146

Driving

►  For maximum acceleration without

touching the selector, fully depress the

accelerator pedal (kick-down).

The gearbox changes down automatically or

holds the gear selected until the maximum

engine speed is reached.

When braking, the gearbox changes down

automatically to provide effective engine braking.

If you release the accelerator sharply, the

gearbox will not shift to a higher gear for safety

reasons.

Never select position

N

 while the vehicle

is moving.

Never select positions

P

 or

R

 unless the

vehicle is completely stationary.

Temporary manual control

of gear changes

You can temporarily assume control of gear

changing using the "

+

" et "

-

” steering-mounted

controls. The gear change request will be

executed if the engine speed permits.

This function allows you to anticipate certain

situations, such as overtaking another vehicle or

approaching a bend in the road.

After a few seconds with no inputs via the control

paddles, the gearbox reverts to automatic

operation.

Creeping (moving without

using the accelerator)

This function facilitates manoeuvring of the

vehicle at low speed (when parking, in traffic

jams, etc.).

With the engine at idle, parking brake released

and position

D

,

M

 or

R

 selected, the

vehicle

moves

 as soon as you take your foot off

the brake pedal (even without pressing the

accelerator).

As a safety precaution, never leave the

vehicle with the engine running and the

doors closed.

Manual operation

►  With the selector in position

D

, press

button

M

 to enable 6- or 8-speed

sequential

 gear changing.

The indicator lamp for the button comes on.

►  Operate the "

+

" or "

-

" steering mounted

controls.

M

 appears and the engaged gears are

shown in succession on the instrument

panel.

►  You can revert to automatic operation at any

time by pressing button

M

 again.

The indicator lamp for the button goes off.

In manual mode, there is no need to

release the accelerator pedal while

changing gear.

It is only possible to change from one

gear to another if the vehicle speed and

engine speed permit.

If the engine speed is too low or too high,

the selected gear flashes for a few

seconds, then the gear actually engaged is

shown.

When the vehicle is stationary or moving very

slowly, the gearbox automatically selects gear

M1

.

To preserve the brakes while descending

a steep incline, use engine braking to

reduce your speed (change down or select a

lower gear).

Keeping the brake pedal pressed

continuously for long periods can overheat

the brakes, with the risk of damaging the

braking system or making it inoperative.

Only use the brakes when necessary, to slow

or stop the vehicle.

Depending on the road configuration

(e.g. mountainous road), manual

operation may be preferable.

Automatic operation may not always be

suitable, and does not enable engine braking.

147

Driving

6

Invalid value during manual

operation

This symbol is displayed if a gear is not

engaged correctly (gear selector between

two positions).

►  Place the selector "correctly" at a position.

Switching off the vehicle

Before switching off the engine, select position

P

 then apply the parking brake to immobilise

the vehicle, unless this is set to automatic mode

(with electric parking brake).

Check that mode

P

 has been engaged and that

the electric parking brake has been applied

automatically; if not, apply it manually.

The corresponding indicator lamps in the

selector and the electric parking brake control

lever must be on, as well as those on the

instrument panel.

A point of resistance may be noticed

when moving to position

P

.

If the selector is not in position

P

, when the

driver's door is opened or approximately 45

seconds after the ignition is switched off,

an audible signal sounds and a message

appears.

►  Return the drive selector to position

P

;

the audible signal stops and the message

disappears.

When positioned on a steep slope with a

loaded vehicle,

depress the brake

pedal

, select position

P

, apply the parking

brake, unless it is set to automatic mode (with

electric parking brake), then release the brake

pedal.

In all circumstances, ensure that the

selector is in position

P

 before leaving

your vehicle.

Malfunction

When the ignition is on, a message appears on

the instrument panel to indicate a fault with the

gearbox.

In this case, the gearbox goes into back-up

mode and is locked in 3

rd

 gear. You may feel a

significant jolt (without risk to the gearbox) when

changing from

P

 to

R

 and from

N

 to

R

.

Do not exceed 62 mph (100 km/h), local speed

restrictions permitting.

Have it checked by a CITROËN dealer or a

qualified workshop.

There is a risk of damaging the gearbox:

–  If the accelerator and brake pedals are

depressed simultaneously.

–  In the event of a battery failure, forcing the

selector from position

P

 to another position.

If your vehicle has an automatic gearbox,

do not try to start the engine by pushing

the vehicle.

Drive selector (Electric)





The drive selector is a pulse selector with a

regenerative braking function.

The drive selector provides traction control

based on the driving style, the road profile and

the vehicle load.

With regenerative braking activated, it also

manages engine braking when the accelerator

pedal is released.

P.

Park

Button for parking the vehicle: the front

wheels are locked (the button lights up to

indicate that it is activated).

R.

Reverse

To engage reverse gear, with your foot on the

brake pedal.

148

Driving

N.

Neutral

To move the vehicle with the ignition off and

so allow it to free-wheel.

For more information on

Free-wheeling

, refer

to the corresponding section.

D.

Drive (automatic forward gear)

B.

Brake (regenerative braking)

Regenerative braking (the button lights up to

indicate its activation).

Information displayed on

the instrument panel

When the ignition is switched on, the drive

selector status is displayed on the instrument

panel:

P

 : Park.

R

 : Reverse.

N

 : Neutral.

D

 : Drive (automatic forward gear).

B

 : Brake (regenerative braking activated).

Operation

►  Move the selector by pressing it forwards

(

N

 or

R

) or rearwards (

N

 or

D

) once or twice,

passing the point of resistance if necessary.

For example, to change from

P

 to

R

 (with your

foot on the brake pedal), either push forwards

twice without passing the point of resistance or

push just once, passing the point of resistance.

Regenerative braking

With the Brake function and when

decelerating

The Brake function emulates engine braking,

slowing the vehicle with no need to depress the

brake pedal. The vehicle slows more quickly

when the driver releases the accelerator pedal.

The energy recovered when the accelerator

pedal is released is then used to partially

recharge the traction battery, thereby increasing

the vehicle's driving range.

The resulting deceleration of the vehicle

does not cause the brake lamps to come

on.

►  From mode

D

, press button

B

 to activate/

deactivate the function (the button lights up when

the function is activated).

D

 on the instrument panel is replaced with

B

.

The status of the function is saved when the

ignition is switched off.

In some situations (e.g. battery full,

extreme temperatures), the amount of

regenerative braking may be temporarily

limited, resulting in less deceleration.

The driver must remain alert to traffic

conditions and must always be ready to use

the brake pedal.

With the brake pedal

When the brake pedal is depressed, the

intelligent braking system automatically recovers

some of the energy and uses it to recharge the

traction battery.

This energy recovery also reduces use of the

brake pads, thereby limiting their wear.

The driver may experience a different

sensation when depressing the brake

pedal compared to a vehicle without

regenerative braking.

Driving modes (Electric)

Driving modes are selected using the following

control:









►  Press the control to display the modes on the

instrument panel, and depending on version, on

the screen with MyCitroën Drive.

149

Driving

6

When starting the vehicle, no mode can be

selected until the

READY

 indicator lamp is

displayed.

When the message disappears, the selected

mode is activated and remains indicated on the

instrument panel (except

Normal

 mode).

Each time the ignition is switched on,

Normal



mode is selected by default.

Normal

This optimises the driving range and dynamic

performance.

To obtain maximum torque and power, depress

the accelerator pedal fully.

Eco

Optimises energy consumption, by reducing

the output of the heating and air conditioning

(without actually deactivating them) and limiting

both motor torque and power.

Power

Provides equivalent vehicle performance when

fully laden (GVW) to when the vehicle is in

Normal mode and when unladen.

Stop & Start

The Stop & Start function puts the engine

temporarily into standby - STOP mode - during

phases when the vehicle is stationary (e.g. red

lights, traffic jams). The engine automatically

restarts - START mode - as soon as the driver

indicates the intention of moving off again.

Primarily designed for urban use, the function

is intended to reduce fuel consumption and

exhaust emissions as well as the noise level

when stationary.

The function does not affect the functionalities of

the vehicle, in particular the braking.

Driving on flooded roads

Before entering into a flooded area, it is

strongly recommended that you deactivate

the Stop & Start system.

For more information on

Driving

recommendations

, particularly on flooded

roads, refer to the corresponding section.

Deactivation/Reactivation

With audio system









►  To deactivate or reactivate the system, press

this button.

The indicator lamp is

on

 when the system is

deactivated

.

With touch screen

The settings are changed via the vehicle

configuration menu.

If the system has been deactivated in

STOP mode, the engine restarts

immediately.

The system is reactivated automatically

whenever the engine is started by the

driver.

Operation

Main conditions for operation

–  The driver’s door must be closed.

–  The sliding side door must be closed.

–  The driver's seat belt must be fastened.

–  The level of charge in the battery must be

sufficient.

–  The temperature of the engine must be within

its nominal operating range.

–  The outside temperature must be between

0°C and 35°C.

Putting the engine into standby

(STOP mode)

The engine automatically enters standby mode

as soon as the driver indicates their intention to

stop:

With a

manual gearbox

: at speeds below 12

mph (20 km/h) or with the vehicle stationary

150

Driving

(depending on engine), with the gear lever in

neutral and the clutch pedal released.

With an

automatic gearbox

: with the brake

pedal depressed or the gear selector in

position

N

, with the vehicle stationary.

Time counter

A time counter adds up the time spent in standby

during the journey. It is reset to zero every time

the ignition is switched on.

Special cases:

The engine will not go into standby if the

conditions for operation are not met and in the

following cases:

–  Steep slope (ascending or descending).

–  Vehicle has not exceeded 6 mph (10 km/h)

since the last engine start (with the key or the

START/STOP

 button).

–  Needed to maintain a comfortable temperature

in the passenger compartment.

–  Demisting active.

In these cases, this indicator lamp flashes

for a few seconds, then goes off.

After the engine has restarted, STOP

mode is not available until the vehicle

has reached a speed of 5 mph (8 km/h).

During parking manoeuvres, STOP mode

is not available for a few seconds after

coming out of reverse gear or turning the

steering wheel.

Restarting the engine (START mode)

The engine automatically restarts as soon as the

driver indicates the intention of moving off again:

With a manual gearbox

: with the clutch pedal

fully depressed.

With an automatic gearbox

:

–  With the selector in position

D

 or

M

: with the

brake pedal released.

–  With the selector in position

N

 and the brake

pedal released: with the selector at

D

 or

M

.

–  With the selector in position

P

 and the brake

pedal depressed: with the selector at

R

,

N

,

D



or

M

.

–  Reverse gear engaged.

Special cases

The engine will restart automatically if the

conditions for operation are met again and in the

following cases:

–  With a

manual gearbox

: vehicle speed

exceeds 16 mph (25 km/h) or 2 mph (3 km/h)

(depending on engine).

–  With an

automatic gearbox

, vehicle speed

exceeds 2 mph (3 km/h).

In these cases, this indicator lamp flashes

for a few seconds, then goes off.

Malfunctions

Depending on the vehicle’s equipment:

In the event of a system malfunction, this

warning lamp flashes on the instrument

panel.

The warning lamp in this button flashes

and a message appears, accompanied by

an audible signal.

Have it checked by a CITROËN dealer or a

qualified workshop.

The vehicle stalls in STOP mode

All of the instrument panel warning lamps come

on if there is a fault.

Depending on version, a warning message

may also be displayed, prompting you to place

the gear selector in position

N

 and depress the

brake pedal.

►  Switch off the ignition then start the engine

again with the key or the "

START/STOP

" button.

12 V battery

The Stop & Start system requires a

12 V battery of specific technology and

specification.

All work must be carried out only by a

CITROËN dealer or a qualified workshop

Tyre

under-inflation

detection

This system automatically checks the pressures

of the tyres while driving.

It compares the information given by the wheel

speed sensors with

reference values, which

must be reinitialised every time the tyre

pressures are adjusted or a wheel changed

.

151

Driving

6

The system triggers an alert as soon as it

detects a drop in the inflation pressure of one or

more tyres.

Under-inflation detection does not

replace the need for vigilance on the part

of the driver.

This system does not avoid the need to

regularly check the tyre pressures (including

the spare wheel) as well as before a long

journey.

Driving with under-inflated tyres, particularly

in adverse conditions (heavy load, high

speed, long journey):

–  worsens road-holding,

–  lengthens braking distances,

–  causes premature wear of the tyres,

–  increases fuel consumption.

The inflation pressures specified for the

vehicle can be found on the tyre pressure

label.

For more information on the

Identification

markings

, refer to the corresponding section.

Checking tyre pressures

This check should be done when the

tyres are "cold" (vehicle stopped for 1 hour or

after a journey of less than 6 miles (10 km) at

moderate speeds).

Otherwise, add 0.3 bar to the pressures

shown on the label.

Snow chains

The system does not have to be

reinitialised after fitting or removing snow

chains.

Spare wheel

The steel spare wheel does not have an

under-inflation detection sensor.

Under-inflation alert

This is signalled by the fixed illumination

of this warning lamp, accompanied by an

audible signal and, depending on equipment, the

display of a message.

►  Reduce speed immediately, avoid excessive

steering movements and avoid sudden braking.

►  Stop the vehicle as soon as it is safe to do

so.

The loss of pressure detected may not

always cause visible deformation of the

tyre.

Do not rely on just a visual check.

►  Using a compressor, such as the one in

the temporary puncture repair kit, check the

pressures of all four tyres when cold.

►  If it is not possible to carry out this check

immediately, drive carefully at reduced speed.

►  In the event of a puncture, use the

temporary puncture repair kit or the spare wheel

(depending on equipment).

Driving too slowly may not ensure

optimum monitoring.

The alert is not immediately triggered in the

event of a sudden loss of pressure or tyre

blow-out. This is because analysis of the

values read by the wheel's speed sensors

can take several minutes.

The alert may be delayed at speeds below

25 mph (40 km/h), or when adopting a sporty

driving mode.

The alert is kept active until the system is

reinitialised.

Reinitialisation

►  The system must be reinitialised after any

adjustment to the pressure of one or more tyres,

and after changing one or more wheels.

Before reinitialising the system, make

sure that the pressures of the four tyres

are correct for the conditions of use of the

vehicle and conform to the values written on

the tyre pressure label.

Check the pressures of the four tyres before

performing the reinitialisation.

The system does not advise if a pressure is

incorrect at the time of reinitialisation.

152

Driving

With dashboard button









►  With the vehicle stationary, press this

button for about 3 seconds then release it.

Reinitialisation is confirmed by an audible signal.

Without dashboard button

With the vehicle stationary, the

system is reinitialised via the

vehicle configuration menu.

Malfunction

In the event of a malfunction,

these warning lamps light up on

the instrument panel.

In this case, the tyre under-inflation monitoring

function is no longer performed.

Have it checked by a CITROËN dealer or a

qualified workshop.

Driving and manoeuvring

aids - General

recommendations

Driving and manoeuvring aids cannot, in

any circumstances, replace the need for

vigilance on the part of the driver.

The driver must comply with the Highway

Code, must remain in control of the vehicle in

all circumstances and must be able to retake

control of it at all times. The driver must adapt

the speed to climatic conditions, traffic and

the state of the road.

It is the driver's responsibility to constantly

monitor traffic conditions, assess the distance

and relative speed of other vehicles, and

anticipate their manoeuvres before using the

direction indicator and changing lanes.

These systems do not make it possible to

exceed the laws of physics.

Driving aids

You should hold the steering wheel with

both hands, always use the door and interior

mirrors, always leave your feet close to the

pedals and take a break every 2 hours.

Manoeuvring aids

The driver must always check the

surroundings of the vehicle before and during

the whole manoeuvre, in particular using the

mirrors.

Radar(s)

The operation of the radar(s), along with

any associated functions, may be affected

by the accumulation of dirt (e.g. mud, ice),

in poor weather conditions (e.g. heavy rain,

snow), or if the bumpers are damaged.

If the front bumper is to be repainted, contact

a CITROËN dealer or a qualified workshop;

certain types of paint could interfere with the

operation of the radar(s).





Driving aids camera

This camera and its associated functions

may be impaired or not work if the windscreen

area in front of the camera is dirty, misty,

frosty, covered with snow, damaged or

masked by a sticker.

In humid and cold weather, demist the

windscreen regularly.

Poor visibility (inadequate street lighting,

heavy rain, thick fog, snowfall), dazzle

(headlamps of an oncoming vehicle, low sun,

reflections on a damp road, leaving a tunnel,

alternating shade and light) can also impair

detection performance.

153

Driving

6

In the event of a windscreen replacement,

contact a CITROËN dealer or a qualified

workshop to recalibrate the camera;

otherwise, the operation of the associated

driving aids may be disrupted.

Other cameras

The images from the camera(s)

displayed on the touch screen or on the

instrument panel may be distorted by the

terrain.

In the presence of areas in shade, or in

conditions of bright sunlight or inadequate

lighting, the image may be darkened and with

lower contrast.

Obstacles may appear further away than they

actually are.

Sensors

The operation of the sensors, as well as

any associated functions, may be disrupted

by noise pollution such as that emitted by

noisy vehicles and machinery (e.g. lorries,

pneumatic drills), by the accumulation of

snow or dead leaves on the road or in the

event of damaged bumpers and mirrors.

When reverse gear is engaged, an audible

signal (long beep) indicates that the sensors

may be dirty.

A front or rear impact to the vehicle can

upset the sensors’ settings, which is not

always detected by the system: distance

measurements may be distorted.

The sensors do not systematically detect

obstacles that are too low (pavements, studs)

or too thin (trees, posts, wire fences).

Certain obstacles located in the sensors’ blind

spots may not be detected or may no longer

be detected during the manoeuvre.

Certain materials (fabrics) absorb sound

waves: pedestrians may not be detected.

Maintenance

Clean the bumpers and door mirrors and

the field of vision of the cameras regularly.

When washing your vehicle at high pressure,

direct the spray from at least 30 cm away

from the radar, sensors and cameras.

Mats/Pedal trims

The use of mats or pedal trims not

approved by CITROËN may interfere with

the operation of the speed limiter or cruise

control.

To avoid any risk of jamming the pedals:

–  Ensure that the mat is secured correctly.

–  Never fit one mat on top of another.

Units of speed

Ensure that the units of speed displayed

on the instrument panel (mph or km/h) are

those for the country you are driving in.

If this is not the case, when the vehicle is

stationary, set the display to the required

units of speed so that it complies with what is

authorised locally.

In case of doubt, contact a CITROËN dealer

or a qualified workshop.

Head-up display

System which projects various information onto a

smoked blade placed in the driver's field of vision

to avoid the driver having to take their eyes off

the road.

Display in operation





Once the system has been activated, the

following information is grouped together in the

head-up display:

A.

The speed of the vehicle.

B.

Cruise control/speed limiter information.

154

Driving

C.

If the vehicle is so equipped, inter-vehicle

distance information, automatic emergency

braking alerts and navigation instructions.

D.

If the vehicle is so equipped, speed limit

information.

For more information about

Navigation

,

refer to the sections describing the audio

and telematics systems.

Selectors





1.

On.

2.

Off (long press).

3.

Brightness adjustment.

4.

Display height adjustment.

Activation/Deactivation

►  With the engine running, press button

1

 to

activate the system and deploy the projection

blade.





►  Press and hold button

2

 to deactivate the

system and retract the projection blade.

The state of the system is saved when the

engine is switched off and restored on restarting.

Adjusting the height

►  With the engine running, adjust the display to

the desired height using the buttons

4

:

•  up to move the display up,

•  down to move the display down.

Brightness adjustment

►  With the engine running, adjust the

brightness of the information display using the

buttons

3

:

•  on the "sun" to increase the brightness,

•  on the "moon" to decrease the brightness.

When stationary or while driving, no

objects should be placed around the

projection blade (or in its recess) so as not to

impede its movement and correct operation.

In certain extreme weather conditions

(rain and/or snow, bright sunshine, etc.),

the head-up display may not be legible or

may suffer temporary interference.

Some sunglasses may hamper reading of the

information.

To clean the projection blade, use a clean,

soft cloth (such as a spectacles cloth or

microfibre cloth). Do not use a dry or abrasive

cloth, or detergent or solvent products, due to

the risk of scratching the projection blade or

damaging the non-reflective coating.

This system operates when the engine is

running, and the settings are saved when

the ignition is switched off.

Memorising speeds

This function allows you to save speed

settings which are then used to set the two

systems: the speed limiter (limits the speed

of the vehicle) or cruise control (vehicle

cruising speed).

You can save 6 speed settings for each of the

two systems.

155

Driving

6

Programming

The speed thresholds can be set in the

vehicle configuration menu using the

touch screen.

►  Select the system for which you want to

memorise new speed settings:

–  speed limiter

or

–  cruise control.





►  Press the button corresponding to the speed

setting you want to change.

►  Enter the new value using the numerical

keypad and confirm.

►  Confirm to record the changes and quit the

menu.

Memorised speeds are recalled

by pressing this button.

Road signs recognition

For more information, refer to the

General recommendations on the use

of driving and manoeuvring aids

.





This system displays the maximum speed

authorised locally on the instrument panel, using:

–  Speed limit signs detected by the camera.

–  Speed limit information from the navigation

system’s mapping.

Navigation mapping should be regularly

updated in order to receive accurate

speed limit information from the system.

The units for the speed limit (mph or

km/h) depend on the country you are

driving in.

This should be taken into account to ensure

you observe the speed limit.

For the system to work properly when

changing countries, the speed unit of the

instrument panel must match that of the

country you are driving in.

Automatic sign reading is a driving aid

system and does not always display the

correct speed limits.

The speed limit signs present on the road

always take priority over those displayed by

the system.

The system is designed to detect signs that

conform to the Vienna Convention on road

signs.

Activation/Deactivation

The settings are changed via the

vehicle configuration menu.

Information displayed on

the instrument panel









156

Driving

Head-up display

1.

Speed limit indication

Speed display





The system is active but is not detecting speed

limit information.





On detection of speed limit information, the

system displays the value.





The driver can, if desired, adjust the

speed of the vehicle according to the

information given by the system.

Operating limits

The system does not take account of reduced

speed limits, especially those imposed in the

following cases:

–  Poor weather (rain, snow).

–  Atmospheric pollution.

– Towing.

–  Driving with a space-saver type spare wheel

or snow chains fitted.

–  Tyre repaired using the temporary puncture

repair kit.

–  Young drivers.

The system may not display the speed limit if it

does not detect a speed limit sign within a preset

period and in the following situations:

–  Road signs that are obstructed, non-standard,

damaged or bent.

–  Obsolete or incorrect maps.

Storing the speed setting





In addition to

Road signs recognition

, the

driver can select the speed displayed as a speed

setting for the speed limiter or cruise control

using the speed limiter or cruise control 'store'

button.

For more information on the

Speed

limiter

,

Cruise control

 or

Adaptive

cruise control

, refer to the corresponding

sections.

Steering-mounted controls

1.

Speed limiter/cruise control mode selection

2.

Memorise the speed setting

157

Driving

6

Information displayed on the

instrument panel









Head-up display

3.

Speed limit indication.

4.

Request to memorise the speed.

5.

Current speed setting.

Storing the speed setting





►  Switch on the speed limiter/cruise control.

The speed limiter/cruise control information is

displayed.

Upon detecting a sign suggesting a new speed

setting, the system displays the value and

"

MEM

" flashes for a few seconds, prompting you

to save it as a new speed setting.

If there is a difference of less than 6 mph

(9 km/h) between the speed setting and

the speed displayed by the Road signs

recognition, the "

MEM

" symbol is not

displayed.

Depending on the road conditions, several

speeds may be displayed.

►  Press button

2 once

 to save the suggested

speed value.

A message is displayed, confirming the request.

►  Press button

2 again

 to confirm and save the

new speed setting.

The display then reverts to its previous state.

Speed limiter

For more information, refer to the

General recommendations on the use

of driving and manoeuvring aids

.

This system prevents the vehicle from

exceeding the speed programmed by the

driver (speed setting).

The speed limiter is switched on manually.

The minimum speed setting is 19 mph (30 km/h).

The speed setting remains in the system

memory when the ignition is switched off.

For more information on this

button and the

Adaptive cruise

control

, refer to the corresponding section.

For more information on

Memorising speeds

, refer to the

corresponding section.

For more information on

Speed limit

recognition

 and memorising the speed

limit in particular, refer to the corresponding

section.

158

Driving

Steering-mounted control









1.

ON (

LIMIT

 position)/OFF (position

0

)

2.

Reduce the speed setting

3.

Increase the speed setting

4.

Pause/resume speed limiter with the speed

setting previously stored

5.

Depending on version:

Display the speed thresholds saved using the

Memorising speeds function

or

Use the speed suggested by the Road signs

recognition function (

MEM

 display)

6.

Display and adjustment of the programmed

inter-vehicle distance

For more information on

Memorising speeds



or the

Road signs recognition

, refer to the

corresponding sections.

Information displayed on

the instrument panel









Head-up display





7.

Speed limiter on/pause indication.

8.

Speed limiter mode selection indication.

9.

Speed setting value.

Switching on/Pausing

►  Turn thumbwheel

1

 to the "

LIMIT

" position

to select speed limiter mode; the function is

paused.

►  If the speed limit setting is suitable (most

recent speed setting programmed in the system),

press button

4-II

 to switch the speed limiter on.

►  Pressing

4-II

 again temporarily pauses the

function (pause).

Adjusting the limit speed

setting

You do not have to switch the speed limiter on in

order to set the speed.

To modify the limit speed setting based on the

vehicle’s current speed:

►  For steps of +/- 1 mph (1 km/h), briefly

press

2-SET-

 or

3-SET+

 repeatedly.

►  For steps of +/- 5 mph (5 km/h), press and

hold

2-SET-

 or

3-SET+

.

To change the limit speed setting using

memorised speeds, via the touch screen:

►  Press

5-MEM

 to display the memorised

speed settings.

►  Press the touch screen button for the desired

speed setting.

The selection screen closes after a few

moments.

This setting becomes the new limit speed.

To modify the speed limit setting based on the

speed suggested by the Road signs recognition

function displayed on the instrument panel:

►  Press

5-MEM

 once; a message is displayed,

confirming the memorisation request.

►  Press

5-MEM

 again to save the suggested

speed.

159

Driving

6

The new speed setting value is displayed on the

instrument panel.

Temporarily exceeding the

programmed speed

►  To temporarily exceed the programmed

speed threshold, fully depress the accelerator

pedal.

The speed limiter is deactivated temporarily and

the displayed programmed speed flashes.

If it is exceeded for a prolonged period of time,

an audible warning is triggered.

Simply release the accelerator pedal to return to

below the programmed speed.

When the limit speed is exceeded but this is not

due to action by the driver (in case of a steep

slope, for example), an audible signal triggers

immediately.

Once the speed of the vehicle returns to the

programmed setting, the speed limiter functions

again: the display of the programmed speed

setting becomes fixed again.

Switching off

►  Turn the thumbwheel

1

 to the "

0

" position:

the display of information on the speed limiter

disappears.

Malfunction





In the event of a malfunction, dashes are

displayed flashing and then fixed instead of the

speed setting.

Have it checked by a CITROËN dealer or a

qualified workshop.

Cruise control - Specific

recommendations

The cruise control function does not

guarantee compliance with the maximum

authorised speed and the safety distance

between vehicles, the driver remains

responsible for their driving.

In the interest of public safety, only use cruise

control if the traffic conditions enable vehicles

to drive at a steady speed and maintain an

adequate safety distance.

Remain vigilant while cruise control is

activated.

 If you press and hold one of the

speed setting modification buttons, your

vehicle may change speed very abruptly.

When

descending a steep hill

, the cruise

control system cannot prevent the vehicle

from exceeding the set speed. Brake if

necessary to control the vehicle speed.

On

steep climbs

 or when towing, the set

speed may not be reached or maintained.

Exceeding the programmed speed

setting

You can

temporarily

 exceed the speed

setting by pressing the accelerator pedal (the

programmed speed flashes).

To return to the speed setting, release the

accelerator pedal (when the set speed is

reached again, the displayed speed stops

flashing).

Operating limits

Never use the system in the following

situations:

–  In an urban area with the risk of

pedestrians crossing the road.

–  In heavy traffic.

–  On winding or steep roads.

–  On slippery or flooded roads.

–  In poor weather conditions.

–  In the event of restricted visibility for the

driver.

–  Driving on a speed circuit.

–  Driving on a rolling road.

–  When using snow chains, non-slip covers

or studded tyres.

Cruise control

For more information, refer to the

General recommendations on the use

of driving and manoeuvring aids

 and the

160

Driving

Cruise control - Specific

recommendations

.

This system automatically maintains the

vehicle’s speed at the value programmed

by the driver (speed setting), without the use of

the accelerator pedal.

Cruise control is switched on manually.

It requires a minimum vehicle speed of 25 mph

(40 km/h).

With a manual gearbox, third gear or higher must

be engaged.

With an automatic gearbox, mode

D

 or second

gear or higher in mode

M

 must be engaged.

With a drive selector, mode

D

 or

B

 must be

engaged.

Cruise control remains active after

changing gear, regardless of the gearbox

type, on engines fitted with the Stop & Start

function.

Switching off the ignition cancels any

speed setting.

Steering-mounted control





1.

ON (

CRUISE

 position)/OFF (position

0

)

2.

Activate cruise control at the current speed/

decrease speed setting

3.

Activate cruise control at the current speed/

increase speed setting

4.

Pause/resume cruise control with the speed

setting previously saved

5.

Depending on version:

Display the speed thresholds saved using the

Memorising speeds function

or

Use the speed suggested by the Road signs

recognition function (

MEM

 display)

For more information on

Memorising speeds



or the

Road signs recognition

, refer to the

corresponding sections.

Information displayed on

the instrument panel









Head-up display





6.

Cruise control pause/resume indication.

7.

Cruise control mode selection indication.

8.

Speed setting value.

Switching on/pausing

►  Turn thumbwheel

1

 to the "

CRUISE

" position

to select cruise control mode; the function is

paused.

161

Driving

6

►  Press button

2-SET-

 or

3-SET+

 to activate

cruise control and save a speed setting when

the vehicle has reached the desired speed; the

vehicle’s current speed is saved as the speed

setting.

►  Release the accelerator pedal.

►  Pressing button

4-II

 temporarily pauses the

function (pause).

►  Pressing button

4-II

 again resumes operation

of the cruise control (ON).

Cruise control can also be paused

temporarily:

–  by pressing the brake pedal.

–  by pressing the clutch pedal with a manual

gearbox (depending on the engine fitted).

–  automatically, if the electronic stability

control (ESC) system is triggered.

Changing the cruise speed

setting

The cruise control must be active.

To change the cruise speed setting, based on

the vehicle’s current speed:

►  For steps of +/- 1 mph (1 km/h), briefly

press

2-SET-

 or

3-SET+

 repeatedly.

►  For steps of +/- 5 mph (5 km/h), press and

hold

2-SET-

 or

3-SET+

.

Pressing and holding

2-SET-

 or

3-SET+



results in a rapid change in the speed of

the vehicle.

As a precaution, we recommend setting

a cruise speed fairly close to the current

speed of your vehicle, to avoid any sudden

acceleration or deceleration of the vehicle.

To change the cruise speed setting using

memorised speed settings and from the touch

screen:

►  Press

5-MEM

 to display the memorised

speed settings.

►  Press the touch screen button for the desired

speed setting.

The selection screen closes after a few

moments.

This setting becomes the new cruise speed.

To change the cruise speed setting using the

speed suggested by the Road signs recognition

function displayed on the instrument panel:

►  Press

5-MEM

 once; a message is displayed,

confirming the memorisation request.

►  Press

5-MEM

 again to save the suggested

speed.

The new speed setting value is displayed on the

instrument panel.

Temporarily exceeding the

programmed speed

If needed (when overtaking, for example),

it is possible to exceed the programmed

speed by pressing the accelerator pedal.

Cruise control is temporarily deactivated and the

programmed speed displayed flashes.

To return to the programmed speed, simply

release the accelerator pedal.

Once the vehicle has returned to the

programmed speed, cruise control takes over

again and the programmed speed setting stops

flashing.

When descending a steep hill, the cruise

control system cannot prevent the

vehicle from exceeding the programmed

speed.

You may have to brake to control the speed of

your vehicle. In this case, the cruise control is

automatically paused.

To activate the system again, with the vehicle

speed above 25 mph (40 km/h), press button

4

.

Switching off

►  Turn the thumbwheel

1

 to the "

0

” position: the

cruise control information disappears from the

screen.

Malfunction





In the event of a malfunction, dashes are

displayed flashing and then fixed instead of the

speed setting.

Have it checked by a CITROËN dealer or a

qualified workshop.
