162

Driving

Adaptive cruise control

Refer to the

General recommendations

on the use of driving and

manoeuvring aids

 and to

Cruise control

- particular recommendations

.

This system

automatically

 maintains the

speed of your vehicle at a value which

you set (speed setting), while keeping a safe

distance from the vehicle in front (target vehicle),

and which has been set beforehand by the

driver. The system controls the vehicle's

acceleration and deceleration automatically

using only engine braking (as if the driver had

pressed the "-" minus button).





To do this, it uses a radar located in the front

bumper.

Primarily designed for driving on main

roads and motorways, this system only

works with moving vehicles driving in the

same direction as your vehicle.

If the driver operates a direction indicator

to overtake a slower vehicle, the cruise

control allows the vehicle to temporarily

approach the vehicle in front to assist the

overtaking manoeuvre, without ever

exceeding the speed setting.

Some vehicles present on the road may

not be properly seen or may be

misinterpreted by the radar (e.g. a lorry),

which may lead to a poor assessment of

distance and lead to the vehicle accelerating

or braking inappropriately.

Steering-mounted controls

1.

ON (

CRUISE

 position)/OFF (position

0

)

2.

Activation of cruise control at the current

speed/decrease speed setting

3.

Activation of cruise control at the current

speed/increase speed setting

4.

Pause/resume cruise control with the speed

setting previously saved

5.

Depending on version:

Display the speed thresholds saved using the

Memorising speeds function

or

Use the speed suggested by the Road signs

recognition function (

MEM

 display)

6.

Display and adjustment of the distance

setting to the vehicle in front

Use

Activating the system (paused)

The adaptive cruise control must be selected in

the "

Driving/Vehicle

" menu.

►  Turn the knob

1

 downwards into the

CRUISE



position with the engine running. The cruise

control is ready for operation.

Starting cruise control and selecting a

speed

The vehicle speed must be between 25 and

93 mph (40 and 150 km/h).

With a manual gearbox, third or fourth gear or

higher must be engaged.

With an automatic gearbox, mode

D

 or second

gear or higher in mode

M

 must be engaged.

With a drive selector, mode

D

 or

B

 must be

engaged.

If the speed setting is above 93 mph

(150 km/h), the adaptive cruise control

switches to standard cruise control mode

163

Driving

6

(without automatic regulation of the inter-

vehicle safety distance).

►  Press buttons

2-SET-

 or

3-SET+

: the current

speed becomes the speed setting (minimum

25 mph (40 km/h)) and the cruise control is

immediately activated.

►  Press

3

 to increase or

2

to decrease the

speed setting (in steps of 5 mph (5 km/h) if the

button is kept depressed).

Pressing and holding either button

2-SET-

 or

3-SET+

 results in a rapid

change in the speed of the vehicle.

Pausing/resuming cruise control

►  Press

4-II

 or depress the

brake pedal

. To

pause cruise control, it is also possible to:

•  Shift from mode

D

 to

N

,

•  Depress the clutch pedal for more than 10

seconds.

•  Press the electric parking brake control.

►  Press

4-II

 to restart cruise control. Cruise

control may have been paused automatically:

•  When the inter-vehicle distance threshold is

reached.

•  When the distance between your vehicle and

the one in front becomes too short.

•  When the vehicle starts moving too slowly or

the vehicle in front starts moving too slowly.

•  When the ESC system is triggered.

When the driver attempts to reactivate

cruise control, after the function has been

paused, the message "Activation not possible,

unsuitable conditions" is briefly displayed if

reactivation is not possible (safety conditions

not met).

Using the Road signs recognition function

or speed limit sign memorisation to

modify the speed setting.

►  Press

5-MEM

 to accept the speed setting

proposed by the system on the instrument panel

or touch screen, then press again to confirm.

To prevent any sudden acceleration or

deceleration of the vehicle, select a

speed setting fairly close to the current speed

of your vehicle.

Changing the inter-vehicle distance

►  Press

6

 to display the distance setting

thresholds ("Distant", "Normal" or "Close"), then

press again to select a threshold.

After a few seconds, the option is accepted and

will be memorised when the ignition is switched

off.

Temporarily exceeding the speed setting

►  Depress the accelerator pedal. Distance

monitoring and cruise control are deactivated as

long as you continue to accelerate. The speed

on the instrument panel flashes.

Deactivating the system

►  Turn the knob

1

 upwards into position

0



(

OFF

).

Information displayed on

the instrument panel









Head-up display

7.

Cruise control pause/resume indication.

8.

Indication of selection of cruise control mode,

or vehicle speed adjustment phase.

9.

Speed setting value.

164

Driving

For more information on the

Head-up

display

, refer to the corresponding

section.

Messages and alerts

The display of these messages or alerts

is not sequential.

“Cruise control paused” or “Cruise control

suspended” following a brief acceleration

by the driver.

“Cruise control active”, no vehicle

detected.

“Cruise control active”, vehicle detected.

“Cruise control active and speed

adjusted”, vehicle detected too close or at

a slower speed.

“Cruise control active and speed

adjusted”, automatic deactivation

imminent following a cruise control limit being

reached.

“Cruise control paused”, automatic

deactivation following speed limit

adjustment being exceeded and no reaction from

the driver.

Operating limits

The regulation range is limited to a maximum

difference of 19 mph (30 km/h) between the

cruise speed setting and the speed of the

vehicle in front.

Above this, the system pauses itself if the safety

distance becomes too short.

The adaptive cruise control uses only engine

braking to slow the vehicle. Consequently the

vehicle loses speed slowly, as when releasing

the accelerator pedal.

The system is paused automatically:

–  if the vehicle in front slows down too much or

too suddenly, and the driver does not brake,

–  if a vehicle comes between your vehicle and

the vehicle in front,

–  if the system does not slow the vehicle enough

to continue to maintain a safe distance, for

example when descending a steep hill.

Cases of non-detection by the radar:

–  Stationary vehicles (traffic jam, breakdown,

etc.).

–  Vehicles driving in the opposite direction.

When the driver must suspend the cruise

control system:





–  When following a narrow vehicle.





–  Vehicles not running in the middle of the lane.





–  Vehicles entering a corner.

–  Vehicles changing lane at the last moment.

Reactivate cruise control when conditions permit.

Cases where the driver is urged to take back

control immediately:

–  When a vehicle cuts in sharply between your

vehicle and the one in front.

–  Excessively sharp deceleration of the vehicle

in front of you.

The adaptive cruise control operates by

day and night, in fog or moderate rainfall.

The system does not act on the braking

system, but works only with engine

braking.

The regulation range is limited: there will

no longer be any adjustment of speed if the

difference between the programmed speed

165

Driving

6

setting and the speed of the vehicle in front

becomes too great.

If the difference between the

programmed speed setting and the

speed of the vehicle in front is too great, the

speed cannot be adjusted: the cruise control

is automatically deactivated.

Malfunction

In the event of a malfunction with the adaptive

cruise control, you will be alerted by an audible

signal and the display of the message "Driving

aid functions fault".

Have it checked by a CITROËN dealer or a

qualified workshop.

Active Safety Brake with

Collision Risk Alert and

Intelligent emergency

braking assistance

For more information, refer to the

General recommendations on the use

of driving and manoeuvring aids

.





This system:

–  warns the driver that their vehicle is at risk of

collision with the preceding vehicle.

–  reduces the vehicle's speed to avoid a

collision or to limit its severity.

The speed will be reduced by a

maximum of 16 mph (25 km/h) (versions

with camera only) or by a maximum of 31

mph (50 km/h) (versions with camera and

radar).

The system also takes motorcyclists into

account.

It may also react on animals. Animals

(especially animals smaller than 0.5 m)

and objects on the road are not necessarily

detected.

This system includes three functions:

–  Collision Risk Alert.

–  Intelligent emergency braking assistance

(iEBA).

–  Active Safety Brake (automatic emergency

braking).





The vehicle has a camera located at the top of

the windscreen and, depending on version, a

radar located in the front bumper.

This system does not replace the need

for vigilance on the part of the driver.

This system is designed to assist the driver

and improve road safety.

It is the driver's responsibility to continuously

monitor traffic conditions in accordance with

applicable driving regulations.

As soon as the system detects a

potential obstacle, it prepares the braking

circuit in case automatic braking is needed.

This may cause a slight noise and a slight

sensation of deceleration.

Operating conditions and

limits

Vehicle moving forward without trailer.

166

Driving

Brake system operational.

Seat belts fastened for all passengers.

Stabilised speed on roads with no or low

curvature.

This warning lamp lights up on the

instrument panel without any additional

message, to indicate that the automatic braking

system is not available.

This is a normal behavior indicating that a

condition is not fulfilled and which does not

request the support of a workshop.

In any situations with ignition on where automatic

braking presents a risk, deactivating the

system via the vehicle's configuration menu is

recommended, for instance:

–  Towing a trailer (particularly a trailer without its

own braking system).

–  Carrying long objects on roof bars or roof rack.

–  Driving with snow chains.

–  Using an automatic car wash.

–  Performing any maintenance (e.g. changing a

wheel, working inside the engine compartment).

–  Placing the vehicle on a rolling bench in a

workshop.

–  Towing the vehicle.

–  Following a front bumper deformation.

–  Following an impact to the windscreen close to

the detection camera.

The system diagnoses permanently its

capability and may inhibit itself without

specific driver indication, if the system is

outside of the regular operating conditions

(e.g. sensor initialization, board voltage out of

regular range, activation of stability system).

Therefore, the system may not be available

just after starting the vehicle.

It can be dangerous to drive if the brake

lamps are not in perfect working order.

The driver must not overload the vehicle

(keep within the GVW limit and load

height limits for roof bars).

Following an impact (e.g.  a collision), the

system is automatically deactivated.

Have it checked by a CITROËN dealer or a

qualified workshop.

Collision Risk Alert

This function warns the driver if there is a risk

of collision with the preceding vehicle, or with a

pedestrian or cyclist.

Modifying the alert trigger threshold

This trigger threshold determines the sensitivity

with which the function warns of the risk of

collision.

The threshold is set via the vehicle

configuration menu with the audio

system or touch screen.

►  Select one of the three pre-defined

thresholds: "Far", "Normal" or "Close".

The last threshold selected is memorised when

the ignition is switched off.

Operation

Depending on the collision risk detected by the

system and the alert trigger threshold chosen

by the driver, different levels of alert may be

triggered and displayed on the instrument panel.

The system takes into account the vehicle

dynamics, the difference speed of the own

vehicle and the object identified for the

collision risk, and the operation of the vehicle

(e.g. actions on the pedals, steering wheel) to

trigger the alert at the most relevant moment.

(orange)

Level 1

: visual alert only, warning that the

preceding vehicle is very close.

The message "

Vehicle close

" is displayed.

(red)

Level 2

: visual and audible alert, warning

that a collision is imminent.

The message "

Brake!

" is displayed.

While approaching a vehicle too quickly,

the level 2 alert may be displayed

directly.

Important:

 the level 1 alert depends on the

trigger threshold selected. It reacts only on

moving vehicles. It is disabled automatically

at lower speed.

167

Driving

6

It is possible that collision warnings are

not given, are given too late or seem

unjustified.

The driver must always stay in control of the

vehicle and be prepared to react at any time

to avoid an accident.

Intelligent emergency

braking assistance (iEBA)

This function supplements braking in the event

that the driver brakes, but not enough to avoid a

collision.

This assistance will only be provided if the driver

presses the brake pedal.

Active Safety Brake





This function, also called "automatic emergency

braking", intervenes after the acoustic alert if the

driver does not operate the brake pedal quickly

enough.

The system aims at reducing the speed of

impact or avoiding a collision if the driver fails to

react.

The speed will be reduced by a

maximum of 16 mph (25 km/h) (versions

with camera only) or by a maximum of 31

mph (50 km/h) (versions with camera and

radar).

Operation

The system operates subject to the following

conditions:

–  At reduced speed in an urban environment,

when a stationary vehicle, pedestrian or cyclist

is detected.

–  The vehicle's speed is between 6 mph and

53 mph (10 km/h and 85 km/h) (versions with

camera only) or 87 mph (140 km/h) (versions

with camera and radar) when a moving vehicle

is detected.

This warning lamp flashes (for

approximately 10 seconds) as soon as

the function applies the vehicle’s brakes.

During the flashing time, the function is not

available.

With an automatic gearbox, in the event of

automatic emergency braking, keep the brake

pedal depressed, also after a complete stop is

reached, to prevent the vehicle from rolling away.

With a manual gearbox, in the event of automatic

emergency braking bringing the vehicle to a

complete stop, the engine may stall.

The driver can override the automatic

emergency braking at any time by firmly

turning the steering wheel and/or firmly

depressing the accelerator pedal.

168

Driving

The brake pedal may feel hard and

vibrate slightly while the function is

operating.

If the vehicle comes to a complete stop,

automatic braking is maintained for 1 to 2

seconds.

Deactivation/Activation

By default, the system is automatically activated

at every engine start.

The settings are changed via the

vehicle configuration menu.

Deactivation of the system is signalled by

the illumination of this warning lamp,

accompanied by the display of a message.

Malfunction

This warning lamp lights up on the

instrument panel with the message

"

Sensor blind

" in certain cases.

Version with camera only:

 the system is

deactivated.

Version with camera and radar:

 the system

may continue to operate in a degraded mode.

This may be caused by a reduced visibility

(e.g. rain, fog, snow, blinding by low sun) or by

a real sensor blockage. In this case, stop the

vehicle and verify if the front camera or the front

radar is covered by dirt, snow, ice or anything

preventing the sensing.

In the event of a malfunction, this warning

lamp lights up on the instrument panel,

accompanied by the display of a message and

an audible signal.

Have it checked by a CITROËN dealer or a

qualified workshop.

If these warning lamps come on after the

engine has been switched off and then

restarted, contact a CITROËN dealer or a

qualified workshop to have the system checked.

These warning lamps light up on

the instrument panel and/or in the

warning lamp display for seat belts and front

passenger airbag to indicate that the driver's

and/or front passenger's seat belt is not fastened

(depending on version). The automatic braking

system is deactivated until the seat belts are

fastened.

Lane departure warning

system

For more information, refer to the

General recommendations on the use

of driving and manoeuvring aids

.





System that uses a camera to recognise

continuous or broken lines on traffic lanes and

triggers an alert if the vehicle wanders off line.

If the direction indicator is not used at speeds

above 50 mph (80 km/h) and there is a risk of

one of these lines on the road surface being

crossed, the system triggers the alert.

This system is particularly useful on motorways

and main roads.

Detection - Alert

You are alerted

by the flashing of this

warning lamp in the instrument panel,

accompanied by an audible signal.

No warning is transmitted while the

direction indicator is active and for

approximately 20 seconds after the direction

indicator is switched off.

Activation/Deactivation

With audio system









►  To activate or deactivate the system, press

this button.

The indicator lamp is

on

 when the system is

activated

.

169

Driving

6

With touch screen

The settings are changed via the vehicle

configuration menu.

Malfunction

Depending on the vehicle’s equipment:

The indicator lamp in this button flashes.



or

/

The button flashes and a fault

appears.

Contact a CITROËN dealer or a qualified

workshop.

Detection may be impeded:

–  If the markings on the ground are worn

and not clearly contrasted against the road

surface.

–  If the windscreen is dirty.

–  In certain extreme weather conditions:

fog, heavy rain, snow, shade, bright sunlight

or direct exposure to the sun (e.g. low sun,

leaving a tunnel).

Distraction detection

For more information, refer to the

General recommendations on the use

of driving and manoeuvring aids

.

Depending on version, the function consists of

either the "Coffee Break Alert" system alone or

combined with the "Driver Attention Warning"

system.

These systems are in no way designed

to keep the driver awake or to prevent

the driver from falling asleep at the wheel.

It is the driver’s responsibility to stop if feeling

tired.

Take a break if you are feeling tired or at least

every 2 hours.

Activation/Deactivation

This function is set via the vehicle

configuration menu.

The function is activated by default when the

ignition is switched on.

Coffee Break Alert

The system triggers an alert when it

detects that the driver has not taken a

break after two hours of driving at a speed above

43 mph (70 km/h).

This alert is issued via the display of a message

encouraging the driver to take a break,

accompanied by an audible signal.

If the driver does not follow this advice, the alert

is repeated hourly until the vehicle is stopped.

The system resets itself if one of the following

conditions is met:

–  With the engine running, the vehicle has been

stationary for more than 15 minutes.

–  The ignition has been switched off for a few

minutes.

–  The driver's seat belt is unfastened and their

door is opened.

As soon as the speed of the vehicle

drops below 43 mph (70 km/h), the

system goes into standby.

Driving time starts being counted again once

the speed reaches above 43 mph (70 km/h).

Driver Attention Warning

Depending

on version, the Coffee Break Alert

system may be combined with the Driver

Attention Warning system.





The system assesses the driver's level of

alertness, fatigue and distraction by

identifying trajectory changes in relation to the

lane markings.

To do this, the system uses a camera, placed on

the upper part of the windscreen.

170

Driving

This system is particularly suited to fast roads

(speed higher than 43 mph (70 km/h)).

At a first alert level, the driver is warned by the

message "

Be vigilant!

", accompanied by an

audible signal.

After three first-level alerts, the system triggers

a further alert with the message "

Dangerous

driving: take a break

", accompanied by a more

pronounced audible signal.

In certain driving conditions (poor road

surface or strong winds), the system may

give alerts independent of the driver's level of

vigilance.

The following situations may interfere

with the operation of the system or

prevent it from working:

–  lane markings absent, worn, hidden (snow,

mud) or multiple (roadworks);

–  close to the vehicle ahead (lane markings

not detected);

–  roads that are narrow, winding, etc.

Blind spot monitoring

For more information, refer to the

General recommendations on the use

of driving and manoeuvring aids

.





This system warns the driver of a potential

danger posed by the presence of another vehicle

(car, lorry, motorcycle) in the vehicle's blind

spots (areas hidden from the driver's field of

vision) using sensors located on the sides of the

bumpers.





A warning lamp appears in the door mirror on the

side in question:

–

fixed

, immediately, when being overtaken;

–

flashing

, after a delay of about one second,

when overtaking a vehicle slowly, and when the

direction indicator is used.

Operation

Sensors fitted in the

front and rear bumpers

monitor the blind spots.

The alert is given by an orange warning lamp

coming on in the relevant door mirror, as soon as

a vehicle - car, lorry, bicycle - is detected.

The following conditions must be met for this:

–  all vehicles are moving in the same direction

and in adjacent lanes,

–  the speed of your vehicle must be between 7

and 87 mph (12 and 140 km/h),

–  you overtake a vehicle with a speed difference

of less than 6 mph (10 km/h),

–  a vehicle overtakes you with a speed

difference of less than 16 mph (25 km/h),

–  the traffic is flowing normally,

–  overtaking a vehicle over a certain period of

time where the vehicle being overtaken remains

in the blind spot,

–  you are driving on a straight or slightly curved

road,

–  your vehicle is not towing a trailer, a caravan,

etc.



171

Driving

6







No alert will be given in the following situations:

–  in the presence of non-moving objects (parked

vehicles, safety barriers, street lamps, road

signs, etc.),

–  with vehicles moving in the opposite direction,

–  driving on a winding road or sharp bends,

–  when overtaking or being overtaken by a very

long vehicle (lorry, bus, etc.) which is both in the

rear blind spot and present in the driver’s front

field of vision,

–  when overtaking quickly,

–  in very heavy traffic: vehicles detected in

front and behind are confused with a lorry or a

stationary object.

Activation/Deactivation

With audio system









►  To activate or deactivate the system, press

this button.

The indicator lamp is

on

 when the system is

activated

.

With touch screen

The settings are changed via the vehicle

configuration menu.

The system is automatically deactivated

when towing with a towing device

approved by CITROËN.

Malfunction

Depending on the vehicle’s equipment:





In the event of a fault, this or these warning

lamp(s) flash(es).

or

The warning lamp in this button flashes

and a message appears, accompanied by

an audible signal.

Contact a CITROËN dealer or a qualified

workshop.

Parking sensors

For more information, refer to the

General recommendations on the use

of driving and manoeuvring aids

.





172

Driving

This system detects and signals the proximity of

obstacles (e.g. pedestrian, vehicle, tree, barrier)

using sensors located in the bumper.

Rear parking sensors

►  Engage

reverse gear to start the system

(confirmed by an audible signal).

The system is switched off when reverse gear is

disengaged.

Audible assistance





The function signals the presence of obstacles

present within the sensors’ detection zone.

The proximity information is given by an

intermittent audible signal, the frequency of

which increases as the vehicle approaches the

obstacle.

When the distance between the vehicle and

the obstacle becomes less than about thirty

centimetres, the audible signal becomes

continuous.

The sound emitted by the speaker (right or left)

allows you to identify the side on which the

obstacle is located.

Visual assistance









This supplements the audible signal by

displaying bars on the screen that move

progressively nearer to the vehicle (green: more

distant obstacles; yellow: close obstacles; red:

very close obstacles).

When the obstacle is very close, the "Danger"

symbol is displayed on the screen.

Front parking sensors

Supplementing the rear parking sensors, the

front parking sensors are triggered when an

obstacle is detected in front and the speed of the

vehicle is below 6 mph (10 km/h).

Front parking sensor operation is suspended if

the vehicle stops for more than three seconds in

forward gear, if an obstacle is no longer detected

or the vehicle speed exceeds 6 mph (10 km/h).

The sound emitted by the speaker (front

or rear) locates the obstacle relative to

the vehicle, in front or behind it.

Deactivation/Activation

With dashboard button









►  To deactivate or activate the system, press

this button.

The indicator lamp is

on

 when the system is

deactivated

.

Without dashboard button

The settings are changed via the

vehicle configuration menu.

The rear parking sensors system will be

deactivated automatically if a trailer or

bicycle carrier is connected to a towing device

installed in accordance with the

manufacturer's recommendations.

173

Driving

6

Operating limits

If the boot is heavily loaded, the vehicle may tilt,

affecting distance measurements.

Malfunction

In the event of a malfunction when

changing into reverse gear, this warning

lamp lights up on the instrument panel,

accompanied by the display of a message and

an audible signal (short beep).

Have it checked by a CITROËN dealer or a

qualified workshop.

Top Rear Vision

For more information, refer to the

General recommendations on the use

of driving and manoeuvring aids

.





As soon as reverse gear is engaged with the

engine running, this system displays views of

your vehicle’s close surroundings on the touch

screen using a camera located at the rear of the

vehicle.









The screen is divided into two parts with a

contextual view and a view from above the

vehicle in its close surroundings.

The parking sensors supplement the information

on the view from above the vehicle.

Various contextual views may be displayed:

–  Standard view.

–  180° view.

–  Zoom view.

AUTO mode is activated by default.

In this mode, the system chooses the best view

to display (standard or zoom).

You can change the type of view at any time

during a manoeuvre.

The system status is not saved when the ignition

is switched off.

Principle of operation





Using the rear camera, the vehicle's close

surroundings are recorded during manoeuvres

at low speed.

An image from above your vehicle in its close

surroundings is reconstructed (represented

between the brackets) in real time and as the

manoeuvre progresses.

It facilitates the alignment of your vehicle when

parking and allows obstacles close to the vehicle

to be seen. It is automatically deleted if the

vehicle remains stationary for too long.

The display disappears above

approximately 6 mph (10 km/h).

The system is automatically deactivated

about 7 seconds after coming out of reverse

or on opening a door or the boot.

Activation

Activation is automatic on engaging reverse gear

at a speed lower than 6 mph (10 km/h).



174

Driving



You can choose the display mode at any time by

pressing this area.

When the sub-menu is displayed, select one of

the four views:

"Standard view".

"180° view".

"Zoom view".

"AUTO mode".

The function will be deactivated:

–  If a trailer is attached or a bicycle

carrier is fitted on a towing device (vehicle

fitted with a towing device installed in line with

the manufacturer's recommendations).

–  Above about 6 mph (10 km/h).

–  When the boot is opened.

–  Upon changing out of reverse gear (the

image remains displayed for 7 seconds).

–  By pressing the white arrow in the upper-

left corner of the touch screen.

AUTO mode





This mode is activated by default.

Using sensors in the rear bumper, the automatic

view changes from the rear view (standard) to

the view from above (zoom) as an obstacle is

approached at the level of the red line (less than

30 cm) during a manoeuvre.

Standard view





The area behind the vehicle is displayed on the

screen.

The blue lines

1

 represent the width of your

vehicle, with the mirrors unfolded; their direction

changes according to the position of the steering

wheel.

The red line

2

 represents a distance of 30 cm

from the rear bumper; the two blue lines

3

 and

4



represent 1 m and 2 m, respectively.

This view is available with AUTO mode or in the

view selection menu.

Zoom view





The camera records the vehicle's surroundings

during the manoeuvre in order to create a

view from above the rear of the vehicle in its

near surroundings, allowing the vehicle to be

manoeuvred around nearby obstacles.

This view is available with AUTO mode or in the

view selection menu.

175

Driving

6

Obstacles may appear further away than

they actually are.

It is important to monitor the sides of the

vehicle during the manoeuvre, using the

mirrors.

Parking sensors also provide additional

information about the area around the vehicle.

180° view





The 180° view facilitates reversing out of a

parking space, making it possible to see the

approach of vehicles, pedestrians and cyclists.

This view is not recommended for carrying out a

complete manoeuvre.

It features 3 areas: left

A

, centre

B

 and right

C

.

This view is only available via the view selection

menu.

Quick start mode





This mode displays, as quickly as possible, the

contextual view (left-hand part) and the overhead

view of the vehicle.

A message is displayed advising you to check

your vehicle's surroundings before starting the

manoeuvre.







FILL UP WITH

CONFIDENCE



WITH QUARTZ LUBRICANTS

* 1L & 5L produced in Europe

Partners  for  more  than  50  years,  Citroën  &

TotalEnergies share common values: technology,

creativity, innovation. TotalEnergies equips Citroën
vehicles with

Quartz lubricants from their first filling

in the factory to approved maintenance networks to

guarantee them optimal performance on a daily basis.

Especially designed for Citroën vehicles, Quartz

lubricants make them even more powerful, more fuel

efficient and more environmentally friendly. For your

car maintenance, fill up with confidence with Quartz
lubricants !

Keep your engine younger for longer !

Quartz  Ineo  Xtra  First  0W-20  is  a  very  high

performance lubricant resulting from the joint work of

the Citroën and TotalEnergies R&D teams. Its innovative

technology extends your engine’s life while reaching

significant fuel savings and thus limiting CO

2

 emissions.

The product is now available in new packaging* made

of 50% recycled material and 100% recyclable.











177

Practical information

7



FILL UP WITH

CONFIDENCE



WITH QUARTZ LUBRICANTS

* 1L & 5L produced in Europe

Partners  for  more  than  50  years,  Citroën  &

TotalEnergies share common values: technology,

creativity, innovation. TotalEnergies equips Citroën
vehicles with

Quartz lubricants from their first filling

in the factory to approved maintenance networks to

guarantee them optimal performance on a daily basis.

Especially designed for Citroën vehicles, Quartz

lubricants make them even more powerful, more fuel

efficient and more environmentally friendly. For your

car maintenance, fill up with confidence with Quartz
lubricants !

Keep your engine younger for longer !

Quartz  Ineo  Xtra  First  0W-20  is  a  very  high

performance lubricant resulting from the joint work of

the Citroën and TotalEnergies R&D teams. Its innovative

technology extends your engine’s life while reaching

significant fuel savings and thus limiting CO

2

 emissions.

The product is now available in new packaging* made

of 50% recycled material and 100% recyclable.



Compatibility of fuels





Diesel fuels conforming to the EN590, EN16734

and EN16709 standards and containing up to

7%, 10%, 20% and 30% fatty acid methyl ester

respectively. The use of B20 or B30 fuels, even

occasionally, imposes special maintenance

conditions referred to as "Arduous conditions".





Paraffinic Diesel fuel conforming to the EN15940

standard.

The use of any other type of (bio) fuel

(e.g. pure or diluted vegetable or animal

oils, domestic fuel) is strictly prohibited - risk

of damaging the engine and fuel system!

The only Diesel fuel additives authorised

for use are those that meet the B715000

standard.

Diesel at low temperature

At temperatures below 0 °C (+32 °F), the

formation of paraffins in summer-type Diesel

fuels could prevent the engine from operating

correctly. In these temperature conditions, use

winter-type Diesel fuel and keep the fuel tank

more than 50 % full.

At temperatures below -15 °C (+5 °F) to avoid

problems starting, it is best to park the vehicle

under shelter (heated garage).

Travelling abroad

Certain fuels could damage your vehicle’s

engine.

In certain countries, the use of a particular

fuel may be required (specific octane rating,

specific trade name, etc.) to ensure correct

operation of the engine.

For all additional information, consult a dealer.

Refuelling

Fuel tank capacity: approximately 69 litres.

Reserve level: approximately 6 litres.

Low fuel level

When the low fuel level is reached,

one of these warning lamps lights

up on the instrument panel, accompanied by the

display of a message and an audible signal.

When it first comes on,

about 8 litres

 of fuel

remain.

You must refuel as soon as possible to avoid

running out of fuel.

For more information on

Running out of fuel

(Diesel)

, refer to the corresponding section.

A small arrow by the warning lamp

indicates which side of the vehicle the

fuel filler flap is located on.

Stop & Start

Never refuel with the engine in STOP

mode; you must switch off the ignition.

Refuelling

At least 8 litres of fuel must be added, in order to

be registered by the fuel gauge.

Opening the filler cap may create a noise caused

by an inrush of air. This is entirely normal and

results from the sealing of the fuel system.

To refuel in complete safety:

►

Always switch off the engine.

►  Unlock the vehicle using the Keyless Entry

and Start.





►  Open the fuel filler flap.
