).

–  On winding or steep roads.

–  On slippery or flooded roads.

–  In poor weather conditions.

–  In the event of restricted visibility for the

driver.

–  Driving on a speed circuit.

–  Driving on a rolling road.

–  When using a ‘space-saver’ type spare

wheel.

–  When using snow chains, non-slip covers

or studded tyres.

Cruise control

For more information, refer to the

General recommendations on the use

of driving and manoeuvring aids

 and

to

Cruise control - particular

recommendations

.

This system automatically maintains the

vehicle’s speed at the value programmed

by the driver (speed setting), without the use of

the accelerator pedal.

Cruise control is switched on manually.

It requires a minimum vehicle speed of 25 mph

(40 km/h).

With an automatic gearbox, mode

D

 or second

gear or higher in mode

M

 must be engaged.

Cruise control remains active after

changing gear on engines fitted with Stop

& Start.

Switching off the ignition cancels any

speed setting.

110

Driving

Steering-mounted controls









1.

Cruise control ON/OFF

2.

Switch on/pause cruise control at the

previously saved speed setting

3.

Increase/Decrease the speed setting (if

cruise control activated)

Activation of cruise control in progress (if

cruise control deactivated)

4.

Activation of cruise control in progress

Use the speed suggested by the Road signs

recognition

For more information on the

Road signs

recognition

, refer to the corresponding section.

Information displayed on

the instrument panel





5.

Cruise control mode selection indication

6.

Cruise control on (green)/pause (grey)

indication

7.

Speed setting value

8.

Speed suggested by the Road signs

recognition function (depending on version)

Switching on/pausing

►  Press button

1

 to select the cruise control

mode; the function is paused (grey).

►  Press

3

 upwards/downwards, or press

4-OK



to activate the cruise control and save a speed

setting as soon as the vehicle speed reaches the

desired level (green).

►  Pressing button

2-I I>

 temporarily pauses the

function.

►  Pressing

2-I I>

 or

4-OK

 again will reactivate

cruise control (green).

Cruise control operation is also

temporarily interrupted (pause):

–  by pressing the brake pedal.

–  automatically, if the electronic stability

control (ESC) system is triggered.

–  by shifting to neutral or engaging reverse

gear.

–  by using the electric parking brake.

Modifying the speed setting

The cruise control must be active.

To change the speed setting using the vehicle’s

current speed:

►  For steps of +/- 1 mph (1 km/h),

make successive short presses upwards/

downwards on

3

 to increase/decrease.

►  For steps of +/- 5 mph (5 km/h), press and

hold upwards/downwards on

3

 to increase/

decrease.

Prolonged pressing and holding

upwards/downwards on

3

 causes a very

rapid change in vehicle speed.

As a precaution, we recommend setting

a cruise speed fairly close to the current

speed of your vehicle, to avoid any sudden

acceleration or deceleration of the vehicle.

111

Driving

6

When the function is activated, it is possible

to change the speed setting using the speed

suggested by the Road signs recognition

function displayed on the instrument panel:

–

When passing the sign:

►  Press

4-OK

 to save the suggested speed.

This value is then immediately shown as the new

speed setting on the instrument panel.

–

After passing the sign:

►  Press

4-OK

. The message "

OK?

" is

displayed to confirm the request to save.

►  Press

4-OK

 again to save the suggested

speed. The new speed setting value is displayed

on the instrument panel.

Off

►  Press

1

: the cruise control information display

disappears.

Malfunction

In the event of a malfunction, dashes are

displayed flashing and then fixed (orange)

instead of the speed setting.

Have it checked by a CITROËN dealer or a

qualified workshop.

Highway Driver Assist

Only available on versions with automatic

gearbox.

This system automatically adjusts the speed

and corrects the trajectory of the vehicle, using

the Adaptive Cruise Control with Stop&Go in

conjunction with the Lane Positioning Assist.

These two functions must be activated and in

operation.

This system is especially suitable for driving on

motorways and main roads.

For more information on

Adaptive cruise

control

 and

Lane Positioning Assist

, refer to

the corresponding sections.

The system assists the driver by acting

on the steering, acceleration and braking

within the physical limits and capacities of the

vehicle. Certain road infrastructure elements

or vehicles in the surroundings may not be

properly seen or may be poorly interpreted by

the camera and radar, resulting in an

unexpected change in direction, a lack of

steering correction and/or inappropriate

management of acceleration or braking.

Selecting/Deselecting the

system







ASSIST



►  Press this button successively until the

Highway Driver Assist mode is displayed on the

instrument panel.

►  After a few seconds, the Highway Driver

Assist mode is selected. The Driving aids mini-

view is displayed on the instrument panel.





The colour of the symbols, representing the

steering wheel and the side lines, depends on

the operating state of the system:

(grey)

One or more operating conditions is not

met; the system is paused.

(green)

All operating conditions are met; the

system is active.

(orange)

System malfunction.

►  Press this button successively again until the

OFF

 mode is displayed on the instrument panel.

►  After a few seconds, the Highway Driver

Assist mode is deselected. The Driving aids

mini-view disappears.

Highway Driver Assist 2.0

This system automatically regulates the speed

and corrects the trajectory of the vehicle by

combining the following functions:

112

Driving

–  Highway Driver Assist with Adaptive Cruise

Control with Stop&Go and Lane positioning

assist.

–  Speed setting advance recommendations.

–  Speed adjustment during cornering.

–  Semi-automatic lane changing.

By default, these functions are activated; but

they can be deactivated.

For more information on these functions, refer to

the corresponding sections.

The availability of the system depends on the

country you are driving in.

This system is only to be used on eligible

motorways and main roads.

Selecting/Deselecting the

system

It is configured in the

ADAS

 touch screen

application.

The system's status is saved when the ignition is

switched off.

Adaptive cruise control

For more information, refer to the

General recommendations on the use

of driving and manoeuvring aids

 and

to

Cruise control - particular

recommendations

.

This system automatically maintains the vehicle

speed at a value set by the driver (speed

setting), while respecting a safety distance from

the vehicle in front (target vehicle) previously set

by the driver. The system automatically manages

the acceleration and deceleration of the vehicle.

With the

Stop & Go function

, the system

manages braking until the vehicle comes to a

complete stop and the restarting of the vehicle.

The brake lamps come on if the vehicle

is slowed down by the system.

The system is not operational in the event of

a brake lamp failure.





To do this, the system uses a camera fitted at the

top of the windscreen and a radar fitted in the

front bumper.

Primarily designed for driving on main

roads and motorways, this system only

works with moving vehicles driving in the

same direction as your vehicle.

If the driver activates the direction

indicator to overtake a slower vehicle,

cruise control may temporarily reduce the

distance to the target vehicle to facilitate

overtaking, without exceeding the speed

setting.

Steering-mounted controls









1.

Selection of cruise control alone or Highway

Driver Assist (depending on version)/

Deselection

2.

Switch on/pause cruise control at the

previously saved speed setting

Confirmation of vehicle restart after automatic

stop

3.

Increase/Decrease the speed setting (if

cruise control activated)

Activation of cruise control in progress (if

cruise control deactivated)

Display and configuration of the inter-vehicle

distance setting

4.

Activation of cruise control in progress

Use the speed suggested by the Road signs

recognition

For more information on the

Road signs

recognition

, refer to the corresponding section.

113

Driving

6

Information displayed on

the instrument panel





5.

Cruise control activated (green)/paused

(grey)

6.

Speed setting value

7.

Speed suggested by the Road signs

recognition

8.

Vehicle held stationary

9.

Inter-vehicle distance setting

10.

Position of the vehicle detected by the

system

Use

Selecting the system

►  With the engine running, press successively

on

1-ASSIST

 until cruise control mode is

displayed on the instrument panel.

►  After a few seconds, cruise control mode is

selected. The Driving aids mini-view is displayed

(grey) and cruise control is ready to be activated.

Switching on cruise control

The vehicle speed must be between 0 and

112 mph (0 and 180 km/h).

System activation is also subject to the following

conditions:

–  driver's door closed.

–  driver's seat belt fastened.

– mode

D

 selected on the automatic gearbox.

–  parking brake released.

–  if the vehicle is stationary, brake pedal

depressed.

The message “

OK?

" is displayed if all the

activation conditions are met.

►  Press

on 4-OK

: the current speed becomes

the speed setting (minimum 19 mph (30 km/h))

and cruise control is immediately activated

(green display).

Modifying the speed setting

To change the speed setting using the vehicle’s

current speed:

►  For steps of +/- 1 mph (1 km/h), make

successive short presses upwards/downwards

on

3

 to increase/decrease.

►  For steps of +/- 5 mph (5 km/h), press and

hold upwards/downwards on

3

 to increase/

decrease.

Prolonged pressing and holding

upwards/downwards on

3

 causes a rapid

change in vehicle speed.

When the function is activated, it is possible

to change the speed setting using the speed

suggested by the Road signs recognition

function displayed on the instrument panel:

–

When passing the sign:

►  Press

4-OK

 to save the suggested speed.

This value is then immediately shown as the new

speed setting on the instrument panel.

–

After passing the sign:

►  Press

4-OK

. The message “

OK?

" is

displayed to confirm the request to save.

►  Press

4-OK

 again to save the suggested

speed. The new speed setting value is displayed

on the instrument panel.

Pausing/resumption of cruise control

►  Press

2-I I>

 or depress the

brake pedal

.

The symbol "

I I>

” is displayed if all the activation

conditions are met.

Cruise control may also have been paused:

–  automatically, if the electronic stability control

(ESC) system is triggered.

–  by shifting to neutral or engaging reverse gear.

–  by using the electric parking brake.

–  by unfastening the seat belt.

–  by opening the driver's door.

►  Press

2-I I>

 or

4-OK

 to reactivate cruise

control.

Following braking that has brought the vehicle

to a complete stop, if the traffic conditions do
