130

Safety

IL:

Seat position suitable for the installation

of an

I

sofix Semi-Universa

L

 seat which is

either:

–  "rearward facing" fitted with an upper

strap or a support leg,

–  "forward facing" fitted with a support leg,

–  a carrycot fitted with an upper strap or a

support leg.

X:

Seat position not suitable for the installation

of an ISOFIX child seat or carrycot for the

specified weight group.

(a)

Refer to the current legislation in the country

in which you are driving before placing a

child in this seat position.

(b)

The seat can be installed centrally in the

vehicle; it then prevents the use of the outer

seats.

For information on securing the upper

strap using the

ISOFIX mountings

, refer

to the corresponding section.

(1)

Installing a carrycot on this seat may

prevent the use of one or more of the other

seats in this row.

(2)

Installation possible only behind the driver's

seat.

(3)

Installation possible only behind the driver's

seat with individual passenger seat.

(4)

The seat in row 2 must be adjusted so that

there is no contact between the child in row

3 and the seat immediately in front.

(5)

The front seat must be adjusted so that

there is no contact between the child in row

2 and the seat immediately in front.

(6)

The front seat must be adjusted so that

there is no contact between the child in row

2 and the seat immediately in front (with the

front seat adjusted to 2 notches ahead of

the centre of the slide).

i-Size child seats

i-Size child seats have two latches that are anchored to the two rings

A

.

These i-Size child seats also have:

–  either an upper strap that is attached to ring

B

.

–  or a support leg that rests on the vehicle floor, compatible with the approved i-Size seat position.

Their role is to prevent the child seat from tipping forward in the event of a collision.

For more information on the

ISOFIX mountings

, refer to the corresponding section.

Locations for i-Size child seats

In accordance with the new European regulations, this table indicates the options for installing i-Size child seats on seats in the vehicle fitted with i-Size

approved ISOFIX mountings.

131

Safety

5

Seat

i-Size restraint system





Row 1 (a)





Passenger seat with passenger

airbag deactivated "

OFF

" or

activated "

ON

"

Not i-Size





Row 2

With 2-seat bench seat in row 1





Outer seats

Not i-Size

Centre seat

Not i-Size

With individual seats in row 1





Outer seats

Not i-Size

Centre seat

Not i-Size

Combi

,

Business

,

Feel





Row 2

With 2-seat bench seat in row 1





Fixed one-piece bench seat, outer

seats and centre seat (b)

i-UF





Seat and bench seat, outer seats

and centre seat (b)

i-UF

With individual seats in row 1





Fixed one-piece bench seat, outer

seats and centre seat (b)

i-U





Seat and bench seat, outer seats

and centre seat (b)

i-U

132

Safety

Seat

i-Size restraint system

Combi

,

Business

,

Feel





Row 3





Fixed one-piece bench seat, outer

seats and centre seat (b)

i-U

 (c)





Seat and bench seat, outer seats

and centre seat (b)

i-U

 (c)

Shine

,

Business Lounge





Row 2 and 3





Rear seats with seat and bench

seat

i-U

 (c)





Rear seats with 2 individual seats

i-UF

 (c, d)

(Excluding group 0)





Rear seats with 1 individual seat

i-UF

 (c, d)

(Excluding group 0)

i-U:

Suitable for forward facing and rearward facing "Universal" i-Size restraint systems.

i-UF:

Only suitable for forward facing "Universal" i-Size restraint systems.

(a)

Refer to the current legislation in the country in which you are driving before placing a child in this seat position.

(b)

The seat can be installed centrally in the vehicle; it then prevents the use of the outer seats.

(c)

The seat in row 2 cannot be used when an i-Size child seat is installed immediately behind.

(d)

Install an i-Size child restraint system only if seats are installed in forward direction.

Manual child lock

Mechanical system to prevent opening of the

sliding side door using its interior lever.



133

Safety

5



Locking/Unlocking

►  Rotate the control located on the edge of the

side door

up

 to

lock

 it, or

down

 to

unlock

 it.

Electric child lock

Remote control system to

prevent opening of the rear

doors (sliding side door(s), side-

hinged rear doors or tailgate

(depending on version)) using

their interior controls.

This control prevents the opening of the rear

doors using their interior handles and the use of

the rear electric windows.

Activation/Deactivation









►  With the ignition on, press this button to

activate/deactivate the child lock.

A message is displayed, confirming activation/

deactivation of the child lock.

When the indicator lamp is on, the child lock is

activated.

In the event of a serious impact, the

electric child lock is deactivated

automatically.

Any other status of the indicator lamp

indicates a malfunction of the electric

child lock.

With the child lock activated, it is still

possible to open the doors from outside.

This system is independent and in no

circumstances does it take the place of

the central locking control.

Check the status of the child lock each time

you switch on the ignition.

Always keep the electronic key with you when

leaving the vehicle, even for a short time.

In the event of a serious impact, the electric

child lock is switched off automatically to

permit the exit of the rear passengers.

Child lock on rear

windows

This mechanical system

prevents opening of the left-

hand and/or right-hand rear side

windows.





►  The system is locked/unlocked using the

remote control key or the back-up key for the

Keyless Entry and Start system.

134

Driving

Driving recommendations

►  Observe the driving regulations and remain

vigilant whatever the traffic conditions.

►  Monitor your environment and keep your

hands on the wheel to be able to react to

anything that may happen any time.

►  Drive smoothly, anticipate the need for

braking and maintain a longer safety distance,

especially in bad weather.

►  Stop the vehicle before performing operations

that require sustained attention (e.g. settings).

►  During long trips, take a break every 2 hours.

To ensure the durability of the vehicle and

for safety reasons, remember that certain

precautionary measures must be taken when

driving the vehicle:

Manoeuvre cautiously, at low speed

Manoeuvre slowly.

Before turning, check that there are no obstacles

at mid-height along the sides.

Before reversing, check that there are no

obstacles, particularly at high level behind the

vehicle.

Be aware of the external dimensions, if ladders

are fitted.

Drive the vehicle carefully

Take corners gently.

Anticipate the need to brake as the stopping

distance is increased, particularly on wet or icy

roads.

Be aware of the effect of side winds on the

vehicle.

Maintenance

Inflate to the minimum pressure indicated on the

label, or even over-inflate by 0.2 to 0.3 bar for

long journeys.

Important!

Never leave the engine running in a

closed space without sufficient

ventilation.

 Internal combustion engines emit

toxic exhaust gases such as carbon

monoxide. Danger of poisoning and death!

In very severe wintry conditions

(temperature below -23°C), let the engine

run for 4 minutes before moving off, to ensure

the correct operation and durability of the

mechanical components of your vehicle

(engine and gearbox).

Never drive with the parking brake

applied

. Risk of overheating and

damaging the braking system!

Never park the vehicle and never

leave the engine running on a

flammable surface (e.g. dry grass, dead

leaves).

The vehicle exhaust system is very

hot, even several minutes after the engine

stops. Risk of fire!

Never drive on surfaces covered with

vegetation (e.g. tall grass,

accumulated dead leaves, crops, debris)

such as a field, a country lane overgrown

with bushes or a grassy verge.

This vegetation could come into contact with

the vehicle's exhaust system or other systems

which are very hot. Risk of fire!

Make sure you do not leave any item in

the passenger compartment which could

act like a magnifying glass under the effect of

the sun's rays and cause a fire. Risk of fire or

damage to interior surfaces!

Never leave the vehicle unattended,

with the engine running

. If you have to

leave your vehicle with the engine running,

apply the parking brake and put the gearbox

into neutral or position

N

 or

P

 (depending on

the type of gearbox).

Never leave children inside the vehicle

unsupervised

.

On flooded roads

We strongly advise against driving on flooded

roads, as this could cause serious damage to the

engine or gearbox, as well as to your vehicle's

electrical systems.



135

Driving

6



If the vehicle absolutely must drive through a

flooded section of road:

►  Check that the depth of the water does not

exceed 15 cm, taking account of waves that

might be generated by other users.

►  Deactivate the Stop & Start function.

►  Drive as slowly as possible without stalling. In

all cases, do not exceed 6 mph (10 km/h).

►  Do not stop and do not switch off the engine.

On leaving the flooded road, as soon as safety

conditions allow, make several light brake

applications to dry the brake discs and pads.

If in doubt about the state of your vehicle,

contact a CITROËN dealer or a qualified

workshop.

Noise (Electric)

On the outside

Due to the vehicle’s quiet operation when

driving, the driver must pay particular attention.

When manoeuvring, the driver must always

check the vehicle's immediate surroundings.

At speeds of up to 19 mph (30 km/h), the

pedestrian horn warns other road users of the

vehicle’s presence.

Cooling the traction battery

The cooling fan comes on during

charging to cool the on-board charger and the

traction battery.

On the inside

During use, you may hear certain perfectly

normal noises specific to electric vehicles, such

as:

–  Traction battery relay when starting.

–  Vacuum pump when braking.

–  Vehicle tyres or aerodynamics when driving.

–  Jolting and knocking noise during hill starts.

Towing

Driving with a trailer places greater

demands on the towing vehicle and

particular care must be taken.

Do not exceed the maximum towable

weights.

At altitude:

 reduce the maximum load by

10% per 1,000 metres of altitude; the lower

air density at high altitudes decreases engine

performance.

New vehicle:

 do not tow a trailer until the

vehicle has driven at least 620 miles

(1,000 kilometres).

If the outside temperature is high, let the

engine idle for 1 to 2 minutes after the

vehicle comes to a stop, to help it to cool.

Before setting off

Nose weight

►  Distribute the load in the trailer so that the

heaviest items are located as close as possible

to the axle, and the nose weight (at the point

where it joins your vehicle) approaches the

maximum permitted, without exceeding it.

Tyres

►  Check the tyre pressures of the towing

vehicle and of the trailer, observing the

recommended pressures.

Lighting

►  Check the electrical signalling on the trailer

and the headlamp beam height of your vehicle.

If a genuine CITROËN towing device is

used, the rear parking sensors will be

deactivated automatically to avoid activating

the audible signal.

When driving

Cooling

Towing a trailer uphill causes the coolant

temperature to increase. The maximum towable

load depends on the gradient and the exterior

136

Driving

temperature. The fan’s cooling capacity does not

increase with engine speed.

►  Reduce speed and lower the engine speed to

limit the amount of heating produced.

►  Pay constant attention to the coolant

temperature.

If this warning lamp and the

STOP

 warning lamp come

on, stop the vehicle and switch off the engine as

soon as possible.

Brakes

Using the engine brake is recommended to limit

the overheating of the brakes. Braking distances

are increased when towing a trailer.

Side wind

Bear in mind that the vehicle will be more

susceptible to wind when towing.

Anti-theft protection

Electronic immobiliser

The remote control contains an electronic chip

which has a special code. When the ignition is

switched on, this code must be recognised in

order for starting to be possible.

A few seconds after switching off the ignition,

this system locks the engine control system,

therefore preventing the engine from being

started in the event of a break-in.

In the event of a fault, you are informed

by illumination of this warning lamp, an

audible signal and a message on the screen.

The vehicle will not start; contact a CITROËN

dealer as soon as possible.

Starting/switching off the

engine

Starting

The parking brake must be applied.

►

With a manual gearbox

, place the gear

lever in neutral, fully depress the clutch pedal

and keep the pedal down until the engine starts.

►

With an automatic gearbox

, place the

selector in position

P

 then depress the brake

pedal.

With the conventional key / With the

remote control key

1. Stop

 position.

2. Ignition on

 position.

3. Starting

 position.

►  Insert the key into the ignition switch. The

system recognises the starting code.

►  Unlock the steering column by simultaneously

turning the steering wheel and the key.

In certain circumstances, you may have

to turn the steering wheel firmly to move

the wheels (if the wheels are against a kerb,

for example).

►  Turn the key to position

2

, Ignition On, to

activate the engine pre-heating system.

►  Wait until this warning lamp goes off in

the instrument panel, then turn the key to

position

3

 without pressing the accelerator pedal,

to operate the starter motor until the engine

137

Driving

6

starts. As soon as the engine starts, release the

key so it returns to position

2

.

The warning lamp does not come on if

the engine is already warm. In some

climatic conditions, the following

recommendations should be followed:

–  In mild conditions, do not leave the engine

at idle to warm up but move off straight away

and drive at moderate speed.

–  In wintry conditions, the pre-heater warning

lamp will stay on for a longer period after

switching on the ignition; wait until it goes off

before starting.

– In

very severe wintry

conditions

 (temperature below -23 °C), to

ensure correct operation and durability of your

vehicle’s mechanical components (engine

and gearbox),

leave the engine running for

4 minutes

 before moving off.

Never leave the engine running in an

enclosed area without adequate ventilation:

internal combustion engines emit toxic

exhaust gases, such as carbon monoxide.

Danger of poisoning and death!

If the engine does not start straight away,

switch off the ignition.

Wait a few seconds before operating the

starter motor again. If the engine does not

start after several attempts, do not keep

trying: you risk damaging the starter motor

and the engine.

With the Keyless Entry and Start





►  Place the remote control inside the vehicle, in

the recognition zone.

►  Press the "

START/STOP

" button.

The steering column unlocks and the engine

starts more or less instantly.

The warning lamp does not come on if

the engine is already warm. In some

climatic conditions, it is advised to follow the

recommendations below:

–  In mild conditions, do not leave the engine

to warm up while stationary, but move off

straight away and drive at moderate speed.

–  In wintry conditions, when the ignition is

switched on, the duration of lighting of the

preheating indicator lamp is extended. Wait

until it goes off before starting the engine.

– In

very severe wintry

conditions

 (temperature below -23°C),

to ensure correct operation and preserve

the lifespan of the vehicle's mechanical

components, engine and gearbox,

leave the

engine running for 4 minutes

 before moving

off.

Never leave the engine running in an

enclosed area without adequate ventilation:

internal combustion engines emit toxic

exhaust gases, such as carbon monoxide.

Danger of poisoning and death!

For

Diesel vehicles

, when the

temperature is below zero,

starting will only occur once the pre-heating

warning lamp goes off.

If this warning lamp comes on after pressing

the "START/STOP" button, keep the brake

or clutch pedal depressed until the warning

lamp goes off, without pressing the "START/

STOP" button again, until the engine starts

and is running.

The "Keyless Entry and Start" system

remote control must be within the

recognition zone.

Never leave the vehicle with the engine

running and with the remote control on your

person.

If the remote control leaves the recognition

zone, a message is displayed.

Move the remote control into the zone in

order to be able to start the engine.

If one of the starting conditions is not

met, a message is displayed on the

instrument panel. In some circumstances, you

must turn the steering wheel while pressing

138

Driving

the "START/STOP" button to assist unlocking

of the steering column. A message is

displayed.

Switching off

With the conventional key/With the

remote control key

►  Immobilise the vehicle.

►  Turn the key all the way to position

1 (Stop)



and remove it from the ignition.

►  To lock the steering column, turn the steering

wheel until it locks.

To facilitate unlocking of the steering

column, it is recommended that the

wheels be returned to the straight ahead

position before switching off the engine.

►  Check that the parking brake is correctly

applied, particularly on sloping ground.

Never switch off the ignition before the

complete immobilisation of the vehicle.

With the engine off, the braking and steering

assistance systems are also turned off: risk of

loss of control of the vehicle.

As a safety measure, never leave the

vehicle without taking the remote control

with you, even for a short time.

Avoid attaching heavy objects to the key

or the remote control, which would weigh

down on its blade in the ignition switch and

could cause a malfunction.

Key left in the ignition

When opening the driver's door, an alert

message is displayed, accompanied by

an audible signal, to remind you that the key

is still in the ignition switch at position

1

(Stop)

.

If the key has been left in the ignition switch

at position

2 (Ignition on)

, the ignition will be

switched off automatically after one hour.

To switch the ignition back on, turn the key

to position

1 (Stop)

, then back to position

2

(Ignition on)

.

With Keyless Entry and Start

►  Immobilise the vehicle.

►  With the remote control in the recognition

zone, press the "

START/STOP

" button.

The engine stops and the steering column locks.

If the vehicle is not immobilised, the

engine will not stop.

To avoid any risk of jamming the pedals:

–  only use mats which are suited to the

fixings already present in the vehicle; these

fixings must be used,

–  never place one mat on top of another.

The use of mats not approved by CITROËN

may interfere with access to the pedals and

hinder the operation of the cruise control /

speed limiter.

The mats approved by CITROËN have two

fixings located below the seat.

Starting/Switching off the

electric motor

Starting

The drive selector must be in mode

P

.

►  If using a conventional or remote control

key, depress the brake pedal and turn the key

to position

3

 until the motor starts, without

depressing the accelerator. As soon as the motor

starts, release the key so it returns to position

2

.

►  If using Keyless Entry and Start, depress the

brake pedal and briefly press the "

START/STOP

"

button.

►  Keep your foot on the brake pedal until the

READY

 indicator lamp comes on and an audible

signal is emitted, indicating that the vehicle is

ready to drive.

►  With your foot on the brake, select mode

D



or

R

.

►  Release the brake pedal, then accelerate.

On starting, the instrument panel lights up

and the power indicator needle performs one

sweep then moves to the "neutral" position. The

139

Driving

6

steering column automatically unlocks (you may

hear a sound and feel the steering wheel move).

Switching off

►  If using a conventional or remote control

key, turn the key fully to position

1 (Stop)

.

►  If using Keyless Entry and Start, press the

"

START/STOP

" button.

Before exiting the vehicle, check that:

–  The drive selector is in mode

P

.

– The

READY

 indicator lamp is off.

The drive selector moves automatically

to mode

P

 when the motor is switched off

or when the driver's door is opened.

If the driver's door is opened while the

required conditions for switching off are

not met, an audible signal is emitted,

accompanied by the display of a warning

message.

Special case with Keyless

Entry and Start

Switching on the ignition without

starting the engine

With the "Keyless Entry and Start"

electronic key inside the vehicle, pressing

the "

START/STOP

" button,

without depressing

any of the pedals

, allows the ignition to be

switched on.

►  Press this button again to switch off the

ignition and allow the vehicle to be locked.

Back-up starting

A back-up reader is fitted to the steering column,

to enable the engine to be started if the system

fails to detect the key in the recognition zone, or

if the battery in the electronic key is flat.





►  Place and hold the remote control against the

back-up reader.

►

With a manual gearbox

, place the gear lever

in neutral, then fully depress the clutch pedal.

►

With an automatic gearbox or a drive

selector

, select mode

P

, then depress the brake

pedal.

►  Press the "

START/STOP

" button.

The engine starts.

Remote control not recognised

If the remote control is no longer in the

recognition zone, a message appears on the

instrument panel when closing a door or trying to

switch off the engine.

►  Press the "

START/STOP

" button for about

3 seconds to confirm switching off the engine,

then contact a CITROËN dealer or a qualified

workshop.

Forced switch-off (also called

Back-up switch-off)

In case of emergency only, the engine can be

switched off without conditions (even when

driving).

►  To do this, press and hold the "

START/

STOP

" button for about 5 seconds.

In this case, the steering column locks as soon

as the vehicle stops.

"Key off" mode

"

Key off

" mode allows you to lock the vehicle

while leaving the engine running without the

key or Keyless Entry and Start being inside the

vehicle.

This mode allows electrical devices to continue

operating to ensure thermal comfort, vehicle

security and operation of the vehicle systems

needed for the task.







KEY

OFF



►  To activate or deactivate this mode, press this

button (the button's indicator lamp is on when

the mode is activated).

140

Driving

With an electric motor, this mode remains

active for about 10 minutes after the

vehicle is locked.

Manual parking brake

Application

►  With your foot on the brake pedal, pull

the parking brake lever up to immobilise your

vehicle.

Release on level ground

►  With your foot on the brake pedal, pull the

parking brake lever up gently, press the release

button, then lower the lever fully.

When the vehicle is being driven, this

warning lamp coming on, accompanied

by an audible signal and a message, indicates

that the parking brake is still applied or has not

been fully released.

When parking on a slope or on a steep

slope with a loaded vehicle, turn the

wheels against the kerb then apply the

parking brake.

Pressing the brake pedal facilitates the

application and release of the manual

parking brake.

With a manual gearbox, engage a gear

and then switch off the ignition.

With an automatic gearbox, place the

gear selector in position

P

, then switch

off the ignition.

Electric parking brake

In automatic mode, this system applies the

parking brake when the engine is switched off

and releases it when the vehicle moves off.









At any time, with the engine running:

►  To apply the parking brake, briefly pull the

control.

►  To release it, briefly push the control while

pressing the brake pedal.

Automatic mode is activated by default.

This automatic operation can be deactivated in

certain situations.

Indicator lamp

This indicator lamp comes on both on the

instrument panel and on the control to

confirm that the parking brake has been applied,

accompanied by display of the message

"

Parking brake applied

".

The indicator lamp goes out to confirm the

release of the parking brake, accompanied by

the display of the message "

Parking brake

released

".

The indicator lamp flashes in response to a

manual request to apply or release the brake.

In the event of a battery failure, the

electric parking brake will not operate.

As a safety measure, with a manual gearbox,

if the parking brake is not applied, immobilise

the vehicle by engaging a gear.

As a safety measure, with an automatic

gearbox or drive selector, if the parking brake

is not applied, immobilise the vehicle by

placing the supplied chock against one of the

wheels.

Contact a CITROËN dealer or a qualified

workshop.





141

Driving

6

Before leaving the vehicle, check that the

parking brake is applied: the parking

brake indicator lamps on the instrument panel

and the control must be on fixed.

If the parking brake is not applied, there is an

audible signal and a message is displayed on

opening the driver's door.

Never leave a child alone inside the

vehicle, as they could release the parking

brake.

When the vehicle is parked: on a

steep slope, heavily loaded or during

towing

With a manual gearbox, turn the wheels

toward the pavement and engage a gear.

With an automatic gearbox or a drive selector,

turn the wheels toward the pavement and

select mode

P

.

When towing, the vehicle is approved for

parking on slopes of up to 12%.

Manual operation

Manual release

With the ignition on or engine running:

►  Press the brake pedal.

►  While maintaining pressure on the brake

pedal, briefly push the control.

If the brake pedal is not depressed, the

parking brake is not released and a

message is displayed.

Manual application

With the vehicle stationary:

►  Briefly pull the control.

The control indicator lamp flashes to confirm the

application request.

Automatic operation

Automatic release

First ensure that the engine is running and that

the driver's door is closed.

The electric parking brake gradually releases

automatically as the vehicle moves off.

With a manual gearbox

►  Fully depress the clutch pedal and engage

first gear or reverse.

►  Depress the accelerator pedal and release

the clutch pedal.

With an automatic gearbox

►  Depress the brake pedal.

►  Select mode

D

,

M

 or

R

.

►  Release the brake pedal and depress the

accelerator pedal.

With a drive selector

►  Depress the brake pedal.

►  Select mode

D

,

B

 or

R

.

►  Release the brake pedal and depress the

accelerator pedal.

With an automatic gearbox or drive

selector, if the brake does not release

automatically, check that the front doors are

properly closed.

When stationary with the engine running,

do not depress the accelerator pedal

unnecessarily. Risk of parking brake release.

Automatic application

With the vehicle stationary, the parking brake

is applied automatically when the engine is

switched off.

It is not applied automatically if the

engine stalls or enters STOP mode with

Stop & Start.

In automatic mode, the parking brake

can be manually applied or released at

any time using the control.

Special cases

Immobilising the vehicle with the

engine running

To immobilise the vehicle with the engine

running, briefly pull the control.

142

Driving

Parking the vehicle with the brake

released

In very cold conditions (ice), applying the

parking brake is not recommended.

To immobilise the vehicle, engage a gear or

place the chocks against one of the wheels.

With an automatic gearbox or drive

selector, mode

P

 is automatically

selected when the ignition is switched off. The

wheels are blocked.

For more information on

Free-wheeling

, refer

to the corresponding section.

With an automatic gearbox or a drive

selector, if you open the driver's

door while mode

N

 is engaged, an audible

signal will sound and mode

P

 will be

engaged. The audible signal stops when the

driver's door is closed.

Deactivating automatic

operation

In some situations, for example when it is

extremely cold or when towing (e.g. caravan,

breakdown), it may be necessary to deactivate

automatic operation of the system.









►  Start the engine.

►  Use the control to apply the parking brake, if

it is released.

►  Take your foot fully off the brake pedal.

►  Keep the control pushed in the release

direction for 10 to a maximum of 15 seconds.

►  Release the control.

►  Depress and hold the brake pedal.

►  Pull the control in the application direction for

2 seconds.

This indicator lamp on the instrument

panel comes on to confirm deactivation of

the automatic functions.

►  Release the control and the brake pedal.

From this point onwards, only the manual

functions, using the control, allow the parking

brake to be applied and released.

►  Follow this procedure again to reactivate

automatic operation (confirmed by the indicator

lamp on the instrument panel going out).

Emergency braking

If depressing the brake pedal fails to provide

effective braking or in exceptional circumstances

(e.g. driver unwell, assisted driving), the vehicle

can be braked by sustained pulling on the

electric parking brake control. Braking continues

for as long as the control is kept pulled, and

ceases when the control is released.

The ABS and DSC systems stabilise the vehicle

during emergency braking.

If emergency braking malfunctions, the message

"

Parking brake fault

" will be displayed on the

instrument panel.

If the ABS and DSC systems

malfunction, indicated by lighting

one or both warning lamps on the instrument

panel, the vehicle’s stability is no longer ensured.

►  In this case, ensure the vehicle's stability by

successive and repeated "pull-release" actions

on the electric parking brake control until the

vehicle comes to a complete stop.

Hill start assist

This system keeps the vehicle briefly stationary

(for approximately 2 seconds) when making a hill

start, while you transfer your foot from the brake

pedal to the accelerator pedal.

The system is only active when:

–  The vehicle is completely stationary, with your

foot on the brake pedal.

–  Certain slope conditions are met.

–  The driver’s door is closed.

143

Driving

6

Do not leave the vehicle while it is being

held temporarily by hill start assist.

If someone needs to get out of the vehicle

with the engine running, apply the parking

brake manually. Then check that the parking

brake indicator lamp and the

P

 indicator lamp

in the electric parking brake control are on

fixed.

The hill start assist function cannot be

deactivated. However, using the parking

brake to immobilise the vehicle interrupts its

operation.

If your vehicle has an automatic gearbox

and you have to move off on a steep

slope (uphill or downhill) with a loaded

vehicle,

press the brake pedal

, select

position

D

, release the parking brake then

release the brake pedal.

Operation





Facing uphill, with the vehicle stationary,

the vehicle is held for a short time when the

driver releases the brake pedal:

–  If first gear or neutral is engaged on a manual

gearbox.

–  If mode

D

 or

M

 is selected on an automatic

gearbox.

–  If mode

D

 or

B

 is selected on the drive

selector.





Facing downhill, with the vehicle stationary

and reverse gear engaged, the vehicle is held

for a short time when the driver releases the

brake pedal.

Malfunction

If the event of a malfunction, these

warning lamps light up on the

instrument panel, accompanied by the display of

a message.

Have it checked by a CITROËN dealer or a

qualified workshop.

6-speed manual gearbox

Engaging 5

th

 or 6

th

 gear

►  Move the gear selector fully to the right to

engage 5

th

 or 6

th

 gear.

Failure to follow this instruction could

cause permanent damage to the gearbox

(inadvertent engagement of 3

rd

 or 4

th

 gear).

Engaging reverse gear





►  Raise the ring under the knob and move the

gear lever to the left, then forwards.

Only engage reverse gear when the

vehicle is stationary with the engine at

idle.

As a safety precaution and to facilitate

engine starting:

–  always select neutral,

144

Driving

–  depress the clutch pedal.

Gear shift indicator

(Depending on engine)

This system is designed to reduce fuel

consumption by recommending the most suitable

gear.

Operation

Depending on the driving situation and

the vehicle's equipment, the system may

recommend skipping one or more gears.

Gear engagement recommendations are

not to be considered mandatory. Indeed, the

configuration of the road, the traffic density and

safety remain determining factors when choosing

the best gear. Therefore, the driver remains

responsible for deciding whether or not to follow

the system’s advice.

The system cannot be deactivated.

On certain BlueHDi Diesel versions with a

manual gearbox, the system may suggest

shifting into neutral (

N

 is displayed on the

instrument panel) so that the engine can go into

standby (STOP mode of Stop & Start), in certain

driving conditions.

With an automatic gearbox, the system is

only active in manual operation.

The information appears on the

instrument panel, in the form of an "up" or

"down" arrow and the recommended gear.

The system adapts the gear change

instructions according to the driving

conditions (e.g. slope, load) and driving style

(e.g. power demand, acceleration, braking).

The system never suggests:

–  engaging first gear.

–  engaging reverse gear.

Automatic gearbox

Automatic 6 or 8-speed gearbox, with electronic

management of gear changes. It also offers a

manual mode with sequential gear changes

via control paddles located behind the steering

wheel.

Gear selector

To turn the gear selector in complete

safety, it is recommended that you keep

your foot on the brake pedal.

P.

Park.

R.

Reverse.

N.

Neutral.

D.

Drive (automatic operation).

M.

Manual (manual operation with sequential

changing of the gears).

Position

N

 can be used in traffic jams or

in a car wash tunnel.

145

Driving

6

Steering mounted controls





►  Pull the right-hand "

+

" or left-hand "

-

" control

paddle towards you to change up or down.

The steering mounted controls do not

allow neutral to be selected and reverse

gear to be engaged or disengaged.

Information displayed on

the instrument panel









When you move the selector or press button

M

,

the corresponding gear and indicator lamp are

shown on the instrument panel.

The "

-

" symbol is displayed if a value is invalid.

►  If the message "

Foot on the brake

" is

displayed on the instrument panel, press

the brake pedal firmly.

Starting the vehicle

►  With your foot on the brake, select

position

P

.

►  Start the engine.

If the conditions are not met, there is an audible

signal, accompanied by a message on the

instrument panel screen.

►  Release the parking brake, unless it is set to

automatic mode (with electric parking brake).

►  Select position

R

,

N

 or

D

.

If you are setting off from a steep slope

with a loaded vehicle,

depress the

brake pedal

, select position

D

, release the

parking brake, unless it is set to automatic

mode (with electric parking brake), then

release the brake pedal.

►  Gradually release the brake pedal.

Or

►  Accelerate gradually in order to release the

electric parking brake (if it is set to automatic

mode).

The vehicle moves off immediately.

If

P

 is displayed on the instrument panel

but the selector is in another position,

place the selector in position

P

 to allow the

engine to be started.

If position

N

 is selected inadvertently while

driving, allow the engine to return to idle, then

select position

D

 to accelerate.

When the engine is running at idle with

the brakes released, if position

R

,

D

 or

M



is selected, the vehicle moves even without

the accelerator being pressed.

Never leave children inside the vehicle

unsupervised.

As a safety measure, never leave the vehicle

without taking your key or remote control with

you, even for a short time.

When carrying out maintenance with the

engine running, apply the parking brake and

select position

P

.

With an automatic gearbox, never try to

start the engine by pushing the vehicle.

Automatic operation

►  Select position

D

 for

automatic



changing of the gears.

The gearbox then operates in auto-adaptive

mode, without any intervention on the part of the

driver. It continuously selects the most suitable

gear according to the driving style, the road

profile and the load in the vehicle.
