Citroën C5 X (2022 year). Manual in english - page 5

66

Lighting and visibility

from the windscreen and around the wiper

arms and blades.

Do not operate the wipers on a dry

windscreen. In extremely hot or cold

weather, check that the wiper blades are not

stuck to the windscreen before operating the

wipers.

After using an automatic car wash, you

may temporarily notice abnormal noises

and poorer wiping performance.  You do not

need to replace the wiper blades.





Windscreen wipers

►  To select the wiping speed: raise or lower the

stalk to the desired position.

Fast wiping (heavy rain)

Normal wiping (moderate rain)

Automatic wipers

Switching off



Manual

After switching off the ignition, a slight

movement of the windscreen wipers to

store them under the bonnet may occur.

In position

1

 or

2

, the wiping frequency is

automatically reduced when the speed of

the vehicle drops below 3 mph (5 km/h).

When the speed is above 6 mph (10 km/h)

again, the wiping frequency returns to the

original frequency (fast or normal).

Single wipe

►  Press and release the control stalk or briefly

pull the control stalk towards you.

Windscreen wash

►  Pull the wiper control stalk towards you and

hold.

A final wiping cycle is performed when

screenwashing ends.

The windscreen wash jets are

incorporated into the tip of each wiper

arm.

Screenwash fluid is sprayed along the length

of the wiper blade. This improves visibility and

reduces screenwash fluid consumption.

With automatic air conditioning, any

action on the screenwash control results

in temporary closure of the air intake to

protect the passenger compartment from any

odour.

To avoid damaging the wiper blades, do

not operate the screenwash if the

screenwash reservoir is empty.

Only operate the screenwash if there is no

risk of the fluid freezing on the windscreen

and hindering visibility. During the winter

period, use "very cold climate" rated products.

Never top up with water.

Automatic windscreen

wipers

In

AUTO

 mode, the front wipers work

automatically and adapt to the intensity of

precipitation depending on the sensitivity of the

sensor selected.

The rainfall detection function uses a rain/

sunshine sensor located at the top centre of the

windscreen, behind the rear view mirror.

In certain weather conditions (e.g. fog,

frost, snow, projections on salty roads),

the driver may have to return to manual

wiping.

Switching on/off

To switch on:

►  Put the wiper control stalk in the

AUTO



position.

67

Lighting and visibility

4

►  Turn the ring to adjust the sensitivity of the

sensor.

A wiping cycle, accompanied by the display of

a message, confirms that the request has been

taken into account.

►  To switch off, put the wiper control stalk in

another position or in the

0

 position.

Adjusting the sensitivity





The first position (upper) corresponds to the

lowest sensitivity of the sensor.

The last position (lower) corresponds to the

highest sensitivity of the sensor.

The higher the sensitivity, the faster the system

reacts and increases the wiping frequency.

A rotation of the ring from a higher position to a

lower position triggers a confirmation wiping.

After the ignition has been switched off

for more than 1 minute with the wiper

control stalk in the

AUTO

 position, when the

ignition is switched on again:

–  the system works, depending on the

volume of rain detected, as soon as the

vehicle exceeds 6 mph (10 km/h), if the

outside temperature is below +3°C.

–  the system works immediately, depending

on the volume of rain detected, if the outside

temperature is above +3°C.

Do not cover the rain/sunshine sensor.

When using an automatic car wash,

switch off the automatic wipers and the

ignition.

In winter, wait until the windscreen is

completely clear of ice before activating the

automatic wipers.

Malfunction

If a fault occurs with the automatic wipers, the

wipers operate in intermittent mode.

Have it checked by a CITROËN dealer or a

qualified workshop.

Special position of the

windscreen wipers

This maintenance position is used while cleaning

or replacing the wiper blades. It can also be

useful, in wintry weather (ice, snow), to release

the wiper blades from the windscreen.

To maintain the effectiveness of the flat

wiper blades, it is advisable to:

–  handle them with care.

–  clean them regularly using soapy water.

–  avoid using them to hold cardboard on the

windscreen.

–  replace them at the first signs of wear.

Before removing a windscreen wiper blade





Operating the wiper control stalk immediately

after switching off the ignition will place the wiper

blades in a vertical position.

►  Proceed with the desired operation or the

replacement of the wiper blades.

After refitting a windscreen wiper blade

►  To return the wiper blades to their initial

position after the operation, switch on the ignition

and operate the wiper control stalk.

68

Lighting and visibility

Changing a wiper blade

Removing/Refitting at the front





►  Carry out these wiper blade replacement

operations from the driver's side.

►  Starting with the wiper blade farthest from

you, hold each arm by the rigid section and raise

it as far as possible.

Take care not to hold the arms at the jet

locations.

Do not touch the wiper blades - risk of

irreparable deformation.

Do not release them while moving them. Risk

of damaging the windscreen!

►  Clean the windscreen using screenwash

fluid.

Do not apply "Rain X" type water-

repellent products.

►  Unclip the worn wiper blade closest to you

and remove it.

►  Install the new wiper blade and clip it to the

arm.

►  Repeat the procedure for the other wiper

blade.

►  Starting with the wiper blade closest to you,

once again hold each arm by the rigid section,

then guide it carefully onto the windscreen.

69

Safety

5

General safety

recommendations

Do not remove the labels attached in

different places on your vehicle. They

include safety warnings as well as

identification information for the vehicle.

Depending on country regulations,

certain safety equipment may be

mandatory: high visibility safety vests,

warning triangles, breathalysers, spare bulbs,

spare fuses, fire extinguisher, first aid kit, mud

flaps at the rear of the vehicle, etc.

Installing electrical accessories:

–  The fitting of electrical equipment or

accessories not approved by CITROËN may

cause excessive current consumption and

faults and failures with the electrical system

of your vehicle. Contact a CITROËN dealer

for information on the range of approved

accessories.

–  As a safety measure, access to the

diagnostic socket, used for the vehicle's

electronic systems, is reserved strictly for

CITROËN dealers or qualified workshops,

equipped with the special tools required (risk

of malfunctions of the vehicle's electronic

systems that could cause breakdowns or

serious accidents). The Manufacturer cannot

be held responsible if this advice is not

followed.

–  Any modification or adaptation not intended

or authorised by CITROËN or carried out

without meeting the technical requirements

defined by the Manufacturer will result in the

suspension of the commercial warranty.

Installation of accessory radio

communication transmitters

Before installing a radio communication

transmitter with an external aerial, you must

without fail contact a CITROËN dealer for

the specification of transmitters which can

be fitted (frequency, maximum power, aerial

position, specific installation requirements),

in line with the Vehicle Electromagnetic

Compatibility Directive (2004/104/EC).

Declarations of conformity for radio

equipment

The relevant certificates are available on the

http://service.citroen.com/ACddb/ website.

Hazard warning lamps









►  Pressing this button causes all the direction

indicators to flash.

They can work with the ignition switched off.

Automatic operation of

hazard warning lamps

When braking in an emergency, depending on

the rate of deceleration, the hazard warning

lamps come on automatically. They switch off

automatically when you next accelerate.

They can be switched off by pressing the button.

Horn





70

Safety

►  Press the central part of the steering wheel.

Pedestrian horn

(Rechargeable hybrid)

This system alerts pedestrians that the vehicle

is approaching, when driving in

Electric

 mode

(100% electric driving).

The pedestrian horn operates once the vehicle

is moving and at speeds of up to 19 mph

(30 km/h), in forward or reverse gear.

This function cannot be deactivated.

Malfunction

In the event of a malfunction, this warning

lamp lights up on the instrument panel.

Have it checked by a CITROËN dealer or a

qualified workshop.

* In accordance with the general conditions of use of the service, available from dealers and subject to technological and technical limitations.

** In areas covered by the eCall (SOS) and the ‘ASSISTANCE’ functions.

The list of countries covered and the telemetry services provided is available from dealers or on the website for your country.

Emergency or assistance

call









1.

eCall (SOS)

2.

ASSISTANCE

eCall (SOS)

Your vehicle may be fitted with the eCall (SOS)

system either as standard or as an option.

The eCall (SOS) system provides direct contact

to the emergency services and is fully built

into the vehicle. This contact is made either

automatically via the sensors built into the

vehicle, or by pressing button

1

.

According to the country of sale, the eCall (SOS)

system corresponds to the systems PE112,

ERAGLONASS, 999, etc.

The eCall (SOS) system is activated by default.

►  To make an emergency call manually, press

button

1

 for more than 2 seconds.

The lit indicator lamp and a voice message

confirm that the call has been made to the

emergency services*.

The eCall (SOS) system immediately locates

your vehicle and puts you in contact with the

appropriate emergency services**.

►  Pressing again immediately cancels the

request.

The indicator lamp flashes while the vehicle

data is being sent, and then remains lit when

communication is established.

In the event that a serious accident is

detected by the sensors built into the

vehicle, such as the airbag control unit, an

emergency call is made automatically.

The eCall (SOS) system is a public

service of general interest and is free of

charge.

Operation of the system

–  Upon switching on the ignition, the indicator

lamp lights up for a few seconds and then goes

out: the system is operating correctly.

71

Safety

5

–  The indicator lamp flashes red: emergency

battery is flat. This will be recharged after a few

minutes' driving.

–  The indicator lamp is fixed red: system

malfunction. The emergency and assistance call

services may not work.

–  If the indicator lamp does not light up when

the ignition is turned on, this is also a system

malfunction.

If the problem persists, contact a qualified

workshop as soon as possible.

The malfunction of the system does not

prevent the vehicle from driving.

When an onboard system update is

being performed, the eCall (SOS)

function is not available.

Data processing

All processing of personal data by

the eCall (SOS) function complies with

the framework for protection of personal

information established by Regulation

2016/679 (General Data Protection

Regulation - GDPR) and Directive 2002/58/

EC of the European Parliament and the

Council, and in particular, seeks to protect

the vital interests of the data subject, in

accordance with Article 6 (1) d) GDPR.

The processing of personal data is strictly

limited to the purpose of handling the eCall

(SOS) function used with the “112” single

European emergency call number.

The eCall (SOS) function is only able to

collect and process the following data

relating to the vehicle: vehicle identification

number, vehicle type (passenger vehicle or

light commercial vehicle), fuel type or power

source, three most recent locations and

direction of travel, number of passengers

and a timestamped log file of the automatic

activation of the system and its timestamp.

The recipients of the processed data are the

emergency call handling centres designated

by the relevant national authorities in the

territory in which they are located, enabling

priority routing and handling of calls to the

“112” emergency number.

Data storage

Data contained in the system’s memory

is not accessible from outside the system until

a call is made. The system is not traceable

and is not continuously monitored in its

normal operating mode.

The data in the system's internal memory is

automatically and continuously erased. Only

the vehicle’s three most recent locations,

necessary for the normal functioning of the

system, are stored.

When an emergency call is triggered, the data

log is stored for no more than 13 hours.

Access to data

You have the right of access to data and

as appropriate to request the rectification,

erasure or restriction of processing of any

personal data not processed in accordance

with the provisions of GDPR. Third parties

to which data has been disclosed shall

be notified of any rectification, erasure or

restriction carried out in compliance with

GDPR, unless it proves impossible or

involves a disproportionate effort.

You also have the right to lodge a complaint

with the respective data protection

supervisory authority.

If you want to claim your above-mentioned

rights please contact us per email at

privacyrights@stellantis.com.

For more information regarding our contact

details please take a look at our Privacy &

Cookies Policy on the brand's website.

72

Safety

ASSISTANCE

►  If the vehicle breaks down, press button

2



for more than 2 seconds to request assistance

(confirmed by a voice message*).

►  Pressing again immediately cancels the

request.

Privacy mode allows you to manage the

level of sharing (data and/or location)

between your vehicle and CITROËN.

It can be configured in the

Settings

 touch

screen application.

If you purchased your vehicle outside the

CITROËN dealer network, you are

invited to have a dealer check the

configuration of these services and, if desired,

modify it as required. In a multilingual country,

services can be configured to use the official

national language of your choice.

For technical reasons and in particular to

improve the quality of telemetry services

provided to customers, the Manufacturer

reserves the right to carry out updates to the

vehicle's on-board telemetry system at any

time.

* According to the geographic coverage of the ‘eCall (SOS)’ and the ‘ASSISTANCE’ functions and the official national language chosen by the owner of the

vehicle.

The list of countries covered and telematic services provided is available from dealers or on the website for your country.

When a vehicle's on-board telemetry

system is being updated, the

ASSISTANCE function is not available.

If you benefit from the Citroën Connect

Box offer with the SOS and Assistance

Pack included, there are additional services

available to you in your personal space, via

the website for your country.

For information about the SOS and

Assistance Pack, please refer to the general

conditions for these services.

Electronic stability control

(ESC)

The electronic stability control programme

includes the following systems:

–  Anti-lock braking system (ABS) and Electronic

brake force distribution (EBFD).

–  Emergency braking assistance (EBA).

–  Automatic post-collision braking (APCB).

–  Anti-slip regulation (ASR).

–  Dynamic stability control (DSC).

–  Trailer stability assist (TSA).

Anti-lock braking system

(ABS)/Electronic brake force

distribution (EBFD)

These systems enhance the vehicle’s stability

and handling during braking, and enable greater

control while cornering, particularly on poor or

slippery road surfaces.

ABS prevents wheel locking in the event of

emergency braking.

Electronic brake force distribution (EBFD)

manages overall braking pressure on each

individual wheel.

►

When braking in an emergency, depress

the pedal very firmly and maintain this

pressure.

The normal operation of the ABS may

result in slight vibrations in the brake

pedal.

This warning lamp comes on fixed in the

event of an ABS malfunction.

The vehicle retains conventional braking. Drive

carefully at a moderate speed.

Have it checked by a CITROËN dealer or a

qualified workshop.

This warning lamp, when lit together with

the

STOP

 and ABS warning lamps,

73

Safety

5

accompanied by a message and an audible

signal, indicates an EBFD malfunction.

You must stop the vehicle.

Stop as soon as it is safe to do so and switch off

the ignition.

Contact a CITROËN dealer or a qualified

workshop.

When changing wheels (tyres and rims),

ensure that these are approved for your

vehicle.

After an impact

Have it checked by a CITROËN dealer or

a qualified workshop.

Emergency braking

assistance (EBA)

This system reduces the emergency stopping

distance, by optimising the braking pressure.

It is triggered in relation to the speed at which

the brake pedal is depressed. The effect of this

is a reduction in the resistance of the pedal and

an increase in braking efficiency.

Post Collision Safety Brake

(APCB)

If an accident is detected, the vehicle initiates

automatic post collision braking. The goal of this

system is to reduce the risk of further collisions if

the driver does not react.

The system is not operational if the capability of

the vehicle to trigger and execute the automatic

post collision braking is not available, as it can

occur in destructive accidents or in other specific

accident scenarios.

It is possible to override the automatic braking by

pressing the brake pedal or accelerator pedal.

Operating conditions

The system operates, if the following conditions

are met:

–  Airbags or pyrotechnic seat belt pretensioners

have been deployed by the collision.

–  Braking systems and electric functions remain

continuously operational during and after

collision.

–  Driver has not depressed the brake or

accelerator pedal.

Malfunction

In the event of a

malfunction, one of these

warning lamps will come on fixed on the

instrument panel, accompanied by the Service

warning lamp, the display of a message and an

audible signal.

Visit a CITROËN dealer or a qualified workshop.

Anti-slip regulation (ASR)

/ Dynamic stability control

(DSC)

Anti-slip regulation (or traction control) optimises

traction by using engine braking and by applying

the brakes on the driving wheels to avoid one

or more wheels spinning. It also enhances the

vehicle's directional stability.

If there is a difference between the vehicle’s

trajectory and the path desired by the driver, the

dynamic stability control system automatically

uses engine braking and the brakes on one or

more wheels to return the vehicle to the desired

path, within the limits of the laws of physics.

These systems are activated automatically every

time the vehicle is started.

These systems are activated in the event

of a problem with grip or trajectory

(confirmed by this warning lamp flashing on the

instrument panel).

Deactivation/Reactivation

In exceptional conditions (e.g. moving a vehicle

that is bogged down in mud, stuck in snow, on

loose soil), it may prove useful to deactivate the

DSC/ASR systems, so that the wheels can move

freely and regain grip.

Reactivate the system as soon as the level of

grip permits.

It is configured in the

ADAS

 touch screen

application.

74

Safety

Deactivation/reactivation is confirmed by

the lighting/switching off of this indicator

lamp on the instrument panel and the display of

a message.

The ASR system is reactivated automatically

every time the ignition is switched on or at

speeds over 31 mph (50 km/h).

Reactivation is manual below 31 mph (50 km/h).

Malfunction

In the event of a malfunction, this warning

lamp lights up on the instrument panel,

accompanied by the display of a message and

an audible signal.

Have it checked by a CITROËN dealer or a

qualified workshop.

ASR/DSC

These systems enhance safety during

normal driving, but should not encourage

the driver to take extra risks or drive at high

speed.

It is in conditions of reduced grip (rain, snow,

ice) that the risk of loss of grip increases. It

is therefore important for your safety to keep

these systems activated in all conditions, and

particularly in difficult conditions.

Correct operation of these systems depends

on compliance with the manufacturer's

recommendations relating to the wheels

(tyres and rims), braking and electronic

components, as well as the assembly and

repair procedures provided by CITROËN

dealers.

In order to ensure that these systems remain

effective in wintry conditions, the use of snow

or all-season tyres is recommended. All four

wheels must be fitted with tyres approved for

your vehicle.

All tyre specifications are listed on the

tyre/paint label. For more information

on

Identification markings

, refer to the

corresponding section.

Trailer stability assist (TSA)

When towing, this system reduces the risk of the

vehicle or trailer snaking.

Operation

The system is activated automatically when the

ignition is switched on.

The electronic stability control system (ESC)

must not have any faults.

The vehicle speed must be between 37 and 99

mph (60 and 160 km/h).

If the system detects that the trailer is

snaking, it applies the brakes to stabilise

the trailer and reduces engine power, if

necessary, to slow the vehicle (indicated by the

flashing of this warning lamp on the instrument

panel and the brake lamps coming on).

For information on weights and towed loads,

refer to the

Engine technical data and towed

loads

 section or your vehicle’s registration

certificate.

To ensure safe driving with a

Towing device

,

refer to the corresponding section.

Malfunction

If a fault occurs, this warning lamp lights

up on the instrument panel, accompanied

by a message and an audible signal.

To continue towing a trailer, reduce speed and

drive carefully!

Have it checked by a CITROËN dealer or a

qualified workshop.

The trailer stability control system

provides an extra safety feature under

normal driving conditions, when following the

recommendations for use of trailers and

current legislation in force in your country. It

must not encourage the driver to take extra

risks, such as using a trailer in unsuitable

conditions of operation (e.g. excessive load,

exceeded nose weight, worn or under-inflated

tyres, faulty braking system) or driving at

excessive speed.

In certain cases, the system may not detect

trailer snaking, particularly with a light trailer.

When driving on slippery or poor surfaces, the

system may not be able to prevent sudden

trailer snaking.

75

Safety

5

Seat belts

Inertia reel

The seat belts are equipped with an inertia reel

which allows the strap length to automatically

adjust to your shape. The seat belt returns to its

storage automatically when it is not used.

The inertia reels are fitted with a device which

automatically locks the strap in the event of a

collision, emergency braking or if the vehicle rolls

over. It can be released by pulling the strap firmly

and then releasing it so that it reels in slightly.

Pyrotechnic pretensioning

This system improves safety in the event of a

frontal or side impact.

Depending on the severity of the impact, the

pyrotechnic pretensioning system instantly

tightens the seat belts against the body of the

occupants.

The pyrotechnic pretensioning seat belts are

enabled when the ignition is on.

Force limiting system

This system reduces the pressure of the seat

belt on the chest of the occupant, thus improving

their protection.

In the event of an impact

Depending on the nature and

seriousness of the impacts, the pyrotechnic

device may trigger before and independently

of airbag deployment. Deployment of the

pretensioners is accompanied by a slight

discharge of harmless smoke and a noise,

due to the activation of the pyrotechnic

cartridge incorporated in the system.

In all cases, the airbag warning lamp comes

on.

Following an impact, have the seat belt

system checked, and if necessary replaced,

by a CITROËN dealer or a qualified

workshop.

Front seat belts

The front seat belts are fitted with a pyrotechnic

pretensioning system and a force limiting

system.

Rear seat belts





Each of the rear seats has a three-point seat belt

with inertia reel.

The outer seats are fitted with a pyrotechnic

pretensioning and force limiting system.

Fastening

►  Pull the strap, then insert the tongue into the

buckle.

►  Check that the seat belt is fastened correctly

by pulling on the strap.

Unfastening

►  Press the red button on the buckle.

►  Guide the seat belt as it is reeled in.

Seat belt not fastened/

unfastened alerts









1.

Front left seat belt warning lamp

2.

Front right seat belt warning lamp

3.

Rear left seat belt warning lamp

4.

Rear centre seat belt warning lamp

5.

Rear right seat belt warning lamp

Not fastened/unfastened warning lamp

It comes on in red on both the instrument panel

and on the seat belts warning lamps display as

soon as the system detects that a seat belt is not

fastened or has been unfastened.

76

Safety

Front seat belt not fastened alert

When the ignition is switched on, if the

driver or front passenger has not fastened their

seat belt, the corresponding warning lamp (

1

 or

2

) comes on in red. At a speed greater than 12

mph (20 km/h), the warning lamp flashes red,

accompanied by an audible signal for around 2

minutes. After this time has elapsed, the warning

lamp remains on fixed in red until the seat belt is

fastened.

Rear seat belt not fastened alert

When the ignition is switched on, if one of

the rear passengers has not fastened their seat

belt, the corresponding warning lamp (

3

,

4

 or

5

)

comes on in red for 1 minute.

Seat belt unfastened alert

After the ignition is switched on, if the

driver or a passenger unfastens their seat belt,

the corresponding warning lamp (

1

,

2

,

3

,

4

 or

5

) comes on in red. At a speed greater than

12 mph (20 km/h), the warning lamp flashes,

accompanied by an audible signal for around 2

minutes. After this time has elapsed, the warning

lamp remains on until the seat belt has been

fastened again.

With the ignition on, if the driver or a

passenger fastens their seat belt, the

corresponding warning lamp (

1

,

2

,

3

,

4

 or

5

)

comes on in green on the display.

With the ignition on, if one of the front or

rear passenger seats is detected as being

unoccupied, the corresponding warning lamp (

2

,

3

,

4

 or

5

) comes on in grey on the display.

When there are no longer any not fastened/

unfastened alerts, the green or grey warning

lamps remain on for around 30 seconds, then

go off.

Advice

The driver must ensure that passengers

use the seat belts correctly and that they

are all fastened before setting off.

Wherever seated in the vehicle, you must

always fasten the seat belt, even for short

journeys.

Do not invert the seat belt buckles, as they

will not fulfil their role properly.

To ensure the proper functioning of the belt

buckles, make sure that there are no foreign

bodies present (e.g. a coin) before fastening.

Before and after use, ensure that the seat belt

is reeled in correctly.

After folding or moving a seat or rear bench

seat, ensure that the seat belt is positioned

and reeled in correctly.

Installation

The lower part of the strap must be

positioned as low as possible over the pelvis.

The upper part must be positioned in the

hollow of the shoulder.

In order to be effective, a seat belt must:

–  be tightened as close to the body as

possible.

–  be pulled in front of you with a smooth

movement, ensuring that it is not twisted.

–  only be used to secure one person.

–  not show signs of tearing or fraying.

–  not be changed or modified, in order to

avoid affecting its performance.

Recommendations for children

Use a suitable child seat if the passenger

is less than 12 years old or shorter than 1.5

metres.

Never use the same seat belt to secure more

than one child.

Never carry a child on your lap.

For more information on

Child seats

, refer to

the corresponding section.

Maintenance

In accordance with current safety

regulations, for all work on your vehicle's

seat belts, contact a qualified workshop with

the skills and equipment needed, which a

CITROËN dealer is able to provide.

Have the seat belts checked regularly by a

CITROËN dealer or a qualified workshop,

particularly if the straps show signs of

damage.

Clean the seat belt straps with soapy water or

a textile cleaning product, sold by CITROËN

dealers.

77

Safety

5

Airbags

General information

System designed to help improve the safety

of the occupants sitting in the front seats and

the rear outer seats, in the event of a violent

collision. The airbags supplement the action

of the seat belts equipped with a force limiting

system.

Electronic detectors record and analyse the

front and side impacts sustained in the impact

detection zones:

–  In the event of violent impact, the airbags

deploy instantly and help better protect the

occupants of the vehicle; immediately after the

impact, the airbags deflate rapidly in order not

to hinder the visibility or the possible exit of the

occupants.

–  In the event of a slight impact, a rear impact

and under certain rollover conditions, the airbags

may not deploy; only the seat belt helps to

protect you in these situations.

The seriousness of the impact depends on the

nature of the obstacle and the speed of the

vehicle at the moment of collision.

The airbags do not operate when the

ignition is switched off.

This equipment will only deploy once. If a

second impact occurs (during the same or a

* For more information on Deactivating the front passenger airbag, refer to the corresponding section.

subsequent accident), the airbag will not be

deployed again.

Impact detection zones

A.

Front impact zone

B.

Side impact zone

When one or more airbags are deployed,

the detonation of the pyrotechnic charge

incorporated in the system makes a noise and

releases a small quantity of smoke.

This smoke is not harmful, but sensitive

individuals may experience irritation.

The detonation noise associated with the

deployment of one or more airbags may result

in a slight loss of hearing for a short time.

Front airbags





System that protects the driver and front

passenger in the event of a serious front impact,

limiting the risk of head and chest injury.

The driver's airbag is fitted in the centre of the

steering wheel; the front passenger airbag is

fitted in the dashboard above the glove box.

Deployment

They deploy, except the front passenger airbag

if it is deactivated*, in the event of a serious front

impact to all or part of the front impact zone

A

.

The front airbag inflates between the thorax and

head of the front occupant of the vehicle and the

steering wheel, driver's side, and the dashboard,

passenger's side, to cushion their forward

movement.

78

Safety

Lateral airbags

In the event of a serious side impact, this system

protects the driver and front passenger to

mitigate the risk of injury to the chest, between

the hip and the shoulder.

Each lateral airbag is fitted in the seat backrest

frame, on the door side.

Deployment

The lateral airbags are deployed on one side in

the event of a serious side impact applied to all

or part of the side impact zone

B

.

The lateral airbag inflates between the chest of

the vehicle's occupant and the corresponding

door panel.

Curtain airbags

System contributing towards greater protection

for the driver and passengers (with the exception

of the rear centre passenger) in the event of a

serious side impact in order to limit the risk of

injury to the side of the head.

Each curtain airbag is built into the pillars and

the upper passenger compartment area.

Deployment

It deploys simultaneously with the corresponding

lateral airbag in the event of a serious side

impact applied to all or part of the side impact

zone

B

.

The curtain airbag inflates between the front

and rear occupants of the vehicle and the

corresponding windows.

Malfunction

In the event of a malfunction,

these warning lamps light up on

the instrument panel. Contact a CITROËN dealer

or a qualified workshop to have the system

checked.

The airbags may not be deployed in the event of

a serious impact.

In the event of a minor impact or bump at

the side of the vehicle or if the vehicle

rolls over, the airbags may not be deployed.

In the event of a rear or front collision, none of

the lateral airbags are deployed.

Advice

For the airbags to be fully effective,

observe the safety recommendations

below.

Adopt a normal and upright sitting position.

Fasten your seat belt and position it correctly.

Do not place anything between the occupants

and the airbags (e.g. child, animal, object), do

not fix or attach anything near or in the path of

the airbags, as this could cause injuries when

they are deployed.

Never modify the original definition of the

vehicle, particularly in the area directly around

the airbags.

Even if all of the precautions mentioned are

observed, a risk of injury or of minor burns to

the head, chest or arms cannot be ruled out

when an airbag is deployed. The bag inflates

almost instantly (within a few milliseconds)

then deflates within the same time,

discharging the hot gas via openings provided

for this purpose.

After an accident or if the vehicle has been

stolen, have the airbag systems checked.

All work must be carried out only by a

CITROËN dealer or a qualified workshop

Front airbags

Do not drive holding the steering wheel

by its spokes or resting your hands on the

centre part of the wheel.

Passengers must not place their feet on the

dashboard.

Do not smoke as deployment of the airbags

can cause burns or the risk of injury from a

cigarette or pipe.

Never remove or pierce the steering wheel or

hit it violently.

Do not fix or attach anything to the steering

wheel or dashboard, as this could cause

injuries when the airbags are deployed.

79

Safety

5

Lateral airbags

Use only approved seat covers

compatible with the deployment of these

airbags. For information on the range of seat

covers suitable for your vehicle, contact a

CITROËN dealer.

Do not fix or attach anything to the seat

backrests (e.g. clothing) as this could cause

injuries to the chest or arm when the airbag is

deployed.

Do not sit with the upper part of the body any

nearer to the door than necessary.

The vehicle's front door panels include side

impact sensors.

A damaged door or any unauthorised or

incorrectly executed work (modification or

repair) on the front doors or their interior trim

could compromise the operation of these

sensors - risk of malfunction of the lateral

airbags!

All work must be carried out only by a

CITROËN dealer or a qualified workshop

Curtain airbags

Do not fix or attach anything to the roof,

as this could cause head injuries when the

curtain airbag is deployed.

Do not remove the grab handles installed on

the roof.

Active bonnet

(Depending on version.)





The active bonnet has been designed to

optimise the safety of pedestrians in the event of

collision with the front of the vehicle.

The pyrotechnic system is triggered at the

hinges of the bonnet to lift it, when the sensors

located at the front of the vehicle detect a

collision.

Deployment of the active bonnet is

accompanied by a slight discharge of

harmless smoke and a noise, due to the

activation of the pyrotechnic cartridge

incorporated in the system. The airbag

warning lamp comes on.

After triggering, do not try to open or close

the bonnet. Call a towing company or go to

the nearest CITROËN dealer or qualified

workshop, driving at a speed below 19 mph

(30 km/h).

Make sure that you adjust the height of the

driver's seat - risk of hindrance to visibility!

This equipment will only trigger once. If a

second impact occurs (during the same

or a subsequent accident), the active bonnet

will not trigger.

After an accident or if the vehicle has been

stolen, have the system checked.

Do not tamper with the pyrotechnic systems

under the bonnet, close to the struts - risk of

explosion!

All work must be carried out only by a

CITROËN dealer or a qualified workshop

Malfunction

In the event of a malfunction, this warning

lamp lights up on the instrument panel,

accompanied by the display of a message and

an audible signal. You must contact a CITROËN

dealer or a qualified workshop to have the

system checked.

The active bonnet may not deploy in the event of

an impact.

Child seats

The legislation on carrying children is

specific to each country. Refer to the

legislation in force in your country.

80

Safety

For maximum safety, please observe the

following recommendations:

–  In accordance with European regulations,

all

children under the age of 12 or less than one

and a half metres tall must travel in approved

child seats suited to their weight

, on seats

fitted with a seat belt or ISOFIX mountings.

–

Statistically, the safest seats in your

vehicle for carrying children are the rear

seats.

–

A child weighing less than 9 kg must travel

in the "rearward facing" position both in the

front and in the rear.

It is recommended

 that children travel

on the

rear seats

 of the vehicle:

– "

rearward facing

" up to the age of 3,

– "

forward facing

" over the age of 3.

Make sure that the seat belt is correctly

positioned and tightened.

For child seats with a support leg, ensure that

the support leg is in firm and steady contact

with the floor.

Advice

An incorrectly installed child seat

compromises the child's safety in the

event of an accident.

Ensure that there is no seat belt or seat belt

buckle under the child seat, as this could

destabilise it.

Remember to fasten the seat belts or the

harness of child seats, keeping the slack

relative to the child's body to a minimum,

even for short journeys.

When installing a child seat using the seat

belt, ensure that the seat belt is tightened

correctly on the child seat and that it secures

the child seat firmly on the seat of the vehicle.

If the passenger seat is adjustable, move it

forwards if necessary.

Remove the head restraint before

installing a child seat with a backrest on a

passenger seat.

Ensure that the head restraint is stored or

attached securely to prevent it from being

thrown around the vehicle in the event of

sharp braking. Refit the head restraint once

the child seat has been removed.

Installing a booster seat

The chest part of the seat belt must be

positioned on the child's shoulder without

touching the neck.

Ensure that the lap part of the seat belt

passes correctly over the child's thighs.

Use a booster seat with backrest, equipped

with a belt guide at shoulder level.

Additional protections

To prevent accidental opening of the

doors and rear windows, use the "Child lock".

Take care not to open the rear windows by

more than one third.

To protect young children from the rays of the

sun, fit side blinds on the rear windows.

As a safety precaution, do not leave:

–  a child alone and unattended in a vehicle,

–  a child or an animal in a vehicle which is

exposed to the sun, with the windows closed,

–  the keys within reach of children inside the

vehicle.

Child seat at the rear

Forward-facing or rearward-facing









►  Move the vehicle's front seat forward and

straighten the backrest so that the legs of the

child in the forward-facing or rearward-facing

child seat itself do not touch the vehicle's front

seat.

►  Check that the backrest of the forward-facing

child seat is as close as possible to the backrest

of the vehicle's rear seat, and ideally in contact

with it.

81

Safety

5

Centre rear seat

A child seat with a support leg must never be

installed on the

centre rear passenger seat

.

Child seat at the front





►  Adjust the front passenger seat to the

highest

 and

fully back longitudinal position

,

with the backrest straightened

.

"Forward facing"





You must leave the front passenger

airbag active.

"Rearward facing"





To ensure the safety of the child, the front

passenger airbag MUST be deactivated

when a "rearward facing" child seat is

installed on the front passenger seat.

Otherwise, the child risks being seriously

injured or killed in the event of deployment of

the airbag.

Vehicles not equipped with a

deactivation/reactivation control

Installing a "rearward facing" child seat on

the front passenger seat is strictly prohibited

- risk of death or serious injury in the event of

airbag deployment!





Warning label - Front passenger airbag





You must comply with the following instruction,

as reminded by the warning label on both sides

of the passenger sun visor:

NEVER use a rearward facing child restraint

on a seat protected by an ACTIVE AIRBAG in

front of it, DEATH or SERIOUS INJURY to the

CHILD can occur.

Deactivating the front

passenger airbag

(Depending on version.)





Passenger airbag OFF

Deactivating/Reactivating the front

passenger airbag

For vehicles on which it is fitted, the switch is

located inside the glove box.
