50

Ease of use and comfort

Backrest angle





►  Tilt the control forwards or rearwards to

adjust the angle of the backrest.

Head restraint height

adjustment





If fitted to your vehicle.

►  To raise it, pull it upwards as far as possible

(notch).

►  To remove it, press the lug

A

 and pull it

upwards.

►  To put it back in place, engage the head

restraint rods in the openings keeping them in

line with the seat backrest.

►  To lower it, press the lug

A

 and push down on

the head restraint at the same time.

The head restraint has a frame with

notches which prevents it from lowering;

this is a safety device in case of impact.

The adjustment is correct when the upper

edge of the head restraint is level with the

top of the head.

Never drive with the head restraints removed;

they must be fitted and correctly adjusted.

2-seat front bench seat

If fitted in the vehicle, this is fixed and has a seat

belt built into the backrest for the seat next to the

driver’s seat.

For more information on the

Seat belts

,

refer to the corresponding section.

Under-seat storage





If the vehicle is so equipped, a storage space is

provided under the seat.

►  Pull the strap towards you to tip the seat

cushion.

Armrest





The armrest has notches.

►  Pull the armrest fully up

►  Lower it fully down.

►  Raise the armrest to the desired position.

51

Ease of use and comfort

3

Heated seats and bench

seat













If fitted to your vehicle.

►  With the engine running and when the

outside temperature is below 20 °C, use the

adjustment knob to switch on and select the level

of heating required from

0

 (off) to

3

 (high).

Prolonged use of heated seats is not

recommended for people with sensitive

skin.

There is a risk of burns for people whose

perception of heat is impaired (e.g. illness,

taking medication).

To keep the heated pad intact and to prevent

a short circuit:

–  Do not place heavy or sharp objects on the

seat.

–  Do not kneel or stand on the seat.

–  Do not spill liquids onto the seat.

–  Never use the heating function if the seat

is damp.

Do not use the function when the seat

is not occupied.

Reduce the heating intensity as soon as

possible.

When the seat and passenger compartment

have reached a satisfactory temperature,

switch the function off; reducing electrical

consumption in turn decreases energy

consumption.

Electric lumbar

adjustment





►  Press the control to obtain the desired lumbar

support.

Massage function





52

Ease of use and comfort

This function provides lumbar massage; it only

operates when the engine is running as well as

in STOP mode of the Stop & Start system.

Activation/Deactivation

►  Press this button to activate/deactivate

the function.

Upon activation, the indicator lamp comes on.

The massage function is activated for a period

of one hour.

During this time, massage is performed in

6 cycles of 10 minutes (6 minutes of massage

followed by a 4-minute break).

After one hour, the function is deactivated; the

indicator lamp goes off.

Adjustment of intensity





Press this button to adjust the intensity of

the massage.

Two levels of massage are available.

Steering wheel

adjustment





►

When stationary

, lower the control lever to

release the steering wheel.

►  Adjust the height and reach.

►  Pull the control lever to lock the steering

wheel.

As a safety precaution, these operations

must only be carried out while the vehicle

is stationary.

Mirrors

Door mirrors

As a safety measure, the mirrors should

be adjusted to reduce the "blind spots".

The objects that you see in the mirrors are

in fact closer than they appear. Take this

into account in order to correctly judge the

distance of vehicles approaching from behind.





►  Move control

A

 to the right or to the left to

select the corresponding mirror.

►  Move control

B

 in any of the four directions

to adjust.

►  Return control

A

 to its central position.

Manual folding

The mirrors can be folded manually (parking

obstruction, narrow garage, etc.).

►  Turn the mirror towards the vehicle.

Electric folding

Depending on equipment, the door mirrors can

be folded electrically.

►  From the inside, with the

ignition on, place control

A

 in the

central position.

►  Pull control

A

 backwards.

53

Ease of use and comfort

3

►  Lock the vehicle from the outside.

If the mirrors are folded using control

A

,

they will not unfold when the vehicle is

unlocked.

Electric unfolding

The door mirrors are unfolded electrically when

the vehicle is unlocked using the remote control

or key. Unless folding was selected with control

A

, pull the control in the central position towards

the rear again.

Folding/unfolding when locking/unlocking

the vehicle can be deactivated. Contact a

CITROËN dealer or a qualified workshop.

If necessary, the mirrors can be folded

manually.

Heated mirrors









►  Press one of these buttons.

For more information on

Rear screen

demisting/de-icing

, refer to the

corresponding section.

Rear view mirror

Equipped with an anti-dazzle system, which

darkens the mirror glass and reduces the

nuisance to the driver caused by the sun,

headlamps of other vehicles, etc.

Day/night position





►  Pull the lever to change to the anti-dazzle

"night” position.

►  Push the lever to change to the normal "day"

position.

Windscreen zone for toll

badge

Depending on the version, the vehicle can be

equiped with a athermic windscreen type.

For a best functionnement of the toll badge

system, it is necessary to place the toll badge on

the zone of windscreen provided for the purpose

symbolised with of black dotteds around of the

interior rear view mirror base.





For the version without athermic

windscreen, to limit the obstruction of you

field of vision through the windscreen, we

recommend you to place the toll badge in the

upper part of the windscreen.

Moduwork





The cushion of the bench seat's outer seat can

be folded up against the backrest to create a

loading area inside the cab.

A removable flap on the partition can be

removed to allow long objects to be loaded.



54

Ease of use and comfort



Once the removable flap has been

removed, you can load long objects

under the outer seat.

Removable flap (type 1)

Removing the flap





►  While holding the flap with one hand, turn the

control at the top of the flap with the other hand

to release it.

►  Lower the flap to remove it from its housing.

►  Stow it behind the driver’s seat, clipping it into

the attachment lugs.

►  Turn the control at the top of the flap to

secure it.

Refitting the flap





►  Tilt the flap, with the yellow hinges pointing

downwards.

►  Insert the hinges into their housing then press

down fully (to avoid vibrations).

►  With one hand lift the flap to close it, then

with the other hand turn the control at the top of

the flap to secure it.

Removable flap (type 2)





►  To open or close the flap, slide it to the left

or right.

The flap is kept in the closed or open position

with magnets located at each end position.

Folding seat cushion

Raising the seat cushion





►  With one hand, firmly pull the strap forwards

to unlock the seat cushion.

►  A strut lifts the seat cushoin against the

backrest.

55

Ease of use and comfort

3

Never

 put your hand underneath the seat

cushion to guide it upwards, as your

fingers may become trapped.

Always use only the strap.

When the outer seat is raised and the

flap is removed, you must install the

anti-slip net.

Refer to the

Anti-slip net

 section.

Lowering the seat cushion





►  Remove the anti-slip net.

►  To reposition the seat cushion, press firmly

on the top of the seat with one hand to lower the

seat cushion until it locks into the seat position.

Ensure that there are no objects or feet

obstructing the anchorage points or

preventing the assembly from locking

properly.

Anti-slip net

Installing the net









►  Put the first fastener into the upper cut-out

1

,

located beneath the folded seat cushion. Keep

the fastener pressed against the structure, then

56

Ease of use and comfort

turn it a quarter turn (in a clockwise direction) to

lock it.

►  Put the second fastener into the lower cut-out

2

, located on the seat base. Keep the fastener

pressed against the structure, then turn it a

quarter turn (in a clockwise direction) to lock it.





►  Secure the first hook to the ring

3

 located in

the glove box.

►  Secure the second hook to the ring

4

 located

on the floor.

Removing the net

►  Release the hooks from the rings

4

 and

3

.

►  Remove the lower fastener

2

 then the upper

fastener

1

, turning them by a quarter turn

backwards to unlock them.

Make sure that the size, shape and

volume of the loads carried are

compatible with the highway code and safety

regulations and do not impair the driver’s field

of vision.

All loads must be appropriately secured

to prevent or minimise displacement and

prevent injury.

Install the anti-slip net (supplied with the

vehicle) every time that the seat is raised and

the partition flap removed.

Never use the net for any other purposes.

Regularly check the condition of the anti-

slip net. As soon as signs of wear or tear

appear, contact a CITROËN dealer to have

it replaced by an anti-slip net that meets the

specifications required by CITROËN for the

vehicle.

Always fit the removable flap back into place

when you are not carrying any long loads.

"Rotating writing table"

If fitted to your vehicle, the central seat cushion

of the bench seat can be tilted to form a pivoting

writing table, thus creating a mobile desk (with

the vehicle stationary).

►  Pull the handle located at the top of the

backrest cushion.





Never use the table while the vehicle is

being driven.

In the event of sudden braking or impact, any

objects on the table might become dangerous

projectiles that could cause injury.

57

Ease of use and comfort

3

Central seat cushion

storage





Precautions for the seats

and bench seats

Do not remove a head restraint without storing it

and securing it to a support.

Ensure that the passengers can always access

the seat belts and fasten them easily.

A passenger must not take their seat without

adjusting the seat's head restraint correctly and

adjusting and fastening their seat belt.

Ensure that no object or passenger feet

could obstruct the anchorage points or

prevent the correct latching of the assembly.

If removing and storing seats and bench

seats out of the vehicle, ensure that they

are placed in a clean area, so as to avoid

introducing any foreign bodies into the

mechanisms.

The seats and bench seats are not

designed for any other use than in the

vehicle. They are equipped with mechanisms

and features that may be damaged if used

improperly or if dropped.

Loading luggage or objects

behind the row 3 seat and

bench seat





If you want to load luggage onto the backrests in

row 3 while in the table position, the backrests in

row 2 must also be in the table position.





When driving, it is prohibited to have a

passenger:

–  in rows 2 and 3, in the outer right-hand seat, if

the bench seat is in the fully folded position,

–  in the centre seat if the outer right-hand seat is

in the fully folded position,

–  in row 3 if the backrest in front (row 2) is in the

table position,

–  in row 3 if the seat/bench seat in front (row 2)

is in the fully folded position.

Fixed one-piece bench

seat

Combi

,

Business

58

Ease of use and comfort

The different equipment and settings described

hereafter vary according to the version and the

configuration of your vehicle.





The bench seat has a one-piece backrest that

may be fixed or foldable (table position).

For more information on the

Seat belts

,

refer to the corresponding section.

Access to row 3





►  Using the handle, release the rear feet then

tip the seat forward.

►  To return the seat, tip the bench towards the

rear until the feet lock into place..

It is not necessary to fold the backrest

(table position) to tip the bench seat for

access to row 3.

Folding the backrest to the

table position

►  Put the head restraints in the low position.





►  From the rear, lower the handle to release the

backrest.

►  From the front, raise the handle to release

the backrest.

►  Fold the backrest onto the cushion.

►  To return the backrest to its normal position,

raise the handle and pull the backrest up.

Do not leave objects (such as a bag or

toys) on the cushion when folding the

backrest.

Tilting

►  If your vehicle has the facility, place the

backrest in the table position.





►  Using the handle, release the rear feet then

tip the seat forward.

►  To return the seat, tip the bench towards the

rear until the feet lock into place..

Removing

►  If the vehicle is so equipped, place the

backrest in the table position.

►  Tip the bench seat.



59

Ease of use and comfort

3



►  Release the front feet using the handles.

►  Disengage the bench seat from its

anchorages.

►  Remove the bench seat.

Refitting

►  Check that there is no object obstructing the

anchorages and preventing the feet locking into

place.





►  Engage the front feet in the anchorages on

the floor (as shown above).





►  Lock the front feet using the handles.

►  Tip the bench seat backwards until the rear

feet lock into place.

Be careful of passengers' feet when

tipping.





►  If the vehicle is so equipped, pull the control

and raise the backrest (from the rear, lower the

handle).

Check that the seat has correctly locked

on the floor when returned to the seating

position.

Fixed rear seat and bench

seat

Combi

,

Business

The different equipment and settings described

hereafter vary according to the version and the

configuration of your vehicle.





The seat has a backrest that may be fixed or

foldable (table position).

The bench seat has a one-piece backrest that

may be fixed or foldable (table position).

For more information on the

Seat belts

,

refer to the corresponding section.

60

Ease of use and comfort

Access to row 3

(example for an individual seat)





►  Using the handle, release the rear feet then

tip the seat forward.

►  To return the seat to the normal position, tip

the seat backwards until the rear feet engage in

their anchorages.

It is not necessary to fold the backrest

(table position) to tip the bench seat and

so access row 3.

Folding the backrest into

the table position

►  Place the head restraints in the low position.





►  From the rear, lower the lever to release the

backrest.

►  From the front, raise the lever to release the

backrest.

►  Fold the backrest onto the seat cushion.

►  To return the backrest to the normal position,

raise the lever and pull the backrest up (from the

rear, lower the lever).

Do not leave objects (such as a bag or

toys) on the seat cushion when folding

the backrest.

Tilting

(example of an individual seat)

►  If your vehicle has the facility, place the

backrest in the table position.





►  Using the handle, release the rear feet then

tip the seat forward.

►  To return the seat to the normal position,

unfold the seat backwards until the rear feet

engage in their anchorages.

Removing

(example of an individual seat)

►  Tip the seat.





►  Release the front feet using the handles.

►  Disengage the seat from its anchorages.

61

Ease of use and comfort

3

►  Remove the seat through the side door for

row 2 or from the rear for row 3.

Refitting

(example of an individual seat)

►  Check that there is no object obstructing the

anchorage points and preventing the feet locking

correctly into place.





►  Engage the front feet in the anchorage points

on the floor (as shown above).





►  Lock the front feet using the levers.

►  Tilt the seat towards the rear until the rear

feet lock into place.

Be careful of passengers' feet during the

manoeuvre.





►  If fitted to your vehicle, pull the control and

raise the backrest (from the rear, lower the

lever).

Check that the seat has correctly

engaged in its anchorage points on the

floor when returned to the sitting position.

Rear seat and bench seat

on rails

Feel

,

Shine

,

Business Lounge

The different equipment and settings described

hereafter vary according to the version and the

configuration of your vehicle.





The individual seat is always on the right and the

bench seat on the left (facing forward).

The seat has an independent backrest and the

bench seat has two independent backrests.

For more information on the

Seat belts

,

refer to the corresponding section.

Adjusting the angle of the

backrest

The reclining backrest can be adjusted to several

positions.





►  To recline the backrest, pull the control

upwards (from the rear, lower the handle).

62

Ease of use and comfort

►  Release the control when the desired position

is reached.

Moving forward or backward

(example for an individual seat)





Two controls are provided for moving the seat

forward and backward:

►  From the rear, pull the strap without going

beyond the point of resistance and push the seat

forward or pull it backward.

►  From the front, raise the control and slide the

seat forward or backward.

Moving the seat along the

full length of the rail





►  Slide the seat by pulling on the front control

or rear strap.

Folding the backrest to the

table position

(example for an individual seat)

►  Put the head restraints in the low position.





►  From the rear, lower the handle to release the

backrest.

►  From the front, raise the handle to release

the backrest.

►  Fold the backrest onto the cushion.

Do not leave objects (such as a bag or

toys) on the cushion when folding the

backrest.

Removing

(example of an individual seat)

►  Move the seat forward for access to the

strap.

►  Fold the backrest to the table position





►  From the rear, pull the strap fully to release

the anchorages and tip the seat forwards to

place it in the vertical position.

►  Remove the seat through the side door for

row 2 or through the rear for row 3.

63

Ease of use and comfort

3

Refitting





Before refitting the seat or bench seat in

the vehicle, pull the strap fully to ensure

that the latching mechanism has engaged.





Do not use the strap to lift the seat or

bench seat.

(example of an individual seat)

►  Check that nothing is obstructing the rails.





►  Place the front part of the guides on the rails.

►  Tip the seat to align the rear of the guides in

the rails.

►  Slide the seat forwards or backwards until it

engages in the notches.

►  Raise the backrest.

Check that the seat has correctly locked

on the floor when returned to the seating

position.

Individual rear seat(s) on

rails

Shine

,

Business Lounge

The different equipment and settings described

hereafter vary according to the version and the

configuration of your vehicle.





The individual seat is fitted with a three-point

inertia reel seat belt.

It can be placed facing

forwards

 or facing

rearwards

.

If there is an individual seat facing

rearwards in row 2, ensure that the seat

in row 1 (driver or passenger) is not set too

far back, in order to avoid contact between

the two seats.

This could cause significant wear of the parts

which are in contact.

For more information on the

Seat belts

,

refer to the corresponding section.

Armrest(s)

The armrest has notches.



64

Ease of use and comfort



►  Pull the armrest fully up.

►  Lower it fully.

►  Raise the armrest to the desired notched

position.

Adjusting the angle of the

backrest

The backrest can be adjusted to several

positions.





►  To recline the backrest, pull the control

upwards (from the rear, lower the handle).

►  Release the control when the desired position

is reached.

Moving forward or backward





Two controls are provided for moving the seat

forward and backward:

►  From the rear, pull the strap without going

beyond the point of resistance and push the seat

forward or pull it backward.

►  From the front, raise the control and slide the

seat forward or backward.

Folding the backrest to the

table position





Ensure that nothing (examples: bag,

case, toy, folding and sliding table) is

interfering with the operation to fold the

backrest.

►  Put the head restraints in the low position.





►  From the rear, lower the handle to release the

backrest.

►  From the front, raise the handle to release

the backrest.

►  Fold the backrest onto the cushion.

Removing

►  Move the seat forwards for access to the

strap.

►  Fold the backrest to the table position.





►  From the rear, pull the strap beyond the point

of resistance to release the anchorages and

65

Ease of use and comfort

3

tip the seat forwards to place it in the vertical

position.

►  Remove the seat through the side door for

row 2 or through the rear for row 3.

Changing the direction of

the seat





When the seat is removed, your can rotate it by

180°.

Refitting





Before refitting the seat in the vehicle,

pull the strap fully to ensure that the

latching mechanism has engaged.





Do not use the strap to lift the seat.

►  Check that nothing is obstructing the rails.





►  Fit the front part on the rails.

►  Tip the seat to align the rear of the guides in

the rails.

►  Slide the seat forwards or backwards until it

engages in the notches.

►  Raise the backrest.

Check that the seat has correctly locked

on the floor when returned to the seating

position.

Fixed crew cab





The crew cab is made up of a fixed bench seat,

seat belts, storage compartments (depending

on equipment) and side windows. It is separated

from the

loading area

 by a high-strength

partition.

Rear bench seat

This ergonomic bench seat has three seats.
