Citroën Jumpy-Dispatch (2022 year). Manual in english - page 3

34

Access

If the vehicle is not fitted with an alarm,

deadlocking is confirmed by fixed

illumination of the direction indicators for

about two seconds.

With Keyless Entry and Start on your

person

To lock the vehicle, the remote control must be in

recognition zone

A

.





►  To lock the vehicle

fully

, press the markings

on one of the door handles (front door(s),

manual sliding side door(s) or left-hand side-

hinged door).

►  To deadlock the vehicle, press the markings

again

within five seconds.

With electric sliding side door(s)

►  With the Keyless Entry and Start on your

person, to lock the vehicle

fully

, press the

markings on one of the

front

 door handles.

►  To deadlock the vehicle, press the markings

again

within five seconds.

With tailgate





►  With the Keyless Entry and Start on your

person, press the tailgate locking control to lock

the

entire

 vehicle.

►  To deadlock the vehicle, press the control

again

within five seconds

.

If the vehicle is not fitted with an alarm,

deadlocking is signalled by fixed lighting

of the direction indicators for approximately

two seconds.

Back-up procedures

Lost keys, remote control,

electronic key

Go to a CITROËN dealer with the vehicle's

registration certificate, your personal

identification documents and if possible, the label

bearing the key code.

The CITROËN dealer will be able to retrieve the

key code and the transponder code, enabling a

new key to be ordered.

Complete unlocking/locking

of the vehicle with the key

Use this procedure in the following situations:

–  Remote control battery discharged.

–  Remote control malfunction.

–  Vehicle battery discharged.

–  Vehicle in an area subject to strong

electromagnetic interference.

In the first case, change the remote control

battery.

In the second case, reinitialise the remote

control.

Refer to the corresponding sections.

►  Insert the key into the door lock.

►  Turn the key towards the front/rear to unlock/

lock the vehicle.

►  Turn the key towards the rear again within

5 seconds to deadlock the vehicle.

If the vehicle is fitted with an alarm, it will

not be activated when locking with the

key.

If the alarm is activated, the siren sounds

when the door is opened; switch on the

ignition to stop it.

If the vehicle is unlocked with the key in

the lock

after locking it with the remote

control or the Keyless Entry and Start

35

Access

2

system

,

all doors and the boot

 are

unlocked.

If the vehicle is unlocked with the key in the

lock

after locking it with the key

, only the

doors (front door and sliding side door(s)) are

unlocked. The side-hinged doors and tailgate

are not unlocked. Switching on the ignition

unlocks them.

Central locking not

functioning

Use these procedures in the following cases:

–  Central locking malfunction.

–  Battery disconnected or discharged.

In the event of a malfunction of the

central locking system, the battery must

be disconnected to ensure that the vehicle is

locked fully.

Front left-hand door

►  Insert the key into the door lock.

►  Turn the key towards the rear of the vehicle

to lock it, or towards the front to unlock it.

Front passenger door and sliding

side door

Unlocking

►  Pull the interior door opening handle.

Locking

►  Open the door.

►  For the side door, check that the child lock is

not on. Refer to the corresponding section.





Front passenger door





Sliding side door

►  Remove the black cap on the edge of the

door, using the key.

►  Insert the key in the aperture without

forcing it, then without turning it, move the latch

sideways towards the inside of the door.

►  Remove the key and refit the black cap.

►  Close the doors and check from the outside

that the vehicle is locked.

Side-hinged doors

Unlocking

►  Use the interior opening handle.

Locking

►  If fitted to your vehicle, check that the electric

child lock is not on.

►  Open the left-hand side-hinged door.





►  Insert the key into the latch aperture on the

edge of the door (without forcing it) and slide the

assembly upwards.

►  Remove the key.

►  Close the door and check from the outside

that the vehicle is locked.

Unlocking the tailgate





►  From inside the vehicle, insert a small

screwdriver into hole

A

 on the lock to unlock the

tailgate.

►  Move the latch to the left.

If the fault persists after closing again,

the tailgate will remain locked.

36

Access

Changing the battery

If the battery is flat, this warning lamp

comes on, accompanied by an audible

signal and the display of a message.

Battery type: CR2032/3 volts.





►  Unclip the cover by inserting a small

screwdriver in the slot and lift the cover.

►  Remove the flat battery from its housing.

►  Put the new battery in place, respecting the

polarity. Start by inserting it into the contacts

located in the corner, then clip the cover onto

the unit.

►  Reinitialise the remote control.

For more information on

Reinitialising the

remote control

, refer to the corresponding

section.

Do not throw remote control batteries

away, as they contain metals that are

harmful to the environment. Take them to an

approved disposal point.

Reinitialising the remote

control

Following replacement of the battery or in

the event of a fault, it may be necessary to

reinitialise the remote control.

Without Keyless Entry and Start





►  Switch the ignition off.

►  Turn the key to position

2 (Ignition on)

.

►  Immediately press the closed padlock button

for a few seconds.

►  Switch off the ignition and remove the key

from the ignition switch.

The remote control is now fully operational

again.





►  Insert the mechanical key (incorporated into

the remote control) into the lock to open the

vehicle.

►  Place the electronic key against the back-up

reader on the steering column and hold it there

until the ignition is switched on.

►

With a manual gearbox,

 place the gear lever

in neutral then fully depress the clutch pedal.

►

With an automatic gearbox or drive

selector

, while in mode

P

, depress the brake

pedal.

►  Switch on the ignition by pressing the

"

START/STOP

" button.

If the fault persists after reinitialisation, contact a

CITROËN dealer or a qualified workshop without

delay.

37

Access

2

Central locking









Manual

►  Press this button to lock/unlock the vehicle

(doors, tailgate or side-hinged doors) from inside

the passenger compartment.

The indicator lamp comes on to confirm the

central locking of the vehicle.

Central locking does not take place if any

of the doors are open.

When locking/deadlocking from the

outside

When the vehicle is locked or deadlocked

from the outside, the indicator lamp flashes

and the button is deactivated.

►  After normal locking, pull one of the

interior door controls to unlock the vehicle.

►  After deadlocking, you must use the

remote control, the "Keyless Entry and

Start" system or the built-in key to unlock the

vehicle.

Driving with the doors locked makes

access for the emergency services more

difficult in an emergency.





When transporting an oversized load

(tailgate or side-hinged doors open),

press the button to lock only the cab doors.





When transporting an oversized load

(tailgate or side-hinged doors open),

press the button to lock only the front and rear

doors (sliding side door).

When locking from inside, the door

mirrors do not fold.

Central locking from the inside does not

operate if one of the doors is open (indicated

by a mechanical noise coming from the

locks).

When the tailgate or side-hinged doors are

open, only the other doors are locked (the

button does not light up).

Automatic (anti-intrusion

security)

The doors and the tailgate or the side-hinged

doors can lock automatically while driving (speed

above 6 mph (10 km/h)).

To deactivate/reactivate this function (activated

by default):

►  Press the button until an audible signal is

heard and/or a message appears on the screen.

Locking/unlocking the

loading area













This button is unavailable if the vehicle

has been locked or deadlocked from

outside (using the key, remote control or

Keyless Entry and Start, depending on

equipment) or if any of the doors are still

open.

38

Access

Automatic

The

loading area

 is always locked when driving.

To deactivate this automatic locking, go

to a CITROËN dealer or a qualified

workshop.

Manual

►  With complete unlocking activated,

press this button to lock (indicator lamp

comes on)/unlock (indicator lamp goes off) the

vehicle

.

►  With selective unlocking activated, press this

button to lock (indicator lamp comes on)/unlock

(indicator lamp goes off) the

loading area

.

Driving with the doors locked could make

it more difficult for the emergency

services to enter the vehicle in an emergency.

The indicator lamp goes off when

unlocking one or more doors of the

loading area

.

With the ignition off and the vehicle fully

locked, the indicator lamp goes off for energy

economy reasons.

Electric sliding side

door(s)

The exterior and interior door handles and the

interior buttons allow the electrically powered

movement of the door to be started.

Opening and closing of the doors is

accompanied by an audible signal.

Opening

With the exterior or interior handle





►  With the door unlocked, pull and release the

handle to start opening the door. Pull the handle

again to reverse the direction of the door's

movement.

With the remote control





►  With the door unlocked, press and

hold this button until the corresponding

sliding side door has opened.

►  Press this button again to reverse the

direction of the door's movement.

The remote control buttons are not active

with the ignition switched on.

With the button(s) on the door pillar









With the button(s) at the front









►  With total unlocking activated and the child

lock deactivated, to unlock the vehicle and start

39

Access

2

opening a door, press the button corresponding

to the door you wish to open.

►  With selective unlocking activated, to unlock

only the

loading area

 and start opening a door,

press the button corresponding to the door you

wish to open.

►  In both cases, pressing the button again

reverses the direction of the door's movement.

Closing

With the exterior handle





►  Pull and release the handle to start closing

the door. Pull the handle again to reverse the

direction of the door's movement.

With the remote control

►  Press and hold this button until the

sliding side door has closed. Pull the

handle again to reverse the direction of the

door's movement.

The remote control buttons are not active

with the ignition switched on.

With the button(s) on the door pillar









With the button(s) at the front









►  To start closing a door, press the

corresponding button for that door. Press again

to reverse the direction of the door's movement.

The button is not operational and

pressing it results in an audible signal, if

the speed of the vehicle is above 20 mph (30

km/h).

The button(s) at the front or on the door

pillar is not operational and pressing it

results in an audible signal, if:

–  the vehicle is moving,

–  the child lock is on (activated) (for the

buttons on the door pillars),

–  the vehicle has been locked or deadlocked

from outside (using the key, remote control

or Keyless Entry and Starting, depending on

equipment).

The button for the left-hand door is not

operational and pressing it results in an

audible signal if the fuel filler flap is open.

General

recommendations for the

sliding side doors

Doors must only be operated when the

vehicle is stationary.

For your safety and that of your passengers,

as well as for correct operation of the doors,

you are strongly advised not to drive with a

door open.

Always check that it is safe to operate the

door and in particular, be sure not to leave

children or animals near the door controls

without supervision.

The audible warning, the lighting of the "door

open" warning lamp and the message on the

screen are there to remind you. Contact a

40

Access

CITROËN dealer or a qualified workshop if

you want to deactivate this warning.

Lock the vehicle when you use an automatic

car wash.

Before opening or closing and while

moving doors, ensure that no person,

animal or object is in the door frame or any

other position that would block the desired

movement, inside or outside the vehicle.

If this advice is not followed, injuries or

damage may occur if any part of a person or

an object is trapped or caught.

Electrical door opening is disabled at speeds

above 2 mph (3 km/h):

–  However, if the vehicle started moving

while the doors were open, the speed must

be reduced below 19 mph (30 km/h) before

they can be closed.

–  Any attempt to open a door electrically

using the interior handle while driving results

in it only being possible to open the door

manually.

–  This situation is accompanied by the

audible warning, the lighting of the "door

open" warning lamp and the message on the

screen. To release the door and be able to

operate it again, it is necessary to stop the

vehicle.

Take care not to block the guide space

on the floor so that the door can slide

correctly.

For safety and functional reasons, do not

drive with the sliding side door open.

The electric controls are disabled in the

event of an impact. Manual opening and

closing remain possible.

While starting the engine, door

movements are paused, resuming when

the engine is running.

Depending on the engine fitted, if

the door is closed and an opening

request is issued in Stop mode of Stop &

Start, the door will open slightly and then

stop. In Start mode, the door will resume its

movement when the engine re-starts.

To hold the sliding side door in the open

position, open the door fully to engage

the latch (located at the bottom of the door).

Doors and door clearances





When open, a door projects beyond the body.

Allow adequate clearance when parking

alongside walls, lamp-posts, high pavements,

etc.





When open, a door never projects

beyond the rear bumper.

41

Access

2

Safety/Obstacle detection

with electric door(s)





The obstacle detection system is triggered when

the moving door encounters an obstacle with a

certain level of physical resistance. If an obstacle

is detected:

–  while the door is closing, the door stops then

opens fully.

–  while the door is opening, the door stops then

closes.

–  twice in succession during a movement of the

door, the door will no longer close electrically

(uninitialisation).

On a steep slope: a safety system slows down

the movement of the door.

In all cases, wait a few seconds before operating

the door (closing or opening).

Close the door manually for safety reasons.

Then reinitialise the door.

Reinitialising electric doors

If electrical operations no longer work:

►  Fully close the door(s)

manually

.

►  Fully open the door(s)

electrically

.

►  Close the door(s)

electrically

.

On completion of this procedure, electric

operation of the doors is restored.

However, if a problem persists following this

procedure, contact a CITROËN dealer or a

qualified workshop.

On a steep slope





It is possible to open and close the doors

electrically on slopes of up to a 20% gradient.

If the vehicle is on a slope, with the front of the

vehicle facing up the slope, open the door with

care. The door may open more quickly due to

the incline.

On a steep slope, guide the side door manually

to help it to close.





If your vehicle is on a slope, with the front of the

vehicle facing down the slope, the door may not

stay open and may close

violently

 with the risk

of injury.

In the case of a steep slope, the door

may be driven by its own weight and as a

consequence may open or close

violently

.

There would not be time for action at the

electric controls to take effect.

There would not be time for the obstacle

detection system to react.

Take care not to leave the vehicle on a

steep slope with the door(s) open without

supervision. If this advice is not followed,

injuries or damage may occur if a person or

an object is trapped or caught.

42

Access

Hands-free sliding side

door(s)

Opening/Closing





With a movement of your foot while keeping the

remote control on your person in the recognition

zone

A

, the system unlocks and opens the

sliding side door or closes and locks it.

The remote control must be located at the rear

of the vehicle, at least about 30 cm but no more

than about 2 m from the vehicle.

The automatic locking after closing the

door can be programmed in the vehicle

configuration menu.

Before making the movement with your

foot, ensure that you are steady and well

positioned, so that you do not lose your

balance (rain, snow, ice, mud, etc.).

Take care not to touch the exhaust tailpipe

when making the movement with your foot -

risk of burns.





►  Put your foot beneath the corner of the rear

bumper, then move the foot at normal speed with

a sweeping side movement.

The sensor detects the foot approaching and

leaving and triggers the opening or closing of the

side door.

Make the movement without interruption

and do not repeat it immediately

afterwards or several times.

If the door does not open, wait about

2 seconds before trying again.

Do not keep the foot in the air.

Confirmation that the door is going to

open or close is signalled by the direction

indicators flashing for a few seconds,

accompanied by an audible signal.

The movement of the door is reversed if the

movement of the foot takes place during the

manoeuvre.

If the vehicle is so equipped, the electric door

mirrors fold/unfold on locking/unlocking the

vehicle.

Automatic locking

The vehicle locks itself following the hands-free

closing of the sliding door.

If your vehicle is not fitted with an alarm,

locking is signalled by the fixed

illumination of the direction indicators for

about two seconds.

Depending on your version, the door mirrors

fold at the same time.

Activation/Deactivation

With audio system or touch screen

By default, hands-free access is activated.

The "Hands-Free Tailgate Access"

function or automatic vehicle

locking when the sliding door is closed is

activated and deactivated via the vehicle

configuration menu.

43

Access

2

Malfunction

An audible signal repeated three times while

using the function indicates a fault with the

system.

Have it checked by a CITROËN dealer or a

qualified workshop.

If the "

Hands-free tailgate access

self-locking

" option is selected in the

vehicle menu and after closing the door,

check that the vehicle is properly locked.

Locking will not take place:

–  if the ignition is on,

–  if one of the doors or the tailgate is open,

–  if a "Keyless Entry and Start" remote

control is inside the vehicle.

If a number of gestures with your foot have

no effect, wait a few seconds before starting

again.

The system is automatically deactivated in

heavy rain or with accumulations of snow.

If it does not work, make sure that the

remote control is not exposed to a source of

electromagnetic interference (smartphone,

etc.).

Operation may be affected if using a

prosthetic leg.

This system may not work correctly if your

vehicle is fitted with a towbar.

The side door may open or close without

warning if:

–  Your vehicle is fitted with a towbar.

–  A trailer is coupled or decoupled.

–  A bicycle carrier is installed or removed.

–  Bicycles are loaded on to or unloaded from

the bicycle carrier.

–  Something is deposited or lifted behind the

vehicle.

–  An animal approaches the bumper,

–  The vehicle is washed.

–  The vehicle is being serviced.

–  A wheel is changed.

To avoid any sudden operation, keep the key

away from the detection zone (also from the

boot’s interior sides) or deactivate the function

in the vehicle configuration menu.

Ensure that no person or object might

prevent the correct opening or closing of

the doors.

Be aware of children when operating the

doors.

Side-hinged rear doors





►  After first opening the left-hand door, pull the

lever

A

 towards you to open the right-hand door.

Closing

►  First close the right-hand door, then the left-

hand door.

If the left-hand door is closed first, a

buffer stop located on the edge of the

right-hand door prevents it closing.

If the left-hand side-hinged door is not properly

closed, the "

door open

" warning lamp lights up

44

Access

(the right-hand door is not detected). For more

information on the

List of warning lamps

 and,

in particular, the door open warning, refer to the

corresponding section.

Opening to approximately

180°





If fitted to your vehicle, a check strap system

allows the doors to be opened from about 90° to

about 180°.

►  Pull the yellow control when the door is open.

The check strap will engage again automatically

on closing.

When parked with the rear doors open to

90°, the doors will cover the rear lamps.

In order to warn other road users travelling in

the same direction (who may not be aware

that the vehicle is stationary) of the vehicle's

position, use a warning triangle or other

device required by legislation and regulations

in your country.

Tailgate

Opening





►  After unlocking the vehicle, pull the handle,

then raise the tailgate.

Closing

►  Lower the tailgate using the interior grab

handle, then lock it.

If the tailgate is not properly closed, the "

door

open

" warning lamp comes on. For more

information on the

list of warning and indicator

lamps

, and in particular the door open warning,

refer to the corresponding section.

In the event of a malfunction or if you

experience difficulty opening or closing

the tailgate, have it checked by a CITROËN

dealer or a qualified workshop without delay,

to avoid the issue deteriorating and prevent

any risk of the tailgate dropping, potentially

causing serious injury.

Tailgate rear screen

The opening rear screen allows you to access

the rear of the vehicle directly, without having to

open the tailgate.

Opening





After unlocking the vehicle, press this control and

lift the rear screen to open it.

Closing

Close the rear screen by pressing the centre of

the glass until it is fully closed.

If the tailgate rear screen is not properly closed,

the "

door open

" warning lamp comes on. For

more information on the

list of warning and

45

Access

2

indicator lamps

 and in particular the door open

warning, refer to the corresponding section.

The tailgate and rear screen cannot both

be open at the same time, to avoid

damaging them.

Alarm





(Depending on version)









System which protects and provides a deterrent

against theft and break-ins.

Exterior perimeter monitoring

The system checks for opening of the vehicle.

The alarm is triggered if anyone tries to open a

door, the boot or the bonnet, for example.

Interior volumetric monitoring

The system only checks for any

variation in volume in the

cab

.

The alarm is triggered if anyone

breaks a window or enters the

vehicle’s

cab

; however it is not

triggered if someone enters the

loading area

.

The system checks for any

variation in volume in the

passenger compartment.

The alarm is triggered if anyone

breaks a window, enters the

passenger compartment or

moves inside the vehicle.

Self-protection function

The system checks whether any of its

components are out of service.

The alarm is triggered if the battery, the central

control or the siren wiring is put out of service or

damaged.

Work on the alarm system

Contact a CITROËN dealer or a qualified

workshop.

If your vehicle is fitted with Additional

Heating / Ventilation, volumetric

monitoring is not compatible with this system.

For more information on

Additional Heating

/ Ventilation

, refer to the corresponding

section.

Locking the vehicle with full

alarm system

Activation

►  Switch off the ignition and exit the vehicle.

►  Lock or deadlock the vehicle using the

remote control or with the Keyless Entry and

Start system.

When the monitoring system is active, the red

indicator lamp in the button flashes once per

second and the direction indicators come on for

about 2 seconds.

The exterior perimeter monitoring is activated

after 5 seconds and the interior volumetric

monitoring after 45 seconds.

If an opening (door, tailgate/side-hinged

doors or bonnet) is not properly closed,

the vehicle is not locked, but the exterior

perimeter monitoring will be activated after 45

seconds, at the same time as the interior

volumetric monitoring.

46

Access

Deactivation

►  Press the remote control unlocking

button.

or

►  Unlock the vehicle with the Keyless Entry and

Start system.

The monitoring system is deactivated: the

indicator lamp in the button goes off and the

direction indicators flash for about 2 seconds.

If the vehicle automatically locks itself

again (as happens if a door or the boot is

not opened within 30 seconds of unlocking),

the monitoring system is automatically

reactivated.

Triggering of the alarm

This is indicated by sounding of the siren

and flashing of the direction indicators for 30

seconds.

The monitoring functions remain active until

the alarm has been triggered ten times in

succession.

When the vehicle is unlocked, rapid flashing of

the indicator lamp in the button indicates that the

alarm was triggered during your absence. When

the ignition is switched on, this flashing stops

immediately.

Locking the vehicle

with exterior perimeter

monitoring only

Deactivate the interior volumetric monitoring to

avoid the unwanted triggering of the alarm, in

certain cases such as:

–  Slightly open window.

–  Washing the vehicle.

–  Changing a wheel.

–  Towing the vehicle.

–  Transport on a ship or ferry.

Deactivating interior volumetric

monitoring

►  Switch off the ignition and within 10 seconds

press the alarm button until the indicator lamp is

on fixed.

►  Exit the vehicle.

►  Immediately lock the vehicle using the remote

control or the "Keyless Entry and Start" system.

Only exterior perimeter monitoring is activated;

the red indicator lamp in the button flashes every

second.

To take effect, this deactivation must be

performed whenever the ignition is switched

off.

Reactivating interior volumetric

monitoring

►  Deactivate exterior perimeter monitoring by

unlocking the vehicle using the remote control or

the "Keyless Entry and Start" system.

The indicator lamp in the button goes off.

►  Reactivate the full alarm system by locking

the vehicle using the remote control or the

"Keyless Entry and Start" system.

The red indicator lamp in the button once again

flashes every second.

Locking the vehicle without

activating the alarm

►  Lock or deadlock the vehicle using the key

(integral to the remote control) in the driver's

door lock.

Failure of the remote control

To deactivate the monitoring functions:

►  unlock the vehicle using the key (integral to

the remote control) in the driver's door lock,

►  Open the door; this sets off the alarm.

►  Upon switching on the ignition the alarm

stops. The button indicator lamp goes off.

Malfunction

When the ignition is switched on, the fixed

lighting of the red indicator lamp in the button

indicates a system malfunction.

Have it checked by a CITROËN dealer or a

qualified workshop.

47

Access

2

Automatic activation

(Depending on version)

The system is activated automatically 2 minutes

after the last door or the boot is closed.

►  To avoid triggering the alarm on entering the

vehicle, first press the unlocking button on the

remote control or unlock the vehicle using the

"Keyless Entry and Start" system.

Electric windows

1.

Left-hand front.

2.

Right-hand front.

Operation

►  To open/close the window manually, press/

pull the switch without passing the point of

resistance; the window stops as soon as the

switch is released.

►  To open/close the window automatically,

press/pull the switch fully, beyond the point of

resistance; the window opens/closes completely

when the switch is released (pressing the switch

again stops the movement of the window).

The electric window controls remain

operational for about 45 seconds after

the ignition is switched off if the front doors

are not open.

After that time, the controls are disabled. To

reactivate them, switch the ignition on again.

Safety anti-pinch

If your vehicle is fitted with the safety anti-pinch

function, when the window rises and meets an

obstacle, it stops and partially lowers.

In the event of unwanted opening of the window

on closing, press the control until the window

opens completely. Within 4 seconds, pull the

control until the window closes.

The safety anti-pinch does not operate while

doing this.

Reinitialising the electric

windows

After reconnecting the battery, or in the event

of abnormal window movement, the anti-pinch

function must be reinitialised.

The anti-pinch function is disabled during the

following sequence of operations.

For each window:

►  Lower the window fully, then raise it; it will

rise in steps of a few centimetres each time the

control is pressed. Repeat the operation until the

window is fully closed.

►  Continue to pull the control for at least one

second after the window reaches the closed

position.

If an electric window meets an obstacle

during operation, the movement of the

window must be reversed. To do this, press

the relevant control.

When the driver operates the passenger

electric window control, it is important to

ensure that nothing can prevent the window

from closing properly.

Pay particular attention to children when

operating the windows.

Do not put your head or arms through the

open windows when the vehicle is moving -

risk of serious injury!

48

Ease of use and comfort

Correct driving position

Before taking to the road and to make the most

of the ergonomic layout of the instruments and

controls, carry out these adjustments in the

following order:

–  the height of the head restraint,

–  the seat backrest angle,

–  the seat cushion height,

–  the longitudinal position of the seat,

–  the height and reach of the steering wheel,

–  the rear view mirror and door mirrors.





Once these adjustments have been

made, check the instrument panel can be

viewed correctly from your driving position.

Manually-adjusted front

seats

For more information on the

Seat belts

,

refer to the corresponding section.

Longitudinal





►  Raise the control bar and slide the seat

forwards or backwards.

►  Release the control bar to lock the seat in

position on one of the notches.

Before moving the seat backwards,

ensure that there is nothing that might

prevent the full travel of the seat.

There is a risk of trapping or pinching

passengers if present in the rear seats or

jamming the seat if large objects are placed

on the floor behind the seat.

Height





►  Pull the control upwards to raise or push it

downwards to lower, until you obtain the position

required.

Backrest angle





►  Depending on equipment, turn the knob

or pull the control all the way up and tilt the

backrest forwards or backwards to obtain the

desired angle.

Lumbar





49

Ease of use and comfort

3

►  Turn the knob to obtain the desired level of

lumbar support.

Table position of the driver's

and/or the front passenger

seat backrest





On the front passenger side, this position allows

long objects to be carried.

On the driver's side, this position allows rear

passengers to be helped out of the vehicle (by

the emergency services).

Check that there is no object that could

interfere with the movement of a seat,

both above and below.

►  Place the head restraint in the low position,

and if fitted to your vehicle, raise the armrest and

fold the table fitted to the back of the seat.

We recommend deactivating the front

passenger airbag.





►  Pull the control fully up and tip the backrest

forward.

To return to the normal position, pull the control

up to release the backrest, then pull the backrest

up to its raised position.

When sharp deceleration occurs, objects

placed on the folded backrest can turn

into projectiles.

Electric front seat

To avoid discharging the battery, carry

out these adjustments with the engine

running.

For more information on the

Seat belts

,

refer to the corresponding section.

Longitudinal





►  Push the control forwards or rearwards to

slide the seat.

Before moving the seat backwards,

ensure that there is nothing that might

prevent the full travel of the seat.

There is a risk of trapping or pinching

passengers if present in the rear seats or

jamming the seat if large objects are placed

on the floor behind the seat.

Seat cushion height





►  Tilt the control upwards or downwards to

obtain the desired height.
